In this paper, a modular cell balancing circuit based on a bidirectional flyback converter (BFC) is designed, which is equipped with a symmetrical BFC for each cell. The primary side of all BFCs is in parallel with the battery pack, and the secondary side is connected to the individual cells. Such an input-parallel output-series structure allows for bidirectional and controllable energy transfer among the cells. The control of the charging/discharging for a specific cell can be realized by adjusting the PWM signal on the primary or secondary side of the corresponding BFC. Based on this, three cell balancing strategies are proposed: maximum voltage discharge (MXVD), minimum voltage charge (MNVC), and maximum and minimum voltage balancing (MX&MNB). For MX&MNB, which is essentially a combination of MXVD and MNVC, it controls the maximum voltage cell discharging and minimum voltage cell charging simultaneously, where the energy is transferred directly between the two cells with the largest voltage difference. A cell balancing prototype is built and tested to verify the feasibility and stability of the proposed strategy. All three proposed methods can implement cell balancing simply and effectively, while the MX&MNB provides a faster speed. Full article

Electric vehicles (EVs) are a sustainable means of transportation, with their onboard batteries being crucial for both performance and energy management. A modular and reconfigurable power converter topology to connect removable batteries to the main DC bus of an EV is proposed in this paper. By employing Dual Active Bridge (DAB) converters in an Input Parallel Output Series (IPOS) configuration, the proposed topology is compatible with 400 V and 800 V standards without the need for external switches. The research explored the possibility to apply a very simple control strategy based on independent linear regulators. A theoretical analysis of the IPOS DAB converter is presented and the design of independent control regulators which minimize the coupling effect between the control variables is addressed. The stability of the IPOS DAB converter could be ensured using the proposed simplistic approach, enabling us to drastically simplify the regulator design step. The dynamic performance of the system was confirmed by means of a simulation and experimentally. Full article

This paper studies the THD and AC losses on the DC cables of offshore wind farm-based multi-terminal HVDC systems when they extract and deliver power from and to more than one connection point. In the paper, the study of a full system PLECS + Simulink model with two branches, including a wind resource, a wind turbine, a Permanent Magnet Synchronous Generator (PMSG), a Pulse Width Modulation (PWM) rectifier, a Single Active Bridge (SAB) DC–DC converter, an Input Parallel Output Series (IPOS) DC–DC converter, HVDC cables, and a simplified onshore system, is presented. It focuses on the investigation of the output ripple content of multiple DC–DC converters on DC cables under different wind conditions with different voltage and power ratings. The importance of the study is providing a general understanding of the operation of the innovative offshore wind farm-based DC system, as well as the interaction between different DC–DC converters and their influence on cable ripple content under different situations. Full article

Under light load conditions, the phase-shifted full-bridge (PSFB) converter often has difficulty in realizing the zero-voltage switching (ZVS) of the lagging-leg by relying on the energy of its resonant inductor; however, for the series-parallel PSFB converter applied in high-power applications, the lagging-leg still has the problem of difficult realization of ZVS. Based on this, the paper analyzes the reasons why the series-parallel PSFB converter has difficulty in achieving ZVS for the lagging-leg under light and heavy loads. Under interleaved control, the ZVS of the lagging-leg over the full load range is realized by adding an auxiliary LC branch at the midpoint of the lagging-leg of both submodules. Based on the double-bridge input-parallel-output-series (IPOS) PSFB converter, analyzing the working principle of the circuit after adding the auxiliary LC branch and extending it to the series-parallel PSFB converter. The design requirements of the LC auxiliary branch of the dual-bridge series-parallel PSFB converter are given and the effects of the LC auxiliary branch on the module operating state and device stress are analyzed. On this basis, an extension is carried out to give the working principle and design method of the auxiliary LC branch of the N-bridge series-parallel PSFB converter. Finally, a 100 kW Matlab/Simulink simulation model verifies the superior performance of the proposed LC auxiliary branch to realize the lagging-leg ZVS of the series-parallel PSFB converter under light and heavy loads and achieves a 1.09% peak efficiency improvement at rated load. Full article

