The main task of the research involves creating a Digital Twin (DT) application serving as a framework for Virtual Commissioning (VC) with Supervisory Control and Data Acquisition (SCADA) and Cloud storage solutions. An Internet of Things (IoT) integrated automation system with Virtual Private Network (VPN) remote control for assembly and disassembly robotic cell (A/DRC) equipped with a six-Degree of Freedom (6-DOF) ABB 120 industrial robotic manipulator (IRM) is presented in this paper. A three-dimensional (3D) virtual model is developed using Siemens NX Mechatronics Concept Designer (MCD), while the Programmable Logic Controller (PLC) is programmed in the Siemens Totally Integrated Automation (TIA) Portal. A Hardware-in-the-Loop (HIL) simulation strategy is primarily used. This concept is implemented and executed as part of a VC approach, where the designed PLC programs are integrated and tested against the physical controller. Closed loop control and RM inverse kinematics model are validated and tested in PLC, following HIL strategy by integrating Industry 4.0/5.0 concepts. A SCADA application is also deployed, serving as a DT operator panel for process monitoring and simulation. Cloud data collection, analysis, supervising, and synchronizing DT tasks are also integrated and explored. Additionally, it provides communication interfaces via PROFINET IO to SCADA and Human Machine Interface (HMI), and through Open Platform Communication—Unified Architecture (OPC-UA) for Siemens NX-MCD with DT virtual model. Virtual A/DRC simulations are performed using the Synchronized Timed Petri Nets (STPN) model for control strategy validation based on task planning integration and synchronization with other IoT devices. The objective is to obtain a clear and understandable representation layout of the A/DRC and to validate the DT model by comparing process dynamics and robot motion kinematics between physical and virtual replicas. Thus, following the results of the current research work, integrating digital technologies in manufacturing, like VC, IoT, and Cloud, is useful for validating and optimizing manufacturing processes, error detection, and reducing the risks before the actual physical system is built or deployed. Full article

Wind turbine fault diagnostics is essential for enhancing turbine performance and lowering maintenance expenses. Supervisory control and data acquisition (SCADA) systems have been extensively recognized as a feasible technology for the realization of wind turbine fault diagnosis tasks due to their capacity to generate vast volumes of operation data. However, wind turbines generally operate normally, and fault data are rare or even impossible to collect. This makes the SCADA data distribution imbalanced, with significantly more normal data than abnormal data, resulting in a decrease in the performance of existing fault diagnosis techniques. This article presents an innovative deep learning-based fault diagnosis method to solve the SCADA data imbalance issue. First, a data generation module centered on generative adversarial networks is designed to create a balanced dataset. Specifically, the long short-term memory network that can handle time series data well is used in the generator network to learn the temporal correlations from SCADA data and thus generate samples with temporal dependencies. Meanwhile, the convolutional neural network (CNN), which has powerful feature learning and representation capabilities, is employed in the discriminator network to automatically capture data features and achieve sample authenticity discrimination. Then, another CNN is trained to perform fault classification using the augmented balanced dataset. The proposed approach is verified utilizing actual SCADA data derived from a wind farm. The comparative experiments show the presented approach is effective in diagnosing wind turbine faults. Full article

In supervisory control tasks, particularly in high-risk fields, operators need to collaborate with automated intelligent agents to manage dynamic, time-sensitive, and uncertain information. Effective human–agent collaboration relies on transparent interface communication to align with the operator’s cognition and enhance trust. This paper proposes a human-centered adaptive transparency information design framework (ATDF), which dynamically adjusts the display of transparency information based on the operator’s needs and the task type. This ensures that information is accurately conveyed at critical moments, thereby enhancing trust, task performance, and interface usability. Additionally, the paper introduces a novel user research method, Heu–Kano, to explore the prioritization of transparency needs and presents a model based on eye-tracking and machine learning to identify different types of human–agent interactions. This research provides new insights into human-centered explainability in supervisory control tasks. Full article

The rapidly increasing installed capacity of Wind Turbines (WTs) worldwide emphasizes the need for Operation and Maintenance (O&M) strategies favoring high availability, reliability, and cost-effective operation. Optimal decision-making and planning are supported by WT health condition analyses based on data from the Supervisory Control and Data Acquisition (SCADA) system. However, SCADA data are highly imbalanced, with a predominance of healthy condition samples. Although this imbalance can negatively impact analyses such as detection, Condition Monitoring (CM), diagnosis, and prognosis, it is often overlooked in the literature. This review specifically addresses the problem of SCADA data imbalance, focusing on strategies to mitigate this condition. Five categories of such strategies were identified: Normal Behavior Models (NBMs), data-level strategies, algorithm-level strategies, cost-sensitive learning, and data augmentation techniques. This review evidenced that the choice among these strategies is mainly dictated by the availability of data and the intended analysis. Moreover, algorithm-level strategies are predominant in analyzing SCADA data because these strategies do not require the costly and time-consuming task of data labeling. An extensive public SCADA database could ease the problem of abnormal data scarcity and help handle the problem of data imbalance. However, long-dated requests to create such a database are still unaddressed. Full article

