This study identifies the characteristics of water regions with negative normalized water-leaving radiance ($n{L}_w\left(\lambda \right)$) values in the satellite observations of the Second-generation Global Imager (SGLI) sensor aboard the Global Change Observation Mission–Climate (GCOM-C) satellite. SGLI Level-2 data, along with atmospheric and in-water optical properties measured by the sun photometers in the AErosol RObotic NETwork-Ocean Color (AERONET-OC) from 26 sites globally, are utilized in this study. The focus is particularly on Tokyo Bay and the Ariake Sea, semi-enclosed water regions in Japan where previous research has pointed out the occurrence of negative $n{L}_w\left(\lambda \right)$ values due to atmospheric correction with SGLI. The study examines the temporal changes in atmospheric and in-water optical properties in these two regions, and identifies the characteristics of regions prone to negative $n{L}_w\left(\lambda \right)$ values due to atmospheric correction by comparing the optical properties of these regions with those of 24 other AERONET-OC sites. The time series results of $n{L}_w\left(\lambda \right)$ and the single-scattering albedo ($\mathsf{\omega }\left(\lambda \right)$) obtained by the sun photometers at the two sites in Tokyo Bay and Ariake Sea, along with SGLI $n{L}_w\left(\lambda \right)$, indicate the occurrence of negative values in SGLI $n{L}_w\left(\lambda \right)$ in blue band regions, which are mainly attributed to the inflow of absorptive aerosols. However, these negative values are not entirely explained by $\mathsf{\omega }\left(\lambda \right)$ at 443 nm alone. Additionally, a comparison of in situ $n{L}_w\left(\lambda \right)$ measurements in Tokyo Bay and the Ariake Sea with $n{L}_w\left(\lambda \right)$ values obtained from 24 other AERONET-OC sites, as well as the inherent optical properties (IOPs) estimated through the Quasi-Analytical Algorithm version 5 (QAA_v5), identified five sites—Gulf of Riga, Long Island Sound, Lake Vanern, the Tokyo Bay, and Ariake Sea—as regions where negative $n{L}_w\left(\lambda \right)$ values are more likely to occur. These regions also tend to have lower $n{L}_w\left(\lambda \right)$ values at shorter wavelengths. Furthermore, relatively high light absorption by phytoplankton and colored dissolved organic matter, plus non-algal particles, was confirmed in these regions. This occurs because atmospheric correction processing excessively subtracts aerosol light scattering due to the influence of aerosol absorption, increasing the probability of the occurrence of negative $n{L}_w\left(\lambda \right)$ values. Based on the analysis of atmospheric and in-water optical measurements derived from AERONET-OC in this study, it was found that negative $n{L}_w\left(\lambda \right)$ values due to atmospheric correction are more likely to occur in water regions characterized by both the presence of absorptive aerosols in the atmosphere and high light absorption by in-water substances. Full article

In this paper, a new simultaneous retrieval method of the SIRAW algorithm is introduced and carried out on FY3D/MERSI-II satellite images to obtain the aerosol optical thickness (AOT) and normalized water-leaving radiance (WLR) over the ocean. In order to improve the operation efficiency of SIRAW, a machine learning solver is developed to improve the speed of forward radiative transfer computation during retrieval. Ground-based measurement data from AERONET-OC and satellite products from VIIRS are used for comparative verification. The results show that the retrieved AOT and WLR from SIRAW are both in good agreement with those of AERONET-OC and VIIRS. Further, considering the degradation of the MERSI sensor, a new calibration scheme on 412 nm and 443 nm is adopted and an evaluation is carried out. Inter-comparison of derived WLR between MERSI and VIIRS indicates that the new calibration scheme could effectively improve the WLR retrieval accuracy of MERSI with better consistency to the official data of VIIRS. Therefore, this paper confirms that a simultaneous retrieval scheme combined with effective calibration coefficients can be used for high-precision retrieval of real aerosol and water-leaving radiation. Full article

