During continuous casting, the flow behavior of liquid steel in the tundish directly affects the temperature distribution of liquid steel, inclusion removal, and billet quality. In tundish-related research, water model experiments remain an intuitive method for investigating the flow process in the tundish. However, water model experiments are often conducted in different seasons, and variations in experimental temperature can change fluid properties such as density and viscosity, thereby affecting flow characteristics and the comparability of experimental results. In this study, a 1:3.57 transparent bare single-strand tundish model made of acrylic was used, and the differences in tracer transport processes at 7 °C and 20 °C, as well as the influence of different tracer dosages on the experimental results, were systematically investigated through flow visualization and stimulus-response experiments. The results showed that, under the 7 °C condition, the upward transport tendency of the pure ink tracer was weakened, the overall flow remained closer to the tundish bottom, the transport speed decreased, and the time required to reach the outlet was significantly prolonged. For the saturated KCl solution tracer, a lower temperature enhanced its transport along the bottom toward the outlet and suppressed its diffusion toward the liquid surface. The RTD results showed that, after the temperature was increased, the curves shifted to the left as a whole, and both the peak time and the mean residence time were shortened. The outflow percentage of tracer results showed that the difference for the 10 mL saturated KCl solution between the 7 °C and 20 °C conditions was the most significant. At 7 °C, the total outflow percentage of the 10 mL salt solution tracer at 1500 s was 76.86%, which was 22.97% lower than that at 20 °C. As the tracer dosage increased, the differences in the transport process, RTD curves, and outflow percentage curves under different temperature conditions gradually decreased, indicating that the effect of dosage on the experimental results gradually became stronger than that of temperature. These results indicate that the combined effects of experimental temperature and tracer dosage cannot be neglected in tundish water model experiments. Full article

To improve steel cleanliness during continuous casting, tundish flow-control devices must effectively regulate molten-steel flow and promote the removal of non-metallic inclusions. In this study, a numerical investigation was conducted to clarify the coupled effects of pore number and pore elevation angle in an inclined porous tundish filter on molten-steel flow behavior and inclusion removal. Twenty-five filter configurations were compared by varying the pore number from 2 to 32 pores and the pore elevation angle from 20° to 40° while maintaining an identical total flow-through area. The results show that inclusion removal is governed by the combined effects of flow guidance, velocity-field uniformity, and post-filter streamline distribution, with the filter containing 8 pores and a 40° pore elevation angle achieving the highest average inclusion removal efficiency of 74.33% for 20–80 μm inclusions. These findings provide a quantitative basis for optimizing tundish filter geometry and improving steel cleanliness during continuous casting. Full article

Steelmaking is one of the most important industries worldwide due to many products being made with different kinds of steel or cast iron; during processing, pig iron and scrap are founded in furnaces and then transported in ladles to be cast in tundishes towards strains to produce steel billets, which are treated in a secondary manufacturing process to produce products like wires and profiles. Then, it is necessary to pay attention to every process and establish rules for safe operational practices, avoid interruptions in production, reduce risks and maintain quality. Thus, the purpose of this research is to study the hydrodynamic behavior of five stopper rods with different but basic geometrical configurations. Stopper rods are devices that are used to control the fluid flow in tundishes to allow or avoid a steel fluid drain. Stopper rods are placed to allow or avoid the liquid steel passing out towards the molds in the deepest holes in the tundishes. Management, drive and mass transport are important parameters to analyze for casting molten steel. After analyzing the hydrodynamic performance of these five stopper rods, and according to the results obtained, two more new designs were created and tested in real industrial trials, and the results are described in detail. Additionally, a study about the counting of the inclusions trapped in the rod walls is also shown to evaluate every design, with the main goal being to retain the flows passing across the stopper rod and the exit nozzle and to avoid clogging problems in order to keep constant the casting of molten steel. Hydro-dynamic analysis was carried out by solving the Navier–Stokes equation using the k-ε turbulence model using Computational Fluid Dynamics (CFD). Full article

