Search Results (54)

Micro-crack defects on the surfaces of plate heat exchanger sheets often exhibit a linear grayscale pattern when clustered. In defect detection, traditional methods are more suitable than deep learning models in controlled production environments with limited computing resources to meet stringent national standards, which require low miss rates. However, deep learning models commonly suffer feature loss when detecting individual, small-scale defects, leading to higher leak detection rates. Moreover, in grayscale image line detection using traditional methods, the varying direction, width, and asymmetric grayscale profiles of defects can result in filled grayscale valleys due to width-adaptive smoothing coefficients, complicating accurate defect extraction. To address these issues, this study establishes a theoretical foundation for parameter selection in variable-width defect detection. We propose a directional gradient-based algorithm that mathematically constrains the Gaussian template width to cover variable-width defects with a fixed σ, reframing the detection defect from ridge edges to centrally symmetric double-ridge edges in gradient images. Experimental results show that, when tested in the defective boards library and under simulated factory CPU conditions, this algorithm achieves a miss detection rate of 14.55%, a false detection rate of 21.85%, and an 600 × 600 pixel image detection time of 0.1402 s. Compared to traditional line detection and deep learning object detection methods, this algorithm proves advantageous for detecting micro-crack defects on plate heat exchanger sheets in industrial production, particularly in data-scarce and resource-limited scenarios. Full article

In fog, rain, snow, haze, and other complex environments, environmental objects photographed by imaging equipment are prone to image blurring, contrast degradation, and other problems. The decline in image quality fails to satisfy the requirements of application scenarios such as video surveillance, satellite reconnaissance, and target tracking. Aiming at the shortcomings of the traditional dark channel prior algorithm in video defogging, this paper proposes a method to improve the guided filtering algorithm to refine the transmittance image and reduce the halo effect in the traditional algorithm. Meanwhile, a gamma correction method is proposed to recover the defogged image and enhance the image details in a low-light environment. The parallel symmetric pipeline design of the FPGA is used to improve the system’s overall stability. The improved dark channel prior algorithm is realized through the hardware–software co-design of ARM and the FPGA. Experiments show that this algorithm improves the Underwater Image Quality Measure (UIQM), Average Gradient (AG), and Information Entropy (IE) of the image, while the system is capable of stably processing video images with a resolution of 1280 × 720 @ 60 fps. By numerically analyzing the power consumption and resource usage at the board level, the power consumption on the FPGA is only 2.242 W, which puts the hardware circuit design in the category of low power consumption. Full article

During the last five years, spiking neural P (SN P) systems have attracted a lot of attention in the field of cryptography since these systems can more efficiently support advanced and complex cryptographic algorithms due to their high computational capabilities. Specifically, these systems can be seen as a potential solution to efficiently performing asymmetric algorithms, which are more demanding than symmetric systems. This factor becomes critical, especially in resource-constrained single-board computer systems, since many of these systems are currently used to ensure the security of IoT applications in portable systems. In this work, we present for the first time the implementation of an asymmetric encryption algorithm called ElGamal based on spiking neural P systems and their cutting-edge variants. The proposed design involves the encryption and decryption processes. Specifically, we propose the design of a neural network to efficiently perform the extended Euclidean algorithm used in the decryption task. Here, we exert major efforts to create a compact and high-performance circuit to perform the extended Euclidean algorithm since the calculation of this algorithm is the most demanding when the decryption process is required. Finally, we perform several tests to show the computational capabilities of our proposal in comparison to conventional implementations on single-board computer systems. Our results show that the proposed encryption/decryption scheme potentially allows its use to ensure confidentiality, data integrity, and secure authentication, among other applications for resource-constrained embedded systems. Full article

Near-field microwave microscopy (NSMM) is a promising technique for the non-destructive, high-resolution imaging of electrical and dielectric properties at the microscale. However, its performance is highly sensitive to the probe-to-sample distance, often requiring extremely close proximity, which limits its practical application in device manufacturing, especially in scenarios involving coatings and packaging. In this study, we propose a distance inversion method based on a dual-port symmetrical microwave probe to improve imaging performance at larger, safer scanning distances. This method utilizes the correlation between probe height and resonant frequency to compensate for distance-induced signal distortions. The experimental results demonstrate that even at a probe–sample distance of 80 µm, clear and distinguishable NSMM images of printed circuit boards (PCBs) can be obtained. The imaging resolution reached 13 µm. The defect structure with dimensions of 130 × 130 µm² on the PCB was successfully identified. The signal-to-noise ratio was significantly enhanced after applying the correction method. This approach not only improves the robustness and flexibility of NSMM in industrial scenarios but also extends its applicability to packaged or coated electronic devices, offering a valuable tool for advanced non-destructive testing. Full article

