The joint is the weak point of HV (high voltage) cable insulation systems; creep discharge between insulation layers of the cable joint, due to moisture intrusion, is one of the main defects leading to single-phase grounding. Carbonization on the insulation interface after creep discharge would lead to a short-circuit defect in the sheath loops and result in abnormal sheath current. In this study, a novel diagnostic criterion using the phasor difference of sheath currents at both ends of the same circuit is proposed. The coupling effect between the sheath and the conductor under defect conditions is considered, and the original lumped parameter model of the cable circuit is optimized. The cable parameters are further corrected using a genetic algorithm. The diagnostic criterion comprehensively accounts for the adverse effects of unequal cable segment lengths, load current fluctuations, grounding impedance, and phase voltage variations. When the phase angle fluctuation of the phasor difference is within 10° and the defect impedance is below 100 Ω, the defective joint can be accurately diagnosed by this method. The conclusion has been validated through PSCAD simulations, with a diagnostic accuracy above 97%. Even under 20 dB noise interference, the error increase remains within 2%. Full article

Power transmission infrastructure requires continuous inspection to prevent failures and ensure grid stability. UAV-based systems, enhanced with deep learning, have emerged as an efficient alternative to traditional, labor-intensive inspection methods. However, most existing approaches rely on separate models for cable segmentation and anomaly detection, leading to increased computational overhead and reduced reliability in real-time applications. To address these limitations, we propose PowerLine-MTYOLO, a lightweight, one-stage, multitask model designed for simultaneous power cable segmentation and broken strand detection from UAV imagery. Built upon the A-YOLOM architecture, and leveraging the YOLOv8 foundation, our model introduces four novel specialized modules—SDPM, HAD, EFR, and the Shape-Aware Wise IoU loss—that improve geometric understanding, structural consistency, and bounding-box precision. We also present the Merged Public Power Cable Dataset (MPCD), a diverse, open-source dataset tailored for multitask training and evaluation. The experimental results show that our model achieves up to +10.68% mAP@50 and +1.7% IoU compared to A-YOLOM, while also outperforming recent YOLO-based detectors in both accuracy and efficiency. These gains are achieved with a smaller model memory footprint and a similar inference speed compared to A-YOLOM. By unifying detection and segmentation into a single framework, PowerLine-MTYOLO offers a promising solution for autonomous aerial inspection and lays the groundwork for future advances in fine-structure monitoring tasks. Full article

This paper investigates the influence of skin and proximity effects on power losses in segmented power cables using finite element (FE) analysis. Two-dimensional (2D) and three-dimensional (3D) FE models are developed to evaluate the AC-to-DC resistance ratio ($R_{\mathrm{AC}}/R_{\mathrm{DC}}$) in single-, three-, and five-segment cable configurations. Frequencies of 0, 50, 150, and 250 Hz are considered under an infinite lay length (parallel strands) assumption. This study reveals that 2D modeling provides nearly identical $R_{\mathrm{AC}}/R_{\mathrm{DC}}$ values to 3D, with deviations of less than 0.6% at 50 Hz when no twisting is present. This highlights the computational efficiency of 2D models for certain cable designs without compromising accuracy. Furthermore, this paper examines the mesh refinement and sub-conductor geometry (hexagonal packing) of underground cables under full compression assumption. The results underscore the viability of 2D cross-sectional simulations for multi-segment cables, ensuring accurate loss predictions while saving considerable computational resources. Full article

Recent increases in rainfall duration and intensity due to climate change have heightened the importance of levee stability. However, previous studies on levee failure, primarily caused by seepage and overtopping, have mostly examined these causes independently owing to their distinct characteristics. In this study, we conducted lateral overtopping failure experiments under seepage conditions that closely resembled those in experiments conducted in previous studies. Seepage was monitored using water pressure sensors and a distributed optical fiber cable that provided continuous heat for temperature monitoring in the levee. Τhe analysis of levee failure due to lateral overtopping, in the presence of seepage, was conducted using image analysis with digitization techniques and machine learning-based color segmentation techniques on the protected lowland side of the levee, targeting the same area. The results revealed that levee failure occurred more than twice as fast in experiments where seepage conditions were considered compared to the experiments where they were not. Thus, levees weakened by seepage are more vulnerable to overtopping and breaching. Consequently, employing a comprehensive approach that integrates various monitoring and analysis methods for assessing levee stability is preferable to relying on a single method alone. Full article

Continuous robots have attracted more and more attention from the robotics community due to their high degree of flexibility and pliability, and have shown great potential for application in a variety of fields. With the continuous progress of material science, control technology, and artificial intelligence, the performance and application range of soft robotics have been further expanded, in which the cable drive has the advantages of large workspace, high flexibility, etc. The cable-driven soft robotic arm serves as an ultra-redundant robot that can operate in cramped and confined environments. In this paper, a cable-driven soft robot based on soft continuums and a cross gimbal is presented. The kinematics of the cable-driven soft robot is modeled and the mapping relations of the kinematics are solved by the D–H method and piecewise constant curvature, and the relations between the cable length, joint angle, and pose are further derived. Finally, the motion space of the cable-driven soft robot in the three-dimensional coordinate system is obtained by MATLAB2021b, and the single-segment soft body is simulated and analyzed using ADAMS to compare the theoretical data with the actual data and verify the reliability of this structure and method. Full article