In this paper, the influence of the novel design of a ladle shroud (LS) on the liquid steel flow structure inside the working volume of a two-strand slab tundish was assessed, determining the best solutions for LS use to achieve the optimal level of active flow zones and protect the tundish lining. A 0.33 scale water model was used for physical experiments. Numerical simulations were carried out in the Ansys-Fluent 12.1 software for a 1:1 scale tundish. The effect of the influence of LS type, LS immersion depth, LS side ports position, LS misalignment and casting speed was examined. Finally, the use of the “umbrella” ladle shroud allows stable hydrodynamics to be maintained even with shroud misalignment. Moreover, the “umbrella” ladle shroud effectively decreases the average velocity of liquid steel inside the tundish and significantly decreases shear stresses and dynamic pressure at the tundish lining in the tundish pouring area. Full article

This study aims to use Computational Fluid Dynamics (CFD) analysis to improve inclusion removal efficiency in tundishes used in the steelmaking industry, with the broader goal of promoting more sustainable steel production and supporting circular economy objectives by producing cleaner steel. Inclusions are non-metallic particles, such as alumina, that enter the tundish with the molten steel and travel through it; if not removed, they can exit through the nozzles and adversely affect the mechanical properties of the final product and process yield. An existing tundish design is modified using three passive techniques, including adding a vertical dam, adding a horizontal baffle, and inclining the side walls, to assess their influence on fluid flow behavior and inclusion removal. Residence time distribution (RTD) analysis is employed to evaluate flow characteristics via key metrics such as dead zone and plug flow volume fractions, as well as plug-to-dead and plug-to-mixed flow ratios. In parallel, a discrete phase model (DPM) analysis is conducted to track inclusion trajectories for particles ranging from 5 to 80 μm. Results show that temperature gradients due to heat losses significantly influence flow patterns via buoyancy-driven circulation, changing RTD characteristics. Among the tested modifications, inclining the side walls proves most effective, achieving average inclusion removal improvements of 8% (Case B1) and 19% (Case B2), albeit with increased heat loss due to greater top surface exposure. Vertical dam and horizontal baffle, despite showing favorable RTD metrics, generally reduce the inclusion removal rate, highlighting a disconnect between RTD-based predictions and DPM-based outcomes. These findings demonstrate the limitations of relying solely on RTD metrics for evaluating tundish performance and suggest that DPM analysis is essential for a more accurate assessment of inclusion removal capability. Full article

Rare earth can modify inclusions in non-oriented silicon steel which is harmful to magnetic properties. This study focused on the 3.1% Si non-oriented silicon steel under industrial production conditions. Samples were taken during the stages before and after addition of rare earth ferrosilicon alloy in Ruhrstahl-Heraeus (RH) unit, different pouring time in tundish, and continuous casting slab. This study systematically examined the morphology, composition, and size distribution of inclusions throughout the smelting process of non-oriented silicon steel by scanning electron microscopy with energy-dispersive spectroscopy (SEM/EDS), and thermodynamic analysis at liquid steel temperature and thermodynamic analysis of equilibrium solidification. The research results demonstrated that the rare earth treatment ultimately modifies the original Al₂O₃ inclusions in the non-oriented silicon steel into REAlO₃ and RE₂O₂S inclusions, while also aggregating AlN inclusions to form composite inclusions. After rare earth modification, the average size of the inclusions decreases. In the RH treatment process, the inclusions before the addition of rare earth ferrosilicon alloy are mainly AlN and Al₂O₃. After the addition of rare earth ferrosilicon alloy, the inclusions are mainly RES and REAlO₃. In the tundish and continuous casting, the rare earth content decreased, and the rare earth inclusions transform into RE₂O₂S and REAlO₃. For the size of inclusions, after adding rare earth ferrosilicon alloy, the average size of inclusions rapidly decreased from 16.15 μm to 2.65 μm and reach its minimum size 2.16 μm at the end of RH treatment. When the molten steel entered the tundish, the average size of inclusions increased slightly and gradually decreased with the progress of pouring. The average size of inclusions in the slab is 5.79 μm. Phase stability diagram calculation indicates the most stable rare earth inclusion is Ce₂O₂S in molten steel. Thermodynamic calculations indicated that Al₂O₃, Ce₂O₂S, Ce₂S₃, AlN, and MnS precipitate sequentially during the equilibrium solidification process of molten steel. Full article

