Meta-optics, enabled by metasurfaces consisting of two-dimensional arrays of meta-atoms, offers ultrathin and multi-functional control over the vectorial wavefront of light at subwavelength scales. The unprecedented optical element technology is a promising candidate to overcome key limitations in augmented reality (AR) and virtual reality (VR) near-eye displays particularly in achieving compact, eyeglass-type form factors with a wide field-of-view, a large eyebox, high resolution, high brightness, and reduced optical aberrations, at the same time. This review highlights key performance bottlenecks of AR/VR displays in the perspective of optical design, with an emphasis on their practical significance for advancing current technologies. We then examine how meta-optical elements are applied to VR and AR systems by introducing and analyzing the major milestone studies. In case of AR systems, particularly, two different categories, free-space and waveguide-based architectures, are introduced. For each category, we summarize studies using metasurfaces as lenses, combiners, or waveguide couplers. While meta-optics enables unprecedented miniaturization and functionality, it also faces several remaining challenges. The authors suggest potential technological directions to address such issues. By surveying recent progress and design strategies, this review provides a comprehensive perspective on the role of meta-optics in advancing the optical engineering of next-generation AR/VR near-eye displays. Full article

Although epsilon-near-zero (ENZ) media have emerged as a promising platform for power dividers, the majority of existing designs are confined to fixed power splitting. In this work, two dynamically tunable power dividers using waveguide ENZ media are proposed by precisely modulating the internal magnetic field and the widths of the output waveguides. The first approach features a mechanically reconfigurable ring-shaped ENZ waveguide. By continuously re-distributing the magnetic field within the ENZ tunneling channels utilizing rotatable copper plates, arbitrary power division among multiple output ports is constructed. The second design integrates a rectangular-loop ENZ cavity into a substrate-integrated waveguide, with four positive–intrinsic–negative diodes embedded to dynamically activate specific output ports. This configuration steers electromagnetic energy toward output ports with varying cross-sectional areas, enabling on-demand control over both the power division and the number of output ports. Both analytical and full-wave simulation results confirm dynamic power division, with transmission efficiencies exceeding 93%. Despite differences in structure and actuation mechanisms, both designs exhibit flexible field control, high reconfigurability, and excellent transmission performance, highlighting their potential in advanced applications such as real-time wireless communications, multi-input–multi-output systems, and reconfigurable antennas. Full article

Electro-optic modulators in the near-infrared spectrum are finding applications in atomic clocks, quantum sensing, quantum information processing, and high-precision measurement. We developed thin-film lithium niobate electro-optic modulators operating at 795 nm for modulation around the D₁ line of ⁸⁷Rb with satisfactory overall performance. Specifically, we made a systematic improvement to reduce the insertion loss, including widening the modulation waveguides, thickening the overcladding, polishing and coating the facets. The fabricated device possesses a low insertion loss of 7.6 dB, an extinction ratio exceeding 30 dB, a 3 dB modulation bandwidth of ~22 GHz, a half-wave voltage-length product of ~1.8 Vcm, and strong adaptability for packaging. Full article

Time- and space-resolved radiation emitted by the plasma produced by a 0.8 ns duration at full width half maximum, ~600 MW maximum power microwave (~9.6 GHz) pulse traversing a hydrogen-, helium-, or air-filled circular waveguide, is studied. Gas ionization by microwaves is an old subject but the regime investigated in the present experimental research, of very high-power microwaves and very short pulses using modern diagnostic tools, is new and follows a series of new studies performed so far only in our laboratory, revealing non-linear phenomena never observed before. In the present research, plasma radiation is observed along a slit made in a circular waveguide wall by either an intensified fast frame camera or a streak camera. Using calibrated input and output couplers, the transmission and reflection coefficients of the high-power microwaves were determined over a broad range of gas pressures, 0.1 kPa < P < 90 kPa. It was found that the intensity of the plasma light emission increases significantly after the high-power microwave pulse has left the waveguide. Depending on pressure, the radiation is either uniform along the slit, while the front of the emitted light follows the microwave pulse at a velocity close to its group velocity, or it remains in the vicinity of the input window, indicating that the plasma density is above critical density. It was also found that the radial distribution of radiation depends on pressure. At pressures <10 kPa, when the electron oscillatory energy reaches 20 keV close to the waveguide axis, light emission forms faster near the waveguide walls, where the ionization rate is maximal. Otherwise, when pressure is >80 kPa, light emission is most intense on the axis where the electron oscillatory energy is ~100 eV and the ionization rate is maximal. We also studied the UV radiation from the plasma, the duration of which was found to be longer than the duration of visible light emission. This indicates the existence of energetic electrons for tens of ns after the high-power microwave pulse has left the observation region. Considering that the emitted light intensity depends on the plasma density and temperature, the observed data may be used for a comparison with the results of collisional radiative models if the electron time and spatial energy distribution is known. Full article