An increasing number of commercial nanosatellite-based Earth-observing sensors are providing high-resolution images for much of the coastal ocean region. Traditionally, to improve the accuracy of normalized water-leaving radiance ($n{L}_w$) estimates, sensor gains are computed using in-orbit vicarious calibration methods. The initial series of Planet nanosatellite sensors were primarily designed for land applications and are missing a second near-infrared band, which is typically used in selecting aerosol models for atmospheric correction over oceanographic regions. This study focuses on the vicarious calibration of Planet sensors and the duplication of its red band for use in both the aerosol model selection process and as input to bio-optical ocean product algorithms. Error measurements show the calibration performed well at the Marine Optical Buoy location near Lanai, Hawaii. Further validation was performed using in situ data from the Aerosol Robotic Network—Ocean Color platform in the northern Adriatic Sea. Bio-optical ocean color products were generated and compared with products from the Visual Infrared Imaging Radiometric Suite sensor. This approach for sensor gain generation and usage proved effective in increasing the accuracy of $n{L}_w$ measurements for bio-optical ocean product algorithms. Full article

The bidirectional reflectance distribution function (BRDF) factor ƒ′ provides a bridge between the inherent and apparent optical properties (IOPs and AOPs) of inland waters. The previous BRDF studies focused on ocean waters, while few studies examine inland waters. It is meaningful to improve the theory of remote sensing of water surface and the accuracy of image derivation in inland waters. In this study, radiative transfer simulation was applied to calculate the ƒ′ values using appropriate IOPs based on in situ combined with realistic boundary conditions (N = 11,232). This study shows that ƒ′ factor varied over the range of 0.33–16.64 in Lake Nansihu, a finite depth water, higher than the range observed for the ocean (0.3–0.6). Our results demonstrate that the factor ƒ′ depends on not only solar zenith angle (${\theta }_s$) but also the average number of collisions ($\stackrel{-}{n}$) and particulate backscattering ratio (${\tilde{b}}_{bp}$). The ƒ′ factor shows a continuous geometric increase as the solar zenith angle increases at 400–650 nm but is relatively insensitive to solar angle in the 650–750 nm range in which ƒ′ increases as ${\tilde{b}}_{bp}$ and $\stackrel{-}{n}$ decreases. To account for these findings, two empirical models for ƒ′ factor as a function of ${\theta }_s$, $\stackrel{-}{n}$ and ${\tilde{b}}_{bp}$ are proposed in various spectral wavelengths for Lake Nansihu waters. Our results are crucial for obtaining Hyperspectral normalized reflectance or normalized water-leaving radiance and improving the accuracy of satellite products. Full article

Visible Infrared Imaging Radiometer Suite (VIIRS) data were systematically evaluated and used to detect harmful algal bloom (HAB) and classify algal bloom types in coasts of the East China Sea covered by optically complex and sediment-rich waters. First, the accuracy and spectral characteristics of VIIRS retrieved normalized water-leaving radiance or the equivalent remote sensing reflectance from September 2019 to October 2020 that were validated by the long-term observation data acquired from an offshore platform and underway measurements from a cruise in the Changjiang Estuary and adjacent East China Sea. These data were evaluated by comparing them with data from the Moderate-Resolution Imaging Spectroradiometer. The bands of 486, 551, and 671 nm provided much higher quality than those of 410 and 443 nm and were more suitable for HAB detection. Secondly, the performance of four HAB detection algorithms were compared. The Ratio of Algal Bloom (RAB) algorithm is probably more suitable for HAB detection in the study area. Importantly, although RAB was also verified to be applicable for the detection of different kinds of HAB (Prorocentrum donghaiense, diatoms, Ceratium furca, and Akashiwo sanguinea), the capability of VIIRS in the classification of those algal species was limited by the lack of the critical band near 531 nm. Full article

