Search Results (43)

The traditional research methods of the notch frequency phenomenon are mainly discussed by experimental observation or the semi-analytical finite element method. In this paper, the notch frequency characteristics of ultrasonic guided waves are simulated by the general finite element method. Firstly, the theoretical dispersion curve of the longitudinal mode in the axially loaded rod is derived by the acoustic elasticity theory, and the finite element simulation is carried out by ABAQUS/Explicit 6.14 to simulate the wave propagation in the seven-wire steel strand. In order to verify the model, laboratory experiments are carried out on three types of prestressed steel strands with diameters of 12.7 mm, 15.2 mm, and 17.8 mm, respectively. Each specimen is gradually loaded from 50 kN to 110 kN in increments of 30 kN. At each loading level, the ultrasonic signal is obtained, and the corresponding notch frequency is extracted from the spectrum. The experimental results confirm the accuracy of the model, and the maximum deviation between the predicted notch frequency and the measured value is 3%. The results show that the proposed method provides a robust and non-destructive means for structural health monitoring in civil engineering applications, and has the potential to be more widely used in complex waveguide structures. Full article

The monitoring of gases and vapors using portable instruments is critical in a variety of fields, such as industrial and household safety, environmental monitoring, process control, and national security, owing to gas pollution. In this study, we design a portable and simple two-dimensional photonic crystal microcavity sensor for detecting gases such as ammonia, methane, carbon monoxide, acetylene, ethylene, and ethane. The basic structure of the sensor consists of silicon rods arranged in a square lattice pattern in air. Waveguide input and output channels are realized by engineering line defects within the lattice structure. Moreover, the sensor’s performance is continuously optimized by adding point defects, introducing a ring cavity, and varying the radius of the dielectric rods in the microcavity. Using the transmission spectrum obtained from the output waveguide, the performance parameters of the gas sensor are calculated. Based on the simulation analysis, the optimized gas sensor exhibits excellent performance, achieving a sensitivity S of 932.43 nm/RIU and a quality factor Q of 2421.719. Full article

Acoustic emission (AE) technology has been extensively applied in the damage assessment of steel strands; however, it remains inadequate in identifying and quantifying the number of strand fractures, which limits the accuracy and reliability of prestressed structure monitoring. In this study, a test platform based on practical engineering was built. The AE monitoring method using a waveguide rod was applied to identify signals from different numbers of strand fractures, and their acoustic characteristics were analyzed using Fourier transform and multi-bandwidth wavelet transform. The propagation attenuation behavior of the AE signals in the waveguide rod was then analyzed, and the optimal parameters for field monitoring as well as the maximum number of plates suitable for series beam plates were determined. The results show that AE signals decrease exponentially with an increasing propagation distance, and attenuation models for various AE parameters were established. As the number of strand fractures increases, the amplitude of the dominant frequency increases significantly, and the energy distribution shifts towards higher-frequency bands. This finding introduces a novel approach for quantifying fractures in steel strands, enhancing the effectiveness of AE technology in monitoring and laying a foundation for the development of related technologies. Full article

This article considers a fluxgate magnetometer (FM) that operates based on a new physical principle. The authors analyze how the alternating electric charge potential of a cylindrical metal electrode impacts the structure of a cylindrical permanent magnet made of composite-conducting ferrite. They demonstrate that this impact and permanent magnet structure initiate the emergence of polarons with oscillating magnetism. This causes significant changes in the entropy of indirect exchange and the related sublattice magnetism fluctuations that ultimately result in the generation of circularly polarized spin waves at the spin wave resonance frequency that are channeled and evolve in dielectric ferrite waveguides of the FM. It is demonstrated that these moving spin waves have an electrodynamic impact on the measuring FM coils on the macro-level and perform parametric modulation of the magnetic permeability of the waveguide material. This results in the respective variations of the changeable magnetic field, which is also registered by the measuring FM coils. The authors considered a generalized flow of the physical processes in the FM to obtain a detailed representation of the operating functions of the FM. The presented experimental results for the proposed FM in the field meter mode confirm its operating parameters (±40 μT—measurement range, 0.5 nT—detection threshold). The usage of a cylindrical metal electrode as a source of exciting electrical change instead of a conventional multiturn excitation coil can significantly reduce temperature drift, simplify production technology, and reduce the unit weight and size. Full article

