Search Results (32)

Laser Doppler vibrometry (LDV) is an essential tool in assessing by evaluating ossicle vibrations. It is used in fundamental research to understand hearing physiology better and develop new surgical techniques and implants. It is also helpful for the intraoperative hearing assessment and evaluation of postoperative treatment results. Traditional volumetric LDVs require access in a straight line to the test object, which is challenging due to the structure of the middle ear and the way the auditory ossicles are accessible. Here, we demonstrate the usage of a fiber-based laser Doppler vibrometer (FLDV) for middle ear diagnostics. Compared to classical vibrometers, the main advantages of this device are the ability to analyze several arbitrarily selected points simultaneously and the flexibility achieved by employing fiber optics to perform analysis in hard-to-reach locations, which are particularly important during endoscopic ear surgery. The device also allows for a simple change in measuring probes depending on the application. In this work, we demonstrate the properties of the designed probe and show that using it together with the FLDV enables recording vibrations of the auditory ossicles of the human ear. The obtained signals enable hearing analysis. Full article

Developing a miniatured laser vibrometer becomes important for many engineering areas, such as experimental and operational modal analyses, model validation, and structural health monitoring. Due to its compact size and light weight, a miniatured laser vibrometer can be attached to various mobilized platforms, such as an unmanned aerial vehicle and a robotic arm whose payloads can usually not be large, to achieve a flexible vibration measurement capability. However, integrating optics into a miniaturized laser vibrometer presents several challenges. These include signal interference from ghost reflectance signals generated by the sub-components of integrated photonics, polarization effects caused by waveguide structures, wavelength drifting due to the semiconductor laser, and the poorer noise characteristics of an integrated laser chip compared to a non-integrated circuit. This work proposes a novel chip-based high-precision laser vibrometer by incorporating two or more sets of quadrature demodulation networks into its design. An additional set of quadrature demodulation networks with a distinct reference arm delay line length can be used to conduct real-time compensation to mitigate linear interference caused by temperature and environmental variations. A series of vibration measurements with frequencies ranging from 0.1 Hz to 1 MHz were conducted using the proposed laser vibrometer to show its repeatability and accuracy in vibration and ultrasonic vibration measurements, and its robustness to test surface conditions. The proposed laser vibrometer has the advantage of directly measuring the displacement response of a vibrating structure rather than integrating its velocity response to yield the measured displacement with a conventional laser Doppler vibrometer. Full article

In this work, a biaxial, piezoelectrically driven resonant MEMS mirror with large design flexibility is presented. After FEM-based design optimization to reduce material stress and thereby maximize the achievable total optical scanning angles, fabricated MEMS mirrors were electrically, mechanically, and optically characterized. While the achievable optical scanning angles were determined using a home-built optical setup, a laser Doppler vibrometer was used to characterize the resonance frequencies of the rotational modes and their respective quality factors. The encapsulation of the mirror by a glass window ensures its operation in vacuum, which increases the Q-factor up to 15,000. Full article

The Self-Mixing Interformeter (SMI) is a self-aligned optical interferometer which has been used for acoustic wave sensing in air through the acousto-optic effect. This paper presents how to use a SMI for the measurement of Sound Pressure Level (SPL) in acoustic waveguides. To achieve this, the SMI is first calibrated in situ as a vibrometer. The optical feedback parameters C and $\alpha$ in the strong feedback regime ($C\ge 4.6$) are estimated from the SMI vibrometric signals and by the solving of non-linear equations governing the SMI behaviour. The calibration method is validated on synthetic SMI signals simulated from SMI governing equations for C ranging from 5 to 20 and $\alpha$ ranging from 4 to 10. Knowing C and $\alpha$, the SMI is then used as an acoustic pressure sensor. The SPLs obtained using the SMI are compared with a reference microphone, and a maximal deviation of 2.2 dB is obtained for plane waves of amplitudes ranging from 20 to 860 Pa and frequencies from 614 to 17,900 Hz. The SPL measurements are carried out for C values ranging from 7.1 to 21.5. Full article