Road classification, knowing whether we are driving in the city, in rural areas, or on the highway, can improve the performance of modern driver assistance systems and contribute to understanding driving habits. This study focuses on solving this problem universally using only vehicle speed data. A data logging method has been developed to assign labels to the On-board Diagnostics data. Preprocessing methods have been introduced to solve different time steps and driving lengths. A state-of-the-art conventional method was implemented as a benchmark, achieving 89.9% accuracy on our dataset. Our proposed method is a neural network-based model with an accuracy of 93% and 1.8% Type I error. As the misclassifications are not symmetric in this problem, loss function weighting has been introduced. However, this technique reduced the accuracy, so cross-validation was used to use as much data as possible during the training. Combining the two approaches resulted in a model with an accuracy of 96.21% and unwanted Type I misclassifications below 1%. Full article

This article introduces a broadband sub-6 GHz 8 × 8 MIMO (multi-input multi-output) antenna array for 5G (fifth-generation) metal-frame mobile phone applications. The unique advantage of this compact antenna design is its placement in the corners of the mobile phone, allowing for significant PCB board space reduction. The proposed antenna’s 6 dB impedance bandwidth ranged from 3.3 to 6 GHz, covering the n77/78/79 and WiFi-5GHz bands. The main radiating element was an open-slot antenna coupled by a T-shaped structure connected to a 50-Ω transmission line. The size of the single-antenna element was 12.25 mm × 2.5 mm × 7 mm, and these antennas were symmetrical at four corners of the smartphone. A wide slot and neutral line were incorporated to reduce mutual coupling between adjacent antennas. The MIMO antenna array achieved isolation above 12 dB. The peak realized gain ranged from 2 to 5.28 dBi, and the total efficiency spanned 37% to 71%. The ECC (envelope correlation coefficient) was less than 0.34, and the CC (channel capacity) ranged from 33 and 41 bps/Hz. Full article

This paper presents a symmetric dual-band multiple-input multiple-output (MIMO) antenna system tailored for fifth-generation (5G) mobile terminals. Operating within the 5G frequency bands N77/N78 (3.4–3.6 GHz) and N79 (4.8–5.0 GHz), the proposed MIMO system achieves high isolation between adjacent antenna elements through slotting and self-decoupling technologies. Antenna elements are strategically positioned on two frames perpendicular to the smartphone’s main board. Each antenna element integrates a rectangular microstrip radiator on the inner frame surface, accompanied by a grounded rectangular ring on the outer frame surface. The feed line, situated atop the main board, connects to an external SMA connector located at the main board’s bottom. Measurement results reveal isolations exceeding 20 dB for the lower band and 24 dB for the higher band. The fabricated and tested MIMO antenna system demonstrates excellent agreement between simulation and measurement outcomes. Full article

Currently, power trains based on an Open-End Winding Induction Machine fed by a Dual Inverter (DI-OEWIM) are attracting a great deal of interest in various modern industrial applications. However, applying symmetrical control to this system (DI-OEWIM), which is symmetrical in nature, will lead to malfunction. Therefore, the objective of this paper is to explore the influence of asymmetric control on the performance of this system. The principle of this study is to create an asymmetrical control by integrating a phase-shift angle in the Space Vector Pulse Width Modulation (SVPWM) strategy. We then evaluate the impact of these angles on various performances, such as the Total Harmonic Distortion (THD), power losses, Common Mode Voltage (CMV), Zero-Sequence Voltage (ZSV), rotation speed and torque ripple of this system. This study was carried out in the Matlab/Simulink environment and was validated experimentally using the dSPACE 1104 board. The results show that the different angles have significant effects on the overall performance of this system. Full article

