In recent years, pneumatic stages have attracted attention as stages for semiconductor manufacturing equipment due to their low cost and minimal maintenance requirements. However, pneumatic stages include nonlinear elements such as friction and air compressibility, making precise control challenging. To address this issue, this paper aims to achieve high-precision positioning by applying a nonlinear position control method to pneumatic stages. To achieve this, we propose a control method that combines filtered right coprime factorization and Prescribed Performance Control–Sliding Mode Control (PPC-SMC). Filtered right coprime factorization not only stabilizes and simplifies the plant but also reduces noise. Furthermore, PPC-SMC enables safer and faster control by constraining the system state within a switching surface that imposes limits on the error range. Through experiments on the actual system, it was confirmed that the proposed method achieves dramatically higher precision and faster tracking compared to conventional methods. Full article

Real-world plants have various nonlinear characteristics such as friction and hysteresis, so nonlinear control is essential for precise control. In addition, actuators of plants have input constraints, which cause the integrator of the controller to windup. So far, anti-windup methods have mainly been for linear controllers, and research on nonlinear controllers has not been sufficient. This paper proposes a back-calculation anti-windup method for nonlinear controllers. By analyzing and extending the back-calculation anti-windup for a Proportional–Integral controller using operator theory, it can be applied to nonlinear controllers. The proposed method is applied to integral sliding mode control and right coprime factorization. In the simulation, we compared the proposed method with and without its application, as well as with conditional integration, and confirmed the effectiveness of the proposed method. In the future, it is necessary to extend the method to be applicable to more complex systems. This study has the potential to contribute to the practical application of nonlinear control. Full article

In recent years, with the growing interest in the Internet of Things (IoT) and decarbonization, energy harvesting has been attracting attention. Energy harvesting is a technology that converts ambient energy such as light, heat, and vibration into electrical power, and it is also known as environmental power generation. A triboelectric nanogenerator is a type of energy harvesting device that converts mechanical energy, such as vibration, into electrical energy using the triboelectric effect and electrostatic induction. The advantages of this device include low cost and high durability. Due to the principle of triboelectric nanogenerators, a stable output voltage cannot be obtained, so auxiliary circuits such as DC–DC converters are required to obtain the desired voltage. In this paper, a DC–DC converter is utilized, controlled by a system based on operator theory, with a filter incorporated to enhance tracking performance, ensuring that the output voltage follows the target value. Full article

In recent years, vibration control utilizing smart materials has garnered considerable attention. In this paper, we aim to achieve vibration suppression of a plate structure with a tail-fin shape by employing piezoelectric actuators—one of the smart materials. The plate structure is rigorously modeled based on the Kirchhoff–Love plate theory, while the piezoelectric actuators are formulated in accordance with the Prandtl–Ishlinskii model. This research proposed a control system that addresses the interference effects arising during vibration control by dividing multiple piezoelectric elements into two groups and implementing MIMO control. The efficacy of the proposed control method was validated through simulations and experiments. Full article

A microreactor is a chemical reaction device that mixes liquids in a very narrow channel and continuously generates reactions. They are attracting attention as next-generation chemical reaction devices because of their ability to achieve small-scale and highly efficient reactions compared to the conventional badge method. However, the challenge is to design a control system that is tolerant of faults in some of the enormous number of sensors in order to achieve parallel production by numbering up. In a previous study, a simultaneous control system for two different temperatures was proposed in an experimental system that imitated the microreactor cooled by Peltier devices. In addition, a fault-tolerant control system for one area has also been proposed. However, the fault-tolerant control system could not be applied to the control system of two temperatures in the previous study. In this paper, we extend it to a two-input, two-output fault-tolerant control system. We also use a fault detection system that combines ChangeFinder, a time-series data analysis method, and One-Class SVM, an unsupervised learning method. Finally, the effectiveness of the proposed method is confirmed by experiments. Full article

