Search Results (36)

Search Parameters:
Keywords = stator lamination

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 2155 KB
Article
Analysis of Stator Material Influence on BLDC Motor Performance
by Daniel Ziemiański, Gabriela Chwalik-Pilszyk and Grzegorz Dudzik
Materials 2025, 18(19), 4630; https://doi.org/10.3390/ma18194630 - 7 Oct 2025
Viewed by 445
Abstract
Brushless DC (BLDC) motors are increasingly used in industrial applications due to their high efficiency, reliability, and low weight. However, their performance strongly depends on the electromagnetic properties of stator and rotor core materials. This study evaluates six BLDC motor configurations, employing materials [...] Read more.
Brushless DC (BLDC) motors are increasingly used in industrial applications due to their high efficiency, reliability, and low weight. However, their performance strongly depends on the electromagnetic properties of stator and rotor core materials. This study evaluates six BLDC motor configurations, employing materials such as M19 electrical steel, 1010 low-carbon steel, magnetic PLA, and ABS, and analyzes their impact using FEMM 4.2 finite element simulations. Key electromagnetic characteristics—including flux linkage, Back-EMF, torque, and torque ripple—were compared across configurations. The reference motor with M19 steel stator and 1010 steel rotor achieved ~7 mWb flux linkage, ~39 V pk–pk Back-EMF, and 1.44 Nm torque with ~49% ripple, confirming the suitability of laminated steels for high-power-density designs. Substituting M19 with 1010 steel in the stator reduced torque by less than 10%, indicating material interchangeability with minimal performance loss. By contrast, polymer-based designs exhibited drastic degradation: magnetic PLA yielded only 3.5% of the baseline torque with sixfold ripple increase, while ABS delivered nearly zero torque and >700% ripple. Hybrid configurations improved PLA-based results by 15–20%, though they remained far below ferromagnetic cores. Overall, results demonstrate a nearly linear relationship between material permeability and both flux linkage and Back-EMF, alongside a sharp rise in torque ripple at low permeability. The findings highlight the advantages of ferromagnetic and laminated steel cores for efficiency and stability, while polymer and hybrid cores are limited to lightweight demonstrator applications. Full article
Show Figures

Figure 1

17 pages, 6362 KB
Article
Development of a 3D-Printed BLDC Motor and Controller for Robotic Applications
by Sangsin Park
Actuators 2025, 14(10), 481; https://doi.org/10.3390/act14100481 - 1 Oct 2025
Cited by 1 | Viewed by 837
Abstract
This paper presents the design and experimental validation of a 3D-printed BLDC motor featuring a hollow-shaft rotor and nickel-reinforced stator. The rotor employs neodymium magnets to reduce inertia while maintaining torque density, and the stator integrates thin nickel laminations to improve flux density. [...] Read more.
This paper presents the design and experimental validation of a 3D-printed BLDC motor featuring a hollow-shaft rotor and nickel-reinforced stator. The rotor employs neodymium magnets to reduce inertia while maintaining torque density, and the stator integrates thin nickel laminations to improve flux density. A custom controller with Hall sensors, BiSS-C encoder, and CAN interface enables closed-loop position control. Experiments demonstrate stable tracking with short settling time and negligible steady-state error, confirming feasibility for robotic and precision applications. Full article
(This article belongs to the Special Issue Power Electronics and Actuators—Second Edition)
Show Figures

Figure 1

21 pages, 6144 KB
Article
A Flexible Assembly and Gripping Process of Hairpin Baskets
by Felix Fraider, Peter Dreher, Josette Lindner, Dominik Reichl, Florian Kößler and Jürgen Fleischer
World Electr. Veh. J. 2025, 16(9), 503; https://doi.org/10.3390/wevj16090503 - 7 Sep 2025
Viewed by 572
Abstract
Established hairpin stators for electric traction motors are made up of a large number of so-called hairpins. To produce these stators, the individual hairpins must first be pre-assembled into an auxiliary device in order to achieve the desired winding scheme. The resulting hairpin [...] Read more.
Established hairpin stators for electric traction motors are made up of a large number of so-called hairpins. To produce these stators, the individual hairpins must first be pre-assembled into an auxiliary device in order to achieve the desired winding scheme. The resulting hairpin basket must then be picked up and transported to the lamination stack. Automated solutions for both processes are characterized by a high degree of complexity and low flexibility. Manual assembly, however, is prone to errors. The new approach presented in this paper is therefore based on the collaborative assembly of the hairpins and a flexible hairpin basket gripper. A cobot hands the hairpins in the correct sequence to the operator. The correct positioning of the hairpins in the auxiliary device is ensured by the use of a monitor located under it. The creation of the correct assembly sequence is partly automated by a collision detection program. In addition, a new and flexible hairpin basket gripping concept is presented. Tests show that the cycle times of both new processes are slow due to hardware limitations. This restricts their use to specific applications, such as complex winding patterns or very small quantities. Full article
Show Figures

