Search Results (69)

Search Parameters:
Keywords = operational deflection shape

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
23 pages, 6199 KB
Article
Climbing Tests and Dynamic Simulation of a Cable-Climbing Mechanism for Stay Cable De-Icing Robot
by Yaoyao Pei, Yayu Li, Zhi Chen, Henglin Xiao, Silu Huang and Changjie Li
Appl. Sci. 2025, 15(19), 10822; https://doi.org/10.3390/app151910822 - 9 Oct 2025
Viewed by 132
Abstract
In winter, stay cable sheaths are prone to icing, which increases cable loads and poses a falling-ice hazard upon thawing. While manual and chemical de-icing are common methods, their safety and cost drawbacks make robotic de-icing a promising alternative. Robotic de-icing offers a [...] Read more.
In winter, stay cable sheaths are prone to icing, which increases cable loads and poses a falling-ice hazard upon thawing. While manual and chemical de-icing are common methods, their safety and cost drawbacks make robotic de-icing a promising alternative. Robotic de-icing offers a promising alternative. However, to protect the sheath from damage, the de-icing blade is designed to minimize contact with its surface. Consequently, a thin layer of residual ice is often left behind, which reduces the surface friction coefficient and complicates the climbing process. This study evaluates the climbing performance of a self-manufactured cable-climbing mechanism through laboratory tests and dynamic simulations (ADAMS). A physical prototype was built, and dynamic simulations of the cable-climbing mechanism were conducted using Automated Dynamic Analysis of Mechanical Systems (ADAMS) software. The preliminary validation results demonstrate that the mechanism is capable of maintaining stable climbing under extreme conditions, including a friction coefficient of 0.12 to reflect thin-ice variability and indicated stable climbing even at μ = 0.12), a vertical inclination of 90°, and a load of 12 kg, confirming the design’s validity. Furthermore, we analyzed key parameters. A lower friction coefficient requires a higher clamping force and adversely affects the climbing speed due to increased slip. Similarly, an increased payload elevates the mechanism’s deflection angle, spring force, and wheel torque, which in turn reduces the climbing speed. Cable inclination has a complex effect: deflection decreases with slope, yet clamping force peaks near 70°, showing a bell-shaped trend. This peak requirement dictated the damping spring selection, which was given a safety margin. This ensures safe operation and acceleration at all other angles. Limitations: The present results constitute a feasibility validation under controlled laboratory conditions and rigid-support simulations. The long-term effects of residual ice and field performance remain to be confirmed in planned field trials. Full article
Show Figures

Figure 1

18 pages, 4069 KB
Article
Dynamic Response of Adjacent Tunnels to Deep Foundation Pit Excavation: A Numerical and Monitoring Data-Driven Case Study
by Shangyou Jiang, Wensheng Chen, Rulong Ma, Xinlei Lv, Fuqiang Sun and Zengle Ren
Appl. Sci. 2025, 15(19), 10570; https://doi.org/10.3390/app151910570 - 30 Sep 2025
Viewed by 155
Abstract
Urban deep excavations conducted near operational tunnels necessitate stringent deformation control. This study investigates the Baiyun Station excavation by employing a three-dimensional finite-element model based on the Hardening Soil Small-strain (HSS) constitutive law, calibrated using Phase I field monitoring data on wall deflection, [...] Read more.
Urban deep excavations conducted near operational tunnels necessitate stringent deformation control. This study investigates the Baiyun Station excavation by employing a three-dimensional finite-element model based on the Hardening Soil Small-strain (HSS) constitutive law, calibrated using Phase I field monitoring data on wall deflection, ground settlement, and tunnel displacement. Material parameters for the HSS model derived from the prior Phase I numerical simulation were held fixed and used to simulate the Phase II excavation, with peak errors of less than 5.8% for wall deflection and less than 2.9% for ground settlement. The model was subsequently applied to evaluate the impacts of Phase II excavation. The key contribution of this study is a monitoring-driven HSS modeling framework that integrates staged excavation simulation with field-based calibration, enabling quantitative assessment of tunnel responses—including settlement troughs, bow-shaped wall deflection patterns, and the distance-decay characteristics of lining displacement—to support structural safety evaluations and protective design measures. The results demonstrate that the predicted deformations and lining stresses in adjacent power and metro tunnels remain within permissible limits, offering practical guidance for excavation control in densely populated urban areas. Full article
Show Figures

