Several experimental and numerical studies have been conducted on the towing behavior of floating offshore wind turbines (FOWTs); however, these studies mainly focus on tension-leg platform (TLP) and semi-submersible designs with cylindrical features. The University of Maine’s VolturnUS+ concept is a cruciform-shaped barge-type FOWT with distinctive hydrodynamic properties that have not been characterized in previous research. This study presents basin-scale experiments that characterize the hydrodynamic drag properties of the VolturnUS+ platform, as well as observing the motion behavior of the platform and added resistance during towing in calm water and waves. The towing experiments are conducted in two towing configurations, with differing platform orientations and towline designs. The basin experiments are supplemented with a numerical study using computational fluid dynamic (CFD) simulations to explore flow-induced motion (FIM) on the platform during towing. In both the experiments and the CFD simulations, it was determined that the towing configuration significantly impacted the drag and motion characteristics of the platform, with the cruciform shape producing FIM phenomena. Observations from the towing tests confirmed the feasibility of towing the VolturnUS+ platform in the two orientations. The results and observations developed from the experimental and numerical towing studies will be used to inform numerical models for planning towing operations, as well as develop informed recommendations for towing similar cruciform-shaped structures in the future. Full article

This study applies a deep neural network (DNN) to optimize the 22.5 m pontoon hull form of a small waterplane area twin hull (SWATH) vessel with fin stabilizers, aiming to reduce calm water resistance at a Froude number of 0.8 under even keel conditions. The vessel’s resistance is simplified into three components: pontoon, strut, and fin stabilizer. Four design parameters define the pontoon geometry: fore-body length, aft-body length, fore-body angle, and aft-body angle. Computational fluid dynamics (CFD) simulations using STAR-CCM+ 2302 provide 1400 resistance data points, including fin stabilizer lift and drag forces at varying angles of attack. These are used to train a DNN in MATLAB 2018a with five hidden layers containing six, eight, nine, eight, and seven neurons. K-fold cross-validation ensures model stability and aids in identifying optimal design parameters. The optimized hull has a 7.8 m fore-body, 6.8 m aft-body, 10$°$ fore-body angle, and 35$°$ aft-body angle. It achieves a 2.2% resistance reduction compared to the baseline. The improvement is mainly due to a reduced Munk moment, which lowers the angle of attack needed by the fin stabilizer, thereby reducing drag. The optimized design provides cost-efficient construction and enhanced payload capacity. This study demonstrates the effectiveness of combining CFD and deep learning for hull form optimization. Full article

With the natural evolution of the Arctic route and advancements in related technologies, the development of new green ice-class ships is becoming a key technological breakthrough for the global shipbuilding industry. As a special vessel form that must perform icebreaking operations and undertake long-distance ocean voyages, an ice-class ship requires sufficient icebreaking capacity to navigate ice-covered water areas. However, since such ships operate for most of their time under open water conditions, it is also crucial to consider their resistance characteristics in these environments. Firstly, this paper employs linear interpolation to extract wind, wave, and sea ice data along the route and calculates the proportion of ice-covered and open water area in the overall voyage. This provides data support for hull form optimization based on real sea state conditions. Then, a resistance optimization platform for ice-class ships is established by integrating hull surface mixed deformation control within a scenario analysis framework. Based on the optimization results, comparative analysis is conducted between the parent hull and the optimized hull under various environmental resistance scenarios. Finally, the optimization results are evaluated in terms of energy consumption using a fuel consumption model of the ship’s main engine. The optimized hull achieves a 16.921% reduction in total resistance, with calm water resistance and wave-added resistance reduced by 5.92% and 27.6%, respectively. Additionally, the optimized hull shows significant resistance reductions under multiple wave and floating ice conditions. At the design speed, calm water power and hourly fuel consumption are reduced by 7.1% and 7.02%, respectively. The experimental results show that the hull form optimization process in this paper can take into account both ice-region navigation and ice-free navigation. The design ideas and solution methods can provide a reference for the design of ice-class ships. Full article