Figure 1

26 pages, 8721 KB
Article
Experiments in 3D Printing Electric Motors
by Alex Ellery, Abdurr Elaskri, Mariappan Parans Paranthaman and Fabrice Bernier
Machines 2025, 13(8), 679; https://doi.org/10.3390/machines13080679 - 1 Aug 2025
Cited by 1 | Viewed by 1892
Abstract
This paper catalogues a series of experiments we conducted to explore how to 3D print a DC electric motor. The individual parts of the electric motor were 3D printed but assembled by hand. First, we focused on a rotor with soft magnetic properties, [...] Read more.
This paper catalogues a series of experiments we conducted to explore how to 3D print a DC electric motor. The individual parts of the electric motor were 3D printed but assembled by hand. First, we focused on a rotor with soft magnetic properties, for which we adopted ProtoPastaTM, which is a commercial off-the-shelf PLA filament incorporating iron particles. Second, we focused on the stator permanent magnets, which were 3D printed through binder jetting. Third, we focused on the wire coils, for which we adopted a form of laminated object manufacture of copper wire. The chief challenge was in 3D printing the coils, because the winding density is crucial to the performance of the motor. We have demonstrated that DC electric motors can be 3D printed and assembled into a functional system. Although the performance was poor due to the wiring problem, we showed that the other 3D printing processes were consistent with high performance. Nevertheless, we demonstrated the principle of 3D printing electric motors. Full article
(This article belongs to the Special Issue Additive Manufacturing of Electrical Machines)
Show Figures

Figure 1

12 pages, 2261 KB
Communication
Technological Challenges for a 60 m Long Prototype of Switched Reluctance Linear Electromagnetic Actuator
by Jakub Rygał, Roman Rygał and Stan Zurek
Actuators 2025, 14(8), 380; https://doi.org/10.3390/act14080380 - 1 Aug 2025
Viewed by 1531
Abstract
In this research project a large linear electromagnetic actuator (LLEA) was designed and manufactured. The electromagnetic performance was published in previous works, but in this paper we focus on the technological challenges related to the manufacturing in particular. This LLEA was based on [...] Read more.
In this research project a large linear electromagnetic actuator (LLEA) was designed and manufactured. The electromagnetic performance was published in previous works, but in this paper we focus on the technological challenges related to the manufacturing in particular. This LLEA was based on the magnet-free switched-reluctance principle, having six effective energised stator “teeth” and four passive mover parts (4:6 ratio). Various aspects and challenges encountered during the manufacturing, transport, and assembly are discussed. Thermal expansion of steel contributed to the decision of the modular design, with each module having 1.3 m in length, with a 2 mm longitudinal dilatation gap. The initial prototype was tested with a 10.6 m length, with plans to extend the test track to 60 m, which was fully achievable due to the modular design and required 29 tons of electrical steel to be built. The stator laminations were cut by a bespoke progressive tool with stamping, and other parts by a CO2 laser. Mounting was based on welding (back of the stator) and clamping plates (through insulated bolts). The linear longitudinal force was on the order of 8 kN, with the main air gap of 7.5–10 mm on either side of the mover. The lateral forces could exceed 40 kN and were supported by appropriate construction steel members bolted to the concrete floor. The overall mechanical tolerances after installation remained below 0.5 mm. The technology used for constructing this prototype demonstrated the cost-effective way for a semi-industrial manufacturing scale. Full article
(This article belongs to the Section High Torque/Power Density Actuators)
Show Figures

