Percentage depth–dose (PDD) distributions are fundamental to characterizing radiation beams in radiotherapy. This review provides an overview of both methods and sensor technologies for measuring PDD in photon, electron, proton, and carbon-ion beams. We summarize conventional dosimetry techniques, including water-phantom scanning with ionization chambers (cylindrical and parallel-plate) and radiochromic film, and discuss their strengths (established accuracy, calibration traceability) and limitations (volume averaging, delayed readout). We then examine emerging sensor technologies designed to improve spatial resolution, speed, and radiation hardness: multi-layer ionization chambers and Faraday cups for one-shot PDD acquisition; scintillator-based detectors (liquid, plastic, and fiber-optic) enabling real-time and high-resolution depth–dose measurements; advanced semiconductor detectors including silicon carbide diodes; as well as novel approaches such as ionoacoustic range sensing for proton beams. For each modality and detector type, we emphasize clinical relevance, measurement accuracy, spatial resolution, radiation durability, and suitability for high dose-per-pulse environments (e.g., FLASH radiotherapy). Current challenges, such as detector response in regions of steep dose gradient, saturation or recombination at ultra-high dose rates, and energy-dependent sensitivity in mixed radiation fields, are analyzed in detail. We also highlight the limitations of each technique and discuss ongoing improvements and prospects for clinical implementation. In summary, no single detector technology fully satisfies all requirements for fast, high-accuracy, high-resolution, radiation-hard PDD measurement, but the integration of emerging sensor innovations into clinical dosimetry promises to enhance the precision and efficiency of radiotherapy quality assurance. Full article

This study presents a detailed electrical analysis of AlGaN/GaN/Si HEMTs grown by molecular beam epitaxy, using direct and pulse current, small-signal microwave, and deep-level transient spectroscopy (DLTS) techniques to investigate transport characteristics and defect-related effects. DC measurements revealed self-heating effects and leakage currents, while RF analysis highlighted the devices’ high-frequency capabilities alongside parasitic effects linked to deep-level traps. Pulsed I–V characterization demonstrated gate-lag and drain-lag behaviors associated with dynamic charge trapping. DLTS identified electron traps, emphasizing their critical role in device degradation and switching performance. The strong correlation between trap states and electrical behavior underlines the importance of defect control for enhancing efficiency and reliability. Full article

Gas ionization chambers face significant challenges in diagnosing laser-accelerated proton beams due to severe space charge effects induced by high peak currents and broad energy dispersion. These effects typically cause electric field distortion, signal saturation, and non-linear responses. In this study, we propose an optimized ionization chamber design that effectively mitigates space charge through a rigorous co-simulation approach. We combined ANSYS for macroscopic electrostatic field optimization with Garfield++ for microscopic charge transport modeling, explicitly incorporating ionization (Heed++) and electron drift/diffusion (Magboltz) processes. A systematic finite element modeling workflow—including gas volume meshing and the removal of dielectric components—was implemented to eliminate field non-uniformities and dielectric charging effects. Crucially, we validated the design’s performance against Boag’s theoretical recombination model. While theoretical calculations predict severe saturation (<80% efficiency) for standard chambers under high-flux conditions (10⁷ protons/pulse), our simulation results demonstrate a strictly linear response with charge collection efficiency consistently exceeding 99.85%. Parametric studies further confirm that the optimized geometry and operational parameters (high bias, low pressure) successfully suppress space charge accumulation, providing a robust solution for laser-driven beam diagnostics. Full article

