Search Results (16)

This paper proposes a sensorless field-oriented control (FOC) strategy for permanent magnet synchronous motors (PMSMs), focusing on rotor flux position estimation based on back-electromotive force (back-EMF) signals. The limitations of conventional phase-locked loop (PLL) techniques for rotor flux position estimation along the motor shaft are analyzed, and an enhanced PLL structure is developed to address these deficiencies.In electric vehicle traction applications, precise flux position estimation alone is insufficient; accurate generation of d–q-axis current commands is equally critical. To address this need, a zero-pole-free PI regulator is designed within the PLL module, enabling more accurate flux estimation. Additionally, a gradient-based self-tuning algorithm is employed to identify system parameters, particularly the stator inductance, enabling the controller to optimize current command generation.Comprehensive system-level simulations have been conducted to validate the effectiveness of the proposed sensorless control scheme. Comparative studies demonstrate that the proposed method significantly improves feasibility and robustness for practical PMSM drive applications. Full article

This paper investigates a back-electromotive force (EMF) harmonic compensation strategy for six-phase permanent-magnet synchronous motors (PMSMs) to reduce current harmonics and improve system performance. Ideally, the back-EMF waveform should be perfectly sinusoidal. However, manufacturing imperfections such as suboptimal magnetic circuit design, uneven winding distribution, and mechanical eccentricity introduce low-order spatial harmonics, particularly the 5th, 7th, 11th, and 13th orders, which distort the back-EMF, increase current harmonics, complicate control, and reduce efficiency. To address these issues, this study proposes a compensation strategy utilizing common-mode and differential-mode current control. By injecting the 6th and 12th harmonics into the decoupled voltage commands along the d-axis and q-axis, the strategy significantly reduces current harmonic distortion. Experimental validation was conducted using a TMS320F28386D microcontroller, which controlled dual inverters via PWM signals and processed real-time current feedback. Rotor position feedback was provided by a resolver to ensure precise and responsive motor control. At a rotational speed of 900 rpm, with a peak phase current $I_m$ of 200 A and an IGBT switching frequency of 10 kHz, the phase-a current total harmonic distortion (THD) was reduced from 11.86% (without compensation) to 6.83% (with compensation). This study focused on mitigating harmonics below the 14th order. The experimental results demonstrate that the proposed back-EMF harmonic compensation strategy effectively minimizes current THD, highlighting its potential for improving the performance and efficiency of multi-phase motor systems. Full article

This paper designs and fabricates a small-type permanent-magnet linear motor and driver for automation applications. It covers structural design, magnetic circuit analysis, control strategies, and hardware development. Magnetic circuit analysis software JMAG is used for flux density distribution, back electromotive force (back-EMF), and electromagnetic force analysis. To address the lack of a complete closed magnetic circuit path at the ends of the linear motor, which causes magnetic field asymmetry, a phenomenon known as end effects, auxiliary core structures are proposed to compensate for the magnetic field at the ends. It successfully utilizes auxiliary cores to achieve the phase voltages of each phase, which are balanced at a phase voltage error of 0.02 V. To address the cogging force caused by variations in the magnetic reluctance of the core, this paper analyzes the relationship between electromagnetic force and mover position, conducting harmonic content analysis to obtain parameters. These parameters are applied to the designed cogging force control compensation strategy. It successfully achieves q-axis current compensation of around 1.05 A based on the mover’s position, ensuring that no jerking caused by cogging force occurs during closed-loop electromagnetic force control. The S-curve motion trajectory control is proposed to replace the traditional trapezoidal acceleration and deceleration, resulting in smoother position control of the linear motor. Simulations using JMAG-RT models in MATLAB/Simulink verified these control strategies. After verification, practical test results showed a maximum position error of approximately 5.0 μm. Practical tests show that the designed small-type permanent-magnet linear motor and its driver provide efficient, stable, and high-precision solutions for automation applications. Full article