Stuffing sand, as a critical auxiliary material, plays an important role in ladle teeming during the continuous casting process and is closely related to steel cleanliness. Based on thermodynamic calculations, a melting test in a vacuum induction furnace, and industrial statistical data analysis, the reoxidation of IF steel caused by conventional Cr₂O₃-based stuffing sand was investigated. The results show that Cr₂O₃-based stuffing sand is one of the main factors resulting in the reoxidation of IF steel. [Al] and [Ti] in IF steel can be oxidized by FeO, Cr₂O₃, and SiO₂ from the Cr₂O₃-based stuffing sand, which leads to the mass burning loss of [Al] and [Ti], thus resulting in the deterioration of steel cleanliness. After reoxidation caused by Cr₂O₃-based stuffing sand, the [Cr] content in IF steel increases by 70 ppm on average. To avoid reoxidation pollution by conventional Cr₂O₃-based stuffing sand, a new kind of Al₂O₃-based stuffing sand with low reactivity was developed and applied in industrial production. After adopting this new kind of stuffing sand, the burning loss of [Al] and [Ti] decreases by 41.3% and 24.2%, respectively, and the total oxygen content (T.[O]) of the steel in the tundish decreases by 35.2% compared with the conventional Cr₂O₃-based stuffing sand. Full article

Nodular cast iron is one of the most widely used materials in the machine building industry. The main reasons for this are its strength, elongation, and competitive price compared to other steels and metals. The possibility to have a high strength and elongation together is thanks to the spheroidal shape of the graphite inserts in the metal structure of the iron. To exploit these advantages, special treatments such as adding magnesium are used after the melting process but before pouring the metal in the casting mold. Classic technology is called tundish/sandwich technology when ferrosiliconmagnesium alloy in bulk is placed at the bottom of a ladle before filling it with liquid cast iron. In the present article, an alternative technology will be presented where a fesimg alloy is filled in a steel wire and inserted automatically into a ladle. The advantages of this technology will be described in detail. Full article

During the continuous casting process, the submerged entry nozzle (SEN) should be maintained at the geometric center of the mold. However, in actual production, factors such as deformation of the tundish bottom and inaccurate positioning of the traversing car occasionally cause SEN offset. SEN offset can make the molten steel flow field in the mold asymmetric, increasing the risks of slag entrainment on the surface of the casting blank and breakout accidents. To evaluate the influence of different SEN offsets on the mold flow field, this study uses a slab continuous casting mold with a cross-section of 920 mm × 200 mm from a specific factory as the research object. Mathematical simulations were used to investigate the influence of SEN offsets (including width-direction and thickness-direction offsets) on the flow behavior of molten steel in the mold. A physical water model at a 1:1 scale was established for verification. Two parameters, the symmetry index (S) and the bias flow index (N), were introduced to quantitatively evaluate the symmetry of the flow field, and the rationality of the liquid-level fluctuation under this flow field was verified using the F-number (proposed by Japanese experts for mold level fluctuation control) from the index model. The results show the following: when the SEN offset in the thickness direction increases from 0 to 50 mm, the longitudinal symmetry index (Sy) of the molten steel flow field in the mold decreases from 0.969 to 0.704—a reduction of 27.4%; the longitudinal bias flow index (Ny) of molten steel level fluctuation increases from 0.007 to 0.186, representing a 25.6-fold increase, and the F-number rises from 4.297 to 8.482; when the SEN offset in the width direction increases from 0 to 20 mm, the transverse-axis symmetry index (Sx) of the flow field decreases gradually from 0.969 to 0.753 at a 20 mm offset, which is a reduction of approximately 22.29%; the transverse-axis bias flow index (Nx) increases from 0.015 to 0.174 at a 20 mm offset—an increase of 10.6 times; and the F-number increases from 4.297 to 5.548. Considering the comprehensive evaluation of horizontal/vertical symmetry indices, bias flow indices, and F-numbers under the two working conditions, the width-direction SEN offset has the most significant impact on the symmetry of the molten steel flow field. Full article

