Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems

Journal Name	Impact Factor	CiteScore	Launched Year	First Decision (median)	APC
Electricity electricity	-	4.8	2020	27.9 Days	CHF 1000
Electronics electronics	2.6	5.3	2012	16.4 Days	CHF 2400
Energies energies	3.0	6.2	2008	16.8 Days	CHF 2600
Sensors sensors	3.4	7.3	2001	18.6 Days	CHF 2600
Sustainability sustainability	3.3	6.8	2009	19.7 Days	CHF 2400

20 pages, 4777 KiB

Open AccessArticle

An Optimization Strategy for EV-Integrated Microgrids Considering Peer-to-Peer Transactions

by Sen Tian, Qian Xiao, Tianxiang Li, Yu Jin, Yunfei Mu, Hongjie Jia, Wenhua Li, Remus Teodorescu and Josep M. Guerrero

Sustainability 2024, 16(20), 8955; https://doi.org/10.3390/su16208955 - 16 Oct 2024

Viewed by 1470

Abstract

The scale of electric vehicles (EVs) in microgrids is growing prominently. However, the stochasticity of EV charging behavior poses formidable obstacles to exploring their dispatch potential. To solve this issue, an optimization strategy for EV-integrated microgrids considering peer-to-peer (P2P) transactions has been proposed [...] Read more.

The scale of electric vehicles (EVs) in microgrids is growing prominently. However, the stochasticity of EV charging behavior poses formidable obstacles to exploring their dispatch potential. To solve this issue, an optimization strategy for EV-integrated microgrids considering peer-to-peer (P2P) transactions has been proposed in this paper. This research strategy contributes to the sustainable development of microgrids under large-scale EV integration. Firstly, a novel cooperative operation framework considering P2P transactions is established, in which the impact factors of EV charging are regarded to simulate its stochasticity and the energy trading process of the EV-integrated microgrid participating in P2P transactions is defined. Secondly, cost models for the EV-integrated microgrid are established. Thirdly, a three-stage optimization strategy is proposed to simplify the solving process. It transforms the scheduling problem into three solvable subproblems and restructures them with Lagrangian relaxation. Finally, case studies demonstrate that the proposed strategy optimizes EV load distribution, reduces the overall operational cost of the EV-integrated microgrid, and enhances the economic efficiency of each microgrid participating in P2P transactions. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

20 pages, 2080 KiB

Open AccessArticle

Multi-Stage Rolling Grid Expansion Planning for Distribution Networks Considering Conditional Value at Risk

by Junxiao Zhang, Chengmin Wang, Jing Zuo, Chong Gao, Shurong Zheng, Ran Cheng, Yao Duan and Yawu Wang

Energies 2024, 17(20), 5134; https://doi.org/10.3390/en17205134 - 16 Oct 2024

Cited by 1 | Viewed by 817

Abstract

Existing single-stage planning and multi-stage non-rolling planning methods for distribution networks have problems such as low equipment utilization efficiency and poor investment benefits. In order to solve the above problems, this paper firstly proposes a multi-stage rolling planning method for distribution networks based [...] Read more.

Existing single-stage planning and multi-stage non-rolling planning methods for distribution networks have problems such as low equipment utilization efficiency and poor investment benefits. In order to solve the above problems, this paper firstly proposes a multi-stage rolling planning method for distribution networks based on analyzing the limitations of the existing planning methods, which divides the planning cycle of the distribution network into multiple planning stages, and makes rolling amendments to the planning scheme of each stage according to the latest information during the planning cycle. Then, a multi-stage rolling planning model of distribution network taking into account conditional value at risk is established with the objective of minimizing the total investment and operation cost of the distribution network. On the one hand, the users’ electricity bill is taken into account in the objective function, and the necessity of this part of the benefits is demonstrated. On the other hand, the conditional value at risk is used to quantify the uncertainty of the operation cost in the process of the expansion planning of the distribution network, which reduces the operation cost risk of the distribution network. Next, this paper uses the rainflow counting method to characterize the capacity decay characteristics of energy storage in the distribution network, and proposes an iterative solution framework that considers energy storage capacity decay to solve the proposed model. Finally, the proposed method is applied to an 18-node distribution network planning case. This confirms that the multi-stage rolling planning method could improve the investment benefits and reduce the investment cost by approximately 27.27%. Besides, it will increase the total cost by approximately 2750 USD in the case if the users’ electricity bill is not taken into account. And the maximum capacity of energy storage may decay to 87.6% of the initial capacity or even lower during operation, which may cause the line current to exceed the limit if it is not taken into account. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

19 pages, 2863 KiB

Open AccessArticle

Sparrow Search Algorithm Based on New Energy Power Hydrogen Synthesis Ammonia Economic Optimization of System Scheduling

by Jingchao Liu, Yue Chen, Jiqing Yu, Huisheng Wang, Liyan Zhang, Biao Li, Linsheng Cheng, Xianhai Liu, Guinan Wang, Yiyao Li and Qingzhu Wan

Energies 2024, 17(15), 3796; https://doi.org/10.3390/en17153796 - 1 Aug 2024

Viewed by 1178

Abstract

P2A (Power to ammonia) is one of the important ways of large-scale consumption of renewable energy, and one of the important technological routes for the chemical industry to realize low-carbon and clean development. The new off-grid energy power to hydrogen ammonia system lacks [...] Read more.