In this paper, an improved speed sensorless control method including the maximum power point tracking (MPPT) algorithm for grid-connected squirrel-cage induction generator (SCIG) wind turbine systems using modified reduced-order generalized integrator (ROGI)–frequency-locked loop (FLL) with the DC offset compensation capability is proposed. The rotor flux linkages are estimated by the modified ROGI-FLL-based observer, of which the inputs are d-q axis rotor EMFs, and hence the position of rotor flux linkage can be obtained directly based on these estimated flux linkages using the arc tangent function. The DC offset in the estimated rotor flux linkages, which can cause oscillations in estimated rotor speed, leading to oscillations in SCIG stator active power due to power signal feedback (PSF)-MPPT algorithm, can be significantly reduced using the DC offset compensators included in modified ROGI-FLL structure. Moreover, the negative effects of high-frequency components on the performance of the rotor flux linkage estimation can be remarkably mitigated owing to the excellent high-frequency component rejection capability of ROGI. The dynamic response analysis of the modified ROGI-FLL with DC offset compensators is provided as well. The feasibility of the proposed method has been demonstrated in comparison with dual SOGI-FLL with DC offset compensator-based existing method. Full article

By 2050, the rice production needs to be increased by at least 50% in order to meet the growing food demands of the global population. Among various yield limiting factors, high temperature is fast becoming a major threat to sustain rice yields due to its increased frequency of occurrence and severity of stress events. The development of heat-resilient rice cultivars has been slow due to the lack of relevant donors for heat tolerance traits and limited information regarding the genetic basis of these component traits. The early morning flowering (EMF) trait, contributing to heat escape by promoting flowering/anthesis during cooler hours in the morning is demonstrated to offer protection against high-temperature-induced failure of pollination and fertilization. In this study, evaluation of CO 51, IR64 and IR64-qEMF3 (NIL of IR64 harboring QTL promoting EMF revealed that qEMF3 promoted early morning flowering in IR64-qEMF3 (1½ to 2 h earlier than IR64) and thereby reduced the sterility by about 8.15%. Attempts through marker-assisted backcross breeding led to development of advanced backcross progenies (NILs) of CO 51, harboring qEMF3. Evaluation of 88 BC₃F₂ progenies identified 19 progenies harboring qEMF3 under homozygous conditions. Evaluation of NILs of CO 51 harboring qEMF3 during summer 2019 revealed that the NILs exhibited early (7.30 a.m.) onset of anthesis by 1½ h and completed its peak anthesis well around cooler hours (9.30 a.m.) of the day and thereby recorded reduced spikelet sterility (7.8–9.0%) than their recurrent parent CO 51 (19.2%). The current study clearly demonstrated the efficacy of early morning flowering in the mitigation of yield losses under high-temperature conditions in a farmer preferred rice variety. Full article

In this study, we investigated the effect of EMF exposure on the regulation of RANKL-induced osteoclast differentiation in Raw 264.7 cells. In the EMF-exposed group, the cell volume did not increase despite RANKL treatment, and the expression levels of Caspase-3 remained much lower than those in the RANKL-treated group. TRAP and F-actin staining revealed smaller actin rings in cells exposed to EMF during RANKL-induced differentiation, indicating that EMF inhibited osteoclast differentiation. EMF-irradiated cells exhibited reduced mRNA levels of osteoclastic differentiation markers cathepsin K (CTSK), tartrate-resistant acid phosphatase (TRAP), and matrix metalloproteinase 9 (MMP-9). Furthermore, as measured by RT-qPCR and Western blot, EMF induced no changes in the levels of p-ERK and p-38; however, it reduced the levels of TRPV4 and p-CREB. Overall, our findings indicate that EMF irradiation inhibits osteoclast differentiation through the TRPV4 and p-CREB pathway. Full article

This study investigates the impact of the position information on the torque performance for an interior permanent magnet synchronous motor (IPMSM) driven by finite set–predictive torque control (FS-PTC). Unlike induction machines, IPMSMs are significantly sensitive to the rotor position during the motor operation owing to the permanent magnet of the rotor. Any misalignment or displacement of the rotor frame (d-q) can lead to poor prediction of the motor drive performance because the predictive control requires speed/position information during the prediction and evaluation by the cost function. Hence, the performance of the FS-PTC, which uses a speed encoder and senseless extended electromotive force (EMF) estimation, is evaluated and compared with respect to the speed and load conditions. Based on the investigation, the sensorless FS-PTC using the EMF method has superior torque performance and THD reduction compared to the measured speed-based PTC, particularly under large load torque. The performance evaluation of IPMSM was carried out through experimental results. Full article

