In the process of machining an aluminum matrix silicon carbide (SiCp/Al) composite material using wire electric discharge machining (WEDM), the thermal conductivity and dielectric properties of working fluid, such as discharge medium and cool carrier, directly determine the material removal rate (MRR) and surface roughness (R_a). In this paper, graphene-working fluid is innovatively used as working medium to optimize the discharge process due to its high thermal conductivity and field emission characteristics. The single-factor experiments show that graphene can increase the MRR by 11.16% and decrease the R_a by 29.96% compared with traditional working fluids. In order to analyze the multi-parameter coupling effect, an L16 (4⁴) orthogonal test is further designed, and the effects of the pulse width (T_on), duty cycle (DC), power tube number (PT), and wire speed (WS) on the MRR and R_a are determined using a signal-to-noise analysis. Based on a gray relational grade analysis, a multi-objective optimization model was established, and the priority of the MRR and R_a was determined using an AHP, and finally the optimal parameter combination (T_on = 22 μs, DC = 1:4, PT = 3, WS = 2) was obtained. Full article

This paper presents an ultrasonic driving and detection system based on a CMUT array using MEMS technology. Among them, the core component CMUT array is composed of 8 × 8 CMUT array elements, and each CMUT array element contains 6 × 6 CMUT units. The collapse voltage of a single CMUT unit obtained through finite element analysis is 95.91 V, and the resonant frequency is 3.16 MHz. The driving section achieves 64-channel synchronous driving, with key parameters including an adjustable excitation signal frequency ranging from 10 kHz to 5.71 MHz, a delay precision of up to 1 ns, and an excitation duration of eight pulse cycles. For the echo reception, a two-stage amplification circuit for high-frequency weak echoes with 32 channels was designed, achieving a gain of 113.72 dB and −3 dB bandwidth of 3.89 MHz. Simultaneously, a 32-channel analog-to-digital conversion based on a self-calibration algorithm was implemented, with a sampling rate of 50 Mbps and a data width of 10 bits. Finally, the experimental results confirm the successful implementation of the driving system’s designed functions, yielding a center frequency of 1.4995 MHz and a relative bandwidth of 127.9%@−6 dB for the CMUT operating in silicone oil. This paper successfully conducted the transmit–receive integrated experiment of the CMUT and applied Butterworth filtering to the echo data, resulting in high-quality ultrasonic echo signals that validate the applicability of the designed CMUT-based system for ultrasonic imaging. Full article

In this work, a new methodology is proposed for the online and non-invasive extraction of partial discharge (PD) pulses from raw measurement data obtained using a simplified setup. This method enables the creation of sub-windows with optimized size, each containing a single candidate PD pulse. The proposed approach integrates mathematical morphological filtering (MMF) with kurtosis, a first-order Savitzky-Golay smoothing filter, the Otsu method for thresholding, and a specific technique to associate each sub-window with the phase angle of the applied voltage waveform, enabling the construction of phase-resolved PD (PRPD) patterns. The methodology was validated against a commercial PD detection device adhering to the IEC (International Electrotechnical Commission) standard. Experimental results demonstrated that the proposed method, utilizing an off-the-shelf 8-bit resolution data acquisition system and a low-cost high-frequency current transformer (HFCT) sensor, effectively diagnoses and characterizes PD activity in high-voltage equipment, such as surge arresters and instrument transformers, even in noisy environments. It was able to characterize PD activity using only a few cycles of the applied voltage waveform and identify low amplitude PD pulses with low signal-to-noise ratio signals. Other contribution of this work is the diagnosis and fault signature obtained from a real surge arrester (SA) with a nominal voltage of 192 kV, corroborated by destructive disassembly and internal inspection of the tested equipment. This work provides a cost-effective and accurate tool for real-time PD monitoring, which can be embedded in hardware for continuous evaluation of electrical equipment integrity. Full article

We investigated the influence of the photobleaching (PB) effect on the dosimetry performances of a phosphosilicate single-mode optical fiber (core diameter of 6.6 µm) operated at 638 nm, within the framework of the LUMINA project. Different irradiation tests were performed under ~40 keV mean energy fluence X-rays at a 530 µ Gy(SiO₂)/s dose rate to measure in situ the radiation-induced attenuation (RIA) growth and decay kinetics while injecting a 638 nm laser diode source with powers varying from 500 nW to 1 mW. For injected continuous power values under 1 µW, we did not measure any relevant influence of the photobleaching effect on the fiber radiation sensitivity coefficient of ~140 dB km⁻¹ Gy⁻¹ up to ~30 Gy. Above 1 µW, the fiber radiation sensitivity is significantly reduced due to the PB associated with the signal and can decrease to ~80 dB km⁻¹ Gy⁻¹ at 1 mW, strongly affecting the capability of this fiber to serve as a dosimeter-sensitive element. Higher power values up to 50 µW can still be used by properly choosing a pulsed regime with periodic injection cycles to reduce the PB efficiency and maintain the dosimetry properties. Basing on the acquired data, a simple model of the photobleaching effect on a coil of the investigated fiber is proposed in order to estimate its sensitivity coefficient evolution as a function of the cumulated dose and its fiber length when injecting a certain laser power. Additional studies need to investigate the influence of the temperature and the dose rate on the PB effects since these parameters were fixed during all the reported acquisitions. Full article

