Labyrinth seals, extensively used in aerospace and turbomachinery as non-contact sealing devices, undergo accelerated wear and enhanced leakage due to repeated rub-impact between rotating shafts and sealing rings. To address the problem of increased leakage under rub-impact conditions, this research integrates experimental and numerical methods to investigate the deformation mechanisms and leakage characteristics of thermoplastic labyrinth seals. A custom designed rub-impact test rig was constructed to measure dynamic forces and validate finite element analysis (FEA) models with an error of 5.1% in predicting tooth height under mild interference (0.25 mm). Computational fluid dynamics (CFD) simulations further demonstrated that thermoplastic materials, such as PAI and PEEK, displayed superior resilience (with rebound ratios of 57% and 70.3%, respectively). Their post-impact clearances were 4.8–18.3% smaller than those of PTFE and F500. Leakage rates were predominantly correlated with interference, causing a substantial increase compared to the original state; at 0.25 mm interference (reverse flow), increases ranged from 151% (PAI) to 217% (PTFE), highlighting material-dependent performance degradation. Meanwhile, tooth orientation modulated leakage by 0.5–3% through the vena contracta effect. Based on these insights, two optimized inclined-tooth geometries were designed, reducing leakage by 28.2% (Opt1) and 28.1% (Opt2) under rub-impact. These findings contribute to the development of high-performance labyrinth seals suitable for extreme operational environments. Full article

To study the nonlinear dynamic behavior and system stability of a rubbing overhung rotor with viscoelastic and memory-effect damping and random uncertain parameters, this paper introduces a fractional-order modeling and stochastic dynamic analysis method for the nonlinear overhung rotor system with frictional impact faults. Firstly, the dynamic equations of the overhung rotor considering friction effect and fractional damping effect are established based on the transfer matrix method and fractional order derivative. Then, the time-domain response of the fractional-order dynamic equations is solved by combining the Runge–Kutta method and the continuous fractional expansion, and the steady-state response characteristics of different fractional damping are analyzed in the deterministic case. Finally, to analyze the response of the system under the effect of stochastic parameters, the sparse grid-based PCE metamodel of the system response is developed. Statistical moments, probability distributions, and sensitivity indices of the response of stochastic systems are revealed. The results of this paper provide a theoretical basis for efficient and accurate prediction of the stochastic response of nonlinear rubbing overhung rotor systems. Full article

When the dual rotor system of the aircraft engine is operating, the mass eccentricity of the power turbine rotor and the misalignment of the shaft coupling or the bearing will cause too large vibration of the rotor; this vibration leads to the rub-impact between the rotor and the casing. The power turbine rotor from the dual rotor system is taken as the research object in this paper. Considering the misalignment, the resulting rub-impact faults, the imbalance of rotor and the disk offset, the equation of motion for the system is developed according to the Lagrangian Equation, and then the Range-Kutta Method is adopted to solve the equation. The influence of the key parameters such as the rotating speed, the misalignment angle and the rub-impact clearance on the dynamics of the system is studied; the finite element analysis was carried out to validate the correctness of the theoretical modeling method. The results show that the rub-impact increases the stiffness of the system; the Hopf bifurcation occurs in the misalignment and rub-impact coupling system; the vibrational stability near the half of the switching speed slumps with the increase of the misalignment angle; with increasing of the stiffness, the number of the chaotic zone increases, and the range of the chaos is widening; enlarging the rub-impact clearance is beneficial to reduce the degree of the rub-impact system and enhance the stability of the system. Full article

The twin-spool rotor-bearing system plays a crucial role in the aero-engine. The potential manufacturing defect, assembly error, and abnormal working loads in the rotor-bearing system can induce multiple rotor failures, such as bolt looseness and rub impact. However, the prediction of the fault rotor dynamic behavior for the aero-engine remains a difficult frontier in numerical modeling. We present a dynamic model of the twin-spool rotor-bearing system, the failure model of bearing seat loosening, and the failure model of rub impact by using second-type Lagrangian equations, finite element theory, and the Timoshenko beam theory. In particular, to improve the accuracy of the numerical model, the rotating speed control equation and the actual aero-engine parameter are taken into account. An analysis is conducted on the impact of critical failure parameters, such as looseness stiffness and rub impact initial gap, on the vibration behaviors of the essential components of the twin-spool rotor system and on the entire engine. Additionally, this paper examines the twin-spool rotor-bearing system affected by looseness–rub coupled failures. The obtained conclusions can serve as a theoretical foundation for optimizing the structure and diagnosing faults in the aero-engine rotor system. Full article

