Search Results (18)

The alumina doped epoxy resin composites have been widely used to prepare the basin-type insulators in gas-insulated switchgear (GIS). In recent years, the air cavity defects in the basin-type insulators became one of the most common factors to induce GIS faults. Therefore, the development of novel detection techniques for air cavities in epoxy resin composites is of great importance. In this study, multiple epoxy resin samples containing various submillimeter air cavities were prepared. Long pulse thermography (LPT) was employed to detect defects in the epoxy resin composite, and multiple data processing methods were applied to extract the characteristics of the air cavity defects. Quantitative analysis was also used to characterize the detection effectiveness in different thermograms. Experimental results show that derivative thermograms are capable of detecting air cavity defects with a diameter of 0.2 mm at a depth of 1.2 mm. The derivative thermograms can reduce noise and sharpen the defect recognition, exhibiting a high signal-to-noise ratio (SNR). This study also analyzes the impact of the aspect ratio on the detection result, which indicates that the defect with a small aspect ratio is difficult to detect. Based on the infrared thermography technology, this work provides a promising route for defects detection in basin-type insulators. Full article

Non-destructive testing (NDT) plays a crucial role in ensuring the structural integrity and safety of industrial facilities and components. Long pulse thermography (LPT), a form of active thermographic testing (ATT), has gained attention for its ability to detect subsurface defects efficiently. However, non-uniform thermal excitation and environmental noise often degrade the accuracy of defect detection. This study proposes an advanced thermographic inspection technique incorporating a halogen array (HA) lamp and a compensation methodology to enhance the reliability of defect detection. Two compensation methods, namely absolute temperature compensation (ATC) and temperature rate compensation (TRC), were developed to correct non-uniform thermal loads and improve the defect contrast. Experimental validation was conducted on A-type and B-type mock-up specimens with artificial subsurface defects (10–90% depth). The results demonstrated a significant enhancement in the signal-to-noise ratio (SNR), reaching up to a 42 dB improvement in severe defects. Furthermore, a quantitative evaluation method was proposed using SNR-based defect depth estimation models, improving the accuracy of defect sizing. This approach eliminates the need for complex amplitude and phase transformations, enabling direct defect assessment from temperature thermograms. Full article

Composites have found applications in critical components and require a high degree of safety and reliability. To ensure this, structural health monitoring systems based on optical fibres embedded within structures are installed for continuous monitoring. Infrared thermography is a non-destructive method that can be applied to inspect the internal structure after manufacturing and during operation. This paper presents an application of pulsed thermography for observing and evaluating the internal structure of glass fibre-reinforced polymer samples with different arrangements of embedded optical fibres. The goal of the paper is to study the feasibility of using pulsed thermography to distinguish optical fibres from glass textile fibre bundles, as well as to track the arrangement of the optical fibres. Full article

The detection of impact and depth defects in Glass Fiber Reinforced Polymer (GFRP) composites has been extensively studied to develop effective, reliable, and cost-efficient assessment methods through various Non-Destructive Testing (NDT) techniques. Challenges in detecting these defects arise from varying responses based on the geometrical shape, thickness, and defect types. Long Pulse Thermography (LPT), utilizing an uncooled microbolometer and a low-resolution infrared (IR) camera, presents a promising solution for detecting both depth and impact defects in GFRP materials with a single setup and minimal tools at an economical cost. Despite its potential, the application of LPT has been limited due to susceptibility to noise from environmental radiation and reflections, leading to blurry images. This study focuses on optimizing LPT parameters to achieve accurate defect detection. Specifically, we investigated 11 flat-bottom hole (FBH) depth defects and impact defects ranging from 8 J to 15 J in GFRP materials. The key parameters examined include the environmental temperature, background reflection, background color reflection, and surface emissivity. Additionally, we employed image processing techniques to classify composite defects and automatically highlight defective areas. The Tanimoto Criterion (TC) was used to evaluate the accuracy of LPT both for raw images and post-processed images. The results demonstrate that through parameter optimization, the depth defects in GFRP materials were successfully detected. The TC success rate reached 0.91 for detecting FBH depth defects in raw images, which improved significantly after post-processing using Canny edge detection and Hough circle detection algorithms. This study underscores the potential of optimized LPT as a cost-effective and reliable method for detecting defects in GFRP composites. Full article