This study presents a comparative numerical investigation of Reynolds-averaged Navier–Stokes (RANS) and partially averaged Navier–Stokes (PANS) turbulence models applied to the Joubert BB2 submarine geometry under steady, calm-water conditions. To assess the influence of turbulence resolution and grid density on hydrodynamic performance prediction, simulations were conducted using three mesh resolutions—coarse, medium, and fine—based on unstructured hexahedral grids. The results were validated against international benchmark data, with emphasis placed on total resistance, pressure and shear stress distributions, wake development, and vortex structure. The PANS model consistently outperformed RANS in accurately predicting total resistance and resolving wake asymmetry, especially at medium grid resolution, due to its ability to partially resolve turbulence without full reliance on eddy viscosity assumptions. It demonstrated superior capability in capturing coherent vortex structures and preserving axial momentum in the stern region, resulting in more realistic surface pressure recovery and delayed boundary layer separation. Cross-sectional and circumferential velocity distributions in the propeller plane further highlighted PANS’s enhanced turbulence fidelity, which is essential for downstream propeller performance evaluation. Overall, the findings support the suitability of the PANS model as a practical and computationally efficient alternative to RANS for high-fidelity submarine flow simulations, particularly in wake-sensitive applications where LES remains computationally prohibitive. Full article

In this study, a correction procedure for ship mass and its longitudinal location of center of gravity suitable for a simulation environment is proposed in OpenFOAM v6.0. The concept is implemented ensuring static equilibrium and an approximately zero-pitch moment on the ship before the simulation. The viscous flow field around the ship in calm water is simulated using the VOF (Volume of Fluid) free surface two-phase and SST (Shear Stress Transport) k–ω turbulence models. Using static mesh, the resistance error of medium and fine grids is 4%, on average, against the experimental value. As the sinkage and trim are predicted using dynamic mesh, the increasing ship’s resistance causes larger errors, except for the container ship. Through the proposed correction, the ship’s vertical motions are significantly improved, and the resistance error decreases for the dynamic simulation. For the container ship, the error of resistance and motion achieved is less than 1%. The sinkage and trim errors improve tremendously for the tanker and bulk carrier, and the resistance errors are reduced slightly, by less than 3%. In the end, the detailed flow field is analyzed, as well as the ship wave-making pattern and the nominal wake velocity distribution, and these are compared with the measurement data available. The characteristics of the flow phenomena are successfully modeled. The resistance value for each hull form satisfies the requirement of Verification and Validation, and the uncertainty values are estimated. Full article

This study investigates the WAM-V (Wave Adaptive Modular Vessel) catamaran configuration, focusing on the hydrodynamic interaction between its articulated hulls. The unique hinged connection mechanism induces a relative angular displacement between the demihulls during operation, significantly modifying the calm water resistance characteristics. Such resistance variations critically influence both vessel maneuverability and the operational effectiveness of onboard acoustic detection systems. This study using computational fluid dynamics (CFD) technology, the effects of varying demihull spacing and the angles of the demihulls on resistance were calculated. Numerical simulations were performed using STAR-CCM+, employing the Reynolds-averaged Navier–Stokes equations (RANS) method combined with the k-epsilon turbulence model. The study investigates the free surface and double body viscous flow at different Froude numbers in the range of 0.3 to 0.75. The analysis focuses on the effects of the demihull spacing ratio (B_S/L_PP, Demihull spacing/Length between perpendiculars) on calm water resistance. Specifically, the resistance coefficient at B_S/L_PP = 0.2 is on average 14% higher than that at B_S/L_PP = 0.5. Additionally, the influence of demihull angles on resistance was simulated at B_S/L_PP = 0.42. The results indicate that inner demihull angles result in higher resistance compared to outer angles, with the maximum increase in resistance being approximately 9%, with specific outer angles effectively reducing resistance. This study provides a scientific basis for optimizing catamaran design and offers valuable insights for enhancing sailing performance. Full article

