Underground metal mines operated using the natural caving method often result in significant surface collapses. Key parameters such as settlement magnitude, settlement rate, settlement extent, and the influence of underground mining on surface deformation warrant serious attention. However, due to the long operational timespan of mines and incomplete data from early collapse events, coupled with the inaccessibility of collapse zones for field measurements, it is challenging to obtain accurate displacement data, thereby posing significant difficulties for follow-up research. This study employs small baseline subset InSAR (SBAS-InSAR) technology to retrieve time series data on early-stage surface displacement and deformation rates in collapse areas, thereby compensating for the lack of historical data and eliminating the safety risks associated with on-site measurements. The 5th percentile of settlement rates across all monitoring points is used to define the severe settlement threshold, determined to be −42.1 mm/year. Continuous wavelet transform (CWT) is applied to calculate the time-series power spectrum, allowing the analysis of long-term stable and periodic settlement patterns in the collapse area. The instantaneous change rate at each point in the study area is identified. Using the 97th percentile of change rates in the time series, the number of severe change events at each point is determined. High-incidence zones of sudden surface deformation are visualized through QGIS 3.16 heat map clustering. The high-risk collapse area, identified by integrating both long-term stable settlement and sudden surface deformation patterns, accounts for multiple deformation modes. This provides robust technical support for the management of mine collapse zones and offers important theoretical guidance. Full article

Geological hazard risk assessment provides essential scientific support for geological disaster prevention and governance. The selection of appropriate evaluation factors is crucial to the accuracy and practicality of the risk assessment results. The existing factors for geological hazard risk assessment often suffer from issues such as poor timeliness and insufficient completeness. Interferometric Synthetic Aperture Radar (InSAR) technology, which offers large-scale, high spatiotemporal resolution monitoring of surface deformation, can effectively compensate for the shortcomings of existing risk assessment factors. How to effectively integrate time-series InSAR deformation results into geological hazard risk assessment has become a focus of research. This study fully considers the time-series InSAR deformation information; both the ascending and descending orbit results of the time-series InSAR deformation are introduced as two categories of evaluation factors in the risk assessment model. Subsequently, 11 types of assessment factors are selected by the Pearson correlation coefficient method, while the Information Volume Model and Evidence Weight Model are applied in the partitioning and assessment of risks in Xiaojin County, China. Finally, ROC (Receiver Operating Characteristic Curve) analysis is utilized to compare the accuracy of model evaluations before and after incorporating time-series InSAR deformation results. The results indicate that: (1) after incorporating time-series InSAR deformation monitoring results as evaluation factors into the information volume model and evidence weight model, the evaluation accuracy of the two models improved by 9.69% and 11.26%, respectively; (2) there are differences in risk partitioning among different evaluation models. From the risk partitioning result of Xiaojin County in this study, the evaluation accuracy of the information volume model is higher than that of the evidence weight model, and the performance is more prominent after adding the time-series InSAR deformation results. Full article

Edgecumbe, a dormant volcano located on Kruzof Island in the southeastern part of Alaska, USA, west of the Sitka Strait, has exhibited increased volcanic activity since 2018. To assess the historical and current intensity of this activity and explore its relationship with seismic events in the surrounding region, this study utilized data from the ERS-1/2, ALOS-1, and Sentinel-1 satellites. The Permanent Scatterer Interferometric Synthetic Aperture Radar (PS-InSAR) and Small Baseline Subset InSAR (SBAS-InSAR) techniques were employed to obtain surface deformation data spanning nearly 30 years. Based on the acquired deformation field, the point-source Mogi model was applied to invert the position and temporal volume changes in the volcanic source. Then, by integrating seismic activity data from the surrounding area, the correlation between volcanic activity and earthquake occurrences was analyzed. The results indicate the following: (1) the coherence of interferograms is influenced by seasonal variations, with snow accumulation during the winter months negatively impacting interferometric coherence. (2) Between 1992 and 2000, the surface of the volcano remained relatively stable. From 2007 to 2010, the frequency of seismic events increased, leading to significant surface deformation, with the maximum Line-of-Sight (LOS) deformation rate during this period reaching −26 mm/yr. Between 2015 and 2023, the volcano entered a phase of accelerated uplift, with surface deformation rates increasing to 68 mm/yr after August 2018. (3) The inversion results for the period from 2015 to 2023 show that the volcanic source, located at a depth of 5.4 km, experienced expansion in its magma chamber, with a volumetric increase of 57.8 × 10⁶ m³. These inversion results are consistent with surface deformation fields obtained from both ascending and descending orbits, with cumulative LOS displacement reaching approximately 210 mm and 250 mm in the ascending and descending tracks, respectively. (4) Long-term volcanic surface deformation, changes in magma source volume, and seismic activity suggest that the earthquakes occurring after 2018 have facilitated the expansion of the volcanic magma source and intensified surface deformation. The uplift rate around the volcano has significantly increased. Full article

