Search Results (53)

Background/Objectives: Ocular wavefront aberrations are clinically relevant for optimizing vision correction and predicting surgical outcomes. This study aimed to establish normative reference ranges for a Korean population by quantifying wavefront aberrations using a Hartmann–Shack wavefront sensor and Zernike coefficients, and to assess correlations with age, sex, and spherical equivalent (SE). Methods: Wavefront aberrations were measured in 98 Koreans (196 eyes) using a Hartmann–Shack aberrometer without cycloplegia. Five repeated measurements per eye at a 6 mm pupil size were averaged. Parameters included Zernike coefficients (Z3–Z20), higher-order aberration (HOA) root mean square (RMS, Z6–Z20), and total RMS (Z3–Z20). Associations with age, sex, and SE were assessed using univariable and multivariable linear mixed-effects models. Second-order polynomial regression assessed nonlinear relationships. Interocular symmetry was evaluated using mirror-symmetry-adjusted Spearman’s correlation and intraclass correlation coefficients (ICCs). Results: Vertical coma (Z7, 0.208 ± 0.174 μm) and spherical aberration (Z12, 0.200 ± 0.161 μm) were the largest contributors to HOA RMS. Mean HOA RMS and total RMS were 0.51 ± 0.21 μm and 3.03 ± 2.51 μm, respectively. HOA RMS increased with age (β = 0.003 μm/year, p = 0.010), whereas total RMS decreased with SE (β = −0.678 μm/D, p < 0.001). Most Zernike coefficients showed positive interocular correlations, with ICCs of 0.75 for total RMS and 0.64 for HOA RMS. Conclusions: In normal Korean eyes, HOAs increased with age and exhibited significant interocular symmetry. Vertical coma and spherical aberration were predominant components. While the pattern was similar to that in Western populations, the absolute values were greater. These normative values may aid future wavefront-guided refractive surgery and presbyopia correction procedures. Full article

Atmospheric turbulence introduces distortions to the wavefront of propagating optical radiation. It causes image resolution degradation in astronomical telescopes and significantly reduces the power density of radiation on the target in focusing applications. The impact of turbulence fluctuations on the wavefront can be investigated under laboratory conditions using either a fan heater (roughly tuned), a phase plate, or a deformable mirror (finely tuned) as a turbulence-generation device and a wavefront sensor as a wavefront-distortion measurement device. We designed and developed a software simulator and an experimental setup for the reconstruction of atmospheric turbulence-phase fluctuations as well as an adaptive optical system for the compensation of induced aberrations. Both systems use two 60 mm, 92-channel, bimorph deformable mirrors and two tip-tilt correctors. The wavefront is measured using a high-speed Shack–Hartmann wavefront sensor based on an industrial CMOS camera. The system was able to achieve a 500 Hz correction frame rate, and the amplitude of aberrations decreased from 2.6 μm to 0.3 μm during the correction procedure. The use of the tip-tilt corrector allowed a decrease in the focal spot centroid jitter range of 2–3 times from ±26.5 μm and ±24 μm up to ±11.5 μm and ±5.5 μm. Full article

The wavefront aberrations (WAs) of a laser beam produced by an optical parametric oscillator (OPO) have been measured using a Hartmann–Shack sensor. The OPO tuning operation requires changes in the device that might affect the shape of the wavefront beam as the illumination wavelength is being modified. Different output wavelengths in the range 550–850 nm were systematically analyzed in terms of WAs. The WA laser beam was fairly stable with time (changes of about 1%), independently of the wavelength. Moreover, WAs were non-negligible and nearly constant between 600 and 800 nm, but they noticeably increased for 550 (~90%) and 850 nm (~50%), mainly due to a higher astigmatism influence. The contributions of other higher-order terms such as coma and spherical aberration also present particular spectral dependences. To our knowledge, this is the first report of a spectral OPO laser beam characterization in terms of optical aberrations. It addresses a gap in OPO laser characterization of WAs and offers actionable insights for multi-wavelength applications. These results might be useful in applications ranging from micromachining procedures to biomedical imaging, where an optimized focal spot is required to increase the efficiency of certain physical phenomena or to enhance the quality of the acquired images. Full article

