The deployment of photovoltaic single-phase inverters has been rapidly increasing worldwide. However, the performance of these systems is highly influenced by atmospheric conditions and load variations, necessitating the development of performance indices to enhance their efficiency and energy quality. In this study, four performance indices are proposed to evaluate the efficiency and energy quality of photovoltaic systems quantitatively. The entire process is analyzed, encompassing solar energy capture, DC-DC and DC-AC conversion, and filtering, to deliver maximum energy and quality to the load. Furthermore, eight system parameters are optimized using advanced techniques such as genetic algorithms, particle swarm optimization, and gray wolf optimization. These optimizations enhance the global performance of two critical stages: (1) the maximum power point tracking algorithm based on sliding mode control, which minimizes switching losses in the boost stage, and (2) the effective transfer of captured solar power to the load by optimizing the gains of a PI controller. The PI controller computes the switching triggers for the inverter stage, significantly improving the total harmonic distortion of voltage and current waveforms. Simulation results validate the proposed approach, demonstrating a marked improvement in overall system efficiency (95.8%) when compared to the incremental conductance method (−11.8%) and a baseline sliding mode control configuration (−1.14%). Full article

A grid-forming converter (GFM) controls power output by adjusting the phase angle and amplitude of its output voltage, providing voltage and frequency support to the power system and effectively enhancing system stability. However, it has limitations in current control, influencing the current only indirectly through voltage regulation, which results in weaker control over current waveform quality. In the context of a large number of renewable energy generation units being connected to the grid, harmonics in the grid voltage can lead to excessively high harmonic content in the grid current, exceeding standard limits and causing oscillations. To solve this problem, this paper proposes a control strategy of harmonic voltage feedforward compensation to suppress grid current distortion. The proposed control strategy extracts harmonic voltages from the output port of the GFM converter through a harmonic extraction module, processes them via a feedforward factor, and introduces the resulting signals into the converter’s control loop as feedforward compensation terms. This allows the converter’s output voltage to compensate for the harmonic components in the grid, achieving the improvement of grid current and reducing the total harmonic distortion (THD) value. The effectiveness of the proposed control strategy is verified by simulation results. Full article

This review paper describes and compares the practical methods that make it possible to calculate an average value of apparent, active, and reactive (i.e., blind and distorted) power in each calculation step. In addition to two methods, $p–q$ and $ip–iq$, it deals with the application of the $id–iq$ method for determining power components’ mean values in a discrete step. The results are important and needed for the right dimensioning and sizing of power electronic and electrical systems (PEESs), which those power components produce. This is because the integral calculation for the mean values of the product of voltage u(t) and current i(t) always gives a value lower than the actual value of the apparent power. Using moving average and moving root mean square (rms) techniques (or digital filtering), one obtains the right values, although with a time delay. Using sliding filtering, these techniques calculate the average or rms values, respectively, of the power components in each step k. By calculating the moving average value of the power components in both transient and steady states (on/off as well), we achieve the correct design of the system. The transients for the three- and single-phase power electronic systems are modeled, simulated, and theoretically supported in this study. Any PEES can be determined and sized using the calculated data. The real-time HW simulator Plecs RT Box 1 and Matlab/Simulink 2024a simulations validate the comprehensive time waveform produced by the suggested method. Full article

This work contributes to both Romania’s and the European Union’s energy policies by highlighting the research results obtained within the Dunarea de Jos University of Galati, but also through the technological transfer of this knowledge to the industry. In order to improve the power quality of the nonlinear loads connected to the electrical grid, a three-phase shunt active power filter prototype based on the Harmonic Component Separation Method with a Low-Pass Filter was used. The active power filter is connected at the Point of Common Coupling to compensate for individual loads or even all of them simultaneously. Therefore, active power filters can be used to compensate for the power factor and reduce the harmonic distortion of power supplies, or for processes subsequently connected to additional nonlinear loads, thus improving the energy efficiency. The shunt active power filter prototype is composed of the power side (three-phase insulated gate bipolar transistor bridge, DC link capacitor precharge system, inductive filter) and the control side (gate drive circuits, control subsystems, signal acquisition system). The filter control strategy is based on the principle of separating harmonic components with a low-pass filter, implemented by the authors on the industrial prototype. In this paper, the main technical features of the industrial shunt active power filter prototype are specified. The authors of this paper involved three cascaded control loops: the DC link voltage control loop, the shunt active power filter current control loop and the phase-locked loop. Both simulation and experimental results for the shunt-type active power filter prototype were obtained. By analyzing the obtained waveforms of the power supply source in two cases (with and without an active power filter), a decrease in the total harmonic distortion was demonstrated, both the voltage harmonic distortion factor THDu and the current harmonic distortion factor THDi in the case of the active power filter connection. By using the Field-Programmed Gate Array processing platform, the powerful computational speed features were exploited to implement the active shunt power filter control on an experimental test bench. Conducting source current harmonics mitigation increased the efficiency of the power system by decreasing the respective harmonic Joule losses. The energy-saving feature led to the increased added value of the parallel active power filter. Through the performed laboratory tests, the authors demonstrated the feasibility of the proposed control solution for the industrial prototype. In accordance with the European Union’s Research and Technological Development Policy, the development of an innovation ecosystem was taken into consideration. The unified and efficient integration of all the specific actors (enterprises, research institutes, universities and entrepreneurs) in innovation was achieved. Full article

