Sensors, Volume 18, Issue 6 (June 2018)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) Pulse-based Time-of-Flight (PB-ToF) cameras are an attractive alternative range imaging approach, [...] Read more.
View options order results:
result details:
Displaying articles 1-312
Export citation of selected articles as:
Open AccessArticle Spectral-Spatial Feature Extraction of Hyperspectral Images Based on Propagation Filter
Sensors 2018, 18(6), 1978; https://doi.org/10.3390/s18061978 (registering DOI)
Received: 29 April 2018 / Revised: 6 June 2018 / Accepted: 17 June 2018 / Published: 20 June 2018
PDF Full-text (1788 KB) | HTML Full-text | XML Full-text
Abstract
Recently, image-filtering based hyperspectral image (HSI) feature extraction has been widely studied. However, due to limited spatial resolution and feature distribution complexity, the problems of cross-region mixing after filtering and spectral discriminative reduction still remain. To address these issues, this paper proposes a
[...] Read more.
Recently, image-filtering based hyperspectral image (HSI) feature extraction has been widely studied. However, due to limited spatial resolution and feature distribution complexity, the problems of cross-region mixing after filtering and spectral discriminative reduction still remain. To address these issues, this paper proposes a spectral-spatial propagation filter (PF) based HSI feature extraction method that can effectively address the above problems. The dimensionality/band of an HSI is typically high; therefore, principal component analysis (PCA) is first used to reduce the HSI dimensionality. Then, the principal components of the HSI are filtered with the PF. When cross-region mixture occurs in the image, the filter template reduces the weight assignments of the cross-region mixed pixels to handle the issue of cross-region mixed pixels simply and effectively. To validate the effectiveness of the proposed method, experiments are carried out on three common HSIs using support vector machine (SVM) classifiers with features learned by the PF. The experimental results demonstrate that the proposed method effectively extracts the spectral-spatial features of HSIs and significantly improves the accuracy of HSI classification. Full article
(This article belongs to the Special Issue Sensors Signal Processing and Visual Computing)
Figures

Figure 1

Open AccessArticle A New Method of High-Precision Positioning for an Indoor Pseudolite without Using the Known Point Initialization
Sensors 2018, 18(6), 1977; https://doi.org/10.3390/s18061977 (registering DOI)
Received: 15 May 2018 / Revised: 8 June 2018 / Accepted: 19 June 2018 / Published: 20 June 2018
PDF Full-text (4857 KB) | HTML Full-text | XML Full-text
Abstract
Due to the great influence of multipath effect, noise, clock and error on pseudorange, the carrier phase double difference equation is widely used in high-precision indoor pseudolite positioning. The initial position is determined mostly by the known point initialization (KPI) method, and then
[...] Read more.
Due to the great influence of multipath effect, noise, clock and error on pseudorange, the carrier phase double difference equation is widely used in high-precision indoor pseudolite positioning. The initial position is determined mostly by the known point initialization (KPI) method, and then the ambiguities can be fixed with the LAMBDA method. In this paper, a new method without using the KPI to achieve high-precision indoor pseudolite positioning is proposed. The initial coordinates can be quickly obtained to meet the accuracy requirement of the indoor LAMBDA method. The detailed processes of the method follows: Aiming at the low-cost single-frequency pseudolite system, the static differential pseudolite system (DPL) method is used to obtain the low-accuracy positioning coordinates of the rover station quickly. Then, the ambiguity function method (AFM) is used to search for the coordinates in the corresponding epoch. The real coordinates obtained by AFM can meet the initial accuracy requirement of the LAMBDA method, so that the double difference carrier phase ambiguities can be correctly fixed. Following the above steps, high-precision indoor pseudolite positioning can be realized. Several experiments, including static and dynamic tests, are conducted to verify the feasibility of the new method. According to the results of the experiments, the initial coordinates with the accuracy of decimeter level through the DPL can be obtained. For the AFM part, both a one-meter search scope and two-centimeter or four-centimeter search steps are used to ensure the precision at the centimeter level and high search efficiency. After dealing with the problem of multiple peaks caused by the ambiguity cosine function, the coordinate information of the maximum ambiguity function value (AFV) is taken as the initial value of the LAMBDA, and the ambiguities can be fixed quickly. The new method provides accuracies at the centimeter level for dynamic experiments and at the millimeter level for static ones. Full article
(This article belongs to the Special Issue GNSS and Fusion with Other Sensors)
Figures

