Search Results (107)

The sub-synchronous oscillation (SSO) characteristics and suppression strategies of a hybrid system comprising doubly fed induction generator (DFIG)-based wind turbines and synchronous pumped storage units connected to the power grid via series-compensated transmission lines are analyzed. A modular modeling approach is used to construct a detailed system model, including the wind turbine shaft system, DFIG, converter control system, synchronous machine, excitation system, power system stabilizer (PSS), and series-compensated transmission lines. Eigenvalue calculation-based small-signal stability analysis is conducted to identify the dominant oscillation modes. Suppression measures are also developed using relative participation analysis, and simulations are carried out to validate the accuracy of the model and analysis method. The analysis results indicate that the SSO phenomenon is primarily influenced by the electrical state variables of the DFIG system, while the impact of the state variables of the synchronous machine is relatively minor. When the level of series compensation in the system increases, SSO is significantly exacerbated. To address this issue, a sub-synchronous damping controller (SSDC) is incorporated on the rotor side of the DFIG. The results demonstrate that this method effectively mitigates the SSO and significantly enhances the system’s robustness against disturbances. Furthermore, a simplified modeling approach is proposed based on relative participation analysis. This method neglects the dynamic characteristics of the synchronous machine while considering its impact on the steady-state impedance and initial conditions of the model. These findings provide theoretical guidance and practical insights for addressing and mitigating SSO issues in hybrid renewable energy systems composed of DFIGs and synchronous machines. Full article

The present study investigates the control strategy of a novel doubled-fed induction generator (DFIG) with a series grid-side converter (SGSC) during grid faults. The rotor-side inverter is subject to a control strategy derived from the Model Predictive Current Control (MPCC) theory, which is implemented during periods of fault occurrence; for the series grid-side converter, the positive and negative sequence component control is implemented during both steady state and fault periods to enhance system stability and performance. The proposed coordinated control strategy is implemented on a doubly fed turbine with SGSC, while taking into account different degrees of symmetric and asymmetric faults to further evaluate the efficacy of the proposed method. The results of the simulations demonstrate the efficacy of the model-predictive current control scheme applied to the rotor-side converter under conditions of asymmetric faults. This enables the suppression of a range of phenomena, including rotor overcurrent, stator overcurrent, and overvoltage, electromagnetic torque ripple, and DC bus voltage during low-voltage ride-through (LVRT), among others. The present study confirms the viability of implementing positive and negative sequences of voltage separation control in the SGSC during both grid faults and steady state. This approach is expected to minimize the switching of SGSC control strategies and thereby reduce output power fluctuations. The Rotor Side Converter (RSC) and SGSC can perform coordinated control during faults, and the proposed method is able to improve low-voltage ride-through performance compared to existing methods, thereby preventing damage to the converter under multiple fault conditions. Full article

DFIG rotor windings face high stress and transients from back-to-back converters, causing inter-turn short circuit (ITSC) faults. Rapid rotor-side dynamics, combined with the unique capability of DFIG to operate in multiple modes, make the fault detection in rotor windings more challenging. This paper presents a comprehensive methodology for online ITSC fault diagnosis in DFIG rotor windings based on zero-sequence current (ZSC) component analysis under variable operating conditions. Fault features are identified and defined through the analytical evaluation of the DFIG mathematical model. Further, a simple yet effective algorithm is presented for online implementation of the proposed methodology. Finally, the simulation of the DFIG model is carried out in MATLAB/Simulink under both sub-synchronous and super-synchronous modes, covering a range of variable loads and low-frequency conditions, along with different fault severity levels of ITSC in rotor windings. Simulation results confirm the effectiveness of the proposed methodology for online ITSC fault detection at a low-severity stage and precise location identification of the faulty phase within the DFIG rotor windings under both sub-synchronous and super-synchronous modes. Full article