Squeeze film dampers are often used to suppress vibration in turbine engines and play an important role in rotor systems. In this paper, the nonlinear dynamic characteristics of an industrial turbine engine fitted with squeeze film dampers are investigated with the static eccentricity of the SFDs. A recently developed time domain technique that combines the finite element method and the fixed interface modal synthesis method is applied to predict the nonlinear unbalance response of the industrial turbine engine under different unbalanced and static eccentricity configurations. By comparing the results obtained using SFDs with and without static eccentricity, it can be concluded that increasing the static eccentricity of the SFDs promotes non-periodic motion, while an increase in the unbalance level promotes the jump phenomenon. The efficiency of the rotor system would improve with an appropriate amount of unbalance applied to compressor IV, resulting in a reduction in the vibration level. If static sprung eccentricity occurs, the center of the journal orbit would be offset from the SFD center, rendering it inefficient or even leading to rub impact. Therefore, it is crucial to control the static eccentricity of the SFDs for optimal performance. The time domain technique is verified by the experimental results reported in the literature. Full article

Magnetic suspended dual-rotor systems (MSDS) provide the potential to significantly improve the performance of aero-engines by eliminating the wear and lubrication system, and solve vibration control issues effectively. However, the nonlinear dynamics of MSDS with rubbing is rarely investigated. In this work, the nonlinear support characteristics of active magnetic bearings (AMBs) are described by the equivalent magnetic circuit method, the impact force is characterized by the Lankarani–Nikravesh model, and the nonlinear dynamic model is established using the finite element method. On this basis, the influence of speed ratio on the nonlinear dynamics is investigated. Simulation results show that the fundamental sub-synchronous vibration of period n is the dominant motion of MSDS, where n is determined by the speed ratio. The frequency components of sub-synchronous vibrations of period k are integer multiples of the minimum dimensionless frequency component 1/k, where k is a positive integral multiple of n. Quasi-periodic and chaotic vibrations are more likely to occur near critical speeds, and their main frequency components can be expressed as a variety of combined frequency components of the rotating frequency difference and its fractional frequency. To reduce the severity of fluctuating stresses stemming from complicated non-synchronous vibrations, speed ratios, corresponding to smaller n and AMB control parameters attenuating vibration amplitude or avoiding critical speeds, are suggested. Full article

Due to various factors such as manufacturing, assembly and operation, the motor air gap will be uneven in the circumferential direction, resulting in the air gap eccentricity having a longer air gap on one side and a shorter air gap on the other side, which affects the normal operation and service life of the motor. This paper analyzed and compared the applicability of linear and nonlinear calculation methods of unbalanced magnetic pull. Based on the method of finite element analysis, the unbalanced magnetic pull of motor rotor under static eccentricity, dynamic eccentricity and compound eccentricity faults were calculated, and the influence of eccentricity on unbalanced magnetic pull was compared, respectively. The results showed that when the motor has static eccentricity, the main components of unbalanced magnetic pull on the rotor are zero frequency and twice the electrical frequency. When the motor has dynamic eccentricity, the unbalanced magnetic tension component of the rotor is mainly frequency conversion. When the motor has two faults at the same time, the unbalanced magnetic pull has zero frequency, rotating frequency and double electric frequency components at the same time. With the increase in the relative eccentricity, the frequency components of the unbalanced magnetic pull under the three faults increase. An air gap eccentricity fault widely exists in motor equipment. When the unbalanced magnetic pull increases to a certain extent, the rotor will be pulled towards the stator, causing the occurrence of rub-impact phenomenon, and seriously threatening the safe operation of the system. In this paper, the numerical analysis method and finite meta-computing method were used for the first time to analyze and compare the unbalanced magnetic pull on the rotor of permanent magnet synchronous motor under three kinds of air gap eccentricity faults. The results showed that the characteristic frequency amplitude of the unbalanced magnetic pull calculated by the two methods is relatively close. Therefore, it is of great significance to carry out calculation and analysis of the unbalanced magnetic pull force under the air gap eccentric fault of the motor. Full article