P2A (Power to ammonia) is one of the important ways of large-scale consumption of renewable energy, and one of the important technological routes for the chemical industry to realize low-carbon and clean development. The new off-grid energy power to hydrogen ammonia system lacks the support of large power grids due to the complex mathematical model of the system, more variables, and cumbersome constraints, which leads to model solving difficulties, and the production simulation results obtained suffer from the problems of low economic efficiency and high new energy power abandonment rate. To address the shortcomings of the algorithm, which converges slowly and easily falls into the local optimum when solving the model, this paper applies the Sparrow Search Algorithm (SSA) to the problem of economic optimization of new energy hydrogen synthesis and ammonia system scheduling. Firstly, based on the characteristics of wind and light, the operating characteristics of an electrolyzer, and the characteristics of an electrochemical energy storage device, and taking the economic optimization of the electric hydrogen synthesis ammonia system as the objective function, the economic optimization scheduling model of an off-grid new energy electric hydrogen synthesis ammonia system is established for 24 h production simulation. Secondly, the model is solved based on the sparrow search algorithm, and the speed of solving and the economic benefits of the system are analyzed in comparison with the conventional algorithm. Finally, the proposed off-grid wind-powered hydrogen synthesis ammonia system based on the sparrow search algorithm is verified to achieve the optimal operation of the 24 h production simulation through an actual example in the Daan area of Baicheng City, Jilin Province, which shows that the optimized system has better economic efficiency and the new energy is completely consumed, thus verifying the reasonableness and validity of the algorithm proposed in this article. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

13 pages, 3148 KiB

Open AccessTechnical Note

Frequency Modulation Control of Grid-Forming Converter Based on LADRC-MI

by Zejian Liu, Fengneng Li, Ping Yang, Xu Lin and Guozun Zhang

Energies 2024, 17(13), 3282; https://doi.org/10.3390/en17133282 - 4 Jul 2024

Cited by 2 | Viewed by 1174

Abstract

The increasing proportion of new energy in the power system leads to a decrease in system inertia and weakens the frequency stability of the system. The use of grid-forming (GFM) control for inverters is an effective method to improve frequency stability in new [...] Read more.

The increasing proportion of new energy in the power system leads to a decrease in system inertia and weakens the frequency stability of the system. The use of grid-forming (GFM) control for inverters is an effective method to improve frequency stability in new energy generation systems. Due to uncertain disturbances in microgrids, it can cause changes in system frequency. A control strategy for linear active disturbance rejection control combined with model information (LADRC-MI) is proposed in this manuscript. In this method, the inertia level and damping of the system are improved by using virtual synchronous generator (VSG)-based GFM control. Then, the obtained part of the model information is written into the coefficient matrix of the linear extended state observer. The LADRC-MI is constructed to improve the immunity of the controller. Finally, the effectiveness of the strategy in improving the immunity and frequency stability of the converter is analyzed and verified. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

25 pages, 3602 KiB

Open AccessArticle

Real-Time Simulation System for Small Scale Regional Integrated Energy Systems

by Wei Jiang, Renjie Qi, Song Xu and Seiji Hashimoto

Energies 2024, 17(13), 3211; https://doi.org/10.3390/en17133211 - 29 Jun 2024

Cited by 1 | Viewed by 1012

Abstract

Regional Integrated Energy Systems (RIESs) integrate wide spectrum of energy sources and storage with optimized energy management and further pollution reduction. This paper presents a real-time simulation system for RIESs powered by multiple digital signal processors (DSPs) with different means of data exchange. [...] Read more.

Regional Integrated Energy Systems (RIESs) integrate wide spectrum of energy sources and storage with optimized energy management and further pollution reduction. This paper presents a real-time simulation system for RIESs powered by multiple digital signal processors (DSPs) with different means of data exchange. The RIES encompasses the DC microgrid (DMG), the district heat network (DHN), and the natural gas network (NGN). To realize multi-energy flow simulation, averaged switch models are investigated for different types of device-level units in the DMG, and the unified energy path method is used to build circuit-dual models of the DHN and NGN. A hierarchical island strategy (HIS) and a multi-energy dispatch strategy (MEDS) are proposed to enhance the energy flow control and operating efficiency. The two-layer HIS can adjust the operating status of device-level units in real time to achieve bus voltage stability in the DMG; MEDS uses energy conversion devices to decouple multi-energy flows and adopts the decomposed flow method to calculate the flow results for each network. The real-time simulation hardware platform is built, and both electricity-led and thermal-led experiments are carried out to verify the accuracy of models and the effectiveness of the proposed strategy. The proposed system with an energy management strategy aims to provide substantial theoretical and practical contributions to the control and simulation of RIESs, thus supporting the advancement of integrated energy systems. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

27 pages, 8336 KiB

Open AccessArticle

Optimal Electrification Using Renewable Energies: Microgrid Installation Model with Combined Mixture k-Means Clustering Algorithm, Mixed Integer Linear Programming, and Onsset Method

by Moyème Kabe, Yao Bokovi, Kwami Senam Sedzro, Pidéname Takouda and Yendoubé Lare

Energies 2024, 17(12), 3022; https://doi.org/10.3390/en17123022 - 19 Jun 2024

Cited by 3 | Viewed by 972

Abstract

Optimal planning and design of microgrids are priorities in the electrification of off-grid areas. Indeed, in one of the Sustainable Development Goals (SDG 7), the UN recommends universal access to electricity for all at the lowest cost. Several optimization methods with different strategies [...] Read more.

