Search Results (39)

This article is devoted to the prediction of the service life of selected structural materials under simulated operating conditions. Special attention is paid to the so-called representative volume element, which characterizes the damage behaviour, since it includes a critical number of microdefects. The overall damage prediction is based on the energy approach, and the development of damage comes from the traction separation laws; the shape of the damage varies for different materials. The calculations were performed using the extended finite element method (XFEM), where several minor modifications were made. This method has been successfully used in many areas of engineering sciences for research, simulation, and prediction of the behaviour of structures. XFEM reformulates the continuous boundary and initial value problems into similar variational forms instead of using the classical forms of differential equations. The simulation of fracture and damage phenomena is presented for two different materials: austenitic steel with a pronounced grain structure under creep (viscous) loading conditions and cement pasta reinforced with metal fibres under conditions of predominantly static loading. Full article

Wood, steel, and concrete constitute the three predominant structural materials employed in contemporary commercial and residential construction. In composite applications, bond interfaces between these materials represent critical structural junctures that frequently exhibit a reduced load-bearing capacity, rendering them susceptible to the initiation of cracks. To elucidate the fracture propagation mechanisms at composite material interfaces, this study implements the cohesive zone method (CZM) to numerically simulate interfacial cracking behavior in two material systems: glued laminated timber (GLT) and reinforced concrete (RC). The adopted CZM framework utilizes a progressive delamination approach through cohesive elements governed by a bilinear traction–separation constitutive law. This methodology enables the simulation of interfacial failure through three distinct fracture modes: mode I (pure normal separation), mode II (pure in-plane shear), and mixed-mode (mode m) failure. Numerical models were developed for GLT beams, RC beams, and RC slab structures to investigate the propagation of interfacial cracks under monotonic loading conditions. The simulation results demonstrate strong agreement with experimental cracking observations in GLT structures, validating the CZM’s efficacy in characterizing both mechanical behavior and crack displacement fields. The model successfully captures transverse tensile failure (mode I) parallel to wood grain, longitudinal shear failure (mode II), and mixed-mode failure (mode m) in GLT specimens. Subsequent application of the CZM to RC structural components revealed a comparable predictive accuracy in simulating the interfacial mechanical response and crack displacement patterns at concrete composite interfaces. These findings collectively substantiate the robustness of the proposed CZM framework in modeling complex fracture phenomena across diverse construction material systems. Full article

Adhesive joints in real-world conditions often experience variable or step loading rather than constant-amplitude fatigue. This study addresses this gap by examining the influence of load sequence and block loading on fatigue damage in adhesive joints of fiber-reinforced polymer (FRP) composites. A novel bilinear traction-separation law based on the Fatigue Crack Growth Rate (FCGR) rule is introduced to predict fatigue failure under step/variable loads, accounting for load history, sequence, and interaction effects. This model was validated using a double-lap joint model under step/variable loading across four experimental scenarios. The proposed model outperformed existing fatigue damage-accumulation models, significantly reducing the Relative Error of Prediction ($REP$). Notably, the proposed model significantly reduced the Relative Error of Prediction ($REP$), achieving reductions from 81.10% to as low as 0.013% in certain cases. The proposed bilinear law exhibited an accelerated damage accumulation rate per cycle for low-to-high loading situations and a decelerated rate for high-to-low loading scenarios, aligning more closely with experimental observations. The proposed model offers practical benefits by improving fatigue life predictions, enabling optimized FRP composite designs, and minimizing overengineering. These advancements are particularly relevant in industries such as aerospace, automotive, and wind energy, where structural durability and safety are paramount. This research represents a significant step forward in the fatigue analysis of composite adhesive joints, paving the way for more reliable engineering solutions. Full article

Nacre has excellent balanced strength and toughness. In this paper, the mechanical performance of the typical “brick-and-mortar” structure, including the stress–strain and strain at the interface as well as the stress in the bricks, was calculated by a simplified analytical model of the nacre. This paper proposes a new method to control the crack deflection based on the toughening mechanism of the nacre. The crack extension of the “brick-and-mortar” structure was simulated using cohesive elements based on the traction–separation law with elastic and softening stiffness as variables, and it was found that both stiffness could effectively control the crack extension. The strength and toughness of the models with different stiffness combinations were calculated and plotted as a function of elastic stiffness and softening stiffness, showing that elastic stiffness significantly affects strength and softening stiffness is a determinant of toughness. Full article