Figure 1

20 pages, 24517 KB
Article
Investigations of Thin-Walled Glass Fiber Reinforced Plastic Laminates with Sealing Function for Electric Motors
by Jan David Hübsch, Nils Meyer, Daniela Feldten, Christian Mittelstedt and Philipp Berendes
J. Compos. Sci. 2025, 9(4), 175; https://doi.org/10.3390/jcs9040175 - 3 Apr 2025
Viewed by 843
Abstract
This article presents, in detail, design considerations for a thin-walled glass fiber reinforced plastic (GFRP) liner on a fluid-cooled stator lamination of an electric motor. In addition to structural requirements due to the cooling fluid pressure, the GFRP liner needs to guarantee impermeability. [...] Read more.
This article presents, in detail, design considerations for a thin-walled glass fiber reinforced plastic (GFRP) liner on a fluid-cooled stator lamination of an electric motor. In addition to structural requirements due to the cooling fluid pressure, the GFRP liner needs to guarantee impermeability. Analytical considerations deriving from different coefficients of thermal expansion (CTEs) determine the two-layered laminate design. Empirical investigations show two innovative, simple, and, therefore, efficient test setups for the leakage of liquid media through a GFRP liner. The weeping investigations employ two different GFRP systems with four different configurations of interfiber failure (IFF) and, therefore, crack densities. The weeping investigations show that at least one ply in the laminate needs to be flawless regarding IFF cracks in order to guarantee the sealing function. Alternatively, a third sealing layer can be used. Full article
(This article belongs to the Section Composites Applications)
Show Figures

Figure 1

19 pages, 12353 KB
Article
The Impact of the Core Laminate Shaping Process on the Parameters and Characteristics of the Synchronous Reluctance Motor with Flux Barriers in the Rotor
by Zbigniew Gmyrek
Energies 2025, 18(5), 1222; https://doi.org/10.3390/en18051222 - 2 Mar 2025
Cited by 1 | Viewed by 1303
Abstract
This article describes the findings of a study that examined the impact of the process of shaping the stator core of a synchronous reluctance motor on its operating parameters. The SynRM motor, with compact geometrical dimensions and a flux barrier rotor, was chosen [...] Read more.
This article describes the findings of a study that examined the impact of the process of shaping the stator core of a synchronous reluctance motor on its operating parameters. The SynRM motor, with compact geometrical dimensions and a flux barrier rotor, was chosen for this study, for which the technological process of forming the stator and rotor cores may be critical. The numerical results for three types of stator core structures were compared. The first, which is commonly used by academics, has no technological cutouts in the stator. The second type has cutouts for the clamps that hold the core laminates together. The third one has cutouts that allow the core to be positioned inside the motor housing. The research campaign also investigated the effect of partial material structure degradation caused by core laminate shaping on motor operation parameters. As a consequence of the computations, the characteristics and motor parameters were compared, including torque ripple, stator core loss, and motor efficiency. It has been demonstrated that, in the case of SynRM motors with relatively small geometric dimensions, technological cutouts caused by the shaping of stator core laminates can drastically influence the motor’s characteristics. Full article
(This article belongs to the Special Issue Design, Analysis, Optimization and Control of Electric Machines)
Show Figures

Figure 1

16 pages, 2846 KB
Article
An Additively Manufactured Fe-3Si Stator for a High-Performance Electrical Motor
by Tej N. Lamichhane, Haobo Wang, Chins Chinnasamy, Latha Sethuraman, Fred A. List, Peeyush Nandwana, Jiaqiang Yan, Zheng Gai and Mariappan Parans Paranthaman
Appl. Sci. 2025, 15(4), 1706; https://doi.org/10.3390/app15041706 - 7 Feb 2025
Cited by 1 | Viewed by 2039
Abstract
Additive manufacturing (AM) has the potential to produce novel high-performance electrical machines, enabling the direct printing of complex shapes and the simultaneous processing of multiple feedstocks in a single build. We examined the properties and functional performance of Fe-3 wt.% Si materials that [...] Read more.
Additive manufacturing (AM) has the potential to produce novel high-performance electrical machines, enabling the direct printing of complex shapes and the simultaneous processing of multiple feedstocks in a single build. We examined the properties and functional performance of Fe-3 wt.% Si materials that were printed via selective laser melting, machined down to thin laminates, and stacked to form a stator core of a prototype brushless permanent-magnet electrical motor. Big Area Additive Manufacturing of Nd2Fe14B (NdFeB)–polyphenylene sulfide (PPS) bonded magnets was performed, with them then being magnetized and used for the rotor. The magnetic, mechanical, and electrical properties of the as-printed and various heat-treated thin laminates and the back electromotive force (EMF) of the electrical motors at different rotational speeds were measured. The thin laminates exhibit a maximum relative permeability of 7494 at an applied field of 0.8 Oe and a core loss of about 20 W/lb at 60 Hz with the maximum induction of 15 kg. In addition to the demonstration of AM printing, motor assembly, and complete characterization of printed Fe-3 wt.% Si, this report highlights the areas of improvement needed in printing technologies to achieve AM built electrical motors and the need for isotropic microstructure refinements to make the laminates appropriate for high-mechanical-strength and low-loss rotational electrical devices. Full article
Show Figures