It may be helpful to integrate multiple aircraft communication and navigation functions into a single software-defined radio (SDR) platform. To transmit these multiple signals, the SDR would first sum the baseband version of the signals. This outgoing composite signal would be passed through a digital-to-analog converter (DAC) before being up-converted and passed through a radio frequency (RF) amplifier. To prevent non-linear distortion in the RF amplifier, it is important to know the peak voltage of the composite. While this is reasonably straightforward when a single modulation is used, it is more challenging when working with composite signals. This paper describes a machine learning solution to this problem. We demonstrate that a generalized gamma distribution (GGD) is a good fit for the distribution of the instantaneous voltage of the composite waveform. A deep neural network was trained to estimate the GGD parameters based on the parameters of the modulators. This allows the SDR to accurately estimate the peak of the composite voltage and set the gain of the DAC and RF amplifier, without having to generate or directly observe the composite signal. Full article

Current trends in the use of energy storage, electric mobility, and the integration of a large number of distributed generations at the distribution level can have positive effects on reducing loads and losses in the network. An excessive and uncontrolled level of integration of the above trends leads to various problems related to the power quality. Distortion of the voltage and current waveforms caused by nonlinear loads is manifested through harmonics and can be classified as one of the most essential parameters of electricity quality. Reducing harmonics thus becomes the primary goal for improving the quality of electricity at the distribution level. This paper, along with a detailed analysis of the literature, provides an overview of different views on the problems of optimal allocation of active filters and emphasizes the importance that the problem of optimal allocation of active filters should be based on the variability of the harmonic spectrum as a function of time. Installing devices for reducing harmonics in the network, in terms of improving the quality of electricity, is one of the essential elements from both a technical and an economic point of view and can solve these challenges. Therefore, it is necessary to develop methods for solving the problem of determining the position, size and parameters of filters, as well as the number of buses on which such devices can be integrated. Applying optimization techniques enables the development of more realistic models for applying active power filters. The research in this paper is directed toward developing a co-simulation optimization model to determine optimal settings of the parallel APF due to harmonic reduction in a real low-voltage network using particle swarm optimization for 24 h intervals. The research in this paper was conducted on a real radial low-voltage feeder, where at each node, the variability of production and/or consumption is taken, which is obtained on the basis of real measurements and tests. Based on this, the position and dimensioning of the shunt active power filters (APFs) depend on the load range within a 24 h interval at all nodes in the observed time interval. Furthermore, the paper emphasizes the importance of observing Voltage Total Harmonic Distortion (THD_V) on the busbars in the depth of the feeder as well as the importance of observing THD_V in each phase. Full article

This paper presents a comparative analysis of interior permanent magnet synchronous motor (IPMSM) drives powered by symmetrical and asymmetrical cascaded H-bridge multilevel inverters. The asymmetric topology operates using multiple DC sources with different voltage values, generating a voltage waveform with more output voltage levels than its traditional counterpart, all while maintaining the same hardware configuration. The main goal is to demonstrate that asymmetrical multilevel inverters are a promising option for improving the performance of electric drives while maintaining cost-efficiency and reliability. The proposed comparison is conducted through simulations in the MATLAB/Simulink R2024a environment, which allows an in-depth analysis of the dynamic performance of the electric drive. Additionally, the variation of the DC link input power of each H-bridge and the Total Harmonic Distortion (THD) of the voltage and current of the output of the converters were studied for different operating conditions in both cases. The obtained results were confirmed through real-time validation, demonstrating the applicability of electric drives powered by asymmetric converters and the advantages, in terms of efficiency, harmonic content and dynamic performance, in certain conditions of operation in terms of speed and applied load. Full article