Due to their unique properties, porous silicon nanostructures have garnered much attention in photonics. For example, these structures can exhibit photoluminescence and are highly efficient in trapping light, making them ideal for applications such as biosensors, optical communication, and solar cells. The production of electromagnetic forces by light is a well-established concept, and the mechanism behind it is well-understood. In the past, we have used these forces to induce mechanical oscillations in a photonic structure based on porous silicon. Usually, to detect the oscillations, a high-precision vibrometer is utilized. However, we report a novel approach to visualizing photonic structure oscillations here. The traditional method of using a vibrometer as an indirect measurement tool has been replaced by one that involves directly observing the changes using a camera, digital movement amplification, a theoretical approximation, and FDTE simulations. This original technique provides researchers with a less expensive means of studying photonic structure movements. This proposal could be extended to other microscopic movements or for dynamical interferometric fringe analysis. Full article

Previous studies demonstrated coupling of acoustic guided waves from one optical fiber to another through a simple adhesive bond coupler. This paper experimentally utilizes such an adhesive bond coupler to easily extend an already existing sensor network. We experimentally demonstrate this concept for detecting simulated cracks growing from circular holes in a thin aluminum plate. A single, remotely bonded FBG sensor is used to detect the original crack growth, followed by the addition of other optical fiber segments using adhesive couplers to detect new crack growth locations on the plate. A laser Doppler vibrometer is also used to measure the guided wave propagation through the plate to verify that the changes in the FBG sensor measurements are due to the growth of the cracks. Full article

Self-mixing interferometry (SMI) is suitable to sense and measure vibrations of amplitudes ranging from picometers to millimeters at frequencies from sub-Hz to MHz’s. As an optical probe, SMI has the advantage of being non-invasive with the ability to measure without any treatment of the target surface and operate from a substantial standoff distance from the target. As an additional advantage, the SMI configuration is much simpler than that of conventional interferometers as it does not require any optical part external to the laser source. After a short introduction to the basics of SMI, we review the development of configurations of SMI instruments for vibration measurements, based on both analog and digital processing, with record performance to cover the range of vibration amplitudes from 0.1 nm to 1 mm, frequencies up to MHz, and stand-off distances up to 100 m. These performances set a benchmark that is unequaled by other approaches reported so far in the literature. The configurations we describe are (i) a simple MEMS-response testing instrument based on fringe counting, (ii) a half-fringe locking vibrometer for mechanical mode analysis and transfer function measurements, with a wide linear response on six decades of amplitude, (iii) a vibrometer with analog switching cancellation for μm-to-mm amplitude of vibrations, and (iv) a long standoff distance vibrometer for testing large structures at distances up to 100 m and with nm sensitivity. Lastly, as the vibrometer will almost invariably operate on untreated, diffusing surfaces, we provide an evaluation of phase-induced speckle pattern errors affecting the SMI measurement. Full article

In the current economic situation of many companies, the need to reduce production time is a critical element. However, this cannot usually be carried out with a decrease in the quality of the final product. This article presents a possible solution for reducing the time needed for quality management. With the use of modern solutions such as optical measurement systems, quality control can be performed without additional stoppage time. In the case of single-point measurement with the Laser Doppler Vibrometer, the measurement can be performed quickly in a matter of milliseconds for each product. This article presents an example of such quality assurance measurements, with the use of fully non-contact methods, together with a proposed evaluation criterion for quality assessment. The proposed quality assurance algorithm allows the comparison of each of the products’ modal responses with the ideal template and stores this information in the cloud, e.g., in the company’s supervisory system. This makes the presented 3D Laser Vibrometry System an advanced instrumentation and data acquisition system which is the perfect application in the case of a factory quality management system based on the Industry 4.0 concept. Full article

