Search Results (11)

Phasor measurement units (PMUs) provide synchronized measurements to enhance power system monitoring, strategically placed to achieve full network observability with minimal cost. In this paper, the PMU placement problem for critical buses is addressed using integer linear programming, taking into account both PMU contingencies and the impact of zero-injection buses. The primary contribution is the development of a multi-stage approach to place PMUs on critical buses. Moreover, it is demonstrated that considering PMU contingencies inherently accounts for line contingencies. Furthermore, a new performance metric, the Bus Coverage Index (BCI), is proposed to evaluate the effectiveness of the placement strategy. This index overcomes the limitations of existing indices, such as the Sum of Redundancy Index (SORI) and Bus Observability Index (BOI). The results are tested on various IEEE benchmark systems under four different cases, showing significantly improved results in terms of network observability and minimized number of PMUs. In Case 1, SORI values improved significantly for the IEEE 7 and IEEE 118 bus systems, while in Case 2, enhancements were observed in the IEEE 30 and IEEE 118 systems. Case 3 demonstrated consistency in results across systems. Notably, in Case 4, the number of required PMUs was reduced in the IEEE 30, IEEE 57, IEEE 118, and New England 39 bus systems, with complete network observability. Full article

Phasor measurement units (PMUs) are deployed at power grid nodes around the transmission grid, determining precise power system monitoring conditions. In real life, it is not realistic to place a PMU at every power grid node; thus, the lowest PMU number is optimally selected for the full observation of the entire network. In this study, the PMU placement model is reconsidered, taking into account single- and multi-capacity placement models rather than the well-studied PMU placement model with an unrestricted number of channels. A restricted number of channels per monitoring device is used, instead of supposing that a PMU is able to observe all incident buses through the transmission connectivity lines. The optimization models are declared closely to the power dominating set and minimum edge cover problem in graph theory. These discrete optimization problems are directly related with the minimum set covering problem. Initially, the allocation model is declared as a constrained mixed-integer linear program implemented by mathematical and stochastic algorithms. Then, the $0/1$ integer linear problem is reformulated into a non-convex constraint program to find optimality. The mathematical models are solved either in binary form or in the continuous domain using specialized optimization libraries, and are all implemented in YALMIP software in conjunction with MATLAB. Mixed-integer linear solvers, nonlinear programming solvers, and heuristic algorithms are utilized in the aforementioned software packages to locate the global solution for each instance solved in this application, which considers the transformation of the existing power grids to smart grids. Full article

The optimal PMU placement problem is placing the minimum number of PMUs in the network to ensure complete network observability. It is an NP-complete optimization problem. PMU placement based on cost and critical nodes is solved separately in the literature. This paper proposes a novel approach, a degree of centrality in the objective function, to combine the effect of both strategies to place PMUs in the power network optimally. The contingency analysis and the effect of zero-injection buses are solved to ensure the reliability of network monitoring and attain a minimum number of PMUs. Integer linear programming is used on the IEEE 7-bus, IEEE 14-bus, IEEE 30-bus, New England 39-bus, IEEE 57-bus, and IEEE 118-bus systems to solve this problem. The results are evaluated based on two performance measures: the bus observability index (BOI) and the sum of redundancy index (SORI). On comparison, it is found that the proposed methodology has significantly improved results, i.e., a reduced number of PMUs and increased network overall observability (SORI). This methodology is more practical for implementation as it focuses on critical nodes. Along with improvement in the results, the limitations of existing indices are also discussed for future work. Full article

Phasor Measurement Units (PMUs) are the backbone of smart grids that are able to measure power system observability in real-time. The deployment of synchronized sensors in power networks opens up the advantage of real-time monitoring of the network state. An optimal number of PMUs must be installed to ensure system observability. For that reason, an objective function is minimized, reflecting the cost of PMU installation around the power grid. As a result, a minimization model is declared where the objective function is defined over an adequate number of constraints on a binary decision variable domain. To achieve maximum network observability, there is a need to find the best number of PMUs and put them in appropriate locations around the power grid. Hence, maximization models are declared in a decision-making way to obtain optimality satisfying a guaranteed stopping and optimality criteria. The best performance metrics are achieved using binary integer, semi-definite, and binary polynomial models to encounter the optimal number of PMUs with suitable PMU positioning sites. All optimization models are implemented with powerful optimization solvers in MATLAB to obtain the global solution point. Full article

The pursuit of achieving total power network observability in smart grids using Phasor Measurement Units (PMUs) carries a significant promise of real-time Wide-Area Monitoring, Protection, and Control (WAMPAC). PMU applications eliminate periodical measurements, thereby increasing accuracy through a high sampling rate of the measured power systems quantities. The high costs of installation of PMUs for total power system observability presents a challenge in the implementation of PMUs. This is due to the expensive costs of PMU devices. This has led to a prominent optimal PMU placement (OPP) problem that researchers tirelessly aim to solve by ensuring a complete power network observability while using the least installed PMU devices possible. In this paper, a novel Binary Firefly Algorithm (BFA) based on the node degree centrality scores of each bus is proposed to minimize PMU installations. The BFA solves the OPP problem in consideration of the effect of Zero Injection Buses (ZIBs) under normal operation and single PMU outage (SPO). The robustness and efficiency of the proposed algorithm is tested on IEEE-approved test systems and visualized with a force-directed technique on an undirected power network graph. The proposed BFA yields the same but better optimal PMU numbers, obtained by existing meta-heuristic optimization techniques found in the literature for each of the IEEE test cases, as well as highlighting the cost–benefit of having a robust system against single PMU loss while considering the ZIB effect for an improved system measurement availability. Full article