Figure 1

35 pages, 4557 KB
Review
A Review of Segmented Stator and Rotor Designs in AC Electric Machines: Opportunities and Challenges
by Bhuvan Khoshoo, Anmol Aggarwal and Shanelle Foster
Eng 2025, 6(1), 7; https://doi.org/10.3390/eng6010007 - 1 Jan 2025
Cited by 3 | Viewed by 4653
Abstract
The use of segmented stator and rotor designs in AC electric machine construction offers several significant advantages, including a high-copper fill factor, increased torque density, improved field-weakening performance, simplified manufacturing processes, and enhanced mechanical strength. Additionally, segmented designs allow for the incorporation of [...] Read more.
The use of segmented stator and rotor designs in AC electric machine construction offers several significant advantages, including a high-copper fill factor, increased torque density, improved field-weakening performance, simplified manufacturing processes, and enhanced mechanical strength. Additionally, segmented designs allow for the incorporation of oriented steel—either partially or fully—which exhibits excellent magnetic properties in the rolling direction, resulting in more efficient machine performance. However, lamination segmentation also introduces challenges. Parasitic air gaps between segments and an increased number of cut edges in the assembled stack can alter the magnetic properties of the machine, potentially leading to degraded performance. Furthermore, the use of oriented steel remains complex, as its highly nonlinear magnetic properties vary depending on the direction of the magnetic flux. This paper reviews the widely adopted stator and rotor segmentation techniques available in the literature, discussing their potential benefits and limitations. It also covers key aspects such as popular manufacturing approaches, the impact of segmentation on machine performance, advanced finite-element analysis (FEA) techniques for numerical modeling, and experimental methods for evaluating the performance of segmented stator and rotor constructions in AC machines. By addressing these areas, this work provides a comprehensive resource for machine designers seeking to develop AC machines with segmented stators and rotors. Full article
(This article belongs to the Special Issue Women in Engineering)
Show Figures

Figure 1

14 pages, 9141 KB
Article
End-Region Losses in High-Power Electrical Machines: Impact of Material Thickness on Eddy Current Losses in Clamping Structures
by Walid Mohand Oussaid, Abdelmounaïm Tounzi, Raphaël Romary, Abdelkader Benabou, Walid Boughanmi and Daniel Laloy
Energies 2024, 17(22), 5684; https://doi.org/10.3390/en17225684 - 14 Nov 2024
Cited by 2 | Viewed by 1157
Abstract
High-power electrical machines often utilize clamping structures composed of various materials with specific geometric dimensions to secure the stator laminations. These structures are exposed to end-region magnetic flux, which induces eddy currents, leading to significant power losses that reduce the machine’s efficiency. This [...] Read more.
High-power electrical machines often utilize clamping structures composed of various materials with specific geometric dimensions to secure the stator laminations. These structures are exposed to end-region magnetic flux, which induces eddy currents, leading to significant power losses that reduce the machine’s efficiency. This study systematically investigates the impact of clamping plate thickness on eddy current losses across different materials and operating frequencies. A simplified experimental configuration was established to validate the numerical model developed using 3D Finite Element Method (FEM). This model was used to calculate the eddy current losses and analyze the influence of plate thickness under various conditions. A comprehensive parametric analysis was performed, revealing critical insights into the relationship between material properties, plate thickness, and loss generation. The findings indicate that while thinner plates exhibit higher current density, thicker plates provide a larger volume for current flow, resulting in varying loss patterns depending on the material’s electrical and magnetic properties. The study’s results offer valuable guidance for optimizing clamping structure designs in high-power electrical machines by selecting materials and thicknesses that minimize losses while maintaining mechanical integrity. Full article
Show Figures