Figure 1

Open AccessArticle On the Coverage of Bus-Based Mobile Sensing
Sensors 2018, 18(6), 1976; https://doi.org/10.3390/s18061976 (registering DOI)
Received: 31 May 2018 / Revised: 12 June 2018 / Accepted: 17 June 2018 / Published: 20 June 2018
PDF Full-text (383 KB) | HTML Full-text | XML Full-text
Abstract
A cost-effective approach to gather information in a smart city is to embed sensors in vehicles such as buses. To understand the limitations and opportunities of this model, it is fundamental to investigate the spatial coverage of such a network, especially in the
[...] Read more.
A cost-effective approach to gather information in a smart city is to embed sensors in vehicles such as buses. To understand the limitations and opportunities of this model, it is fundamental to investigate the spatial coverage of such a network, especially in the case where only a subset of the buses have a sensing device embedded. In this paper, we propose a model to select the right subset of buses that maximizes the coverage of the city. We evaluate the model in a real scenario based on a large-scale dataset of more than 5700 buses in the city of Rio de Janeiro, Brazil. Among other findings, we observe that the fleet of buses covers approximately 5655 km of streets (approximately 47% of the streets) and show that it is possible to cover 94% of the same streets if only 18% of buses have sensing capabilities embedded. Full article
(This article belongs to the Special Issue Sensor Networks for Smart Roads)
Figures

Figure 1

Open AccessArticle Directional Sensitivity of a MEMS-Based Fiber-Optic Extrinsic Fabry–Perot Ultrasonic Sensor for Partial Discharge Detection
Sensors 2018, 18(6), 1975; https://doi.org/10.3390/s18061975 (registering DOI)
Received: 15 May 2018 / Revised: 14 June 2018 / Accepted: 17 June 2018 / Published: 20 June 2018
PDF Full-text (2919 KB) | HTML Full-text | XML Full-text
Abstract
Extrinsic Fabry–Perot (FP) interferometric sensors are being intensively applied for partial discharge (PD) detection and localization. Previous research work has mainly focused on novel structures and materials to improve the sensitivity and linear response of these sensors. However, the directional response behavior of
[...] Read more.
Extrinsic Fabry–Perot (FP) interferometric sensors are being intensively applied for partial discharge (PD) detection and localization. Previous research work has mainly focused on novel structures and materials to improve the sensitivity and linear response of these sensors. However, the directional response behavior of an FP ultrasonic sensor is also of particular importance in localizing the PD source, which is rarely considered. Here, the directional sensitivity of a microelectromechanical system (MEMS)-based FP ultrasonic sensor with a 5-μm-thick micromechanical vibrating diaphragm is experimentally investigated. Ultrasonic signals from a discharge source with varying incident angles and linear distances are measured and analyzed. The results show that the sensor has a 5.90 dB amplitude fluctuation over a ±60° incident range and an exciting capability to detect weak PD signals from 3 m away due to its high signal–noise ratio. The findings are expected to optimize the configuration of a sensor array and accurately localize the PD source. Full article
(This article belongs to the Special Issue Optics Sensors Using Microstructured and Photonics Crystal Fibers)
Figures

Figure 1

Open AccessArticle Accurate Smartphone Indoor Visual Positioning Based on a High-Precision 3D Photorealistic Map
Sensors 2018, 18(6), 1974; https://doi.org/10.3390/s18061974 (registering DOI)
Received: 23 May 2018 / Revised: 13 June 2018 / Accepted: 15 June 2018 / Published: 20 June 2018
PDF Full-text (11785 KB) | HTML Full-text | XML Full-text
Abstract
Indoor positioning is in high demand in a variety of applications, and indoor environment is a challenging scene for visual positioning. This paper proposes an accurate visual positioning method for smartphones. The proposed method includes three procedures. First, an indoor high-precision 3D photorealistic
[...] Read more.
Indoor positioning is in high demand in a variety of applications, and indoor environment is a challenging scene for visual positioning. This paper proposes an accurate visual positioning method for smartphones. The proposed method includes three procedures. First, an indoor high-precision 3D photorealistic map is produced using a mobile mapping system, and the intrinsic and extrinsic parameters of the images are obtained from the mapping result. A point cloud is calculated using feature matching and multi-view forward intersection. Second, top-K similar images are queried using hamming embedding with SIFT feature description. Feature matching and pose voting are used to select correctly matched image, and the relationship between image points and 3D points is obtained. Finally, outlier points are removed using P3P with the coarse focal length. Perspective-four-point with unknown focal length and random sample consensus are used to calculate the intrinsic and extrinsic parameters of the query image and then to obtain the positioning of the smartphone. Compared with established baseline methods, the proposed method is more accurate and reliable. The experiment results show that 70 percent of the images achieve location error smaller than 0.9 m in a 10 m × 15.8 m room, and the prospect of improvement is discussed. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1