Pulse signals carry comprehensive information regarding human cardiovascular physiology and pathology, providing a noninvasive and continuous method to assess cardiovascular health status in blood pressure monitoring. The blood pressure measurement method based on the pulse signal needs to extract the features of the single-cycle pulse signal, while the pulse signal pertains to the weak physiological signal of body surface. The acquisition process is susceptible to various factors leading to abnormal cycles, especially adjacent channel interference, affecting the subsequent feature extraction. To address this problem, this paper conducts an analysis of the formation mechanism of adjacent channel interference and proposes a single-cycle pulse signal recognition algorithm based on a one-dimensional deep convolutional neural network (1D-CNN) model. Radial pulse signals were collected from 150 subjects by pulse bracelet, and a dataset comprising 3446 single-cycle signals was extracted in total after denoising, single-cycle segmentation, and standardized preprocessing. The 1D-CNN model is trained to classify input signals into three categories: effective pulse signals, distortion, and interference signals. This classification is achieved by evaluating the waveform morphology of the signals within a single cycle. The results show that the overall classification accuracy of the algorithm on the test set is 98.26%, in which the classification accuracy of pulse waves is 99.8%, indicating that it can effectively recognize single-cycle pulse waves, which lays the foundation for subsequent continuous blood pressure measurement. Full article

The dynamic characteristics of high-speed on/off valves (HSVs) are a key factor in measuring their performance, and determining the control accuracy of valve-controlled systems. Furthermore, the hysteresis characteristics of HSVs can seriously affect their dynamic characteristics. This study evaluated the hysteresis characteristics of HSVs in a valve-controlled hydraulic control system, and considered the pressure changes in front of the valve during the opening and closing process of the valve core. A time-delay compensation control (TDCC) based on pulse-width modulation (PWM) was proposed. The reference PWM signal was used to control the opening and closing time of the HSV, while the loading signal was composed of an opening compensation PWM, an excitation PWM, an opening holding PWM, and a closing compensation PWM. Using an opening compensation PWM to start the initial current, combined with current feedback and pressure changes in front of the valve, the amplitude and duty cycle of different PWM signals were determined in real time. This reduced the time delay and working current of the HSV during opening and closing. A simulation comparison analysis was conducted, with a single PWM control and a pre-excitation control algorithm (PECA). The results showed that, compared to a single PWM control, the TDCC can reduce the overall opening and closing time delay by 78.1%, and the energy consumption by 64.7%. Compared with PECA, the overall opening and closing time delay was reduced by 10.9%, and the energy consumption was reduced by 28%. At the same time, the frequency response of the valve core displacement increased by 70%, compared to the single PWM control. Full article

This experiment to search for the one of the charged lepton flavor-violating processes, muon-electron conversion, DeeMe, is being conducted at the J-PARC MLF H-Line in Japan. This experiment utilizes a pulsed proton beam from the Rapid Cycling Synchrotron (RCS). A graphite target is bombarded with a pulsed proton beam, negative pion production and pion-in-flight-decay to negative muon; then, the creation of muonic atoms is caused in the same pion production target. A converted electron is expected to be emitted after 1 ∼ 2 micro second-delayed timing. And two-body reaction of the new process, ${\mu }^{-}+(\mathrm{A},\mathrm{Z})\to e^{-}+(\mathrm{A},\mathrm{Z})$, results in 105 MeV monoenergetic electron. Thus, 1 ∼ 2 micro second-delayed 105 MeV monoenergetic electron is a searched signal. Electrons around 105 MeV are transported by the H-Line and analyzed using the dipole magnet (0.4 T) and four multi-wire proportional chambers (MWPCs). However, the burst pulse reaching ${10}^8$ charged particles/pulse attributable to the RCS pulse leads to significant dead time for the MWPC. Thus, the HV switching scheme is introduced to handle the prompt burst. The target single event sensitivity is ${10}^{-13}$. The H-Line construction was completed, and commissioning went well. The overview of the experiment and the current status are described in this article. Full article

