Search Results (103)

This article presents an analysis and the modeling of cutting forces in the process of oscillation milling of side surfaces of workpieces made of hardened steel. In addition, the impact of the oscillation machining method on cutting forces was analyzed, taking into account feed optimization. A sinusoidal function was used to describe the trajectory of the tool in order to induce the oscillatory motion. The study is based on a set of 34 cutting tests using four end-mill cutters, each characterized by a unique combination of feed rate and sinusoidal downward and upward angles. This constitutes a novel approach to sine wave period selection. Empirical mathematical models of the cutting forces were developed using the response surface method. The results demonstrate that the sinusoidal trajectory of the tool movement, together with optimization of the feed rate, leads to a reduction in fluctuations and the stabilization of cutting forces, and an approximately 30% increase in the efficiency of this machining process. Full article

The intricate and dynamic cutting behavior observed in titanium alloy turning leads to non-uniform surface and subsurface properties in the workpiece, impacting torsional strength and fatigue life. A transient pose model, founded on the configuration of a turning tool, is developed to elucidate the evolution of the transition surface during transient turning. Through finite element simulation, the plastic deformation, residual stress, and work hardening rate of the machined surface and subsurface of a titanium alloy are quantitatively examined. The torsional strength and fatigue life calculation method is developed based on initial performance parameters derived from the finite element model. This method enables the correlation identification between surface morphology characteristics, surface and subsurface performance parameters, and fatigue properties. Surface morphology, scanning electron microscopy (SEM), and energy-dispersive X-ray spectroscopy (EDS) are employed to quantitatively analyze the surface features and elemental composition of the titanium alloy turning surface, unveiling their influence on torsional fatigue properties. The findings demonstrate the efficacy of the proposed models and methodologies in identifying the torsional fatigue properties and their distribution patterns of titanium alloy turning surfaces. Full article

Springback represents the deflection of a workpiece after releasing the forming tools or dies, which influences the quality and precision of the final products. It is basically governed by the elastic strain recovery of the material after unloading. Most approaches only implement reverse bending to determine the final shape of the formed product. However, stretch plays significant role whe the blank is held by a blank holder. In this paper, an algorithm is presented to calculate the contributions of both stretch loads and bending moments to elastic deformation during springback for each element, and to combine them mathematically and geometrically to achieve the final shape of the product. Comparing the results of this algorithm for different sheet metal forming processes with experimental measurements demonstrates that this technique successfully predicts a wide range of springback with reasonable accuracy. The advantage of this approach is its accuracy, which is not sensitive to hardening and softening mechanisms, the magnitude of plastic deformation during the forming process, or the size of the object. The application of the proposed formulation is limited to long profiles (plane-strain cases). However, it can be extended to more general applications by adding the effect of torsion and developing equations in 3D space. Due to the explicit nature of the calculations, data-processing time would be reduced significantly compared to the sophisticated algorithms used in commercial software. Full article

Cu-based alloys and composites are popular to prepare electroconductive parts. However, their processing can be challenging, especially in case of composites strengthened with oxides. To save the necessary time and costs, numerical simulations can be of help when determining the deformation behaviour of (newly introduced) materials. The study presents a combined method of strengthening of Cu by adding 5 wt.% of La₂O₃ particles and performing shear-based deformation by equal channel angular pressing (ECAP). The effects of the method on the microstructure, mechanical properties, and thermal stability of the composite are examined both numerically and experimentally. The results showed that the La₂O₃ addition caused the maximum imposed strain to be higher for the composite than for commercially pure Cu, which led to the development of subgrains and shear bands within the microstructure, and a consequent increase in microhardness. The numerical predictions revealed that the observed differences could be explained by the differences in the material plastic flow (comparing the composite to commercially pure Cu). The work hardening supported by the addition of La₂O₃ led to a significant increase in stress and punch load during processing, as well as contributed to a slight increase in deformation temperature in the main deformation zone of the ECAP die. Certain inhomogeneity of the parameters of interest across the processed workpiece was observed. Nevertheless, such inhomogeneity is typical for the ECAP process and steps prospectively leading to its elimination are proposed. Full article