Wear usually occurs in the loaded part of hydrodynamic bearings and leads to bearing geometry imperfections. This paper investigates the effects of wear-induced geometric imperfections of tilting pad journal bearings (TPJBs) on the dynamic behavior of the system. Furthermore, the effect of wear on the journal-bearing rub-induced contact pressure severity is investigated. A novel tribo-dynamic model is proposed for a flexible rotor-worn TPJB which integrates a mixed elastohydrodynamic model with a rotor-worn TPJB thermal and dynamic model to assess the effects of the bearing wear progression on rotor-TPJB behavior. Based on the results, wear changes the temperature distribution of the pads and oil film as well as the dynamic behavior of the system. Dynamic simulations reveal a higher vibration level and contact pressure for the worn TPJBs near the system’s critical speed and service speed. Finally, thermal and dynamic condition indicators are suggested to detect TPJB wear severity at its early stages. Full article

This study mainly investigated the nonlinear vibration performance of a rotor-casing coupling system containing a bolted flange connection. The dynamic equations of the coupling system were developed while considering the radial stiffness of the bolted flange structure, which contained a spigot, squirrel cage with ball bearing, and rotor-casing coupling vibration. To study the influence of the disk casing fixed-point rubbing fault on the coupling system’s nonlinear dynamic performance, an analytical model of the nonlinear impact forces was established, which considered the contact and vibration responses of the rotor and casing. The frictional force was obtained based on the Coulomb friction law. The iterative analysis of motion equations was performed utilizing the Newmark method. Then, the nonlinear dynamic behaviors of the coupled systems were examined using data, including a bifurcation diagram, spectrum plot, greatest Lyapunov exponents, etc. The effects of rubbing fault on the dynamic properties of system were investigated in detail, indicating that there were various motion states, which were described as periodic, multi-periodic, and quasi-periodic motions. Comparing the simulation results, it was found that rubbing fault seriously affected the motion stability of the rotor system. Finally, by gathering and examining the vibration data set from a test platform for rotor-casings with bolted joints, the correctness of the numerical simulation findings was confirmed. Additionally, the results of the experimental investigation agreed with that of the simulation. The dynamic distinguishing characteristics that were noticed can be used as an indicator for determining whether the fixed-point rubbing fault between the rotor and casing has become worse. Full article

The current study aims to study the drill string–casing system operating in an inviscid fluid under imbalanced and rubbing damage types. The Navier–Stokes equations were linearized to establish the hydrodynamic forces surrounding the drill string and resulted in a five-dimensional system of nonlinear differential equations. To ensure the accurate acquisition of friction characteristics in a fluid medium, a nonlinear wavelet synchronized transform (NWSST) technique was enhanced based on the denoised wavelet hard thresholding algorithm to extract the features of the rubbing system. The developed model was verified through various test conditions, and the extracted data tests show that the frictional impact proves sufficient to modify the dynamic behavior of the drill string throughout the energy concentration with a slight shift above and below the resonant frequency. It was shown by simulation that the vibration of the submerged drill string system potentially enhanced highly undesirable hidden vibrational frequencies that led to a disturbed and chaotic 3D orbit pattern vibrational response. The experimental results show how vibration analysis combined with the synchrosqueezed technique can identify the condition of the drill string system even under harsh operating conditions and demonstrate that fluid enables the drill string system to rotate with minimum friction. Full article

In a pressurized water reactor nuclear power plant, metal foreign matter in the rod–rod gap of the fuel assembly is constantly rubbed and collided with the fuel rod under continuous scouring of the coolant, resulting in wear to the fuel rod and even leakage of the perforation. In this work, the effects of different debris shapes and materials on the impact wear behavior of Zr−4 alloy tubes were studied through the dynamic response and damage of Zr−4 alloy tubes under cyclic impact. The results show that the sharper the shape of the impact block, the higher the wear rate of the Zr−4 alloy tube. Although the energy absorption rate of SA 508−A during the impact process is high, most of the energy is used for the wear of the impact block itself and the formation and peeling of the wear debris accumulation layer, and the damage to the Zr−4 alloy tube is small. The wear debris generated by the Zr−4 impact block is not easy to oxidize, and the wear caused by the cyclic impact is more serious. After the Zr−4 impact block cyclically impacts the Zr−4 alloy tube 200 w times, the Zr−4 alloy tube will be perforated due to wear. The oxidation and accumulation of wear debris and the wear mechanism in the impact process are mainly abrasive wear and surface peeling behavior. The occurrence of cutting and wear removal will promote the wear and thinning of the tube wall of the Zr−4 alloy tube, and the tube wall is easily perforated after thinning. Full article

