Ultra-High Performance Concrete (UHPC), characterized by its superior mechanical properties and excellent durability, has emerged as a promising material for the repair and reinforcement of tunnels. This study aimed to clarify the reinforcement mechanism of UHPC for tunnel linings and the improvement in bearing capacity through numerical simulation and theoretical derivation. By simulating normal concrete (NC) and reinforced concrete (RC) eccentrically loaded columns under varying reinforcement configurations and working conditions, the study investigated the failure modes and mechanical behaviors of UHPC-reinforced tunnels. Analytical equations for the compression-bending capacity of UHPC-reinforced columns under secondary loading were established and validated. Subsequently, the influence of key parameters was systematically analyzed. The results show that UHPC reinforcement significantly enhances load-bearing capacity, deformation resistance, stiffness, and ductility, albeit with varying failure modes. Notably, the ultimate load-carrying capacity increases by up to 184.6% for NC columns at 180 mm eccentricity and 286.5% for RC columns at 200 mm eccentricity. Reinforcement effectiveness is highly influenced by eccentricity: inner-side reinforcement proves more advantageous under small eccentricities, whereas outer-side reinforcement outperforms under large eccentricities. Comparative analyses of various parameters reveal that initial strain has the greatest impact on reinforcement effectiveness, followed by UHPC thickness, UHPC strength, and the reinforcement ratio of the reinforcement layer, in descending order of influence. The research provides valuable insights into the application of UHPC in tunnel reinforcement, offering a reliable theoretical and numerical basis for engineering design. Full article

To address the problems of the lining cracking and spalling in tunnel structures in coastal areas under the influence of special geological conditions, environmental loading, and the coupling effect of chemical erosion, hybrid fibers were introduced to fly ash concrete in this study. The working performance, compressive strength, split tensile strength, and flexural strength of the hybrid fiber fly ash concrete were tested. A chloride diffusion coefficient under steady-state conditions and a durability test for resistance to sulfate corrosion were carried out. Thus, in-depth analyses of the comprehensive performance of the hybrid fiber fly ash concrete used for the tunnel lining were carried out and the damage mechanism was explored. The results showed that the hybrid fiber fly ash concrete exhibited higher strength compared to the concrete in the control group. However, when the fibers exceeded a certain dosage, the reduction in the working properties of the concrete structure led to the creation of larger pores in the matrix structure, which in turn affected the mechanical properties of the concrete. The most significant reduction in the chloride diffusion coefficient was observed when both steel fibers and coconut fibers were added at a 1.0% volumetric parameter, compared to the control group. The apparent state and compressive strength after sulfate corrosion were also minimally affected. This study ensured that the mechanical properties of the concrete were improved and the corrosion resistance of the matrix also substantially improved, providing a scientific basis for improving the performance of tunnel lining concrete, and confirming that steel–coconut hybrid fiber fly ash concrete has a great potential to improve the structural load-bearing capacity and durability, which may provide theoretical support for its continued use in tunneling projects and construction processes. Full article

The Global Navigation Satellite System (GNSS) is widely used for its high accuracy, wide coverage, and strong real-time performance. However, limited by the navigation signal mechanism, satellite signals in urban canyons, bridges, tunnels, and other environments are seriously affected by non-line-of-sight and multipath effects, which greatly reduce positioning accuracy and positioning continuity. In order to meet the positioning requirements of human and vehicle navigation in complex environments, it was necessary to carry out this research on the integration of multiple signal sources. The Fifth Generation (5G) signal possesses key attributes, such as low latency, high bandwidth, and substantial capacity. Simultaneously, 5G Base Stations (BSs), serving as a fundamental mobile communication infrastructure, extend their coverage into areas traditionally challenging for GNSS technology, including indoor environments, tunnels, and urban canyons. Based on the actual needs, this paper proposes a system algorithm based on 5G and GNSS joint positioning, aiming at the situation that the User Equipment (UE) only establishes the connection with the 5G base station with the strongest signal. Considering the inherent nonlinear problem of user position and angle measurements in 5G observation, an angle cosine solution is proposed. Furthermore, enhancements to the Sage–Husa Adaptive Kalman Filter (SHAKF) algorithm are introduced to tackle issues related to observation weight distribution and adaptive updates of observation noise in multi-system joint positioning, particularly when there is a lack of prior information. This paper also introduces dual gross error detection adaptive correction of the forgetting factor based on innovation in the iterative Kalman filter to enhance accuracy and robustness. Finally, a series of simulation experiments and semi-physical experiments were conducted. The numerical results show that compared with the traditional method, the angle cosine method reduces the average number of iterations from 9.17 to 3 with higher accuracy, which greatly improves the efficiency of the algorithm. Meanwhile, compared with the standard Extended Kalman Filter (EKF), the proposed algorithm improved $48.66\%$, $35.17\%$, and $38.23\%$ at $1\sigma /2\sigma /3\sigma$, respectively. Full article