The Partial Power Processing (PPP) concept has garnered attention as it enables the down-sizing of converter and component ratings. Unlike conventional power processing, PPP addresses a portion of the transferred power, leading to a reduction in conversion losses. Throughout this paper, the state of the art of isolated and non-isolated DC-DC converter topologies will be revised. Partial Power Converter (PPC) systems represent one of the main streams of PPP, which, based on isolation requirements and converter connections, can further be divided into isolated converters, such as: Input-Parallel-Output-Series (IPOS), Input-Series-Output-Parallel (ISOP), and, Input-Series-Output-Series (ISOS), or non-isolated converters. This work intends to evaluate and differentiate the characteristics of each type of topology while developing analytically possible connections that may require further research and reviewing metrics that help in fair comparisons of different PPC arrangements, operating under different conditions. A thorough revision is provided for DC-DC converter topologies due to their increased importance in present-day applications, such as energy storage, Electric Vehicles (EVs), and Photo-Voltaics (PVs). Full article

Parasitic oscillations in the rectifier diode voltage of phase-shifted-full-bridge (PSFB) converters limit their application in high-voltage and high-power situations. The conventional analysis method for parasitic oscillation in rectifier diode voltage in PSFB converters treats the filter inductor as a constant current source and fails to consider the impact of changes in filter inductor current on the rectifier diode’s parasitic oscillation. Consequently, this approach does not apply when analyzing the rectifier diode voltage’s parasitic oscillations in high-power PSFB converters employing an input-parallel output-series (IPOS) configuration with interleaved drive. This research paper introduces an innovative equivalent circuit model for analyzing the parasitic oscillations of rectifier diode voltage in IPOS high-power PSFB converters. The model takes into account the mutual influence of rectifier diode voltage oscillations between submodules under interleaved control, considering the influence of changes in filter inductor current on rectifier diode parasitic oscillation. Based on the circuit model, we explain the mechanism of multiple oscillations of the rectifier diode voltage and the reason for the high peak of the first oscillation. Consequently, the interplay of rectifier diode voltage oscillations in IPOS high-power k-module PSFB converters under interleaved control is analyzed. To mitigate the adverse effects of rectifier diode voltage parasitic oscillation, a buffering strategy involving the connection of a resistor capacitor diode (RCD) circuit in parallel after the rectifier bridge is adopted, considering the structure of the IPOS high-power PSFB converter. The study provides a detailed analysis of the circuit’s operation mechanism upon incorporating the RCD buffer circuit and establishes the relationship between buffer capacitance, resistance, and spike voltage. Furthermore, a design method for buffer capacitors and discharge resistors in buffer circuits is presented. Finally, a 100 kW prototype is tested to verify the rectifier diode voltage oscillation mechanism of the IPOS high-power PSFB converter and the rationality of the buffer capacitor and discharge resistor design method under the interleaved drive approach. Full article

The multilevel back-to-back cascaded H-bridge converter (CHB-B2B) presents a significantly reduced components per level in comparison to other classical back-to-back multilevel topologies. However, this advantage cannot be fulfilled because of the several internal short circuits presented in the CHB-B2B when a conventional PWM modulation is applied. To solve this issue, a powerful math tool known as graph theory emerges as a solution for defining the converter switching matrix to be used with an appropriate control strategy, such as the model-based predictive control (MPC). Therefore, this research paper proposes a MPC with the graph theory approach applied to CHB-B2B which capable of not only eliminating the short circuit stages, but also exploring all the switching states remaining without losing the converter controllability and power quality. To demonstrate the proposed strategy applicability, the MPC with graph theory approach is tested in four different types of SST configurations, input-parallel output-parallel (IPOP), input-parallel output series (IPOS), input-series output-parallel (ISOP), and input-series output series (ISOS), attending distribution grids with different voltage and power levels. Real-time experimental results obtained in a hardware-in-the-loop (HIL) platform demonstrate the proposed strategy’s effectiveness, such as DC-link voltages regulation, multilevel voltage synthesis, and currents with reduced harmonic content. Full article

Photovoltaic (PV) power plant collection and connection to a high voltage direct current (HVDC) grid has many advantages. Compared with the traditional AC collection and grid-connection scheme, it can reduce the power conversion links and improve the system efficiency. As one of the most important devices in the application of a PV HVDC collection and grid-connection system, a high voltage, large capacity, high step-up ratio DC/DC converter is the critical technology. A DC/DC converter scheme based on a boost full bridge isolated power module cascaded in input parallel output series (IPOS) structure is proposed to meet the technical requirements of PV power conversion with high voltage, large capacity, and high step-up ratio. The operation mode of the power module is analyzed, the soft switching method is proposed, and the constraint to realize the soft switching of the power module is deduced. Aiming to resolve the problem of multi-module voltage and current equalization in a cascaded DC/DC converter, a distributed module equalization control strategy is proposed to realize the reliable operation of a power module and converter. A 5 kV/80 kW standard power module is developed, the DC/DC converter experimental platform is built, and the proposed system scheme and control strategy are verified by experiments. Based on a 14-power module input parallel output series connection, a ±30 kV/1 MW PV DC/DC converter is developed, a ±30 kV PV HVDC collection and grid-connection demonstration system is established, and the experimental test is completed to realize the stable operation of the system. Full article