This paper investigates the low-velocity impact response and damage behavior of glass fiber reinforced polymer (GFRP) hollow ribbed emergency pipes of our design under different impact heights. Drop hammer impact tests with impact velocities of 8.41 m/s, 8.97 m/s, and 9.50 m/s were conducted using an impact platform. A progressive damage model for low-velocity impact was developed using Abaqus/Explicit finite element software. The model used the three-dimensional Hashin damage initiation criteria and a damage evolution model based on the equivalent strain method to simulate the initiation and evolution of intralaminar damage in the pipe ring. A cohesive zone model (CZM) based on a bilinear traction-separation law was used to simulate delamination. The results show that the pipe rings experienced fiber or matrix fractures and delamination damage during the impact process. Additionally, the pipe ring specimens underwent bending vibrations under the impact load, leading to fluctuating contact forces at all three impact heights. Analysis of the simulation results reveals that the primary damage modes in the GFRP hollow ribbed emergency pipe are fiber tension damage, matrix tension damage, and fiber compression damage, with delamination occurring mainly in the impact area and the interface area on both sides of the rib. Full article

Numerous studies have demonstrated that under low-velocity, low-energy impact conditions, although the surface damage to fiber-reinforced composite laminates may be minimal, significant internal damage can occur. Consequently, a progressive damage finite element model was specifically developed for thermoplastic carbon fiber-reinforced composite laminates subjected to low-speed impact loads, with the objective of analyzing the damage behavior of laminates under impacts of varying energy levels. The model utilizes a three-dimensional Hashin criterion for predicting intralayer damage initiation, with cohesive elements based on bilinear traction–separation law for predicting interlaminar delamination initiation, and incorporates a damage constitutive model based on equivalent displacement to characterize fiber damage evolution, along with the B-K criterion for interlaminar damage evolution. The impact response of laminates at energy levels of 5 J, 10 J, 15 J, 20 J, and 25 J was analyzed through numerical simulation, drop-hammer experiments, and XCT non-destructive testing. The results indicated that the simulation outcomes closely correspond with the experimental findings, with both the predicted peak error and absorbed energy error maintained within a 5% margin, and the trends of the mechanical response curves aligning closely with the experimental data. The damage patterns predicted by the numerical simulations were consistent with the results obtained from XCT scans. The study additionally revealed that the impact damage of the laminates primarily stems from interlaminar delamination and intralayer tensile failure. Initial damage typically presents as internal delamination; hence, enhancing interlaminar bonding performance can significantly augment the overall load-bearing capacity of the laminate. Full article

Due to their anisotropic behavior, composite structures are weak in transverse direction loading. produces transverse cracks, which for a laminated composite, may lead to delamination and total failure. The transition from transverse crack to delamination failure is important and the subject of recent studies. In this paper, a simulation of transverse crack and its transition to delamination on cross-ply laminate was studied extensively using a cohesive element Finite Element Method (FEM). A pre-cracked [0/90] composite laminate made of bamboo was modeled using ABAQUS/CAE. The specimen was in a three-point bending configuration. Cohesive elements were inserted in the middle of the 90° layer and in the interface between the 0° and 90° layer to simulate transverse crack propagation and its transition to delamination. A load–displacement graph was extracted from the simulation and analyzed. As the loading was given to the specimen, stress occurred in the laminates, concentrating near the pre-cracked region. When the stress reached the tensile transverse strength of the bamboo, transverse crack propagation initiated, indicated by the failure of transverse cohesive elements. The crack then propagated towards the interface of the [0/90] laminates. Soon after the crack reached the interface, delamination propagated along the interface, represented by the failure of the longitudinal cohesive elements. The result of the numerical study in the form of load–displacement graph shows a consistent pattern compared with the data found in the literature. The graph showed a linear path as the load increased and the crack propagated until a point where there was a load-drop in the graph, which showed that the crack was unstable and propagated quickly before it turned into delamination between the 0^o and 90° plies. Full article

This paper presents a numerical investigation of the R-curve effect in delamination propagation in composite materials. The R-curve effect refers to the phenomenon whereby resistance to crack propagation increases with the advancement of the delamination, due to toughening mechanisms, such as fiber bridging. Numerical models often neglect this effect assuming a constant value of the fracture toughness. A numerical approach based on cohesive elements and on the superposition of two bilinear traction-separation laws is adopted here to accurately predict the R-curve effect in skin-doubler composite specimens subjected to three-point bending tests. The carbon-epoxy material presents two different sensitivities to the fiber bridging phenomenon resulting in two different R-curves. Comparisons with literature experimental data, in terms of load and delaminated area vs. applied displacement, and ultrasonic C-scan images show the effectiveness of the adopted approach in simulating the R-curve effect. The predicted numerical stiffness aligns with the experimental scatter, although the maximum load is slightly underestimated by approximately 15% compared with the average experimental results. The numerical model accurately predict the R-curve effect observed in the experimental data, demonstrating a 31% increase in the maximum load for the material configuration exhibiting greater sensitivity to fiber bridging. Full article