We present a compact dielectric lens integrated at the aperture of a WR90 rectangular waveguide, achieved using polytetrafluoroethylene (PTFE). This innovative configuration enables, for the first time in the X- and Ku-bands, the direct generation of a subwavelength electromagnetic jet from a guided structure. The beam exhibits the hallmark features of an electromagnetic jet: strong near-field focusing, a subwavelength beam width surpassing the diffraction limit, and a quasi-planar wavefront sustained over a propagation distance of about $2\lambda$. The lens design was systematically optimized, and its performance was assessed through full-wave finite element simulations and experimentally validated on a fabricated prototype. Excellent agreement between the simulation and measurement confirms the robustness of the approach. Beyond its simplicity and low cost, this solution achieves state-of-the-art focusing performance compared to free-space and guided-wave alternatives. It offers strong potential for applications in high-resolution imaging, precision sensing, and material characterization, particularly in opaque or highly lossy environments. Full article

A directly coupled waveguide uni-traveling carrier photodetector (UTC-PD) with high responsivity and broad bandwidth is demonstrated. The device’s epitaxial structure was carefully optimized via optical simulations to enhance quantum efficiency. Furthermore, the fabrication process was refined to introduce a vertically defined mushroom-shaped mesa structure, which effectively maintains high responsivity while facilitating further improvement in bandwidth performance. As a result, the fabricated device, without the use of an anti-reflection coating, simultaneously achieves a responsivity of 0.49 A/W and a 3 dB bandwidth of 90 GHz. Full article

Narrow-linewidth broadband tunable external cavity diode lasers (NBTECDLs), with their broadband tuning range, narrow linewidth, high side-mode suppression ratio (SMSR), and high output power, have become important laser sources in many fields such as optical communication, spectral analysis, wavelength division multiplexing systems, coherent detection, and ultra-high-speed optical interconnection. This paper briefly describes the basic theory of NBTECDLs, introduces NBTECDLs with diffraction grating type, fiber Bragg grating (FBG) type, and waveguide type, and conducts an in-depth analysis on the working principles and performance characteristics of NBTECDLs based on different NBTECDL types. Then, it reviews the latest research progress on Littrow-type, Littman-type, FBG-type, and waveguide-type NBTECDLs in detail and compares and summarizes the characteristics of Littrow-type NBTECDLs, Littman-type NBTECDLs, FBG-type NBTECDLs, and waveguide-type NBTECDLs. Finally, it looks at the structural features, key technologies, optical performance, and application fields of the most cutting-edge research in recent years and summarizes the challenges and future development directions of NBTECDLs. Full article