The search for neuroprotective compounds in lavender is driven by its traditional use for brain health, with antioxidant activity serving as a key mechanism in reducing oxidative stress and supporting cognitive function. Lavender’s potential to protect neurons is based on its calming, anti-stress properties, which increase the brain’s resistance to neurodegeneration. Although lavender is not a traditional medicinal plant in Ukraine, it is increasingly recognised for its medicinal properties and is widely cultivated in the country. Lavender use in Ukraine is influenced by both global herbal practices and local medical traditions. The aim of this study was to optimise the preparation of lavender herb extracts, perform chemical profiling and evaluate their antioxidant and neuroprotective activities. The study focused on Lavandula angustifolia cultivated in Lviv, Ukraine. Modern analytical methods were used, including HPLC, spectrophotometry, molecular docking, lyophilisation and pharmacological testing. The selection of the optimal conditions for obtaining lavender herb extracts was determined on the basis of the results of the total yield of phenolic compounds in each extract, where it was found that the raw material–solvent ratio (1:10) in water and 50% ethanol gave the highest yield of substances; the preferred extraction time was 20 min, and the temperature was 60–70 °C, especially for water extraction. Further HPLC analysis identified marker compounds including rosmarinic acid (28.31 mg/g), chlorogenic acid (1.64 mg/g) and luteolin (0.23 mg/g) in the lyophilised ethanol extract, which were previously recognised as neuroprotective markers by molecular docking. The water extract showed higher antioxidant (total 50.85 mg/g) and neuroprotective activity, probably due to synergistic interactions among the components. Behavioural tests further demonstrated the neuroprotective potential of lavender herb. These results demonstrate the potential neuroprotective activity of lavender herb and open new possibilities for its use in the treatment of various neurodegenerative diseases. Full article

Reducing greenhouse gas (GHG) emissions is essential across all sectors, including the maritime transport industry. Speed reduction is a key short-term operational measure for lowering GHG emissions from ships, and its implementation has already begun. While speed reduction offers significant benefits, particularly in terms of GHG emissions reduction potential, there are concerns about its application, including increased voyage times, an increase in the number of ships required, and the fact that ships may operate in conditions quite different from those for which they were designed and optimized. This study investigates the impact of speed reduction on ship performance in calm water, using a post-Panamax container ship as an example. Numerical simulations of resistance, open-water, and self-propulsion tests were conducted for a full-scale ship and propeller, and the results were validated against extrapolated towing tank data. Hydrodynamic characteristics, fuel consumption, and carbon dioxide emissions at various speeds were then estimated. The results indicated that when constant transport work was maintained, yearly CO₂ emissions decreased by −16.89% with a 10% speed reduction, −21.97% with a 20% speed reduction, and −25.74% with a 30% speed reduction. This study demonstrates that the classical cubic law for fuel oil consumption and speed dependence is not valid, as the speed exponent is lower than 3. The potential benefits and drawbacks of implementing slow steaming are discussed. Finally, this research contributes to the existing literature by evaluating the CO₂ emissions reduction potential of slow steaming. Full article

Navigable tunnels serve as an effective method to connect upstream and downstream navigation structures in mountainous regions with sharp bends. The towing resistance of ships in navigable tunnels, a key technical indicator for towing equipment development, demands focused research. Utilizing the innovative top towing method for tunnels, this study develops a physical model for towed navigable tunnels, conducts ship model tests, and measures and calculates the total resistance of ships towing through navigation under various conditions. Through resistance test results, it analyzes factors influencing the total resistance of ship navigation. The findings reveal: (1) regarding towing speed, at speeds exceeding 1.5 m/s, resistance spikes by 100 kN to 560 kN; (2) concerning water depth, at depths lower than 5.5 m, the impact on a ship navigation’s total resistance is pronounced, reaching 5 to 13 times that of calm water; (3) in terms of flow velocity, at velocities over 2 m/s, the impact on a ship navigation’s total resistance is substantial, amounting to 1.5 to 2 times the resistance at a flow velocity of 1.5 m/s; (4) in comparative analyses, the total resistance of ships towing through navigation in narrow tunnels is significantly higher than calculations based on existing formulas, increasing by 7 to 138 times. Full article

