This study investigates a multi-scenario combustion state diagnosis system based on acoustic feature extraction techniques. In this study, the voiceprint technology is applied to combustion condition monitoring for the first time, and an integrated approach for monitoring and diagnosis is proposed by combining multiple acoustic features, such as acoustic pattern features, step index P, and frequency-domain monitoring. In this study, a premixed hydrogen combustion test bed was built to simulate common combustion faults, and the corresponding acoustic features were collected and extracted. In this study, step index P and acoustic features are used for parallel diagnostic analysis, and CNN, ANN, and BP models are used to train the four states of flameout, flameback, thermoacoustic oscillation, and stable combustion, and the training diagnostic performance of each model is compared and analyzed using a confusion matrix. It is found that CNN has the strongest classification ability, can accurately distinguish the four states, has the lowest misclassification rate, has very strong generalization ability, and has a diagnostic accuracy of 93.49%. The classification accuracy of ANN is not as good as that of CNN, and there are local fluctuations during the training process. The BP neural network has a slower convergence speed and a high error rate in recognizing the flameback and thermoacoustic oscillations. In summary, the combustion state diagnosis system based on CNN model combined with acoustic features has optimal performance, and the combination of step index P and frequency-domain monitoring in the flameback diagnosis can improve the accuracy of combustion state identification and safety control level, which provides an important theoretical basis and practical reference in the field of combustion state diagnosis and is of profound significance to ensure the safe and efficient operation of the combustion process. Full article

The transition to low-carbon energy systems has heightened interest in hydrogen and ammonia as sustainable alternatives to traditional hydrocarbon fuels. However, the development and operation of combustors utilizing these fuels, like other combustion systems, are challenged by thermoacoustic instabilities arising from the interaction between unsteady heat release and acoustic wave oscillations. Among many different methods for studying thermoacoustic instabilities, thermoacoustic network models have played an important role in analyzing the essential dynamics of these instabilities in combustors operating with low-carbon fuels. This paper provides a comprehensive review of thermoacoustic network modeling techniques, focusing specifically on their application to hydrogen- and ammonia-based combustion systems. We outline the key mathematical frameworks derived from fundamental equations of motion, along with experimental validations and practical applications documented in existing studies. Furthermore, current research gaps are identified, and future directions are proposed to improve the reliability and effectiveness of thermoacoustic network models, contributing to the advancement of efficient and stable low-carbon combustors. Full article

This paper investigates the role of chaotic analysis and deep learning models in combustion instability predictions. To detect the precursors of impending thermoacoustic instability (TAI) in a swirled combustor with various fuel injection strategies, a data-driven framework is proposed in this study. Based on chaotic analysis, a recurrence matrix derived from combustion system is used in deep learning models, which are able to detect precursors of TAI. More specifically, the ResNet-18 network model is trained to predict the proximity of unstable operation conditions when the combustion system is still stable. The proposed framework achieved state-of-the-art 91.06% accuracy in prediction performance. The framework has potential for practical applications to avoid an unstable operation domain in active combustion control systems and, thus, can offer on-line information on the margin of the combustion instability. Full article

When aiming to cut down on the emission of nitric oxides by gas turbine engines, it is advantageous to have them operate at low combustion temperatures. This is achieved by lean premixed combustion. Although lean premixed combustion is a proven and promising technology, it is also very sensitive to thermoacoustic instabilities. These instabilities occur due to a coupling between the unsteady heat release rate of the flame and the acoustic field inside the combustion chamber. In this paper, this coupling is investigated in detail. Two acoustic design parameters of a swirl-stabilized pressurized preheated air (300 °C)/natural gas combustor are varied, and the occurrence of thermoacoustic limit cycle oscillations is explored. The sensitivity of the acoustic field as a function of combustion chamber length (0.9 m to 1.8 m) and reflection coefficient (0.7 and 0.9) at the exit of the combustor is investigated first using a hybrid numerical and analytical approach. ANSYS CFX is used for Unsteady Reynolds Averaged Navier-Stokes (URANS) numerical simulations, and a one-dimensional acoustic network model is used for the analytical investigation. Subsequently, the effects of a change in the reflection coefficient are validated on a pressurized combustor test rig at 125 kW and 1.5 bar. With the change in reflection coefficient, the combustor switched to limit cycle oscillation as predicted, and reached a sound pressure level of 150 dB. Full article

In combustor systems, thermoacoustic instabilities may occur and must be avoided for reliable operation. An acoustic network model can be used to predict the eigenfrequencies of the instabilities and the growth rate by incorporating the combustion dynamics with a flame transfer function (FTF). The FTF defines the interconnection between burner aerodynamics and the rate of combustion. In the current study, the method to measure the FTF in a pressurized combustor is explored. A siren unit, mounted in the fuel line, induced a fuel flow excitation of variable amplitude and high maximum frequency. This was performed here for pressurized conditions at 1.5 bar and 3 bar and at a thermal power of 125 kW and 250 kW. In addition to the experimental investigation, a 1-D acoustic network model approach is used. In the model, thermoviscous damping effects and reflection coefficients are incorporated. The model results compare well with experimental data, indicating that the proposed method to determine the FTF is reliable. In the approach, a combination of an FTF with a band stop approach and a network modeling approach was applied. The method provides a good match between experimentally observed behavior and an analytical approach and can be used for instability analysis. Full article