Due to the capability of multiplexing thousands of sensors on a single optical cable, ultra-weak fiber Bragg grating (UWFBG) vibration sensing technology has been utilized in monitoring the vibration response of large-scale infrastructures, particularly urban railway tracks, and the volume of the collected monitoring data can be huge with the great number of sensors. Even though the train-induced vibration responses of urban railway tracks constitute the most informative and crucial component, they comprised less than 7% of the total operational period. This is mainly attributed to the temporal sparsity of commuting trains. Consequently, the majority of the stored data consisted of low-informative environmental noise and interference excitation data, leading to an inefficient structural health monitoring (SHM) system. To address this issue, this paper introduced an adaptive monitoring strategy for railway track structures, which is capable of identifying train-load patterns by leveraging deep learning techniques. Inspired by image semantic segmentation, a U-net model with one-dimensional convolution layers (U-net-1D) was developed for the pointwise classification of vibration monitoring data. The proposed model was trained and validated using a dataset obtained from an actual urban railway track in China. Results indicated that the proposed method outperforms the traditional dual-threshold method, achieving an Intersection over Union (IoU) of 94.27% on the segmentation task of the test dataset. Full article

The universal hinge support (UHS) is a new connection system for the tower and pier of a single-tower cable-stayed bridge (STCSB), which could conform the multi-direction rotation of the tower and release the bending moment at the bottom of the tower in all directions. However, UHS is not an ideal hinge in practical projects, and the rotational constraint stiffness (RCS) of UHS is constantly changed with construction. In order to determine the RCS of UHS in situ, parametric analysis was performed by establishing a theoretical mechanical model of plane rotation and a refined solid finite element (FE) model of UHS. The slope of the linear rising segment of the load–displacement curve obtained from the numerical simulation was considered as the RCS of the UHS. The relationships between RCS and the vertical force, geometric parameters, and material parameters were established, and then the calculation formula of RCS was further proposed. To verify the accuracy of the proposed formula, a case study for a real bridge was conducted in this paper. The results show that the error of the tower rotation displacement can be reduced by about 90% using the proposed method compared with the conventional method, which regards the hinge as an ideal one, and the precision is greatly improved. This study has enormous potential to quickly determinate the RCS of UHS in practical applications, and plays a great promotion role in enriching the structural system of cable-stayed bridges. Full article

High voltage direct current (HVDC) transmission systems play an increasingly important role in long-distance power transmission. Realizing accurate and timely fault location of transmission lines is extremely important for the safe operation of power systems. With the development of modern data acquisition and deep learning technology, deep learning methods have the feasibility of engineering application in fault location. The traditional single-terminal traveling wave method is used for fault location in HVDC systems. However, many challenges exist when a high impedance fault occurs including high sampling frequency dependence and difficulty to determine wave velocity and identify wave heads. In order to resolve these problems, this work proposed a deep hybrid convolutional neural network (CNN) and long short-term memory (LSTM) network model for single-terminal fault location of an HVDC system containing mixed cables and overhead line segments. Simultaneously, a variational mode decomposition–Teager energy operator is used in feature engineering to improve the effect of model training. 2D-CNN was employed as a classifier to identify fault segments, and LSTM as a regressor integrated the fault segment information of the classifier to achieve precise fault location. The experimental results demonstrate that the proposed method has high accuracy of fault location, with the effects of fault types, noise, sampling frequency, and different HVDC topologies in consideration. Full article

In this study, a numerical model is proposed for the analysis of a simply supported structural cable. Smoothed particle hydrodynamics (SPH)—a mesh-free, Lagrangian method with advantages for analysis of highly deformable bodies—is utilized to model a cable. In the proposed numerical model, it is assumed that a cable has only longitudinal stiffness in tension. Accordingly, SPH equations derived for solid mechanics are adapted for a structural cable, for the first time. Besides, a proper damping parameter is introduced to capture the behavior of the cable more realistically. In order to validate the proposed numerical model, different experimental and numerical studies available in the literature are used. In addition, novel experiments are carried out. In the experiments, different harmonic motions are applied to a uniformly loaded cable. Results show that the SPH method is an appropriate method to simulate the structural cable. Full article