Power network codes necessitate that any renewable source aligns with LVRT rules and assists in voltage restoration during voltage dips. This paper focuses on increasing the low-voltage ride through capability of a doubly fed induction generator-based wind turbine. Three different controllers are discussed in this article. The first is based on robust super-twisting sliding mode control, which is a recent robust control technique. The second uses a new metaheuristic optimizer called the Arctic Puffin optimizer (APO), and the third relies on the traditional PI controller. The grid-side converter sustains the potential of the DC converter link and the regulation of both the active and reactive power supplied to the power grid via three controllers. The rotor-side converter regulates the generator’s electromagnetic torque via two controllers. Doubly fed induction generator control is a challenging task as the two converters have five controllers, and it is vital to specify the ideal parameters for each controller. In the case of super-twisting sliding mode control, the APO is utilized to obtain the sliding surfaces needed for the five controllers. Moreover, the APO is exploited to obtain the optimal constants of the suggested PI regulators. The simulation results prove the excellent performance of both super-twisting- and APO-based controllers, with better performance demonstrated with super-twisting sliding mode control, which demonstrates excellent transient performance with the least overshoot among the three controllers. The super-twisting-based controller has a distinct feature, as it has good performance with parameter variations. Full article

The full-size converter-based variable-speed pumped storage unit (FSC-VSPSU) is widely regarded as the future direction of variable-speed pumped storage technology due to its wide operating range and fast switching capabilities. However, previous studies often assume a constant DC-link voltage, which is not applicable to FSC-VSPSU, as fluctuations in grid-side active power can affect the DC-link voltage, thereby threatening system stability. To address this issue, this article proposes a crowbar-less low-voltage ride-through (LVRT) control strategy for FSC-VSPSU. The proposed approach effectively mitigates the elevated system costs inherent in conventional crowbar circuit implementations by harnessing the significant energy storage potential of the rotor to absorb power imbalances during LVRT. Furthermore, a novel parameter design methodology for the DC-link voltage controller is introduced to guarantee that the DC-link voltage consistently remains within the allowable threshold range during LVRT. The effectiveness of the proposed control strategy and the accuracy of the parameter design methodology have been validated through MATLAB(R2023a)/Simulink. Full article

The bacterial flagellum, a complex nanomachine composed of numerous proteins, is utilized by bacteria for swimming in various environments and plays a crucial role in their survival and infection. The flagellar motor is composed of a rotor and stator complexes, with each stator unit functioning as an ion channel that converts flow from outside of cell membrane into rotational motion. Paenibacillus sp. TCA20 was discovered in a hot spring, and a structural analysis was conducted on the stator complex using cryo-electron microscopy to elucidate its function. Two of the three structures (Classes 1 and 3) were found to have structural properties typical for other stator complexes. In contrast, in Class 2 structures, the pentamer ring of the A subunits forms a C-shape, with lauryl maltose neopentyl glycol (LMNG) bound to the periplasmic side of the interface between the A and B subunits. This interface is conserved in all stator complexes, suggesting that hydrophobic ligands and lipids can bind to this interface, a feature that could potentially be utilized in the development of novel antibiotics aimed at regulating cell motility and infection. Full article

Wind energy is essential for promoting sustainability and renewable power solutions. However, ensuring stability and consistent performance in DFIG-based wind turbine systems (WTSs) remains challenging due to rapid wind speed variations, grid disturbances, and parameter uncertainties. These fluctuations result in power instability, increased overshoot, and prolonged settling times, negatively impacting grid compliance and system efficiency. Conventional proportional-integral (PI) controllers are simple and effective in steady-state conditions, but they lack adaptability in dynamic situations. Similarly, artificial intelligence (AI)-based controllers, such as fuzzy logic controllers (FLCs) and artificial neural networks (ANNs), improve adaptability but suffer from high computational demands and training complexity. To address these limitations, this paper presents a hybrid adaptive neuro-fuzzy inference system (ANFIS)-PI controller for DFIG-based WTS. The proposed controller integrates fuzzy logic adaptability with neural network-based learning, allowing real-time optimization of control parameters. Implemented within the rotor-side converter (RSC) and grid-side converter (GSC), ANFIS enhances reactive power management, grid compliance, and overall system stability. The system was tested under a step wind speed signal varying from 10 m/s to 12 m/s to evaluate its robustness. The simulation results confirmed that the ANFIS-PI controller significantly improved performance compared with the conventional PI controller. Specifically, it reduced rotor speed overshoot by 3%, torque overshoot by 12.5%, active power overshoot by 2%, and DC link voltage overshoot by 20%. Additionally, the ANFIS-PI controller shortened settling time by 50% for rotor speed, by 25% for torque, by 33% for active power, and by 16.7% for DC link voltage, ensuring faster stabilization, enhanced dynamic response, and greater efficiency. These improvements establish the ANFIS-PI controller as an advanced, computationally efficient, and scalable solution for enhancing the reliability of DFIG-based WTS, facilitating seamless integration of wind energy into modern power grids. Full article

