Search Results (61)

Organ-on-a-chip (OoC) technology aims to replicate the functions of human organs and tissues. This study evaluates femtosecond laser micromachining (FLM) for producing PDMS membranes with controlled porosity as an alternative approach to conventional microfabrication for OoCs. Membranes of varying thicknesses were microdrilled, and the influence of laser parameters on microhole geometry was assessed, showing that pulse energy strongly affected hole diameter, whereas exposure time had a lesser impact. The heat-affected zone (HAZ) and taper angle, key indicators of microhole geometric quality, were also analyzed and found to be strongly dependent on membrane thickness. Prediction models were developed to guide parameter selection for future laser-based ablation processes. A numerical model that predicts plasma shielding effects provided further insight into the physics of PDMS laser ablation, revealing that higher pulse energies led to a marked increase in crater diameter. The fabricated membranes were integrated into an OoC device, onto which human mesenchymal stem cells were seeded. The results demonstrated strong cell adhesion, the rapid formation of a homogeneous monolayer, and no evidence of cytotoxicity. These findings confirm that FLM is a versatile and flexible technique for microdrilling PDMS membranes, enabling their effective integration into OoC. Full article

The preparation of high-performance hard coatings on the surface of cemented carbide PCB (printed circuit board) microdrills can effectively decrease the rapid tool wear that occurs during cutting. In this study, arc ion plating technology was employed to deposit conventional AlTiN columnar crystal single-layer coatings and AlTiN nanocrystalline single-layer coatings on the cemented carbide substrates of PCB microdrills. Additionally, a novel AlTiN composite coating with alternating columnar and nanocrystalline layers was designed and deposited. The mechanical properties and morphological characteristics of the three coating structures were analyzed using an indentation tester and scanning electron microscopy. The above three coated PCB microdrills were tested under the same conditions, and the cutting performance and tool wear mechanisms were compared and analyzed. The results show that the primary wear mechanisms for AlTiN-coated PCB microdrills are abrasive wear and coating flaking, and that the microdrill with the AlTiN columnar/nanocrystalline multilayer composite coating has the longest tool life. The novel AlTiN columnar/nanocrystalline composite coating exhibits superior interfacial adhesion strength, higher toughness, and better surface quality, and, hence, is more suitable for the high-speed drilling of PCB microholes. Full article

The Drake Goldfield, also known as Mount Carrington, is located in north-eastern New South Wales, Australia. It contains a number of low–intermediate-sulfidation epithermal precious metal deposits with a current total resource of 724.51 metric tons of Ag and 10.95 metric tons of Au. These deposits occur exclusively within the Drake Volcanics, a 60 × 20 km NW-SE trending sequence of Late Permian volcanics and related epiclastics. Drilling of the Copper Deeps geochemical anomaly suggests that the volcanics are over 600 m thick. The Drake Volcanics are centered upon a geophysical anomaly called “the Drake Quiet Zone” (DQZ), interpreted to be a collapsed volcanic caldera structure. A total of 105 fresh carbonate samples were micro-drilled from diamond drillcores from across the field and at various depths. A pXRD analysis of these carbonates identified five types as follows: ankerite, calcite, dolomite, magnesite, and siderite. Except for three outlier values (i.e., −21.32, −19.48, and 1.42‰), the δ¹³C_VPDB generally ranges from−15.06 to −5.00‰, which is less variable compared to the δ¹⁸O_VSMOW, which varies from −0.92 to 17.94‰. μ-XRF was used to analyze the elemental distribution, which indicated both syngenetic/epigenetic relationships between calcite and magnesite. In addition, a total of 53 sulfide samples (primarily sphalerite and pyrite) from diamond drillcores from across the Drake Goldfield were micro-drilled for S isotope analysis. Overall, these have a wide range in δ³⁴S_CDT values from −16.54 to 2.10‰. The carbon and oxygen isotope results indicate that the fluids responsible for the precipitation of carbonates from across the Drake Goldfield had complex origins, involving extensive mixing of hydrothermal fluids from several sources including those of magmatic origin, meteoric fluids and fluids associated with low-temperature alteration processes. Sulfur isotope ratios of sulfide minerals indicate that although the sulfur was most likely derived from at least two different sources; magmatic sulfur was the dominant source while sedimentary-derived sulfur was more significant for the deposits distal from the DQZ, with the relative importance of each varying from one deposit to another. Our findings contribute to a greater understanding of Au-Ag formation in epithermal environments, particularly in collapsed calderas, enhancing exploration strategies and models for ore deposition. Full article