Nondestructive testing (NDT) of composite materials is of paramount importance to the aerospace industry. Several NDT methods have been adopted for the inspection of components during production and all through the aircraft service life, with infrared thermography (IRT) techniques, such as line scan thermography (LST) and pulsed thermography (PT), gaining popularity thanks to their rapidity and versatility. On one hand, LST is an attractive solution for the fast inspection of large and complex geometry composite parts during production. On the other hand, PT can be employed for the characterization of composite materials, e.g., the determination of thermal diffusivity and defect depth estimation. In this study, the use of LST with an uncooled microbolometer camera is explored for the identification of artificially produced porosity and barely visible impact damage (BVID) on academic samples. The performance of LST is quantitatively assessed with respect to PT (considered the gold standard in this case) using a high-definition cooled camera through the contrast-to-noise ratio (CNR) criterium. It is concluded that, although in most cases the measured CNR values were higher for PT than for LST (as expected since a high-definition camera and longer acquisition times were used), the majority of the defects were clearly detected (CNR ≥ 2.5) by LST without the need of advanced signal processing, proving the suitability of LST for the inspection of aerospace composite components. Furthermore, the deepest defect investigated herein (z ≈ 3 mm) was detected solely by LST combined with signal processing and spatial filtering (CNR = 3.6) and not by PT (since pulse heating was not long enough for this depth). In addition, PT was used for the determination of the thermal diffusivity of all samples and the subsequent depth estimation of porosity and damaged areas by pulsed phase thermography (PPT). Full article

When studying paintings with active infrared thermography (IRT), minimizing the temperature fluctuations and thermal shock during a measurement becomes important. Under these conditions, it might be beneficial to use lock-in thermography instead of the conventionally used pulse thermography (PT). This study compared the observations made with lock-in thermography (LIT) and pulse phase thermography (PPT) with halogen light excitation. Three distinctly different paintings were examined. The LIT measurements caused smaller temperature fluctuations and, overall, the phase images appeared to have a higher contrast and less noise. However, in the PPT phase images, the upper paint layer was less visible, an aspect which is of particular interest when trying to observe subsurface defects or the structure of the support. The influence of the spectral range of the cameras on the results was also investigated. All measurements were taken with a mid-wave infrared (MWIR) and long wave infrared (LWIR) camera. The results show that there is a significant number of direct reflection artifacts, caused by the use of the halogen light sources when using the MWIR camera. Adding a long-pass filter to the MWIR camera eliminated most of these artifacts. All results are presented in a side-by-side comparison. Full article

The differences in dynamic thermal changes during laser lithotripsy between various laser pulse modes are unclear. We used thermography to evaluate the temporal changes in high-temperature areas during laser activation in order to compare different laser pulse modes. An unroofed artificial kidney model was used for the experiments. The laser fired for 60 s with a laser setting of 0.4 J/60 Hz in the following four different laser pulse modes without saline irrigation: short pulse mode (SPM), long pulse mode (LPM), virtual basket mode (VBM) and Moses mode (MM). Using the first 30 s of moving images, we compared the ratio of a high-temperature area of >43 °C to the total area every 5 seconds. The dynamic changes in fluid temperatures were shown to be different between the laser pulse modes. The extent of the high-temperature areas during the laser activation was large in the LPM and MM compared with the SPM and VBM. While the high-temperature areas expanded in an anterior direction in the early laser irradiation period using the LPM, they spread in a posterior direction in the early laser activation period using the MM. Although only the temperature profile in one specific plane was investigated, these results are considered useful for preventing thermal injuries during retrograde intrarenal surgeries. Full article