In aero-engines, the rotor systems are frequently designed with multistage discs, in which the discs are fastened together through bolted joints. During operation, rotating machines are susceptible to rotor–stator rubbing faults. Those bolted joints are subjected to friction and impact forces during a rubbing event, leading to a dramatic change in mechanical properties at the contacting interfaces, influencing the rotor dynamics, which have attracted the attention of scholars. In the present work, a mathematical model, which considers the unbalance force, rotor dimensional properties, nonlinear oil-film force and rub-impact effect, is developed to study the bifurcation and stability characteristics of the bolted joint rotor system containing multi-discs subjected to the rub-impact effect. The time-domain waveforms of the system are obtained numerically by using the Runge–Kutta method, and a bifurcation diagram, time domain waveforms, spectrum plots, shaft orbits and Poincaré maps are adopted to reveal the rotor dynamics under the effect of the rub-impact. Additionally, the influences of rubbing position at the multi-discs on rotor dynamic properties are also examined through bifurcation diagrams. The numerical simulation results show that the segments of the rotating speeds for rubbing are wider and more numerous, and the middle disc is subjected to the rub-impact. When the rub-impact position is far away from disc 1, the rubbing force has little effect on the response of disc 1. The corresponding results can help to understand the bifurcation characteristics of a bolted joint rotor system containing multi-discs subjected to the rub-impact effect. Full article

Natural gas hydrate (NGH) is a kind of unique resource among hydrocarbon fuels. It is stable within its sedimentary hosts and will only convert to its constituent gas and water phases relatively quickly if reservoir pressure-temperature conditions are artificially disturbed. The unwanted vibrations from the drill string with the complex external environment and excitation usually cause instability in the NGH. In this paper, a nonlinear mathematical model is presented taking into account the fluid–solid coupling vibration caused by the drilling fluid inside and outside the drill string, the non-smooth rub-impact between the drill string and borehole wall, and the influence of centralizer setting interval on nonlinear resonant vibration of the drill string. The relationship between the variable parameters of the drill string and the complex dynamics of the drill string is analyzed. Finally, the bifurcation diagram is given. The results show that the system response exhibits complex dynamic behavior due to rub-impact and nonlinear effects. However, there is always a suitable parameter in the bifurcation diagram of each parameter change, so that the amplitude of the system is small and the failure probability of the drill string is reduced. The research results have reference significance for exploring the nonlinear dynamic mechanism of a drill string under complex working conditions and reasonably optimizing drilling parameters. Full article

Ongoing climate change most pronounces itself in northern latitudes, including in the Arctic zone of the Russian Federation (AZRF). Climate change is a complex multidirectional process that is characterized by both positive and negative effects on the functioning of territorial economic systems. In this regard, an analysis of the impacts of climate change on economic development is a particularly urgent scientific and practical task that requires comprehensive study. This research was devoted to assessing the probable impacts of climate transformations on the parameters of the economic development of the AZRF regions. The authors created a methodological approach to the assessment of the costs of the effects of climate change for the economy of the AZRF regions, taking into account the average predicted dynamics of surface air temperature and key regional economic specializations, as well as the degree of susceptibility of various industries to the climate change. The energy industry was considered in particular detail since it is the basis for all of the other industries and is the guarantor of life support for the populations that live in the extreme Arctic climate. Calculations have shown that the accumulated economic effects of climate change as a whole for the AZRF economy during the period 2020–2050 will be negative and have been estimated as having a cost of more than RUB 8 trillion (or nearly USD 111 billion in 2020 prices), which would be about 3% of total Russian Arctic GRP in average annual terms. Full article

The bilinear hysteresis friction model and the Coulomb friction model are two typical macro slip models which are widely used by researchers in simulation analysis of rub-impact dynamics of shrouded blades. However, differences in the simulation results of shrouded blades based on these two friction models have not well been studied recently. In this paper, a two-dimensional lumped mass model of shrouded blades including axial displacements and tangential displacements is established, and the kinetic equations of the blades under different contact conditions are derived. The contact-separation and stick-slip transition points are determined by the bisection method. Using the fourth-order Runge–Kutta method, comparative analysis of the nonlinear characteristics and the vibration reduction characteristics of shrouded blades based on the bilinear hysteresis friction model and the Coulomb friction model are carried out. Numerical simulation results indicate that the nonlinear characteristics and the vibration reduction characteristics of shrouded blades based on these two friction models are not accordant. The discussion in this paper offers thinking for the selection of the friction model in a study on rub-impact dynamics of shrouded blades. Full article
