Thermal imaging is increasingly applied in remote sensing to identify material degradation, monitor structural integrity, and support energy diagnostics. However, its adoption is limited by the low spatial resolution of thermal sensors compared to RGB cameras. This study proposes a modular pipeline to generate thermally enriched 3D point clouds by fusing RGB and thermal imagery acquired simultaneously with a dual-sensor unmanned aerial vehicle system. The methodology includes geometric calibration of both cameras, image undistortion, cross-spectral feature matching, and projection of radiometric data onto the photogrammetric model through a computed homography. Thermal values are extracted using a custom parser and assigned to 3D points based on visibility masks and interpolation strategies. Calibration achieved 81.8% chessboard detection, yielding subpixel reprojection errors. Among twelve evaluated algorithms, LightGlue retained 99% of its matches and delivered a reprojection accuracy of 18.2% at 1 px, 65.1% at 3 px and 79% at 5 px. A case study on photovoltaic panels demonstrates the method’s capability to map thermal patterns with low temperature deviation from ground-truth data. Developed entirely in Python, the workflow integrates into Agisoft Metashape or other software. The proposed approach enables cost-effective, high-resolution thermal mapping with applications in civil engineering, cultural heritage conservation, and environmental monitoring applications. Full article

This paper addresses the problem of automatically reconstructing three-dimensional coronary vessel trees from a series of X-ray angiography images, a task which remains difficult, particularly with respect to solutions requiring no additional user input. This study analyses the performance of a visual hull-based algorithm, producing the actual positions of heart arteries in the coordinate system, which is an approach not sufficiently explored in XRA images analysis. The proposed algorithm first creates a bounding cube using a novel heuristic and then iteratively projects the cube onto preprocessed 2D images, removing points too far from the depicted arteries. The method performance is first evaluated on a synthetic dataset through a series of experiments, and for a set of common clinical angles, 3D Dice of 75.25% and 78.61% reprojection Dice is obtained, which rivals the state-of-the-art machine learning methods. The findings suggest that the method offers a promising and interpretable alternative to black box methods on the synthethic dataset in question. Full article

In air–ground cooperative systems, identifying the identities of unmanned ground vehicles (UGVs) from an unmanned aerial vehicle (UAV) perspective is a critical step for downstream tasks. Traditional approaches involving attaching markers, like AprilTags on UGVs, fail under low-resolution or occlusion conditions, and the visually identical UGVs are hard to distinguish through similar visual features. This paper proposes a markerless method that associates UGV onboard sensor data with UAV visual detections to achieve identification. Our approach employs a Dempster–Shafer fused methodology integrating two proposed complementary association techniques: a projection-based method exploiting sequential motion patterns through reprojection error validation, and a topology-based method constructing distinctive topology using positional and orientation data. The association process is further integrated into a multi-object tracking framework to reduce ID switches during occlusions. Experiments demonstrate that under low-noise conditions, the projection-based method and the topology-based method achieves association precision at 89.5% and 87.6% respectively, which is superior to the previous methods. The fused approach enables robust association at 79.9% precision under high noise conditions, nearly 10% higher than original performance. Under false detection scenarios, our method achieves effective false-positive exclusion, and the integrated tracking process effectively mitigates occlusion-induced ID switches. Full article

Recent advancements in cooperative 3D object detection have demonstrated significant potential for enhancing autonomous driving by integrating roadside infrastructure data. However, deploying comprehensive LiDAR-based cooperative perception systems remains prohibitively expensive and requires precisely annotated 3D data to function robustly. This paper proposes an improved multi-modal method integrating LiDAR-based shape references into a previously mono-camera-based semantic vertex reconstruction framework to enable robust and cost-effective monocular and cooperative pose estimation after the reconstruction. A novel camera–LiDAR loss function that combines re-projection loss from a multi-view camera system alongside LiDAR shape constraints is proposed. Experimental evaluations conducted on the Argoverse dataset and real-world experiments demonstrate significantly improved shape reconstruction robustness and accuracy, thereby improving pose estimation performance. The effectiveness of the algorithm is proven through a real-world smart valet parking application, which is evaluated in our university parking area with real vehicles. Our approach allows accurate 6DOF pose estimation using an inexpensive IP camera without requiring context-specific training, thereby advancing the state of the art in monocular and cooperative image-based vehicle localization. Full article