Laser Doppler vibrometers (LDVs) have been widely adopted due to their large number of benefits in comparison to traditional contacting vibration transducers. Their high sensitivity, among other unique characteristics, has also led to their use as optical microphones, where the measurement of object vibration in the vicinity of a sound source can act as a microphone. Recent work enabling full correction of LDV measurement in the presence of sensor head vibration unlocks new potential applications, including integration within autonomous vehicles (AVs). In this paper, the common AV challenge of object classification is addressed by presenting and evaluating a novel, non-contact vibro-acoustic object recognition technique. This technique utilises a custom set-up involving a synchronised loudspeaker and scanning LDV to simultaneously remotely solicit and record responses to a periodic chirp excitation in various objects. The 864 recorded signals per object were pre-processed into spectrograms of various forms, which were used to train a ResNet-18 neural network via transfer learning to accurately recognise the objects based only on their vibro-acoustic characteristics. A five-fold cross-validation optimisation approach is described, through which the effects of data set size and pre-processing type on classification accuracy are assessed. A further assessment of the ability of the CNN to classify never-before-seen objects belonging to groups of similar objects on which it has been trained is then described. In both scenarios, the CNN was able to obtain excellent classification accuracy of over 99.7%. The work described here demonstrates the significant promise of such an approach as a viable non-contact object recognition technique suitable for various machine automation tasks, for example, defect detection in production lines or even loose rock identification in underground mines. Full article

In this paper, we present how complementary characterization techniques, such as electrical measurements with a vector network analyzer (VNA), optical measurements with a laser Doppler vibrometer (LDV), and numerical simulations with the finite element method, coupled with spectral domain analysis (FEMSDA), allow us to independently access different properties of a SAW device and fully characterize its operation using the coupling-of-modes theory (COM). A set of chemical SAW sensors coated with parylene C layers of different thicknesses (1, 1.5, and 2 µm) and an uncoated sensor were used as test samples. The sensors represent dual-channel electroacoustic delay lines operating in the vicinity of 77 MHz. The IDTs consist of split aluminum electrodes deposited on a AT-cut quartz substrate. The thickness-dependent influence of the parylene C layer was observed on the operating frequency (SAW velocity), static capacitance, attenuation, crosstalk, and reflection coefficient. COM parameters were reported for the four cases considered; measured and simulated data show good agreement. The presented approach is suitable for the design, characterization, and validation of polymer film-coated SAW sensors. Full article

Structural health monitoring of lightweight constructions made of composite materials can be performed using guided ultrasonic waves. If modern fiber metal laminates are used, this requires integrated sensors that can record the inner displacement oscillations caused by the propagating guided ultrasonic waves. Therefore, we developed a robust MEMS vibrometer that can be integrated while maintaining the structural and functional compliance of the laminate. This vibrometer is directly sensitive to the high-frequency displacements from structure-borne ultrasound when excited in a frequency range between its first and second eigenfrequency. The vibrometer is mostly realized by processes earlier developed for a pressure sensor but with additional femtosecond laser ablation and encapsulation. The piezoresistive transducer, made from silicon, is encapsulated between top and bottom glass lids. The eigenfrequencies are experimentally determined using an optical micro vibrometer setup. The MEMS vibrometer functionality and usability for structural health monitoring are demonstrated on a customized test rig by recording application-relevant guided ultrasonic wave packages with a central frequency of 100 kHz at a distance of 0.2 m from the exciting ultrasound transducer. Full article

Multilayer Ceramic Capacitors (MLCC) have a major role in modern electronic devices due to their small price and size, large range of capacitance, small ESL and ESR, and good frequency response. Unfortunately, the main dielectric material used for MLCCs, Barium Titanate, makes the capacitors vibrate due to the piezoelectric and electrostrictive effects. This vibration is transferred to the PCB, making it resonate in the audible range of 20 Hz–20 kHz, and in this way the singing capacitors phenomenon occurs. This phenomenon is usually measured with a microphone, to measure the sound pressure level, or with a Laser Doppler Vibrometer (LDV), to measure the vibration. Besides this, other methods are mentioned in the literature, for example, the optical fiber and the active excitation method. There are several solutions to attenuate or even eliminate the acoustic noise caused by MLCC. Specially designed capacitors for low acoustic levels and different layout geometries are only two options found in the literature. To prevent the singing capacitor phenomenon, different simulations can be performed, the harmonic analysis being the most popular technique. This paper is an up-to-date review of the acoustic noise caused by MLCCs in electronic devices, containing measurements methodologies, solutions, and simulation methods. Full article

