A special issue of Micromachines (ISSN 2072-666X). This special issue belongs to the section "D：Materials and Processing".

Deadline for manuscript submissions: 31 December 2024 | Viewed by 9150

Share This Special Issue

Special Issue Editor

Dr. Chen Li

E-Mail Website
Guest Editor

School of Mechatronics Engineering, Harbin Institute of Technology, Harbin 150001, China
Interests: ultra-precision machining; grinding; cutting; nanoscratch; brittle material

Special Issue Information

Dear Colleagues,

Difficult-to-machine materials, such as semiconductor, laser crystal, engineering ceramics, optical glass, superalloys, and composite materials, have been widely used in aerospace, 5G networks, and new energy vehicles owing to their excellent mechanical properties and steady chemical properties. For these advanced applications, these materials must be shaped into smooth substrates with high surface integrity using precision and ultra-precision machining technologies such as grinding, lapping, polishing, cutting, etc. However, these materials have high brittleness, high hardness, and high elasticity which pose great challenges for efficient machining. Severe surface and subsurface damage and cutting tool wear are easily generated during the machining process, which inevitably shortens the accuracy and service life of the components and increases the production costs. Understanding the mechanical properties, revealing the damage evolution and material removal mechanism in micro- and nanoscales, exploring innovative machining technology, and optimizing machining process parameters are of great significance to realize the high-efficiency and precision machining of difficult-to-machine materials. This collection aims at summarizing the frontier research on processing and surface integrity characterization of difficult-to-machine materials. The scope of this Special Issue includes but is not limited to:

Precision machining technology of difficult-to-machine materials, such as grinding, polishing, lapping, cutting, etc.;
In-depth characterization to reveal damage evaluation and removal behaviors that involved in machining processes;
Numerical simulation of the material deformation and removal process;
Surface engineering when it relates specifically to a manufacturing process;
Design of cutting tools.

Dr. Chen Li
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Micromachines is an international peer-reviewed open access monthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

ultra-precision machining
grinding
polishing
cutting
nanoscratch
material removal mechanism
difficult-to-machine material
brittle material

Benefits of Publishing in a Special Issue

Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (7 papers)

Download All Papers

Order results

Result details

Show export options Show export options

Select all

Export citation of selected articles as:

Research

16 pages, 12794 KiB

Open AccessArticle

Understanding the Processing Quality Problem for Cutting Ceramic Materials Using the Thermal-Controlled Fracture Method Induced by a Single-Surface Heat Source

by Xiaoliang Cheng, Zhenzhen Cui, Junwen Chen, Yang Wang and Lijun Yang

Micromachines 2024, 15(8), 957; https://doi.org/10.3390/mi15080957 - 26 Jul 2024

Viewed by 550

Abstract

The thermal-controlled fracture method has been increasingly focused upon in the high-quality cutting of advanced ceramic materials due to its excellent characteristics. The successful application of this method in cutting ceramics mainly depends on the volumetric heating effect. However, most ceramics are treated using the surface heating mode. For the surface heating mode, the processing quality, including fracture trajectory and fracture quality, is far lower than the industrial application standards. This work was conducted to reveal the mechanism of this processing quality. Experiments involving cutting ceramics in single-surface heating mode indicate that the fracture trajectories of the upper and lower surfaces display a significant inconsistency, and the fracture quality is worse than that using the dual-surface heating mode. A cutting model was established to calculate the thermal stress distribution and to simulate the crack-propagation behaviors. The simulation results show good agreement with the experiment and provide the stress distribution, and are used to understand the reason for the processing quality problem. The mechanism of the trajectory deviation and uneven distribution of the fracture quality is revealed based on the simulation and calculation results. This study helps provide a deep understanding of the processing problems arising from this method and thus helps to innovate high-quality processing methods in this field. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

14 pages, 3071 KiB

Open AccessArticle

Experimental Study on Chemical–Mechanical Synergistic Preparation for Cemented Carbide Insert Cutting Edge

by Changjiang Qin, Jian Pan, Lei Guo, Chi Zhang, Wanli Chen, Zihua Hu, Shengqiang Jiang, Xiaogao Chen and Meijiao Mao