The rapid advancement of high-performance electronics has intensified the demand for wide-bandgap semiconductor materials capable of operating under high-power and high-temperature conditions. Among these, silicon carbide (SiC) has emerged as a leading candidate due to its superior thermal conductivity, chemical stability, and mechanical strength. However, the high cost and complexity of SiC wafer fabrication, particularly in slicing and exfoliation, remain significant barriers to its widespread adoption. Conventional methods such as wire sawing suffer from considerable kerf loss, surface damage, and residual stress, reducing material yield and compromising wafer quality. Additionally, techniques like smart-cut ion implantation, though capable of enabling thin-layer transfer, are limited by long thermal annealing durations and implantation-induced defects. To overcome these limitations, ultrafast laser-based processing methods, including laser slicing and stealth dicing (SD), have gained prominence as non-contact, high-precision alternatives for SiC wafer exfoliation. This review presents the current state of the art and recent advances in laser-based precision SiC wafer exfoliation processes. Laser slicing involves focusing femtosecond or picosecond pulses at a controlled depth parallel to the beam path, creating internal damage layers that facilitate kerf-free wafer separation. In contrast, stealth dicing employs laser-induced damage tracks perpendicular to the laser propagation direction for chip separation. These techniques significantly reduce material waste and enable precise control over wafer thickness. The review also reports that recent studies have further elucidated the mechanisms of laser–SiC interaction, revealing that femtosecond pulses offer high machining accuracy due to localized energy deposition, while picosecond lasers provide greater processing efficiency through multipoint refocusing but at the cost of increased amorphous defect formation. The review identifies multiphoton ionization, internal phase explosion, and thermal diffusion key phenomena that play critical roles in microcrack formation and structural modification during precision SiC wafer laser processing. Typical ultrafast-laser operating ranges include pulse durations from 120–450 fs (and up to 10 ps), pulse energies spanning 5–50 µJ, focal depths of 100–350 µm below the surface, scan speeds ranging from 0.05–10 mm/s, and track pitches commonly between 5–20 µm. In addition, the review provides quantitative anchors including representative wafer thicknesses (250–350 µm), typical laser-induced crack or modified-layer depths (10–40 µm and extending up to 400–488 µm for deep subsurface focusing), and slicing efficiencies derived from multi-layer scanning. The review concludes that these advancements, combined with ongoing progress in ultrafast laser technology, represent research opportunities and challenges in transformative shifts in SiC wafer fabrication, offering pathways to high-throughput, low-damage, and cost-effective production. This review highlights the comparative advantages of laser-based methods, identifies the research gaps, and outlines the challenges and opportunities for future research in laser processing for semiconductor applications. Full article

In this paper, a T-type buncher for a ridgetron accelerator is designed to further enhance the beam capture efficiency of a high-power ridgetron irradiation accelerator and reduce beam loss in the accelerator system. By incorporating a branch, the T-shaped buncher can reduce the required space compared with conventional coaxial bunchers at the same operating frequency. The physical design and electromagnetic field simulation of the T-type buncher were carried out using the CST frequency-domain solver and eigenmode solver. Subsequently, the bunching performance and its impact on beam transport in the ridgetron accelerator were further evaluated using the PIC solver. The results show that, within an input power range of 120–200 W, a 5 ns input pulse can be compressed to less than 0.6 ns, while the energy spread is maintained between 22% and 26%. At an input power of 140 W, the application of the buncher reduces beam loss after the first deflection by approximately 40%. When a 5 ns electron bunch is compressed to 2 ns (non-FWHM), the beam current increases by a factor of approximately 3.13 compared with the injection without the buncher. These results clearly demonstrate the effectiveness of the T-shaped buncher in improving beam capture efficiency and overall accelerator performance, providing a valuable reference for further power enhancement of ridgetron accelerators. Full article

Future space detectors for Ultra High Energy neutrinos and cosmic rays will utilize Cherenkov telescopes to detect forward-beamed Cherenkov light produced by charged particles in Extensive Air Showers (EASs). A Cherenkov detector can be equipped with an array of Silicon Photo-Multiplier (SiPM) pixels, which offer several advantages over traditional Photo-Multiplier Tubes (PMTs). SiPMs are compact and lightweight and operate at lower voltages, making them well-suited for space-based experiments. The SiSMUV (SiPM-based Space Monitor for UV-light) is developing a SiPM-based Cherenkov camera for PBR (POEMMA Baloon with Radio) at INFN Napoli. To understand the response of such an instrument, a comprehensive simulation of the response of individual SiPM pixels to incident light is needed. For the accurate simulation of a threshold trigger, this simulation must reproduce the current produced by a SiPM pixel as a function of time. Since a SiPM pixel is made of many individual Avalanche Photo-Diodes (APDs), saturation and pileup in APDs must also be simulated. A Gaussian mixture fit to ADC count spectrum of a SiPM pixel exposed to low levels of laser light at INFN Napoli shows a significant amount of samples between the expected PE (Photo Electron) peaks. Thus, noise sources such as dark counts and afterpulses, which result in partially integrated APD pulses, must be accounted for. With static, reasonable values for noise rates, the simulation chain presented in this work uses the characteristics of individual APDs to produce the aggregate current produced by a SiPM pixel. When many such pulses are simulated and integrated, the ADC spectra generated by low levels of laser light at the INFN Napoli SiSMUV test setup can be accurately reproduced. Full article