Figure 1

14 pages, 3445 KB
Article
Hybrid Actuation MEMS Micromirror with Decoupled Piezoelectric Fast Axis and Electromagnetic Slow Axis for Crosstalk Suppression
by Haoxiang Li, Jiapeng Hou, Zheng Gong, Huijun Yu, Yue Liu and Wenjiang Shen
Micromachines 2025, 16(9), 1072; https://doi.org/10.3390/mi16091072 - 22 Sep 2025
Viewed by 362
Abstract
Electromagnetic micro-electro-mechanical system (MEMS) micromirrors are widely used in optical scanning systems but often encounter mechanical crosstalk due to the use of shared drive coils. This phenomenon leads to parasitic motion along the slow axis during fast-axis operation, resulting in undesirable elliptical scanning [...] Read more.
Electromagnetic micro-electro-mechanical system (MEMS) micromirrors are widely used in optical scanning systems but often encounter mechanical crosstalk due to the use of shared drive coils. This phenomenon leads to parasitic motion along the slow axis during fast-axis operation, resulting in undesirable elliptical scanning patterns that degrade image quality. To tackle this issue, a hybrid actuation scheme is proposed in which a piezoelectric actuator drives the fast axis through an S-shaped spring structure, achieving a resonance frequency of 792 Hz, while the slow axis is independently driven by an electromagnetic actuator operating in quasi-static mode. Finite element simulations and experimental measurements validate that the proposed decoupled design significantly suppresses mechanical crosstalk. When the fast axis is driven to a 40° optical scan angle, the hybrid system reduces the parasitic slow-axis deflection (typically around 1.43°) to a negligible level, thereby producing a clean single-line scan. The piezoelectric fast axis exhibits a quality factor of Q = 110, while the electromagnetic slow axis achieves a linear 20° deflection at 20 Hz. This hybrid design facilitates a distortion-free field of view measuring 40° × 20° with uniform line spacing, presenting a straightforward and effective solution for high-precision scanning applications such as LiDAR (Light Detection and Ranging) and structured light projection. Full article
Show Figures

Figure 1

25 pages, 8561 KB
Article
CFD-Driven Enhancement for Supersonic Aircraft Variable Geometry Inlet
by Abdullah Ezzeldin and Zhenlong Wu
Appl. Sci. 2025, 15(17), 9825; https://doi.org/10.3390/app15179825 - 8 Sep 2025
Viewed by 607
Abstract
High-speed propulsion systems require supersonic inlets for operation; however, these inlets lose efficiency when the flight speed range is wide. Fixed-geometry inlets designed for particular conditions encounter operational difficulties when running at supercritical speeds, including shockwave instabilities and pressure reduction, limiting their operational [...] Read more.
High-speed propulsion systems require supersonic inlets for operation; however, these inlets lose efficiency when the flight speed range is wide. Fixed-geometry inlets designed for particular conditions encounter operational difficulties when running at supercritical speeds, including shockwave instabilities and pressure reduction, limiting their operational speed and altitude range. Increasing inlet flexibility is a critical requirement for aerospace systems that need multivariable propulsion capabilities for civilian and military operations. This study, based on a supersonic inlet whose design flight Mach number is 2.2, determines its operational performance when operating at a speed of Mach 3 and then investigates modifications for expanding its operational boundaries with variable geometry components. This study used computational fluid dynamics in ANSYS Fluent with the k-ω SST turbulence model for airflow analysis. The methodology starts with Mach 2.2 baseline validation before proceeding to the Mach 3 investigation at different upward cowl-lip deflection angles ranging from 5° to 16°. This study conducted tests with a bleed slot and a 6 mm semi-conical bump to practically diminish unstart occurrences and treatment of shock–boundary-layer interactions. The results showed that a lip deflection angle of 15° upward delivers maximum operational efficiency on Mach 3 in terms of compression efficiency, flow deceleration, and flow uniformity at the inlet exit, as it generates an exit Mach number of 1.9, identical to that of the unmodified baseline operating at Mach 2.2, while a 5° deflection upward has shown the best values for total pressure recovery. Bleed slot implementation with the bump shape decreased unstart effects at a backpressure 30 times bigger than ambient pressure and produced stable flow despite a total pressure recovery drop of 8.5%. At Mach 3, with 15 km altitude, these modifications allow the system to operate with similar effectiveness as the baseline design at lower speeds. This study introduces a method for modifying a fixed-geometry inlet and extending its limitations, offering a pathway for adaptable supersonic inlets. The findings contribute to propulsion systems design by introducing a simple method for applying geometrical variations with less mechanical complexity compared to traditional variable geometry inlets. They change the entire throat area, supporting the design of supersonic vehicles and sustainable supersonic travel. Full article
Show Figures