Optimal planning and design of microgrids are priorities in the electrification of off-grid areas. Indeed, in one of the Sustainable Development Goals (SDG 7), the UN recommends universal access to electricity for all at the lowest cost. Several optimization methods with different strategies have been proposed in the literature as ways to achieve this goal. This paper proposes a microgrid installation and planning model based on a combination of several techniques. The programming language Python 3.10 was used in conjunction with machine learning techniques such as unsupervised learning based on K-means clustering and deterministic optimization methods based on mixed linear programming. These methods were complemented by the open-source spatial method for optimal electrification planning: onsset. Four levels of study were carried out. The first level consisted of simulating the model obtained with a cluster, which is considered based on the elbow and k-means clustering method as a case study. The second level involved sizing the microgrid with a capacity of 40 kW and optimizing all the resources available on site. The example of the different resources in the Togo case was considered. At the third level, the work consisted of proposing an optimal connection model for the microgrid based on voltage stability constraints and considering, above all, the capacity limit of the source substation. Finally, the fourth level involved a planning study of electrification strategies based mainly on microgrids according to the study scenario. The results of the first level of study enabled us to obtain an optimal location for the centroid of the cluster under consideration, according to the different load positions of this cluster. Then, the results of the second level of study were used to highlight the optimal resources obtained and proposed by the optimization model formulated based on the various technology costs, such as investment, maintenance, and operating costs, which were based on the technical limits of the various technologies. In these results, solar systems account for 80% of the maximum load considered, compared to 7.5% for wind systems and 12.5% for battery systems. Next, an optimal microgrid connection model was proposed based on the constraints of a voltage stability limit estimated to be 10% of the maximum voltage drop. The results obtained for the third level of study enabled us to present selective results for load nodes in relation to the source station node. Finally, the last results made it possible to plan electrification using different network technologies and systems in the short and long term. The case study of Togo was taken into account. The various results obtained from the different techniques provide the necessary leads for a feasibility study for optimal electrification of off-grid areas using microgrid systems. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

28 pages, 9681 KiB

Open AccessArticle

Smart Operation Control of Power and Heat Demands in Active Distribution Grids Leveraging Energy Flexibility

by Rakesh Sinha, Sanjay K. Chaudhary, Birgitte Bak-Jensen and Hessam Golmohamadi

Energies 2024, 17(12), 2986; https://doi.org/10.3390/en17122986 - 17 Jun 2024

Cited by 1 | Viewed by 978

Abstract

Demand flexibility plays a crucial role in mitigating the intermittency of renewable power sources. This paper focuses on an active distribution grid that incorporates flexible heat and electric demands, specifically heat pumps (HPs) and electric vehicles (EVs). Additionally, it addresses photovoltaic (PV) power [...] Read more.

Demand flexibility plays a crucial role in mitigating the intermittency of renewable power sources. This paper focuses on an active distribution grid that incorporates flexible heat and electric demands, specifically heat pumps (HPs) and electric vehicles (EVs). Additionally, it addresses photovoltaic (PV) power generation facilities and electrical batteries to enhance demand flexibility. To exploit demand flexibility from both heat and electric demand, along with the integration of PVs and batteries, Control and Communication Mechanisms (CCMs) are formulated. These CCMs integrate demand flexibility into the distribution grids to obtain economic benefits for private households and, at the same time, facilitate voltage control. Concerning EVs, the paper discusses voltage-based droop control, scheduled charging, priority charging, and up-/down-power regulation to optimize the charging and discharging operations. For heat demands, the on-off operation of the HPs integrated with phase change material (PCM) storage is optimized to unlock heat-to-power flexibility. The HP controllers aim to ensure as much self-consumption as possible and provide voltage support for the distribution grid while ensuring the thermal comfort of residents. Finally, the developed CCMs are implemented on a small and representative community of an active distribution grid with eight houses using Power Factory software and DIgSILENT simulation language (DSL). This scalable size of the active distribution network facilitates the careful study of symbiotic interaction among the flexible load, generation, and different houses thoroughly. The simulation results confirm that the integration of flexible demands into the grid using the designed CCMs results in the grid benefiting from stabilized voltage control, especially during peak demand hours. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

14 pages, 12001 KiB

Open AccessArticle

Research on a Unified Data Model for Power Grids and Communication Networks Based on Graph Databases

by Dong Li, Bin Yang, Lei Liu, Chongbin Chen, Chao Sun, Liang Ma, Shenyang Xiao and Jian Sun

Electronics 2024, 13(11), 2014; https://doi.org/10.3390/electronics13112014 - 22 May 2024

Viewed by 1275

Abstract

With the continuous development of the power grid, its structure is becoming increasingly complex. The occurrence of faults in transmission lines may lead to cascading failures in the power grid, ultimately resulting in widespread power outages. The transmission of equipment information and the [...] Read more.