Nowadays, the demand for high power converters for DC applications, such as renewable sources or ultra-fast chargers for electric vehicles, is constantly growing. Galvanic isolation is mandatory in most of these applications. In this context, the Solid State Transformer (SST) converter plays a fundamental role. The adoption of the Medium Frequency Transformers (MFT) guarantees galvanic isolation in addition to high performance in reduced size. In the present paper, a multi MFT structure is proposed as a solution to improve the power density and the modularity of the system. Starting from $20\mathrm{kW}$ planar transformer model, experimentally validated, a multi-transformer structure is analyzed. After an analytical treatment of the Input Parallel Output Series (IPOS) structure, an equivalent electrical model of a $200\mathrm{kW}$ IPOS (made by 10 MFTs) is introduced. The model is validated by experimental measurements and tests. Full article

Electric Vehicles (EVs) play a significant role in the reduction of CO₂ emissions and other health-threatening air pollutants Accordingly, several research studies are introduced owing to replacing conventional gasoline-powered vehicles with battery-powered EVs. However, the ultra-fast charging (UFC) of the battery pack or the rapid recharging of the battery requires specific demands, including both: the EV battery and the influence on the power grid. In this regard, advanced power electronics technologies are emerging significantly to replace the currently existing gas station infrastructures with the EV charging stations to move from conventional charging (range of hours) to UFC (range of minutes). Among these power electronics conversion systems, the DC-DC conversion stage plays an essential role in supplying energy to the EV via charging the EV’s battery. Accordingly, this paper aims to present possible architectures of connecting multiple Dual Active Bridge (DAB) units as the DC-DC stage of the EV fast charger and study their Small-Signal Modeling (SSM) and their control scheme. These are, namely, Input-Series Output-Series (ISOS), Input-Series Output-Parallel (ISOP), Input-Parallel Output-Parallel (IPOP), and Input-Parallel Output-Series (IPOS). The control scheme for each system is studied through controlling the output filter inductor current such that the current profile is based on Reflex Charging (RC). The main contribution of this paper can be highlighted in providing generalized SSM as well as providing a generalized control approach for the Input-Series Input-Parallel Output-Series Output-Parallel (ISIP-OSOP) connection. The generalized model is verified with three different architectures. The control strategy for each architecture is studied to ensure equal power sharing, where simulation results are provided to elucidate the presented concept considering a three-module ISOS, IPOP, ISOP, and IPOS DC-DC converters. Full article

There has been increasing interest for industry applications, such as solar power generation, fuel cell systems, and dc microgrids, in step-up dc-dc converters with reduced number of components, low component stress, small input ripples and high step-up ratios. In this paper, an input-parallel-output-series three-level boost (IPOS-SC-TLB) converter is proposed. In addition to achieving the required performance, the input and output terminals can share the same ground and an automatic current balance function is also achieved in the IPOS-SC-TLB converter. Besides, a capacitor voltage imbalance mechanism was revealed and a three-loop control strategy composed of output voltage loop, input current loop and voltage-balance loop was proposed to address the voltage imbalance issue. Finally both simulation and experiment studies have been conducted to verify the effectiveness of the IPOS-SC-TLB converter and the three-loop control strategy. Full article

This work presents a partial power converter allowing us to obtain, with a single DC-DC converter, the same feature as the classical interleaved operation of two converters. More precisely, the proposed topology performs similarly as the input-parallel output-series (IPOS) configuration reducing the current ripple at the input of the system and dividing the individual converters power rating, compared to a single converter. The proposed topology consists of a partial DC-DC converter processing only a fraction of the total power, thus allowing high efficiency. Experimental results are provided to validate the proposed converter topology with a Flyback-based 100 W test bench with a transformer turns ratio $n_1=n_2$ . Experimental results show high performances reducing the input current ripple around $30\%$ , further increasing the conversion efficiency. Full article