Open AccessArticle Downlink Cooperative Broadcast Transmission Based on Superposition Coding in a Relaying System for Future Wireless Sensor Networks
Sensors 2018, 18(6), 1973; https://doi.org/10.3390/s18061973 (registering DOI)
Received: 11 May 2018 / Revised: 12 June 2018 / Accepted: 15 June 2018 / Published: 20 June 2018
PDF Full-text (619 KB) | HTML Full-text | XML Full-text
Abstract
This study investigates the superiority of cooperative broadcast transmission over traditional orthogonal schemes when applied in a downlink relaying broadcast channel (RBC). Two proposed cooperative broadcast transmission protocols, one with an amplify-and-forward (AF) relay, and the other with a repetition-based decode-and-forward (DF) relay,
[...] Read more.
This study investigates the superiority of cooperative broadcast transmission over traditional orthogonal schemes when applied in a downlink relaying broadcast channel (RBC). Two proposed cooperative broadcast transmission protocols, one with an amplify-and-forward (AF) relay, and the other with a repetition-based decode-and-forward (DF) relay, are investigated. By utilizing superposition coding (SupC), the source and the relay transmit the private user messages simultaneously instead of sequentially as in traditional orthogonal schemes, which means the channel resources are reused and an increased channel degree of freedom is available to each user, hence the half-duplex penalty of relaying is alleviated. To facilitate a performance evaluation, theoretical outage probability expressions of the two broadcast transmission schemes are developed, based on which, we investigate the minimum total power consumption of each scheme for a given traffic requirement by numerical simulation. The results provide details on the overall system performance and fruitful insights on the essential characteristics of cooperative broadcast transmission in RBCs. It is observed that better overall outage performances and considerable power gains can be obtained by utilizing cooperative broadcast transmissions compared to traditional orthogonal schemes. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle Improved Dynamic Mode Decomposition and Its Application to Fault Diagnosis of Rolling Bearing
Sensors 2018, 18(6), 1972; https://doi.org/10.3390/s18061972
Received: 17 May 2018 / Revised: 13 June 2018 / Accepted: 16 June 2018 / Published: 19 June 2018
PDF Full-text (757 KB)
Abstract
To solve the intractable problems of optimal rank truncation threshold and dominant modes selection strategy of the standard dynamic mode decomposition (DMD), an improved DMD algorithm is introduced in this paper. Distinct from the conventional methods, a convex optimization framework is introduced by
[...] Read more.
To solve the intractable problems of optimal rank truncation threshold and dominant modes selection strategy of the standard dynamic mode decomposition (DMD), an improved DMD algorithm is introduced in this paper. Distinct from the conventional methods, a convex optimization framework is introduced by applying a parameterized non-convex penalty function to obtain the optimal rank truncation number. This method is inspirited by the performance that it is more perfectible than other rank truncation methods in inhibiting noise disturbance. A hierarchical and multiresolution application similar to the process of wavelet packet decomposition in modes selection is presented so as to improve the algorithm’s performance. With the modes selection strategy, the frequency spectrum of the reconstruction signal is more readable and interference-free. The improved DMD algorithm successfully extracts the fault characteristics of rolling bearing fault signals when it is utilized for mechanical signal feature extraction. Results demonstrated that the proposed method has good application prospects in denoising and fault feature extraction for mechanical signals. Full article
(This article belongs to the Section Physical Sensors)
Open AccessArticle Processing Ultrasonic Data by Coda Wave Interferometry to Monitor Load Tests of Concrete Beams
Sensors 2018, 18(6), 1971; https://doi.org/10.3390/s18061971
Received: 11 May 2018 / Revised: 5 June 2018 / Accepted: 12 June 2018 / Published: 19 June 2018
PDF Full-text (4864 KB) | HTML Full-text | XML Full-text
Abstract
Ultrasonic transmission measurements have been used for decades to monitor concrete elements, mostly on a laboratory scale. Recently, coda wave interferometry (CWI), a technique adapted from seismology, was introduced to civil engineering experiments. It can be used to reveal subtle changes in concrete
[...] Read more.
Ultrasonic transmission measurements have been used for decades to monitor concrete elements, mostly on a laboratory scale. Recently, coda wave interferometry (CWI), a technique adapted from seismology, was introduced to civil engineering experiments. It can be used to reveal subtle changes in concrete laboratory samples and even large structural elements without having a transducer directly at the place where the change is taking place. Here, several load tests until failure on large posttensioned concrete beams have been monitored using networks of embedded transducers. To detect subtle effects at the beginning of the experiments and cope with severe changes due to cracking close to failure, the coda wave interferometry procedures had to be modified to an adapted step-wise approach. Using this methodology, we were able to monitor stress distribution and localize large cracks by a relatively simple technique. Implementation of this approach on selected real structures might help to make decisions in infrastructure asset management. Full article
Figures