With the continuous development of the power grid, its structure is becoming increasingly complex. The occurrence of faults in transmission lines may lead to cascading failures in the power grid, ultimately resulting in widespread power outages. The transmission of equipment information and the sending of fault reports in the power grid rely on the power communication network. This network is crucial for ensuring the safe, stable, and economical operation of the power grid. As the number of devices in the power grid increases and sensor technology becomes more widespread, the volume of data generated by both the power grid and the power communication network has increased sharply. However, relational databases have limited scalability and struggle to meet the growing volume of data and user demands. This paper proposes a graph mapping method based on the power grid and communication network, utilizing data from both networks to construct a unified data plane in a graph database. Taking power transfer operations as an example, a unified standard data model and monitoring indicator system are established for both networks, enabling faster response and power restoration to blackout areas in the event of power grid faults. Simulation results demonstrate that compared to traditional relational databases, graph databases exhibit significantly improved efficiency in handling large-scale, highly connected data, making them more suitable for future power grids. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

19 pages, 13076 KiB

Open AccessArticle

Hierarchical Energy Management of DC Microgrid with Photovoltaic Power Generation and Energy Storage for 5G Base Station

by Jingang Han, Shiwei Lin and Boyu Pu

Sustainability 2024, 16(6), 2422; https://doi.org/10.3390/su16062422 - 14 Mar 2024

Cited by 4 | Viewed by 1491

Abstract

For 5G base stations equipped with multiple energy sources, such as energy storage systems (ESSs) and photovoltaic (PV) power generation, energy management is crucial, directly influencing the operational cost. Hence, aiming at increasing the utilization rate of PV power generation and improving the [...] Read more.

For 5G base stations equipped with multiple energy sources, such as energy storage systems (ESSs) and photovoltaic (PV) power generation, energy management is crucial, directly influencing the operational cost. Hence, aiming at increasing the utilization rate of PV power generation and improving the lifetime of the battery, thereby reducing the operating cost of the base station, a hierarchical energy management strategy based on the improved dung beetle optimization (IDBO) algorithm is proposed in this paper. The first control layer provides bus voltage control to each power module. In the second control layer, a dynamic balance control strategy calculates the power of the ESSs using the proportional–integral (PI) controller and distributes power based on the state of charge (SOC) and virtual resistance. The third control layer uses the IDBO algorithm to solve the DC microgrid’s optimization model in order to achieve the minimum daily operational cost goal. Simulation results demonstrate that the proposed IDBO algorithm reduces the daily cost in both scenarios by about 14.64% and 9.49% compared to the baseline method. Finally, the feasibility and effectiveness of the proposed hierarchical energy management strategy are verified through experimental results. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

22 pages, 6429 KiB

Open AccessFeature PaperArticle

Designing a High-Order Sliding Mode Controller for Photovoltaic- and Battery Energy Storage System-Based DC Microgrids with ANN-MPPT

by Tushar Kanti Roy, Amanullah Maung Than Oo and Subarto Kumar Ghosh

Energies 2024, 17(2), 532; https://doi.org/10.3390/en17020532 - 22 Jan 2024

Cited by 8 | Viewed by 1744

Abstract

This paper introduces a robust proportional integral derivative higher-order sliding mode controller (PID-HOSMC) based on a double power reaching law (DPRL) to enhance large-signal stability in DC microgrids. The microgrid integrates a solar photovoltaic (SPV) system, an energy storage system (ESS), and DC [...] Read more.

This paper introduces a robust proportional integral derivative higher-order sliding mode controller (PID-HOSMC) based on a double power reaching law (DPRL) to enhance large-signal stability in DC microgrids. The microgrid integrates a solar photovoltaic (SPV) system, an energy storage system (ESS), and DC loads. Efficient DC-DC converters, including bidirectional and boost converters, are employed to maintain a constant voltage level despite the lower SPV output power. An artificial neural network (ANN) generates the optimal reference voltage for the SPV system. The dynamical model, which incorporates external disturbances, is initially developed and based on this model, and the PID-HOSMC is designed to control output power by generating switching gate pulses. Afterwards, Lyapunov stability theory is used to demonstrate the model’s closed-loop stability, and theoretical analysis indicates that the controller can converge tracking errors to zero within a finite time frame. Finally, a comparative numerical simulation result is presented, demonstrating that the proposed controller exhibits a 58% improvement in settling time and an 82% improvement in overshoot compared to the existing controller. Experimental validation using processor-in-the-loop (PIL) confirms the proposed controller’s performance on a real-time platform. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

27 pages, 4616 KiB

Open AccessArticle

Economic Viability Assessment of Neighbourhood versus Residential Batteries: Insights from an Australian Case Study

by Soheil Mohseni, Jay Rutovitz, Heather Smith, Scott Dwyer and Farzan Tahir

Sustainability 2023, 15(23), 16331; https://doi.org/10.3390/su152316331 - 27 Nov 2023

Cited by 2 | Viewed by 2293

Abstract

Amidst the evolving paradigms of the contemporary energy landscape, marked by the imperative of sustainability and efficiency, the integration of energy storage has emerged as a transformative strategy that seeks to recalibrate the dynamics of electricity distribution and consumption. However, there remains a [...] Read more.