Figure 1

26 pages, 4555 KB
Article
Influence of Geometric Effects on Dynamic Stall in Darrieus-Type Vertical-Axis Wind Turbines for Offshore Renewable Applications
by Qiang Zhang, Weipao Miao, Kaicheng Zhao, Chun Li, Linsen Chang, Minnan Yue and Zifei Xu
J. Mar. Sci. Eng. 2025, 13(7), 1327; https://doi.org/10.3390/jmse13071327 - 11 Jul 2025
Viewed by 554
Abstract
The offshore implementation of vertical-axis wind turbines (VAWTs) presents a promising new paradigm for advancing marine wind energy utilization, owing to their omnidirectional wind acceptance, compact structural design, and potential for lower maintenance costs. However, VAWTs still face major aerodynamic challenges, particularly due [...] Read more.
The offshore implementation of vertical-axis wind turbines (VAWTs) presents a promising new paradigm for advancing marine wind energy utilization, owing to their omnidirectional wind acceptance, compact structural design, and potential for lower maintenance costs. However, VAWTs still face major aerodynamic challenges, particularly due to the pitching motion, where the angle of attack varies cyclically with the blade azimuth. This leads to strong unsteady effects and susceptibility to dynamic stalls, which significantly degrade aerodynamic performance. To address these unresolved issues, this study conducts a comprehensive investigation into the dynamic stall behavior and wake vortex evolution induced by Darrieus-type pitching motion (DPM). Quasi-three-dimensional CFD simulations are performed to explore how variations in blade geometry influence aerodynamic responses under unsteady DPM conditions. To efficiently analyze geometric sensitivity, a surrogate model based on a radial basis function neural network is constructed, enabling fast aerodynamic predictions. Sensitivity analysis identifies the curvature near the maximum thickness and the deflection angle of the trailing edge as the most influential geometric parameters affecting lift and stall behavior, while the blade thickness is shown to strongly impact the moment coefficient. These insights emphasize the pivotal role of blade shape optimization in enhancing aerodynamic performance under inherently unsteady VAWT operating conditions. Full article
(This article belongs to the Special Issue Advanced Studies in Marine Data Analysis)
Show Figures