Figure 1

16 pages, 8562 KB
Article
A Study on Enhancing Axial Flux Motor Efficiency Using Cladding Core Technology
by Seung-Woo Park, Ju-Hyeong Moon, Dong-Woo Kang and Khac-Huan Su
Mathematics 2024, 12(19), 2981; https://doi.org/10.3390/math12192981 - 25 Sep 2024
Cited by 1 | Viewed by 4344
Abstract
With the rise of eco-friendly policies, advanced motor technologies are being developed to replace fossil fuel-based engines in the mobility industry. Axial flux motors, known for their ability to reduce size and increase output torque compared to radial flux motors, require different materials [...] Read more.
With the rise of eco-friendly policies, advanced motor technologies are being developed to replace fossil fuel-based engines in the mobility industry. Axial flux motors, known for their ability to reduce size and increase output torque compared to radial flux motors, require different materials and manufacturing techniques. Specifically, the production of complex stator cores and segmented magnets presents significant challenges, often leading to higher costs. To address this issue, soft magnetic composite (SMC) materials, which offer greater design flexibility, are being explored for use in stator cores. However, soft magnetic composite materials exhibit lower permeability and saturation flux density compared to laminated silicon steel, resulting in reduced output torque and efficiency. This paper investigates the effects of stator geometry on axial flux motor performance and explores cladding core technology, which combines soft magnetic composite materials with silicon steel. By conducting finite element method (FEM) analysis to evaluate the output torque and efficiency based on the shape of the silicon steel within the cladding core, this study proposes an optimized cladding core design to enhance the efficiency and output torque of axial flux motors. Full article
Show Figures

Figure 1

15 pages, 2352 KB
Article
Development of a Low-Expansion and Low-Shrinkage Thermoset Injection Moulding Compound Tailored to Laminated Electrical Sheets
by Florian Braunbeck, Florian Schönl, Timo Preußler, Hans-Christian Reuss, Martin Demleitner, Holger Ruckdäschel and Philipp Berendes
World Electr. Veh. J. 2024, 15(7), 319; https://doi.org/10.3390/wevj15070319 - 18 Jul 2024
Viewed by 1705
Abstract
This study presents a thermoset moulding compound designed for electrical machines with high power densities. The compound reduces residual stresses induced by the difference in thermal expansion during use and by shrinkage in the compound during the manufacturing process. To reduce the internal [...] Read more.
This study presents a thermoset moulding compound designed for electrical machines with high power densities. The compound reduces residual stresses induced by the difference in thermal expansion during use and by shrinkage in the compound during the manufacturing process. To reduce the internal stresses in the compound, in the electrical sheet lamination and at their interface, first the moulding’s coefficient of thermal expansion (CTE) must match that of the lamination because the CTE of the electrical sheets cannot be altered. Second, the shrinkage of the compound needs to be minimized because the moulding compound is injected around a prefabricated electrical sheet lamination. This provides greater freedom in the design of an electric motor or generator, especially if the thermoset needs to be directly bonded to the electrical sheet. The basic suitability of the material for the injection moulding process was iteratively optimised and confirmed by spiral flow tests. Due to the reduction of the residual stresses, the compound enables efficient cooling solutions for electrical machines with high power densities. This innovative compound can have a significant impact on electric propulsion systems across industries that use laminated electrical sheets. Full article
Show Figures

Figure 1

19 pages, 7842 KB
Article
Process Development of Screen-Printed Magnetic Sheets for Electric Machines via Statistical Design of Experiments
by Alexander Schmidt, Nico Wieprecht, Johannes Schlichting, Stefan Denneler, Jörg Franke and Alexander Kuehl
Metals 2023, 13(11), 1814; https://doi.org/10.3390/met13111814 - 27 Oct 2023
Cited by 3 | Viewed by 2064
Abstract
Electrical machines play a major role in achieving a more sustainable economy by driving the further electrification of industry and transportation. To enhance the electric motor productivity during production and the efficiency during operation, it is essential to maximize the material yield rate [...] Read more.
Electrical machines play a major role in achieving a more sustainable economy by driving the further electrification of industry and transportation. To enhance the electric motor productivity during production and the efficiency during operation, it is essential to maximize the material yield rate during the production of stator and rotor sheet stacks and reduce iron losses during operation. Screen-printing technology can help to achieve these goals by producing thin magnetic sheet laminations in near-net-shape geometry, resulting in minimum material waste during production. Moreover, reducing the sheet thickness decreases the eddy current losses and avoids mechanical stress during manufacturing, leading to improved motor efficiency. Additionally, screen printing facilitates the production of multi-material components and variable alloy compositions. This study aims to identify the relevant factors and printing parameters so that screen-printed magnetic sheets can achieve product specifications. A method involving the statistical design of experiments is performed in several iterations to investigate the target parameters of the print cycle time, green part weight, shape integrity and layer thickness, and to analyze the main interdependencies. The results of this study provide valuable insights into optimizing the screen-printing process for soft magnetic sheets, enabling the production of efficient electric motors while reducing material scrap. Full article
(This article belongs to the Section Powder Metallurgy)
Show Figures

