The TECSL has attracted much attention due to its wide tuning range, narrow linewidth, high output power, and excellent SMSR. It holds irreplaceable value in optical communication, spectroscopy analysis, and biomedical applications. The demand for a wide tuning range, high power, narrow linewidth, and a high SMSR has driven the development of high-performance TECSL structures. This paper comprehensively discusses five key TECSL structures: Littrow-type structures, Littman-type structures, filter-type structures, fiber-type structures, and waveguide-type structures, and elaborates on their structures and principles. This paper reviews the research process of different type-structure TECSLs, analyzes the advantages and disadvantages of different external cavity structures, and explores the future development trends of TECSLs. The review shows that the Littrow-type structure TECSL achieved an extremely wide tuning range using diffraction gratings, reaching up to 360 nm. The Littman-type structure TECSL demonstrated excellent spectral purity, achieving an SMSR of 71.03 dB. The filter-type structure TECSL was able to achieve flexible wavelength selection using tunable filters, achieving a linewidth of 570 Hz. The fiber-type structure TECSL has a linewidth of up to 600 Hz. The waveguide-type structure TECSL can achieve a linewidth as low as 0.252 kHz and a tuning range of up to 120.9 nm. Full article

An external power build-up cavity of a line-narrowed 407-nm laser diode for Raman gas analysis was demonstrated to possess good gas detection capabilities. By employing an ordinary laser diode without anti-reflection coating or and a bandpass interference filter in an external cavity resonance, the laser linewidth was narrowed by resonant optical feedback, and tens of watts of external cavity power were built up. The coupling mechanism between the semiconductor laser and the external cavity are discussed, as well as the noise background in the experimental results. The Raman spectrum of ambient air was analyzed, achieving a methane detection limit of 1 ppm. Full article

We propose a dual-ring optical filter based on direct binary search inverse design. The proposed device comprises two cascaded rings in an add–drop configuration. A physical model was established using temporal coupled mode theory to derive theoretical spectra and analyze key parameters governing transmission performance. Based on theoretical results, a direct binary search algorithm was implemented. The parameters of the proposed device were calculated using a three-dimensional finite-difference time-domain method for verification. The numerical results demonstrate a free spectral range of 86 nm, with insertion loss and extinction ratios of 0.3 dB and 22 dB, respectively. The proposed device has a narrow spectral linewidth of 0.3 nm within a compact footprint of $24 \mathsf{\mu }\mathrm{m}\times 25.5 \mathsf{\mu }\mathrm{m}$. The device shows significant application potential in laser external cavities and dense wavelength division multiplexing systems. Moreover, this work provides a novel methodology for precision design of photonic devices. Full article

State-of-the-art research on narrow-linewidth external cavity semiconductor lasers has provided limited discussion on the capability of continuous wavelength tuning. In this study, we present a 780 nm tunable external cavity diode laser (ECDL) with narrow linewidth. An angle-adjustable interference filter (IF) is employed as the mode-selection element, enabling a wide wavelength tuning range. Precise, mode-hop-free continuous tuning is achieved through a combination of current modulation and piezoelectric ceramic transducer (PZT) control, with a tuning accuracy of 1.65 pm/mA. Experimental optimization of the interference filter external cavity diode laser (IF-ECDL) operating conditions resulted in a narrow linewidth of 55 kHz and a high output power of 51 mW. Furthermore, by integrating current and PZT tuning, continuous wavelength tuning of the IF-ECDL output is demonstrated over a specified range. Full article

The main characteristic of a reflective semiconductor optical amplifier chip (RSOA) is that it does not generate optical resonance under electric pumping and maintains the operation state of spontaneous emission. In this paper, a Nb₂O₅/SiO₂/Nb₂O₅/SiO₂ (four-layer Nb₂O₅/SiO₂) film system is employed as the coating material for the output facet of the RSOA. The 3 dB spectral width of the spontaneous emission spectrum from this RSOA reaches 79.4 nm, with a ripple of less than 1 dB occurring across this wavelength range. Notably, around the 1550 nm wavelength, the ripple is as low as 0.5 dB. This represents the best performance reported for this type of chip. The RSOA is packaged as a narrow-linewidth external cavity laser. Under test conditions of 25 °C and 180 mA, the external cavity laser produces an output power of 12.6 mW and achieves a linewidth of 299.8 Hz. Furthermore, by adjusting the Fabry–Pérot (FP) standard cavity, filtering, and other external cavity parameters, the lasing spectrum of the narrow-linewidth external cavity laser based on the RSOA is tunable across a wavelength range from 1535.83 nm to 1561.42 nm, which shows the usability of the proposed ROSA for a C-band external cavity narrow-linewidth laser. Full article

