Buildings

Research

22 pages, 5555 KiB

Open AccessArticle

Fatigue Life Prediction for Stud Shear Connectors Based on a Machine Learning Model

by Dong-Hyun Kang, Gi-Tae Roh, Chang-Su Shim and Kyoung-Chan Lee

Buildings 2024, 14(10), 3278; https://doi.org/10.3390/buildings14103278 - 16 Oct 2024

Viewed by 582

The shear connector of a steel composite bridge is designed by predicting fatigue life using the fatigue strength curves (S-N curve) based on push-out test results. The fatigue strength curves of the current design codes present only a linear relationship between the stress [...] Read more.

The shear connector of a steel composite bridge is designed by predicting fatigue life using the fatigue strength curves (S-N curve) based on push-out test results. The fatigue strength curves of the current design codes present only a linear relationship between the stress range and fatigue life on a log scale based on push-out experiment results. However, an alternative to the current empirical formula is necessary for the fatigue design of shear connections involving many detailed variations or high strength steel materials. This study collected and reanalyzed data from push-out fatigue tests to determine the factors influencing fatigue life and propose a machine learning-based fatigue life prediction model. The proposed machine learning model demonstrated an improvement in predictive performance of approximately 2 to 8 times compared to the existing design codes when evaluated against experimental data. Feature importance analysis based on the proposed model revealed that the stress range most significantly influenced fatigue life prediction. Model validation results indicated that the proposed model provided reliable predictions with accuracy and generalization performance. Moreover, it effectively accounted for uncertainty by incorporating features previously overlooked in existing design codes. Plans for fine-tuning pretrained models were also discussed. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

20 pages, 7502 KiB

Open AccessArticle

Analysis of Factors Affecting the Seismic Performance of Widened Flange Connections in Mid-Flange H-Beams and Box Columns

by Tigist Demssice Gemechu and Linfeng Lu

Buildings 2024, 14(10), 3170; https://doi.org/10.3390/buildings14103170 - 5 Oct 2024

Viewed by 609

Abstract

Following the Northridge and Kobe earthquakes, research has increasingly focused on achieving high ductility in beam-to-column connections. This study investigates the seismic performance of connections featuring widened beam-end flanges in mid-flange H-beams and box columns, an area with limited prior research compared to [...] Read more.

Following the Northridge and Kobe earthquakes, research has increasingly focused on achieving high ductility in beam-to-column connections. This study investigates the seismic performance of connections featuring widened beam-end flanges in mid-flange H-beams and box columns, an area with limited prior research compared to I-section columns and narrow-flange H-beams. Detailed finite element modeling using ABAQUS 6.1.4 demonstrates that widened beam-end flanges significantly improve bending capacity and ductility by relocating the plastic hinge away from the connection, thereby enhancing seismic resilience. Key findings include the identification of optimal design parameters: flange length ranging from 0.55 to 0.75 times the beam flange width, beam flange cutting length between 0.36 and 0.39 times the beam depth, and flange cutting depth from 0.19 to 0.23 times the beam flange width. These parameters ensure effective plastic hinge development and improved structural performance. This study introduces a novel approach that emphasizes geometric optimization over material-based enhancements, offering a cost-effective and practical solution for improving seismic performance and extending previous research insights. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

22 pages, 6176 KiB

Open AccessArticle

A Study on the Bearing Performance of an RC Axial Compression Shear Wall Strengthened by a Replacement Method Using Local Reinforcement with an Unsupported Roof

by Yuanwen Liu, Jie Deng, Yigang Jia, Guangyu Wu, Naiwen Ke and Xianglan Wei

Buildings 2024, 14(9), 2926; https://doi.org/10.3390/buildings14092926 - 15 Sep 2024

Viewed by 675

Abstract

When compared with conventional replacement reinforcement methods, the method of replacement using a local reinforcement with an unsupported roof has the advantages of shortening the reinforcement cycle and reducing material loss, and many scholars have carried out useful explorations thereof. At present, the [...] Read more.

When compared with conventional replacement reinforcement methods, the method of replacement using a local reinforcement with an unsupported roof has the advantages of shortening the reinforcement cycle and reducing material loss, and many scholars have carried out useful explorations thereof. At present, the formula for the bearing capacity of reinforcement by replacing concrete in the Code does not consider the effect of stress hysteresis on the parts of the reinforcement; so when the initial stress level is greater than 0.4, the Code’s strength utilization coefficient of 0.8 for the new concrete in the replaced area is on the side of insecurity. In this study, we are trying to improve and supplement the formula in the Code through the following work. Firstly, 18 groups of shear wall models were constructed using a VFEAP finite element analysis program to analyze the bearing performances of the shear walls after the replacement. The results showed that the replacement concrete strength, the initial stress level and the size of the replaced area had a significant influence on the bearing capacity of the shear wall after the replacement. Secondly, utilizing the replacement concrete strength, the initial stress level and the size of the replacement area as key parameters, then introducing the strength improvement coefficient considering the constraints of the stirrups, the modified strength utilization coefficient of new concrete in the replaced area was formulated. Finally, based on the modified strength utilization coefficient, the replacement bearing capacity formulas for the one-batch, two-batch, and three-batch replacements were derived, and an N-batch replacement bearing capacity formula was regressed and fitted on the basis of these equations, which are less discrete and more secure than the Code’s formula. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