Tomographic synthetic aperture radar (TomoSAR) obtains elevation resolution by adding multiple baselines successively in the direction perpendicular to the line of sight, thereby realizing three-dimensional (3D) reconstruction of complex scenes and significantly promoting the development of the 3D application field. However, a large data redundancy and long mapping time in traditional 3D imaging lead to a large data transmission burden, low efficiency, and high costs. To solve the above problems, this paper proposes a distributed SAR high-resolution and wide-swath (HRWS) 3D imaging technology scheme. The proposed scheme overcomes the size limitation of traditional single-satellite antennas through the multi-channel arrangement of multiple satellites in the elevation direction to achieve HRWS imaging; meanwhile, the distributed SAR system is integrated with tomographic processing technology to realize 3D imaging of difficult areas by using the elevation directional resolution of TomoSAR systems. HRWS 3D SAR increases the baseline length and channel number by transmission in turn, which leads to excessive pulse repetition frequency and causes echoes of different pulse signals to overlap in the same receiving cycle, resulting in range ambiguity and thus seriously affecting the quality of the 3D reconstruction. To solve this problem, this paper proposes a range ambiguity resolution algorithm based on multi-beam forming and verifies it on the measured data from airborne array SAR. Compared with the traditional TomoSAR, the distributed HRWS 3D SAR scheme proposed in this paper can obtain a greater mapping bandwidth with the same resolution in a single flight, thereby enhancing the time correlation, reducing data redundancy, and greatly improving mapping efficiency. Full article

We numerically investigate the dynamics of a ring consisting of three unidirectionally coupled Erbium-Doped Fiber Lasers (EDLFs) without external pump modulation. The study focuses on the system behavior as the coupling strength is varied, employing a six-dimensional mathematical model that includes three variables for laser intensities and three variables for population inversions of all lasers. Our primary objective is to understand the system evolution towards chaos from a stable equilibrium in the ring, considering the impact of increasing coupling strength. To analyze the system’s behavior, we employ various techniques such as time series analysis, power spectra, Poincaré sections, bifurcation diagrams, and Lyapunov exponents. During the transition to chaos, the system undergoes a Hopf bifurcation and a series of torus bifurcations. An essential aspect of this study is the exploration of a rotating wave propagating along the ring, where the wave nature (periodic, quasiperiodic, or chaotic) depends on the coupling strength. Additionally, we observe the coexistence of periodic and chaotic orbits within a specific range of the coupling strength. However, for very strong coupling, this bistability disappears, resulting in a monostable system with a single limit cycle. This regime exhibits potential for applications that demand short laser pulses with a substantial increase in peak power, reaching nearly 20 times higher levels compared to the continuous mode when the lasers are uncoupled. This discovery holds particular importance for optical communication systems, especially considering the attenuation optical signals experience when transmitted over long distances. Full article

This paper presents a single-stage three-port isolated power converter that enables energy conversion among a renewable energy port, a battery energy storage port, and a DC grid port. The proposed converter integrates an interleaved synchronous rectifier boost circuit and a bidirectional full-bridge circuit into a single-stage architecture, which features four power conversion modes, allowing energy adjustment for both the renewable energy and the battery storage energy ports when power is supplied by the renewable energy port. It also features bidirectional functionality that allows the battery storage energy port to provide energy storage through the DC grid port, thereby providing uninterrupted power supply functionality. The converter uses four power switches and two inductors to boost and convert energy from the renewable energy port to the battery storage energy port or to the DC grid port through the bidirectional full-bridge circuit. The converter is also capable of 1 kW power energy conversion by utilizing an adjustable duty cycle with a fixed frequency of 100 kHz and phase-shift control through a built-in pulse width modulation control module of a TMS320F28 series digital signal processor. According to the experimental results, the converter developed in this study can achieve a conversion efficiency of up to 94%. Full article

The electron valley pseudospin in two-dimensional hexagonal materials is a crucial degree of freedom for achieving their potential application in valleytronic devices. Here, bringing valleytronics to layered van der Waals materials, we theoretically investigate lightwave-controlled valley-selective excitation in twisted bilayer graphene (tBLG) with a large twist angle. It is demonstrated that the counter-rotating bicircular light field, consisting of a fundamental circularly-polarized pulse and its counter-rotating second harmonic, can manipulate the sub-cycle valley transport dynamics by controlling the relative phase between two colors. In comparison with monolayer graphene, the unique interlayer coupling of tBLG renders its valley selectivity highly sensitive to duration, leading to a noticeable valley asymmetry that is excited by single-cycle pulses. We also describe the distinct signatures of the valley pseudospin change in terms of observing the valley-selective circularly-polarized high-harmonic generation. The results show that the valley pseudospin dynamics can still leave visible fingerprints in the modulation of harmonic signals with a two-color relative phase. This work could assist experimental researchers in selecting the appropriate protocols and parameters to obtain ideal control and characterization of valley polarization in tBLG. Full article