Free Space Optical Communication (FSOC) is a wireless communication method that utilizes laser beams for high speed and secure data transmission. Its performance is affected by various factors, among which atmospheric turbulence causes random fluctuations in the atmospheric refractive index, significantly impacting the reliability of communication links. The atmospheric coherence length is a key parameter describing the coherence properties of a laser signal as it propagates through the atmosphere, and accurately measuring it is crucial for assessing the quality of FSOC links. This paper proposes a novel strategy that utilizes extended sources directly as the information sources, combining the wavefront phase variance method with the extended source offset algorithm based on Shack–Hartmann wavefront sensors to directly measure atmospheric coherence length. Existing methods in extended scenarios typically rely on deploying laser beacons to aid in the calibration of atmospheric coherence length but setting up suitable beacons on horizontal communication links is challenging. Additionally, these approaches can be costly in terms of equipment and measurement expenses. Compared to traditional measurement methods, the algorithm proposed in this paper can measure directly based on extended scenarios in horizontal links, thereby effectively reducing system complexity and equipment costs. To verify the feasibility and effectiveness of this method, targeted simulations and experiments were conducted, and the results show that the coherence length measured by the algorithm is highly consistent with that measured by the Differential Image Motion Monitor (DIMM), with a deviation of less than 2% from actual values, effectively demonstrating the algorithm’s feasibility in coherence length assessment. Full article

Shack–Hartmann wavefront sensors (SHWFSs) are crucial for detecting distortions in adaptive optics systems, but the accuracy of wavefront reconstruction is often hampered by low guide star brightness or strong atmospheric turbulence. This study introduces a new method of using the Vision Transformer model to process image information from SHWFSs. Compared with previous traditional methods, this model can assign a weight value to each subaperture by considering the position and image information of each subaperture of this sensor, and it can process to obtain wavefront reconstruction results. Comparative evaluations using simulated SHWFS light intensity images and corresponding deformable mirror command vectors demonstrate the robustness and accuracy of the Vision Transformer under various guide star magnitudes and atmospheric conditions, compared to convolutional neural networks (CNNs), represented in this study by Residual Neural Network (ResNet), which are widely used by other scholars. Notably, normalization preprocessing significantly improves the CNN performance (improving Strehl ratio by up to 0.2 under low turbulence) while having a varied impact on the Vision Transformer, improving its performance under a low turbulence intensity and high brightness (Strehl ratio up to 0.8) but deteriorating under a high turbulence intensity and low brightness (Strehl ratio reduced to about 0.05). Overall, the Vision Transformer consistently outperforms CNN models across all tested conditions, enhancing the Strehl ratio by an average of 0.2 more than CNNs. Full article

A pulsed detonation chamber (PDC) equipped with Hartmann–Sprenger resonators has been designed and tested for both Hydrogen/air and Hydrogen/Oxygen mixtures. A full-factorial experimental campaign employing four factors with four levels each has been carried out for both mixtures. Instantaneous static pressure has been measured at two locations on the exhaust pipe of the PDC, and the signal has been processed to extract the average and maximum cycle pressures and the operating frequency of the spark plug. The PDC has been shown to be able to reach sustained detonation cycles over a length below 200 mm, measured from the spark plug to the first pressure sensor. The optimal regimes for both air and Oxygen operation have been determined, and the influence of the four factors on the responses is discussed. Full article

Atmospheric turbulence characteristics are essential in determining the quality of astronomical images and implementing adaptive optics systems. In this study, the vertical distributions of optical turbulence at the Peak Terskol observatory (43.27472°N 42.50083°E, 3127 m a.s.l.) using the Era-5 reanalysis and scintillation measurements are investigated. For the closest reanalysis grid node to the observatory, vertical profiles of the structural constant of the air refractive index turbulent fluctuations $C_n^2$ were obtained. The calculated $C_n^2\left(z\right)$ vertical profiles are compared with the vertical distribution of turbulence intensity obtained from tomographic measurements with a Shack–Hartmann sensor. The atmospheric coherence length at the location of Terskol Peak was estimated. Using a combination of atmospheric models and paramaterization schemes of turbulence, $C_n^2\left(z\right)$ profiles at Mt. Kurapdag were obtained. The values of atmospheric coherence length at Peak Terskol are compared with estimated values of this length at the ten astronomical sites, including Ali, Lenghu and Daocheng. Full article