Beijing’s royal gardens represent the highest artistry in the artificial modification and utilization of natural hill and lake landforms. They also encompass the most concentrated ancient Chinese royal architectural heritage complexes. Their sustainable development has drawn significant attention, particularly in detecting and identifying areas of land subsidence and analyzing its influencing factors, which are crucial for preserving Beijing’s royal architectural heritage. This study employed time-series interferometric synthetic aperture radar (InSAR) technology to collect 148 SAR datasets from 2019 to 2023. It compares the persistent scatterer (PS)–InSAR and small baseline subset (SBAS)–InSAR techniques for cross-validation analyses to systematically assess the spatial characteristics of land subsidence of the most valuable architectural heritage complexes in the four most representative Beijing’s royal gardens. The study identified several areas with concentrated subsidence. Further analysis of the types of ancient building locations reveals that buildings situated in hilly areas (Type C), waterside buildings (Type A1), and near-water buildings (Type A2) are more significantly affected by land subsidence. Through an analysis of the causes of subsidence, it was found that, affected by the “excavating lakes and piling hills” landscape modification method and the utilization of natural hilled terrain approach, the subsidence observed in most Type C architectural heritage complexes within the study area may be associated with the Holocene sediments in the underlying soils beneath the shallow foundations of architectural heritage, localized bedrock instability caused by exposure and weathering, and slope instability. Type A building complexes’ subsidence and localized uplift may be associated with Holocene sediments beneath their foundations. The cross-comparison between SBAS-InSAR and PS-InSAR provides a reference framework for exploring land deformation research in architectural heritage sites where detection methods are constrained. Full article

The dynamic loads of fluid impact and static loads, such as the gravity of a rock mass during the formation of debris flows, exhibit a coupled effect of mutual influence. Under this coupling effect, surface monitoring points in disaster areas experience displacement. However, existing methods do not consider the dynamic–static coupling effects of debris flows on the surface. Instead, they rely on GNSS or InSAR technology for dynamic or static single-scale monitoring, leading to high Mean Absolute Percentage Error (MAPE) values and low warning accuracy. To address these limitations and improve debris flow warning accuracy, a multi-scale warning method was proposed based on Global Navigation Satellite System (GNSS) and Synthetic Aperture Radar Interferometry (InSAR) technology. GNSS technology was utilized to correct coordinate errors at monitoring points, thereby enhancing the accuracy of monitoring data. Surface deformation images were generated using InSAR and Small Baseline Subset (SBAS) technology, with time series calculations applied to obtain multi-scale deformation data of the surface in debris flow disaster areas. A debris flow disaster morphology classification model was developed using a support vector mechanism. The actual types of debris flow disasters were employed as training labels. Digital Elevation Model (DEM) files were utilized to extract datasets, including plane curvature, profile curvature, slope, and elevation of the monitoring area, which were then input into the training model for classification training. The model outputted the classification results of the hidden danger areas of debris flow disasters. Finally, the dynamic and static coupling variables of surface deformation were decomposed into valley-type internal factors (rock mass static load) and slope-type triggering factors (fluid impact dynamic load) using the moving average method. Time series prediction models for the variable of the dynamic–static coupling effects on surface deformation were constructed using polynomial regression and particle swarm optimization (PSO)–support vector regression (SVR) algorithms, achieving multi-scale early warning of debris flows. The experimental results showed that the error between the predicted surface deformation results using this method and the actual values is less than 5 mm. The predicted MAPE value reached 6.622%, the RMSE value reached 8.462 mm, the overall warning accuracy reached 85.9%, and the warning time was under 30 ms, indicating that the proposed method delivered high warning accuracy and real-time warning. Full article