Amidst the evolving paradigms of the contemporary energy landscape, marked by the imperative of sustainability and efficiency, the integration of energy storage has emerged as a transformative strategy that seeks to recalibrate the dynamics of electricity distribution and consumption. However, there remains a pressing need to determine the most economically viable approach for deploying energy storage solutions in residential low-voltage (LV) feeders, especially in rural areas. In this context, this paper presents the results of an economic evaluation of energy storage solutions for a residential LV feeder in a rural town in Australia. Specifically, the study compares the financial viability of a front-of-the-meter (FTM) battery installed on the feeder with that of a fleet of behind-the-meter (BTM) batteries. The FTM battery, with a size of 100 kW/200 kWh, is assumed to be operated by the retailer but owned by the community, with any profits assigned to the community. In this scenario, we studied a battery operating under standard network tariffs and three different trial tariffs that distribution network service providers currently offer in Australia. On the other hand, the fleet of BTM batteries (3 kW, 3.3 kWh) are individually owned by households with solar installations, and their cumulative capacity matches that of the FTM battery. The comparison is based on key economic parameters, including network charges, retail margins, frequency control ancillary service (FCAS) revenues, wholesale energy costs, technology costs associated with community batteries, and net profit or loss for the community, as well as considerations of utility grid arbitrage and solar photovoltaic (PV) self-consumption. The study also assumes different grant levels to assess the impact of subsidies on the economic feasibility for both battery configurations. The findings indicate that, while both require some form of subsidy for profitability, the BTM batteries outperform the FTM battery in terms of economic viability and so would require lower grant support. The FTM battery case finds a need for grants ranging from 75% to 95% to break even, while the BTM fleet requires approximately 50% in grants to achieve a similar outcome. In conclusion, this study highlights the importance of grant support in making energy storage solutions economically feasible. In particular, it highlights how the less mature segment of FTM batteries will need higher support initially if it is to compete with BTM. The outcomes of this study inform decision-making processes for implementing energy storage solutions in similar communities, fostering sustainable and cost-effective energy systems. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

15 pages, 3872 KiB

Open AccessArticle

Impact of an ML-Based Demand Response Mechanism on the Electrical Distribution Network: A Case Study in Terni

by Marco Antonio Bucarelli, Mohammad Ghoreishi, Francesca Santori, Jorge Mira and Jesús Gorroñogoitia

Electronics 2023, 12(18), 3948; https://doi.org/10.3390/electronics12183948 - 19 Sep 2023

Viewed by 979

Abstract

The development of smart grids requires the active participation of end users through demand response mechanisms to provide technical benefits to the distribution network and receive economic savings. Integrating advanced machine learning tools makes it possible to optimise the network and manage the [...] Read more.

The development of smart grids requires the active participation of end users through demand response mechanisms to provide technical benefits to the distribution network and receive economic savings. Integrating advanced machine learning tools makes it possible to optimise the network and manage the mechanism to maximise the benefits. This paper proceeds by forecasting consumption for the next 24 h using a recurrent neural network and by processing these data using a reinforcement learning-based optimisation model to identify the best demand response policy. The model is tested in a real environment: a portion of the Terni electrical distribution network. Several scenarios were identified, considering users’ participation at different levels and limiting the potential with various constraints. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

16 pages, 3709 KiB

Open AccessArticle

Novel TI^λDND²N² Controller Application with Equilibrium Optimizer for Automatic Voltage Regulator

by Abdulsamed Tabak

Sustainability 2023, 15(15), 11640; https://doi.org/10.3390/su151511640 - 27 Jul 2023

Cited by 6 | Viewed by 1253

Abstract

Sustainability is important in voltage regulation control in grids and must be done successfully. In this paper, a novel tilt-fractional order integral-derivative with a second order derivative and low-pass filters controller, referred to as TI^λDND²N² controller, is proposed [...] Read more.

Sustainability is important in voltage regulation control in grids and must be done successfully. In this paper, a novel tilt-fractional order integral-derivative with a second order derivative and low-pass filters controller, referred to as TI^λDND²N² controller, is proposed to enhance the control performance of an automatic voltage regulator (AVR). In this article, the equilibrium optimizer (EO) algorithm is used to optimally determine the eight parameters of the proposed controller. In this study, a function consisting of time domain specifications is used as the objective function. To evaluate the performance of the proposed controller, it is compared with the proportional-integral-derivative (PID), fractional order PID (FOPID), PID accelerator (PIDA), PID plus second order derivative (PIDD²), and hybrid controllers used in previous studies. Then, Bode analysis is performed to determine the achievement of the proposed controller in the frequency domain. Finally, the robustness test is realized to assess the response of the proposed controller against the deterioration of the system parameters. As a result, the proposed controller demonstrates outstanding control performance compared to studies in terms of settling time, rise time and overshoot. The proposed controller shows superior performance not only in frequency domain analysis but also in perturbed system parameters. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

33 pages, 12779 KiB

Open AccessArticle

Decentralized Power Flow Control Strategy Using Transition Operations of DC-Bus Voltage for Detection of Uncertain DC Microgrid Operations

by Muhammad Alif Miraj Jabbar, Dat Thanh Tran and Kyeong-Hwa Kim

Sustainability 2023, 15(15), 11635; https://doi.org/10.3390/su151511635 - 27 Jul 2023

Cited by 1 | Viewed by 1289

Abstract

To enhance the reliability and flexibility of DC microgrids (DCMGs), this paper presents a decentralized power flow control strategy (PFCS) by using the transition operation modes. The transition operation modes are introduced as an effective communication method among power units, eliminating the use [...] Read more.