The Visible Infrared Imaging Radiometer Suite (VIIRS) onboard the Suomi National Polar-orbiting Partnership (SNPP) satellite has been a reliable source of ocean color data products, including five moderate (M) bands and one imagery (I) band normalized water-leaving radiance spectra nL_w(λ). The spatial resolutions of the M-band and I-band nL_w(λ) are 750 m and 375 m, respectively. With the technique of convolutional neural network (CNN), the M-band nL_w(λ) imagery can be super-resolved from 750 m to 375 m spatial resolution by leveraging the high spatial resolution features of I1-band nL_w(λ) data. However, it is also important to enhance the spatial resolution of VIIRS-derived chlorophyll-a (Chl-a) concentration and the water diffuse attenuation coefficient at the wavelength of 490 nm (K_d(490)), as well as other biological and biogeochemical products. In this study, we describe our effort to derive high-resolution K_d(490) and Chl-a data based on super-resolved nL_w(λ) images at the VIIRS five M-bands. To improve the network performance over extremely turbid coastal oceans and inland waters, the networks are retrained with a training dataset including ocean color data from the Bohai Sea, Baltic Sea, and La Plata River Estuary, covering water types from clear open oceans to moderately turbid and highly turbid waters. The evaluation results show that the super-resolved K_d(490) image is much sharper than the original one, and has more detailed fine spatial structures. A similar enhancement of finer structures is also found in the super-resolved Chl-a images. Chl-a filaments are much sharper and thinner in the super-resolved image, and some of the very fine spatial features that are not shown in the original images appear in the super-resolved Chl-a imageries. The networks are also applied to four other coastal and inland water regions. The results show that super-resolution occurs mainly on pixels of Chl-a and K_d(490) features, especially on the feature edges and locations with a large spatial gradient. The biases between the original M-band images and super-resolved high-resolution images are small for both Chl-a and K_d(490) in moderately to extremely turbid coastal oceans and inland waters, indicating that the super-resolution process does not change the mean values of the original images. Full article

The geostationary ocean color imager (GOCI), as the world’s first operational geostationary ocean color sensor, is aiming at monitoring short-term and small-scale changes of waters over the northwestern Pacific Ocean. Before assessing its capability of detecting subdiurnal changes of seawater properties, a fundamental understanding of the uncertainties of normalized water-leaving radiance (nLw) products introduced by atmospheric correction algorithms is necessarily required. This paper presents the uncertainties by accessing GOCI-derived nLw products generated by two commonly used operational atmospheric algorithms, the Korea Ocean Satellite Center (KOSC) standard atmospheric algorithm adopted in GOCI Data Processing System (GDPS) and the NASA standard atmospheric algorithm implemented in Sea-Viewing Wide Field-of-View Sensor Data Analysis System (SeaDAS/l2gen package), with Aerosol Robotic Network Ocean Color (AERONET-OC) provided nLw data. The nLw data acquired from the GOCI sensor based on two algorithms and four AERONET-OC sites of Ariake, Ieodo, Socheongcho, and Gageocho from October 2011 to March 2019 were obtained, matched, and analyzed. The GDPS-generated nLw data are slightly better than that with SeaDAS at visible bands; however, the mean percentage relative errors for both algorithms at blue bands are over 30%. The nLw data derived by GDPS is of better quality both in clear and turbid water, although underestimation is observed at near-infrared (NIR) band (865 nm) in turbid water. The nLw data derived by SeaDAS are underestimated in both clear and turbid water, and the underestimation worsens toward short visible bands. Moreover, both algorithms perform better at noon (02 and 03 Universal Time Coordinated (UTC)), and worse in the early morning and late afternoon. It is speculated that the uncertainties in nLw measurements arose from aerosol models, NIR water-leaving radiance correction method, and bidirectional reflectance distribution function (BRDF) correction method in corresponding atmospheric correction procedure. Full article

Sun induced chlorophyll fluorescence (SICF) emitted by phytoplankton provides considerable insights into the vital role of the carbon productivity of the earth’s aquatic ecosystems. However, the SICF signal leaving a water body is highly affected by the high spectral variability of its optically active constituents. To disentangle the SICF emission from the water-leaving radiance, a new high spectral resolution retrieval algorithm is presented, which significantly improves the fluorescence line height (FLH) method commonly used so far. The proposed algorithm retrieves the reflectance without SICF contribution by the extrapolation of the reflectance from the adjacent regions. Then, the SICF emission curve is obtained as the difference of the reflectance with SICF, the one actually obtained by any remote sensor (apparent reflectance), and the reflectance without SICF, the one estimated by the algorithm (true reflectance). The algorithm first normalizes the reflectance spectrum at 780 nm, following the similarity index approximation, to minimize the variability due to other optically active constituents different from chlorophyll. Then, the true reflectance is estimated empirically from the normalized reflectance at three wavelengths using a machine learning regression algorithm (MLRA) and a cubic spline fitting adjustment. Two large reflectance databases, representing a wide range of coastal and ocean water components and scattering conditions, were independently simulated with the radiative transfer model HydroLight and used for training and validation of the MLRA fitting strategy. The best results for the high spectral resolution SICF retrieval were obtained using support vector regression, with relative errors lower than 2% for the SICF peak value in 81% of the samples. This represents a significant improvement with respect to the classic FLH algorithm, applied for OLCI bands, for which the relative errors were higher than 40% in 59% of the samples. Full article