To address the limitations of existing LiDAR–visual fusion methods in adequately accounting for map uncertainties induced by LiDAR measurement noise, this paper introduces a LiDAR–inertial–visual odometry framework leveraging mergeable probabilistic voxel mapping. The method innovatively employs probabilistic voxel models to characterize uncertainties in environmental geometric plane features and optimizes computational efficiency through a voxel merging strategy. Additionally, it integrates color information from cameras to further enhance localization accuracy. Specifically, in the LiDAR–inertial odometry (LIO) subsystem, a probabilistic voxel plane model is constructed for LiDAR point clouds to explicitly represent measurement noise uncertainty, thereby improving the accuracy and robustness of point cloud registration. A voxel merging strategy based on the union-find algorithm is introduced to merge coplanar voxel planes, reducing computational load. In the visual–inertial odometry (VIO) subsystem, image tracking points are generated through a global map projection, and outlier points are eliminated using a random sample consensus algorithm based on a dynamic Bayesian network. Finally, state estimation accuracy is enhanced by jointly optimizing frame-to-frame reprojection errors and frame-to-map RGB color errors. Experimental results demonstrate that the proposed method achieves root mean square errors (RMSEs) of absolute trajectory error at 0.478 m and 0.185 m on the M2DGR and NTU-VIRAL datasets, respectively, while attaining real-time performance with an average processing time of 39.19 ms per-frame on the NTU-VIRAL datasets. Compared to state-of-the-art approaches, our method exhibits significant improvements in both accuracy and computational efficiency. Full article

Common single-line 2D LiDAR sensors and cameras have become core components in the field of robotic perception due to their low cost, compact size, and practicality. However, during the data fusion process, the randomness and complexity of real industrial scenes pose challenges. Traditional calibration methods for LiDAR and cameras often rely on precise targets and can accumulate errors, leading to significant limitations. Additionally, the semantic fusion of LiDAR and camera data typically requires extensive projection calculations, complex clustering algorithms, or sophisticated data fusion techniques, resulting in low real-time performance when handling large volumes of data points in dynamic environments. To address these issues, this paper proposes a semantic fusion algorithm for LiDAR and camera data based on contour and inverse projection. The method has two remarkable features: (1) Combined with the ellipse extraction algorithm of the arc support line segment, a LiDAR and camera calibration algorithm based on various regular shapes of an environmental target is proposed, which improves the adaptability of the calibration algorithm to the environment. (2) This paper proposes a semantic segmentation algorithm based on the inverse projection of target contours. It is specifically designed to be versatile and applicable to both linear and arc features, significantly broadening the range of features that can be utilized in various tasks. This flexibility is a key advantage, as it allows the method to adapt to a wider variety of real-world scenarios where both types of features are commonly encountered. Compared with existing LiDAR point cloud semantic segmentation methods, this algorithm eliminates the need for complex clustering algorithms, data fusion techniques, and extensive laser point reprojection calculations. When handling a large number of laser points, the proposed method requires only one or two inverse projections of the contour to filter the range of laser points that intersect with specific targets. This approach enhances both the accuracy of point cloud searches and the speed of semantic processing. Finally, the validity of the semantic fusion algorithm is proven by field experiments. Full article

The evolution of photogrammetry has been significantly influenced by advancements in camera technology, particularly the emergence of spherical cameras. These devices offer extensive photographic coverage and are increasingly utilised in many photogrammetry applications due to their significant user-friendly configuration, especially in their low-cost versions. Despite their advantages, these cameras are subject to high image distortion. This necessitates specialised calibration solutions related to fisheye images, which represent the primary geometry of the raw files. This paper evaluates fisheye calibration processes for the effective utilisation of low-cost spherical cameras, for the purpose of 3D reconstruction and the verification of geometric stability. Calibration optical parameters include focal length, pixel positions, and distortion coefficients. Emphasis was placed on the evaluation of solutions for camera calibration, calibration network design, and the assessment of software or toolboxes that support the correspondent geometry and calibration for processing. The efficiency in accuracy, correctness, computational time, and stability parameters was assessed with the influence of calibration parameters based on the accuracy of the 3D reconstruction. The assessment was conducted using a previous case study of graffiti on an underpass in Wiesbaden, Germany. The robust calibration solution is a two-step calibration process, including a pre-calibration stage and the consideration of the best possible network design. Fisheye undistortion was performed using OpenCV, and finally, calibration parameters were optimized with self-calibration through bundle adjustment to achieve both calibration parameters and 3D reconstruction using Agisoft Metashape software. In comparison to 3D calibration, self-calibration, and a pre-calibration strategy, the two-step calibration process has demonstrated an average improvement of 2826 points in the 3D sparse point cloud and a 0.22 m decrease in the re-projection error value derived from the front lens images of two individual spherical cameras. The accuracy and correctness of the 3D point cloud and the statistical analysis of parameters in the two-step calibration solution are presented as a result of the quality assessment of this paper and in comparison with the 3D point cloud produced by a laser scanner. Full article