An analysis of the features of measurements and correction of phase distortions in optical waves propagating in the atmosphere at various levels of turbulence was performed. It is shown that with increasing intensity fluctuations, the limiting capabilities of phase correction decrease, and the phase of an optical wave that has passed through a turbulence layer consists of two components: potential and vortex. It was found that even in the region of weak fluctuations there is an overlap of spectral filtering functions for intensity and phase fluctuations. Areas of turbulence inhomogeneities have been identified that will have mutual influence and negatively affect the operation of the phase meter. It is noted that correlation functions, both phase and intensity, are less susceptible to this compared to structural functions. The results of experimental studies on the reconstruction of the wavefront of laser radiation distorted by atmospheric turbulence using a Shack–Hartmann wavefront sensor during vignetting and central screening of the entrance pupil in the optical system are presented. Studies have been carried out on the propagation of laser radiation along a horizontal atmospheric path for various levels of turbulence. The results are analyzed in terms of Zernike polynomials. Full article

The Shack–Hartmann wavefront sensor (SHWFS) is widely utilized for ocular aberration measurement. However, large ocular aberrations caused by individual differences can easily make the spot move out of the range of the corresponding sub-aperture in SHWFS, rendering the traditional centroiding method ineffective. This study applied a novel convolutional neural network (CNN) model to wavefront sensing for large dynamic ocular aberration measurement. The simulation results demonstrate that, compared to the modal method, the dynamic range of our method for main low-order aberrations in ocular system is increased by 1.86 to 43.88 times in variety. Meanwhile, the proposed method also has the best measurement accuracy, and the statistical root mean square (RMS) of the residual wavefronts is 0.0082 ± 0.0185 $\lambda$ (mean ± standard deviation). The proposed method generally has a higher accuracy while having a similar or even better dynamic range as compared to traditional large-dynamic schemes. On the other hand, compared with recently developed deep learning methods, the proposed method has a much larger dynamic range and better measurement accuracy. Full article

Achieving a high-quality wavefront sensing light spot and accurate wavefront estimation of the rat eye is still challenging due to its large ocular aberrations and the back reflections from fundus multilayer. Simulation and experiments of rat eye wavefront sensing are conducted to improve the quality of sensing spot for accurate wavefront estimation. The simulation results show that a smaller pupil diameter leads to a high quality of wavefront sensing light spot, and the model rat eye reaches diffractive limitation when the pupil diameter is 0.8 mm. However, the experimental results indicate a different conclusion. Consistent with the simulation results, the quality of the sensing light spot significantly improves when the pupil diameter decreases from 3.6 mm to 1.8 mm. The full width at half maximum (FWHM) of the sensing light spots decreases from 77.36 ± 8.95 μm to 26.78 ± 3.25 μm, and the calculated Strehl ratio increases from 0.007 to 0.396. As the pupil diameter continues to decrease to 1.2 mm, the sensing spot and calculated Strehl ratio continue to improve, while the detected low-order aberrations exhibit a significant increase in both value and variance. This observation suggests that using a half-filled pupil for rat wavefront detection may be a more favorable choice, which assists in obtaining high-resolution retinal images in the rat eye using adaptive optics technology. Full article

This paper presents a real-time implementation of a hybrid connected component labeling method for processing the Shack–Hartmann wavefront sensor’s images for an adaptive optics (AO) system. The output image of a wavefront sensor is an image of spots. During the sensor’s operation, it can happen that highly distorted wavefronts (WF) may cause the spots to shift outside of their sub-aperture, which may lead to the reduction of the AO system performance. This article explains the benefits of high-performance computing and parallel processing of a field programmable gate array (FPGA). The objective is to calculate the centroids of these spots. A hybrid labeling method was investigated to fulfill this purpose. First, this method was implemented using a forward and backward scan with a respective mask for each scan. Additionally, a relabeling process is applied after labeling each line, and it is carried out in both directions. After labeling, several processing units were implemented in parallel to calculate centroids. Each unit is responsible for calculating the centroid of one label. The system runs in real time with a latency of one frame, which means the output image is a fusion of a current frame and the centroids of the previous frame. Forward and backward labeling requires a large amount of memory, which is the reason for limiting the investigation to forward labeling only. The forward labeling was successfully implemented, and the centroids were detected under minimum spot distortion conditions. This forward labeling implementation also runs in real time with significant latency reduction to calculate the centroids, which leads to minimizing the overall AO system latency, enabling faster computation and correction in addition to reducing the memory usage to 1% when compared to the forward and backward labeling usage of 81% as an advantage for the hardware implementation. Full article