Compared to traditional temperature measurement methods, ultrasonic temperature measurement technology based on the principle of resonance offers advantages such as shorter section lengths, higher signal amplitude, and reduced signal attenuation. First, the type of sensor-sensitive element was determined, with a resonant design chosen to improve measurement performance; using magnetostrictive and resonant temperature measurement principles, the length, diameter, and resonator dimensions of the waveguide rod were designed, and a molybdenum–rhenium alloy (Mo-5%Re) material suitable for high-temperature environments was selected; COMSOL finite element simulation was used to simulate the propagation characteristics of acoustic signals in the waveguide rod, observing the distribution of sound pressure and energy attenuation, verifying the applicability of the model in high-temperature testing environments. Second, a resonant temperature sensor consistent with the simulation parameters was prepared using a molybdenum–rhenium alloy waveguide rod, and an ultrasonic resonant temperature-sensing system suitable for high-temperature environments up to 1800 °C was constructed using the molybdenum–rhenium alloy waveguide rod. The experiment used a tungsten–rhenium calibration furnace to perform static calibration of the sensor. The temperature range was set from room temperature to 1800 °C, with the temperature increased by 100 °C at a time, and it was maintained at each temperature point for 5 to 10 min to ensure thermal stability. This was conducted to verify the performance of the sensor and obtain the functional relationship between temperature and resonance frequency. Experimental results show that during the heating process, the average resonance frequency of the sensor decreased from 341.8 kHz to 310.37 kHz, with an average sensitivity of 17.66 Hz/°C. During the cooling process, the frequency increased from 309 kHz to 341.8 kHz, with an average sensitivity of 18.43 Hz/°C. After cooling to room temperature, the sensor’s resonant frequency returned to its initial value of 341.8 kHz, demonstrating excellent repeatability and thermal stability. This provides a reliable technical foundation for its application in actual high-temperature environments. Full article

Substrate Integrated Circuits (SICs) represent a significant advancement in microwave communication systems due to their high efficiency, performance, and integration capabilities. Empty Substrate-Integrated Waveguides (ESIWs) are a type of SIC that offers benefits such as cost-effectiveness while maintaining high performance. This paper presents the design and implementation of the first floating patch antenna integrated into an ESIW, fed by a metallic rod. The proposed antenna is designed to operate in the X-band (8–12 GHz), with a resonance peak at 10 GHz. The patch antenna is square, which provides interesting radiation characteristics. It is excited by a metallic rod that connects the patch to the ESIW line, resulting in excellent performance in terms of measured radiation efficiency (over 90%) and −10 dB impedance bandwidth (approximately 20%). The prototype demonstrates minimal differences between the simulated and manufactured versions. These results highlight the potential of ESIW-fed floating patch antennas for advanced satellite communication systems. This will enable the integration of complete communication systems within ESIWs and facilitate the straightforward development of 2D element arrays. Full article

Most of the traditional rod antennas in the literature are in the shape of a cylinder or are conical, which are not suitable shapes for planar PCB technology or planar integrated CMOS or BiCMOS technology. In this paper, we present a 24 GHz planar end-fire rod antenna based on an SIW (substrate integrated waveguide) suitable for planar PCB technology or planar integrated circuit technology. The antenna is made of PCB Rogers 4350 and utilizes the SIW to realize the end-fire rod antenna. The measurement results of the antenna are presented: its gain is 8.55 dB and its S11 bandwidth is 6.2 GHz. This kind of planar end-fire rod antenna possesses the characteristics of high gain, wide bandwidth, compactness, and simple design and structure. This type of antenna can also be used as a PCB antenna in other frequency bands, and it could also possibly be utilized in mm-wave and THz integrated antenna design in the future due to its very simple architecture. Full article

A novel 4-to-2 photonic crystal encoder is proposed by modulating the intensity of four input optical signals, and four distinct output states are achieved. Nonlinear rods are employed to couple input waves into resonant cavities, directing the light to the desired output waveguides. The proposed design, with a footprint of 114 µm², demonstrates efficient encoding operation at a wavelength of 1550 nm and is highly suitable for integrated photonics applications. A comprehensive comparative analysis revealed that the proposed 4-to-2 encoder exhibits a time response 176 fs faster than previously presented encoders. Furthermore, the contrast ratio of the designed structure is as high as 13.78 dB to distinguish between logic 0 and 1. These advancements hold significant potential for enhancing the performance of compact, high-speed digital circuits. Full article