The non-contact long pulse thermography method is commonly used to detect the defects in thermal barrier coatings (TBCs). The profile of interfacial defect in TBCs can be monitored by infrared camera under the irradiation of the excitation source. Unfortunately, the defect profile is always blurry due to heat diffusion between the defect area and the intact area. It is difficult to quantify the size of defect size in TBCs. In this work, combined with derived one-dimensional heat conduction analytical model, a non-contact long pulse thermography (LPT) method is applied to quantitatively investigate the interface defects in TBCs. Principal component analysis (PCA) and background subtraction method are used to improve the contrast of the defect profile in collected thermal images. By fitting the results between the profile of the interface defect in thermal images and the predicted shape of the model, the interface defect size can be determined. Furthermore, a simple extension of proposed method for interfacial defects with irregular shape is presented. The predicted errors for round defect with diameters of 3 mm, 5 mm and 7 mm are roughly distributed in the range of 3%~6%, which are not affected by the defect diameter. Full article

Among the different forms of art, the puppet theatre constitutes a long-standing and often little-known tradition. The use of puppets as support for acting dates back to the Greek age, and it was mainly developed during the modern period. The reason for such a large diffusion was due to the possibility of using affordable materials, such as papier-mâché, for the puppets’ manufacture. In this paper, a method based on the combined use of pulsed thermography (PT) and mid-wave infrared reflectography (MIR) is, for the first time, proposed for the characterization of papier-mâché artworks. In particular, some puppets belonging to the collection of the Museo delle Civiltà in Rome and made by Olga Lampe Minelli, a 20th-century puppet master, were investigated in order to detect damaged areas, such as those affected by insect attacks, and, consequently, to specifically plan suitable restoration works. Finally, the investigations were also carried out after the restoration to evaluate the effectiveness of the adopted treatments. Full article

Inductive thermography is an NDT method, which can be excellently used to inspect long metallic specimens (such as railway tracks) to detect surface defects. Aiming at the inspection of railway tracks in service with a movable setup, the method had to be advanced from a stationary application to a scanning setup. This work presents methods for using calibration targets for rectification, in order to improve the quality of the resulting images. Two scanning techniques are presented for detecting different types of rolling contact fatigue (RCF) defects on rail pieces. In the case of the first method, separate stationary inductive pulsed measurements are carried out for the segments of a long sample and the results are stitched together to one panoramic image of the whole specimen (“stop-and-go”). Since the surface of the rail piece is curved, rectification of the surface with a flexible grid is necessary to generate seamless panoramic images. In the case of the second method, a specimen is moved with constant speed underneath the induction coil. For the detection of shallow surface cracks, the infrared camera has to have a view of the surface during the heating; therefore, the camera is placed behind the coil but tilted towards a position below the induction coil. In order to be able to evaluate phase images from the temporal temperature change, a checkerboard grid as a rectification target is used. It is also analyzed how the chosen IR camera frame rate and the motion speed affect the scanning result. Full article

In building construction, it is very important to reduce energy consumption and provide thermal comfort. In this regard, defects in insulating panels can compromise the capability of these panels of reducing the heat flow by conduction with the surroundings. In recent years, both experimental techniques and numerical methods have been used for investigating the effect of defects on the thermal behavior of building panels. The main novelty of this work regards the application of both numerical and experimental approaches based on infrared thermography techniques for studying the effects of defects such as debonding on the insulation properties of cork panels. In particular, the effects of defects were investigated by using the Long Pulse Thermography technique and then by analyzing the thermal behavior of the panel during the cooling phase. Results show the capability of the proposed approaches in describing the effects of defects in cork panels such as detachments and the benefit effect of a shield coating in improving the insulation properties of the panel. Full article