Figure 1

17 pages, 1635 KB
Article
The Conceptual Design of a Variable Camber Wing
by Spencer Troy P. Cortez, Seksan Winyangkul and Suwin Sleesongsom
Biomimetics 2025, 10(6), 353; https://doi.org/10.3390/biomimetics10060353 - 1 Jun 2025
Viewed by 928
Abstract
The variable camber wing (VCW) is a morphing wing design anticipated to enhance unmanned aerial vehicles’ (UAVs’) performance in flight through continuously changing shape. The performance of VCWs has been proven, but techniques for their integration, including aerodynamic analysis, mechanism synthesis, and structural [...] Read more.
The variable camber wing (VCW) is a morphing wing design anticipated to enhance unmanned aerial vehicles’ (UAVs’) performance in flight through continuously changing shape. The performance of VCWs has been proven, but techniques for their integration, including aerodynamic analysis, mechanism synthesis, and structural tests, still lag in development at the conceptual design stage. Therefore, this research focuses on designing a variable camber wing, a key area for the advancement of morphing aircraft. Inspired by the high-lift capabilities of traditional aircraft devices but aiming for smoother airflow through continuous shape alteration, this research proposes a novel three-step design for a structurally integrated VCW. This approach begins with a critical aerodynamic analysis to determine wing shape adaptations across various flight conditions, followed by a mechanism synthesis phase to design a four-bar linkage that accurately approximates the desired trailing edge deflections by utilizing a variant of teaching–learning-based optimization. The objective is to minimize error between the intended and actual coupler link while adhering to design constraints for proper integration in the wing structure. Finally, structural analysis evaluates the skin’s ability to withstand operational loads and ensure the integrity of the VCW system. The design result demonstrates the success of this three-step approach to synthesizing a VCW mechanism that meets the defined aerodynamic (actual deflection of 9.1764°) and structural targets (maximum Von Mises stress of 81.5 MPa and maximum deflection of 0.073 m), paving the way for enhanced aircraft performance. Full article
Show Figures

Figure 1

23 pages, 7142 KB
Article
Analysis of Vibration Characteristics of the Grading Belt in Wolfberry Sorting Machines
by Yang Yu, Zhiwei Su, Junhao Zhang, Jinglong Li and Wu Qin
Appl. Sci. 2025, 15(11), 6022; https://doi.org/10.3390/app15116022 - 27 May 2025
Viewed by 471
Abstract
The vibration of the belt drive system in fresh wolfberry sorting machines significantly impacts the sorting efficiency of wolfberries. To analyze the vibration changes induced by the belt drive, a simulation model was developed using multi-body dynamics software, Recur Dyn. The lateral vibration [...] Read more.
The vibration of the belt drive system in fresh wolfberry sorting machines significantly impacts the sorting efficiency of wolfberries. To analyze the vibration changes induced by the belt drive, a simulation model was developed using multi-body dynamics software, Recur Dyn. The lateral vibration characteristics of the grading device’s belt were examined under varying initial tensions, speeds, and deflection angles. Response surface methodology (RSM) was employed to determine the relative influence of these factors on the belt’s vibration characteristics. The analysis indicated the order of influence, from greatest to least, as initial tension, deflection angle, and speed. Aiming to minimize the vibration amplitude at the belt’s midpoint, the optimal parameter combination was determined. The operating conditions yielding the minimum amplitude were found to be an initial tension of 520 N/mm, a drive speed of 60 rpm, and a belt deflection angle of 5°. Concurrently, a transverse vibration modal analysis was conducted to study the system’s natural frequencies and corresponding mode shapes, aiding in the identification of potential resonance issues. Finally, under optimal operating conditions, guided by the results of the belt simulation test, a 10 mm fillet was introduced at the edge of the pulley, effectively mitigating wear and vibration. Specifically, when the effective length of the transmission mechanism is set to 2200 mm and the total length of the fixed device is configured as 1600 mm, the amplitude attenuation rate achieves its peak value. This study demonstrates that the integration of theoretical analysis with simulation techniques provides a robust approach for optimizing the structural design of the grading device. Full article
Show Figures