SiC MOSFETs are used in many power conversion applications because of their superior characteristics, such as fast switching speed, low on-resistance, and high operating temperature. In certain high-power systems, SiC MOSFETs are connected in parallel to enhance their current capacity and power efficiency. However, compared with Si-based devices, the current imbalance caused by the parasitic inductance difference becomes more severe when driving SiC MOSFETs in parallel, owing to the fast switching speed. Furthermore, the power loop inductance imbalance that occurs when constructing a half-bridge with parallel SiC MOSFETs has rarely been addressed in previous studies. In this study, a half-bridge switching power module based on parallel-connected SiC MOSFETs is proposed to solve the current imbalance through a symmetric structure of the gate and power loops. The effects of the magnitude and imbalance of the gate and power loop inductances in the half-bridge structure based on parallel-connected devices are also explained. A detailed printed circuit board layout of the proposed switching power module is provided, and the inductance symmetry is verified through simulations. A double-pulse test is conducted to verify the current-balancing capability of the proposed switching power module. In addition, an LLC resonant converter is designed using the proposed switching power module, and the power loss between parallel SiC MOSFETs is compared. The experimental results indicate the total power loss error between the parallel-connected SiC MOSFETs of the proposed power module is only 1.94%. Full article

In the paper, a novel design of a wideband power splitter for a four-element antenna array using two RF antiphase segments is proposed. Based on a detailed analysis of the power splitter circuit, an analytical model was set up in the MATLAB environment. The derived analytical model allows the development of a design of the described structure for any operating frequency and estimates the properties of the designed structure. In addition to the RF electrical part, the copper cover is also considered in this study. The copper cover serves as both a support and shielding part of the proposed structure. The electrical part consists of two sections of transmission lines. The first transmission line is symmetrical, while the second transmission line is asymmetrical. The given transmission lines can be realized using any technology (microstrip, coaxial, etc.). A prototype of the proposed wideband splitter operating at 650 MHz with a fractional bandwidth of 84.3% was designed and tested in real-world conditions to prove the concept. The board of the manufactured prototype has dimensions of 25 × 152 mm. A double-sided FR4 material with a substrate height of 1.48 mm, copper thickness of $50\mathsf{\mu }$m, and ${ϵ}_r$ ≅ 4.3, with a dielectric loss tangent of 0.021 was used to manufacture the prototype. The prototype was tested and its parameters were verified in practical conditions as a part of the current radio communication system for the 5G band. Under these conditions, verification measurements of the proposed splitter with a four-element antenna array were carried out. Full article

In this study, we utilized exposure time ($\overline{\theta }$) as a key metric to investigate water exchange and its spatiotemporal variations in the Northern South China Sea (NSCS). The Eulerian adjoint method and Lagrangian tracking were adopted to capture a comprehensive view of water exchange in coastal regions. Our findings reveal distinct spatial and seasonal variations in $\overline{\theta }$. Spatially, a long $\overline{\theta }$ (exceeding 150 days) appears in the coastal region, and the largest values occur in the Beibu Gulf (300 days). Temporally, $\overline{\theta }$ exhibits clear seasonal patterns across the extensive shelf area, influenced by the seasonal monsoon which induced seasonally reversing shelf current and results in symmetrical distribution patterns of $\overline{\theta }$ across the board shelf during both winter and summer months. $\overline{\theta }$ is longer in winter than in summer. The study also revealed pronounced vertical contrasts in cross-isobath transport over the NSCS shelf, though significant vertical variations in net exchange time were noted only in specific locations, including the northeast side of Hainan Island, the Beibu Gulf mouth, and along the west side of Taiwan Island. The Beibu Gulf emerged as a critical factor in the NSCS’s water exchange dynamics in both seasons. In summer, it impacts more than 20% of the water exchange over adjacent areas, particularly through its westward transport against typical northeastward shelf currents. This highlights the combined effect of the westward spread of the Pearl River freshwater and the stable slope current on regional hydrodynamics. In winter, the Gulf’s retention characteristics profoundly affected even distant areas, contributing to up to 50% of water exchange, showing its broad impact on the NSCS’s water dynamics throughout the year. Full article