In this paper, an operator-based voltage control method for TENGs is investigated, achieving output voltage tracking without compensators and uncertainty suppression using robust right coprime factorization. Initially, a comprehensive simulation-capable circuit model for TENGs is developed, integrating their open-circuit voltage and variable capacitance characteristics. This model is implemented to simulate the behavior of TENGs with a rectifier bridge and capacitive load. To address the high-voltage, low-current pulsating nature of TENG outputs, a storage capacitor switching model is designed to effectively transfer the pulsating energy. This switching model is directly connected to a buck converter and operates under a unified control strategy. A complete TENG power management system was established based on this model, incorporating an operator theory-based control strategy. This strategy ensures steady output voltage under varying load conditions without using compensators, thereby reducing disturbances. Simulation results validate the feasibility of the proposed TENG system and the efficacy of the control strategy, providing a robust framework for optimizing TENG energy harvesting and management systems with significant potential for practical applications. Full article

The main objective of this research is to expand right coprime factorization based on operator theory in nonlinear systems. A novel method for right coprime factorization is proposed by introducing an operator that can deform the system’s response into an arbitrary shape. This enables the design of control systems that are highly effective against noise. As an application, we use a pneumatic stage. The effectiveness of this method is verified through simulations and real-world experiments. Full article

In a nonlinear control system, hysteresis exists usually as common characteristics. In addition, external output disturbances like modelling error, machine friction and so on also occur frequently. Both of them are considered to cause instability and unsatisfactory performance. In this paper, a practical nonlinear control system design is proposed so as to achieve the simultaneous control of input hysteresis and output disturbance. The system is based on RCF (right coprime factorization theory). Additionally, the proposed design has been applied to a soft robotic finger system and the results of simulations and practical experiments are exhibited, which show the effectiveness of the proposed system. Full article

In this paper, the robustness of a system with sundry disturbed open loop dynamics is investigated by employing robust right coprime factorization (RRCF). These sundry disturbed open loop dynamics are present not only in the feed forward path, but also within the feedback loop. In such a control framework, the nominal plant is firstly right coprime factorized and a feed forward and a feedback controllers are designed based on Bezout identity to ensure the overall stability. Subsequently, considering the sundry disturbed open loop dynamics, a new condition formulated as a disturbed Bezout identity is put forward to achieve the closed loop stability of the system, even in the presence of disturbances existing in sundry open loops, where in the feedback loop a disturbed identity operator is defined. This approach guarantees the system robustness if a specific inequality condition is satisfied. And, it should be noted that the proposed approach is applicable to both linear and nonlinear systems with sundry disturbed open loop dynamics. Simulations demonstrate the effectiveness of our methodology. Full article

Fractional calculus is defined by expanded integer order integration and differentiation. In this paper, multiple mathematical models of a nonlinear dual-tank device are precisely formulated by fractional calculus. Using the accurate model, a multivariable fractional-order controller is designed for nonlinear devices. The merits of the fractional-order design include: (1) control of multivariable nonlinearities, (2) compensation of uncertainties, and (3) elimination of coupling effects. Simulations and experiments are conducted to verify the precision of the fractional order models and the effectiveness of the multivariable fractional-order control system design. Full article

This paper investigates the problem of trajectory tracking control in the presence of bounded model uncertainty and external disturbance. To cope with this problem, we propose a novel intelligent operator-based sliding mode control scheme for stability guarantee and control performance improvement in the closed-loop system. Firstly, robust stability is guaranteed by using the operator-based robust right coprime factorization method. Secondly, in order to further achieve the asymptotic tracking and enhance the responsiveness to disturbance, a finite-time integral sliding mode control law is designed for fast convergence and non-zero steady-state error in accordance with Lyapunov stability analysis. Lastly, the controller’s parameters are automatically adjusted by the proved stabilizing particle swarm optimization with the linear time-varying inertia weight, which significantly saves tuning time with a remarkable performance guarantee. The effectiveness and efficiency of the proposed method are verified on a highly nonlinear ionic polymer metal composite application. The extensive numerical simulations are conducted and the results show that the proposed method is superior to the state-of-the-art methods in terms of tracking accuracy and high robustness against disturbances. Full article