Figure 1

22 pages, 18253 KB
Article
Damage Identification of Fiber-Reinforced Composite Thin Plate by Curvature Modal Shape Scanning Method
by Yougle Chang, Qi Zhao, Hao Han, Xiaodi Zhao, Lingyao Qin, Xiaoye Li, Liyan Wu and Hui Li
Materials 2025, 18(11), 2431; https://doi.org/10.3390/ma18112431 - 22 May 2025
Viewed by 469
Abstract
The damage location detection of the fiber-reinforced composite thin plate (FCTP) is studied through the curvature modal shape scanning method (CMSSM), utilizing the advantages of the sensitivity of curvature modal shapes to local stiffness changes and the high measurement accuracy of a laser [...] Read more.
The damage location detection of the fiber-reinforced composite thin plate (FCTP) is studied through the curvature modal shape scanning method (CMSSM), utilizing the advantages of the sensitivity of curvature modal shapes to local stiffness changes and the high measurement accuracy of a laser vibrometer. Firstly, our research begins with the construction of a laser scanning frame model for the FCTP. Subsequently, during the analysis of modal shape data extraction principles, the two-dimensional five-spot-tripling surface smoothing method is developed, so that the quantitative index for damage location detection of the FCTP, i.e., the damage localization index, can be derived. The operating deflection shapes of the FCTP at different natural frequencies are obtained, and the self-developed laser scanning vibration testing system is employed to scan and measure the vibration. Then, a TC500 fiber/epoxy composite plate is utilized as an experimental object to perform a damage identification experiment. It has been proven that this approach can detect the fiber breakage location of the FCTP with high accuracy. Finally, the influence of parameters such as boundary constraint, excitation level, and laser scanning rate on the damage detection results is also discussed. Through studies on influencing parameters, practical guidance is provided for the application of the damage identification approach of the FCTP. Full article
Show Figures

Figure 1

30 pages, 35859 KB
Article
Research on Propagation Characteristics of Fracture Grouting in Clay Formation
by Rong Fan, Tielin Chen, Man Li and Xueda Wei
Symmetry 2024, 16(12), 1599; https://doi.org/10.3390/sym16121599 - 30 Nov 2024
Viewed by 992
Abstract
Splitting grouting is a highly effective technique for reinforcing tunnels and underground structures, ensuring their operational stability and facilitating long-term maintenance. It has been widely adopted in the prevention and remediation of geological hazards. However, the theoretical research on the diffusion mechanisms of [...] Read more.
Splitting grouting is a highly effective technique for reinforcing tunnels and underground structures, ensuring their operational stability and facilitating long-term maintenance. It has been widely adopted in the prevention and remediation of geological hazards. However, the theoretical research on the diffusion mechanisms of split grouting lags behind its practical applications. This study addresses several key scientific challenges in understanding the diffusion behavior of split grouting. By integrating experimental design, numerical simulations, and theoretical analysis, we conduct a systematic investigation into the diffusion process and vein morphology of split grouting in both homogeneous and heterogeneous formations. We first employed a self-developed two-dimensional grouting test system to perform diffusion experiments on cohesive strata, focusing on the influence of various factors such as grout density, water/cement ratio, soil consistency, and fracture characteristics. The results provide insights into the diffusion patterns, morphology, soil pressure distribution, and surface uplift behavior of the grout veins. Subsequently, a numerical simulation program, developed in-house, based on the finite element method (FEM) and the volume of fluid (VOF) approach, was employed to model the entire process of fracturing grouting within clay strata. The experimental and numerical results indicate that grout vein diffusion in layered soil follows a Y-shaped pattern with an inclined deflection. In uniform strata, the surface uplift curve displays both symmetrical and asymmetrical “convex” elevations, while in heterogeneous soft and hard strata, the uplift is characterized by distinct “convex” deformations. Finally, based on these findings and the principles of contact mechanics, we analyze the underlying mechanisms. The results suggest that weak contact zones undergo tensile cracking and horizontal deflection prior to the formation of grout veins. Additionally, local stress rotations in the soil can induce tilting and deflection. The theoretical insights derived from this study provide valuable guidance for practical engineering applications. Full article
(This article belongs to the Section Engineering and Materials)
Show Figures