Unbalanced loads are extremely prevalent in real systems, and they create power quality issues for the UPS system. To address this problem, this work provides an optimal voltage control scheme for a three-phase inverter using the linear matrix inequality method. In addition, the purpose of this controller is to provide a well-balanced three-phase sinusoidal voltage regardless of the imbalance of the loads. This symmetrical component-based controller features two paralleled voltage controls: a positive sequence to regulate output signals and a negative sequence to eliminate unbalanced voltages. Along with that, the optimization problem is formulated such that the convergence rate is maximized to obtain the output voltage as swiftly as possible. PSIM is used to carry out the simulation, and MATLAB is utilized to assist in determining the optimal control gain for the state feedback and integral control of each sequence. The control algorithm is then deployed utilizing an in-house designed control board together with a TMS320F28335 digital signal processor. To determine the efficacy of the proposed control, simulation, and experiment results are compared to those of an optimal controller without a negative sequence. Full article

This paper investigates the effect of a temperature shock on a small spacecraft with symmetrically arranged flexible elements. A two-dimensional thermoelasticity problem is posed. The disturbing effect of temperature shock on a small spacecraft has been determined. The assessment of the main disturbing factors arising from the temperature shock of flexible elements of a small spacecraft was carried out. Approximate dependences were obtained for the components of the displacement vector of the flexible element points. Numerical simulation was carried out for the symmetric scheme of the small spacecraft with two and four flexible elements. The dependence of the inertia force on temperature shock for the simulated small spacecraft at various initial deflections of the flexible element was constructed. Conclusions were drawn about the significance of the temperature shock influence on the dynamics of a small spacecraft. The results obtained were compared with the results of other studies and can be used in solving problems of remote sensing of the Earth and the implementation of gravity-sensitive processes on board small spacecraft. Full article

Vehicular ad hoc network (VANET) communications face severe fading problems due to the signal reflections and diffractions within tunnels. Unlike the open road, the space of a tunnel is very limited, so VANET communication performance in a tunnel is seriously affected. In the process of signal transmission, the reflected signal is symmetrical with the incident signal after it is reflected by the road and the wall. In this paper, we establish a mathematical model of path loss for V2V (Vehicle-to-Vehicle) communication based on the principle of signal reflection symmetry in tunnels and considering several factors, such as the tunnel surface and the color of the tunnel wall. In addition, we use cooperative communication to form a virtual multiple-input multiple-output (V-MIMO) system, to improve the communication quality in tunnels. In the proposed system, the OBU (On-Board-unit) and RSU (Road-Side-Unit) share each other’s antennas, so that wireless cooperative communication can be employed, without increasing the number of antennas in a one-way tunnel. Therefore, this multipath fading internal electromagnetic wave propagation model can be used to improve performance. A deep reinforcement learning algorithm was used to solve the pairing problem to obtain a more accurate OBU and RSU pair, to form a V-MIMO system. Here, the RSU is regarded as an agent and interacts with the OBU in the tunnel. The optimal strategy was learned in a real-time changing simulation environment, and the experiment verified the convergence of the algorithm. The simulation results showed that, compared with the Q-learning based scheme, the optimal matching algorithm based on V-MIMO and a DQN (Deep Q-network) could effectively reduce the probability of transmission outages and improve the communication efficiency in tunnels. Full article

Nuclear fusion experiments are becoming one of the most interesting focuses of research, given the hope of generating programmable, safe, and green energy. Among them, ASDEX (axially symmetric divertor experiment) upgrade has been operating at the Max Planck Institute for Plasma Physics (IPP) research center since 1991. To ignite and confine the plasma, several coils must be supplied through controllable high-current pulsed power supplies. The toroidal field magnets are here considered and a modular multilevel converter (MMC)-like system was designed and tested thanks to a small-scale prototype in previous works. The MMC-like topology, consisting of full-bridge submodules (SMs) with IGBTs and supercapacitor and exploitable also for other industrial applications, was chosen because of its modularity, redundancy, fault tolerance, and large amount of stored energy. The prototype, made of four SMs, was necessary to highlight critical key points in the design process. However, its scalability must be further tested before building a full-scale power supply, meant to reach almost 2400 SMs to guarantee the energy required by the load. This paper aims at validating hardware-in-the-loop (a powerful, safe, and relatively inexpensive real-time simulation environment that enables testing with real control boards) as a useful technology for power supply scalability studies and not only for control strategy tests. The results obtained previously from the prototype will allow us to finally increase the number of SMs and test the MMC-like scalability. Full article