To enhance the reliability and flexibility of DC microgrids (DCMGs), this paper presents a decentralized power flow control strategy (PFCS) by using the transition operation modes. The transition operation modes are introduced as an effective communication method among power units, eliminating the use of additional digital communication links (DCLs) for the purpose of ensuring the power balance as well as the voltage regulation even under uncertain conditions. During the transition operation modes, the power unit which transmits the information shifts the DC-link voltage level, and the power unit which receives the information continuously monitors the DC-link voltage with predetermined time. When uncertain conditions occur in a particular power unit, this power unit triggers the transition operation modes to send this information to all power units in the DCMG system. The proposed PFCS can maintain the DC-link voltage at the nominal value for steady-state conditions both in the grid-connected mode and islanded mode. Moreover, the proposed PFCS significantly enhances the overall reliability of the decentralized DCMG system by effectively addressing several uncertainties stemmed from electricity price fluctuations, grid availability, battery state-of-charge (SOC) levels, and wind power variations. The scalability of the DCMG system is also demonstrated by incorporating an electric vehicle (EV) unit as an additional energy storage system (ESS). The EV unit seamlessly cooperates with the existing battery unit, functioning as additional ESS to regulate the DC-link voltage when the battery SOC level is low. Simulation and experimentation results under various conditions demonstrate the effectiveness of the proposed PFCS. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

18 pages, 5837 KiB

Open AccessArticle

A Switched Capacitor Inverter Structure with Hybrid Modulation Method Lowering Switching Loss

by Yanjun Zhao, Wentao Ge, Xiaobing Liang, Yue Yang, Jingxing Tang and Junfeng Liu

Energies 2023, 16(14), 5574; https://doi.org/10.3390/en16145574 - 24 Jul 2023

Cited by 1 | Viewed by 1660

Abstract

The high-frequency modulation method (HFM) for a switched capacitor (SC) inverter often leads to high switching loss since it increases switching frequency. In order to reduce the switching frequency and switching loss in the HFM for SC inverter, this paper proposes a novel [...] Read more.

The high-frequency modulation method (HFM) for a switched capacitor (SC) inverter often leads to high switching loss since it increases switching frequency. In order to reduce the switching frequency and switching loss in the HFM for SC inverter, this paper proposes a novel hybrid modulation strategy as well as a corresponding demo switched capacitor topology. The hybrid strategy limits the number of high-frequency switches, thus reducing the switching loss significantly. Meanwhile, the demo topology maintains the merits of current switched capacitor inverter such as low switch count, quadruple voltage-boosting ability and self-balancing capacity. The principle of the hybrid modulation method and the circuit configuration of the inverter are analyzed in detail. And comparisons are introduced to demonstrate the advantages of the proposed modulation method and topology. Finally, experimental results have proved the feasibility of the proposed inverter. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

23 pages, 4952 KiB

Open AccessArticle

Microgrid Robust Planning Model and Its Modification Strategy Based on Improved Grey Relational Theory

by Jiayin Xu, Xu Gui, Kun Li, Guifen Jiang, Tao Wang and Zhen Xu

Sustainability 2023, 15(3), 2835; https://doi.org/10.3390/su15032835 - 3 Feb 2023

Cited by 2 | Viewed by 1923

Abstract

A two-stage robust planning model is constructed in this paper, which can reduce the joint planning uncertainty of a wind-photovoltaic-energy storage system caused by the stochastic characteristics of renewable energy and ensure the sustainability of the power grid. Considering the life loss of [...] Read more.

A two-stage robust planning model is constructed in this paper, which can reduce the joint planning uncertainty of a wind-photovoltaic-energy storage system caused by the stochastic characteristics of renewable energy and ensure the sustainability of the power grid. Considering the life loss of energy storage system comprehensively, the joint planning is realized in the worst scenario. Addressing the problem that subjective and uniform robustness parameters in robust optimization cannot cope with the differentiated characteristics of each uncertainty, a robust microgrid-planning model and its modification strategy based on improved grey relational theory are proposed. The idea of weight distribution and dynamic value of identification coefficients are introduced into grey relational theory, so as to enhance the weight of indicators that influence planning and the relational degree between them, which can avoid the locally relational tendency. According to the relation degree, the renewable energy’s robustness parameters are modified to improve the applicability and flexibility of the microgrid-planning results. Finally, the effectiveness and superiority of the proposed theory and method are verified using a case study approach. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

22 pages, 5060 KiB

Open AccessArticle

Deep Reinforcement Learning for Charging Scheduling of Electric Vehicles Considering Distribution Network Voltage Stability

by Ding Liu, Peng Zeng, Shijie Cui and Chunhe Song

Sensors 2023, 23(3), 1618; https://doi.org/10.3390/s23031618 - 2 Feb 2023

Cited by 22 | Viewed by 5643

Abstract

The rapid development of electric vehicle (EV) technology and the consequent charging demand have brought challenges to the stable operation of distribution networks (DNs). The problem of the collaborative optimization of the charging scheduling of EVs and voltage control of the DN is [...] Read more.

