Search Results (12)

Search Parameters:
Keywords = Chebyshev low-pass filter design

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 962 KB
Article
Automated Neural Network-Based Optimization for Enhancing Dynamic Range in Active Filter Design
by Funda Daylak and Serdar Ozoguz
Electronics 2025, 14(4), 786; https://doi.org/10.3390/electronics14040786 - 17 Feb 2025
Cited by 3 | Viewed by 1176
Abstract
This study presents an automated circuit design approach using neural networks to optimize the dynamic range (DR) of active filters, illustrated through the design of a 7th-order Chebyshev low-pass filter. Traditional design methods rely heavily on designer expertise, often resulting in time-intensive and [...] Read more.
This study presents an automated circuit design approach using neural networks to optimize the dynamic range (DR) of active filters, illustrated through the design of a 7th-order Chebyshev low-pass filter. Traditional design methods rely heavily on designer expertise, often resulting in time-intensive and energy-consuming processes. Two techniques are proposed: inverse modeling and forward modeling. In inverse modeling, artificial neural networks (ANNs) predict circuit parameters to meet specific performance goals. A randomly selected subset, comprising 0.05% of the 1,953,125 possible circuit configurations, was used to train and validate the model, providing an accurate representation of the entire dataset without requiring full-scale data analysis. In forward modeling, the same subset was used to train the network, which was then used to predict DR values for the remaining dataset. This approach enabled the identification of circuit parameters that resulted in optimal DR values. The results confirm the effectiveness of these techniques, with both inverse modeling and forward modeling outperforming the standard circuit design. At 160 kHz, a critical frequency for the operation of the designed filter, inverse modeling achieved a DR of 140.267 dB and forward modeling reached 136.965 dB, compared to 132.748 dB for the standard circuit designed using the traditional approach. These findings demonstrate that ANN-based methods can significantly enhance design accuracy, reduce time requirements, and improve energy efficiency in analog circuit optimization. Full article
Show Figures

Figure 1

17 pages, 5553 KB
Article
Complementary Metal Oxide Semiconductor Circuit Realization of Inverse Chebyshev Low-Pass Filter of Order (1 + α)
by Soubhagyaseetha Nettar, Shankaranarayana Kilingar, Chandrika B. Killuru and Dattaguru V. Kamath
Fractal Fract. 2024, 8(12), 712; https://doi.org/10.3390/fractalfract8120712 - 30 Nov 2024
Cited by 1 | Viewed by 1083
Abstract
This paper presents the CMOS circuit realization of a low-pass Inverse Chebyshev fractional-order filter (FOF) of order (1 + α) using the inverse-follow-the-leader feedback (IFLF) topology. A nonlinear least squares optimization routine is used to determine the coefficients of the fractional-order transfer function [...] Read more.
This paper presents the CMOS circuit realization of a low-pass Inverse Chebyshev fractional-order filter (FOF) of order (1 + α) using the inverse-follow-the-leader feedback (IFLF) topology. A nonlinear least squares optimization routine is used to determine the coefficients of the fractional-order transfer function to approximate the stop-band characteristics. The Inverse Chebyshev FOF of orders 1.3, 1.6, and 1.9 using cross-coupled operational transconductance amplifier (OTA) was designed in united microelectronics corporation (UMC) 180 nm complementary metal–oxide–semiconductor process. The MATLAB and Cadence Spectre simulations are used to validate the implementation of the fractional-order filter of orders 1.3, 1.6 and 1.9. The dynamic range (DR) of the filter is found to be 83.04 dB, 86.13 dB, and 84.71 dB, respectively, for order of 1.3, 1.6, and 1.9. The simulation results such as magnitude response, transient plot, Monte Carlo, and PVT plots, have justified the design accuracy. Full article
(This article belongs to the Section Numerical and Computational Methods)
Show Figures