Affected by the erosive environment, tunnel lining concrete in the long-term service zprocess often exhibits engineering diseases such as concrete corrosion degradation and loss of strength, decreasing the stability of the tunnel lining structure and the traffic safety. Based on HTG tunnel project, the basic distribution rule of tunnel lining corrosion and macro mechanical properties of corroded concrete were explored in this paper through engineering disease site investigation. Then, on this basis, aiming at large-scale corrosion of tunnel lining structure, two reinforcement and repair schemes are proposed, corrugated steel plate reinforcement method and channel steel reinforcement method. Indoor component tests are carried out on the two reinforcement schemes. The failure characteristics and stress and deformation law of tunnel lining members after reinforcement and repair were verified. The analysis showed that the failure process of the reinforced specimens on the tensile side could be divided into the non-cracking stage and the working stage with cracks, and the cracking load and failure load of the specimens were significantly increased. The bearing capacity of the reinforced specimens was divided into the ultimate bearing capacity against cracking and the ultimate bearing capacity during failure. Finally, the calculation methods of the bearing capacity of the channel steel reinforcement method and the corrugated steel plate reinforcement method were derived. Comparative analysis shows that the results of numerical simulation, experimental testing and theoretical simplification methods are close to each other, and the maximum deviation is less than 8%. The established method for calculating the bearing capacity of corroded components after reinforcement is reliable and can be used for the design calculation of corroded lining reinforcement. Full article

A new type of Filament Wound Profiles (FWPs) have been applied to strengthen the deformed stagger-jointed segmental tunnel linings, and a full-scale test was carried out on the ultimate bearing capacity of the linings that are strengthened by the new FWPs. The failure phenomena and the main experimental results were obtained, including the load-displacement curve, strain and bond failure. The internal forces of the FWPs in the strengthened lining were calculated and discussed. The failure chain and weak sections of the strengthened lining were discussed. The overall strengthening benefits were summarized. The results show that: (1) The FWPs were in the state of compression bending or tension bending, and bore part of the axial force and bending moment in the strengthened lining. (2) The initial failure of the strengthened linings was caused by the bond failure between the FWPs and the concrete linings at 0°. (3) The filament wound profiles strengthening method can effectively improve the ultimate bearing capacity and stiffness of the stagger-jointed shield tunnel linings. Full article

For buried municipal tunnels—such as cable tunnels and utility tunnels with structural defects—due to the sheltering of the internal pipelines, shelves, and other auxiliary facilities, traditional trenchless rehabilitating methods are not applicable since an intact ring is needed for spraying and lining. In these tunnels, only the exposed area at the crown of the ring can be partly rehabilitated. In this paper, three-edge bearing tests (TEBTs) for partially rehabilitated reinforced concrete (RC) pipe sections are carried out to simulate the case of a municipal tunnel and the effects of different repair materials (cement mortar and epoxy resin) and different dimensional parameters of the liner (lining thickness, lining range) on the partial rehabilitation effect of defective RC pipes are studied. The deforming compatibility of the liner–pipe interface is discussed, and the flexural rigidity of the partially rehabilitated section is calculated. The results show that the load-carrying capacities of partial rehabilitated RC pipes are effectively improved. Full article

In the present study, large-scale specimens based on the tunnel prototype were prepared and static load tests were carried out to investigate the damage caused by lining voids. Based on the strengthening scheme of the tunnel, the strengthened specimens were prepared to explore the strengthening effect on the strengthening structure. The strengthening structure is made of a steel plate fixed with chemical anchor bolts and two-component epoxy adhesive. By analyzing the failure mode, structural deformation, and the relationship between load and strain, the damage caused by vault void with various void heights was analyzed and the obtained results were verified through the experiment. Moreover, the enhancement of the bearing capacity and stiffness of the structure strengthened by surface bonding steel was studied. The obtained results show that the damage caused by the lining void mainly occurs at the void boundary. The damage appears as multiple longitudinal cracks. The crack starts from the lower surface and develops radially. Using chemical anchor bolts and two-component epoxy adhesive to bond the steel plate on the lining surface, the damage can be reduced, and the bearing capacity of the structure can be improved effectively when the void height is a quarter of the second lining thickness, the number of cracks is reduced from 14 to 5 after steel plate strengthening, and the length of the longest crack is reduced from 13.2 cm to 8.3 cm, reduced by 37.12%. The steel plate strengthening also reduces the strain of the lower steel bar at the void boundary from 1130.58 με to 555.12 με, and the strain decreases by 50.89%. The experimental results show that the position where the void has the greatest impact on the lining is at the void boundary. Therefore, when steel plates are used to strengthen the void lining, the void boundary should be emphasized, which makes the strengthening more accurate and saves the cost of treatment. Full article