Four outer rotor surface-mounted permanent magnet synchronous machines (SMPSM), supplied by a seven-phase drive system, are proposed in this study, considering different q (number of stator slot per phase per pole ratio) to achieve a satisfying value of electromagnetic torque and Back-Electromotive Force (Back-EMF) with lower torque pulsation. Accordingly, the proposed configurations are investigated, and results are comparatively reported. Thus based on the results, the best-performing configuration, the candidate model, which presents the lowest torque pulsation with a desirable value of T_avg and Back-EMF is selected. In order to demonstrate the advantages of this candidate model, an optimization analysis is performed using 2D Finite Element Analysis (FEA). The resultant values of the variables are applied, designing three optimized models. Performance results of the optimized models demonstrate that T_Cog reduced noticeably and T_Ripple declined below 5%. The Artemis Drive-Cycles analysis results are also included for the best-optimized model, considering E-Motorcycle requirements and properties for urban, rural, and motorway driving conditions. Accordingly, in terms of In-Wheel application of the optimized machine, high torque/power density along with high values of PF and efficient performance are provided for E-Motorcycle application. Full article

Natural and anthropogenic electromagnetic fields (EMFs) are ubiquitous in the environment and interfere with all biological organisms including plants. Particularly the quality and quantity of alternating EMFs from anthropogenic sources are increasing due to the implementation of novel technologies. There is a significant interest in exploring the impact of EMFs (similar to those emitted from battery chargers of electric cars) on plants. The model plant Arabidopsis thaliana was exposed to a composite alternating EMF program for 48 h and scrutinized for molecular alterations using photosynthetic performance, metabolite profiling, and RNA sequencing followed by qRT-PCR validation. Clear differences in the photosynthetic parameters between the treated and control plants indicated either lower nonphotochemical quenching or higher reduction of the plastoquinone pool or both. Transcriptome analysis by RNA sequencing revealed alterations in transcript amounts upon EMF exposure; however, the gene ontology groups of, e.g., chloroplast stroma, thylakoids, and envelope were underrepresented. Quantitative real-time PCR validated deregulation of some selected transcripts. More profound were the readjustments in metabolite pool sizes with variations in photosynthetic and central energy metabolism. These findings together with the invariable phenotype indicate efficient adjustment of the physiological state of the EMF-treated plants, suggesting testing for more challenging growth conditions in future experiments. Full article

A smooth coupling is implemented between the grid and doubly fed induction generator-based wind turbines (DFIG-WTs) during grid voltage imbalance. The nonlinear characteristics of a grid-connected DFIG-WT system may increase stresses on the mechanical and electrical components of wind turbines. Such difficulties are greatly increased during periods of voltage imbalance. Consequently, in this paper, a new control scheme is proposed to regulate DFIGs in order to support a smooth connection to the grid during voltage imbalance. In synchronization mode, the positive sequence of the rotor dq-axes currents regulates the stator q-axis EMF that is to be synchronized with the q-axis voltage of the grid-side voltage. The phase difference between the grid and stator voltages is compensated by adjusting the stator d-axis EMF to zero. Under normal conditions, a PR controller is used to dampen the negative sequence of the rotor dq-axes currents. PI current controllers are tuned to control the positive sequence of the DFIG rotor currents, while PR current controllers are used to regulate the negative sequence of the rotor currents during synchronization and under normal operation conditions. Experiments are performed to verify the smooth synchronization of the DFIG and the robustness of the proposed control scheme during grid voltage imbalance. Full article

This study aimed to develop a three-phase permanent-magnet synchronous motor drive system with improvement in current harmonics. Considering the harmonic components in the induced electromotive force of a permanent-magnet synchronous motor, the offline response of the induced electromotive force (EMF) was measured for fast Fourier analysis, the main harmonic components were obtained, and the voltage required to reduce the current harmonic components in the corresponding direct (d-axis) and quadrature (q-axis) axes was calculated. In the closed-loop control of the direct axis and quadrature axis current in the rotor reference frame, the compensation amount of the induced EMF with harmonic components was added. Compared with the online adjustment of current harmonic injection, this simplifies the control strategy. The drive system used a 32-bit digital signal processor (DSP) TMS320F28069 as the control core, the control strategies were implemented in software, and a resolver with a resolver-to-digital converter (RDC) was used for the feedback of angular position and speed. The actual measurement results of the current harmonic improvement control show that the total harmonic distortion of the three-phase current was reduced from 5.30% to 2.31%, and the electromagnetic torque ripple was reduced from 15.28% to 5.98%. The actual measurement results verify the feasibility of this method. Full article