A T-shaped photonic crystal waveguide was designed with square lattice tellurium photonic crystals. A diamond-shaped ferrite pillar array was inserted in the junction of the waveguide to make a novel terahertz polarization splitter. Both transverse electric and transverse magnetic modes were numerically investigated by the plane wave expansion method, which used complete photonic band gaps covering from 0.138 THz to 0.144 THz. In this frequency domain of the fully polarized band gaps, the transmission efficiency of the photonic crystal waveguide was up to −0.21 dB and −1.67 dB for the transverse electric and transverse magnetic modes, respectively. Under the action of a DC magnetic field, the THz waves were rotated 90 degrees by the diamond-shaped ferrite pillar array. Transverse electric waves or transverse magnetic waves can be separated by a polarization isolator (six smaller tellurium rods) from the fixed waves. The characteristics of the designed polarization splitter were analyzed by the finite element method, and its transmission efficiency was optimized to 95 percent by fine-tuning the radii of the thirteen ferrite pillars. A future integrated communication network of sky–earth–space will require fully polarized devices in the millimeter and terahertz wavebands. The envisaged polarization splitter has a unique function and provides a promising method for the realization of fully polarized 6G devices. Full article

The three stages of loess collapse are characterized by notable concealment and sudden onset due to the sudden nature of loess collapse and the prolonged duration of the peristaltic deformation stage. Traditional displacement monitoring methods struggle to detect early signals of instability and failure, leading to poor timeliness in disaster warnings. This project begins by examining non-force field information related to the loess collapse process. It focuses on acoustic emission monitoring and employs model tests to identify effective waveguide rods for monitoring loess collapse. Additionally, the project investigates the evolution anomalies of acoustic emission parameters before and after loess collapse failure, aiming to establish early warning criteria for loess collapse based on acoustic emission. This work provides a theoretical basis for monitoring and early warning of loess collapses. This study evaluates five parameters of the active waveguide system: sensor installation method, filling material, waveguide rod wall thickness, outer wrapping material, and outer wrapping wall thickness. The densities of the filler materials were tested using the optimal parameters derived from the tests to identify the best configurations for active acoustic emission (AE) waveguide systems suitable for monitoring loess collapse. Subsequently, a one-sided connected loess collapse model was employed for indoor tests, integrating real-time AE monitoring with the active waveguide method. This model facilitates the exploration of AE response characteristics during loess collapse and the analysis of destructive forms of loess collapse and time-sequence evolution of AE ringing counts throughout the deformation and destruction process. Results indicate that using filler materials with high elasticity modulus, high compactness, and low Poisson’s ratio, along with thin outer wrapping and waveguide rod walls, leads to strong AE signals. As deformation damage of loess collapse intensifies, the number of AE ringing counts notably increases. A rapid rise in cumulative ringing counts can indicate a “sudden increase”, or the b-value may stabilize, providing precursor information for loess collapse. Full article

L-cone opsin expression by gene therapy is a promising treatment for blue cone monochromacy (BCM) caused by congenital lack of long- and middle-wavelength-sensitive (L/M) cone function. Eight patients with BCM and confirmed pathogenic variants at the OPN1LW/OPN1MW gene cluster participated. Optical coherence tomography (OCT), chromatic perimetry, chromatic microperimetry, chromatic visual acuity (VA), and chromaticity thresholds were performed with unmodified commercial equipment and/or methods available in the public domain. Adaptive optics scanning laser ophthalmoscope (AOSLO) imaging was performed in a subset of patients. Outer retinal changes were detectable by OCT with an age-related effect on the foveal disease stage. Rod and short-wavelength-sensitive (S) cone functions were relatively retained by perimetry, although likely impacted by age-related increases in the pre-retinal absorption of short-wavelength lights. The central macula showed a large loss of red sensitivity on dark-adapted microperimetry. Chromatic VAs with high-contrast red gratings on a blue background were not detectable. Color vision was severely deficient. AOSLO imaging showed reduced total cone density with majority of the population being non-waveguiding. This study developed and evaluated specialized outcomes that will be needed for the determination of efficacy and safety in human clinical trials. Dark-adapted microperimetry with a red stimulus sampling the central macula would be a key endpoint to evaluate the light sensitivity improvements. VA changes specific to L-opsin can be measured with red gratings on a bright blue background and should also be considered as outcome measures in future interventional trials. Full article