This paper presents a comparison of two turbulence models implemented in two different frameworks (Eulerian and Lagrangian) in order to simulate the motion in calm water of a displacement hull. The hydrodynamic resistance is calculated using two open-source Computational Fluid Dynamics (CFD) software packages: OpenFOAM and DualSPHysics. These two packages are employed with two different numerical treatments to introduce turbulence closure effects. The methodology includes rigorous validation using a Wigley hull with experimental data taken from the literature. Then, the validated frameworks are applied to model a ship hull with a 30 m length overall (LOA), and their results discussed, outlining the advantages and disadvantages of the two turbulence treatments. In conclusion, the resistance calculated with OpenFOAM offers the best compactness of results and a shorter simulation time, whereas DualSPHysics can better capture the free-surface deformations, preserving similar accuracy. Full article

In this study, a new route planning model is proposed to help ocean-going ships avoid dangerous weather conditions and ensure safe ship navigation. First, we integrate ocean-going ship vulnerability into the study of the influence of meteorological and oceanic factors on navigational risk. A multi-layer fuzzy comprehensive evaluation model for weather risk assessment is established. A multi-objective nonlinear route planning model is then constructed by comprehensively considering the challenges of fuel consumption, risk, and time during ship navigation. The International Maritime Organization (IMO) guidelines are highlighted as constraints in the calculations, and wind, wave, and calm water resistance to ships in the latest ITTC method is added to the fuel consumption and sailing time in the objective function. Finally, considering the large amount of data required for ocean voyages, the bidirectional A* algorithm is applied to solve the model and reduce the planning time. Furthermore, our model is applied to the case of an accident reported in the Singapore Maritime Investigation Report, and the results show that the model-planned route is very close to the original planned route using the Towing Manual, with an average fit of 98.22%, and the overall meteorological risk of the model-planned route is 11.19% smaller than the original route; our model can therefore be used to plan a safer route for the vessel. In addition, the importance of risk assessments and the IMO guidelines as well as the efficiency of the bidirectional A* algorithm were analyzed and discussed. The results show that the model effectively lowers the meteorological risk, is more efficient than the traditional route planning algorithm, and is 86.82% faster than the Dijkstra algorithm and 49.16% faster than the A* algorithm. Full article

Given the typical characteristics of self-propulsion and jack-up wind turbine installation vessels (WTIVs), including their full and blunt hull form and complex appendages, this paper combines the model test method with the RANS-based CFD numerical prediction method to experimentally and numerically study the resistance of the optimized hull at different spudcan retraction positions. The calm water resistance components and their mechanisms of WTIVs based on T-BOW were obtained. Furthermore, using the multivariate nonlinear least squares method, an empirical formula for rapid resistance estimation based on the Holtrop method was derived, and its prediction accuracy and applicability were validated with a full-scale ship case. This study indicates that the primary resistance components of such low-speed vessels are viscous pressure resistance, followed by frictional resistance and wave-making resistance. Notably, the spudcan retraction well area, as a unique appendage of WTIVs, exhibits a significant “moonpool additional resistance” effect. Different spudcan retraction positions affect the total calm water resistance by approximately 20% to 30%. Therefore, in the resistance optimization design of WTIVs, special attention should be paid to the matching design of the spudcan structure and the hull shell plate lines in the spudcan retraction well area. Full article

