Search Results (18)

Changes in the refractive indices of a GaAs laser chip owing to bonding strain are investigated by two-dimensional (2D) and three-dimensional (3D) finite element method (FEM) simulations. The strain induced by die attach (i.e., the bonding strain) was estimated by fitting simulations to the measured degree of polarisation (DOP) of photoluminescence from the facet of the bonded chip. Changes in the refractive indices were estimated using the strains obtained from fits to DOP data. Differences between the 2D and 3D FEM estimations of the deformation and of the photo-elastic effect are noted. It is recommended that 2D FEM simulations be used as starting points for 3D FEM simulations. Elastic constants for GaAs in plane-of-the-facet coordinate systems for 2D (plane stress and plane strain) and 3D FEM simulations are given. Full article

This study presents an experimental and numerical investigation into the stress field in cylinders manufactured from photosensitive resin using the Masked Stereolithography (MSLA) technique. For material characterization, tensile and bending test data from resin specimens were utilized. The stress field in resin disks was experimentally analyzed using photoelasticity and Digital Image Correlation (DIC) methods, subjected to compressive loads, according to the cylinder–plane contact model. Images were captured during the experiments using polarizing film and a low-cost CPL lens, coupled to a smartphone. The experimental results were compared with numerical and analytical simulations, where the formation of fringes and regions indicating the direction and magnitude of normal and shear stresses were observed, with variations ranging from 0.6% to 8.2%. The convergence of the results demonstrates the feasibility of using parts produced with commercially available photosensitive resin on non-professional printers for studying contact theory and stress fields. In the future, this methodology is intended to be applied to studies on stress in gears. Full article

This study investigates the impact of various experimental parameters on the reflective photoelastic coating technique used to measure the stress and strain in model soil particles. The focus is directed towards three pivotal parameters: the choice of adhesive for the photoelastic coating, the inherent properties of the light source, and the configuration of the camera for color image analysis. Through a series of uniaxial compression tests on consistently crafted model soil particles, a notable relationship emerges between the adhesive’s shear strength, its viscosity, and the uniformity of the photoelastic response. While the light source’s characteristics and camera adjustments hold significance, their influence on the consistency of the response is comparatively subtle. Consequently, the adhesive’s role is underscored as instrumental in influencing the photoelastic response, offering valuable insights for subsequent research endeavors utilizing the reflective photoelastic technique. Full article

In the present work, the interaction between electrons and holes in semiconductor materials is investigated. According to the excitation process, the optical-elastic-thermal-diffusion (OETD) process is considered when the medium is exposed to a strong magnetic field and laser pulses. Photo-elastic and photo-electronics deformations are taken into account when the Hall current impact appears due to the magnetic field pressure on the semiconductor medium. Due to the complexity of the model, the governing equations that describe the system in one dimension (1D) are studied. Mathematical transformations (Laplace transform) were used to simplify the equations to obtain the physical quantities under study which were affected by laser pulses. To obtain complete solutions, some conditions were obtained from the free surface as well as from a mechanical ramp type and pulse heat flux, and then numerical transformations were applied using the inverse Laplace transform. Under the influence of several variables in this question, the results were explained graphically for silicon (Si) material and the results were analyzed in terms of their physical significance. Full article

Our study investigated the partially degenerate intermodal four-wave mixing (IM-FWM) process in nonlinear multimode optical fibers with strain-induced birefringence. The difference in the refractive index along the two orthogonal directions was due to the photoelastic effect that occurred when the fiber under test (FUT) was subjected to uniformly applied diameter stress caused by winding on a cylinder of a given diameter. Our work analyzed how the nonlinear frequency conversion and the output modal field profiles depended on the degree of birefringence in FUT. The experimental results significantly affected the order of the excited moduli in fiber sections characterized by different amounts of birefringence. We also checked the efficiency of the FWM process for different polarizations of the pump beam to determine those for which the FWM process was most effective for the 532 nm sub-nanosecond pulses. More than 30% conversion efficiency was obtained for the FUTs with a length of tens of centimeters. Full article

We investigated the strength of acousto-optical (AO) interaction in one-dimensional fishbone silicon nanobeam computationally. The structure can generate phononic and photonic band gaps simultaneously. We use defect cavity optical mode and slow light mode to interact with acoustic defect modes. The AO coupling rates are obtained by adding the optical frequency shifts, which result from photo-elastic effect and moving-boundary effect disturbances. The AO coupling rates are strongly dependent on the overlap of acoustic and optical mode distribution. The strength of AO interaction can be enhanced by choosing certain acoustic defect modes that are formed by the stretching of wings and that overlap significantly with optical fields. Full article