A permanent magnet synchronous motor (PMSM) based on the principle of variable exciting magnetic reluctance (VMRPMSM) is presented. The motor is equipped with symmetrical non-magnetic conductors on both sides of the tangential magnetized permanent magnets (PMs). By placing the non-magnetic conductor (NMC), the magnetic reluctance in the exciting circuit is adjusted, and the flux weakening (FW) of the motor is realized. Hence, the NMC is studied comprehensively. On the basis of introducing the motor structure, the FW principle of this PMSM is described. The shape of the NMC is determined by analyzing and calculating the electromagnetic force (EF) acting on the PMs. We calculate the magnetic reluctance of the NMC and research on the effects of the NMC on electromagnetic force, d-axis and q-axis inductance and FW performance. The critical speeds from the test of the no-load back electromotive force (EMF) verify the correctness of the NMC design. The analysis is corresponding to the test result which lays the foundation of design for this kind of new PMSM. Full article

This paper presents a novel method to control sinusoidal distributed winding or sinusoidal back electromotive force (back-EMF) multi-phase permanent magnet (PM) machines under open-circuit fault conditions. In this study, five different fault conditions are considered: single-phase, adjacent double-phase, non-adjacent double-phase, adjacent three-phase, and non-adjacent three-phase open circuit conditions. New current sets for the remaining healthy phase under open-circuit fault conditions are obtained by compensating the direct-quadrature (d-q) axes currents. For this purpose, an iterative method has been used to get the new set of currents. D-q axes currents, due to faulty phase/phases, are shared to the healthy phases to obtain the same d-q axes currents as in the healthy condition. Therefore, the same torque is produced as in the healthy condition. The developed method is simulated in MATLAB/Simulink by using a d-q modelled sinusoidal back-EMF five-phase machine. A vector control block diagram has been designed to run the machine under healthy and faulty conditions. The machine model has been run successfully under fault tolerant conditions. Additionally, a finite element analysis (FEA) has been undertaken to simulate the five-phase PM model machine by using MagNet software. Open-circuit fault-tolerant control currents are fed into the coils of the machine model. Satisfactory torque results have been obtained. Because the model five-phase PM machine includes higher order back-EMF harmonics, especially the third harmonic, torque has ripple due to interaction between the fault-tolerant control currents and the higher order back-EMF harmonics. Full article

High-speed Permanent-Magnet Synchronous Motors/Generators (PMSMs/Gs) in a Flywheel Energy Storage System (FESS) are faced with high cross-coupling voltages and low switching-to-fundamental frequency ratios. High cross-coupling voltages between d-q axis current loops lead to transient current errors, which is more serious at lower switching-to-fundamental-frequency ratios. If the delays are not properly considered during the current controller design in a digital control system, the low switching-to-fundamental-frequency ratios may result in oscillatory or unstable responses. In this study, an accurate discrete current controller for high-speed PMSMs/Gs is proposed based on an accurate discrete model that takes the phase and magnitude errors generated during the sampling period into consideration, and an Extended State Observer (ESO) is applied to estimate and compensate the back EMF error. The cross-coupling problem is well settled, and the current loop dynamic at lower switching-to-fundamental frequency ratios is improved. Finally, the proposed discrete controller is validated on a 12,000 rpm PMSM/G prototype. Full article

This paper presents a new adaptive torque estimation algorithm for an interior permanent magnet synchronous motor (IPMSM) with parameter variations and cross-coupling between d- and q-axis dynamics. All cross-coupled, time-varying, or uncertain terms that are not part of the nominal flux equations are included in two equivalent mutual inductances, which are described using the equivalent d- and q-axis back electromotive forces (EMFs). The proposed algorithm estimates the equivalent d- and q-axis back EMFs in a recursive and stability-guaranteed manner, in order to compute the equivalent mutual inductances between the d- and q-axes. Then, it provides a more accurate and adaptive torque equation by adding the correction terms obtained from the computed equivalent mutual inductances. Simulations and experiments demonstrate that torque estimation errors are remarkably reduced by capturing and compensating for the inherent cross-coupling effects and parameter variations adaptively, using the proposed algorithm. Full article