The Heifangtai Loess terrace in northwest China is frequently affected by landslides due to hydrological factors, establishing it as a significant research area for loess landslides. Advanced time-series InSAR technology facilitates the retrieval of surface deformation information, thereby aiding in the monitoring of landslide deformation status. However, existing methods that analyze deformation patterns do not fully exploit the displacement time series derived from InSAR, which hampers the exploration of potentially coexisting deformation patterns within the area. This study integrates InSAR with time-series clustering methods to reveal the surface deformation patterns and their spatial distribution characteristics in Heifangtai. Initially, utilizing the Sentinel-1 ascending and descending SAR data stack from January 2020 to June 2023, we optimize the interferometric phase based on distributed scatterer characteristics to reduce noise levels and obtain higher spatial density of measurement points. Subsequently, by combining the differential interferometric datasets from both ascending and descending orbits, the multidimensional small baseline subsets technique is employed to calculate the two-dimensional deformation time series. Finally, time-series clustering methods are utilized to extract the deformation patterns present and their spatial distribution from all measurement point time series. The results indicate that the deformation of the Heifangtai is primarily distributed around the surrounding area of the platform, with subsidence deformation being more intense than horizontal deformation. The entire terrace exhibits five deformation patterns: eastward subsidence, westward subsidence, vertical subsidence, westward movement, and eastward movement. The spatial distribution of these patterns suggests that the areas beneath the platform, namely Yanguoxia Town and Dangchuan Village, may be more susceptible to landslide threats in the future. Furthermore, wavelet analysis reveals the response relationship between rainfall and various deformation patterns, further enhancing the interpretability of these patterns. These findings hold significant implications for subsequent landslide monitoring, early warning, and risk prevention. Full article

For change detection in synthetic aperture radar (SAR) imagery, amplitude change detection (ACD) and coherent change detection (CCD) are widely employed. However, time-series SAR data often contain noise and variability introduced by system and environmental factors, requiring mitigation. Additionally, the stability of SAR signals is preserved when calibration accounts for temporal and environmental variations. Although ACD and CCD techniques can detect changes, spatial variability outside the primary target area introduces complexity into the analysis. This study presents a robust change detection methodology designed to identify urban changes using KOMPSAT-5 time-series data. A comprehensive preprocessing framework—including coregistration, radiometric terrain correction, normalization, and speckle filtering—was implemented to ensure data consistency and accuracy. Statistical homogeneous pixels (SHPs) were extracted to identify stable targets, and coherence-based analysis was employed to quantify temporal decorrelation and detect changes. Adaptive thresholding and morphological operations refined the detected changes, while small-segment removal mitigated noise effects. Experimental results demonstrated high reliability, with an overall accuracy of 92%, validated using confusion matrix analysis. The methodology effectively identified urban changes, highlighting the potential of KOMPSAT-5 data for post-disaster monitoring and urban change detection. Future improvements are suggested, focusing on the stability of InSAR orbits to further enhance detection precision. The findings underscore the potential for broader applications of the developed SAR time-series change detection technology, promoting increased utilization of KOMPSAT SAR data for both domestic and international research and monitoring initiatives. Full article

Coal is the main mineral resource, but over-exploitation will cause a series of geological disasters. Interferometric synthetic aperture radar (InSAR) technology provides a superior monitoring method to compensate for the inadequacy of traditional measurements for mine surface deformation monitoring. In this study, the whole process of mining a working face in Huaibei Mining District, Anhui Province, is taken as the object of study. The ALOS PALSAR satellite radar image data and ground measurements were acquired, and the ISK-DPIM-InSAR deformation monitoring model with the dynamic probabilistic integral model (DPIM) was proposed by combining the probabilistic integral method (PIM) and the improved segmented Knothe time function (ISK). The ISK-DPIM-InSAR model constructs the inversion equations of InSAR line-of-sight deformation, north–south and east–west horizontal movement deformation, vertical deformation, inverts the optimal values of the predicted parameters of the workforce through the particle swarm algorithm, and substitutes it into the ISK-DPIM-InSAR model for predicting the three-dimensional dynamic deformation of a mining face. Simulated workface experiments determined the feasibility of the model, and by comparing the level observation results of the working face, it is confirmed that the ISK-DPIM-InSAR model can accurately monitor the three-dimensional deformation of the surface in the mining area. Full article