Refined empirical algorithms for chlorophyll-a (Chl-a) concentration, using the maximum ratio of normalized water-leaving radiance nL_w(λ) at the blue and green bands, and Secchi depth (SD) from nL_w(λ) at 551 nm, nL_w(551), are proposed for the Visible Infrared Imaging Radiometer Suite (VIIRS) onboard the Suomi National Polar-orbiting Partnership (SNPP) satellite in the Great Lakes. We demonstrated that water quality properties and phytoplankton production can be successfully monitored and assessed using the new regional Chl-a and SD algorithms, with reasonably accurate estimates of Chl-a and SD from the VIIRS-SNPP ocean color data in the Great Lakes. VIIRS-derived Chl-a and SD products using the proposed algorithms provide the temporal and spatial variabilities in the Great Lakes. Overall, Chl-a concentrations are generally low in lakes Michigan and Huron, while Chl-a data are highest in Lake Erie. The seasonal pattern shows that overall low Chl-a concentrations appear in winter and high values in June to September in the lakes. The distribution of SD in the Great Lakes is spatially and temporally different from that of Chl-a. The SD data are generally lower in summer and higher in winter in most of the Great Lakes. However, the highest SD in Lake Erie appears in summer, and lower values in winter. Significantly high values in Chl-a, and lower values in SD, in the nearshore regions, such as Thunder Bay, Saginaw Bay, and Whitefish Bay, can be related to the very shallow bathymetry and freshwater inputs from the land. The time series of VIIRS-derived Chl-a and SD data provide strong interannual variability in most of the Great Lakes. Full article

A field intercomparison was conducted at the Acqua Alta Oceanographic Tower (AAOT) in the northern Adriatic Sea, from 9 to 19 July 2018 to assess differences in the accuracy of in- and above-water radiometer measurements used for the validation of ocean colour products. Ten measurement systems were compared. Prior to the intercomparison, the absolute radiometric calibration of all sensors was carried out using the same standards and methods at the same reference laboratory. Measurements were performed under clear sky conditions, relatively low sun zenith angles, moderately low sea state and on the same deployment platform and frame (except in-water systems). The weighted average of five above-water measurements was used as baseline reference for comparisons. For downwelling irradiance ( $E_d$ ), there was generally good agreement between sensors with differences of <6% for most of the sensors over the spectral range 400 nm–665 nm. One sensor exhibited a systematic bias, of up to 11%, due to poor cosine response. For sky radiance ( $L_{sky}$ ) the spectrally averaged difference between optical systems was <2.5% with a root mean square error (RMS) <0.01 mWm⁻² nm⁻¹ sr⁻¹. For total above-water upwelling radiance ( $L_t$ ), the difference was <3.5% with an RMS <0.009 mWm⁻² nm⁻¹ sr⁻¹. For remote-sensing reflectance ( $R_{rs}$ ), the differences between above-water TriOS RAMSES were <3.5% and <2.5% at 443 and 560 nm, respectively, and were <7.5% for some systems at 665 nm. Seabird-Hyperspectral Surface Acquisition System (HyperSAS) sensors were on average within 3.5% at 443 nm, 1% at 560 nm, and 3% at 665 nm. The differences between the weighted mean of the above-water and in-water systems was <15.8% across visible bands. A sensitivity analysis showed that $E_d$ accounted for the largest fraction of the variance in $R_{rs}$ , which suggests that minimizing the errors arising from this measurement is the most important variable in reducing the inter-group differences in $R_{rs}$ . The differences may also be due, in part, to using five of the above-water systems as a reference. To avoid this, in situ normalized water-leaving radiance ( $L_{wn}$ ) was therefore compared to AERONET-OC SeaPRiSM $L_{wn}$ as an alternative reference measurement. For the TriOS-RAMSES and Seabird-HyperSAS sensors the differences were similar across the visible spectra with 4.7% and 4.9%, respectively. The difference between SeaPRiSM $L_{wn}$ and two in-water systems at blue, green and red bands was 11.8%. This was partly due to temporal and spatial differences in sampling between the in-water and above-water systems and possibly due to uncertainties in instrument self-shading for one of the in-water measurements. Full article