A statistical experimental investigation of the characteristic changes associated with the degree-of-polarization reduction of high-power laser diodes is reported. A simple model accounting for the stress-induced degree-of-polarization changes through the photoelastic effect is introduced to qualitatively support the experimental results. Functional characteristics addressed in the investigation are the threshold current, the slope efficiency, the polarization-resolved far field and near field, and the beam parameter product. Model outcomes and measured parameters related to different degree-of-polarization values have proven very useful for device optimization aimed to polarization multiplexing applications. Full article

This work aims to explore the interaction between water and ion-exchanged aluminosilicate glass. The surface mechanical properties of ion-exchanged glasses after different hydration durations are investigated. The compressive stress and depth of stress layer are determined with a surface stress meter on the basis of photo-elasticity theory. The hardness and Young’s modulus are tested through nanoindentation. Infrared spectroscopy is used to determine the variation in surface structures of the glass samples. The results show that hydration has obvious effects on the hardness and Young’s modulus of the raw and ion-exchanged glasses. The hardness and Young’s modulus decrease to different extents after different hydration times, and the Young’s modulus shows some recovery with the prolonging of hydration time. The ion-exchanged glasses are more resistant to hydration. The tin side is more resistant to hydration than the air side. The results are expected to serve as reference for better understanding the hydration process of ion-exchanged glass. Full article

The phenomenon of residual stress in optical lens injection molding affects the quality of optical devices, with the refractive errors that are caused by geometric errors being the most serious, followed by the reduced accuracy and function of optical components; it is very important to ensure that the lens geometry remains intact and that the refractive index is reduced. This paper uses a photoelastic stress compensation method for measurement verification along with fuzzy theory to reorganize a set of processes that can be used to evaluate the residual stress of a product, whereby the use of corresponding theoretical formulas can effectively quantify and measure the residual stress of the product. A mold flow simulation is used to analyze the molded optical components and determine the feasibility of evaluating the quality of the lens. Through the measurement of the refractive stress value of the optical components, the molding quality of the lens can be improved, and its force distribution effects can be investigated. Geometric analysis and shear stress affect the performance of optical components, and these errors may also cause irreparable problems during secondary processing. Therefore, it is crucial to reduce the residual stress of optical components. When the stress distribution is uniform and the internal melting pressure is reasonably configured, the product’s shrinkage rate can be controlled; the method for determining the residual stress is the core theme of this research. Full article

This study is a contribution to our understanding of the mechanical behaviour of dental implants through the use of the finite element and the photoelastic methods. Two internal connection and bone level dental implants with different design have been analysed (M-12 by Oxtein S.L., Zaragoza, Spain, and ASTRA, from Dentsply Sirona, Charlotte, NC, USA), evaluating the stress distribution produced by axial stresses and a comparison has been established between them, as well as between the two methods used, in order to validate the adopted hypotheses and correlate the numerical modelling performed with experimental tests. To load the implant in laboratory testing, a column was placed, such that the loading point was about 9.3 mm from the upper free surface of the resin plate. This column connects the implant with the weights used to define the test load. In turn, support for both plates was achieved by two 6 mm bolts 130 mm apart and located on a parallel line with the resin (flush with the maximum level of the implant), at a depth of 90 mm. The results obtained with both methods used were similar enough. The comparison of results is fundamentally visual, but ensures that, at least in the range of forces used, both methods are similar. Therefore, the photoelastic method can be used to confirm in a real way the virtual conditions of the finite element models, with the implications in the investigation of dental implants that this entails. Full article

This paper aimed to perform systematical study on the distribution of landslide thrust in pile-anchor support system, which has been a widely applicable treatment method in landslide control with safety, highly efficiency and adaptation. The advantage of photoelastic technique is visualization of strain and stress fields, therefore photoelastic model tests are conducted to show the distribution of landslide thrust in pile-anchor structure before failure in landslide. The effects of different materials and pile lengths are investigated by 6 photoelastic test cases under different loading conditions. It can be found from quantitative analysis of experimental results that load proportion of anchor would increase gradually with the decrease of pile embedded depth or the increase of landslide thrust force. Meanwhile, landslide thrust distribution in pile-anchor structure is directly affected by the stiffness of piles. The pile-anchor structure is significantly better at reducing bending moment value and optimizing bending moment distribution of pile. Finally, some theoretical analysis and design suggestions are proposed based on the experimental study. Full article