Recent advances in flexible pressure sensors have fueled increasing attention as promising technologies with which to realize human epidermal pulse wave monitoring for the early diagnosis and prevention of cardiovascular diseases. However, strict requirements of a single sensor on the arterial position make it difficult to meet the practical application scenarios. Herein, based on three single-electrode sensors with small area, a 3 × 1 flexible pressure sensor array was developed to enable measurement of epidermal pulse waves at different local positions of radial artery. The designed single sensor holds an area of 6 × 6 mm², which mainly consists of frosted microstructured Ecoflex film and thermoplastic polyurethane (TPU) nanofibers. The Ecoflex film was formed by spinning Ecoflex solution onto a sandpaper surface. Micropatterned TPU nanofibers were prepared on a fluorinated ethylene propylene (FEP) film surface using the electrospinning method. The combination of frosted microstructure and nanofibers provides an increase in the contact separation of the tribopair, which is of great benefit for improving sensor performance. Due to this structure design, the single small-area sensor was characterized by pressure sensitivity of 0.14 V/kPa, a response time of 22 ms, a wide frequency band ranging from 1 to 23 Hz, and stability up to 7000 cycles. Given this output performance, the fabricated sensor can detect subtle physiological signals (e.g., respiration, ballistocardiogram, and heartbeat) and body movement. More importantly, the sensor can be utilized in capturing human epidermal pulse waves with rich details, and the consistency of each cycle in the same measurement is as high as 0.9987. The 3 × 1 flexible sensor array is employed to acquire pulse waves at different local positions of the radial artery. In addition, the time domain parameters including pulse wave transmission time (PTT) and pulse wave velocity (PWV) can be obtained successfully, which holds promising potential in pulse-based cardiovascular system status monitoring. Full article

This work proposes an improvement for a recently proposed converter. The discussed converter is the so-called low-voltage in capacitors (LVC). It offers a larger voltage gain compared to the standard step-up or boost converter while operating with a relatively low voltage in their capacitors (lower than the voltage at the output port). The improvement consists of a modification in the pulse width modulation (PWM) scheme. The new modulation scheme allows for a reduction in the voltage ripple at the output port, which means an improvement in the power quality. The LVC converter contains two transistors, but it was proposed to operate with a single switching signal. The new PWM scheme is based on two switching signals with the same duty cycle (same waveform and same average time in high) but 180° of phase shift among them. The PWM scheme significantly affects the voltage ripple at the converter’s output port. The voltage ripple reduction at the converter’s output port is achieved without increasing the transistor switching frequency and without modifying the circuit parameters (capacitance in capacitors or inductance in inductors). The article starts by introducing the converter. Then, it presents its mathematical model, including the calculation of the voltage ripple at its output port. The experimental results performed on the LCV in both the former and the proposed operation prove the reduction in the voltage ripple, and the comparison also includes the traditional boost converter. Full article

This paper presents a comparison of Isolated (Flyback) and non-Isolated (Buck) multiple input-single output (MISO) DC-DC converters. The analysis of DC-DC converters is based on pulsed voltage source cells (PVSC). The modeling of both converter types is detailed through their mathematical models and electrical simulations using Matlab/Simulink and PSIM. The comparison focuses on the sizing parameters, non-ideal output characteristics and efficiency. Results show that the output voltage of the MISO Buck converter exhibits a linear dependence on the duty cycles control signal and has slightly higher efficiency than the Flyback converter. To validate the operation of both converters, a scenario with two inputs (low-power hydroelectric and photovoltaic voltage sources) is considered. The modeling and control of both source systems are detailed and the MISO converter performance response is evaluated under sources changes and efficiency point of view. Full article

A bidirectional pulse power supply with continuously adjustable forward parameters 8 V/20 A and reverse parameters 20 V/50 A was designed using DSP (Digital Signal Processor), and the bidirectional pulse power supply was used to test copper plating on printed circuit boards with filled via holes. The effects of frequencies, pulse width ratios of forward and reverse currents, and current densities on the copper plating effect were investigated by the single variable method and were compared with DC copper plating. The experimental results showed that compared with DC power supply, the bidirectional pulse power supply had a better effect and a faster speed on via-filling copper plating, and can also reduce the use of additives, which is in line with green development. The parameters of the pulse affected the plating effect to varying degrees. In this solution system, the optimal parameters for bidirectional pulse plating are frequency 1 kHz, forward pulse current density 4 ASD (Ampere per Square Decimeter) with 50% duty cycle, and reverse pulse current density 16 ASD with 2.5% duty cycle. Full article