The growing interest in high-power amplifiers for the terahertz (THz) radar system leads to significant performance improvements of THz wave traveling-wave tubes (TWT). This article presents a detailed development of a G-band pulsed wave TWT with 120 W output power. Three approaches have been combined to improve the tube’s output power including proposing the modified folded waveguide (MFWG) slow wave structure (SWS), using large beam current, and adopting phase velocity tapering (PVT). Firstly, the MFWG SWS circuit has an additional degree of freedom that can be used to achieve approximately 36% higher interaction impedance than that in the conventional folded waveguide (CFWG). Subsequently, the electron beam current was increased to approximately 100 mA to boost the DC power of the electron beam. Finally, the PVT technology dramatically enhanced the output power from 98 W to 143 W, concomitant with a notable increase in electronic efficiency from 4.75% to 7.03%. Hot experimental results show that the measured output power can be over 100 W at 20% duty cycle within a bandwidth of 5 GHz when the operation voltage and the current are 22.48 kV and 103.5 mA, respectively. In addition, the maximum power is 121 W with the corresponding electronic efficiency of 5.1%. The proposed G-band 100 W TWT will have broad applications in far-distance high-resolution imaging. Full article

In the present work, chemical and ion beam surface treatments were performed in order to modify the electrochemical behavior of industrial austenitic–martensitic steel VNS-5 in 3.5 wt. % NaCl. Immersion for 140 h in a solution containing 0.05 M potassium dichromate and 10% phosphoric acid promotes formation of chromium hydroxides in the outer surface layer. By means of a new type of ion source, based on a high-current pulsed magnetron discharge with injection of electrons from vacuum arc plasma, ion implantation with Ar⁺ and Cr⁺ ions of the VNS-5 steel was performed. It has been found that the ion implantation leads to formation of an Fe- and Cr-bearing oxide layer with advanced passivation ability. Moreover, the ion beam-treated steel exhibits a lower corrosion rate (by ~7.8 times) and higher charge transfer resistance in comparison with an initial (mechanically polished) substrate. Comprehensive electrochemical and XPS analysis has shown that a Cr₂O₃-rich oxide film is able to provide an improved corrosion performance of the steel, while the chromium hydroxides may increase the specific conductivity of the surface layer. A scheme of a charge transfer between the microgalvanic elements was proposed. Full article

This study presents a systematic investigation into the influence of pulse frequency on the micro-arc oxidation (MAO) coating of AZ31B magnesium alloy following electron-beam remelting (EBR). The morphology, thickness, and corrosion resistance of the EBR-MAO composite coating were meticulously analyzed across various pulse frequencies (100 Hz, 200 Hz, 300 Hz, 400 Hz) employing scanning electron microscopy (SEM), X-ray diffraction (XRD), and electrochemical measurement techniques. The results show that as the pulse frequency escalates from 100 Hz to 400 Hz, the average thickness of the EBR-MAO composite coating diminishes from 41.1 μm to 38.5 μm, reduced by 6.7% compared to 10.4% in the MAO coating. Concurrently, the porosity exhibits a reduction from 1.93% to 1.35%, accompanied by a densification of the coating’s structure. High pulse frequencies yield coatings with enhanced smoothness and fewer defects. Notably, the corrosion resistance of the coatings demonstrates significant improvement at higher frequencies (400 Hz) compared to their lower-frequency (100 Hz) counterparts, as evidenced by a tenfold increase in corrosion current density. This research underscores the pivotal role of pulse frequency in optimizing the protective qualities of MAO coatings on magnesium alloys. Full article

Low-Energy High-Current Electron Beam (LEHCEB) is an innovative vacuum technology employed for the surface modification of conductive materials. Surface treatments by means of LEHCEB allow the melting and rapid solidification of a thin layer (up to ~10 μm) of material. The short duration of each pulse (2.5 μs) allows for the generation of high thermal rates, up to 10⁹ K/s. Due to the peculiar features of LEHCEB source, in situ temperature monitoring inside the vacuum chamber is unfeasible, even with the most rapid IR pyrometers available on the market. Therefore, multiphysics simulations serve as a tool for predicting and assessing the thermal effects induced by electron beam irradiation. COMSOL Multiphysics was employed to study the thermal behaviour of metals and alloys at the sub-microsecond time scale by implementing both experimental power time profiles and semi-empirical electron penetration functions. Three case studies were considered: (a) 17-4 PH steel produced by Binder Jetting, (b) biphasic Al-Si13 alloy, and (c) Magnetron Sputtering Nb films on Ti substrate. The influence on the thermal effects of electron accelerating voltage and number of pulses was investigated, as well as the role of the physicochemical properties of the materials. Full article

Lightweight aeronautical structures and power generation structures such as wind turbines are fitted with protected external layers designed and certified to withstand severe climatic events such as lightning strikes. During these events, high currents flow through the structural protection but are likely to induce effects deeper in the supporting composite material and could even reach or perforate pressurized tanks. In situ measurements are hard to achieve during current delivery due to the severe electromagnetic conditions, and the lightning strike phenomenon on these structures is not yet fully investigated. To gain a better understanding of the physics involved, similarities in direct damage between lightning-struck samples and those subjected to pulsed lasers and an electron gun are analyzed. These analyses show the inability of a pure mechanical contribution to fully reproduce the shape of the delamination distribution of lightning strikes. Conversely, the similarities in effect and damage with the thermomechanical contribution of electron beam deposition are highlighted, particularly the increase in core delamination due to the paint and the apparent similarities in delamination distribution. Full article