The optimization of the efficiency of wind turbine systems is a fundamental task, from the perspective of a growing share of electricity produced from wind. Despite this, and given the complex multivariate dependence of the power of wind turbines on environmental conditions and working parameters, the literature is lacking studies specifically devoted to a careful characterization of wind farm performance. In particular, in the literature, it is overlooked that there are several types of faults which have similar manifestations and that can be defined as static errors. This kind of error manifests as a static bias occurring from a certain time onward, which can affect the anemometer, the absolute or relative pitch of the blades, or the yaw system. Static or systematic errors typically do not cause the functional failure of the wind turbine system, but they deserve attention due to the fact that they cause power production loss throughout the operation time. Based on this, the first objective of the present study is a critical review of the recent papers devoted to three types of wind turbine static errors: anemometer bias, static yaw error, and pitch misalignment. As a result, a comprehensive viewpoint, enhancing the state of the art in the literature, is developed in this study. Given that the use of data collected by Supervisory Control And Data Acquisition (SCADA) systems has, up to now, been prevailing for the diagnosis of systematic errors compared to the use of further specific sensors, particular attention in the present study is thus devoted to the discussion of the phenomena which can be observable through SCADA data analysis. Based on this, finally, a rigorous work flow is formulated for detecting static errors and discriminating among them through SCADA data analysis. Nevertheless, methods based on additional information sources (like further sensors or meteorological data) are also discussed. An important aspect of this study is that, for each considered type of systematic error, some previously unpublished results based on real-world SCADA data are reported in order to corroborate the proposed framework. Summarizing, then, the present is the first paper which considers and discusses several types of wind turbine static errors in a unified viewpoint, correctly interprets apparently controversial results collected in the literature, and finally provides guidelines for the diagnosis of this kind of error and for the quantification of the performance drop associated with their presence. Full article

This study presents a methodology for the development of modern Supervisory Control and Data Acquisition (SCADA) systems aimed at improving the operation and management of concentrated solar power (CSP) plants, leveraging the tools provided by industrial digitization. This approach is exemplified by its application to the CESA-I central tower heliostat field at the Plataforma Solar de Almería (PSA), one of the oldest CSP facilities in the world. The goal was to upgrade the control and monitoring capabilities of the heliostat field by integrating modern technologies such as OPC (Open Platform Communications)) Unified Architecture (UA), a Wi-Fi mesh communication network, and a custom Python-based gateway for interfacing with legacy MODBUS systems. Performance tests demonstrated stable, scalable communication, efficient real-time control, and seamless integration of new developments (smart heliostat) into the existing infrastructure. The SCADA system also introduced a user-friendly Python-based interface developed with PySide6, significantly enhancing operational efficiency and reducing task complexity for system operators. The results show that this low-cost methodology based on open-source software provides a flexible and robust SCADA architecture, suitable for future CSP applications, with potential for further optimization through the incorporation of artificial intelligence (AI) and machine learning. Full article

Trust is a crucial human factor in automated supervisory control tasks. To attain appropriate reliance, the operator’s trust should be calibrated to reflect the system’s capabilities. This study utilized eye-tracking technology to explore novel approaches, given the intrusive, subjective, and sporadic characteristics of existing trust measurement methods. A real-world scenario of alarm state discrimination was simulated and used to collect eye-tracking data, real-time interaction data, system log data, and subjective trust scale values. In the data processing phase, a dynamic prediction model was hypothesized and verified to deduce and complete the absent scale data in the time series. Ultimately, through eye tracking, a discriminative regression model for trust calibration was developed using a two-layer Random Forest approach, showing effective performance. The findings indicate that this method may evaluate the trust calibration state of operators in human–agent collaborative teams within real-world settings, offering a novel approach to measuring trust calibration. Eye-tracking features, including saccade duration, fixation duration, and the saccade–fixation ratio, significantly impact the assessment of trust calibration status. Full article