The behavior of molten steel within a tundish plays a crucial role in achieving uniform temperature and chemical composition, enhancing the removal efficiency of non-metallic inclusions, and reducing the wear of refractory linings. These aspects are key for ensuring the production of steel with superior quality. In multi-strand delta-type tundishes, such as the six-strand configuration, flow dynamics become particularly challenging. Key considerations include strand-specific residence times, the uniform distribution of steel flow, and the mitigation of refractory degradation. This paper presents a detailed numerical analysis aimed at designing an optimally shaped impact pad. The effectiveness of each proposed design was assessed through a tracer-based visualization of flow behavior and the evaluation of residence time distribution (RTD) curves. RTD curves were created in isothermal conditions, while the calculations of the temperature fields of steel in the tundish were made in non-isothermal conditions. The results of the simulations were verified by a real plant trial test and indicate that the use of the “SPHERIC-K4” impact pad can greatly enhance the flow characteristics of liquid steel during the continuous casting process. These improvements include preventing the erosion of the tundish refractory lining, improving the distribution of residence times between individual casting strands, and adjusting the proportions of the mixing zones. Full article

The study analyzes the splash dynamics of liquid steel jets impacting solid surfaces, using a physical model with scaled-down water experiments. Two turbulence inhibitor designs are compared, focusing on droplet formation and distribution. The interaction of the jet with the inhibitors influences droplet generation and dispersion, impacting the safety and quality of the continuous casting process. Key parameters such as the Weber number and surface tension are identified as factors affecting the stability of liquid films. Finally, similarities between splash dynamics in water and steel are highlighted. Full article

The production of silicon steel involves complex metallurgical processes, where the kind, composition, size, and quantity of the inclusions generated affect the silicon steel properties. This article is based on the smelting process for W350 non-oriented silicon steel produced by a certain factory. By systematically sampling, at key nodes of the converter–RH refining–tundish smelting process, the change in cleanliness of molten steel in the whole smelting process, the evolution of typical inclusions, and the transformation rules for the precipitated phase were analyzed by means of SEM-EDS, ASPEX, and Thermal-Calc. The results indicate that the total oxygen mass fraction in the steel decreases by more than 95% after deoxidation alloying, and the average oxygen mass fraction in the RH outbound steel is 0.0012%. While the nitrogen mass fraction shows a rising trend as a whole, the average nitrogen mass fraction in the tundish steel reaches approximately 0.0014%. Before RH refining, large Al₂O₃–CaO–SiO₂ and Al₂O₃–CaO–SiO₂–MgO composite inclusions are the main inclusions. MnO and Al₂O₃–SiO₂–MnO inclusions are the main inclusions after RH inlet and RH decarburization. After RH deoxidation with aluminum, the inclusions were almost entirely transformed into Al₂O₃ inclusions. After RH alloying, with the content of Si and Mn increased, the inclusions transformed into Al₂O₃–SiO₂–MnO inclusions. The number of inclusions from RH desulfurization to the RH outbound stage declined significantly, and composite inclusions containing CaS and precipitates such as AlN and MnS began to appear. The inclusions’ main types were Al₂O₃–MgO–CaS, AlN–MnS, AlN, and Al₂O₃–MgO. The inclusions inside the tundish were the same, but the numbers were slightly increased due to the secondary oxidation of molten steel. More than 80% of the oxide inclusions in the whole process were between 1 μm and 5 μm in size. The average size and the number of inclusions per unit area reached 5.45 μm and 63.1 per mm², respectively, after RH deoxidation, and respectively decreased to 3.71 μm and 1.9 per mm² during the RH outbound stage, but both increased slightly in the tundish. Thermodynamic calculation shows that Al₂O₃–MgO inclusions are formed when w([Mg]) > 0.0033% in molten steel at 1873 K. Under the actual temperature of 1828K and w([Al]s) = 0.6515%, the range of w([Mg]) corresponding to the stable existence of Al₂O₃–MgO is between 0.0053% and 0.1676%. The liquidus temperature of W350 non-oriented silicon steel is 1489 °C. MnS and AlN inclusions are precipitated successively with the solidification of molten steel, and the precipitation temperatures are 1460.7 °C and 1422.2 °C, respectively. As the temperature decreases, the sequence of inclusion precipitation calculated in liquid was as follows: Al₂O₃–CaO → 2Al₂O₃–CaO + MnS → 6Al₂O₃–CaO → Al₂O₃ + AlN + MnS + CaS. Full article