48 pages, 28803 KiB

Open AccessArticle

Cyclic Behavior of Concrete-Filled Tube Columns with Bidirectional Moment Connections Considering the Local Slenderness Effect

by Ramón Mata and Eduardo Nuñez

Buildings 2024, 14(7), 2240; https://doi.org/10.3390/buildings14072240 - 21 Jul 2024

Viewed by 945

Abstract

In this research, the cyclic behavior of concrete-filled thin tube (CFTT) columns with bidirectional moment connections was numerically studied within the context of thin-walled structures. Novel considerations in the design of CFTT columns with slenderness sections are proposed through a parametric study. A [...] Read more.

In this research, the cyclic behavior of concrete-filled thin tube (CFTT) columns with bidirectional moment connections was numerically studied within the context of thin-walled structures. Novel considerations in the design of CFTT columns with slenderness sections are proposed through a parametric study. A total of 70 high-fidelity finite element (FE) models are developed using ANSYS software v2022 calibrated from experimental research using similar 3D joint configurations. Furthermore, a comparison of different width-to-thickness ratios in columns was considered. The results showed that the models with a high slenderness ratio reached a stable cyclic behavior until 0.03 rad of drift, and a flexural strength of 0.8 Mp was reached for 4% of the drift ratio according to the Seismic Provisions. However, this effect slightly decreased the strength and the dissipated energy of the moment connection in comparison to columns with a high ductility ratio. Moreover, an evaluation of concrete damages shows concrete cracked for cyclic loads higher than 3% of drift. Finally, the joint configurations studied can achieve a good performance, avoiding brittle failure mechanisms and ensuring the plastic hinges in the beams. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

19 pages, 11191 KiB

Open AccessArticle

Experimental and Numerical Investigation on Stress Concentration Factors of Offshore Steel Tubular Column-to-Steel Beam (STCSB) Connections

by Chao Hu, Qian Xia, Erxian Zeng, Jielong Zhu, Songsong Yu, Lei Zhang and Fei Xu

Buildings 2024, 14(7), 2004; https://doi.org/10.3390/buildings14072004 - 2 Jul 2024

Cited by 1 | Viewed by 791

Abstract

Steel tubular column-to-steel beam (STCSB) connections are critical parts in offshore structures, where complex component connections and the stress concentration are of significant concern. This study conducted stress concentration tests on welded STCSB connections and subsequently developed a finite element (FE) model for [...] Read more.

Steel tubular column-to-steel beam (STCSB) connections are critical parts in offshore structures, where complex component connections and the stress concentration are of significant concern. This study conducted stress concentration tests on welded STCSB connections and subsequently developed a finite element (FE) model for the connections, with the experimental results validating the accuracy of the model. The discussion focused on the influence of parameters such as the width-to-diameter ratio of the beam to the column, the diameter-to-thickness ratio of the column, the diameter-to-thickness ratio of the column to the beam, and the height-to-thickness ratio of the beam web on the fatigue performance. The study proposed optimization methods including the addition of stiffeners and outer flange plates. The findings indicate that optimized connection configurations can effectively mitigate stress concentration in the connected areas, thereby enhancing the structural stability and fatigue life. The width-to-diameter ratio of the beam to the column and the diameter-to-thickness ratio of the column significantly affect the fatigue performance of welded STCSB connections, with an increased width-to-diameter ratio of the beam to the column or a reduced diameter-to-thickness ratio of the column leading to a substantial decrease in the maximum stress concentration factors (SCFs). The addition of stiffeners and adjustment of the outer flange plate can improve stress concentration effects in the connection area. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

27 pages, 6875 KiB

Open AccessArticle

Seismic Performance of Wall-Type Concrete-Filled Steel Tubular Column to H-Beam Connections with Internal Diaphragms

by Hanchao Liu, Honggang Lei, Yuqi Huang, Yongchang Chen and Feng Xu

Buildings 2024, 14(6), 1741; https://doi.org/10.3390/buildings14061741 - 10 Jun 2024

Viewed by 741

Abstract

This study introduces a new internal diaphragm joint to connect steel beams with wall-type concrete-filled steel tubular (WCFST) columns. This study combines experimental research with numerical simulations for analysis. Firstly, one full-scale test specimen was designed and subjected to cyclic loading. The obtained [...] Read more.

