A T-shaped photonic crystal waveguide was designed with square lattice tellurium photonic crystals. A diamond-shaped ferrite pillar array was inserted in the junction of the waveguide to make a novel terahertz polarization splitter. Both transverse electric and transverse magnetic modes were numerically investigated by the plane wave expansion method, which used complete photonic band gaps covering from 0.138 THz to 0.144 THz. In this frequency domain of the fully polarized band gaps, the transmission efficiency of the photonic crystal waveguide was up to −0.21 dB and −1.67 dB for the transverse electric and transverse magnetic modes, respectively. Under the action of a DC magnetic field, the THz waves were rotated 90 degrees by the diamond-shaped ferrite pillar array. Transverse electric waves or transverse magnetic waves can be separated by a polarization isolator (six smaller tellurium rods) from the fixed waves. The characteristics of the designed polarization splitter were analyzed by the finite element method, and its transmission efficiency was optimized to 95 percent by fine-tuning the radii of the thirteen ferrite pillars. A future integrated communication network of sky–earth–space will require fully polarized devices in the millimeter and terahertz wavebands. The envisaged polarization splitter has a unique function and provides a promising method for the realization of fully polarized 6G devices. Full article

A review of recent advances in spacetime optics is given, with special emphasis on time refraction. This is a basic optical process, occurring at a temporal discontinuity or temporal boundary, which is able to produce various different effects, such as frequency shifts, energy amplification, time reflection, and photon emission. If, instead of a single discontinuity, we have two reverse temporal boundaries, we can form a temporal beam splitter, where temporal interferences can occur. It will also be shown that, in the presence of an axis of symmetry, such as a magnetic field, the temporal beam splitter can induce a rotation of the initial polarization state, similar to a Faraday rotation. Recent work on time crystals, superluminal fronts, and superfluid light will be reviewed. Time gates based on spacetime optical effects will be discussed. We also mention recent work on optical metamaterials. Finally, the quantum properties of time refraction, which imply the emission of photon from vacuum, are considered, while similar problems in high-energy QED associated with electron–positron pairs are briefly mentioned. Full article

We designed 60% thick airfoil to improve the aerodynamic performance in the root region of wind turbine rotor blades, taking into account current constraints. After an extensive literature review and patent research, a design methodology (including the considerations of simple manufacturing) was set up, and extensive 2D- and 3D-CFD investigations with four codes (Xfoil, MSES, ANSYS fluent, and DLR-tau) were performed, including implementation inside a generic 10 MW test-blade (CIG10MW). Comparison with results from Blade Element Momentum (BEM) methods and the estimation of 3D effects due to the rotating blade were undertaken. One specific shape (with a pronounced flat-back) was selected and tested in the Deutsche WindGuard aeroacoustic Wind Tunnel (DWAA), in Bremerhaven, Germany. A total of 34 polars were measured, included two trailing edge shapes and aerodynamic devices such as vortex generators, gurney flaps, zig-zag tape, and a splitter plate. Considerable changes in lift and drag characteristics were observed due to the use of aerodynamic add-ons. With the studies presented here, we believe we have closed an important technological gap. Full article

Coarse wavelength division multiplexing (CWDM)-targeted novel silicon (Si)-nanowire-type polarization-diversified optical demultiplexers were numerically analyzed and experimentally verified. The optical demultiplexer comprised a hybrid mode conversion-type polarization splitter rotator (PSR) and a delayed Mach–Zehnder interferometric demultiplexer. Si-nanowire-based devices were fabricated using a commercially available Si photonics foundry process, exhibiting nearly identical spectral responses regardless of the polarization states of the input signals under the PSR. The experiment demonstrated a low insertion loss of 1.0 dB and a polarization-dependent loss of 1.0 dB, effectively suppressing spectral crosstalk from other channels by less than −15 dB. Furthermore, a TM-mode rejection-filter-integrated optical demultiplexer was designed and experimentally validated to mitigate unwanted TM-mode-related polarization crosstalk that arose from the PSR. It exhibited an improved polarization crosstalk rejection efficiency of −25 dB to −50 dB within the whole CWDM spectral range. Full article