Waste heat recovery stands out as a promising technique for tackling both energy shortages and environmental pollution. Currently, this valuable resource, generated through processes like fuel combustion or chemical reactions, is often dissipated into the environment, despite its potential to significantly contribute to the economy. To harness this untapped potential, a traveling-wave thermo-acoustic generator has been designed and subjected to comprehensive experimental analysis. Fifty-two data corresponding to different working conditions of the system were extracted to build ANN, ANFIS, and ANN-PSO models. Evaluation of performance metrics reveals that the ANN-PSO model demonstrates the highest predictive accuracy ($R^2=0.9959$), particularly in relation to output voltage. This research demonstrates the potential of machine learning techniques for the analysis of thermo-acoustic systems. In doing so, it is possible to obtain an insight into nonlinearities inherent to thermo-acoustic systems. This advancement empowers researchers to forecast the performance characteristics of alternative configurations with a heightened level of precision. Full article

Thermoacoustic instabilities in gasturbine combustor systems can be predicted in the design phase with a thermoacoustic network model. In this model, the coupling between acoustic pressure fluctuations and the combustion rate is described by the Flame Transfer Function. The present paper introduces a new, efficient, and robust method for deriving the FTF from CFD predictions by means of a discrete multi-frequency sinusoidal fuel flow excitation method. The CFD-based FTF result compares well with experimental data for the time delay, but for the gain, only up to 400 Hz. Above 400 Hz, the CFD result reveals a smooth low-amplitude gain, which is not found in the measured data. A novel, accurate continuous correlation function for the FTF gain is computed based on the results for discrete frequencies. When this is implemented into a 1D acoustic network model, the stability map shows, below 600 Hz, two eigenfrequencies, by both the experiment and CFD-based FTF, that are identical. The CFD-based FTF correctly predicts marginal activity at the highest eigenfrequency, while the experimentally based FTF suggests an unstable operation. The unstable operation is not observed in the experiments. This suggests that the CFD-based FTF is also correct for high frequencies. Full article

Thermoacoustic refrigerators are emerging devices that make use of meaningful high-pressure sound waves to induce cooling. Despite the accelerated progress in the field of thermoacoustics, knowledge of the heat transfer process in the heat exchange of the devices is still developing. This work applies different soft computing techniques, namely, an artificial neural network trained by particle swarm optimisation (ANN-PSO), adaptive neuro-fuzzy inference system (ANFIS), and artificial neural networks (ANNs) to predict the oscillatory heat transfer coefficient in the heat exchangers of a thermoacoustic device. This study provides the details of the parametric analysis of an artificial neural network model trained by particle swarm optimisation. The solution model considers the number of neurons, the swarm population, and the acceleration factors to develop and analyse the architecture of several models. The regression model (R²) and mean squared error (MSE) were used to evaluate the accuracy of the models. The result showed that the proposed soft computing techniques can potentially be used for the modelling and the analysis of the oscillatory heat transfer coefficient with a higher level of accuracy. The result reported in this study implies that the prediction of the OHTC can be considered for the enhancement of thermoacoustic refrigerators performances. Full article

This paper presents a nonparametric regression model of categorical time series in the setting of conditional tensor factorization and Bayes network. The underlying algorithms are developed to provide a flexible and parsimonious representation for fusion of correlated information from heterogeneous sources, which can be used to improve the performance of prediction tasks and infer the causal relationship between key variables. The proposed method is first illustrated by numerical simulation and then validated with two real-world datasets: (1) experimental data, collected from a swirl-stabilized lean-premixed laboratory-scale combustor, for detection of thermoacoustic instabilities and (2) publicly available economics data for causal inference-making. Full article

In therapeutic ultrasound applications, accurate ultrasound output intensities are crucial because the physiological effects of therapeutic ultrasound are very sensitive to the intensity and duration of these applications. Although radiation force balance is a benchmark technique for measuring ultrasound intensity and power, it is costly, difficult to operate, and compromised by noise vibration. To overcome these limitations, the development of a low-cost, easy to operate, and vibration-resistant alternative device is necessary for rapid ultrasound intensity measurement. Therefore, we proposed and validated a novel two-layer thermoacoustic sensor using an artificial neural network technique to accurately measure low ultrasound intensities between 30 and 120 mW/cm². The first layer of the sensor design is a cylindrical absorber made of plexiglass, followed by a second layer composed of polyurethane rubber with a high attenuation coefficient to absorb extra ultrasound energy. The sensor determined ultrasound intensities according to a temperature elevation induced by heat converted from incident acoustic energy. Compared with our previous one-layer sensor design, the new two-layer sensor enhanced the ultrasound absorption efficiency to provide more rapid and reliable measurements. Using a three-dimensional model in the K-wave toolbox, our simulation of the ultrasound propagation process demonstrated that the two-layer design is more efficient than the single layer design. We also integrated an artificial neural network algorithm to compensate for the large measurement offset. After obtaining multiple parameters of the sensor characteristics through calibration, the artificial neural network is built to correct temperature drifts and increase the reliability of our thermoacoustic measurements through iterative training about ten seconds. The performance of the artificial neural network method was validated through a series of experiments. Compared to our previous design, the new design reduced sensing time from 20 s to 12 s, and the sensor’s average error from 3.97 mW/cm² to 1.31 mW/cm² respectively. Full article