The karst lakes in Jiuzhaigou Nature Reserve are an integral part of the karst lake landscape, yet research on the formation mechanism for the color of the blue-green lakes in Jiuzhaigou is insufficient. With the help of hyperspectral instruments, coupled with hydro-chemical analysis, this paper elaborates on the unique color characteristics of the Jiuzhaigou karst lakes, delves into the color formation mechanism of the lakes, establishes a regression equation for the color of the lakes as well as the water quality parameters, and sheds light upon the causes for the color distinction between the karst lakes in Jiuzhaigou and the plateau freshwater lakes. The experiment shows that the Jiuzhaigou karst lakes are primarily blue and green, while the proportion of short-wavelength light in the normalized water-leaving radiance and the total incident irradiance of lake water is higher. Based on the redundancy analysis and the correlation analysis, travertine deposition is the core link in the color formation of the blue karst lakes in Jiuzhaigou, while the selective reflection and scattering of the suspended calcium carbonate particulate matters towards visible light represents the optical foundation for the formation. In addition, physical factors such as depth and transparency, changes to the water quality parameters that affect the travertine deposition rate, and the eutrophication process will all exert significant influence over the formation. By building on water-leaving radiance, this paper quantifies the lake color with the tristimulus values (R, G, B) via colorimetrical methods, which features solid goodness of fit with the linear regression equation established based on the water quality parameters. The principal component analysis and colorimetrical analysis show that the color of the karst lakes in Jiuzhaigou varies substantially from that of the plateau freshwater lakes, which mainly results from the difference in the water quality. Research conducted in this paper on the color formation mechanism of the distinct blue karst lakes in Jiuzhaigou illuminates the formation and maintenance mechanism of the plateau karst lakes, which is conducive to better understanding towards the relationship between the water quality and colors of the karst lakes, and provides scientific proof for the establishment of the water quality assessment indicator system based on the colors of the karst lakes. Full article

Remote-sensing ocean color products have stringent requirements on radiometric calibration stability. To address a calibration deficiency in Moderate Resolution Imaging Spectroradiometer (MODIS) Aqua in recent years, the NASA Ocean Biology Processing Group (OBPG) developed a new calibration for reflective solar bands. Prior to the reprocessing of NASA’s ocean color products for 2018 (R2018), the OBPG MODIS products had been based on calibration provided by the MODIS Calibration Support Team (MCST). Several modifications were made to the MCST calibration approach to improve the calibration accuracy for ocean color products. These include (1) applying 936-nm detector normalization to solar diffuser stability monitor (SDSM) data to reduce coherent noise; (2) modeling solar diffuser (SD) degradation wavelength dependency to determine SD degradation in near-infrared and shortwave infrared wavelengths; (3) computing detector gains using SD screen-closed data to better match ocean radiance levels in all bands; (4) performing a simple atmospheric correction to reduce bidirectional reflectance distribution function (BRDF) effects in desert trends; (5) estimating and using modulated relative spectral response (RSR) impact on ocean data to adjust the calibration coefficients; (6) using smoothing to characterize the temporal change in calibration; and characterizing response versus scan angle (RVS) changes using 2nd-order polynomials to improve spatial/temporal calibration stability. Relative to the previous R2014 ocean color products, the R2018 calibration removed the suspect late-mission global trends in blue-band water-leaving reflectance and some anomalously large short-term variability (spikes) in the temporal trend of chlorophyll concentration. This paper will describe the OBPG calibration with a focus on the differences between the MCST and OBPG approaches. Full article

