Search Results (51)

The design of ergonomic tool handles is crucial for user comfort and performance, yet conventional stiff materials often lead to uneven pressure distribution and discomfort. This study investigates the application of 3D-printed cellular metamaterials with tunable stiffness, specifically gyroid structures, to enhance the ergonomic and haptic properties of tool handles. We employed finite element analysis to simulate finger–handle interactions and conducted subjective comfort evaluations with participants using a foxtail saw with handles of varying gyroid infill densities and a rigid PLA handle. Numerical results demonstrated that handles with medium stiffness significantly reduced peak contact pressures and promoted a more uniform pressure distribution compared to the stiff PLA handle. The softest gyroid handle, while compliant, exhibited excessive deformation, potentially compromising stability. Subjective comfort ratings corroborated these findings, with medium-stiffness handles receiving the highest scores for overall comfort, fit, and force transmission. These results highlight that a plateau-like mechanical response of the 3D-printed cellular metamaterial handle, inversely bioinspired by human soft tissue, effectively balances pressure redistribution and grip stability. This bioinspired design approach offers a promising direction for developing user-centered products that mitigate fatigue and discomfort in force-intensive tasks. Full article

Human–machine interfacing (HMI) has emerged as a critical technology in healthcare, robotics, and wearable electronics, with hydrogels offering unique advantages as multifunctional materials that seamlessly connect biological systems with electronic devices. This review provides a detailed examination of recent advancements in hydrogel design, focusing on their properties and potential applications in HMI. We explore the key characteristics such as biocompatibility, mechanical flexibility, and responsiveness, which are essential for effective and long-term integration with biological tissues. Additionally, we highlight innovations in conductive hydrogels, hybrid and composite materials, and fabrication techniques such as 3D/4D printing, which allow for the customization of hydrogel properties to meet the demands of specific HMI applications. Further, we discuss the diverse classes of polymers that contribute to hydrogel conductivity, including conducting, natural, synthetic, and hybrid polymers, emphasizing their role in enhancing electrical performance and mechanical adaptability. In addition to material design, we examine the regulatory landscape governing hydrogel-based biointerfaces for HMI applications, addressing the key considerations for clinical translation and commercialization. An analysis of the patent landscape provides insights into emerging trends and innovations shaping the future of hydrogel technologies in human–machine interactions. The review also covers a range of applications, including wearable electronics, neural interfaces, soft robotics, and haptic systems, where hydrogels play a transformative role in enhancing human–machine interactions. Thereafter, the review addresses the challenges hydrogels face in HMI applications, including issues related to stability, biocompatibility, and scalability, while offering future perspectives on the continued evolution of hydrogel-based systems for HMI technologies. Full article

With an increasing number of elderly individuals, the demand for advanced technologies to treat cardiac diseases has become more critical than ever. Additionally, there is a pressing need to reduce the learning curve for cardiac interventionalists to keep pace with the rapid development of new types of procedures and devices and to expand the adoption of established procedures in more hospitals. This comprehensive review aims to shed light on recent advancements in novel robotic systems for cardiac interventions. To do so, this review provides a brief overview of the history of previously developed robotic systems and describes the necessity for advanced technologies for cardiac interventions to address the technological limitations of current systems. Moreover, this review explores the potential of cutting-edge technologies and methods in developing the next generation of intra-procedure autonomous navigation. Each highlighted topic undergoes a critical analysis to evaluate its technical limitations and the challenges that must be addressed for successful clinical implementation. Full article

Coronary heart disease, a leading global cause of mortality, has witnessed significant advancement through robotic coronary artery bypass grafting (CABG), with the internal mammary artery (IMA) emerging as the preferred “golden conduit” for its exceptional long-term patency. Despite these advances, robotic-assisted IMA harvesting remains challenging due to the absence of force feedback, complex surgical maneuvers, and proximity to the beating heart. This study introduces a novel virtual simulation platform for robotic IMA harvesting that integrates dynamic anatomical modeling and real-time haptic feedback. By incorporating a dynamic cardiac model into the surgical scene, our system precisely simulates the impact of cardiac pulsation on thoracic cavity operations. The platform features high-fidelity representations of thoracic anatomy and soft tissue deformation, underpinned by a comprehensive biomechanical framework encompassing fascia, adipose tissue, and vascular structures. Our key innovations include a topology-preserving cutting algorithm, a bidirectional tissue coupling mechanism, and dual-channel haptic feedback for electrocautery simulation. Quantitative assessment using our newly proposed Spatial Asymmetry Index (SAI) demonstrated significant behavioral adaptations to cardiac motion, with dynamic scenarios yielding superior SAI values compared to static conditions. These results validate the platform’s potential as an anatomically accurate, interactive, and computationally efficient solution for enhancing surgical skill acquisition in complex cardiac procedures. Full article