With the increase in reliance on doubly fed induction generator-based wind energy conversion systems (DFIG-WECSs), extracting maximum power from wind energy and enhancing fault ride-through (FRT) techniques meeting the grid code requirements is the foremost concern. This paper proposes a modified control scheme that operates in normal running conditions and during faults as a dual mode. The proposed control scheme operates in a coordinated wind speed estimation-based maximum power point tracking (WSE-MPPT) mode during normal running conditions to extract maximum power from wind energy and enhances the crowbar rotor active impedance-based FRT mode during faults. The proposed technique controls the rotor side converter (RSC) parameters during faults by limiting the transient surge in the rotor and stator currents. In this study, the transient behavior of the proposed technique is analyzed under a three-phase symmetrical fault with a severe voltage dip, and it is observed that, when the fault is over and the RSC is activated and connected to the system, a large inrush current is produced with transient oscillations; the proposed scheme suppresses this post-fault inrush current and limits the transient oscillation. During the FRT operating mode under a symmetrical fault, the simulation results of the proposed technique are validated by the conventional crowbar strategy. In contrast, during the WSE-MPPT operating mode under normal running conditions, a smooth achievement of system parameters after starting the inrush period to a steady state at fixed wind speed is observed. Full article

With the escalating proliferation of wind power plants, the imperative focus on system robustness and stability intensifies. Doubly fed induction machines (DFIMs) are extensively employed in land-based wind power plants due to their performance advantages. While the stator windings are directly connected to the power system, the rotor windings are connected via power converters, making these units vulnerable to voltage disturbances. During faults, voltage drops at the stator terminals lead to elevated voltages and currents on the rotor side due to electromagnetic coupling between stator and rotor, potentially damaging rotor insulation and costly power electronics. Historically, wind power plants employing DFIMs were disconnected from the grid during faults—an unsatisfactory solution given the burgeoning number of these installations. Consequently, grid operators and IEEE standard 2800 mandate fault ride-through (FRT) capabilities to maintain system stability during disturbances. This paper provides a short review of the existing techniques for protecting DFIMs during faults, focusing on both passive and active protection methods. Additionally, a simple calculation is presented to compare two different protection strategies, illustrating the differences in their effectiveness. The review emphasizes the necessity for developing models that represent all protection methods for DFIMs, due to the clear differences in the results obtained. Full article

This paper addresses the challenge of developing a cost-effective and efficient soft-starting method for doubly fed induction machines (DFIMs), a critical requirement for various industrial applications, such as pumped-storage hydropower. The research aims to improve a previously developed starting method by introducing a rotor-side synchronization technique at standstill conditions, which simplifies the starting process and eliminates the need for additional equipment such as autotransformers, resistors, or auxiliary converters. The proposed method begins with the stator winding being fed directly from the power system, while the rotor-side converter adjusts the voltage and frequency to achieve synchronization. Once synchronized, the rotor frequency is gradually reduced by the converter, resulting in a smooth acceleration of the machine. The methodology is validated through a combination of simulations and experimental testing, demonstrating the effectiveness of the proposed approach. The results reveal smooth startup dynamics, with significant reductions in electrical stress, operational complexity, and converter sizing requirements compared to existing methods. Notably, the magnetizing current is supplied directly by the power system through the stator, reducing the burden on the rotor converter by 60% compared to the previous method. The conclusions highlight the method’s robustness and its potential as a superior alternative to existing DFIM starting techniques. Full article

This paper presents the design of a fault-tolerant control system based on fault estimation, aimed at enhancing the sustainability and efficiency of a wind energy conversion system using a doubly-fed induction generator. The control architecture comprises a rotor-side converter (RSC) and a grid-side converter (GSC). The RSC is responsible for regulating both active and reactive power, and its model incorporates two linear subsystem representations. A fault-tolerant control (FTC) scheme is developed using a state-feedback controller; this controller is applied to regulate stator and rotor currents. Additionally, for comparison purposes, Proportional–Integral (PI) and Sliding-Mode Controllers (SMCs) are designed to analyze the performance of each controller. Furthermore, a proportional integral observer is employed in the proposed fault-tolerant scheme for actuator fault estimation. Fault detection is achieved by comparing the fault estimation signal with a predefined threshold. The main contribution of this work is the design and validation of a comprehensive active FTC scheme that enhances system reliability and sustainability. It also includes a performance analysis comparing three controllers (PI, SMC, and state-feedback) applied to the RSC. These controllers are evaluated for their ability to regulate active and reactive power in a wind energy conversion system under conditions of non-constant actuator faults. Full article