Faults, as unique geological structures, disrupt the mechanical connections between rock masses. During coal mining, faults in the overlying strata can disturb the original stress balance, leading to fault activation and altering the typical subsidence patterns. This can result in abnormal ground deformation and significant damage to surface structures, posing a serious geological hazard in mining areas. This study examines the influence of a known fault (F13 fault) on ground subsidence in the Wannian Mine of the Fengfeng Mining Area. We utilized 12 Sentinel-1A images and applied SBAS-InSAR, StaMPS-InSAR, and DS-InSAR time-series InSAR methods, alongside the D-InSAR method, to investigate surface deformations caused by the F13 fault. The monitoring accuracy of these methods was evaluated using leveling measurements from 28 surface movement observation stations. In addition, the density of effective monitoring points and the relative strengths and limitations of the three time-series methods were compared. The findings indicate that, in low deformation areas, DS-InSAR has a monitoring accuracy of 7.7 mm, StaMPS-InSAR has a monitoring accuracy of 16.4 mm, and SBAS-InSAR has an accuracy of 19.3 mm. Full article

InSAR has emerged as a leading technique for studying and monitoring ground movements over large areas and across various geodynamic environments. Recent advancements in SAR sensor technology have enabled the acquisition of dense spatial datasets, providing substantial information at regional and national scales. Despite these improvements, classifying and interpreting such vast datasets remains a significant challenge. InSAR analysts and geologists frequently have to manually analyze the time series from Persistent Scatterer Interferometry (PSI) to model the complexity of geological and tectonic phenomena. This process is time-consuming and impractical for large-scale monitoring. Utilizing Artificial Intelligence (AI) to classify and detect deformation processes presents a promising solution. In this study, vertical ground deformation time series from northeastern Italy were obtained from the European Ground Motion Service and classified by experts into different deformation categories. Convolutional and pre-trained neural networks were then trained and tested using both numerical time-series data and trend images. The application of the best performing trained network to test data showed an accuracy of $83\%$. Such a result demonstrates that neural networks can successfully identify areas experiencing distinct geodynamic processes, emphasizing the potential of AI to improve PSI data interpretation. Full article

Due to the limitations inherent in SAR satellite imaging modes, utilizing time-series InSAR technology to process single-orbit satellite image data typically only yields one-dimensional deformation information along the LOS direction. This constraint impedes a comprehensive representation of the true surface deformation of landslides. Consequently, in this paper, after the SBAS-InSAR and PS-InSAR processing of the 30-view ascending and 30-view descending orbit images of the Sentinel-1A satellite, based on the imaging geometric relationship of the SAR satellite, we propose a novel computational method of fusing ascending and descending orbital LOS-direction time-series deformation to extract the landslide’s downslope direction deformation of landslides. By applying this method to Baige landslide monitoring and integrating it with an improved tangential angle warning criterion, we classified the landslide’s trailing edge into a high-speed, a uniform-speed, and a low-speed deformation region, with deformation magnitudes of 7~8 cm, 5~7 cm, and 3~4 cm, respectively. A comparative analysis with measured data for landslide deformation monitoring revealed that the average root mean square error between the fused landslide’s downslope direction deformation and the measured data was a mere 3.62 mm. This represents a reduction of 56.9% and 57.5% in the average root mean square error compared to the single ascending and descending orbit LOS-direction time-series deformations, respectively, indicating higher monitoring accuracy. Finally, based on the analysis of landslide deformation and its inducing factors derived from the calculated time-series deformation results, it was determined that the precipitation, lithology of the strata, and ongoing geological activity are significant contributors to the sliding of the Baige land-slide. This method offers more comprehensive and accurate surface deformation information for dynamic landslide monitoring, aiding relevant departments in landslide surveillance and management, and providing technical recommendations for the fusion of multi-orbital satellite LOS-direction deformations to accurately reconstruct the true surface deformation of landslides. Full article

Due to a heavy reliance on groundwater, Bangladesh is experiencing a severe decline in groundwater storage, with some areas even facing land subsidence. This study aims to investigate the relationship between groundwater storage changes and land subsidence in Bangladesh, utilizing a combination of GRACE and InSAR technologies. To clarify this relationship from a macro perspective, the study employs GRACE data merged with GLDAS to analyze changes in groundwater storage and SBAS-InSAR technology to assess land subsidence. The Dynamic Time Warping (DTW) method calculates the similarity between groundwater storage and land subsidence time series, incorporating precipitation and land cover types into the data analysis. The findings reveal the following: (1) Groundwater storage in Bangladesh is declining at an average rate of −5.55 mm/year, with the most significant declines occurring in Rangpur, Mymensingh, and Rajshahi. Notably, subsidence areas closely match regions with deeper groundwater levels; (2) The similarity coefficient between the time series of groundwater storage and land subsidence changes exceeds 0.85. Additionally, land subsidence in different regions shows an average lagged response of 2 to 6 months to changes in groundwater storage. This study confirms a connection between groundwater dynamics and land subsidence in Bangladesh, providing essential knowledge and theoretical support for further research. Full article