The paper presents the possibility of using cable screen earthing current measurements for MV, single-core cable line monitoring. Cable screen earthing current measurement allows the condition of cable screen connections, degradation of earthing systems, and the earthing system integrity to be observed, which allows a condition based maintenance (CBM) strategy to be introduced for cable screens and earthing systems in MV networks. CBM allows the workload and failure rate to be reduced. Analysis of the condition of the cable screen and earthing system is carried out based on the cable screen earthing current trends and rapid changes of the current. The proposed system is integrated with a state of the art advanced metering infrastructure (AMI) and uses AMI data to calculate currents flowing through cable segments of the analyzed feeder. Additionally, a system which counts thermo-mechanical stresses associated with high current incidents in cable screens is proposed. The stresses are assessed using data from conventional protection relays and the ratio of currents in the cable core and cable screens. The stresses can be used as an indicator of the cable joint condition. The presented phenomena are studied carefully in PowerFactory software. Theoretical considerations are confirmed using measurements taken in the real MV cable line. Finally, the results of a SWOT analysis are presented and future research activities are outlined. Full article

Different from the traditional goaf-side entry in the mining face, a goaf-side entry driving heading mining face can greatly alleviate the problem of mining and excavation replacement tension under the high-intensity mining condition of a single-wing mine, withstanding the whole process of the fracture, rotation, and sinking of key blocks in the overlying rock layer, which is extremely difficult to maintain. Taking the roadway layout in a single-wing mining face of a coal mine in Neimenggu, China as the research background, first, the stress environment and structural stability characteristics of a goaf-side entry driving heading mining face is qualitatively analyzed with the theoretical analysis method according to five different stages. Secondly, the distribution and evolution law of stress and displacement with a goaf-side entry driving heading mining face are systematically studied during the whole process of advanced mining, excavation, and mining with the numerical simulation method, and the reasonable width of the section of the coal pillar is determined to be 6.0 m. Finally, the deformation laws of a goaf-side entry driving heading mining face are revealed with the field survey method: (1) the stage of advanced mining—the function relation between the distance of the excavation and mining face and roadway displacement is approximately the logistic function; (2) the stage of goaf-side entry driving—the function relation between roadway displacement and the driving distance basically forms the exponential function. Based on the above research, the dynamic segmentation control principle of “high-resistance support, dynamic monitoring, sectional control, consolidation coal sides, and stable roof control” and the dynamic segmentation control technology of “section combined strong support of anchor, net, cable, and beam, narrow coal pillar grouting and reinforcement in key periods, strengthening support of the roof with a single pillar π steel beam”, and industrial tests are carried out on site. The monitoring results of the underground pressure show that the deformation failure of the goaf-side entry driving heading mining face is effectively controlled with the control principle and technology, the difficult problem of mining and excavation replacement tension is alleviated with the single-wing mine, and the useful reference and reference for the engineering practice under similar conditions are provided. Full article

The rail-cable-shifting-girder (RCSG) technique is a new erecting method for the main girders of the long span suspension bridge in rural mountain areas with poor transportation and no navigable rivers for carrying large components. The pseudo-static analysis of the shifting-girder process for this girder erecting technique is performed. The global mechanical model of the double-layer cable system in the shifting-girder process is established, by analytically modeling the main-cable, rail cable, and slings according to cable’s basic assumptions. Based on the flexible cable theory, the main-cable segments are simulated as segmental catenary elements, the slings are considered as straight cable elements, the rail-cable segment that the shifting-girder trolley is moving on is simulated as multiple straight cable elements and other rail-cable segments are considered as single straight cable elements. The solving program is developed to obtain the pseudo-static responses including the forces and deflections of the shifting-girder system undergoing girder loads. Meanwhile, a global indoor reduced-scale model of shifting-girder system is designed to validate the presented theoretical results, by taking the Aizhai suspension bridge as engineering background. The results from the presented theoretical method match well with the measured experimental results of the indoor model test. The forces and deflections of the main-cable, rail-cable, and slings for the 21 working cases of erecting girder segments exhibit some specific distribution regularities. The presented theoretical method is able to correctly and effectively solve the pseudo-static responses of the RCSG system undergoing girder loads for the long span suspension bridge adopting the construction method of the RCSG technique. Full article

In order to improve the practice in the operation and maintenance of high voltage (HV) cables, this paper proposes a fault location method based on the monitoring of cable sheath currents for use in cross-bonded HV cable systems. This method first analyzes the power–frequency component of the sheath current, which can be acquired at cable terminals and cable link boxes, using a Fast Fourier Transform (FFT). The cable segment where a fault occurs can be localized by the phase difference between the sheath currents at the two ends of the cable segment, because current would flow in the opposite direction towards the two ends of the cable segment with fault. Conversely, in other healthy cable segments of the same circuit, sheath currents would flow in the same direction. The exact fault position can then be located via electromagnetic time reversal (EMTR) analysis of the fault transients of the sheath current. The sheath currents have been simulated and analyzed by assuming a single-phase short-circuit fault to occur in every cable segment of a selected cross-bonded high voltage cable circuit. The sheath current monitoring system has been implemented in a 110 kV cable circuit in China. Results indicate that the proposed method is feasible and effective in location of HV cable short circuit faults. Full article