Micro-electrical discharge machining is valuable in industry thanks to its ability to realise precise micro-holes with high aspect ratios. However, a limitation of the technology is represented by its low material removal rate compared to other material removal technologies. Therefore, different strategies are under investigation to make the process faster. One of these strategies consists of adding powders into the dielectric. This process is called powder-mixed electrical discharge machining (PMEDM). This paper focusses on the optimisation of different aspects of this process, particularly the effects of the powder concentration, the presence of the surfactant, the stirring of the dielectric during the machining and the stability in time of the dielectric in micro-drilling. Graphite was used as powder in pure water, and in some tests a dispersant was also added. The concentration of the powder was varied, maintaining the same ratio between the graphite and the surfactant. The optimal graphite concentration was also used without the dispersant but with a changed parameter for the stirring system. The powder-mixed dielectrics showed better removal performance than pure water, and the best graphite concentration was the highest. The material removal rate increased by 40–150% compared to pure water. The tests made without dispersant showed that its presence did not improve the machining rate, while the stirring system deeply affected the process. The electrode wear benefitted from the reduction in machining time, and when the dispersant was used, electrode wear was lowered up to 50% compared to pure water. The trend of the electrode law of motion was affected by the concentration of the contaminant (debris from the erosion and powder). The geometrical characteristics were also affected by the presence of the powder, which changed the spark length. With the highest graphite concentration, radial overcut increased up to 50% compared to pure water. The stability in time of the dielectric when the powder was added was also evaluated and it was found that an efficient stirring system without the use of dispersant is a good solution, able to limit the possible sedimentation and aggregation of the powder. Full article

The drilling of State-of-the-Art printed circuit boards (PCBs) often leads to shortened tool lifetime and low drilling accuracy due to improved strength of the PCB composites with nanofillers and higher thickness-to-hole diameter ratio. Diamond coatings have been employed to improve the tool lifetime and drilling accuracy, but the coated microdrills are brittle and suffer from coating delamination. To date, it is still difficult to deposit diamonds on ultrathin microdrills with diameters lower than 0.2 mm. To avoid tool failure, the pretreatment was optimized to afford sufficient fracture strength and enough removal of cobalt. Further, the adhesion of the diamond coating was improved by employing an interlayer comprising SiC/microcrystalline diamond, which mitigates stress accumulation at the interface. By these means, microdrills with diameters of 0.8 and 0.125 mm were coated with adherent diamonds. In this context, the composite coating with the diamond/SiC interlayer and a nanodiamond top layer featured enhanced adhesion compared to single nano- or microdiamond coatings on the WC-Co microdrills. The composite diamond-coated WC-Co microdrills featured improved wear resistance, resistance to delamination of the diamond coating, and improved performance for drilling PCBs compared to micro- and nanodiamond-coated microdrills without interlayer. In addition, a higher hole quality was achieved when the diamond-coated microdrills were used. These results signify that the composite/nanodiamond coating features the highest bonding strength and best drilling performance. Full article

Hybrid Laminar Flow Control (HLFC) is a promising technology for reducing aircraft drag and, therefore, emissions and fuel consumption. The integration of HLFC systems within the small space of the wing leading edge, together with de-icing and high lift systems, is one of the main challenges of this technology. This challenge can be tackled by using microholes along the outer skin panels to control suction without the need for an internal chamber. However, microperforations modify the mechanical properties of titanium sheets, which bring new challenges in terms of wing manufacturability. These modified properties create uncertainty that must be investigated. The present paper studies the mechanical properties of micro-drilled titanium grade 2 sheets and their modeling using the Finite Element Method (FEM). First, an experimental campaign consisting of tensile and Nakajima tests is conducted. Then, an FEM model is developed to understand the role of the anisotropy in sheet formability. The anisotropy ratios are found by combination of Design of Experiments (DoE) and the Response Surface Method (RSM); these ratios are as follows: 1.050, 1.320, and 0.975 in the directions Y, Z, and XY, respectively. Some mechanical properties are affected by the presence of microholes, especially the elongation and formability that are significantly reduced. The reduction in elongation depends on the orientation: 20% in longitudinal, 17% in diagonal, and 31% in transversal. Full article