The completeness of landslide inventories and the selection of evaluation models significantly impact the accuracy of landslide susceptibility assessments. Conventional field geological survey methods and single remote-sensing technology struggle to reliably identify landslides under complex environmental conditions. Moreover, prevalent landslide susceptibility evaluation models are often plagued by issues such as subjectivity and overfitting. Therefore, we investigated the uncertainty in susceptibility modeling from the aspects of landslide inventory quality and model selection. The study focused on Luquan County in Yunnan Province, China. Leveraging multisource remote-sensing technologies, particularly emphasizing optical remote sensing and InSAR time-series deformation detection, the existing historical landslide inventory was refined and updated. This updated inventory was subsequently used to serve as samples. Nine evaluation indicators, encompassing factors such as distance to faults and tributaries, lithology, distance to roads, elevation, slope, terrain undulation, distance to the main streams, and average annual precipitation, were selected on the basis of the collation and organization of regional geological data. The information value and two coupled machine-learning models were formulated to evaluate landslide susceptibility. The evaluation results indicate that the two coupled models are more appropriate for susceptibility modeling than the single information value (IV) model, with the random forest model optimized by genetic algorithm in Group I2 exhibiting higher predictive accuracy (AUC = 0.796). Furthermore, comparative evaluation results reveal that, under equivalent model conditions, the incorporation of a remote-sensing landslide inventory significantly enhances the accuracy of landslide susceptibility assessment results. This study not only investigates the impact of landslide inventories and models on susceptibility outcomes but also validates the feasibility and scientific validity of employing multisource remote-sensing technologies in landslide susceptibility assessment. Full article

Land subsidence caused by human engineering activities is a serious problem worldwide. We selected Qian’an County as the study area to explore the evolution of land subsidence and predict its deformation trend. This study utilized synthetic aperture radar interferometry (InSAR) technology to process 64 Sentinel-1 data covering the area, and high-precision and high-resolution surface deformation data from January 2017 to December 2021 were obtained to analyze the deformation characteristics and evolution of land subsidence. Then, land subsidence was predicted using the intelligence neural network theory, machine learning methods, time-series prediction models, dynamic data processing techniques, and engineering geology of ground subsidence. This study developed three time-series prediction models: a support vector regression (SVR), a Holt Exponential Smoothing (Holt) model, and multi-layer perceptron (MLP) models. A time-series prediction analysis was conducted using the surface deformation data of the subsidence funnel area of Zhouzi Village, Qian’an County. In addition, the advantages and disadvantages of the three models were compared and analyzed. The results show that the three developed time-series data prediction models can effectively capture the time-series-related characteristics of surface deformation in the study area. The SVR and Holt models are suitable for analyzing fewer external interference factors and shorter periods, while the MLP model has high accuracy and universality, making it suitable for predicting both short-term and long-term surface deformation. Ultimately, our results are valuable for further research on land subsidence prediction. Full article

Affected by geological factors, the scale of surface deformation in a hilly semi-desertification mining area varies. Meanwhile, there is certain dense vegetation on the ground, so it is difficult to construct a high-precision and complete image of a subsidence basin by using a single monitoring method, and hence the laws of the deformation and inversion of mining parameters cannot be known. Therefore, we firstly propose conducting collaborative monitoring by using InSAR (Interferometric Synthetic Aperture Radar), UAV (unmanned aerial vehicle), and 3DTLS (three-dimensional terrestrial laser scanning). The time-series complete surface subsidence basin is constructed by fusing heterogeneous data. In this paper, SBAS-InSAR (Small Baseline Subset) technology, which has the characteristics of reducing the time and space discorrelation, is used to obtain the small-scale deformation of the subsidence basin, oblique photogrammetry and 3D-TLS with strong penetrating power are used to obtain the anomaly and large-scale deformation, and the local polynomial interpolation based on the weight of heterogeneous data is used to construct a complete and high-precision subsidence basin. Compared with GNSS (Global Navigation Satellite System) monitoring data, the mean square errors of 1.442 m, 0.090 m, 0.072 m are obtained. The root mean square error of the high-precision image of the subsidence basin data is 0.040 m, accounting for 1.4% of the maximum subsidence value. The high-precision image of complete subsidence basin data can provide reliable support for the study of surface subsidence law and mining parameter inversion. Full article