The TacTip is a cost-effective, 3D-printed optical tactile sensor commonly used in deep learning and reinforcement learning for robotic manipulation. However, its specialized structure, which combines soft materials of varying hardnesses, makes it challenging to simulate the distribution of numerous printed markers on pins. This paper aims to create an interpretable, AI-applicable simulation of the deformation of TacTip under varying pressures and interactions with different objects, addressing the black-box nature of learning and simulation in haptic manipulation. The research focuses on simulating the TacTip sensor’s shape using a fully tunable, chain-based mathematical model, refined through comparisons with real-world measurements. We integrated the WRS system with our theoretical model to evaluate its effectiveness in object pose estimation. The results demonstrated that the prediction accuracy for all markers across a variety of contact scenarios exceeded 92%. Full article

Virtual reality systems may benefit from wearable (fingertip-mounted) haptic displays capable of rendering the softness of virtual objects. According to neurophysiological evidence, the easiest reliable way to render a virtual softness is to generate purely tactile (as opposed to kinaesthetic) feedback to be delivered via a finger-pulp-interfaced deformable surface. Moreover, it is necessary to control not only the skin indentation depth by applying quasi-static (non-vibratory) contact pressures, but also the skin contact area. This is typically impossible with available devices, even with those that can vary the contact area, because the latter cannot be controlled due to the complexity of sensing it at high resolutions. This causes indetermination on an important tactile cue to render softness. Here, we present a technology that allows the contact area to be open-loop controlled via personalised optical calibrations. We demonstrate the solution on a modified, pneumatic wearable tactile display of softness previously described by us, consisting of a small chamber containing a transparent membrane inflated against the finger pulp. A window on the device allowed for monitoring the skin contact area with a camera from an external unit to generate a calibration curve by processing photos of the skin membrane interface at different pressures. The solution was validated by comparisons with an ink-stain-based method. Moreover, to avoid manual calibrations, a preliminary automated procedure was developed. This calibration strategy may be applied also to other kinds of displays where finger pulps are in contact with transparent deformable structures. Full article

Manipulating a flexible ureteroscope is difficult, due to its bendable body and hand–eye coordination problems, especially when exploring the lower pole of the kidney. Though robotic interventions have been adopted in various clinical scenarios, they are rarely used in ureteroscopy. This study proposes a teleoperation system consists of a soft robotic endoscope together with a Guidance Virtual Fixture (GVF) to help users explore the kidney’s lower pole. The soft robotic arm was a cable-driven, 3D-printed design with a helicoid structure. GVF was dynamically constructed using video streams from an endoscopic camera. With a haptic controller, GVF can provide haptic feedback to guide the users in following a trajectory. In the user study, participants were asked to follow trajectories when the soft robotic arm was in a retroflex posture. The results suggest that the GVF can reduce errors in the trajectory tracking tasks when the users receive the proper training and gain more experience. Based on the NASA Task Load Index questionnaires, most participants preferred having the GVF when manipulating the robotic arm. In conclusion, the results demonstrate the benefits and potential of using a robotic arm with a GVF. More research is needed to investigate the effectiveness of the GVFs and the robotic endoscope in ureteroscopic procedures. Full article

Dielectric elastomer actuators (DEAs) have gained significant attention due to their potential in soft robotics and adaptive structures. However, their performance is often limited by their in-plane strain distribution and limited mechanical stability. We introduce a novel design utilizing fiber reinforcement to address these challenges. The fiber reinforcement provides enhanced mechanical integrity and improved strain distribution, enabling efficient energy conversion and out-of-plane displacement. We discuss an analytical model and the fabrication process, including material selection, to realize fiber-reinforced DEAs. Numerical simulations and experimental results demonstrate the performance of the fiber-reinforced equibiaxial DEAs and characterize their displacement and force capabilities. Actuators with four and eight fibers are fabricated with 100 $\mathsf{\mu }$m and 200 $\mathsf{\mu }$m dielectric thicknesses. A maximal out-of-plane displacement of 500 $\mathsf{\mu }$m is reached, with a force of 0.18 N, showing promise for the development of haptic devices. Full article