This paper presents an integrated tunable hybrid multi-laser module designed to simultaneously generate multiple radiofrequency (RF) local oscillator (LO) signals through optical heterodyning. The device consists of five hybrid InP/Si₃N₄ integrated lasers, each incorporating an intracavity wavelength-selective optical filter formed by two micro-ring resonators. Through beating the wavelengths generated from three of these lasers, we demonstrate the simultaneous generation of two LO signals within bands crucial for satellite communications (SatCom): one in the Ka-band and the other in the V-band. The device provides an extensive wavelength tuning range across the entire C-band and exhibits exceptionally narrow optical linewidths, below 40 kHz in free-running mode. This results in ultra-wideband tunable RF signals with narrow electrical linewidths below 100 kHz. The system is compact and highly scalable, with the potential to generate up to 10 simultaneous LO signals, being a promising solution for advanced RF signal generation in high throughput satellite payloads. Full article

A low-cost, wavelength-tunable single-longitudinal-mode (SLM) thulium–holmium co-doped fiber laser (THDFL) in a 2 μm band with a simple structure is described in the present paper. To obtain a stable SLM and narrow laser linewidth, a five-coupler-based three-ring (FCTR) filter is utilized in the ring cavity of the fiber laser. Tunable SLM wavelength output from THDFLs with kHz linewidths can be achieved by designing the FCTR filter with an effective free-spectral range and a 3 dB bandwidth at the main resonant peak. The measurement results show that the laser is in the SLM lasing state, with a highly stabilized optical spectrum, a linewidth of approximately 9.45 kHz, an optical signal-to-noise ratio as high as 73.6 dB, and a relative intensity noise of less than −142.66 dB/Hz. Furthermore, the wavelength can be tuned in the range of 2.6 nm. The proposed fiber laser has a wide range of applications, including coherence optical communication, optical fiber sensing, and dense wavelength-division-multiplexing. Full article

To meet the demands of laser communication, quantum precision measurement, cold atom technology, and other fields for narrow linewidth and low-noise light sources, an external cavity diode laser (ECDL) operating in the wavelength range around 780 nm was set up with a Fabry–Pérot etalon (F–P) and an interference filter (IF) in the experiment. The interference filter type ECDL (IF–ECDL) with butterfly-style packaging configuration has continuous wavelength tuning within a specified range through precise temperature and current control and has excellent single-mode characteristics. Experimental results indicate that the output power of the IF–ECDL is 14 mW, with a side-mode suppression ratio (SMSR) of 54 dB, a temperature-controlled mode-hop-free tuning range of 527 GHz (1.068 nm), and an output linewidth of 570 Hz. Compared to traditional lasers operating at 780 nm, the IF–ECDL exhibits narrower linewidth, lower noise, and higher spectral purity, and its dimensions are merely 25 × 15 × 8.5 mm³ weighing only 19.8 g, showcasing remarkable miniaturization and lightweight advantages over similar products in current research fields. Full article

In this paper, a dual-wavelength narrow-linewidth fiber laser based on parity-time (PT) symmetry theory is proposed and experimentally demonstrated. The PT-symmetric filter system consists of two optical couplers (OCs), four polarization controllers (PCs), a polarization beam splitter (PBS), and cascaded fiber Bragg gratings (FBGs), enabling stable switchable dual-wavelength output and single longitudinal-mode (SLM) operation. The realization of single-frequency oscillation requires precise tuning of the PCs to match gain, loss, and coupling coefficients to ensure that the PT-broken phase occurs. During single-wavelength operation at 1548.71 nm (λ₁) over a 60-min period, power and wavelength fluctuations were observed to be 0.94 dB and 0.01 nm, respectively, while for the other wavelength at 1550.91 nm (λ₂), fluctuations were measured at 0.76 dB and 0.01 nm. The linewidths of each wavelength were 1.01 kHz and 0.89 kHz, with a relative intensity noise (RIN) lower than −117 dB/Hz. Under dual-wavelength operation, the maximum wavelength fluctuations for λ₁ and λ₂ were 0.03 nm and 0.01 nm, respectively, with maximum power fluctuations of 3.23 dB and 2.38 dB. The SLM laser source is suitable for applications in long-distance fiber-optic sensing and coherent LiDAR detection. Full article

High-average-power narrow-linewidth tunable solid-state lasers in the wavelength region between 2 and 3 μm are attractive light sources for many applications. This paper reports a narrow-linewidth widely tunable laser system based on the polycrystalline Cr²⁺:ZnSe elements pumped by repetitively pulsed 2.1 µm Ho³⁺:YAG laser operating at a pulse rate of tens of kilohertz. An advanced procedure of ZnSe element doping and surface improvement was applied to increase the laser-induced damage threshold, which resulted in an increase in the output power of the Cr²⁺:ZnSe laser system. The high-average-power laser system comprised double master oscillators and power amplifiers: Ho³⁺:YAG and Cr²⁺:ZnSe laser oscillators, and Ho³⁺:YAG and Cr²⁺:ZnSe power amplifiers. The output wavelength was widely tuned within 2.3–2.7 µm by means of an acousto-optical tunable filter inside a Cr²⁺:ZnSe master oscillator cavity. The narrow-linewidth operation at the pulse repetition rate of 20–40 kHz in a high-quality beam with an average output power of up to 9.7 W was demonstrated. Full article