Figure 1

22 pages, 7419 KB
Article
Material Tradeoff of Rotor Architecture for Lightweight Low-Loss Cost-Effective Sustainable Electric Drivetrains
by Ahmed Selema
Sustainability 2023, 15(19), 14413; https://doi.org/10.3390/su151914413 - 1 Oct 2023
Cited by 4 | Viewed by 2534 | Correction
Abstract
The art of the successful design of high-speed electrical machines comes with many challenges in the mass, size, reliability, and energy efficiency. Material engineering of electrical machines has been identified as a key solution for higher power dense electric drivetrains. One of the [...] Read more.
The art of the successful design of high-speed electrical machines comes with many challenges in the mass, size, reliability, and energy efficiency. Material engineering of electrical machines has been identified as a key solution for higher power dense electric drivetrains. One of the main challenges at high speed is the eddy-current losses in the active electromagnetic parts, especially magnetic materials and permanent magnets (PMs). This study is devoted to the selection of PM rotor materials using multidisciplinary design optimization for a high-speed electric drivetrain. Beside AC loss minimization, more disciplines are considered, such as the minimization of weight, and cost. Different laminations are investigated with different magnetic properties as well as cost. Additionally, different PMs are optimized considering low-cost ferrite and high-coercivity permanent magnets (HCPMs). Moreover, the optimal materials are identified which have the best balance between loss, weight, cost, ripples. Finally, different rotor designs are prototyped, assembled, and tested using the same stator configuration. Also, the best rotor design is selected, and the electromagnetic performance is measured and compared with conventional designs. The optimal design results in 8% extra torque with at least 20% weight reduction. Full article
Show Figures

Figure 1

19 pages, 11883 KB
Article
Electric Aerospace Actuator Manufactured by Laser Powder Bed Fusion
by Borja Lizarribar, Borja Prieto, Miren Aristizabal, Jose Manuel Martín, Miguel Martínez-Iturralde, Ekain San José, Ione Golvano and Sergio Montes
Aerospace 2023, 10(9), 813; https://doi.org/10.3390/aerospace10090813 - 17 Sep 2023
Cited by 4 | Viewed by 3013
Abstract
Recent advances in manufacturing methods have accelerated the exploration of new materials and advantageous shapes that could not be produced by traditional methods. In this context, additive manufacturing is gaining strength among manufacturing methods for its versatility and freedom in the geometries that [...] Read more.
Recent advances in manufacturing methods have accelerated the exploration of new materials and advantageous shapes that could not be produced by traditional methods. In this context, additive manufacturing is gaining strength among manufacturing methods for its versatility and freedom in the geometries that can be produced. Taking advantage of these possibilities, this research presents a case study involving an electric aerospace actuator manufactured using additive manufacturing. The main objectives of this research work are to assess the feasibility of additively manufacturing electric actuators and to evaluate potential gains in terms of weight, volume, power consumption and cost over conventional manufacturing technologies. To do so and in order to optimise the actuator design, a thorough material study is conducted in which three different magnetic materials are gas-atomised (silicon iron, permendur and supermalloy) and test samples of the most promising materials (silicon iron and permendur) are processed by laser powder bed fusion. The final actuator design is additively manufactured in permendur for the stator and rotor iron parts and in 316L stainless steel for the housing. The electric actuator prototype is tested, showing compliance with design requirements in terms of torque production, power consumption and heating. Finally, a design intended to be manufactured via traditional methods (i.e., punching and stacking for the stator laminations and machining for the housing) is presented and compared to the additively manufactured design. The comparison shows that additive manufacturing is a viable alternative to traditional manufacturing for the application presented, as it highly reduces the weight of the actuator and facilitates the assembly, while the cost difference between the two designs is minimal. Full article
(This article belongs to the Special Issue Metal Additive Manufacturing for Aerospace Applications)
Show Figures

Figure 1