Phasor measurement unit (PMU) technology is a need of the power system due to its better resolution than conventional estimation devices used for wide-area monitoring. PMUs can provide synchronized phasor and magnitude of voltage and current measurements for state estimation of the power system to prevent blackouts. The drawbacks of a PMU are the high cost of the device and its installation. The main aspect of using PMUs in electrical networks is the property to observe the adjacent buses, thereby making it possible to observe the system with fewer PMUs than the number of buses through their optimal placement. In the last two decades, exhaustive research has been done on this issue. Considering the importance of this field, a comprehensive review of the progress achieved until now is carried out and the limitations of existing reviews in the literature are highlighted. This paper can be seen as a major attempt to provide an up-to-date review of the research work carried out in this all-important field of PMU placement and indicates that some perspectives of optimal PMU placement still need attention. Eventually, the work will open a new standpoint for the research community to fill the research gap. Full article

Recent developments in electrical power systems are concerned not only with static power flow control but also with their control during dynamic processes. Smart Grids came into being when it was noticed that the traditional electrical power system structure was lacking in reliability, power flow control, and consistency in the monitoring of phasor quantities. The Phasor Measurement Unit (PMU) is one of the main critical factors for Smart Grid (SG) operation. It has the ability to provide real-time synchronized measurement of phasor quantities with the help of a Global Positioning System (GPS). However, when considering the installation costs of a PMU device, it is far too expensive to equip on every busbar in all grid stations. Therefore, this paper proposes a new approach for the Optimum Placement of the PMU problem (OPP problem) to minimize the installed number of PMUs and maximize the measurement redundancy of the network. Exclusion of the unwanted nodes technique is used in the proposed approach, in which only the most desirable buses consisting of generator bus and load bus are selected, without considering Pure Transit Nodes (PTNs) in the optimum PMU placement sets. The focal point of the proposed work considers, most importantly, the case factor of the exclusion technique of PTNs from the optimum PMU locations, as prior approaches concerning almost every algorithm have taken PTNs as their optimal PMU placement sets. Furthermore, other case factors of the proposed approach, namely, PMU channel limits, radial bus, and single PMU outage, are also considered for the OPP problem. The proposed work is tested on standard Institute of Electrical and Electronics Engineering (IEEE)-case studies from MATPOWER on the MATLAB software. To show the success of the proposed work, the outputs are compared with the existing techniques. Full article

Integer linear programming (ILP) has been widely applied to solve the optimal phasor measurement unit (PMU) placement (OPP) problem for its computational efficiency. Using ILP, a placement with minimum number of Phasor Measurement Units (PMUs) and maximum measurement redundancy can be obtained while ensuring system observability. Author response: please delete this above sentence. However, the existing ILP-based OPP methods does not guarantee full coverage of solutions to the optimization problem, which may sequentially results in suboptimal supervision of the system. In this paper, a hybrid ILP-based method is proposed to cover all solutions to the OPP problem without any omission. Comparing with the existing exhaustive searching methods, the proposed method is more computationally efficient, which makes finding all solutions in a large system a more feasible problem. Full article

A phasor measurement unit (PMU) can provide phasor measurements to the distribution network to improve observability. Based on pre-configuration and existing measurements, a network compression method is proposed to reduce PMU candidate locations. Taking the minimum number of PMUs and the lowest state estimation error as the objective functions and taking full observability of distribution network as the constraint, a multi objective model of optimal PMU placement (OPP) is proposed. A hybrid state estimator based on supervisory control and data acquisition (SCADA) and PMU measurements is proposed. To reduce the number of PMUs required for full observability, SCADA measurement data are also considered into the constraint by update and equivalent. In addition, a non-dominated sorting genetic algorithm-II (NSGA-II) is applied to solve the model to get the Pareto set. Finally, the optimal solution is selected from the Pareto set by the technique for order preference by similarity to ideal solution (TOPSIS). The effectiveness of the proposed method is verified by IEEE standard bus systems. Full article

Phasor measurement units (PMUs) are becoming popular and populating the power system grids rapidly due to their wide range of benefits and applications. This research paper proposes a comprehensive, effective, and revised formulation of the optimal PMU placement (OPP) problem with a view to minimizing the required number of PMU and ensuring the maximum number of measurement redundancy subjected to the full observability of the distribution grids. The proposed formulation also incorporates the presence of passive measurements/zero injection buses (ZIB) and the channel availability of the installed PMU. Additionally, the formulation is extended to various contingency cases i.e., the single line outage and single PMU loss cases. This paper solves the proposed OPP formulation employing a heuristic technique called backtracking search algorithm (BSA) and tests its effectiveness through different IEEE standard distribution feeders. Additionally, this study compares the obtained results with the mixed integer linear programming (MILP)-based approach and the referenced works. The obtained results demonstrate the superiority of the proposed formulation and solution methodology compared to other methodologies. Full article

Micro-phasor measurement unit (μPMU) is under fast development and becoming more and more important for application in future distribution networks. It is unrealistic and unaffordable to place all buses with μPMUs because of the high costs, leading to the necessity of determining optimal placement with minimal numbers of μPMUs in the distribution system. An optimal μPMU placement (OPP) based on the information entropy evaluation and node selection strategy (IENS) using greedy algorithm is presented in this paper. The uncertainties of distributed generations (DGs) and pseudo measurements are taken into consideration, and the two-point estimation method (2PEM) is utilized for solving stochastic state estimation problems. The set of buses selected by improved IENS, which can minimize the uncertainties of network and obtain system observability is considered as the optimal deployment of μPMUs. The proposed method utilizes the measurements of smart meters and pseudo measurements of load powers in the distribution systems to reduce the number of μPMUs and enhance the observability of the network. The results of the simulations prove the effectiveness of the proposed algorithm with the comparison of traditional topological methods for the OPP problem. The improved IENS method can obtain the optimal complete and incomplete μPMU placement in the distribution systems. Full article