In power systems, various power quality disturbances are present, including voltage deviation, voltage unbalance, and voltage waveform distortions. Voltage waveform distortions are usually identified with harmonics, but in some systems, subharmonics (subsynchronous interharmonics) and interharmonics may also occur—that is, components of frequency less than the fundamental frequency, or not an integer multiple of it. This study examines torque pulsations of an induction motor under voltage subharmonics combined with voltage unbalance. The motor and the driven DC generator vibrations were analysed under the power quality disturbances. Investigations were carried out using finite element and empirical methods. Experimental tests were performed for the maximal levels of the power quality disturbances specified or proposed in the relevant standards. For the investigated motor, under voltage subharmonics or voltage unbalance occurring as a single power quality disturbance, the vibration level was within the prescribed limit. However, under unbalance combined with subharmonics, the level could be accepted for only a limited time. Consequently, the permissible level of voltage subharmonics in non-generation installations should be interconnected with the voltage unbalance in the power system. Full article

This paper investigates a back-electromotive force (EMF) harmonic compensation strategy for six-phase permanent-magnet synchronous motors (PMSMs) to reduce current harmonics and improve system performance. Ideally, the back-EMF waveform should be perfectly sinusoidal. However, manufacturing imperfections such as suboptimal magnetic circuit design, uneven winding distribution, and mechanical eccentricity introduce low-order spatial harmonics, particularly the 5th, 7th, 11th, and 13th orders, which distort the back-EMF, increase current harmonics, complicate control, and reduce efficiency. To address these issues, this study proposes a compensation strategy utilizing common-mode and differential-mode current control. By injecting the 6th and 12th harmonics into the decoupled voltage commands along the d-axis and q-axis, the strategy significantly reduces current harmonic distortion. Experimental validation was conducted using a TMS320F28386D microcontroller, which controlled dual inverters via PWM signals and processed real-time current feedback. Rotor position feedback was provided by a resolver to ensure precise and responsive motor control. At a rotational speed of 900 rpm, with a peak phase current $I_m$ of 200 A and an IGBT switching frequency of 10 kHz, the phase-a current total harmonic distortion (THD) was reduced from 11.86% (without compensation) to 6.83% (with compensation). This study focused on mitigating harmonics below the 14th order. The experimental results demonstrate that the proposed back-EMF harmonic compensation strategy effectively minimizes current THD, highlighting its potential for improving the performance and efficiency of multi-phase motor systems. Full article

Voltage notches are steady-state sub-cycle waveform distortions caused by the normal operation of line-commutated power converters, significantly impacting power quality in industrial low-voltage (LV) networks. Despite their common occurrence, research on this phenomenon is still incipient, and realistic simulation platforms are lacking. This paper introduces a detailed MATLAB (R2024a)/Simulink-based simulation platform that models a benchmark low-voltage industrial installation, including a six-pulse controlled rectifier, linear loads, and a capacitor bank for power factor correction. Systematic simulations are performed with the platform to examine the sensitivity of notch characteristics to key parameters within plausible ranges, such as short-circuit power at the point of common coupling, commutation reactance, firing angle, snubber circuits, and rated power of the rectifier. In addition, parameters such as the rated power of linear loads and the compensation power of the capacitor bank are examined. Other influencing parameters including background voltage unbalance and distortion are also modeled and considered. A comparative analysis with field measurements from German industrial LV networks validates the plausibility and suitability of the simulations. Building upon this platform, a Monte Carlo simulation approach is adopted to generate extensive datasets of realistic voltage notch waveforms by randomly varying these key parameters. A case study conducted under conditions typical of German LV networks demonstrates the applicability of the simulations. To support further research, the simulation platform and exemplary synthetic waveforms are provided alongside the paper, serving as a valuable tool for testing and designing strategies for analysis, detection, and monitoring of voltage notches. Full article

The rapid growth of power electronics-based devices, such as electric vehicles and renewable energy systems, has introduced nonlinear components into power systems, generating high-frequency harmonics that distort current and voltage waveforms. These distortions pose significant risks to the stability of power grids, potentially leading to equipment malfunctions, reduced efficiency, and even system failures. To address these challenges, advanced harmonic detection, suppression, and estimation techniques are required to ensure the reliable operation of modern power systems. This paper comprehensively reviews the most widely used methods for managing harmonic distortions, focusing on recent harmonic detection, suppression, and estimation advancements. Key techniques, such as Fourier analysis and wavelet transforms, are compared alongside emerging machine learning-based approaches and adaptive filtering methods, which offer enhanced accuracy in real-time and dynamic environments. Additionally, advancements in harmonic suppression technologies, including passive, active, and hybrid filtering, are discussed for their effectiveness in mitigating harmonic impacts. Furthermore, the paper explores harmonic aggregation techniques that assess the cumulative impact of multiple harmonic sources and innovative estimation models that improve harmonic quantification under complex grid conditions. With the growing integration of renewable energy and electric vehicles, this review highlights the importance of advanced harmonic management strategies to ensure the safety, efficiency, and long-term stability of power systems. Full article