The monitoring and control of an assembly/disassembly/replacement (A/D/R) multifunctional robotic cell (MRC) with the ABB 120 Industrial Robotic Manipulator (IRM), based on IoT (Internet of Things)-cloud, VPN (Virtual Private Network), and digital twin (DT) technology, are presented in this paper. The approach integrates modern principles of smart manufacturing as outlined in Industry/Education 4.0 (automation, data exchange, smart systems, machine learning, and predictive maintenance) and Industry/Education 5.0 (human–robot collaboration, customization, robustness, and sustainability). Artificial intelligence (AI), based on machine learning (ML), enhances system flexibility, productivity, and user-centered collaboration. Several IoT edge devices are engaged, connected to local networks, LAN-Profinet, and LAN-Ethernet and to the Internet via WAN-Ethernet and OPC-UA, for remote and local processing and data acquisition. The system is connected to the Internet via Wireless Area Network (WAN) and allows remote control via the cloud and VPN. IoT dashboards, as human–machine interfaces (HMIs), SCADA (Supervisory Control and Data Acquisition), and OPC-UA (Open Platform Communication-Unified Architecture), facilitate remote monitoring and control of the MRC, as well as the planning and management of A/D/R tasks. The assignment, planning, and execution of A/D/R tasks were carried out using an augmented reality (AR) tool. Synchronized timed Petri nets (STPN) were used as a digital twin akin to a virtual reality (VR) representation of A/D/R MRC operations. This integration of advanced technology into a laboratory mechatronic system, where the devices are organized in a decentralized, multilevel architecture, creates a smart, flexible, and scalable environment that caters to both industrial applications and educational frameworks. Full article

It is widely recognized that airspace capacity must increase over the coming years. It is also commonly accepted that meeting this challenge while balancing concerns around safety, efficiency, and workforce issues will drive greater reliance on automation. However, if automation is not properly developed and deployed, it represents something of a double-edged sword, and has been linked to several human–machine system performance issues. In this article, we argue that human–automation function and task allocation may not be the way forward, as it invokes serialized interactions that ultimately push the human into a problematic supervisory role. In contrast, we propose a flight-based allocation strategy in which a human controller and digital colleague each have full control authority over different flights in the airspace, thereby creating a parallel system. In an exploratory human-in-the-loop simulation exercise involving six operational en route controllers, it was found that the proposed system was considered acceptable after the users gained experience with it during simulation trials. However, almost all controllers did not follow the initial flight allocations, suggesting that allocation schemes need to remain flexible and/or be based on criteria capturing interactions between flights. In addition, the limited capability of and feedback from the automation contributed to this result. To advance this concept, future work should focus on substantiating flight-centric complexity in driving flight allocation schemes, increasing automation capabilities, and facilitating common ground between humans and automation. Full article

The increasing importance of hydropower generation has led to the development of new smart technologies and the need for reliable and efficient equipment in this field. As long as hydropower plants are more complex to build up than other power plants, the operation regimes and maintenance activities become essential for the hydropower companies to optimize their performance, such that including the data-driven approaches in the decision-making process represents a challenge. In this paper, a comprehensive and multi-task framework integrated into a Knowledge Discovery module based on Data Mining to support the decisions of the operators from the control rooms and facilitate the transition from the classical to smart Supervisory Control and Data Acquisition (SCADA) system in hydropower plants has been designed, developed, and tested. It integrates tasks related to detecting the outliers through advanced statistical procedures, identifying the operating regimes through the patterns associated with typical operating profiles, and developing strategies for loading the generation units that consider the number of operating hours and minimize the water amount used to satisfy the power required by the system. The proposed framework has been tested using the SCADA system’s database of a hydropower plant belonging to the Romanian HydroPower Company. The framework can offer the operators from the control room comparative information for a time horizon longer than one year. The tests demonstrated the utility of a Knowledge Discovery module to ensure the transition toward smart SCADA systems that will help the decision-makers improve the management of the hydropower plants. Full article

Considering Industry 4.0 directions, followed by recent Industry 5.0 principles, interest in integrating legacy systems in industrial manufacturing has emerged. Due to the continuous evolution of the Internet of Things (IoT) and the Industrial Internet of Things (IIoT), as well as the rapid extension of the scope and adoption of broader technologies, such integration has become feasible. Even though newly developed equipment provides easier interoperability, the replacement of legacy systems highly impacts cost and sustainability, which usually extends to the entire production process, the operators and the maintenance team, and sometimes even the robustness of the production process. Ensuring the interoperability of legacy systems is a problematic task, being dependent on technologies and development techniques and specific industrial domain particularities. This paper considers strategies to ensure the interoperability of legacy systems in a building-management system scenario where local structures are approached using both industrial protocols and web-based contexts. The solution is built following the Industry 5.0 pillars (sustainability, human focus, resilience) and conceives the entire data acquisition and supervisory solution to be flexible, open-source, resilient, and under the control of company engineers. The chosen environment for interfacing and supervision is Node-RED, enabling IoT and IIoT tools, together with a complete orientation toward digital transformation. This way, it is possible to construct a final result that enhances security while bridging outdated protocols and technologies, eliminating compatibility risks in the context of the evolutionary IIoT, ensuring critical process functions are possible, and aiding operators in complying with regulations governing building-management system (BMS) operations, thus solving the challenges that arise in the complex task of adopting the IoT backbone of digital transformation in relation to the integration of legacy equipment. The obtained solution is tested in an automotive industry building-management system, and the results demonstrate its performance, reliability, and high customizability in a context of openness and low cost. Full article