Figure 1

16 pages, 2230 KB
Article
Computational Analysis of Stiffness Reduction Effects on the Dynamic Behaviour of Floating Offshore Wind Turbine Blades
by Daniel O. Aikhuele and Ogheneruona E. Diemuodeke
J. Mar. Sci. Eng. 2024, 12(10), 1846; https://doi.org/10.3390/jmse12101846 - 16 Oct 2024
Cited by 1 | Viewed by 1600
Abstract
This paper describes the study of a floating offshore wind turbine (FOWT) blade in terms of its dynamic response due to structural damage and its repercussions on structural health monitoring (SHM) systems. Using a finite element model, natural frequencies and mode shapes were [...] Read more.
This paper describes the study of a floating offshore wind turbine (FOWT) blade in terms of its dynamic response due to structural damage and its repercussions on structural health monitoring (SHM) systems. Using a finite element model, natural frequencies and mode shapes were derived for both an undamaged and a damaged blade configuration. A 35% reduction in stiffness at node 1 was applied in order to simulate significant damage. Concretely, the results are that the intact blade has a fundamental frequency of 0.16 Hz, and this does not change when damaged, while higher modes exhibit frequency changes: mode 2 drops from 2.05 Hz to 2.00 Hz and mode 3 from 6.15 Hz to 6.01 Hz. The shifts show a critical loss in the capability of handling vibrational energy due to the damage; higher modes (4, 5, and 6) show larger frequency deviations going down to as low as 18.06 Hz in mode 6. The mode shape change is considerable for the edge-wise and flap-wise deflection of the 2D contour plots, indicating possible coupling effects between modes. These results indicate that lower modes are sensitive to stiffness reductions, and the continuous monitoring of the lower harmonic modes early is required to detect damages. These studies have helped to improve blade design, maintenance, and operational safety for FOWT systems. Full article
(This article belongs to the Special Issue Modelling Techniques for Floating Offshore Wind Turbines)
Show Figures

Figure 1

31 pages, 3793 KB
Article
A Circular Touch Mode Capacitive Rainfall Sensor: Analytical Solution and Numerical Design and Calibration
by Xiao-Ting He, Jun-Song Ran, Ji Wu, Fei-Yan Li and Jun-Yi Sun
Sensors 2024, 24(19), 6291; https://doi.org/10.3390/s24196291 - 28 Sep 2024
Cited by 1 | Viewed by 1434
Abstract
A circular capacitive rainfall sensor can operate from non-touch mode to touch mode; that is, under the action of enough rainwater, its movable electrode plate can form a circular contact area with its fixed electrode plate. Therefore, the weight of rainwater is borne [...] Read more.
A circular capacitive rainfall sensor can operate from non-touch mode to touch mode; that is, under the action of enough rainwater, its movable electrode plate can form a circular contact area with its fixed electrode plate. Therefore, the weight of rainwater is borne by only its movable electrode plate in non-touch mode operation but by both its movable and fixed electrode plates in touch mode operation, and the total capacitance of its touch mode operation is much larger than that of its non-touch mode operation. Essential to its numerical design and calibration is the ability to predict the deflection shape of its moveable electrode plate to determine its total capacitance. This requires the analytical solution to the fluid–structure interaction problem of its movable electrode plate under rainwater. In our previous work, only the analytical solution for the fluid–structure interaction problem before its movable electrode plate touches its fixed electrode plate was obtained, and how to numerically design and calibrate a circular non-touch mode capacitive rainfall sensor was illustrated. In this paper, the analytical solution for the fluid–structure interaction problem after its movable electrode plate touches its fixed electrode plate is obtained, and how to numerically design and calibrate a circular touch mode capacitive rainfall sensor is illustrated for the first time. The numerical results show that the total capacitance and rainwater volume when the circular capacitive rainfall sensor operates in touch mode is indeed much larger than that when the same circular capacitive rainfall sensor operates in non-touch mode, and that the average increase in the maximum membrane stress per unit rainwater volume when the circular capacitive rainfall sensor operates in touch mode can be about 20 times smaller than that when the same circular capacitive rainfall sensor operates in non-touch mode. This is where the circular touch mode capacitive rainfall sensor excels. Full article
(This article belongs to the Special Issue Recent Advances in Low Cost Capacitive Sensors)
Show Figures