Fano resonances that feature strong field enhancement in the narrowband range have motivated extensive studies of light–matter interactions in plasmonic nanomaterials. Optical metasurfaces that are subject to different mirror symmetries have been dedicated to achieving nanoscale light manipulation via plasmonic Fano resonances, thus enabling advantages for high-sensitivity optical sensing and optical switches. Here, we investigate the plasmonic sensing and switches enriched by tailorable multiple Fano resonances that undergo in-plane mirror symmetry or asymmetry in a hybrid rotational misalignment metasurface, which consists of periodic metallic arrays with concentric C-shaped- and circular-ring-aperture unit cells. We found that the plasmonic double Fano resonances can be realized by undergoing mirror symmetry along the X-axis. The plasmonic multiple Fano resonances can be tailored by adjusting the level of the mirror asymmetry along the Z-axis. Moreover, the Fano-resonance-based plasmonic sensing that suffer from mirror symmetry or asymmetry can be implemented by changing the related structural parameters of the unit cells. The passive dual-wavelength plasmonic switches of specific polarization can be achieved within mirror symmetry and asymmetry. These results could entail benefits for metasurface-based devices, which are also used in sensing, beam-splitter, and optical communication systems. Full article

The standard silicon photonic platforms provide three-step silicon etching, i.e., 220 nm for full etching, 70 nm for shallow etching, and 130 nm (or 150 nm) for slab etching. Previously reported mode-evolution-based polarization rotators and splitters (PSRs) usually employ 130 nm-etched slab waveguides for adiabatic TM${}_0$-to-TE${}_1$ conversion, however, they are not compatible with the platforms adopting 150 nm-etching techniques. In this paper, we demonstrate a broadband PSR based on 70 nm-etched slab waveguides, which is compatible with all the platforms. The PSR consists of a bi-level taper and an inverse-tapered coupler. The length of the polarization rotator shrinks from hundreds to only thirty microns by employing the 70 nm-etched slab waveguides, while a high efficiency of >95% is achieved, covering an ultra-wide bandwidth from 1250 nm to 1650 nm. The proposed PSR shows superior performance over S, C, and L bands. Low cross-talk of <−20 dB and a loss of <1.5 dB are experimentally confirmed over a wavelength range of 75 nm. Full article

Polarization splitter–rotators (PSRs) are an essential component in on-chip polarization-sensitive and polarization–division multiplexing systems. In this work, we propose an ultracompact and high-performance silicon-based polarization splitter–rotator utilizing anisotropic metasurfaces, which is the first to combine the two, to our knowledge. The tilted periodic metasurface structure has different modulation effects on different polarized light fields, such as the transverse–electric (TE) mode and the transverse–magnetic (TM) mode, which are beneficial for designing polarization management devices. According to the results, the entire length of the silicon PSR was ~13.5 μm. The TE-to-TM conversion loss and polarization conversion ratio ere −0.154 dB and 96.5% at 1.55 μm, respectively. In the meanwhile, the cross talk and reflection loss were −27.0 dB and −37.3 dB, when the fundamental TE mode was input. The insertion loss and cross talk were −0.19 dB and −25.01 dB at the central wavelength when the fundamental TM mode was input. In addition, the bandwidth reached up to ~112 nm with polarization conversion loss and insertion loss higher than −0.46 dB and −0.36 dB. The simulations also show that the designed devices had good fabrication tolerance. Full article

This paper describes a modified Sagnac interferometer with a self-referenced polarization and phase-shifting technique for real-time thickness measurement of single- and double-layer transparent thin films. The proposed interferometric setup generated outstanding rotating linearly polarized light with a degree of polarization (DOP) of 99.40%. A beam splitter placed at the interferometer output separated the beam into two identical linearly polarized beams. One of the beams served as a reference, while the other served as a sensing arm. The output linear polarizer set at 45° relative to a reference plane was positioned anterior to the photodetectors to get rotating light intensities for phase shift measurement; hence, the intensities at various polarizations of 0°, 45°, and 90° were automatically acquired without any polarizing device adjustments. These intensities were then transformed into a phase retardation introduced by a sample, and the resulting phase shift was eventually converted into film thickness. The samples were properly prepared, with pure BK7 substrate being deposited by $W{O}_3$-, $T{a}_2{O}_5$-, and $W{O}_3$/$T{a}_2{O}_5$ films of known thicknesses. The thickness measurement obtained from the proposed system yielded reading errors of 1.3%, 0.2%, and 1.3/2.5% for $W{O}_3$-, $T{a}_2{O}_5$-, and $W{O}_3$/$T{a}_2{O}_5$ films, respectively. The mathematical theory was effectively demonstrated and empirically confirmed. The experimental results show that the proposed setup has a lot of potential for real-time, non-destructive thickness assessment of transparent thin films without the need to modify polarizing device orientations. Full article