Stern flaps and interceptors are prevalent stern appendages on medium- to high-speed ships, designed to modify the sailing posture of ships and diminish resistance. Using the Reynolds-averaged Navier–Stokes (RANS) method combined with overset mesh technology, this study evaluates the performance of a ship in regular waves before and after interceptor and stern flap installation. The findings indicate that the interceptor and stern flap resistance reduction rates initially declined and then rose with wavelength, typically 1–3% higher than in calm water. For a constant wavelength of 1.5 L_PP and when wave steepness ak ≥ 0.05, the interceptor and stern flap resistance reduction rates in regular waves decline as wave steepness increases. The stern appendages have a more prominent impact on ship posture owing to heightened ship motion amplitude in wave conditions compared to calm water. Moreover, after fitting the interceptor and stern flap, the heave and pitch transfer functions of the ship lessen after fitting the interceptor and stern flap, particularly when λ/L_PP = 1–2; average reduction rates for TF₃ and TF₅ are 7.2% and 3.9%, respectively, with a stern flap, and 4.4% and 2.1% after fitting the interceptor. This study offers invaluable insights and practical guidance for designing and applying stern appendages. Full article

The stern flap is a practical hull appendage equipment that enhances ship navigation performance and saves energy. The existing studies mainly focus on the fixed stern flap, other than an actively controlled one, so it is worth further exploring its effect and mechanism. By implanting the PID controller to the stern flap, this paper proposed a free-running CFD model on the ONRT (the Office of Naval Research Tumblehome) ship coupled with the active-controlled stern flap to investigate the hydrodynamic performance in resonance waves. The free-running performance in calm water and regular waves is numerically researched and verified versus the experimental and referenced results. Then, the effect of different PID coefficients and control strategies of the stern flap on the traveling speed, attitudes, and propulsion performance under the resonance wave condition is conducted, and the influence mechanism is explored. The results show that adopting a fixed flap controller and PID controller can reduce the original speed loss by 4.2% and 6.9%, respectively, and increase the average propulsive efficiency of the propeller by 1.0% and 1.4%, respectively. Further analysis reveals that the global effect of the suppressed motion attitudes due to the installation of the fixed flap effectively contributes to the resistance reduction. However, the local effect of the stern flap increases the resistance due to interaction with the propeller and stern. The PID-controlled stern flap exhibits similar average attitudes compared to the fixed one, which means the resistance reduction of the global effect is kept the same, and the active stern flap further improves the stern flow field, where the resistance increment of the local effect is weakened, enhancing the traveling speed and improving the propulsion efficiency. Full article

This work shows the performance of LincoSim, a web-based virtual towing tank enabling automated and standardized calm water computational fluid dynamics (CFD) data sampling, extending previous published applications to the case of a high-speed hull. The calculations are performed for a 1:10 scale model of a 43 ft powerboat hull form in the Froude number range from 0.3 to 2.0. The counterpart physical model is the experimental fluid dynamics (EFD) campaign performed at the University of Naples Federico II, where the resistance, sinkage and trim data have been measured. The EFD/CFD data comparison is performed and shown with a discussion of the spotted differences. The average percentage differences between the EFD and CFD data for the whole speed range are 1.84, 6.87 and 6.94 for the resistance, dynamic trim, and sinkage, respectively. These results confirm the maturity of the standardized and automated CFD modeling for calm water hydrodynamic analysis included in LincoSim, even at very high Froude numbers. The wetted length of the keel and chine and the wetted surface are calculated from numerical data using the advanced post-processing. Finally, as a work in progress, we test a first comparison for the same hull of the EFD and CFD data, considering two seakeeping conditions for head waves at a given wavelength for two velocity conditions. Also, this kind of analysis confirms the tight correlation between the measured and computed outcomes. This synergic interplay of EFD and CFD can link the advantages of both methods to support hull design but also requires experiment planning and final data analysis to obtain physical parameters not easily measurable in laboratory, such as the wetted surface, wetted lengths, proper viscous contribution, and pressure distribution both in calm water and in waves. Full article