Figure 1

19 pages, 3957 KB
Article
A Scaled Numerical Simulation Model for Structural Analysis of Large Wind Turbine Blade
by Guoqiang Gao, Hongsheng Shu, Zixin Yi, Shuyi Yang, Juchuan Dai and Fan Zhang
Energies 2024, 17(19), 4849; https://doi.org/10.3390/en17194849 - 27 Sep 2024
Cited by 3 | Viewed by 1664
Abstract
Numerical simulation technology is a crucial tool for reducing costs and increasing efficiency in the wind power industry. However, with the development of large-scale wind turbines, the computational cost of numerical simulation has gradually increased. This paper uses the geometric similarity, structural similarity [...] Read more.
Numerical simulation technology is a crucial tool for reducing costs and increasing efficiency in the wind power industry. However, with the development of large-scale wind turbines, the computational cost of numerical simulation has gradually increased. This paper uses the geometric similarity, structural similarity criterion, Reynolds similarity and boundary layer theory to establish a scaled model of the geometric three-dimensional shape, composite material, and finite element mesh of large wind turbine blades. The study analyzes the aerodynamic, gravitational, and centrifugal load variations within the scaled model. The proportional relationship between the scaled model’s operating parameters, the numerical simulation’s environmental parameters, and the mechanical response parameters is established. These parameters are coordinated to ensure the similarity of the blade structure and the fluid dynamics. For a geometric scale factor of 0.316, the relative difference in maximum deflection is 4.52%, with a reduction in calculation time by 48.1%. On the premise of ensuring the calculation accuracy of the aerodynamic and structural response of the blade, the calculation efficiency is effectively improved. Full article
(This article belongs to the Section A3: Wind, Wave and Tidal Energy)
Show Figures

Figure 1

18 pages, 7237 KB
Article
Ground Strength Test Technique of Variable-Camber Wing Leading Edge
by Shanshan Li, Xianmin Chen, Zhigang Wang and Yuanbo Liang
Biomimetics 2024, 9(8), 467; https://doi.org/10.3390/biomimetics9080467 - 1 Aug 2024
Viewed by 1586
Abstract
Morphing wing technology is crucial for enhancing the flight performance of aircraft. To address the monitoring challenges of full-scale variable-camber leading edges under flight conditions, this study introduces a ground-based strength testing technique aimed at precisely evaluating the deformation patterns and structural strength [...] Read more.
Morphing wing technology is crucial for enhancing the flight performance of aircraft. To address the monitoring challenges of full-scale variable-camber leading edges under flight conditions, this study introduces a ground-based strength testing technique aimed at precisely evaluating the deformation patterns and structural strength during actual operation. Firstly, the motion characteristics of the variable-camber leading edge were analyzed using numerical simulation based on kinematic theory. Secondly, a tracking loading test rig was designed and constructed to simulate the actuated deformation and aerodynamic loads of the leading edge. Next, mechanical boundary numerical simulation was then utilized to predict the motion trajectories of loading points on the upper and lower wing surfaces, and a multi-point coordinated control system was developed to achieve accurate experimental control. Finally, a multi-sensor iterative method was employed to ensure loading precision throughout the testing process. A case study was conducted using a leading edge test piece from a specific commercial aircraft. The results indicated that in the motion test of the variable-camber leading edge, the average error of the deflection angle was 4.59%; in the strength test, the average errors in the magnitude and direction of the applied load were 0.54% and 0.24%, respectively. These findings validate the effectiveness of the proposed technique in simulating the flight conditions of deforming wings and accurately obtaining the leading edge shape change curve, deformation accuracy curve, and strain curves of the upper and lower wing surfaces under deflection angles. Furthermore, this paper compares the deformation accuracy of different testing methods under test conditions, providing scientific evidence and technical support for the testing and evaluation of variable-camber leading edges. Full article
Show Figures