The significance of low voltage ride-through (LVRT) capability in wind energy conversion systems (WECSs) is paramount for ensuring grid stability and reliability during voltage dips. This systematic review delves into the advancements, challenges, and methodologies associated with LVRT capabilities in WECSs. By synthesizing recent research findings, this review highlights technological innovations, control strategies, and regulatory requirements that influence LVRT performance. Key insights include the efficacy of various LVRT techniques, the role of grid codes in shaping LVRT standards, and the integration of advanced control algorithms to improve system resilience. The study offers a comprehensive understanding of the current landscape of LVRT in WECSs and pinpoints future research directions to optimize their performance in increasingly complex grid environments. During the LVRT process, the stator of a double-fed induction generator (DFIG) is directly linked to the power grid. When the external power grid experiences a failure, the stator flux produces a significant transient component, resulting in substantial overvoltage and overcurrent on the rotor side of the DFIG. Failure to implement preventative measures may result in damage to the converter, therefore compromising the safety and stability of how the power system functions. Full article

The doubly-fed induction generator (DFIG) is vulnerable to overcurrent at the stator winding and overvoltage at the DC link due to voltage drop after the grid fault. The large wind farm may have a capacity of several million MWs, whose tripping yields a notable power imbalance and frequency drop in the power systems, which may be avoided by the low-voltage ride-through (LVRT) strategies implemented with the hardware or software. The latter has the merits of low cost and easy to realize, thus studied in this paper. Considering the grid fault uncertainty and DFIG parameters’ correlation, this paper newly introduces the sliding mode structure into the passive control to improve the performance of the inner current control loop of the rotor-side converter (RSC), thus proposing a passive sliding mode control (P-SMC) based RSC control strategy to improve the LVRT capability of the DFIG. The time domain analysis with different fault severities, i.e., voltage drops, at the point of public coupling (PCC) is performed. The simulation results with the P-SMC control or not are obtained and compared to verify the control effect and the robustness of the proposed LVRT strategy. This study is beneficial for maintaining power system security against fast-increasing wind power. Full article

Turbine systems equipped with doubly fed induction generation (DFIG) are becoming increasingly vital in wind power generation, with the reliability of the devices serving as a pillar in the industrial sector. Thermal stress and lifetime assessment are fundamental indicators in this regard. This paper primarily addresses the thermal stress and lifespan of power semiconductor devices utilized in a DFIG grid-side converter (GSC) and rotor-side converter (RSC). PLECS (Piecewise Linear Electrical Circuit Simulation) is employed to validate the electrical and thermal stress of the power devices. Additionally, Ansys Icepak, a finite element analysis (FEA) software, is utilized to confirm temperature fluctuations under various operations. The power consumption and junction temperature of the power devices in the GSC and RSC of a 2 MW DFIG are compared. It is evident that the most stressed power semiconductor is the IGBT for the GSC with a temperature swing of 3.4 °C, while the diode in the RSC is the most stressed with a temperature swing of 10.1 °C. This paper also presents a lifetime model to estimate the lifespan of the power device based on the annual wind profile. By considering the annual mission profile, we observe that the lifetime of the back-to-back power converter is limited by the diode of the RSC, whose B₁₀ lifetime is calculated at 15 years. Full article

This work deals with doubly fed induction generator (DFIG) modeling and stability when connected to weak AC grids. A detailed state-space model that includes the phase-locked loop (PLL) is developed. This work aims to determine the influence of the network’s strength on DFIG stability through the short-circuit ratio (SCR). The critical values of the proportional control parameters of the grid-side and rotor-side converters (RSC and GSC), as well as PLL, which make the system unstable, are calculated for different SCR values. Finally, PSCAD/EMTDC dynamic simulations are used to validate the critical control parameters obtained by studying the eigenvalues of the DFIG state-space model regarding system stability. Full article