Soft robotics is a hot scientific topic in areas such as medicine and medical care, implantology, haptic technologies, and the design of various flexible structures. Integrated actuators (DEAP and MRE) are characterized by special functionality and a wider range of operations than when used individually. Such actuators can later be controlled with high voltages ranging from several to a dozen or so kV. Unfortunately, the production process of integrated actuators is multi-stage and therefore more complicated. Thus, at the stage of prototyping, microscopic errors often occur that cannot be detected using simple measurement methods. The result of such errors is actuator damage at the testing stage or in subsequent application. Unfortunately, due to high voltages, actuator damage usually leads to it catching fire, which is potentially dangerous. This work presents an approach that enables the prediction of actuator damage at the testing stage. The results of modeling damaged actuators, a modified safe testing method, and a complete supervising system for testing the actuator with protection are shown. The work is also enriched with a set of data from the analyzed damage to DEAP and MRE actuators, which may prove useful in other research on the actuators of soft robotics. Full article

In robot-assisted microsurgery (RAMS), surgeons often face the challenge of operating with minimal feedback, particularly lacking in haptic feedback. However, most traditional desktop haptic devices have restricted operational areas and limited dexterity. This report describes a novel, lightweight, and low-budget wearable haptic controller for teleoperated microsurgical robotic systems. We designed a wearable haptic interface entirely made using off-the-shelf material-PolyJet Photopolymer, fabricated using liquid and solid hybrid 3D co-printing technology. This interface was designed to resemble human soft tissues and can be wrapped around the fingertips, offering direct contact feedback to the operator. We also demonstrated that the device can be easily integrated with our motion tracking system for remote microsurgery. Two motion tracking methods, marker-based and marker-less, were compared in trajectory-tracking experiments at different depths to find the most effective motion tracking method for our RAMS system. The results indicate that within the 4 to 8 cm tracking range, the marker-based method achieved exceptional detection rates. Furthermore, the performance of three fusion algorithms was compared to establish the unscented Kalman filter as the most accurate and reliable. The effectiveness of the wearable haptic controller was evaluated through user studies focusing on the usefulness of haptic feedback. The results revealed that haptic feedback significantly enhances depth perception for operators during teleoperated RAMS. Full article

In the realm of virtual and augmented reality (VR/AR) and teleoperation applications, haptic feedback plays a role in enhancing task performance. One of the main goals of this study is to simplify haptic device hardware while improving its capacity to provide various stimuli at different intensities. In response to these challenges, this research introduces the Pneumatic Unit Cell (PUC), a soft pneumatically driven device—a hollow silicone cylinder with the ability to provide both static-pressure and vibrotactile feedback. Furthermore, the Pneumatic Unit Cell’s design simplicity has the potential for scalability, modularity, and the flexibility to mount the device on any part of the human body. The focus of the current paper is to study PUCs as actuators and lay the foundation for future perceptual studies. The characterization studies encompass the fabrication and verification of the fabrication accuracy through dimensional measurements, characterizing PUCs under static-pressure conditions (measuring the free deflection and blocking force) and frequency conditions (measuring the free deflection). In the static-pressure conditions, we applied pressures ranging from 0 to 40 kPa to measure the free deflection and from 0 to 30 kPa to measure the blocking force. In the frequency conditions, we applied pressures of 10, 20, and 30 kPa with inflation/deflation rates varying between 0.5 Hz and 100 Hz. The measurements of free deflection under static-pressure conditions revealed that 0.9 mm and 1.2 mm PUCs exhibit a linear increase in free deflection with an increase in inflation pressure. The results of free-deflection measurements under the frequency conditions indicate a direct relationship between the free-deflection magnitude and applied pressure. The results also demonstrate an inverse relationship to the frequency of inflation/deflation. The characterization results demonstrate a broad range of free deflection observed under both static-pressure and frequency conditions, encouraging the potential application of Pneumatic Unit Cell actuators as haptic devices. Full article