In mode-locked fiber lasers and optical sensors, in-line filters are essential components. Fiber-core Mach–Zehnder interferometer (MZI) technology has garnered a lot of research interest for the several manufacturing techniques for in-line MZI filters. Although multi-line inscription is frequently needed in existing methods to attain enough waveguide width, this approach adds complexity to production and may result in compromised waveguide quality. In this work, we present an improved single-line direct-writing method that attains similar MZI filtering results to multi-line scan. Additionally, the MZI filter created with the modified single-line direct-writing technique has a smaller insertion loss and requires less direct-writing energy than the previous single-line direct-writing technique. A 516 μm long MZI-based in-line filter was successfully constructed. The results of the characterization showed a central loss dip at 1089.82 nm, a free-spectral range (FSR) of 141.36 nm, an extinction ratio of 19.69 dB, and an insertion loss of 1.122 dB. This method decreased the insertion loss by a factor of 2.7 for an identical extinction ratio and improved the direct-writing efficiency by a factor of 9 for an equivalent FSR with multi-line scan. There was consistency between the experimental and simulation results. We also took measurements of the MZI’s temperature sensitivity. This work shows notable improvements in waveguide quality and ease of manufacture. This accomplishment lays the groundwork for further advancements in integrated mode-locked fiber laser technology. Full article

This paper presents the design and implementation of a wideband diode-based down-converter operating from 60 to 90 GHz with a variable flat conversion gain. The proposed down-converter is implemented utilizing the Miniature Hybrid-Microwave Integrated Circuit (MHMIC) technology. It is composed of a wideband double-balanced mixer, a Local Oscillator (LO) chain, and a differential TransImpedance Amplifier (TIA) with a variable gain. The designed mixer uses a novel topology exhibiting minimum reflection and high isolation between the RF and LO ports across a wide operating frequency of 30 GHz. In this topology, two balanced detectors generate the differential IF signal with minimum reflection. The characteristic impedance ($Z_0$) of the mixer is set to be $70.7$$\Omega$, to minimize trace widths to reduce the mutual coupling and increasing the bandwidth. The OPA 657 is the core of the designed differential TIA with a variable gain. In addition, the LO chain of the down-converter utilized a combination of an active (×2) and a passive (×3) multiplier to generate enough RF power in the desired frequency range. Also, a WR-12 waveguide to Substrate Integrated Waveguide (SIW) transition is designed for the RF and LO ports that operates through the E-band. The proposed down-converter demonstrates excellent performance, with a high isolation between RF and LO ports exceeding 22 dB and a maximum conversion gain of $-5$ dB, and a response with a variation of ±5 dB across the band. The proposed mixer exhibits a return loss of better than 10 dB at both RF and LO ports, and it consumes a power of 560 mW. Full article

This paper investigates quiescent solitons in optical fibers and crystals, modeled by the complicated Ginzburg–Landau equation incorporating nonlinear chromatic dispersion and six self-phase modulation structures introduced by Kudryashov. The model is formulated with linear temporal evolution and analyzed using Lie symmetry methods. The study also identified parameter constraints under which solutions exist. Full article

The traditional research methods of the notch frequency phenomenon are mainly discussed by experimental observation or the semi-analytical finite element method. In this paper, the notch frequency characteristics of ultrasonic guided waves are simulated by the general finite element method. Firstly, the theoretical dispersion curve of the longitudinal mode in the axially loaded rod is derived by the acoustic elasticity theory, and the finite element simulation is carried out by ABAQUS/Explicit 6.14 to simulate the wave propagation in the seven-wire steel strand. In order to verify the model, laboratory experiments are carried out on three types of prestressed steel strands with diameters of 12.7 mm, 15.2 mm, and 17.8 mm, respectively. Each specimen is gradually loaded from 50 kN to 110 kN in increments of 30 kN. At each loading level, the ultrasonic signal is obtained, and the corresponding notch frequency is extracted from the spectrum. The experimental results confirm the accuracy of the model, and the maximum deviation between the predicted notch frequency and the measured value is 3%. The results show that the proposed method provides a robust and non-destructive means for structural health monitoring in civil engineering applications, and has the potential to be more widely used in complex waveguide structures. Full article