Figure 1

16 pages, 3458 KB
Article
Design of Infinite Impulse Response Filters Based on Multi-Objective Particle Swarm Optimization
by Te-Jen Su, Qian-Yi Zhuang, Wei-Hong Lin, Ya-Chung Hung, Wen-Rong Yang and Shih-Ming Wang
Signals 2024, 5(3), 526-541; https://doi.org/10.3390/signals5030029 - 14 Aug 2024
Cited by 4 | Viewed by 1934
Abstract
The goal of this study is to explore the effectiveness of applying multi-objective particle swarm optimization (MOPSO) algorithms in the design of infinite impulse response (IIR) filters. Given the widespread application of IIR filters in digital signal processing, the precision of their design [...] Read more.
The goal of this study is to explore the effectiveness of applying multi-objective particle swarm optimization (MOPSO) algorithms in the design of infinite impulse response (IIR) filters. Given the widespread application of IIR filters in digital signal processing, the precision of their design plays a significant role in the system’s performance. Traditional design methods often encounter the problem of local optima, which limits further enhancement of the filter’s performance. This research proposes a method based on multi-objective particle swarm optimization algorithms, aiming not just to find the local optima but to identify the optimal global design parameters for the filters. The design methodology section will provide a detailed introduction to the application of multi-objective particle swarm optimization algorithms in the IIR filter design process, including particle initialization, velocity and position updates, and the definition of objective functions. Through multiple experiments using Butterworth and Chebyshev Type I filters as prototypes, as well as examining the differences in the performance among these filters in low-pass, high-pass, and band-pass configurations, this study compares their efficiencies. The minimum mean square error (MMSE) of this study reached 1.83, the mean error (ME) reached 2.34, and the standard deviation (SD) reached 0.03, which is better than the references. In summary, this research demonstrates that multi-objective particle swarm optimization algorithms are an effective and practical approach in the design of IIR filters. Full article
Show Figures

Figure 1

13 pages, 5586 KB
Article
0.5 V Multiple-Input Fully Differential Operational Transconductance Amplifier and Its Application to a Fifth-Order Chebyshev Low-Pass Filter for Bio-Signal Processing
by Tomasz Kulej, Fabian Khateb and Montree Kumngern
Sensors 2024, 24(7), 2150; https://doi.org/10.3390/s24072150 - 27 Mar 2024
Cited by 5 | Viewed by 2016
Abstract
This paper presents a multiple-input fully differential operational transconductance amplifier (MI-FD OTA) with very low power consumption. To obtain a differential MOS pair with minimum supply voltage and minimum power consumption, the multiple-input bulk-driven MOS transistor operating in the subthreshold region is used. [...] Read more.
This paper presents a multiple-input fully differential operational transconductance amplifier (MI-FD OTA) with very low power consumption. To obtain a differential MOS pair with minimum supply voltage and minimum power consumption, the multiple-input bulk-driven MOS transistor operating in the subthreshold region is used. To show the advantage of the MI-FD OTA, a fifth-order Chebyshev filter was used to realize a low-pass filter capable of operating with a supply voltage of 0.5 V and consuming 60 nW at a nominal setup current of 3 nA. The proposed filter uses five MI-FD OTAs and five capacitors. The total harmonic distortion (THD) was 0.97% for a rail-to-rail sinusoidal input signal. The MI-FD OTA and the filter application were designed and simulated in the Cadence environment using a 0.18 µm CMOS process from TSMC. The robustness of the design was confirmed by Monte Carlo analysis and process, voltage, and temperature corner analysis. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

30 pages, 11047 KB
Article
Analytical Design of Gaussian Anisotropic 2D FIR Filters and Their Implementation Using the Block Filtering Approach
by Radu Matei and Doru Florin Chiper
Electronics 2024, 13(7), 1243; https://doi.org/10.3390/electronics13071243 - 27 Mar 2024
Cited by 3 | Viewed by 1381
Abstract
This work proposes an analytical design procedure for a particular class of 2D filters, namely anisotropic Gaussian FIR filters. The design is achieved in the frequency domain and starts from a low-pass Gaussian 1D prototype with imposed specifications, whose frequency response is efficiently [...] Read more.
This work proposes an analytical design procedure for a particular class of 2D filters, namely anisotropic Gaussian FIR filters. The design is achieved in the frequency domain and starts from a low-pass Gaussian 1D prototype with imposed specifications, whose frequency response is efficiently approximated by a factored trigonometric polynomial using the Chebyshev series. Then, using specific 1D to 2D frequency mappings applied to the prototype, the frequency response for a 2D anisotropic filter with a specified orientation angle is directly derived in two versions, namely with a straight or elliptical shape in the frequency plane. The resulting filters have an accurate shape with low distortion. Several design examples for specified parameters (angle and selectivity) are provided. Then, simulations of directional filtering on various test images are given, which show their capability of extracting oriented lines or other various oriented objects from synthetic or real-life images. Finally, a computationally efficient implementation at the system level is proposed, based on a polyphase decomposition and block-filtering approach, which yields a 2D filter with a high degree of parallelism and low arithmetic complexity. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