Micromachines 2024, 15(1), 17; https://doi.org/10.3390/mi15010017 - 21 Dec 2023

Cited by 1 | Viewed by 917

Abstract

Typical edge defects in the edge region of a new cemented carbide insert without edge preparation include burrs, poor surface quality, micro-breakages, and irregularities along the edge. To address the problems in new cemented carbide inserts without edge preparations, a chemical–mechanical synergistic preparation (CMSP) method for the cemented carbide insert cutting edge was proposed. Firstly, the CMSP device for the insert cutting edge was constructed. Then, the polishing slurry of the CMSP for the insert cutting edge was optimized using the Taguchi method combined with a grey relation analysis and fuzzy inference. Finally, orthogonal experiments, the Taguchi method, and analysis of variance (ANOVA) were used to investigate the effect of the polishing plate’s rotational speed, swing angle, and input frequency of the controller on the edge preparation process, and the parameters were optimized. The results showed that the best parameter combination for the polishing slurry for the cemented carbide inserts was the mass concentration of the abrasive particle of 10 wt%, the mass concentration of the oxidant of 10 wt%, the mass concentration of the dispersant of 2 wt%, and the pH of 8. The CMSP process parameter combination for the linear edge had the polishing plate’s rotational speed of 90 rpm, the swing angle of 6°, and the input frequency of the controller of 5000 Hz. The optimum CMSP process parameter combination for the circular edge had the polishing plate’s rotational speed of 90 rpm, the swing angle of 6°, and the input frequency of the controller of 7000 Hz. The polishing plate’s rotational speed had the most significant impact on the edge preparation process, followed by the swing angle, and the effect of the input frequency of the controller was the smallest. This study demonstrated that CMSP is a potential way to treat the cemented carbide insert cutting edge in a tool enterprise. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

17 pages, 10107 KiB

Open AccessArticle

Investigation of Surface Integrity Induced by Ultra-Precision Grinding and Scratching of Glassy Carbon

by Kirk Jahnel, Robert Michels, Dennis Patrick Wilhelm, Tim Grunwald and Thomas Bergs

Micromachines 2023, 14(12), 2240; https://doi.org/10.3390/mi14122240 - 14 Dec 2023

Cited by 2 | Viewed by 1240

Abstract

Glassy carbon provides material characteristics that make it a promising candidate for use as a mould material in precision glass moulding. However, to effectively utilize glassy carbon, a thorough investigation into the machining of high-precision optical surfaces is necessary, which has not been thoroughly investigated. This research analyses the process of material removal and its resulting surface integrity through the use of nano-scratching and ultra-precision grinding. The nano-scratching process begins with ductile plastic deformation, then progresses with funnel-shaped breakouts in the contact zone, and finally concludes with brittle conchoidal breakouts when the cutting depth is increased. The influence of process factors and tool-related parameters resulting from grinding has discernible impacts on the ultimate surface roughness and topography. Enhancing the cutting speed during cross-axis kinematic grinding results in improved surface roughness. Increasing the size of diamond grains and feed rates leads to an increase in surface roughness. An achievable surface roughness of Ra < 5 nm together with ductile-regime grinding behaviour meet optical standards, which makes ultra-precision grinding a suitable process for optical surface generation. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

15 pages, 15918 KiB

Open AccessArticle

Influence of Diamond Wire Saw Processing Parameters on the Sawn Surface Characteristics of Silicon Nitride Ceramics

by Siyuan Zhang, Yufei Gao, Xingchun Zhang and Yufeng Guo

Micromachines 2023, 14(9), 1660; https://doi.org/10.3390/mi14091660 - 25 Aug 2023

Cited by 3 | Viewed by 1590

Abstract

For the slicing of superhard silicon nitride ceramics, diamond wire sawing technology has great potential for application, and its slicing surface characteristics are an important indicator of cutting quality. In this paper, the sawing experiments of silicon nitride ceramics were carried out within the range of industrial processing parameters of diamond wire sawing (saw wire speed: 800–1600 m/min, workpiece feed speed 0.1–0.4 mm/min). The effects of cutting parameters on the surface morphology, surface roughness and waviness of the as-sawn slices were analyzed. The results show that within the range of sawing parameters for industrial applications, the material on the diamond wire as-sawn surface of silicon nitride ceramics is removed mainly in a brittle mode, with the slice morphology showing brittle pits and regularly distributed wire marks in the 20–55 μm scale range. The surface roughness of the slices along the workpiece feed direction ranges from 0.27 to 0.38 μm and decreases with increasing saw wire speed and decreasing feed rate. The surface waviness ranges from 0.09 to 0.21 μm, which is in good agreement with the changing trend of the sliced-surface roughness. The results of the study provide an experimental reference for promoting the engineering application of diamond wire sawing technology to the processing of silicon nitride ceramic slices. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

17 pages, 10541 KiB

Open AccessArticle

Longitudinal–Torsional Ultrasonic Grinding of GCr15: Development of Longitudinal–Torsional Ultrasonic System and Prediction of Surface Topography

by Huan Zhang, Ying Niu, Xiaofeng Jia, Shuaizhen Chu and Jingjing Niu

Micromachines 2023, 14(8), 1626; https://doi.org/10.3390/mi14081626 - 17 Aug 2023