The durability of sandstones of historical building materials and geoheritage landforms is a major issue that requires an assessment methodology to follow salt weathering evolution. The building blocks of monuments support decorative carvings and reliefs that are outstanding testimonies of human activity. An evaluation based on quasi- and non-destructive testing is a reliable and generally accepted way of testing and inspecting historical building materials. Compression tests were performed on specimens of similar building sandstones extracted close to those of from St. Leonard’s Middle Ages Church, and microdrilling tests were carried out on adequate blocks of this monument. The locations of the latter tests were determined using the results of low-pressure water absorption tests, which contributed to finding a link between the sandstone specimens and the building blocks of the monument. This innovative methodology was used to generate simulated stress–strain diagrams of the building blocks of this church based on drilling strength results, avoiding the cutting of specimens from the façades with the sizes needed to ensure the mechanical validity of the results. A good agreement between the predicted and experimental stress–strain curves was achieved. The stress–strain curves of sound stones from historical building blocks and of their weathered envelopes are shown. The evolution of weathering profiles can be followed through the analysis of stress–strain diagrams, allowing an assessment of structural stability, which is essential to the study of the durability of historical building sandstones. This innovative methodology allows the adequate conservation of monuments and is a contribution to the knowledge of sustainable cultural tourism. Full article

Size effects, high thrust forces, limited heat dissipation, and tool deterioration are just some of the challenges that deep microdrilling poses, underscoring the importance of effective process control to ensure quality. In this paper, an investigation performed on a microdrilling process on pure magnesium using a 0.138 mm diameter microdrill to achieve an aspect ratio equal to 36 is proposed. The effect of the variation of the cutting parameters feed per tooth $f_z$ and cutting speed $v_c$ was studied on thrust force, supporting hole quality evaluation in terms of burr height, entrance, and inner diameters. The results showed that $f_z$ significantly influences the hole quality. In fact, as $f_z$ increases, the burr height decreases and the inner diameter approaches the nominal diameter. However, optimizing the hole geometry with high feed per tooth values increases the thrust forces, compromising tool life. In fact, a significant dependence of the thrust force on both cutting parameters was found. In this scenario, increasing $v_c$ can mitigate the high thrust forces by inducing material softening. The study results improve precision manufacturing by refining parameters, ensuring the quality and reliability of magnesium-based microcomponents. Full article

Given the growing importance of lab-on-a-chip in a number of fields, such as medical diagnosis or environmental analysis, the fact that the current fabrication process relies mainly on oil-based polymers raises an ecological concern. As an eco-responsible alternative, we presented, in this article, a manufacturing process for microfluidic devices from chitosan, a bio-sourced, biodegradable, and biocompatible polysaccharide. From chitosan powder, we produced thick and rigid films. To prevent their dissolution and reduce their swelling when in contact with aqueous solutions, we investigated a film neutralization step and characterized the mechanical and physical properties of the resulting films. On these neutralized chitosan films, we compared two micropatterning methods, i.e., hot embossing and mechanical micro-drilling, based on the resolution of microchannels from 100 µm to 1000 µm wide. Then, chitosan films with micro-drilled channels were bonded using a biocompatible dry photoresist on a glass slide or another neutralized chitosan film. Thanks to this protocol, the first functional chitosan microfluidic devices were prepared. While some steps of the fabrication process remain to be improved, these preliminary results pave the way toward a sustainable fabrication of lab-on-a-chip. Full article