The TECSL has attracted much attention due to its wide tuning range, narrow linewidth, high output power, and excellent SMSR. It holds irreplaceable value in optical communication, spectroscopy analysis, and biomedical applications. The demand for a wide tuning range, high power, narrow linewidth, and a high SMSR has driven the development of high-performance TECSL structures. This paper comprehensively discusses five key TECSL structures: Littrow-type structures, Littman-type structures, filter-type structures, fiber-type structures, and waveguide-type structures, and elaborates on their structures and principles. This paper reviews the research process of different type-structure TECSLs, analyzes the advantages and disadvantages of different external cavity structures, and explores the future development trends of TECSLs. The review shows that the Littrow-type structure TECSL achieved an extremely wide tuning range using diffraction gratings, reaching up to 360 nm. The Littman-type structure TECSL demonstrated excellent spectral purity, achieving an SMSR of 71.03 dB. The filter-type structure TECSL was able to achieve flexible wavelength selection using tunable filters, achieving a linewidth of 570 Hz. The fiber-type structure TECSL has a linewidth of up to 600 Hz. The waveguide-type structure TECSL can achieve a linewidth as low as 0.252 kHz and a tuning range of up to 120.9 nm. Full article

Waveguide-integrated metasurfaces offer a promising platform for ultracompact on-chip optical systems, enabling applications such as fluorescence sensing, holography, and near-eye displays. In particular, integrated achromatic metalenses that couple guided modes to free-space radiation are highly desirable for single-molecule fluorescence sensing, where high numerical aperture (NA), efficient light focusing, and consistent focal volume overlap across excitation and emission wavelengths are critical. However, designing integrated high-NA metalenses with multi-wavelength operation remains fundamentally challenging due to the wavelength-dependent propagation of guided modes. Here, we present an inverse design framework that simultaneously optimizes the geometries and positions of silicon nitride nanofins atop a slab waveguide to achieve diffraction-limited focusing at three wavelengths with unity NA. The resulting metalens outperforms conventional segmented designs in focusing efficiency and sidelobe suppression, particularly at wavelengths corresponding to the excitation and emission bands of the model fluorophore Alexa Fluor 647. Numerical analysis shows that the design yields a high molecule detection efficiency suitable for epi-fluorescence single-molecule sensing. This work highlights the potential of inverse-designed metalenses as a versatile on-chip platform for advanced applications in fluorescence spectroscopy, augmented reality, or optical trapping. Full article

In this work, we present a wideband on-wafer characterization technique for InAlAs/InGaAs/InAs InP-based high-electron mobility transistors (HEMTs) using an optimized multiline Thru-Reflect-Line (mTRL) calibration kit. Our goal is to directly extract transition frequency f_T and maximum frequency of oscillation f_max values from S-parameters measurements with frequencies up to 1.1 THz and overcome the limitations of the traditional 20 dB/dec extrapolation method using lower-frequency band measurements. Indeed, as the state-of-the-art transistors now exhibit cutoff frequencies exceeding 1 THz, standard low-frequency extrapolation methods become increasingly inaccurate. Full-wave electromagnetic simulations were used to design low-loss coplanar waveguide (CPW) access structures with stable impedance and minimal parasitic effects. These structures were co-fabricated with HEMTs and calibration standards on the same InP substrate. The 2-finger transistor with a 80 nm gate length exhibits a directly measured f_T = 320 GHz and f_max = 800 GHz. The technique showed high consistency across six frequency bands and confirms that direct broadband measurement with mTRL improves accuracy. This work highlights the metrological strength of mTRL-based setups for next-generation THz device characterization. Full article

The monitoring of gases and vapors using portable instruments is critical in a variety of fields, such as industrial and household safety, environmental monitoring, process control, and national security, owing to gas pollution. In this study, we design a portable and simple two-dimensional photonic crystal microcavity sensor for detecting gases such as ammonia, methane, carbon monoxide, acetylene, ethylene, and ethane. The basic structure of the sensor consists of silicon rods arranged in a square lattice pattern in air. Waveguide input and output channels are realized by engineering line defects within the lattice structure. Moreover, the sensor’s performance is continuously optimized by adding point defects, introducing a ring cavity, and varying the radius of the dielectric rods in the microcavity. Using the transmission spectrum obtained from the output waveguide, the performance parameters of the gas sensor are calculated. Based on the simulation analysis, the optimized gas sensor exhibits excellent performance, achieving a sensitivity S of 932.43 nm/RIU and a quality factor Q of 2421.719. Full article