The flexible arm easily vibrates due to its thin structural characteristics, which affect the operation accuracy, so reducing the vibration of the flexible arm is a significant issue. Smart materials are very widely used in the research topic of vibration suppression. Considering the hysteresis characteristic of the smart materials, based on previous simulation research, this paper proposes an experimental system design of nonlinear vibration control by using the interactive actuation from shape memory alloy (SMA) for a flexible arm. The experiment system was an interactive actuator–sensor–controller combination. The vibration suppression strategy was integrated with an operator-based vibration controller, a designed integral compensator and the designed n-times feedback loop. In detail, a nonlinear vibration controller based on operator theory was designed to guarantee the robust stability of the flexible arm. An integral compensator based on an estimation mechanism was designed to optimally reduce the displacement of the flexible arm. Obtaining the desired tracking performance of the flexible arm was a further step, by increasing the n-times feedback loop. From the three experimental cases, when the vibration controller was integrated with the designed integral compensator, the vibration displacement of the flexible arm was much reduced compared to that without the integral compensator. Increasing the number of n-times feedback loops improves the tracking performance. The desired vibration control performance can be satisfied when n tends to infinity. The conventional PD controller stabilizes the vibration displacement after the 7th vibration waveform, while the vibration displacement approaches zero after the 4th vibration waveform using the proposed vibration control method, which is proved to be faster and more effective in controlling the flexible arm’s vibration. The experimental cases verify the effectiveness of the proposed interactive actuation vibration control approach. It is observed from the experimental results that the vibration displacement of the flexible arm becomes almost zero within less time and with lower input power, compared with a traditional controller. Full article

Nowadays, quickly changing customer demands are a big challenge in the manufacturing industry, especially for job shops, which are typical coupling and nonlinear multi-input–multi-output (MIMO) systems. In order to achieve good shop floor performance in the presence of short-term demand fluctuations, a key performance indicator—work in process (WIP)—is required to be effectively controlled in the vicinity of the desired levels. For this purpose, a machinery-oriented capacity adjustment approach via a reconfigurable machine tool (RMT) is employed to flexibly balance capacity and load in the case of a bottleneck. A mathematical model concerning the RMT and WIP was first established in the presence of uncertainty and delays. The operator-based robust right coprime factorization (RRCF) method was adopted to stabilize the uncertain system, and adaptive integral separated proportional–integral (ISPI) tracking controllers were further designed to improve the transient and robustness performance. The performance of the proposed ISPI-RRCF was analyzed and compared with that of a state-of-the-art method in a simulation. The results showed that both control systems could ensure that the WIP was within an allowed bound, while the former had lower overshoots, shorter setting times, and more concentrated distributions facing stochastic demands. This further indicated the effectiveness of the proposed algorithm in the avoidance of serious bottlenecks and unbalanced capacity distributions. Full article

Fractional-order calculus and derivative is extended from integral-order calculus and derivative. This paper investigates a nonlinear robust control problem using fractional order and operator theory. In order to improve the tracking performance and antidisturbance ability, operator- and fractional-order-based nonlinear robust control for the spiral counter-flow heat exchanger described by the parallel fractional-order model (PFOM) is proposed. The parallel fractional-order model for the spiral counter-flow heat exchanger was identified by particle swarm optimization (PSO) and the parameters of a fractional-order PID (FOPID) controller were optimized by the PSO. First, the parallel fractional-order mathematical model for a spiral counter-flow heat exchanger plant was identified by PSO. Second, a fractional-order PID controller and operator controller for the spiral heat exchanger were designed under the identified parallel fractional-order mathematical model. Third, the parameters of the operator and fractional-order PID were optimized by PSO. Then, tracking and antidisturbance performance of the control system were analyzed. Finally, comparisons of two control schemes were performed, and the effectiveness illustrated. Full article

Linear sliders are linear actuators using linear motors. It is used in many applications, such as factory lines and linear motor cars. In recent years, the demand for smaller semiconductor devices has been increasing due to the proliferation of smartphones. High-precision positioning of linear motors is needed because manufacturing semiconductor devices uses the stage with linear motors. However, linear motors have nonlinearity due to the position dependence of interlinkage flux. It affects precise positioning. In this study, the nonlinear characteristics due to the position dependence of the flux are expressed as a mathematical model by using a distributed constant magnetic circuit. A method compensating it using an operator-based feedback controller with the obtained mathematical model is proposed. The effectiveness of the proposed method is confirmed by simulating and experimenting with the reference following disturbance elimination. Full article