To achieve a micro-destructive and rapid measurement of the wood density of standing trees, this study investigated the possibility of the unified modeling of multiple tree species, the reliability of the micro drilling resistance method for measuring wood density, the relationship between drilling needle resistance and wood density, and whether moisture content has a significant impact on the model. First, 231 tree cores and drill resistance data were sampled from Pinus massoniana, Cunninghamia lanceolate, and Cryptomeria fortunei. The basic density and moisture content of each core were measured, and the average value of each resistance data record was calculated. Second, the average drill resistance, the natural logarithm of average drill resistance, and absolute moisture content were used as independent variables, while the basic wood density was used as the dependent variable. Third, the total model of the three tree species and sub-model for each tree species were established through a stepwise regression method. Finally, the accuracy of each model was compared and analyzed with that of using the average basic density of each tree species as an estimated density. The estimated accuracy of the total model, sub model, and average wood density modeling data were 90.070%, 93.865%, and 92.195%, respectively. The results revealed that the estimation accuracy of the sub-model was 1.670 percentage points higher than that of the average wood density modeling data, while the estimation accuracy of the total model was 2.125 percentage points lower than that of the average wood density modeling data. Additionally, except for Cryptomeria fortunei, the natural logarithm of drill resistance significantly influenced the wood density model at a significance level of 0.05. Moreover, moisture content significantly affected the total model and sub-models of Pinus massoniana at a significance level of 0.05. The results indicated the feasibility of using the micro-drilling resistance method to measure the wood density of standing trees. Moreover, the relationship between wood density and drill resistance did not follow a linear pattern, and moisture content slightly influenced the drill needle resistance. Furthermore, the establishment of a mathematical model for each tree species was deemed essential. This study provides valuable guidance for measuring the wood density of standing trees through the micro-drilling resistance method. Full article

Micro-drilled aluminum surfaces containing micro-holes were anodized to produce nanopores over the machined and lapped surfaces. The anodized nanopores had an approximate diameter of 30–40 nm and a depth distribution of 20–30 μm from the surface. The diameter and depth of the machined micro-holes were 125 μm and 300 μm, respectively. Anodization itself did not change the surface roughness because the nanopores were very small. Ball-on-disk reciprocating tests were performed under lubricated conditions for 2 h using a frequency of 2 Hz, a load of 2 N, and a travel distance of 5 mm. The results showed that both the micro-drilled and anodized surfaces greatly reduced the coefficient of friction compared with the lapped bare surface; however, the coefficient of friction of the hole-textured specimen was not maintained till the end. Contrary to expectations, the lubricant retention capability of the textured structure declined because of hole failure that occurred during oscillation. This gradually increased friction until the end of the reciprocating test. When the micro-drilled surface was anodized, the coefficient of friction decreased again, implying that non-anodized micro-holes alone were ineffective for reducing friction. The surface hardness of Al increased owing to anodization, and thus the micro-holes remained intact. Therefore, it is concluded in this study that a prerequisite for friction reduction in Al is to increase the hardness to minimize the failure of micro-holes, which can be achieved by anodization. The synergistic lubricant retention capability can be maintained by the presence of both nanopores and micro-holes. Full article

Aluminum alloys with open-channel and columnar structures were fabricated by casting the melt of aluminum alloys using a ceramic fiber template method. Stainless steel plates or wires coated with ceramic fibers impregnated by polyvinyl alcohol were used as cores. The cores were embedded in a melt of an aluminum alloy. After solidification, the ceramic fibers were macerated and became sodden by immersing the aluminum alloy ingots in water so that the plates or wires were easily removed by extraction forces as large as 5N, in other words, by pulling out them manually. Thus, an open-channel aluminum alloy was fabricated by a simple method. On the other hand, ceramic fiber blocks composed of ceramic fibers impregnated by polyvinyl alcohol were perforated by microdrills. Melts of aluminum alloy were cast in the holes by a vacuum suction method. The ceramic fibers were removed by immersing the ingots in water. Thus, a columnar-structured aluminum alloy was produced. Previous methods for the fabrication of open-channel metals necessitates a process to extract the metallic wires embedded in the solidified metals. However, the ceramic fiber template method does not require such an extraction process and thus is a very simple technique for the fabrication of open-channel metals, such as porous metals with rectangular holes and circular holes and columnar structures metals. Full article