An approach that improves the spectral-based PHYSAT method for identifying phytoplankton functional types (PFT) in satellite ocean-color imagery is developed and applied to one study case. This new approach, called PHYSTWO, relies on the assumption that the dominant effect of chlorophyll-a (Chl-a) in the normalized water-leaving radiance (nLw) spectrum can be effectively isolated from the signal of accessory pigment biomarkers of different PFT by using Empirical Orthogonal Function (EOF) decomposition. PHYSTWO operates in the dimensionless plane composed by the first two EOF modes generated through the decomposition of a space–nLw matrix at seven wavelengths (412, 443, 469, 488, 531, 547, and 555 nm). PFT determination is performed using orthogonal models derived from the acceptable ranges of anomalies proposed by PHYSAT but adjusted with the available regional and global data. In applying PHYSTWO to study phytoplankton community structures in the coastal upwelling system off central Chile, we find that this method increases the accuracy of PFT identification, extends the application of this tool to waters with high Chl-a concentration, and significantly decreases (~60%) the undetermined retrievals when compared with PHYSAT. The improved accuracy of PHYSTWO and its applicability for the identification of new PFT are discussed. Full article

Normalized water-leaving radiance spectra nL_w(λ), particle backscattering coefficients b_bp(λ) in the near-infrared (NIR) wavelengths, and total suspended matter (TSM) concentrations over turbid waters are analytically correlated. To demonstrate the use of b_bp(λ) in the NIR wavelengths in coastal and inland waters, we used in situ optics and TSM data to develop two TSM algorithms from measurements of the Visible Infrared Imaging Radiometer Suite (VIIRS) onboard the Suomi National Polar-orbiting Partnership (SNPP) using backscattering coefficients at the two NIR bands b_bp(745) and b_bp(862) for Lake Taihu. The correlation coefficients between the modeled TSM concentrations from b_bp(745) and b_bp(862) and the in situ TSM are 0.93 and 0.92, respectively. A different in situ dataset acquired between 2012 and 2016 for Lake Taihu was used to validate the performance of the NIR TSM algorithms for VIIRS-SNPP observations. TSM concentrations derived from VIIRS-SNPP observations with these two NIR b_bp(λ)-based TSM algorithms matched well with in situ TSM concentrations in Lake Taihu between 2012 and 2016. The normalized root mean square errors (NRMSEs) for the two NIR algorithms are 0.234 and 0.226, respectively. The two NIR-based TSM algorithms are used to compute the satellite-derived TSM concentrations to study the seasonal and interannual variability of the TSM concentration in Lake Taihu between 2012 and 2016. In fact, the NIR-based TSM algorithms are analytically based with minimal in situ data to tune the coefficients. They are not sensitive to the possible nL_w(λ) saturation in the visible bands for highly turbid waters, and have the potential to be used for estimation of TSM concentrations in turbid waters with similar NIR nL_w(λ) spectra as those in Lake Taihu. Full article

The Geostationary Ocean Color Imager (GOCI) is the first geostationary ocean color sensor in orbit that provides bio-optical properties from coastal and open waters around the Korean Peninsula at unprecedented temporal resolution. In this study, we compare the normalized water-leaving radiance (nLw) products generated by the Naval Research Laboratory Automated Processing System (APS) with those produced by the stand-alone software package, the GOCI Data Processing System (GDPS), developed by the Korean Ocean Research & Development Institute (KORDI). Both results are then compared to the nLw measured by the above water radiometer at the Ieodo site. This above-water radiometer is part of the Aerosol Robotic NETwork (AeroNET). The results indicate that the APS and GDPS processed correlates well within the same image slot where the coefficient of determination (r²) is higher than 0.84 for all the bands from 412 nm to 745 nm. The agreement between APS and the AeroNET data is higher when compared to the GDPS results. The Root-Mean-Squared-Error (RMSE) between AeroNET and APS data ranges from 0.24 [mW/(cm²srμm)] at 555 nm to 0.52 [mW/(cm²srμm)] at 412 nm while RMSE between AeroNET and GDPS data ranges from 0.47 [mW/(cm²srμm)] at 443 nm to 0.69 [mW/(cm²srμm)] at 490 nm. Full article