23 pages, 19289 KB
Article
Various-Order Low-Pass Filter with the Electronic Change of Its Approximation
by Lukas Langhammer, Roman Sotner and Radek Theumer
Sensors 2023, 23(19), 8057; https://doi.org/10.3390/s23198057 - 24 Sep 2023
Cited by 6 | Viewed by 2465
Abstract
The design of a low-pass-frequency filter with the electronic change of the approximation characteristics of resulting responses is presented. The filter also offers the reconnection-less reconfiguration of the order (1st-, 2nd-, 3rd- and 4th-order functions are available). Furthermore, the filter offers the electronic [...] Read more.
The design of a low-pass-frequency filter with the electronic change of the approximation characteristics of resulting responses is presented. The filter also offers the reconnection-less reconfiguration of the order (1st-, 2nd-, 3rd- and 4th-order functions are available). Furthermore, the filter offers the electronic control of the cut-off frequency of the output response. The feature of the electronic change in the approximation characteristics is investigated for the Butterworth, Bessel, Elliptic, Chebyshev and Inverse Chebyshev approximations. The design is verified by PSpice simulations and experimental measurements. The results are also supported by the transient domain response (response to the square waveform), comparison of the group delay, sensitivity analysis and implementation feasibility based on given approximation. The benefit of the proposed electronic change in the approximation characteristics feature (in general signal processing or for sensors in particular) is presented and discussed for an exemplary scenario. Full article
Show Figures

Figure 1

17 pages, 8290 KB
Article
Compact Wideband Groove Gap Waveguide Bandpass Filters Manufactured with 3D Printing and CNC Milling Techniques
by Clara Máximo-Gutierrez, Juan Hinojosa, José Abad-López, Antonio Urbina-Yeregui and Alejandro Alvarez-Melcon
Sensors 2023, 23(13), 6234; https://doi.org/10.3390/s23136234 - 7 Jul 2023
Cited by 7 | Viewed by 2582
Abstract
This paper presents for the first time a compact wideband bandpass filter in groove gap waveguide (GGW) technology. The structure is obtained by including metallic pins along the central part of the GGW bottom plate according to an n-order Chebyshev stepped impedance [...] Read more.
This paper presents for the first time a compact wideband bandpass filter in groove gap waveguide (GGW) technology. The structure is obtained by including metallic pins along the central part of the GGW bottom plate according to an n-order Chebyshev stepped impedance synthesis method. The bandpass response is achieved by combining the high-pass characteristic of the GGW and the low-pass behavior of the metallic pins, which act as impedance inverters. This simple structure together with the rigorous design technique allows for a reduction in the manufacturing complexity for the realization of high-performance filters. These capabilities are verified by designing a fifth-order GGW Chebyshev bandpass filter with a bandwidth BW = 3.7 GHz and return loss RL = 20 dB in the frequency range of the WR-75 standard, and by implementing it using computer numerical control (CNC) machining and three-dimensional (3D) printing techniques. Three prototypes have been manufactured: one using a computer numerical control (CNC) milling machine and two others by means of a stereolithography-based 3D printer and a photopolymer resin. One of the two resin-based prototypes has been metallized from a silver vacuum thermal evaporation deposition technique, while for the other a spray coating system has been used. The three prototypes have shown a good agreement between the measured and simulated S-parameters, with insertion losses better than IL = 1.2 dB. Reduced size and high-performance frequency responses with respect to other GGW bandpass filters were obtained. These wideband GGW filter prototypes could have a great potential for future emerging satellite communications systems. Full article
(This article belongs to the Collection RF and Microwave Communications)
Show Figures