For insulated gate bipolar transistor (IGBT) modules using wire bonding as the interconnection method, the main failure mechanism is cracking of the bonded interface. Studying the mechanical properties of the bonded interface is crucial for assessing the reliability of IGBT modules. In this paper, first, shear tests are conducted on the bonded interface to test the bonded interface’s strength. Then, finite element–cohesive zone modeling (FE-CZM) is established to describe the mechanical behavior of the bonded interface. A novel machine learning (ML) architecture integrating a convolutional neural network (CNN) and a long short-term memory (LSTM) network is used to identify the shape and parameters of the traction separation law (TSL) of the FE-CZM model accurately and efficiently. The CNN-LSTM architecture not only has excellent feature extraction and sequence-data-processing abilities but can also effectively address the long-term dependency problem. A total of 1800 sets of datasets are obtained based on numerical computations, and the CNN-LSTM architecture is trained with load–displacement (F–δ) curves as input parameters and TSL shapes and parameters as output parameters. The results show that the error rate of the model for TSL shape prediction is only 0.186%. The performance metric’s mean absolute percentage error (MAPE) is less than 3.5044% for all the predictions of the TSL parameters. Compared with separate CNN and LSTM architectures, the proposed CNN-LSTM-architecture approach exhibits obvious advantages in recognizing TSL shapes and parameters. A combination of the FE-CZM and ML methods in this paper provides a promising and effective solution for identifying the mechanical parameters of the bonded interfaces of IGBT modules. Full article

The aim of this study is to solve a practical problem encountered in the automotive industry, especially the failure of a cracked lower control arm made of al 6062 T6 material during static and crash physical tests, and to characterize the behavior of cracked parts made of aluminum materials using the fracture mechanics parameters. As a first step, we carried out a numerical study and simulation using Abaqus/CAE 2020 software and the finite element method to determine the stress concentration and load limit capacity for different car weight cases. The von Mises stress variation shows crack initiation and propagation to be in the area of the lower control arm’s attachment to the vehicle platform, where stress is concentrated. These numerical results are consistent with the experimental test results found by automotive manufacturers. Also, we find that the mechanical load that can support this part is below 4900 N for good performance. In the second step, we use the results of the first section to simulate the failure of a lower control arm with a crack defect. This paper investigates the stress intensity factor KI in mode I for different lengths (L) and depths (a) of the crack in the lower control arm using the extended finite element method (XFEM) under Abaqus/CAE. For crack failure initiation and progression, we relied on the traction separation law, specifically the maximum principal stress (MAXPS) criterion. The KI factor was evaluated for the materials steel and Al 6062 T6. The results obtained from the variation of the KI coefficient as a function of crack depth (a) and the thickness (t) show that the crack remains stable even when a depth ratio (a/t = 0.8) is reached for the steel material. However, the crack in the Aluminum 6062 T6 material becomes unstable at depth (a/t = 0.6), with a high risk of total failure of the lower control arm. Full article

With the increasing demand for lightweight and high-performance materials in the automotive and aerospace industries, full-thermoplastic hybrid composites have emerged as a pivotal solution, offering enhanced mechanical properties and design flexibility. This work aims to numerically model the fracture strength in full-thermoplastic hybrid composites made by forming and overmolding organosheets. The mode I fracture was investigated by modeling the behavior of T-joint specimens under a tensile test following the cohesive zone modeling (CZM) approach. The sample was designed to replicate the connection between the laminate and the overmolded part. Double cantilever beam (DCB) specimens were manufactured with organosheets and tested to mode I opening to determine the interlaminar fracture toughness. The fracture toughness out of the mode I test with DCB specimens was used to define the CZM parameters that describe the traction-separation law. Later, due to the particular geometry of the T-join specimens that under tensile load work close to pure mode I, the cohesive parameters were determined by inverse analysis, i.e., calibrating the theoretical models to match experimental results. The fracture resistance T-joint specimens appeared dependent on the fiber-bridging phenomenon during the delamination. In particular, the presence of fiber-bridging visible from the experimental results has been replicated by virtual analyses, and it is observed that it leads to a higher energy value before the interface’s complete breakage. Moreover, a correspondence between the mode I fracture toughness of the DCB specimen and T-joint specimens was observed. Full article