Cited by 1 | Viewed by 1090

Abstract

The common material of bearing rings is GCr15 bearing steel which is a typical difficult-to-machine material. As an important working surface of the bearing, the inner surface of the raceway plays a vital role in the performance of the bearing. As an important means to solve the high-performance manufacturing of difficult-to-machine materials, longitudinal–torsional ultrasonic processing is widely used in various types of processing. In the presented work, the basic size of the horn is obtained from the wave equation of the forced vibration, and the modal analysis and amplitude test are carried out to verify the rationality of the LUTG structure. Then, according to the probability density function of cutting thickness and the overlapping effect of adjacent abrasive trajectories, the LUTG surface topography prediction model is established by using the height formula of the surface residual material, and the model reliability is verified by using the orthogonal test. The error between the test results and the prediction model is within 13.2%. Finally, based on the response surface method, the optimal process parameters that can meet the requirements of low roughness (Ra) and high material removal rate (MRR) are screened, and the optimal combination of process parameters is obtained as follows:

A

= 4.5 μm,

n

= 6493.3 r/min,

a_{p}

= 28.4 μm, and

v_{f}

= 21.1 mm/min. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

19 pages, 188415 KiB

Open AccessArticle

Process Analysis and Topography Evaluation for Monocrystalline Silicon Laser Cutting-Off

by Fei Liu, Aiwu Yu, Chongjun Wu and Steven Y. Liang

Micromachines 2023, 14(8), 1542; https://doi.org/10.3390/mi14081542 - 31 Jul 2023

Cited by 3 | Viewed by 1383

Abstract

Due to the characteristics of high brittleness and low fracture toughness of monocrystalline silicon, its high precision and high-quality cutting have great challenges. Aiming at the urgent need of wafer cutting with high efficiency, this paper investigates the influence law of different laser processes on the size of the groove and the machining affected zone of laser cutting. The experimental results show that when laser cutting monocrystalline silicon, in addition to generating a groove, there will also be a machining affected zone on both sides of the groove and the size of both will directly affect the cutting quality. After wiping the thermal products generated by cutting on the material surface, the machining affected zone and the recast layer in the cutting seam can basically be eliminated to generate a wider cutting seam and the surface after wiping is basically the same as that before cutting. Increasing the laser cutting times will increase the width of the material’s machining affected zone and the groove width after chip removal. When the cutting times are less than 80, increasing the cutting times will increase the groove width at the same time; but, after the cutting times exceed 80, the groove width abruptly decreases and then slowly increases. In addition, the lower the laser scanning speed, the larger the width of the material’s machining affected zone and the width of the groove after chip removal. The increase in laser frequency will increase the crack width and the crack width after chip removal but decrease the machining affected zone width. The laser pulse width has a certain effect on the cutting quality but it does not show regularity. When the pulse width is 0.3 ns the cutting quality is the best and when the pulse width is 0.15 ns the cutting quality is the worst. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures

Figure 1

15 pages, 12051 KiB

Open AccessArticle

Investigation of Cutting Force and the Material Removal Mechanism in the Ultrasonic Vibration-Assisted Scratching of 2D-SiCf/SiC Composites

by Hao Lin, Ming Zhou, Haotao Wang and Sutong Bai

Micromachines 2023, 14(7), 1350; https://doi.org/10.3390/mi14071350 - 30 Jun 2023

Cited by 5 | Viewed by 1462

Abstract

Ultrasonic-assisted grinding (UAG) is widely used in the manufacture of hard and brittle materials. However, the process removal mechanism was never elucidated and its potential is yet to be fully exploited. In this paper, the mechanism of material removal is analyzed by ultrasonic-assisted scratching. Three distinct surfaces (S1, S2, and S3) were selected on the basis of the braided and laminated structure of fiber bundles. The ultrasonic-assisted scratching experiment is carried out under different conditions, and the scratching force (SF) of the tested surface will fluctuate periodically. Under the conditions of different feed speeds, depths, and ultrasonic amplitudes, the normal scratching force (SF_n) is greater than the tangential scratching force (SF_t), and the average scratching force on the three surfaces is generally S3 > S2 >S1. Among the three processing parameters, the speed has the most significant influence on the scratching force, while the scratching depth has little influence on the scratching force. Under the same conditions and surface cutting mode, the ultrasonic vibration-assisted scratching force is slightly lower than the conventional scratching force. The scratching force decreases first and then increases with the amplitude of ultrasonic vibration. Because the fiber undergoes a brittle fracture in the ultrasonic-assisted scratching process, the matrix is torn, and the surface residues are discharged in time; therefore, the surface roughness is improved. Full article

(This article belongs to the Special Issue Ultra-Precision Machining of Difficult-to-Machine Materials)

► Show Figures