This work proposes and experimentally demonstrates a high-performance polarization space parity-time (PT) symmetric fiber ring laser to achieve a low-noise, narrow-linewidth, and highly stable single-longitudinal-mode output. The gain/loss and coupling coefficients are regulated by adjusting a polarization controller (PC) and the pumping current of an erbium-doped fiber amplifier (EDFA) within the ring cavity. The results show that the single longitudinal mode oscillation of the laser can be implemented by PT symmetry breaking. The frequency noise spectral density and the linewidth characteristics of the laser are evaluated by the short-delay self-heterodyne method. The results reveal that excellent low-frequency noise (181 Hz²/Hz at a 10 kHz offset frequency) and narrow fundamental linewidth (68 Hz) can be achieved. Additionally, the laser exhibits outstanding stability with only 0.64 pm wavelength drift over 30 min. By tuning an optical tunable filter (OTF), the wavelength tunable range of the laser can cover the entire C-band. Furthermore, the impacts of different fiber length on the frequency noise spectral density and the filter bandwidth on stability are analyzed, offering guidance for component selection in such laser systems. Full article

An external cavity wavelength-fiber ring laser (ECWTFL) based on a semiconductor optical amplifier and a combined wavelength scanning filter in the Littrow configuration is proposed and experimentally demonstrated. With the benefit of the combination of an external cavity wavelength filter and a Lyot filter, the laser achieves a single-mode narrow linewidth output with a linewidth of 1.75 kHz. The wavelength tuning range reaches 133 nm, covering the entire S + C band. The proposed ECWTFL is used for demodulation of a fiber EFPI sensor; the result shows that the proposed ECWTFL has the ability to demodulate the small cavity-length FPI sensor. Full article

The transmission spectrum of a narrow-band interference filter is crucial and highly influenced by factors such as the temperature and angle, thus requiring precise and online measurements. The traditional method of measuring the transmission spectrum of an interference filter involves the use of a spectrometer, but the accuracy of this method is limited. Moreover, placing a narrow-band interference filter inside a spectrometer hinders real-time online measurements. To address this issue, there is demand for high-precision online spectral testing methods. In response to this demand, we propose and experimentally validate a fine spectral characterization method for narrow-band interference filters. This method uses a narrow-linewidth tunable laser, achieving a spectral resolution in the MHz range for online testing. Two types of narrow-band interference filters were tested using the constructed laser spectroscopy experimental system, obtaining a transmission spectrum with a spectral resolution of 318 MHz. In comparison to spectrometer-based methods, our proposed method demonstrates higher spectral accuracy, enables online measurements, and provides more accurate measurements for special spectral interference filters. This approach has significant application value and promising development prospects. Full article

In the field of inter-satellite laser communication, achieving high-quality communication and compensating for the Doppler frequency shift caused by relative motion necessitate lasers with narrow linewidths, low phase noise, and the ability to achieve mode-hop-free tuning within a specific range. To this end, this paper investigates a novel external cavity diode laser (ECDL) with a frequency-selective F-P etalon structure, leveraging the external cavity F-P etalon structure in conjunction with an auxiliary filter to achieve single longitudinal mode selection. The laser undergoes linewidth testing using a delayed self-heterodyne beating method, followed by the testing of its phase noise and frequency noise characteristics using a noise analyzer, yielding beat spectra and noise power spectral density profiles. Furthermore, the paper introduces an innovative bidirectional temperature-scanning laser method to achieve optimal laser-operating point selection and mode-hop-free tuning. The experimental results showcase that the single longitudinal mode spectral side-mode suppression ratio (SMSR) is around 70 dB, and the output power exceeds 10 mW. Enhancing the precision of the F-P etalon leads to a more pronounced suppression of low-frequency phase noise, reducing the Lorentzian linewidth from the initial 10 kHz level to a remarkable 5 kHz level. The bidirectional temperature-scanning laser method not only allows for the selection of the optimal operating point but also enables mode-hop-free tuning within 160 pm. Full article

Nanostructured color filters, particularly those generated by the extraordinary optical transmission (EOT) resonance of metal–dielectric nanostructures, have been intensively studied over the past few decades. In this work, we propose a hybrid array composed of a hole array and a disk array with the same working period within the 3–14 μm mid-infrared band. Through numerical simulations, near-perfect transmission (more than 99%) and a narrower linewidth at some resonance wavelengths were achieved, which is vital for highly sensitive sensing applications. This superior performance is attributed to the surface plasmon coupling resonance between the hole and disk arrays. A high tunability of the near-perfect transmission peak with varying structural parameters, characteristics of sensitivity to the background refractive index, and angle independence were observed. We expect that this metallic hole and disk coupling array is promising for use in various applications, such as in plasmon biosensors for the high-sensitivity detection of biochemical substances. Full article