Noise in 3D photogrammetric point clouds—both close-range and UAV-generated—poses a significant challenge to the accuracy and usability of digital models. This study presents a novel deep learning-based approach to improve the quality of point clouds by addressing this issue. We propose a two-step methodology: first, a variational autoencoder reduces features, followed by clustering models to assess and mitigate noise in the point clouds. This study evaluates four clustering methods—k-means, agglomerative clustering, Spectral clustering, and Gaussian mixture model—based on photogrammetric parameters, reprojection error, projection accuracy, angles of intersection, distance, and the number of cameras used in tie point calculations. The approach is validated using point cloud data from the Temple of Neptune in Paestum, Italy. The results show that the proposed method significantly improves 3D reconstruction quality, with k-means outperforming other clustering techniques based on three evaluation metrics. This method offers superior versatility and performance compared to traditional and machine learning techniques, demonstrating its potential to enhance UAV-based surveying and inspection practices. Full article

Scarce feature points are a critical limitation affecting the accuracy and stability of incremental structure from motion (SfM) in small-scale scenes. In this paper, we propose an incremental SfM method for small-scale scenes, combined with an auxiliary calibration plate. This approach increases the number of feature points in sparse regions, and we randomly generate feature points within those areas. At the same time, we obtain a coarse matching set of feature points using pairwise polar geometric constraints. The positional results from the geometric constraints of the calibration plate are then used to filter out high-precision matching points, thereby improving the accuracy of the three-dimensional reconstruction. Experimental results demonstrate that the proposed method achieves superior reconstruction completeness and accuracy. In three real-world experiments, the average re-projection errors were 0.5245, 0.4151, and 0.4996 pixels, outperforming competing methods. This approach ensures robust pose estimation and facilitates precise 3D reconstructions. Full article

In this paper, we face the point-cloud segmentation problem for spinning laser sensors from a deep-learning (DL) perspective. Since the sensors natively provide their measurements in a 2D grid, we directly use state-of-the-art models designed for visual information for the segmentation task and then exploit the range information to ensure 3D accuracy. This allows us to effectively address the main challenges of applying DL techniques to point clouds, i.e., lack of structure and increased dimensionality. To the best of our knowledge, this is the first work that faces the 3D segmentation problem from a 2D perspective without explicitly re-projecting 3D point clouds. Moreover, our approach exploits multiple channels available in modern sensors, i.e., range, reflectivity, and ambient illumination. We also introduce a novel data-mining pipeline that enables the annotation of 3D scans without human intervention. Together with this paper, we present a new public dataset with all the data collected for training and evaluating our approach, where point clouds preserve their native sensor structure and where every single measurement contains range, reflectivity, and ambient information, together with its associated 3D point. As experimental results show, our approach achieves state-of-the-art results both in terms of performance and inference time. Additionally, we provide a novel ablation test that analyses the individual and combined contributions of the different channels provided by modern laser sensors. Full article

In industrial robotic arm gripping operations within disordered environments, the loss of physical information on the object’s surface is often caused by changes such as varying lighting conditions, weak surface textures, and sensor noise. This leads to inaccurate object detection and pose estimation information. A method for industrial object pose estimation using point cloud data is proposed to improve pose estimation accuracy. During the feature extraction process, both global and local information are captured by integrating the appearance features of RGB images with the geometric features of point clouds. Integrating semantic information with instance features effectively distinguishes instances of similar objects. The fusion of depth information and RGB color channels enriches spatial context and structure. A cross-entropy loss function is employed for multi-class target classification, and a discriminative loss function enables instance segmentation. A novel point cloud registration method is also introduced to address re-projection errors when mapping 3D keypoints to 2D planes. This method utilizes 3D geometric information, extracting edge features using point cloud curvature and normal vectors, and registers them with models to obtain accurate pose information. Experimental results demonstrate that the proposed method is effective and superior on the LineMod and YCB-Video datasets. Finally, objects are grasped by deploying a robotic arm on the grasping platform. Full article

In this work, an innovative perception-guided approach is proposed for landing zone detection and realization of Unmanned Aerial Vehicles (UAVs) operating in unstructured environments ridden with obstacles. To accommodate secure landing, two well-established tools, namely fuzzy systems and visual Simultaneous Localization and Mapping (vSLAM), are implemented into the landing pipeline. Firstly, colored images and point clouds acquired by a visual sensory device are processed to serve as characterizing maps that acquire information about flatness, steepness, inclination, and depth variation. By leveraging these images, a novel fuzzy map infers the areas for risk-free landing on which the UAV can safely land. Subsequently, the vSLAM system is employed to estimate the platform’s pose and an additional set of point clouds. The vSLAM point clouds presented in the corresponding keyframe are projected back onto the image plane on which a threshold fuzzy landing score map is applied. In other words, this binary image serves as a mask for the re-projected vSLAM world points to identify the best subset for landing. Once these image points are identified, their corresponding world points are located, and among them, the center of the cluster with the largest area is chosen as the point to land. Depending on the UAV’s size, four synthesis points are added to the vSLAM point cloud to execute the image-based visual servoing landing using image moment features. The effectiveness of the landing package is assessed through the ROS Gazebo simulation environment, where comparisons are made with a state-of-the-art landing site detection method. Full article