Micro-EDM is an unconventional technology used to machine every type of electrically conductive material regardless of its mechanical properties. Material removal occurs through electrical discharges between the workpiece and the electrode immersed in a dielectric fluid. In drilling operations, the technology is able to realise microholes with excellent quality in terms of precision, quality surface, roundness, and taper to the detriment of the machining time, which is less than other technologies. Several efforts are being made to improve different features related to the process performance that are severely affected by both the operative conditions, such as the electrode material or the type of dielectric, and process parameters. The typical indexes used to characterise the performance are the machining time, the material removal rate, and the geometric indexes. These indexes are very effective and are easily measurable, but they do not give information about the evolution of the drilling process, which could be irregular due to the different phenomena occurring during machining. The aim of this paper is the development of a method able to elaborate the motion law of the electrode during the micro-EDM drilling operation. In order to do this, a single hole was manufactured in several steps, recording both the machining time and electrode wear for each step. In this way, the actual position of the electrode during the drilling can be measured without the use of a predictive model for electrode wear. It was tested to confirm that the multistep procedure did not introduce new phenomena, in contrast to the traditional drilling operation. This method was used to study the effects of the electrode diameter, the type of electrode, the length of the electrode out of the spindle, and the entity of the run-out on the process performance. The tests were executed on titanium alloy sheets using a tungsten carbide electrode and hydrocarbon oil as the dielectric. It was found that the descent of the electrode into the workpiece was not regular, but it depended on the level of debris concentration in the machining zone. The debris concentration was influenced by the type and diameter of the electrode, its length out of the spindle, and, to a lesser extent, the run-out. This method was found to be a useful method for an in-depth analysis of the micro-EDM drilling process, contributing to a better understanding of the physical aspects of the process. Full article

The conventional (mechanical) micro-drilling of Inconel 625 alloys suffers from premature breakage of the drill bit due to its brittle nature and limited cutting tool life. Even greater problems are encountered when micro-drilling holes at an acute angle to the machining plane. In such a process, there are great difficulties associated with the low stiffness of the tool, which leads to the frequent breakage of the drill during machining. Therefore, in this type of mechanical drilling operation, the hole surface is usually milled with an end mill to provide a flat surface on the entry side of the drill bit. The aim of this article is to recognise the process of sequential micro-drilling and to assess the possibility of its use as an effective and efficient method of micro-drilling in hard-to-cut metals. The paper describes the process of initial laser drilling followed by final mechanical micro-drilling. Inconel 625 Ni-based alloy sheets were used as the test material. The shape and microstructure of pre-holes made with a laser, the volumetric efficiency of laser processing, the energy in the mechanical drilling process, and tool wear were analysed. The research results show that in the sequential drilling process, mechanical re-drilling eliminates the geometrical discrepancies resulting from the laser pre-drilling. In addition, it was found that, compared to mechanical micro-drilling, the use of sequential micro-drilling resulted in a two-fold increase in drill life. It has been also observed that sequential machining reduces the energy demand by 60% compared to mechanical micro-drilling. In addition, it was found that the edge of the drill bit is a key factor in deciding the target diameter of the laser-drilled pilot hole, and thus in selecting the micro-drilling parameters. Full article

The packaging substrate plays a significant role in electrical connection, heat dissipation, and protection for the chips. With the characteristics of high hardness and the complex material composition of packaging substrates, drill bit failure is an austere challenge in micro-drilling procedures. In order to monitor the health state of the drill bit and predict its remaining useful life (RUL) in micro-drilling of packaging substrate, an improved RUL prediction model is established based on the similarity principle, degradation rate, and offset coefficient. And then, a micro-drilling experiment on packaging substrate is carried out to collect the axial drilling force through the precision drilling force measurement platform. Axial drilling force signals, which are processed via the Wiener filtering method, are used to analyze the effectiveness of the improved RUL prediction model. The experiment results indicate that, compared to the curves of the traditional RUL prediction model, the curves of the improved RUL prediction model present a higher fitting degree with the actual RUL curves. The average relative errors of the improved RUL prediction model are small and stable in all groups; all of the values are less than 15%, while the fluctuation of the average relative errors of the traditional model is greatly large, and the maximum value even reaches 74.43%. Therefore, taking the degradation rate and offset coefficient into account is a proper method to enhance the accuracy of the RUL prediction model. Furthermore, the improved RUL prediction model is a reliable theoretical support for the health state monitoring of drill bits during the micro-drilling of packaging substrates, which also acts as a potential method to improve micro hole processing efficiency for packaging substrates. Full article