Modeling metal matrix composites in finite element software requires incorporating a cohesive zone model (CZM) to represent the interface between the constituent materials. The CZM determines the behavior of traction–separation (T–S) in this region. Specifically, when a diffusion zone is formed due to heat treatment, it becomes challenging to determine experimentally the equivalent mechanical properties of the interface. Additionally, understanding the influence of heat treatment and the creation of a diffusion zone on the T–S law is crucial. In this study, the molecular dynamics approach was employed to investigate the effect of the diffusion region formation, resulting from heat treatment, on the T–S law at the interface of a SiC/Al composite in tensile, shear, and mixed-mode loadings. It was found that the formation of a diffusion layer led to an increase in tensile and shear strengths and work of separation compared with the interfaces without heat treatment. However, the elastic and shear moduli were not significantly affected by the creation of the diffusion layer. Moreover, the numerical findings indicated that the shear strength in the diffusion region was higher when compared with the shear strength of the $\left\{111\right\}$ slip plane within the fcc aluminum component of the composite material. Therefore, in the diffusion region, crack propagation did not occur in the pure shear loading case; however, shear sliding was observed at the aluminum atomic layers. Full article

Methodologies are developed for analyzing failure initiation and crack propagation in highly heterogeneous concrete mesostructures. Efficient algorithms are proposed in Python to generate and pack geometric features into a continuous phase. The continuous phase represents the mortar matrix, while the aggregates and voids of different sizes represent the geometric features randomly distributed within the matrix. The cohesive zone model (CZM) is utilized to investigate failure initiation and crack propagation in mesoscale concrete specimens. Two-dimensional zero-thickness cohesive interface elements (CIEs) are generated at different phases of the concrete mesostructure: within the mortar matrix, aggregates, and at the interfacial transition zone (ITZ). Different traction–separation laws (TSL) are assigned to different phases to simulate potential crack paths in different regions of the mesoscale concrete specimen. The mesoscale finite element simulations are verified using experimental results from the literature, with a focus on implementing mixed-mode fracture and calibrating its corresponding parameters with respect to the experimental data. In addition, the current study addresses the limited exploration of void effects in mesoscale concrete simulations. By investigating voids of diverse sizes and volume fractions, this research sheds light on their influence on the mechanical behavior of concrete materials. The algorithms for generating cohesive interface elements and concrete microstructures are described in detail and can be easily extended to more complex states. This methodology provides an effective tool for the mesostructural optimization of concrete materials, considering specific strength and toughness requirements. Full article

This study examined the fracture and failed performance of foamed concrete materials by testing normalized notched beams under three-point bending via three methods: inverse analysis, digital image correlation (DIC), and finite element modeling (FEM). It also discussed both experimental and FEM characteristics. However, inverse analysis is only applicable for specimens with a notch height of 30 mm. Bilinear softening of the tested beams was estimated to identify the fracture energy (G_F), critical crack length (a_c), and elastic modulus (E). Additionally, the fracture toughness was calculated by adopting the double-K method (initiation fracture, unstable fracture, and cohesive fracture). Two-dimensional FEA modeling of the fracture was conducted using the traction-separation law (TSL), incorporating the extended finite element method (XFEM) and cohesive zone (CZM) techniques. A finite element sensitivity for the XFEM and CZM was performed, with the global mesh size of 2 and the damage stabilization cohesion of 1 × 10⁻⁵ showed good convergence and were used in other models. Further comparison of the DIC experiment findings with those from the FEM demonstrated good agreement in terms of crack propagation simulation. Full article

In order to study the effect of TiB₂ particles on the mechanical properties of TiB₂/6061Al composites, a series of 3D TiB₂/6061Al representative volume elements (RVEs) were established based on SEM photos. This model took into account the ductile damage of the matrix and the traction separation behavior of the interface, and the linear damage evolution law was introduced to characterize stiffness degradation in the matrix elements. Mixed boundary conditions were used in the RVE tensile experiments, and the accuracy of the predicted result was verified by the agreement of the experimental stress-strain curve. The results showed that the addition of TiB₂ particles can effectively promote the load-bearing capacity of the composite, but elongation is reduced. When the weight fraction of TiB₂ increased from 2.5% to 12.5%, the elastic modulus, yield strength, and tensile strength increased by 8%, 10.37%, and 11.55%, respectively, while the elongation decreased by 10%. The clustering rate of the TiB₂ particles is also an important factor affecting the toughness of the composites. With an increase in the clustering rate of TiB₂ particles from 20% to 80%, the load-bearing capacity of the composites did not improve, and the elongation of the composites was reduced by 8%. Moreover, the high-strain region provides a path for rapid crack propagation, and particle spacing is a crucial factor that affects the stress field. Full article