The problem of increasing the tool durability (service life) when machining hard-to-machine materials is one of the major practical problems of modern mechanical engineering. This paper aims to improve the wear resistance of modular disk mills using the pre-processing method. Second-order rotatable planning was applied for the experimental study of the pre-processing of modular disk mills. Experimental research on the pre-processing of modular disk mills was carried out on a vertical milling machine XH950A when milling a workpiece made of steel 45. It was revealed that the increase in pre-processing modes up to specific values (f = 60 mm/min; $v_c$ = 17 m/min; t = 6 min) on the tool durability period has a positive effect. At the same time, the tool durability period was increased up to T = 155 min. Tests of the machined modular disk mills were carried out in the conditions of the laboratory base to determine the durability period. After pre-processing at different modes, each modular disk mill was used to machine the workpiece until wear signs appeared on the cutting edge. At the same time, the time was recorded to determine the durability period. It was found that the optimum mode of tool preliminary pre-processing provides the best deformation and thermal conditions for hardening the tool cutting part. As a result of modeling with the ANSYS 2024 R1 program, it was found that a hardened layer is indeed formed on the cutting part of the modular disk mill after pre-processing. The results obtained show the possibility of using the preliminary pre-processing method to improve the wear resistance of other metal-cutting tools. Full article

The formation of surface austenite leads to microstructural changes, causing grinding hardening. However, the effect of grinding mechanical stresses on surface austenitization remains unclear. Additionally, the mechanical properties of the metamorphic layer are crucial for studying grinding hardening. Therefore, in this study, the evolution of the microstructure and corresponding mechanical properties of the grinding surface in 8Cr4Mo4V steel was analyzed. The microstructure of the metamorphic layer was characterized using scanning electron microscopy (SEM) and transmission electron microscopy (TEM). Physical simulation was employed to analyze the effect of mechanical compressive stress on the austenite transformation start temperature (Ac1). Dimensionless analysis, based on nanoindentation results, was conducted to study the mechanical properties of the metamorphic layer. The metamorphic layer in 8Cr4Mo4V steel consists of martensite, retained austenite, and undissolved carbides. The unresolved carbides are distributed within the cryptocrystalline martensite. Increasing the grinding depth and workpiece feed speed results in higher mechanical stress and temperature, which leads to a reduction in Ac1 and a higher content of austenite. The yield strength of the metamorphic layer is 2427 MPa, which is 427 MPa higher than that of the matrix, indicating obvious grinding hardening. Full article

The grind-hardening process is capable of generating a martensitic-based hardened layer on the workpiece surface. The production of a hardened layer can significantly improve the application properties of the workpiece. In fact, theoretical research on the wear process of hardened layers is a powerful key to promoting the grind-hardening process, which is the main focus of the current experimental study. For this purpose, the paper carries out the grind-hardening experiment on AISI 1045 steel first by discovering the formation mechanism of the hardened layer. Then, friction and wear experiments are conducted on hardened workpieces to analyze the influence laws of different conditions on the friction coefficient and wear morphology, as well as its profile. On this basis, combined with the Archard wear model, finite element simulations are carried out on the wear process with different friction conditions. The wear depth is effectively predicted. The results show that the wear depth gradually rises with the increase in friction load and frequency. Additionally, considering different friction conditions, the errors between the predictive and experimental values of the wear depth with both average friction coefficient and variable friction coefficient are 4.36–15.22% and 1.57–10.4%, respectively, which validates theoretical research on the wear resistance of the hardened workpiece. Full article

The surface integrity of grinding has a significant influence on the service performance and life of machined parts. In this study, the influence of grinding parameters and the grit size of the grinding wheel on the surface integrity of the hardened steel, including the roughness, microstructure, and hardness of the subsurface and the residual stress of the ground surface, was comprehensively investigated, and the corresponding mechanisms were revealed. The results show that the roughness perpendicular to the grinding direction was significantly larger than that parallel to the grinding direction due to serious side flow, and increasing the grinding speed or reducing the grinding depth was beneficial for reducing the side flow and thus decreasing the roughness. It was found that the grinding temperature dominated the formation of a harder white layer and a softer black layer, and workpiece speed had the smallest effect on the transition of subsurface microstructure compared to grinding speed and depth. It was also found that the increase in workpiece speed, grinding depth, or grinding speed resulted in a transition from compressive to tensile residual stress or an increase in tensile residual stress, and that grinding wheels with finer grit tended to induce compressive residual stress. This study may help to improve surface integrity by optimizing grinding parameters or facilitating the selection of the optimal grinding wheel. Full article