In the evolution of the modern “More Electric Aircrafts” (MEAs) concept, higher-pulse rectification systems using differential fork autotransformers play a pivotal role. These systems align with the MEAs concept, which aims to replace traditional hydraulic and pneumatic systems with electric alternatives. The reason is that MEAs prioritize weight reduction to enhance fuel efficiency and reduce emissions. Higher-pulse rectifiers achieve this by minimizing losses and optimizing power conversion. Additionally, they mitigate harmonics, ensuring a clean power supply to critical avionic components. These systems also regulate voltage effectively, contributing to overall system stability. Furthermore, their compliance with IEEE-519 standards ensures their safe and efficient operation. Keeping in view the above applications, a comparative study of 12-, 18-, and 24-pulse rectification systems was carried out using different autotransformer topologies. The simulation and hardware results are presented for validation. The voltage and current waveforms were meticulously analyzed for each topology, emphasizing the pivotal role played by the differential fork autotransformer design. By quantifying the total harmonic distortion (THD) levels using MATLAB simulations, intriguing insights were revealed. Notably, the 24-pulse system emerged as the clear winner in harmonic mitigation, showcasing its superior waveform quality and reduced harmonic content. However, the 18-pulse configuration also exhibited a commendable performance, surpassing the 12-pulse counterpart. Full article

This paper investigates the influence of harmonic content on the root mean square value of electromagnetic fields emitted by overhead power lines. The paper presents a methodology to assess the intensity of electric field and magnetic flux density, incorporating both fundamental frequencies and harmonics. The results of our calculations indicate that harmonic distortion in current waveforms can significantly increase the RMS value of magnetic flux density but its effect on electric field intensity is minimal. Additionally, our findings highlight a potential increase in induced voltages on buried or overhead steel pipelines in the vicinity of OPLs, which could pose risks such as pipeline damage and increased corrosion. This underscores the importance of considering harmonic content in EMF exposure evaluations to address both health risks and potential infrastructure impacts comprehensively. Effective harmonic management and rigorous infrastructure monitoring are essential to prevent potential hazards and ensure the reliability of protective systems. Full article

With increasing interest in integrating solar power into the utility grid, multilevel inverters are gaining much more attention for medium- and high-power applications due to their high-quality waveform, low voltage stress across active components, and low total harmonic distortion in output voltage. However, to achieve these benefits, a large number of active and passive components are required. A transformer is also required to provide galvanic isolation, which increases its size and weight and reduces its power density and efficiency. In order to overcome the disadvantages posed by transformer-based inverters, research is being conducted on the transformerless topology of multilevel inverters. The first aim of this review article is to summarize traditional transformerless multilevel inverters (TMLIs) considering both single- and three-phase topologies. Secondly, the main aim of this article is to provide a detailed overview of the hybrid topologies of TMLIs that employ fewer components for photovoltaic applications. In addition, this study compares traditional and hybrid single-/three-phase topologies in terms of component count and performance factors, which will be useful to researchers. Full article

Multi-level inverters have characteristics suitable for high-voltage and high-power applications through various topology configurations. These reduce harmonic distortion and improve the quality of the output waveform by generating a multi-level output voltage waveform. In particular, an active neutral-point-clamped topology is one of the multi-level inverters advantageous for high-power and medium-voltage applications. It has the advantage of controlling the output waveform more precisely by actively clamping the neutral point using an active switch and diode. However, it has a problem, which is that an unwanted zero-crossing current may occur if an inaccurate switching signal is applied at the time when the polarity of the output voltage changes. In this paper, a control strategy to suppress the zero-crossing current of a single-phase half-bridge three-level active neutral-point-clamped inverter is proposed. The operating principle of a single-phase half-bridge three-level active neutral-point-clamped inverter is identified through an operation mode analysis. In addition, how the switching signal is reflected in an actual digital signal processor is analyzed to determine the situation in which the zero-crossing current occurs. Through this, a control strategy capable of suppressing zero-crossing current is designed. The proposed method prevents a zero-crossing current by appropriately modifying the update timing of reference voltages at the point where the polarity of the output changes. The validity of the proposed method is verified through simulation and experiments. Based on the proposed method, the total harmonic distortion of the output current is significantly reduced from 12.15% to 4.59% in a full-load situation. Full article