After long-term operation, tunnel lining segments encounter various problems. Aiming at these problems, in this paper, we present a method of strengthening tunnel lining segments by in situ spraying mortar. An experimental study of the in situ spraying mortar was carried out to determine the compressive strength, flexural strength and interface properties (splitting tensile strength and shear strength) between concrete and H-70 mortar. The experimental results show that the mechanical properties of H-70 mortar are less dependent on the curing humidity than ordinary concrete under standard curing conditions, the 7-day compressive strength of H-70 is 55 MPa, which is 61% of the 28-day compressive strength. This shows that H-70 has high early strength and is very suitable for rapid reinforcement. The interface roughness has a significant effect on the splitting tensile strength, and it can be increased by chiseling to improve the bearing capacity of the strengthened structure. A full-scale loading experiment was carried out on the segment strengthened by in situ spraying mortar. The loading process, failure mode and ultimate bearing capacity of the strengthened structure were analyzed by full-scale loading experiment. The research shows that the ultimate bearing capacity of the tunnel segment strengthened by in situ spraying mortar increased significantly. The ultimate bearing capacity of the strengthened structure is 10% higher than that of the unstrengthened structure. The advantages and disadvantages of in the situ spraying-mortar strengthening method are analyzed in comparison with the internal-tension steel-ring strengthening method. Full article

The linings of tunnels in cold regions with long service lives usually have cracks, with parts of the structure peeling and falling off, which seriously threatens the tunnel safety and operation. The unsaturated freeze–thaw cycle of concrete, which is the main cause of structural deterioration, has not received much research attention. During the service life of tunnels in cold regions, unsaturated freeze–thaw cycles deteriorate the quality of the concrete, and its degree presents a gradual distribution in the circumferential and longitudinal directions. An experiment system was adopted to simulate the distribution of the progressive deterioration of tunnel lining concrete. The test results of the temperature field of the model show the distribution law of freeze–thaw cycles, and the gradual deterioration of the lining concrete was realized. Then, the bearing capacity of the model was tested after the progressive deterioration. The results show that the ultimate load of the model decreases with an increase in the number of freeze–thaw cycles. Finally, a numerical simulation was carried out to discuss the influence of the gradual deterioration of the lining. The gradual deterioration of lining concrete will encourage the gradual development of cracks, leading to serious cracking of the lining structure and even block spalling. Through this study, we hope to provide useful information for the prevention and control of tunnel frost damage in cold regions. Full article

Ultrahigh-performance concrete (UHPC) is a novel material demonstrating superior mechanical, durability and sustainability performance. However, its implementation in massive structures is hampered by its high initial cost and the lack of stakeholders’ confidence, especially in developing countries. Therefore, the present study explores, for the first time, a novel application of UHPC, incorporating hybrid steel fibers in precast tunnel lining segments. Reduced scale curved tunnel lining segments were cast using UHPC incorporating hybrid 8 mm and 16 mm steel fibers at dosages of 1%, 2% and 3% by mixture volume. Flexural and thrust load tests were conducted to investigate the mechanical behavior of UHPC tunnel lining segments thus produced. It was observed that the flow of UHPC mixtures decreased due to steel fibers addition, yet steel fibers increased the mechanical and durability properties. Flexural tests on lining segments showed that both the strain hardening (multiple cracking) and strain softening (post-peak behavior) phases were enhanced due to hybrid addition of steel fibers in comparison with the control segments without fibers. Specimens incorporating 3% of hybrid steel fibers achieved 57% increase in ultimate load carrying capacity and exhibited multiple cracking patterns compared to that of identical UHPC segments with 1% fibers. Moreover, segments without fibers incurred excessive cracking and spalling of concrete at the base under the thrust load test. However, more stable behavior was observed for segments incorporating steel fibers under the thrust load, indicating its capability to resist typical thrust loads during tunnel lining field installation. This study highlights the potential use of UHPC with hybrid steel fibers for improved structural behavior. Moreover, the use of UHPC allows producing structural members with reduced cross-sectional dimensions, leading to reduced overall structural weight and increased clear space. Full article

A compact source is important for various applications utilizing terahertz (THz) waves. In this paper, the recent progress in resonant-tunneling diode (RTD) THz oscillators, which are compact semiconductor THz sources, is reviewed, including principles and characteristics of oscillation, studies addressing high-frequency and high output power, a structure which can easily be fabricated, frequency tuning, spectral narrowing, different polarizations, and select applications. At present, fundamental oscillation up to 1.98 THz and output power of 0.7 mW at 1 THz by a large-scale array have been reported. For high-frequency and high output power, structures integrated with cylindrical and rectangular cavities have been proposed. Using oscillators integrated with varactor diodes and their arrays, wide electrical tuning of 400–900 GHz has been demonstrated. For spectral narrowing, a line width as narrow as 1 Hz has been obtained, through use of a phase-locked loop system with a frequency-tunable oscillator. Basic research for various applications—including imaging, spectroscopy, high-capacity wireless communication, and radar systems—of RTD oscillators has been carried out. Some recent results relating to these applications are discussed. Full article