Optical polyimide (PI) membranes have been increasingly attractive in optoelectronic substrate and optical element material applications. Controlled stress distribution is very important to optical PI membrane-based optics. However, nondestructive absolute stress measurement inside optical PI membranes remains challenging. In this letter, we adopted the stress birefringence method to experimentally investigate the correlation between stress and retardation in uniaxially, biaxially, and circularly stretched PI membranes. The calculated value of the photoelastic coefficient was found to be around 400 nm/Mpa·cm. A theoretical model was established where the retardation angle is the negative arctan of the principal stress ratio in the biaxially stretched membrane. We also found that the average retardation angle is an important parameter for evaluating the uniformity of stretching force in the circularly stretched membrane. This work provides a better understanding of the stress birefringence measurement of membrane materials. Full article

The effect of initial granular structural conditions on load transmission patterns was experimentally investigated. Two types of granular structures were prepared by laminating cylindrical model particles of different diameters, to which photoelastic sheets were attached. Two-dimensional, reflective photoelasticity tests were performed under two granular conditions: (1) a uniform structure without initial defects and (2) with initial local imperfections at the bottom of the granular assembly. Two granular assemblies were tested for uniaxial compressive loading and shallow foundation loading conditions. For macroscopic analyses of the load–displacement relationship, the photoelastic response of individual particles was measured to microscopically observe the distribution of the main contact force chains within each granular assembly. Furthermore, the effect of initial local defects on the bearing capacity of granular assemblies was examined by confirming particle movement and the expansion of initial local defects in the granular assembly via particle image velocimetry (PIV). As a result, a completely different form of internal contact force chain was developed from the beginning of loading to the final failure stage, depending upon whether or not initial local instability existed in the granular assembly. In particular, a significant effect on the bearing capacity was found under shallow foundation loading conditions. Full article

This study focuses on understanding the effect of cellulose nanocrystals (CNCs) on glass fiber/epoxy interfacial interactions. The glass fibers (GF) were coated with solutions containing cellulose nanomaterial. The parameters that were investigated were the CNC surface chemistry, concentration, and dispersing medium, i.e., aqueous solution only versus emulsions. To determine the effect of the CNC coatings on the interfacial adhesion, specimens of a single GF in an epoxy matrix were prepared for GF coating by varying the coating formulations. The interfacial shear stress (IFSS) was determined by the single fiber fragmentation test (SFFT). Following the SFFT, the samples were investigated by cross-polarized microscopy in order to understand the fracture modes which are related to the nature of the interphase. According to the SFFT data and photoelastic fracture patterns, both the emulsion and aqueous coatings containing cellulose nanocrystals functionalized with methyl(triphenyl) phosphonium (CNCPh) improve the IFSS in comparison to coated GFs without CNCs. Full article

Ion-releasing polymeric restorative materials seem to be promising solutions, due to their possible anticaries effect. However, acid functional groups (monomers) and glass filler increase hydrophilicity and, supposedly, water sorption. The purpose of the study was to evaluate the influence of water sorption of polymeric materials on the stress state at the restoration-tooth interface. Beautifil Bulk Fill Flow, Beautifil Flow Plus F00, Beautifil Flow F02, Dyract eXtra, Compoglass Flow, Ionosit, Glasiosite, TwinkiStar, Ionolux and Fuji II LC were used for the study. The stress state was measured using photoelastic analysis after: 0.5, 24, 72, 96, 168, 240, 336, 504, 672, 1344 and 2016 h. Moreover, water sorption, solubility and absorption dynamic were assessed. The water sorption, solubility and absorption dynamic of ion-releasing restorative materials are material dependent properties. The overall results indicated that the tested restorative materials showed significant stress decrease. The total reduction in contraction stress and water expansion stress was not observed for materials with low value of water sorption (Beautifil Bulk Fill, Dyract eXtra, Glasionosit and Twinky Star). The photoelastic method turned out to be inadequate to evaluate stress changes of resin modified glass-ionomer cement (RMGI, Fuji II LC and Ionolux). Full article