The temperature gradient inside a tundish leads to the uneven density distribution of molten steel, resulting in thermal buoyancy, which has a significant impact on the motion of inclusion particles. Based on practice data and necessary assumptions, a three-dimensional model of a tundish considering non-uniform thermal transfer was established. The flow and temperature distribution were studied, and the changes in inclusion removal rate were compared with different casting speeds and temperature reduction rates using computational fluid dynamics simulation. It was observed that, when the inlet temperature is higher, the molten steel floats up under the action of thermal buoyancy, which can form a horizontal stream behind the weir. While the inlet temperature is lower, the horizontal stream cannot be maintained, resulting in a decrease in the removal rate of inclusions. Increasing the casting speed will increase the velocity of the molten steel in the tundish, make it easier to shorten the temperature difference between the inlet and outlet, and reduce the removal rate of inclusions. When formulating production processes, the impact of thermal buoyancy on the flow field should be taken into account. Full article

Casting AISI 52100 steel represents a challenge, particularly at the start of the casting sequence, due to its low melting point. The steel spilling over the tundish bottom cools down rapidly and freezes in the stopper rods, obliging the closure of a strand. Therefore, an additional function of turbulence inhibitors is to induce steel masses at a slow cooling rate. This paper deals with the physical and mathematical modeling of unsteady state-flows using two turbulence inhibitors (TIs) during the sequence start. One of the TIs makes steel spill forming thin layers of liquid on the tundish bottom, while the other forms a thicker layer. Based on the Flow of Volume Model, the mathematical simulation was satisfactorily replicated in the water model. Full article

In order to optimize the application effect of induction heating (IH) tundishes, a four-channel IH tundish is taken as the research object. Based on numerical simulation methods, the influence of different relative placement angles of induction heaters and channels on the electromagnetic field, flow field and temperature field of the tundish is investigated. We focus on comparing the magnetic flux density (B) and electromagnetic force (EMF) distribution of the channel. The results show that regardless of the relative placement angle between the heater and the channel, the distribution of B in the central circular cross-section of the channel is eccentric. When the heater rotates around channel 1 towards the bottom of the tundish, the distribution of B in the central circular cross-section of the channel changes from a horizontal eccentricity to a vertical one. Through the analysis of the B contour in the longitudinal section of the channel, the difference in effective magnetic flux density area (ΔA_B) between the upper and lower parts of the channel can be obtained, thereby quantitatively analyzing the distribution of B in this section. The distribution pattern of ΔA_B is consistent with the distribution pattern of the electromagnetic force in the vertical direction (F_Z) of the channel centerline. The ΔA_B and F_Z of channel 1 gradually increase as the heater rotates downwards, while those of channel 2 reach their maximum value at a rotation angle of 60°. Compared to the conventional placement, when the heater rotation angle is 60°, the outlet flow velocities at channel 1 and channel 2 decrease by 15% and 12%, respectively. However, the outlet temperature at channel 2 increases by 1.96 K, and the molten steel flow at the outlet of channel 1 and channel 2 no longer exhibits significant downward flow. This shows that when the heater rotation angle is 60°, it has a dual advantage. On the one hand, it is helpful to reduce the erosion of the molten steel on the channel and the bottom of the discharging chamber, and on the other hand, it can more effectively exert the heating effect of the induction heater on the molten steel in the channel. This presents a new approach to enhance the application effectiveness of IH tundish. Full article