Stainless steel 17-4PH is valued for its high strength and corrosion resistance but poses machining challenges due to rapid tool wear. This research investigates the use of pulsed electron beam surface treatment to enhance the surface properties of components fabricated by binder jetting additive manufacturing. The aim is to improve the tribological performance compared to the as-sintered condition and the H900 aging process, which optimizes hardness and wear resistance. Printed samples were sintered in a reducing atmosphere and superficially treated with an electron beam by varying the voltage and the pulse count. Results showed that the voltage affects the roughness and thickness of the treated layer, while the number of pulses influences the hardening of the microstructure and, consequently, the wear resistance. A reciprocating linear pin-on-disk wear test was conducted at 2 N and 10 Hz. Surface-treated samples exhibited lower coefficients of friction, though the values approached those of aged samples after the abrasion of the melted layer, indicating a deeper heat-affected zone formation. Still, the friction remained lower than that of as-printed specimens. This study demonstrates that optimizing electron beam parameters is vital for achieving surface performance comparable to bulk aging treatments, with significant implications for long-term wear resistance. Full article

Zircaloy-4 is extensively used in nuclear reactors as fuel element cladding and core structural material. However, the safety concerns post-Fukushima underscore the need for further enhancing its high-temperature and high-pressure water-side corrosion resistance. Therefore, this study aimed to investigate the effects of high-current pulsed electron beam (HCPEB) irradiation on the microstructures and corrosion resistance of Zircaloy-4, with the goal of improving its performance in nuclear applications. Results showed that after irradiation, the cross-section of the sample could be divided into three distinct layers: the outermost melted layer (approximately 4.80 μm), the intermediate heat-affected zone, and the bottom normal matrix. Large numbers of twin martensites were induced within the melted layer, which became finer with increasing irradiation times. Additionally, plenty of ultrafine/nanoscale grains were observed on the surface of the sample pulsed 25 times. Zr(Fe, Cr)₂ second-phase particles (SPPs) were dissolved throughout the modified layer and Fe and Cr elements were uniformly distributed under the action of HCPEB. As a result, the corrosion resistance of the sample pulsed 25 times was significantly improved compared to the initial one. Research results confirmed that HCPEB irradiation is an effective method in improving the service life of Zircaloy-4 under extreme environmental conditions. Full article

This paper investigates the enhancement of the microstructure and properties of Ag-10La_0.7Sr_0.3CoO₃ composites, prepared by powder metallurgy, through the application of high-current pulsed electron beam (HCPEB) irradiation. The X-ray diffraction results showed that the irradiated samples exhibited selective orientations on the surface of their (200) and (311) crystal planes. Microstructural observations revealed a dense remelted layer on the samples’ surface after HCPEB irradiation. The surface hardness of the samples increased after 15 treatments, showing an improvement of 36.76%. This is primarily attributed to fine-grain strengthening, surface remelting, and recrystallization. Further, the electrical conductivity of the samples treated 15 times increased by 74.8% compared to that of the original samples. Electrochemical test results showed that the samples treated 15 times showed the lowest corrosion current density in a 3.5 wt.% NaCl solution. This improved corrosion resistance is attributable to the refinement of the surface’s microstructure and the introduction of residual compressive stress. This study demonstrates the significant impact of HCPEB irradiation on the regulation of the properties of Ag-10La_0.7Sr_0.3CoO₃ composites. Full article

We present a laser–plasma electron accelerator module designed to be driven by high-repetition-rate lasers for industrial applications of laser-driven electron beams. It consists of a single vacuum chamber containing all the necessary components for producing, optimizing, and monitoring electron beams generated via laser wakefield acceleration in a gas jet when driven by a suitable laser. The core methods in this paper involve a comprehensive metrological assessment of the driving laser by rigorous temporal laser pulse characterization and contrast measurements, supplemented by detailed spatiotemporal distribution analyses of the laser focus. Results demonstrate the good stability and reproducibility of the laser system, confirming its suitability for advanced scientific and industrial applications. We further demonstrate the functionality of the laser–plasma accelerator module diagnostics, perform target density characterizations, and time-resolved laser–plasma shadowgraphy. Current limitations of the set-up preventing first electron acceleration are analyzed and an outlook for future experiments is given. Our work is a first step towards the wide dissemination of fully integrated laser–plasma accelerator technology. Full article
