Recent Excellent Optoelectronic Applications Based on Two-Dimensional WS2 Nanomaterials: A Review

by
Changxing Li
,
Dandan Sang
*,
Shunhao Ge
,
Liangrui Zou
and
Qinglin Wang
*
Shandong Key Laboratory of Optical Communication Science and Technology, School of Physics Science and Information Technology, Liaocheng University, Liaocheng 252000, China
*
Authors to whom correspondence should be addressed.
Molecules 2024, 29(14), 3341; https://doi.org/10.3390/molecules29143341
Submission received: 5 June 2024 / Revised: 5 July 2024 / Accepted: 13 July 2024 / Published: 16 July 2024
(This article belongs to the Special Issue Materials for Emerging Electrochemical Devices)

Abstract

Tungsten disulfide (WS2) is a promising material with excellent electrical, magnetic, optical, and mechanical properties. It is regarded as a key candidate for the development of optoelectronic devices due to its high carrier mobility, high absorption coefficient, large exciton binding energy, polarized light emission, high surface-to-volume ratio, and tunable band gap. These properties contribute to its excellent photoluminescence and high anisotropy. These characteristics render WS2 an advantageous material for applications in light-emitting devices, memristors, and numerous other devices. This article primarily reviews the most recent advancements in the field of optoelectronic devices based on two-dimensional (2D) nano-WS2. A variety of advanced devices have been considered, including light-emitting diodes (LEDs), sensors, field-effect transistors (FETs), photodetectors, field emission devices, and non-volatile memory. This review provides a guide for improving the application of 2D WS2 through improved methods, such as introducing defects and doping processes. Moreover, it is of great significance for the development of transition-metal oxides in optoelectronic applications.
Keywords: WS2; optoelectronics; devices; nano; materials WS2; optoelectronics; devices; nano; materials