In recent years, with the widespread application of indoor inspection robots, high-precision, robust environmental perception has become essential for robotic mapping. Addressing the issues of visual–inertial estimation inaccuracies due to redundant pose degrees of freedom and accelerometer drift during the planar motion of mobile robots in indoor environments, we propose a visual SLAM perception method that integrates wheel odometry information. First, the robot’s body pose is parameterized in SE(2) and the corresponding camera pose is parameterized in SE(3). On this basis, we derive the visual constraint residuals and their Jacobian matrices for reprojection observations using the camera projection model. We employ the concept of pre-integration to derive pose-constraint residuals and their Jacobian matrices and utilize marginalization theory to derive the relative pose residuals and their Jacobians for loop closure constraints. This approach solves the nonlinear optimization problem to obtain the optimal pose and landmark points of the ground-moving robot. A comparison with the ORBSLAM3 algorithm reveals that, in the recorded indoor environment datasets, the proposed algorithm demonstrates significantly higher perception accuracy, with root mean square error (RMSE) improvements of 89.2% in translation and 98.5% in rotation for absolute trajectory error (ATE). The overall trajectory localization accuracy ranges between 5 and 17 cm, validating the effectiveness of the proposed algorithm. These findings can be applied to preliminary mapping for the autonomous navigation of indoor mobile robots and serve as a basis for path planning based on the mapping results. Full article

Infrared binocular cameras, leveraging their distinct thermal imaging capabilities, are well-suited for visual measurement and 3D reconstruction in challenging environments. The precision of camera calibration is essential for leveraging the full potential of these infrared cameras. To overcome the limitations of traditional calibration techniques, a novel method for calibrating infrared binocular cameras is introduced. By creating a virtual target plane that closely mimics the geometry of the real target plane, the method refines the feature point coordinates, leading to enhanced precision in infrared camera calibration. The virtual target plane is obtained by inverse projecting the centers of the imaging ellipses, which are estimated at sub-pixel edge, into three-dimensional space, and then optimized using the RANSAC least squares method. Subsequently, the imaging ellipses are inversely projected onto the virtual target plane, where its centers are identified. The corresponding world coordinates of the feature points are then refined through a linear optimization process. These coordinates are reprojected onto the imaging plane, yielding optimized pixel feature points. The calibration procedure is iteratively performed to determine the ultimate set of calibration parameters. The method has been validated through experiments, demonstrating an average reprojection error of less than 0.02 pixels and a significant 24.5% improvement in calibration accuracy over traditional methods. Furthermore, a comprehensive analysis has been conducted to identify the primary sources of calibration error. Ultimately, this achieves an error rate of less than 5% in infrared stereo ranging within a 55-m range. Full article

Continuous and dense time series of satellite remote sensing data are needed for several land monitoring applications, including vegetation phenology, in-season crop assessments, and improving land use and land cover classification. Supporting such applications at medium to high spatial resolution may be challenging with a single optical satellite sensor, as the frequency of good-quality observations can be low. To optimize good-quality data availability, some studies propose harmonized databases. This work aims at developing an ‘all-in-one’ Google Earth Engine (GEE) web-based workflow to produce harmonized surface reflectance data from Landsat-7 (L7) ETM+, Landsat-8 (L8) OLI, and Sentinel-2 (S2) MSI top of atmosphere (TOA) reflectance data. Six major processing steps to generate a new source of near-daily Harmonized Landsat and Sentinel (HLS) reflectance observations at 30 m spatial resolution are proposed and described: band adjustment, atmospheric correction, cloud and cloud shadow masking, view and illumination angle adjustment, co-registration, and reprojection and resampling. The HLS is applied to six equivalent spectral bands, resulting in a surface nadir BRDF-adjusted reflectance (NBAR) time series gridded to a common pixel resolution, map projection, and spatial extent. The spectrally corresponding bands and derived Normalized Difference Vegetation Index (NDVI) were compared, and their sensor differences were quantified by regression analyses. Examples of HLS time series are presented for two potential applications: agricultural and forest phenology. The HLS product is also validated against ground measurements of NDVI, achieving very similar temporal trajectories and magnitude of values (R² = 0.98). The workflow and script presented in this work may be useful for the scientific community aiming at taking advantage of multi-sensor harmonized time series of optical data. Full article