This work focused on the experimental characterization of a complex flow structure behind a cross-flow array of cylindrical pins installed on the wall of a supersonic duct. This geometry simulates several common gas dynamic configurations, such as a supersonic mixer, a turbulence-generating grid, or, to some extent, a grid fin. In this work, the instrumentation employed is essentially non-intrusive, including spanwise integrating techniques such as (1) fast schlieren visualization and (2) Shack–Hartmann wavefront sensors; and planar techniques, namely (3) acetone Mie scattering and (4) acetone planar laser-induced fluorescence. An analysis of the data acquired by these complementary methods allowed the reconstruction of a three-dimensional portrait of supersonic flow interactions with a discrete pin array, including the shock wave structure, forefront separation zone, shock-induced separation zone, shear layer, and the mixing zone behind the pins. The main objective of this activity was to use various visualization techniques to acquire essential details of a complex compressible flow in a wide range of temporal–spatial scales. Particularly, a fine structure in the supersonic shear layer generated by the pin tips was captured by a Mie scattering technique. Based on the available publications, such structures have not been previously identified or discussed. Another potential outcome of this work is that the details revealed could be utilized for adequate code validation in numerical simulations. Full article

Optical satellite communications (OSC) downlinks can support much higher bandwidths than radio-frequency channels. However, atmospheric turbulence degrades the optical beam wavefront, leading to reduced data transfer rates. In this study, we propose using reinforcement learning (RL) as a lower-cost alternative to standard wavefront sensor-based solutions. We estimate that RL has the potential to reduce system latency, while lowering system costs by omitting the wavefront sensor and low-latency wavefront processing electronics. This is achieved by adopting a control policy learned through interactions with a cost-effective and ultra-fast readout of a low-dimensional photodetector array, rather than relying on a wavefront phase profiling camera. However, RL-based wavefront sensorless adaptive optics (AO) for OSC downlinks faces challenges relating to prediction latency, sample efficiency, and adaptability. To gain a deeper insight into these challenges, we have developed and shared the first OSC downlink RL environment and evaluated a diverse set of deep RL algorithms in the environment. Our results indicate that the Proximal Policy Optimization (PPO) algorithm outperforms the Soft Actor–Critic (SAC) and Deep Deterministic Policy Gradient (DDPG) algorithms. Moreover, PPO converges to within $86\%$ of the maximum performance achievable by the predominant Shack–Hartmann wavefront sensor-based AO system. Our findings indicate the potential of RL in replacing wavefront sensor-based AO while reducing the cost of OSC downlinks. Full article

Adaptive Optics (AO) technology is an effective means to compensate for wavefront distortion, but its inherent delay error will cause the compensation wavefront on the deformable mirror (DM) to lag behind the changes in the distorted wavefront. Especially when the change in the wavefront is higher than the Shack–Hartmann wavefront sensor (SHWS) sampling frequency, the multi-frame delay will seriously limit its correction performance. In this paper, a highly stable AO prediction network based on deep learning is proposed, which only uses 10 frames of prior wavefront information to obtain high-stability and high-precision open-loop predicted slopes for the next six frames. The simulation results under various distortion intensities show that the prediction accuracy of six frames decreases by no more than 15%, and the experimental results also verify that the open-loop correction accuracy of our proposed method under the sampling frequency of 500 Hz is better than that of the traditional non-predicted method under 1000 Hz. Full article

Atmospheric turbulence causes refractive index fluctuations, which in turn introduce extra distortions to the wavefront of the propagated radiation. It ultimately degrades telescope resolution (in imaging applications) and reduces radiation power density (in focusing applications). One of the possible ways of researching the impact of turbulence is to numerically simulate the spectrum of refractive index fluctuations, to reproduce it using a wavefront corrector and to measure the resultant wavefront using, for example, a Shack–Hartmann sensor. In this paper, we developed turbulence simulator software that generates phase screens with Kolmogorov spectra. We reconstructed the generated set of phase screens using a stacked-actuator deformable mirror and then compensated for the introduced wavefront distortions using a bimorph deformable mirror. The residual amplitude of the wavefront reconstructed by the 19-channel stacked-actuator mirror was 0.26 λ, while the residual amplitude of the wavefront compensated for by the 32-channel bimorph mirror was 0.08 λ. Full article