Figure 1

11 pages, 801 KB
Article
Design of a Wide-Beamwidth Pixelated Dielectric Resonator Antenna Using a Modified Stepped-Impedance Filter to Suppress Harmonics
by Dong Geun Lee, Taeyong Jeong and Keum Cheol Hwang
Appl. Sci. 2022, 12(15), 7765; https://doi.org/10.3390/app12157765 - 2 Aug 2022
Cited by 2 | Viewed by 2272
Abstract
This study designed a wide-beamwidth pixelated dielectric resonator antenna (DRA) combined with a low-pass filter (LPF) to suppress harmonics. The DRA was designed to create a wide-beam pattern with a pixelated structure. The pixelated DRA was optimized by a genetic-learning particle swarm optimization [...] Read more.
This study designed a wide-beamwidth pixelated dielectric resonator antenna (DRA) combined with a low-pass filter (LPF) to suppress harmonics. The DRA was designed to create a wide-beam pattern with a pixelated structure. The pixelated DRA was optimized by a genetic-learning particle swarm optimization algorithm. To prevent significant higher-mode radiation and harmonics from occurring in the DRA, an LPF was included in its feeding line. The filter had a seventh-order Chebyshev design, and a hybrid step-impedance filter was proposed by modifying the step-impedance filter for use in narrow spaces behind the ground. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

18 pages, 5911 KB
Article
Design of an Efficient 24–30 GHz GaN MMIC Power Amplifier Using Filter-Based Matching Networks
by Lin Peng, Jianqiang Chen, Zhihao Zhang and Gary Zhang
Electronics 2022, 11(13), 1934; https://doi.org/10.3390/electronics11131934 - 21 Jun 2022
Cited by 7 | Viewed by 4398
Abstract
A broadband GaN MMIC power amplifier (PA) with compact dimensions of 1.94 × 0.83 mm2 is presented for 5G millimeter-wave communication. To guarantee output capability at the operating band edges where serious performance degradation is likely to occur, the appropriate large-signal matching [...] Read more.
A broadband GaN MMIC power amplifier (PA) with compact dimensions of 1.94 × 0.83 mm2 is presented for 5G millimeter-wave communication. To guarantee output capability at the operating band edges where serious performance degradation is likely to occur, the appropriate large-signal matching model and optimal impedance domain need to be carefully determined through load-pull analysis. Broadband matching networks (MNs) in the lowpass form are thereafter developed based on the Chebyshev filter synthesis theory. Using high-pass interstage MN in conjunction with parallel RC lossy circuits to compensate for the transistor’s negative gain roll-off slope ensures a flat frequency response. The input MN is designed as a band-pass filter due to the reactance extracted from the input side of the stabilized device exhibiting series LC resonance characteristics. Measured on-wafer pulsed results for the proposed three-stage PA demonstrate up to 30.9 dBm of output power, more than 28.6 dB of small-signal gain, and a peak power-added efficiency (PAE) of 35.6% at 27 GHz. Both uniform gain and saturated output power (Psat) are achieved across 24–30 GHz with fluctuations of less than 0.8 dB. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

13 pages, 6538 KB
Article
Quasi-Isotropic Hybrid Dielectric Resonator Antenna—Bow-Tie Patch with Harmonic Suppression
by Taeyong Jeong, Jong Seon Lee, Dong Geun Lee, Jun Hee Kim, Jinsu Park, Dong Hyee Hwang and Keum Cheol Hwang
Appl. Sci. 2022, 12(8), 3842; https://doi.org/10.3390/app12083842 - 11 Apr 2022
Cited by 3 | Viewed by 2377
Abstract
This paper proposes a quasi-isotropic hybrid dielectric resonator antenna (DRA) and bow-tie patch with harmonics suppression. The suggested antenna consists of a DRA, a bow-tie patch, and a microstrip seventh-order Chebyshev low-pass filter. By loading a bow-tie patch on the designed DRA, a [...] Read more.
This paper proposes a quasi-isotropic hybrid dielectric resonator antenna (DRA) and bow-tie patch with harmonics suppression. The suggested antenna consists of a DRA, a bow-tie patch, and a microstrip seventh-order Chebyshev low-pass filter. By loading a bow-tie patch on the designed DRA, a quasi-isotropic pattern is realized. The seventh-order Chebyshev low-pass filter was applied to the feed line, and harmonics were reduced in the section separate to the operating band to remove harmonics generated by the proposed antenna. The simulated S11 that satisfies below −10 dB is 3.09–3.3 GHz (6.25%), and the measured S11 is 3.10–3.28 GHz (5.64%). The simulated gain difference considering all radiating regions (0φ360 and 0θ180) is 7.211 dB. Compared with the antenna without a filter, the harmonic gain was reduced by 10.847 and 15.774 dB. The measured gain isolation of the operating band and the second and third harmonics are 10.10 and 18.94 dB, respectively. The proposed antenna is considered to be applicable to applications that require radio wave reception in all directions such as wireless point access points, internet of things and radio frequency identification, and is expected to contribute to reducing the size of the RF system. Full article
Show Figures