Figure 1

Open AccessArticle Heading Estimation for Pedestrian Dead Reckoning Based on Robust Adaptive Kalman Filtering
Sensors 2018, 18(6), 1970; https://doi.org/10.3390/s18061970
Received: 17 May 2018 / Revised: 12 June 2018 / Accepted: 15 June 2018 / Published: 19 June 2018
PDF Full-text (8959 KB) | HTML Full-text | XML Full-text
Abstract
Pedestrian dead reckoning (PDR) using smart phone-embedded micro-electro-mechanical system (MEMS) sensors plays a key role in ubiquitous localization indoors and outdoors. However, as a relative localization method, it suffers from the problem of error accumulation which prevents it from long term independent running.
[...] Read more.
Pedestrian dead reckoning (PDR) using smart phone-embedded micro-electro-mechanical system (MEMS) sensors plays a key role in ubiquitous localization indoors and outdoors. However, as a relative localization method, it suffers from the problem of error accumulation which prevents it from long term independent running. Heading estimation error is one of the main location error sources, and therefore, in order to improve the location tracking performance of the PDR method in complex environments, an approach based on robust adaptive Kalman filtering (RAKF) for estimating accurate headings is proposed. In our approach, outputs from gyroscope, accelerometer, and magnetometer sensors are fused using the solution of Kalman filtering (KF) that the heading measurements derived from accelerations and magnetic field data are used to correct the states integrated from angular rates. In order to identify and control measurement outliers, a maximum likelihood-type estimator (M-estimator)-based model is used. Moreover, an adaptive factor is applied to resist the negative effects of state model disturbances. Extensive experiments under static and dynamic conditions were conducted in indoor environments. The experimental results demonstrate the proposed approach provides more accurate heading estimates and supports more robust and dynamic adaptive location tracking, compared with methods based on conventional KF. Full article
Figures

Figure 1

Open AccessArticle UCMAC: A Cooperative MAC Protocol for Underwater Wireless Sensor Networks
Sensors 2018, 18(6), 1969; https://doi.org/10.3390/s18061969
Received: 21 May 2018 / Revised: 13 June 2018 / Accepted: 19 June 2018 / Published: 19 June 2018
PDF Full-text (7915 KB) | HTML Full-text | XML Full-text
Abstract
This paper proposes a cooperative medium access control (MAC) protocol for underwater wireless sensor networks (UWSNs) named UCMAC, which fundamentally benefits from cooperative communication. In UCMAC, a source identifies cooperators and provides its destination with a list of the cooperators while also delineating
[...] Read more.
This paper proposes a cooperative medium access control (MAC) protocol for underwater wireless sensor networks (UWSNs) named UCMAC, which fundamentally benefits from cooperative communication. In UCMAC, a source identifies cooperators and provides its destination with a list of the cooperators while also delineating their proximity to the destination. For erroneous reception of data packets, the destination then requests retransmission to the cooperators in a closest-one-first manner. A designated cooperator transmits the buffered data packet it has successfully overheard from the source or other cooperators. A signaling procedure and the various waiting times of the nodes are carefully designed to address the overheads that stem from cooperation. Through computer simulation, this paper evaluates UCMAC in terms of system throughput, latency, single-hop packet delivery ratio (PDR), and energy efficiency. The results show that UCMAC performs better than existing schemes, including MACA-U and CD-MACA. Full article
(This article belongs to the Section Sensor Networks)
Figures