Initial defects, for example, those occurring during the production of a rotor blade, encourage early damages such as rain erosion at the leading edge of wind turbine rotor blades. To investigate the potential that initial defects have for early damage, long-pulse thermography as a non-destructive and contactless measurement technique is applied to a strongly curved and coated test specimen for the first time. This specimen is similar in structural size and design to a rotor blade leading edge and introduced with sub-surface defects whose diameters range between $2\mathrm{mm}$ and $3.5\mathrm{mm}$ at depths between $1.5\mathrm{mm}$ and $2.5\mathrm{mm}$ below the surface. On the curved and coated test specimen, sub-surface defects with a depth-to-diameter ratio of up to $1.04$ are successfully detected. In particular, defects are also detectable when being observed from a non-perpendicular viewing angle, where the intensity of the defects decreases with increasing viewing angle due to the strong surface curvature. In conclusion, long-pulse thermography is suitable for the detection of sub-surface defects on coated and curved components and is therefore a promising technique for the on-site application during inspection of rotor blade leading edges. Full article

Finding efficient and less expensive techniques for different aspects of culvert inspection is in great demand. This study assesses the potential of infrared thermography (IRT) to detect the presence of cavities in the soil around a culvert, specifically for cavities adjacent to the pipe of galvanized culverts. To identify cavities, we analyze thermograms, generated via long pulse thermography, using absolute thermal contrast, principal components thermography, and a statistical approach along with a combination of different pre- and post-processing algorithms. Using several experiments, we evaluate the performance of IRT for accomplishing the given task. Empirical results show a promising future for the application of this approach in culvert inspection. The size and location of cavities are among the aspects that can be extracted from analyzing thermograms. The key finding of this research is that the proposed approach can provide useful information about a certain type of problem around a culvert pipe which may indicate the early stage of the cavity formation. Becoming aware of this process in earlier stages will certainly help to prevent any costly incidents later. Full article

Inductive thermography is a non-destructive testing method, whereby the specimen is slightly heated with a short heating pulse (0.1–1 s) and the temperature change on the surface is recorded with an infrared (IR) camera. Eddy current is induced by means of high frequency (HF) magnetic field in the surface ‘skin’ of the specimen. Since surface cracks disturb the eddy current distribution and the heat diffusion, they become visible in the IR images. Head checks and squats are specific types of damage in railway rails related to rolling contact fatigue (RCF). Inductive thermography can be excellently used to detect head checks and squats on rails, and the method is also applicable for characterizing individual cracks as well as crack networks. Several rail pieces with head checks, with artificial electrical discharge-machining (EDM)-cuts and with a squat defect were inspected using inductive thermography. Aiming towards rail inspection of the track, 1 m long rail pieces were inspected in two different ways: first via a ‘stop-and-go’ technique, through which their subsequent images are merged together into a panorama image, and secondly via scanning during a continuous movement of the rail. The advantages and disadvantages of both methods are compared and analyzed. Special image processing tools were developed to automatically fully characterize the rail defects (average crack angle, distance between cracks and average crack length) in the recorded IR images. Additionally, finite element simulations were used to investigate the effect of the measurement setup and of the crack parameters, in order to optimize the experiments. Full article

Advanced materials such as continuous carbon fiber-reinforced thermoplastic (CFRP) laminates are commonly used in many industries, mainly because of their strength, stiffness to weight ratio, toughness, weldability, and repairability. Structural components working in harsh environments such as satellites are permanently exposed to some sort of damage during their lifetimes. To detect and characterize these damages, non-destructive testing and evaluation techniques are essential tools, especially for composite materials. In this study, artificial intelligence was applied in combination with infrared thermography to detected and segment impact damage on curved laminates that were previously submitted to a severe thermal stress cycles and subsequent ballistic impacts. Segmentation was performed on both mid-wave and long-wave infrared sequences obtained simultaneously during pulsed thermography experiments by means of a deep neural network. A deep neural network was trained for each wavelength. Both networks generated satisfactory results. The model trained with mid-wave images achieved an F1-score of 92.74% and the model trained with long-wave images achieved an F1-score of 87.39%. Full article