The rapid development of computers and robots has seen robotic minimally invasive surgery (RMIS) gradually enter the public’s vision. RMIS can effectively eliminate the hand vibrations of surgeons and further reduce wounds and bleeding. However, suitable RMIS and virtual reality-based digital-twin surgery trainers are still in the early stages of development. Extensive training is required for surgeons to adapt to different operating modes compared to traditional MIS. A virtual-reality-based digital-twin robotic minimally invasive surgery (VRDT-RMIS) simulator was developed in this study, and its effectiveness was introduced. Twenty-five volunteers were divided into two groups for the experiment, the Expert Group and the Novice Group. The use of the VRDT-RMIS simulator for face, content, and structural validation training, including the peg transfer module and the soft tissue cutting module, was evaluated. Through subjective and objective evaluations, the potential roles of vision and haptics in robot surgery training were explored. The simulator can effectively distinguish surgical skill proficiency between experts and novices. Full article

In this study, a comprehensive approach for sensing object stiffness through the pincer grasping of soft pneumatic grippers (SPGs) is presented. This study was inspired by the haptic sensing of human hands that allows us to perceive object properties through grasping. Many researchers have tried to imitate this capability in robotic grippers. The association between gripper performance and object reaction must be determined for this purpose. However, soft pneumatic actuators (SPA), the main components of SPGs, are extremely compliant. SPA compliance makes the determination of the association challenging. Methodologically, the connection between the behaviors of grasped objects and those of SPAs was clarified. A new concept of SPA modeling was then introduced. A method for stiffness sensing through SPG pincer grasping was developed based on this connection, and demonstrated on four samples. This method was validated through compression testing on the same samples. The results indicate that the proposed method yielded similar stiffness trends with slight deviations in compression testing. A main limitation in this study was the occlusion effect, which leads to dramatic deviations when grasped objects greatly deform. This is the first study to enable stiffness sensing and SPG grasping to be carried out in the same attempt. This study makes a major contribution to research on soft robotics by progressing the role of sensing for SPG grasping and object classification by offering an efficient method for acquiring another effective class of classification input. Ultimately, the proposed framework shows promise for future applications in inspecting and classifying visually indistinguishable objects. Full article

The purpose of this study is to analyze the cognitive characteristics that can be induced by vibration stimuli at two intensities, three frequencies, and five presentation periods. The experiment was conducted on 20 right-handed adult males, and a subjective evaluation was performed using a questionnaire. Regression analysis was performed to observe the parameters affecting cognitive characteristics according to changes in intensity, frequency, and stimulation duration. The regression analysis results showed that the cognitive characteristics affected by changes in intensity, frequency, and stimulation duration were “heavy”, “bold”, “thick”, and “light”. The cognitive characteristics affected by two-variable combinations were “deep”, “clear”, “vibrating”, “dense”, “numb”, “blunt”, “shallow”, “fuzzy”, and “soft”. Cognitive characteristics affected by either intensity, frequency, or stimulation duration were “fast”, “pungent”, “skinny”, “thin”, “slow”, “ticklish”, “tingling”, “prickling”, “tap”, and “rugged”. By observing the cognitive characteristics that can be induced by the combination of intensity, frequency, and stimulation duration, we confirmed that in addition to intensity and frequency, the stimulation duration is an important factor that influences the induction of various cognitive characteristics. The results presented in the study can be used to enhance the utility of haptic surfaces for extended reality applications. Full article

This paper presents results of the first phase of “Dielectric Elastomer Cooperative Microactuator Systems” (DECMAS), a project within the German Research Foundation Priority Program 2206, “Cooperative Multistable Multistage Microactuator Systems” (KOMMMA). The goal is the development of a soft cooperative microactuator system combining high flexibility with large-stroke/high-frequency actuation and self-sensing capabilities. The softness is due to a completely polymer-based approach using dielectric elastomer membrane structures and a specific silicone bias system designed to achieve large strokes. The approach thus avoids fluidic or pneumatic compo-nents, enabling, e.g., future smart textile applications with cooperative sensing, haptics, and even acoustic features. The paper introduces design concepts and a first soft, single-actuator demonstrator along with experimental characterization, before expanding it to a 3 × 1 system. This system is used to experimentally study coupling effects, supported by finite element and lumped parameter simulations, which represent the basis for future cooperative control methods. Finally, the paper also introduces a new methodology to fabricate metal-based electrodes of sub-micrometer thickness with high membrane-straining capability and extremely low resistance. These electrodes will enable further miniaturization towards future microscale applications. Full article