This paper presents the transmission characteristics of flexible solid circular dielectric waveguides in the terahertz frequency band. In this paper, we measured the electrical properties of certain polymers within 325–500 GHz. Through simulation and measurement, the transmission loss, bending loss, and electric field distribution of solid-core polymer dielectric waveguides were analyzed and discussed. Additionally, we considered the surrounding cladding of the dielectric waveguide, the signal-feeding mode transmitter, and the interconnection of the dielectric waveguide. Ultimately, in the operating frequency range of 325–500 GHz, we selected PTFE rods with diameters of 0.5 mm and 1 mm as the dielectric waveguides, with measured transmission loss of less than 30 dB/m and 33 dB/m, respectively, and bending loss of less than 1 dB/m. The described dielectric waveguide has engineering significance for short-distance connections in complex geometric environments and provides a reference for subsequent research. Full article

This paper proposes a unique configuration for an all-optical D Flip Flop (D-FF) utilizing a quasi-square ring resonator (RR) and T-Splitter, as well as NOT and OR logic gates within a 2-dimensional square lattice photonic crystal (PC) structure. The components realizing the all-optical D-FF comprise of optical waveguides in a 2D square lattice PC of 45 × 23 silicon (Si) rods in a silica (SiO₂) substrate. The utilization of these specific materials has facilitated the fabrication process of the design, diverging from alternative approaches that employ an air substrate, a method inherently unattainable in fabrication. The configuration underwent examination and simulation utilizing both plane-wave expansion (PWE) and finite-difference time-domain (FDTD) methodologies. The simulation outcomes demonstrate that the designed waveguides and RR effectively execute the operational principles of the D-FF by guiding light as intended. The suggested configuration holds promise as a logic block within all-optical arithmetic logic units (ALUs) designed for digital computing optical circuits. The design underwent optimization for operation within the C-band spectrum, particularly at 1550 nm. The outcomes reveal a distinct differentiation between logic states ‘1’ and ‘0’, enhancing robust decision-making on the receiver side and minimizing logic errors in the photonic decision circuit. The D-FF displays a contrast ratio (CR) of 4.77 dB, a stabilization time of 0.66 psec, and a footprint of 21 μm × 12 μm. Full article

A novel terahertz polarization isolator using a two-dimensional square lattice tellurium rod array is numerically investigated at the interesting band of 0.22 THz in this short paper. The isolator is designed by inserting six hexagonal tellurium rods into a fully polarized photonic crystals waveguide with high efficiency of −0.34 dB. The TE and TM photonic band gaps of the 7 × 16 tellurium photonic crystals are computed based on the plane wave expansion method, which happen to coincide at the normalized frequency domain from 0.3859(a/λ) to 0.4033(a/λ), corresponding to the frequency domain from 0.2152 to 0.2249 THz. The operating bandwidth of the tellurium photonic crystals waveguide covers 0.2146 to 0.2247 THz, calculated by the finite element method. The six hexagonal tellurium rods with smaller circumradii of 0.16a serve to isolate transverse electric waves and turn a blind eye to transverse magnetic waves. The polarization isolation function and external characteristic curves of the envisaged structure are numerically simulated, which achieves the highest isolation of −33.49 dB at the central frequency of 0.2104 THz and the maximum reflection efficiency of 98.95 percent at the frequency of 0.2141 THz. The designed isolator with a unique function and high performance provides a promising approach for implementing fully polarized THz devices for future 6G communication systems. Full article

A novel, highly efficient terahertz fully polarized transmission line is designed by two-dimensional tellurium photonic crystals consisting of square lattice rod arrays with a complete photonic bandgap. The TE and TM photonic bandgaps of the tellurium photonic crystals, which are computed by plane wave expansion, happen to coincide, and the complete photonic bandgap covers from 2.894 to 3.025 THz. The function of the designed waveguide is simulated by the finite element method, and the transmission characteristics are optimized by accurately adjusting its structural parameters. The transmission efficiency of the waveguide for TE mode achieves a peak value of −0.34 dB at a central frequency of 2.950 THz and keeps above −3 dB from 2.82 THz to 3.02 THz, obtaining a broad relative bandwidth of about 6.84 percent. The operating bandwidth of the tellurium photonic crystals’ waveguide for TM mode is narrower than that of TE mode, whose relative bandwidth is about 4.39 percent or around 2.936 THz above −5 dB. The designed terahertz photonic crystals’ waveguide can transmit both TE and TM waves, and not only can it be used as a high-efficiency transmission line, but it also provides a promising approach for implementing fully polarized THz devices for future 6G communication systems. Full article