The water immersion of surrounding rock slide surface causes lining cracking of the shallow buried loess tunnel, and different types of slide surface and different immersion degrees have different effects on secondary lining. In this paper, four types of slide surfaces for shallow buried loess tunnel are proposed. In order to find out the characteristics and laws of lining cracking under the effect of slide surface immersion, a loading model test with a large geometric similarity ratio of 1:10 was carried out. The test results show that the immersion of the slide surface has the most significant influence on the deformation of the lining vault and the arch waist, and the value and speed of the vault deformation are always the largest. When the unilateral slide surface is immersed in water, the lining cracking is concentrated on the flooded side of the slide surface, and the appearance of compressive cracks can be regarded as a precursor of lining instability. In the direction of lining thickness, the cracks always begin to develop from I-type, then gradually develop into L-type, and finally develop to Y-type, among which the number of L-type cracks is the most. Furthermore, the residual bearing capacity of cracked lining is also discussed. Full article

Cracks in the lining significantly reduce the safety of a tunnel during operation. It is urgent to figure out the influence of cracks on tunnel carrying capacity. In this paper, three-dimensional model tests were conducted to investigate deformation, internal force, and deterioration laws of the lining with prefabricated cracks at different positions. The main conclusions were obtained as follows: (1) The carrying capacity of the lining structure with prefabricated cracks was reduced, and the deformation of the lining structure increased. The penetration of the vault crown crack accelerated the damage of the lining structure, and structural failure occurred when the crack went through at the left arch spring. (2) The internal force of the lining was greatly affected by the positions of prefabricated cracks. The internal forces of the lining structure decreased with the existence of prefabricated cracks. Whether or not there were prefabricated cracks, tension cracks appeared in the inside fiber of the vault and inverted arch. (3) The deformation of the lining structure with the existence of prefabricated cracks increased. When the prefabricated crack was located at the vault, the deformation was the largest, followed by the arch spring, side wall, and arch shoulder. (4) The analysis shows that prefabricated cracks at the vault are the most damaging under stress and deformation of the lining structure, so longitudinal cracks at the vault should be strengthened. Full article

The presence of symmetric and asymmetric voids directly affects the mechanical behaviors of tunnel linings and further induces tunnel diseases among influence factors. In this paper, 1:5-scale model tests were carried out to study the mechanical behaviors of reinforced concrete (RC) linings considering the voids located at the crown and at the spandrel. Based on the experimental results and concrete plastic damage (CDP) model, the effects of void (i.e., location and size), subgrade stiffness, and lining size on bearing capacity of RC lining were investigated using numerical simulation. The results of model test and parametric analysis showed that the existence of voids significantly affected the mechanical behavior of the lining during inelastic deformation period. The lining with a larger void size corresponded to low bearing capacity and larger deformation around the void, thus increasing the damage possibility of linings. The influence of voids on the bearing capacity of linings varied with the void location, load direction (especially under horizontal symmetrical loads), and subgrade stiffness. High soil stiffness corresponded to a great influence of the void size on the lining bearing capacity. In addition, the lining strength increased inconsistently with the increase of model size. On the basis of parameter sensitivity analysis, the Levenberg–Marquardt (L-M) optimization algorithm and Logistic model were used to establish the equation of lining bearing capacity loss rate considering the void effect. Full article

Railway tunnel clearance is directly related to the safe operation of trains and upgrading of freight capacity. As more and more railway are put into operation and the operation is continuously becoming faster, the railway tunnel clearance inspection should be more precise and efficient. In view of the problems existing in traditional tunnel clearance inspection methods, such as low density, slow speed and a lot of manual operations, this paper proposes a tunnel clearance inspection approach based on 3D point clouds obtained by a mobile laser scanning system (MLS). First, a dynamic coordinate system for railway tunnel clearance inspection has been proposed. A rail line extraction algorithm based on 3D linear fitting is implemented from the segmented point cloud to establish a dynamic clearance coordinate system. Second, a method to seamlessly connect all rail segments based on the railway clearance restrictions, and a seamless rail alignment is formed sequentially from the middle tunnel section to both ends. Finally, based on the rail alignment and the track clearance coordinate system, different types of clearance frames are introduced for intrusion operation with the tunnel section to realize the tunnel clearance inspection. By taking the Shuanghekou Tunnel of the Chengdu–Kunming Railway as an example, when the clearance inspection is carried out by the method mentioned herein, its precision can reach 0.03 m, and difference types of clearances can be effectively calculated. This method has a wide application prospects. Full article