Figure 1

18 pages, 6597 KB
Article
An Optimal Framework for WDM Systems Using Analytical Characterization of Refractive Index-Related Nonlinear Impairments
by Muhammad Irfan, Farman Ali, Fazal Muhammad, Abdullah S. Alwadie, Adam Glowacz, Iwona Goldasz, Ryszard Mielnik, Fahad Salem Alkahtani and Hidayatullah Khan
Electronics 2021, 10(3), 221; https://doi.org/10.3390/electronics10030221 - 20 Jan 2021
Cited by 7 | Viewed by 3437
Abstract
Nonlinear effects in the optical transmission systems (OTSs) are considered as the major performance limiting factor to provide high transmission rates over ultra-long distances. As the demands for system capacity, transmission range and the number of users is increasing exponentially with the development [...] Read more.
Nonlinear effects in the optical transmission systems (OTSs) are considered as the major performance limiting factor to provide high transmission rates over ultra-long distances. As the demands for system capacity, transmission range and the number of users is increasing exponentially with the development of mobile broadband, new challenges are being faced by the backbone optical networks. Mainly, the refractive index related non-linearities (RIrNLs) need to be characterized to design an optimal OTS for error-free transmission with provision of wavelength division multiplexing (WDM) to support for multiple channels. This paper provides an estimation technique of RIrNLs for long-haul transmission and their treatment for different channel spacing and the number of channels in a WDM system operating frequency domain multiple in multiple out (FD-MIMO) equalizer based digital signal processing (DSP) receiver and microstrip Chebyshev low pass filter. The main focus of this work is to utilize the existing structure of OTS for RIrNLs treatment with a low cost solution. Thus, by varying the parameters of the third order dispersion parameters, group velocity dispersion parameters, phase modulation dispersion and nonlinear refractive index, the impact of RIrNLs is investigated in detail to enhance the transmission range and capacity of the current OTS. The proposed system is analyzed in terms of range of input power, fiber length and received power for OTS figure of merits including bit error rate (BER) and optical signal-to-noise ratio (OSNR). Using duo-binary modulation, the BER achieved in this work is <105 till 500 km range, for maximum number of 32 channels, with 100 Gbps aggregate data rate, which shows the feasibility and effectiveness of our proposed model. Full article
(This article belongs to the Section Networks)
Show Figures

Figure 1

10 pages, 2404 KB
Article
Design of a Wide-Band Microstrip Filtering Antenna with Modified Shaped Slots and SIR Structure
by Yasir I. A. Al-Yasir, Hana’a A. Alhamadani, Ahmed S. Kadhim, Naser Ojaroudi Parchin, Ameer L. Saleh, Issa T. E. Elfergani, Jonathan Rodriguez and Raed A. Abd-Alhameed
Inventions 2020, 5(1), 11; https://doi.org/10.3390/inventions5010011 - 24 Feb 2020
Cited by 13 | Viewed by 6673
Abstract
This paper presents a new compact microstrip filtering antenna with modified shaped slots to improve the impedance bandwidth. The proposed microstrip filtering antenna consists of three parts: the monopole radiating patch antenna; the Stepped Impedance Resonator (SIR) filter; and the feeding microstrip line. [...] Read more.
This paper presents a new compact microstrip filtering antenna with modified shaped slots to improve the impedance bandwidth. The proposed microstrip filtering antenna consists of three parts: the monopole radiating patch antenna; the Stepped Impedance Resonator (SIR) filter; and the feeding microstrip line. The designed structure is achieved on one-sided glass epoxy FR-4 substrate with dielectric constant εr = 4.4 and thickness h = 1.6 mm. The design procedure of the proposed filtering antenna starts from the second-order Chebyshev low pass filter (LPF) prototype. The achieved results show an excellent performance of S11-parameter with broadside antenna gain on +z-direction. Having two transmission zeros at 5.4 GHz and 7.7 GHz, good skirt selectivity and a wide-band impedance bandwidth of about 1.66 GHz makes the designed filtering antenna suitable for high-speed data communications. Both the simulation results generated by using the Computer Simulation Technology (CST) software package and the measurement achieved by using a vector network analyzer (HP 8510C) and the anechoic chamber show good agreement. Full article
Show Figures

Figure 1