This work consists of the analysis and design of a LC series resonant inverter with reactive element control for induction heating hardening applications. This novel method uses a current-controlled variable transformer (VT) to control the reflected inductance of the inductor in the resonant, and a magnetic energy recovery switch (MERS) to vary the influence of the capacitor as a reactive power compensation element. This converter topology allows quality factor (Q) or operating frequency $\left(f_{sw}\right)$ to be adjusted, making it possible to harden workpieces of different geometries and materials with a single converter. In the article, the design of both elements will be studied and tested. Experimental results were carried out with a 10 kW induction heating inverter prototype, with a frequency range of 60 kHz to 100 kHz and a quality factor of 6 to 10, measuring efficiencies above 95%. Full article

This study develops an analytical model for the plastic bending of anisotropic sheet materials, incorporating strain-hardening effects. The model, experimentally validated with aluminum alloy samples and digital image correlation, accurately predicts stress–strain distributions, bending moments, and thinning behavior in the bending processes. The results reveal that while plastic anisotropy significantly increases the strain intensity, enhancing it by up to 15% on the inner surface relative to the outer under identical bending radius, it does not affect the position of the neutral layer. Strain hardening, on the other hand, raises the bending moment by approximately 12% and contributes to material thinning, which can reach 3% at smaller bend radii. Furthermore, quantitative analysis shows that decreasing the bend radius intensifies the strain, impacting the final geometry of the workpiece. These findings provide valuable insights for optimizing die design and material selection in forming processes involving anisotropic materials, enabling engineers to more precisely control the force requirements and product dimensions in applications where accurate bending characteristics are critical. Full article

This article deals with a mutual comparison of indexable cutting inserts of the CNMG 120408 type from two different manufacturers during the machining of hardened steel AISI 4337 and austenitic stainless steel AISI 316 L. The main goal is to analyse the different wear processes depending on the difference in the manufacturer’s design and also depending on the properties of the different machined materials. The progress of the wear of the main spine of the tool, the types of wear and the service life of the cutting edge were monitored, with the achievement of the critical value VB_max = 300 µm being the standard. In addition to the wear of the inserts, the production of chips was monitored in terms of their shape, average size and number of chips per 100 g of chips produced. In order to understand the relationships arising from the obtained data, an SEM equipped with an elemental analyser was used to analyse the coating layers and the substrate of the unworn inserts and the types of wear and the intensity of the surface damage of the worn inserts. A several-fold difference in the lifetime of the cutting edge was found, both in terms of design and in terms of the selected machined material, while in both cases the cutting edge with Al₂O₃ and TiCN layers of half thickness achieved a better result in liveness. From the point of view of chip formation, very similar results in shape and average length were observed despite the different designs of chip breakers. Cutting inserts with half the thickness of the coating layers achieved longer cutting edge life in the non-primary material application compared to the target workpiece material. At the same time, it was observed that a thinner coating layer has a positive effect on chip formation in terms of its length and shape. Full article

The AMg6 alloy, which belongs to the Al–Mg–Mn system, has high corrosion resistance in various environments, good weldability, and good mechanical properties. During analytical and experimental studies, it was established that the AMg6 alloy, when deformed in the temperature range of 130–175 °C, has high plastic properties and can withstand large degrees of deformation without destruction and crack formation. At the same time, its microstructure retains the texture of deformation, and the hardness of the alloy increases, which indicates its deformation hardening. The article presents the results of numerical and laboratory experiments on upsetting of 20 mm diameter workpieces from a heating temperature of 20, 130, 260 and 390 °C. Using numerical experiments, the dependences of deformation heating on the upsetting rate and the initial temperature of the workpiece were obtained. Deformation heating should be taken into account when choosing heating before deformation since it can be critical in terms of overburning and loss of plastic properties and corrosion resistance of finished products. The deformation behavior of the AMg6 alloy at a heating temperature of the workpiece up to 130–175 °C, revealed in this study, indicates the prospects for conducting additional research on the study of changes in the microstructure and mechanical properties of this alloy during warm deformation. Full article