Figure 1

15 pages, 6721 KB
Article
Twist Angle Error Statistical Analysis and Uncertain Influence on Aerodynamic Performance of Three-Dimensional Compressor Rotor
by Yue Dan, Ruiyu Li, Limin Gao, Huawei Yu and Yuyang Hao
Aerospace 2024, 11(8), 614; https://doi.org/10.3390/aerospace11080614 - 26 Jul 2024
Cited by 1 | Viewed by 1377
Abstract
Twist angle errors along the blade radial direction are uncertain and affected by cutting force, tool wear, and other factors. In this paper, the measured twist angle errors of 13 sections of 72 rotor blades were innovatively analyzed to obtain the rational statistical [...] Read more.
Twist angle errors along the blade radial direction are uncertain and affected by cutting force, tool wear, and other factors. In this paper, the measured twist angle errors of 13 sections of 72 rotor blades were innovatively analyzed to obtain the rational statistical distribution. It is surprisingly found that the under-deflection systematic deviation of twist angle errors shows a gradually increasing W-shaped distribution along the radial direction, while the scatter is nearly linear. Logically, the statistical model is established based on the linear correlation of the scatter by regression analysis to reduce variable dimension from 13 to 1. The influence of the radial non-uniform twist angle errors’ uncertainty on the aerodynamic performance of the three-dimensional compressor rotor is efficiently quantified combining the non-intrusive polynomial chaos method. The results show that the mean values of mass flow rate, total pressure ratio, and isentropic efficiency at the typical operating conditions are lower than the nominal values due to the systematic deviation, indicating that the under-deflection twist angle errors lead to the decrease in compressor thrust. The compressor’s stable operating range is more sensitive to the scatter of twist angle errors, which is up to an order of magnitude greater than that of the total pressure ratio and isentropic efficiency, indicating the compressor’s safe and stable operation risk increases. Additionally, the flow field at the tip region is significantly affected by twist angle errors, especially at the shock wave position of the near-stall condition. Full article
Show Figures

Figure 1

17 pages, 18446 KB
Article
Operational Deflection Shape Measurements on Bladed Disks with Continuous Scanning Laser Doppler Vibrometry
by Cuihong Liu, Tengzhou Xu, Tao Chen, Shi Su, Jie Huang and Yijin Li
Sensors 2024, 24(11), 3413; https://doi.org/10.3390/s24113413 - 25 May 2024
Viewed by 1469
Abstract
The continuous scanning laser Doppler vibrometry (CSLDV) technique is usually used to evaluate the vibration operational deflection shapes (ODSs) of structures with continuous surfaces. In this paper, an extended CSLDV is demonstrated to measure the non-continuous surface of the bladed disk and to [...] Read more.
The continuous scanning laser Doppler vibrometry (CSLDV) technique is usually used to evaluate the vibration operational deflection shapes (ODSs) of structures with continuous surfaces. In this paper, an extended CSLDV is demonstrated to measure the non-continuous surface of the bladed disk and to obtain the ODS efficiently. For a bladed disk, the blades are uniformly distributed on a given disk. Although the ODS of each blade can be derived from its response data along the scanning path with CSLDV, the relative vibration direction between different blades cannot be determined from those data. Therefore, it is difficult to reconstruct the complete vibration mode of the whole blade disk. In order to measure the complete ODS of the bladed disk, a method based on ODS frequency response functions (ODS FRFs) has been proposed. While the ODS of each blade is measured by designing the suitable scanning paths in CSLDV, an additional response signal is obtained at a fixed point as the reference signal to identify the relative vibration phase between the blade and the blade of the bladed disk. Finally, a measurement is performed with a simple bladed disk and the results demonstrate the feasibility and effectiveness of the proposed extended CSLDV method. Full article
(This article belongs to the Topic Advances in Non-Destructive Testing Methods, 2nd Edition)
Show Figures

Figure 1