We demonstrate a polarization splitter rotator (PSR) based on multimode waveguide grating (MWG) on a silicon-on-insulator (SOI) platform. Bloch mode hybridization in mini-stopband is exploited to achieve high polarization conversion efficiency. The fabricated device yields a high extinction ratio of > 53 dB and > 31 dB, low crosstalk of < −26.4 dB and < −40 dB for the injected TE₀ and TM₀ mode, with average insertion loss of 1.2 dB and 1.5 dB in the wavelength regime 1552 nm–1562 nm. Such a device shows great design flexibility and an easy fabrication process, serving as a good candidate in integrated polarization diversity circuits, especially for applications requiring spectra manipulation. Additionally, the polarization conversion approach provides opportunities to develop novel polarization management devices. Full article

In this paper, an energy regulation method based on the combination of a half-wave plate (HWP) and a polarization beam splitter (PBS) is proposed for the fabrication of apodized fiber gratings, which can effectively improve the side lobe suppression ratio of high-reflectivity fiber Bragg gratings (FBGs) fabricated by femtosecond laser. The apodized FBGs prepared by this method has good repeatability and flexibility. By inputting different types of apodization functions through the program, the rotation speed of the stepping motor can be adjusted synchronously, and then the position of the HWP can be accurately controlled so that the laser energy can be distributed as an apodization function along the axial direction of the fiber. By using the energy apodization method, the gratings with a reflectivity of 75% and a side lobe suppression ratio of 25 and 32 dB are fabricated in the fiber with a core diameter of 9 and 4.4 μm, respectively. The temperature and strain sensitivities of the energy-apodized fiber gratings with a core diameter of 4.4 μm are 10.36 pm/°C and 0.9 pm/με, respectively. The high-reflectivity gratings fabricated by this energy apodization method are expected to be used in high-power narrow-linewidth lasers and wavelength division multiplexing (WDM) systems. Full article

The modal property and light propagation in tapered silicon ridge waveguides with different ridge heights are investigated for a silicon on insulator (SOI) platform with a 500 nm silicon (Si) thickness. Mode conversion between the transverse magnetic (TM) fundamental and higher-order transverse electric (TE) modes occurs when light is propagated in a waveguide taper. Such a conversion is due to mode hybridization resulting from the vertical asymmetry of the cross-section in the ridge waveguides. The influence of angled sidewalls and asymmetric cladding on mode conversion is also studied. It is shown that a very long taper length (adiabatic) is required for a complete conversion to take place. Conversely, such mode conversion could be suppressed by designing a short non-adiabatic taper. Our results show that significant improvement in performance metrics can be achieved by considering process parameters’ effect on mode conversion. With an optimum selection of the etching depth and accounting asymmetries due to angled sidewalls and cladding, we demonstrate an 84.7% reduction in taper length (adiabatic) for mode conversion and a 97% efficiency TM preserving taper (ultra-short). The analysis is essential for applications such as compact polarizers, polarization splitters/rotators, and tapers for TM devices. Full article

A brief description of the Water vapor, Cloud and Aerosol Lidar (WACAL) system is provided. To calibrate the volume linear depolarization ratio, the concept of “ $\Delta 90°$ -calibration” is applied in this study. This effective and accurate calibration method is adjusted according to the design of WACAL. Error calculations and analysis of the gain ratio, calibrated volume linear depolarization ratio and particle linear depolarization ratio are provided as well. In this method, the influences of the gain ratio, the rotation angle of the plane of polarization and the polarizing beam splitter are discussed in depth. Two groups of measurements with half wave plate (HWP) at angles of (0 $°$ , 45 $°$ ) and (22.5 $°$ , −22.5 $°$ ) are operated to calibrate the volume linear depolarization ratio. Then, the particle linear depolarization ratios measured by WACAL and CALIOP (the Cloud-Aerosol Lidar with Orthogonal Polarization) during the simultaneous observations were compared. Good agreements are found. The calibration method was applied in the third Tibetan Plateau Experiment of Atmospheric Sciences (TIPEX III) in 2013 and 2014 in China. Vertical profiles of the particle depolarization ratio of clouds and aerosol in the Tibetan Plateau were measured with WACAL in Litang (30.03° N, 100.28° E, 3949 m above sea level (a.s.l.)) in 2013 and Naqu (31.48° N, 92.06° E, 4508 m a.s.l.) in 2014. Then an analysis on the polarizing properties of the aerosol, clouds and cirrus over the Tibetan Plateau is provided. The particle depolarization ratio of cirrus clouds varies from 0.36 to 0.52, with a mean value of 0.44 ± 0.04. Cirrus clouds occurred between 5.2 and 12 km above ground level (a.g.l.). The cloud thickness ranges from 0.12 to 2.55 km with a mean thickness of 1.22 ± 0.70 km. It is found that the particle depolarization ratio of cirrus clouds become larger as the height increases. However, the increase rate of the particle depolarization ratio becomes smaller as the height increases. Full article