The intensive quenching process compared to traditional methods results in a lower quenching cracking tendency. The comprehensive mechanical properties of an intensive quenching workpiece has good advantages. In order to improve the performance and product quality of a 45 steel workpiece, the hardening–tempering treatment used in the traditional quenching process is replaced by an intensive quenching process. This study investigates the tribological properties of 45 steel and their differences and connection under the intensive quenching and high-temperature tempering process in comparison to when under the traditional hardening–tempering process. Both intensive quenching and tempering and hardening–tempering workpieces are composed of carburized particles and ferrite. Compared with hardening–tempering workpieces, intensive quenching and high-temperature tempering workpieces have a finer and more uniform microstructure and higher hardness, impact toughness, and yield strength. Wear tests show that intensive quenchingand tempered specimens have better wear resistance. At the same frequency, the coefficient of friction and relative wear rate of the intensive quenching and tempering specimens were lower than those of the hardening–tempering treatment, and the wear surface was flatter. The wear morphology shows that the main wear mechanisms of the intensive quenching and tempering workpieces and those of hardening–tempering are abrasive and adhesive wear, and that the main wear mechanism changes from adhesive wear to abrasive wear as the frequency increases. Full article

Nickel-based superalloys (GH4169) are a typical difficult-to-machine material with poor thermal conductivity and severe work hardening. They are also prone to poor surface quality, severe tool wear, and poor machinability, which affect their performance. In this paper, an experimental study of GH4169 ultrasonic elliptical vibratory ultra-precision cutting was carried out. The experimental results show that ultrasonic elliptical vibratory cutting (UEVC) significantly reduces surface roughness and improves surface quality compared to conventional cutting (CC). The effects of cutting parameters such as cutting speed, feed rate, cutting depth, ultrasonic amplitude, and tool nose radius on the surface roughness of GH4169 workpieces were further investigated in UEVC. Based on the analysis of the experimental data, the optimal combination of parameters for GH4169 ultrasonic elliptical vibration ultra-precision cutting was determined: cutting speed of 3 m/min, feed rate of 16 μm/rev, cutting depth of 2 μm, ultrasonic amplitude of A_y = 3.0 μm, A_z = 0.8 μm, and a tool nose radius of 0.8 mm. This parameter combination improves the machining quality of GH4169 and provides a valuable reference for the subsequent development of ultrasonic elliptical vibratory cutting for other difficult-to-machine materials. Full article

Cooling–lubricating processes have a big impact on cutting force, tool wear, and the quality of the machined surface, especially for hard-to-machine superalloys, so the choice of the right cooling–lubricating method is of great importance. Nickel-based superalloys are among the most difficult materials to machine due to their high hot strength, work hardening, and extremely low thermal conductivity. Previous research has shown that flood cooling results in the least tool wear and cutting force among different cooling–lubricating methods. Thus, the effects of the flood oil concentration (3%; 6%; 9%; 12%; and 15%) on the above-mentioned factors were investigated during the slot milling of the GTD-111 nickel-based superalloy. The cutting force was measured during machining with a Kistler three-component dynamometer, and then after cutting the tool wear and the surface roughness on the bottom surface of the milled slots were measured with a confocal microscope and tactile roughness tester. The results show that at a 12% oil concentration, the tool load and tool wear are the lowest; even at an oil concentration of 15%, a slight increase is observed in both factors. Essentially, a higher oil concentration reduces friction between the tool and the workpiece contact surface, resulting in reduced tool wear and cutting force. Furthermore, due to less friction, the heat generation in the cutting zone is also reduced, resulting in a lower heat load on the tool, which increases tool life. It is interesting to note that the 6% oil concentration had the highest cutting force and tool wear, and strong vibration was heard during machining, which is also reflected in the force signal. The change in oil concentration did not effect the surface roughness. Full article