Figure 1

Open AccessArticle Deformation Monitoring for Chinese Traditional Timber Buildings Using Fiber Bragg Grating Sensors
Sensors 2018, 18(6), 1968; https://doi.org/10.3390/s18061968
Received: 6 May 2018 / Revised: 12 June 2018 / Accepted: 14 June 2018 / Published: 19 June 2018
PDF Full-text (4942 KB) | HTML Full-text | XML Full-text
Abstract
The Fiber Bragg Grating (FBG) sensing technique is suitable for a wide variety of measurements, including temperature, pressure, acceleration, liquid level, etc., and has been applied to many bridges and buildings in the past two decades. The fact that the FBG technique can
[...] Read more.
The Fiber Bragg Grating (FBG) sensing technique is suitable for a wide variety of measurements, including temperature, pressure, acceleration, liquid level, etc., and has been applied to many bridges and buildings in the past two decades. The fact that the FBG technique can only monitor and measure strain data for most cases when it is used for deformation measurements impedes application of the FBG sensing technique in civil infrastructures. This paper proposes FBG sensing-based deformation monitoring methods that are applicable to monitoring beam deflection, column inclination angle and mortise-tenon joint dislocation for Chinese traditional timber structures. On the basis of improved conjugated beam theory and geometrical trigonometric function relationship, the relationships between the FBG sensing strain values and the deflection of beam, inclination angle of column, as well as the amount of dislocation of mortise-tenon joint are deducted for Chinese traditional buildings. A series of experiments were conducted to verify the applicability and effectiveness of the proposed deformation monitoring methods. The results show that a good agreement is obtained between the values given by the methods proposed in this paper and other methods. This implies that the proposed deformation monitoring methods are applicable and effective in the health monitoring of Chinese traditional timber structures. Full article
(This article belongs to the Special Issue Smart Sensors and Smart Structures)
Figures

Figure 1

Open AccessArticle GNSS Code Multipath Mitigation by Cascading Measurement Monitoring Techniques
Sensors 2018, 18(6), 1967; https://doi.org/10.3390/s18061967
Received: 9 May 2018 / Revised: 14 June 2018 / Accepted: 14 June 2018 / Published: 19 June 2018
PDF Full-text (6725 KB) | HTML Full-text | XML Full-text
Abstract
Various measurement monitoring techniques are investigated to mitigate the effect of global navigation satellite systems (GNSS) code multipath through error correction, stochastic weighting of measurements and detection and exclusion (or de-weighting) of affected measurements. Following a comprehensive review of each approach, the paper
[...] Read more.
Various measurement monitoring techniques are investigated to mitigate the effect of global navigation satellite systems (GNSS) code multipath through error correction, stochastic weighting of measurements and detection and exclusion (or de-weighting) of affected measurements. Following a comprehensive review of each approach, the paper focuses on detection/exclusion and detection/de-weighting techniques where several single and dual-frequency monitoring metrics are employed in a combination with time-averaging and the M of N detection strategy. A new Geometry-Free (GF) detection metric is proposed given its capability to be combined with a preceding Code-Minus-Carrier (CMC)-based error correction to reduce the number of excluded or de-weighted measurements and thus preserve the measurement geometry. Three geometry-based algorithms, namely measurement subset testing, consecutive exclusion and iterative change of measurement weights are investigated to address multipath scenarios with multiple simultaneously affected measurements. Experimental results are provided using GPS L1, L2C and L5 data collected in multipath environments for static and kinematic scenarios. For GPS L1, the proposed combined method shows more than 38% improvement over a conventional Carrier-to-Noise-density ratio (C/N0)-based Least-Squares (LS) solution in all but deep urban canyons. Lower performance was observed for L2C and L5 frequencies with a limited number of satellites in view. Full article
(This article belongs to the Special Issue GNSS and Fusion with Other Sensors)
Figures

Figure 1

Open AccessArticle Estimation of Tri-Axial Walking Ground Reaction Forces of Left and Right Foot from Total Forces in Real-Life Environments
Sensors 2018, 18(6), 1966; https://doi.org/10.3390/s18061966
Received: 3 April 2018 / Revised: 11 June 2018 / Accepted: 17 June 2018 / Published: 19 June 2018
PDF Full-text (5573 KB) | HTML Full-text | XML Full-text
Abstract
Continuous monitoring of natural human gait in real-life environments is essential in many applications including disease monitoring, rehabilitation, and professional sports. Wearable inertial measurement units are successfully used to measure body kinematics in real-life environments and to estimate total walking ground reaction forces
[...] Read more.
Continuous monitoring of natural human gait in real-life environments is essential in many applications including disease monitoring, rehabilitation, and professional sports. Wearable inertial measurement units are successfully used to measure body kinematics in real-life environments and to estimate total walking ground reaction forces GRF(t) using equations of motion. However, for inverse dynamics and clinical gait analysis, the GRF(t) of each foot is required separately. Using an experimental dataset of 1243 tri-axial separate-foot GRF(t) time histories measured by the authors across eight years, this study proposes the ‘Twin Polynomial Method’ (TPM) to estimate the tri-axial left and right foot GRF(t) signals from the total GRF(t) signals. For each gait cycle, TPM fits polynomials of degree five, eight, and nine to the known single-support part of the left and right foot vertical, anterior-posterior, and medial-lateral GRF(t) signals, respectively, to extrapolate the unknown double-support parts of the corresponding GRF(t) signals. Validation of the proposed method both with force plate measurements (gold standard) in the laboratory, and in real-life environment showed a peak-to-peak normalized root mean square error of less than 2.5%, 6.5% and 7.5% for the estimated GRF(t) signals in the vertical, anterior-posterior and medial-lateral directions, respectively. These values show considerable improvement compared with the currently available GRF(t) decomposition methods in the literature. Full article
(This article belongs to the Section Physical Sensors)
Figures