This study introduces a new internal diaphragm joint to connect steel beams with wall-type concrete-filled steel tubular (WCFST) columns. This study combines experimental research with numerical simulations for analysis. Firstly, one full-scale test specimen was designed and subjected to cyclic loading. The obtained failure mode and hysteresis curves illustrate that the joint specimens exhibit ample energy dissipation capacities. Subsequently, a reliable FE model was obtained based on experimental verification, and parametric analysis was conducted. The findings indicate that axial compression ratios critically affect the load-carrying capacity and displacement at failure, with a 2% reduction in capacity for each 0.1 increment in the ratio. The thicknesses of the column web and flange in the joint area are recommended to be 0.85 to 1.2 times and 1 to 1.2 times the beam flange thickness, respectively. The length of the internal diaphragm is advised to be between 0.2 and 0.3 times the width of the cross-section. Overall, these results significantly enrich our understanding of WCFST systems and will inform future design and construction best practices. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

21 pages, 6564 KiB

Open AccessArticle

Mechanical Properties and Influence Factors of Ordinary Shear Links

by Shujun Hu, Shangwen Liu, Sizhi Zeng and Tiefeng Shao

Buildings 2024, 14(1), 160; https://doi.org/10.3390/buildings14010160 - 9 Jan 2024

Viewed by 819

Abstract

The current specification requires the same limiting values of inelastic rotation and the overstrength factor for shear links with a length ratio less than 1.6. However, recent studies have shown that the mechanical properties of ordinary shear links with a length ratio ranging [...] Read more.

The current specification requires the same limiting values of inelastic rotation and the overstrength factor for shear links with a length ratio less than 1.6. However, recent studies have shown that the mechanical properties of ordinary shear links with a length ratio ranging from 1.0 to 1.6 are obviously different from those of very short shear links with a length ratio less than 1.0. Additionally, shear links made of different steel materials have differences in mechanical properties. Based on Q345 steel, three ordinary shear links with a length ratio of 1.36 were designed to intensively explore the influence of stiffener configurations and spacing on mechanical properties. Under cyclic loading tests, the failure modes, hysteresis curves, skeleton curves, secant stiffness curves and energy dissipation capacities of shear link specimens were recorded. The results show that the overstrength factor and inelastic rotation of specimens SL-1 and SL-2, which had different stiffener configurations, reached 1.59 and 0.10, while those of specimen SL-3, which had wider stiffener spacing, reached 1.48 and 0.07, which showed that varying the stiffener configuration has no obvious effect, while relaxing stiffener spacing can result in severe buckling of the web. Additionally, its bearing capacity, inelastic rotation, secant stiffness and energy dissipation capacity reduced. Hence, the stiffener spacing should satisfy the requirements of the specification and not be too wide. Based on ABAQUS software, finite element models of ordinary shear links proved to be accurately consistent with test specimens in terms of mechanical properties. On this basis, 114 numerical models of ordinary shear links with different length ratios, stiffener spacings, flange-to-web area ratios, flange strengths, web depth-to-thickness ratios and stiffener thicknesses were designed to study the influence on the overstrength factor. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1

28 pages, 7984 KiB

Open AccessArticle

Cyclic Behavior of the Column-Tree Moment Connection with Weakened Plates: A Numerical Approach

by Pablo Matthews and Eduardo Núñez

Buildings 2023, 13(12), 2908; https://doi.org/10.3390/buildings13122908 - 22 Nov 2023

Viewed by 1263

Abstract

The use of column-tree connections is common in controlled shop environments due to their cost-effectiveness in achieving ductile welds. Field bolts are also easy to install and inspect. However, there is currently no prequalification available for these connections, their performance is not fully [...] Read more.

The use of column-tree connections is common in controlled shop environments due to their cost-effectiveness in achieving ductile welds. Field bolts are also easy to install and inspect. However, there is currently no prequalification available for these connections, their performance is not fully understood, and the cost of aftermath repairs is still a major concern for owners. In this research, analytical and numerical studies were performed to assess the cyclic behavior considering the effects of the bolted splice location, bolt slippage, and splice plate thickness. Fourteen numerical models using the finite element method in ANSYS software were analyzed to evaluate the nonlinear behavior of moment connection configurations in terms of the strength, stiffness, ductility, energy dissipation, and overall cyclic response. The results showed that appropriately proportioned bolted splice connections can meet the requirements for prequalified moment connections. The models complied with the criteria established in AISC 358 and achieved flexural resistance that was higher than 80% of the beam plastic moment at 4% of the interstory drift ratio. The weakened plates concentrated the inelastic action, which allowed us to prevent the brittle behavior and damage to the column, welding, and other components of the moment connection. Complex geometries or specially fabricated parts were not required, providing a cost-effective way to control seismic-related damage. Also, required repairs are based on the replacement of standard parts, reducing operational detentions in facilities. Finally, the moment connection studied is classified as partially restrained (PR) according to the requirements established in AISC 360. Full article

(This article belongs to the Special Issue Advanced Studies on Steel Structures)

► Show Figures

Figure 1