This paper introduces a novel hybrid filtering algorithm that leverages the advantages of Phasor Measurement Units (PMU) to address state estimation challenges in power systems. The primary objective is to integrate the benefits of PMU measurements into the design of traditional power system dynamic estimators. It is noteworthy that PMUs and Supervisory Control and Data Acquisition (SCADA) systems typically operate at different sampling rates in power system estimation, necessitating synchronization during the filtering process. To address this issue, the paper employs a predictive interpolation method for SCADA measurements within the framework of the Extended Kalman Filter (EKF) algorithm. This approach achieves more accurate estimates, closer to real observation data, by averaging the KL distribution. The algorithm is particularly well-suited for state estimation tasks in power systems that combine traditional and PMU measurements. Extensive simulations were conducted on the IEEE-14 and IEEE-30 test systems, and the results demonstrate that the fused estimator outperforms individual estimators in terms of estimation accuracy. Full article

Large-scale photovoltaic (PV) electricity production plants rely on reliable operation and maintenance (O&M) systems, often operated by means of supervisory control and data acquisition (SCADA) platforms aimed at limiting, as much as possible, the intrinsic volatility of this energy resource. The current trend is to develop SCADAs that achieve the finest possible control of the system components to efficiently and effectively cope with possible energy delivery problems. In this study, we investigated an innovative design of an IoT-based SCADA specifically tailored for large PV systems in which data transmission overheads are reduced by adopting lightweight protocols, and reliable data storage is achieved by means of hybrid solutions that allow the storage of historical data, enabling accurate performance analysis and predictive maintenance protocols. The proposed solution relies on an architecture where independent functional microservices handle specific tasks, ensuring scalability and fault tolerance. The technical approaches for IoT-SCADA connectivity are herein described in detail, comparing different possible technical choices. The proposed IoT-based SCADA is based on edge computing for latency reduction and to enhance real-time decision making, enabling scalability, and centralized management while leveraging cloud services. The resulting hybrid solutions that combine edge and cloud resources offer a balance between responsiveness and scalability. Finally, in the study, a blockchain solution was taken into account to certify energy data, ensuring traceability, security, and reliability in commercial transactions. Full article

With increasing automation in the rail sector, the train driver’s task changes from full control to a supervisory position. This bears the risk of monotony and subsequent changes in visual attention, possibly for the worse. Similar to concepts in car driving, one solution for this could be driver state monitoring with triggered interventions in case of declining task attention. Previous research on train drivers’ visual attention has used eye tracking. In contrast, head tracking is easier to realize within the train driver cabin. This study set out to test whether head tracking is a feasible alternative to eye tracking and can provide similar findings. Based on previous eye-tracking research, we compared differences in head movements in automated vs. manual driving, and for different levels of driving speed and driving experience. We conducted a study with 25 active train drivers in a high-fidelity train simulator. Statistical analyses revealed no significant difference in the vertical head movements between automation levels. There was a significant difference in the horizontal head movements, with train drivers looking more to the right for manual driving. We found no significant influence of driving speed and experience on head movements. Safety implications and the feasibility of head tracking as an alternative to eye tracking are discussed. Full article

This paper details the design and implementation of a virtualized bottle sealing plant using the Hardware in the Loop technique, for which it is divided into two parts: (i) Software consists of a virtualized environment in Unity 3D to visualize its behavior in real time; and (ii) Hardware was implemented through a PLC S7 1200 AC/DC/RLY (Programmable Logic Controller), which is responsible for the automation of the plant, programmed through the software TIA Portal V16 (Totally Integrated Automation Portal) and a control panel with buttons and indicator lights. The two developed parts communicate through bidirectional TCP/IP Ethernet, achieving a Server–Client architecture. For real-time monitoring and visualization, a SCADA (Supervisory Control and Data Acquisition) system implemented in InTouch is considered. In addition, the data acquisition is accomplished through the OPC (Open Platform Communication) server; the functionality of the OPC server is to transmit the information generated in an industrial plant at the enterprise level. This allows the process to execute its tasks of connectivity of automated processes and their supervision, as well as having scalability so that more tags can be included in other processes over time and ensure its operability. Full article