Figure 1a

Open AccessArticle Impact of Sliding Window Length in Indoor Human Motion Modes and Pose Pattern Recognition Based on Smartphone Sensors
Sensors 2018, 18(6), 1965; https://doi.org/10.3390/s18061965
Received: 7 May 2018 / Revised: 14 June 2018 / Accepted: 15 June 2018 / Published: 18 June 2018
PDF Full-text (10222 KB) | HTML Full-text | XML Full-text
Abstract
Human activity recognition (HAR) is essential for understanding people’s habits and behaviors, providing an important data source for precise marketing and research in psychology and sociology. Different approaches have been proposed and applied to HAR. Data segmentation using a sliding window is a
[...] Read more.
Human activity recognition (HAR) is essential for understanding people’s habits and behaviors, providing an important data source for precise marketing and research in psychology and sociology. Different approaches have been proposed and applied to HAR. Data segmentation using a sliding window is a basic step during the HAR procedure, wherein the window length directly affects recognition performance. However, the window length is generally randomly selected without systematic study. In this study, we examined the impact of window length on smartphone sensor-based human motion and pose pattern recognition. With data collected from smartphone sensors, we tested a range of window lengths on five popular machine-learning methods: decision tree, support vector machine, K-nearest neighbor, Gaussian naïve Bayesian, and adaptive boosting. From the results, we provide recommendations for choosing the appropriate window length. Results corroborate that the influence of window length on the recognition of motion modes is significant but largely limited to pose pattern recognition. For motion mode recognition, a window length between 2.5–3.5 s can provide an optimal tradeoff between recognition performance and speed. Adaptive boosting outperformed the other methods. For pose pattern recognition, 0.5 s was enough to obtain a satisfactory result. In addition, all of the tested methods performed well. Full article
Figures

Figure 1

Open AccessArticle TM02 Quarter-Mode Substrate-Integrated Waveguide Resonator for Dual Detection of Chemicals
Sensors 2018, 18(6), 1964; https://doi.org/10.3390/s18061964
Received: 19 May 2018 / Revised: 14 June 2018 / Accepted: 16 June 2018 / Published: 18 June 2018
PDF Full-text (5634 KB) | HTML Full-text | XML Full-text
Abstract
The detection of multiple fluids using a single chip has been attracting attention recently. A TM02 quarter-mode substrate-integrated waveguide resonator designed at 5.81 GHz on RT/duroid 6010LM with a return loss of 13 dB and an unloaded quality factor of Q ≈
[...] Read more.
The detection of multiple fluids using a single chip has been attracting attention recently. A TM02 quarter-mode substrate-integrated waveguide resonator designed at 5.81 GHz on RT/duroid 6010LM with a return loss of 13 dB and an unloaded quality factor of Q ≈ 13 generates two distinct strong electric fields that can be manipulated to simultaneously detect two chemicals. Two asymmetric channels engraved in a polydimethylsiloxane sheet are loaded with analyte to produce a unique resonance frequency in each case, regardless of the dielectric constants of the liquids. Keeping in view the nature of lossy liquids such as ethanol, the initial structure and channels are optimized to ensure a reasonable return loss even in the case of loading lossy liquids. After loading the empty channels, Q is evaluated as 43. Ethanol (E) and deionized water (DI) are simultaneously loaded to demonstrate the detection of all possible combinations: [Air, Air], [E, DI], [DI, E], [E, E], and [DI, DI]. The proposed structure is miniaturized while exhibiting a performance comparable to that of existing multichannel microwave chemical sensors. Full article
(This article belongs to the Special Issue RF Technology for Sensor Applications)
Figures

Figure 1