Ultrasonic time-of-flight (ToF) measurements enable the non-destructive characterization of material parameters as well as the reconstruction of scatterers inside a specimen. The time-consuming and potentially damaging procedure of applying a liquid couplant between specimen and transducer can be avoided by using air-coupled ultrasound. However, to obtain accurate ToF results, the waveform and travel time of the acoustic signal through the air, which are influenced by the ambient conditions, need to be considered. The placement of microphones as signal receivers is restricted to locations where they do not affect the sound field. This study presents a novel method for in-air ranging and ToF determination that is non-invasive and robust to changing ambient conditions or waveform variations. The in-air travel time was determined by utilizing the azimuthal directivity of a laser Doppler vibrometer operated in refracto-vibrometry (RV) mode. The time of entry of the acoustic signal was determined using the autocorrelation of the RV signal. The same signal was further used as a reference for determining the ToF through the specimen in transmission mode via cross-correlation. The derived signal processing procedure was verified in experiments on a polyamide specimen. Here, a ranging accuracy of $<0.1$ mm and a transmission ToF accuracy of $0.3$$\mathsf{\mu }$s were achieved. Thus, the proposed method enables fast and accurate non-invasive ToF measurements that do not require knowledge about transducer characteristics or ambient conditions. Full article

Making use of magnetic resonance imaging (MRI) for diagnostics on patients with implanted medical devices requires caution due to mutual interactions between the device and the electromagnetic fields used by the scanner that can cause a number of adverse events. The presented study offers a novel test method to quantify the risk of unintended output of acoustically stimulating hearing implants. The design and operating principle of an all-optical, MRI safe vibrometer is outlined, followed by an experimental verification of a prototype. Results obtained in an MRI environment indicate that the system can detect peak displacements down to 8 pm for audible frequencies. Feasibility testing was performed with an active middle ear implant that was exposed to several pulse sequences in a 1.5 Tesla MRI environment. Magnetic field induced actuator vibrations, measured during scanning, turned out to be equivalent to estimated sound pressure levels between 25 and 85 dB SPL, depending on the signal frequency. These sound pressure levels are situated well below ambient sound pressure levels generated by the MRI scanning process. The presented case study therefore indicates a limited risk of audible unintended output for the examined hearing implant during MRI. Full article

Vibration measurements of turbomachinery components are of utmost importance to characterize the dynamic behavior of rotating machines, thus preventing undesired operating conditions. Local techniques such as strain gauges or laser Doppler vibrometers are usually adopted to collect vibration data. However, these approaches provide single-point and generally 1D measurements. The present work proposes an optical technique, which uses two low-speed cameras, a multimedia projector, and three-dimensional digital image correlation (3D-DIC) to provide full-field measurements of a bladed disk undergoing harmonic response analysis (i.e., pure sinusoidal excitation) in the kHz range. The proposed approach exploits a downsampling strategy to overcome the limitations introduced by low-speed cameras. The developed experimental setup was used to measure the response of a bladed disk subjected to an excitation frequency above 6 kHz, providing a deep insight in the deformed shapes, in terms of amplitude and phase distributions, which could not be feasible with single-point sensors. Results demonstrated the system’s effectiveness in measuring amplitudes of few microns, also evidencing blade mistuning effects. A deeper insight into the deformed shape analysis was provided by considering the phase maps on the entire blisk geometry, and phase variation lines were observed on the blades for high excitation frequency. Full article