The rapid development of electric vehicle (EV) technology and the consequent charging demand have brought challenges to the stable operation of distribution networks (DNs). The problem of the collaborative optimization of the charging scheduling of EVs and voltage control of the DN is intractable because the uncertainties of both EVs and the DN need to be considered. In this paper, we propose a deep reinforcement learning (DRL) approach to coordinate EV charging scheduling and distribution network voltage control. The DRL-based strategy contains two layers, the upper layer aims to reduce the operating costs of power generation of distributed generators and power consumption of EVs, and the lower layer controls the Volt/Var devices to maintain the voltage stability of the distribution network. We model the coordinate EV charging scheduling and voltage control problem in the distribution network as a Markov decision process (MDP). The model considers uncertainties of charging process caused by the charging behavior of EV users, as well as the uncertainty of uncontrollable load, system dynamic electricity price and renewable energy generation. Since the model has a dynamic state space and mixed action outputs, a framework of deep deterministic policy gradient (DDPG) is adopted to train the two-layer agent and the policy network is designed to output discrete and continuous control actions. Simulation and numerical results on the IEEE-33 bus test system demonstrate the effectiveness of the proposed method in collaborative EV charging scheduling and distribution network voltage stabilization. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

14 pages, 3956 KiB

Open AccessArticle

Short-Term Wind Power Prediction by an Extreme Learning Machine Based on an Improved Hunter–Prey Optimization Algorithm

by Xiangyue Wang, Ji Li, Lei Shao, Hongli Liu, Lei Ren and Lihua Zhu

Sustainability 2023, 15(2), 991; https://doi.org/10.3390/su15020991 - 5 Jan 2023

Cited by 22 | Viewed by 2036

Abstract

Considering the volatility and randomness of wind speed, this research suggests an improved hunter-prey optimization (IHPO) algorithm-based extreme learning machine (ELM) short-term wind power prediction model to increase short-term wind power prediction accuracy. The original wind power history data from the wind farm [...] Read more.

Considering the volatility and randomness of wind speed, this research suggests an improved hunter-prey optimization (IHPO) algorithm-based extreme learning machine (ELM) short-term wind power prediction model to increase short-term wind power prediction accuracy. The original wind power history data from the wind farm are used in the model to achieve feature extraction and data dimensionality reduction, using the partial least squares’ variable importance of projection (PLS-VIP) and normalized mutual information (NMI) methods. Adaptive inertia weights are added to the HPO algorithm’s optimization search process to speed up the algorithm’s convergence. At the same time, the initialized population is modified, to improve the algorithm’s ability to perform global searches. To accomplish accurate wind power prediction, the enhanced algorithm’s optimal parameters optimize the extreme learning machine’s weights and threshold. The findings demonstrate that the method accurately predicts wind output and can be confirmed using measured data from a wind turbine in Inner Mongolia, China. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

14 pages, 4794 KiB

Open AccessArticle

Transformer Fault Warning Based on Spectral Clustering and Decision Tree

by Hongli Liu, Junchao Chen, Ji Li, Lei Shao, Lei Ren and Lihua Zhu

Electronics 2023, 12(2), 265; https://doi.org/10.3390/electronics12020265 - 4 Jan 2023

Cited by 11 | Viewed by 2116

Abstract

The insufficient amount of sample data and the uneven distribution of the collected data across faults are key factors limiting the application of machine learning in power transformer fault warning, as demonstrated by the poor adaptability of the established data-driven models under actual [...] Read more.

The insufficient amount of sample data and the uneven distribution of the collected data across faults are key factors limiting the application of machine learning in power transformer fault warning, as demonstrated by the poor adaptability of the established data-driven models under actual operating conditions. In this paper, an unsupervised and supervised learning method is designed for power transformer fault early warning based on electrical quantities and vibration signals. The method is based on the Fourier levels of transformer vibration signals under different electrical conditions measured in the field, and the vibration features are clustered according to their intrinsic properties by means of a spectral clustering algorithm. A decision tree model of the vibration characteristics under each cluster is then constructed to calculate early warning values for the transformer vibration spectrum under different electrical conditions, enabling the assessment of transformer production variability. The above process, which is based on field measurement data and data mining analysis methods, is cheaper than the existing transformer fault warning techniques at home and abroad and makes better use of information and training models. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

36 pages, 6191 KiB

Open AccessReview

Review on the Microgrid Concept, Structures, Components, Communication Systems, and Control Methods

by Maysam Abbasi, Ehsan Abbasi, Li Li, Ricardo P. Aguilera, Dylan Lu and Fei Wang

Energies 2023, 16(1), 484; https://doi.org/10.3390/en16010484 - 1 Jan 2023

Cited by 63 | Viewed by 13327

Abstract

This paper provides a comprehensive overview of the microgrid (MG) concept, including its definitions, challenges, advantages, components, structures, communication systems, and control methods, focusing on low-bandwidth (LB), wireless (WL), and wired control approaches. Generally, an MG is a small-scale power grid comprising local/common [...] Read more.

This paper provides a comprehensive overview of the microgrid (MG) concept, including its definitions, challenges, advantages, components, structures, communication systems, and control methods, focusing on low-bandwidth (LB), wireless (WL), and wired control approaches. Generally, an MG is a small-scale power grid comprising local/common loads, energy storage devices, and distributed energy resources (DERs), operating in both islanded and grid-tied modes. MGs are instrumental to current and future electricity network development, such as a smart grid, as they can offer numerous benefits, such as enhanced network stability and reliability, increased efficiency, an increased integration of clean and renewable energies into the system, enhanced power quality, and so forth, to the increasingly growing and complicated power systems. By considering several objectives in both islanded and grid-tied modes, the development of efficient control systems for different kinds of MGs has been investigated in recent years. Among these control methods, LB communication (LBcom)-based control methods have attracted much attention due to their low expenses, recent developments, and high stability. This paper aims to shed some light on different aspects, a literature review, and research gaps of MGs, especially in the field of their control layers, concentrating on LBcom-based control methods. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

15 pages, 2590 KiB

Open AccessArticle

Approach to Multi-Timescale Optimization for Distributed Energy Resources Clusters Considering Flexibility Margin

by Bo Li, Weichao Ou, Tingwei Chen, Gaoming Li, Yuanrui Chen and Junfeng Liu

Energies 2023, 16(1), 308; https://doi.org/10.3390/en16010308 - 27 Dec 2022

Viewed by 1365

Abstract

The disordered access of massively distributed energy resources (DERs) brings great challenges to the operation stability of the power grid. This paper puts forward the concept of a cluster, which gathers DERs in large quantities, small capacities, dispersion and disorder to form a [...] Read more.

The disordered access of massively distributed energy resources (DERs) brings great challenges to the operation stability of the power grid. This paper puts forward the concept of a cluster, which gathers DERs in large quantities, small capacities, dispersion and disorder to form a large, centralized and orderly whole, namely cluster, with certain incentive measures. In this paper, a multi-timescale optimization method of day-ahead planning and intra-day rolling optimization is proposed according to the characteristics of aggregated clusters and the requirements of China’s power grid architecture. Specifically, the day ahead model is proposed in two steps: the first step is to establish an optimization model with the goal of optimal fitting the target load curve and maximizing the utilization of DERs; The second step is to establish a potential game model considering the reasonable distribution of cluster benefits. Taking the minimum percentage of output correction of each cluster as the objective, considering the deviation of load forecasting and the deviation of day ahead instruction execution, an intra-day rolling optimization model is established. Finally, the application scenario of cluster participation in power grid auxiliary peak shaving is simulated and verified. The simulation results show that the cluster collaborative optimization method proposed in this paper can effectively reduce the load peak valley difference and maximize the use of cluster resources. The optimization tasks can be reasonably allocated while ensuring the stable and reliable operation of the power grid. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

17 pages, 7507 KiB

Open AccessArticle

Control Strategy for Resonant Inverter in High Frequency AC Power Distribution System with Harmonic Suppression and Transient Performance Improvement

by Hao Zhou, Junfeng Liu, Zijie Fang, Pengyu Zhang, Bolun Zhang, Mingze Ma and Jun Zeng

Energies 2022, 15(23), 8992; https://doi.org/10.3390/en15238992 - 28 Nov 2022

Cited by 3 | Viewed by 2374

Abstract

In high frequency AC (HFAC) distribution system, the resonant inverter is used to improve power quality and keep the stability of the output AC voltage. Aiming at the problems of poor output power quality and slow transient performance caused by unreasonable filter parameter [...] Read more.

In high frequency AC (HFAC) distribution system, the resonant inverter is used to improve power quality and keep the stability of the output AC voltage. Aiming at the problems of poor output power quality and slow transient performance caused by unreasonable filter parameter design and load change during inverter operation, a single-phase H-bridge LCLC resonant inverter based on analog circuit controller implement is introduced in this paper for HFAC power distribution system (PDS). In this study, to design harmonic compensator and analyze the responsiveness of the inverter, it is necessary to analyze the output voltage total harmonic distortion (THD) of LCLC resonant inverter and the performance of the open loop system in detail. On the one hand, a proportional-integral-resonant (PIR) controller is designed to maintain the zero static error of the voltage output and suppress the output voltage THD of LCLC resonant inverter. On the other hand, an integral controller combines with phase-shift modulation (PSM) method is presented to effectively improve the transient performance of resonant inverter and provide the fixed frequency of the output voltage. On the basis of the above, the experimental prototype is implemented with the output AC voltage root mean square of 28 V, and the output voltage frequency for resonant inverter is equal to switching frequency. A rated output power of 130 W experimental platform is built to verify the effectiveness of the theoretical analysis, control strategy, and modulation method. Full article

(This article belongs to the Topic Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems)

► Show Figures

Figure 1

Topic Menu

Topic Editors

Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems

Topic Information

Keywords

Participating Journals

Published Papers (22 papers)

Further Information

Guidelines

MDPI Initiatives

Follow MDPI

Topic Menu

Topic Editors

Optimal Planning, Integration and Control of Smart Grids and Microgrids Systems

Topic Information

Keywords

Participating Journals

Related Topic

Published Papers (22 papers)

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
