The subject of this paper is how certain electrode array parameters affect the operating characteristics of electrohydrodynamic (EHD) propulsion systems. The focus is on how changes in the shapes and arrangements of electrodes, such as the diameter of the coronating conductor, effective electrode length and the spacing between electrodes, influence the formation and behaviour of the corona discharge and the resulting ion-induced airflow. A modular experimental setup was created to allow for a systematic study of each parameter in controlled atmospheric conditions using a high-voltage DC power supply. The study includes both the theoretical background and experimental methods, in order to explore the connections between the electric field distribution, ion mobility and propulsion force generation. By measuring the current, voltage and flow velocity, the impacts of design changes on the propulsion behaviour are examined. The findings help to improve the understanding of EHD propulsion mechanics and lay the groundwork for optimising electrode designs in future applications. This research supports the ongoing work to create compact, quiet and efficient propulsion technologies for use in lightweight aerial vehicles, precise fluid control and other engineering areas, where solid-state thrust systems have clear benefits over traditional methods. Full article

Phased-array ultrasonic transducers using sol–gel composites face challenges in terms of polarization uniformity when using conventional corona poling. Pb(Zr, Ti)O₃ (PZT)/PZT composites with a thickness of 25 µm were fabricated on 3 mm thick titanium substrates, and the samples were poled by AC poling, DC poling, and corona discharge poling at RT. It was found that the polarization direction could be controlled by the voltage off-phase angle. When poling was performed with a voltage off-phase angle of 90°, applied voltage of 200 V (rms), 10 cycles, and frequency of 1 Hz, average values and standards of measured piezoelectric constant d₃₃ of −35.1 ± 0.8 pC/N and ultrasonic sensitivity of 11.4 ± 0.1 dB were obtained. Furthermore, the AC-poled samples demonstrated smaller variations in d₃₃ and ultrasonic sensitivity compared with the corona-poled samples, and higher values of d₃₃ and ultrasonic sensitivity compared with the DC-poled samples, indicating the potential of AC poling for PZT/PZT sol–gel composites with large areas. Full article

Although oily sludge is an industrial waste and difficult to separate, its calorific value can still reach 6000 cal/g, thus possessing significant recycling value. This study compares various types of non-thermal plasma for refining oily sludge. The pre-treatment technology utilized filtration combined with solvent extraction to extract the oil portion from the oily sludge. Subsequently, two types of non-thermal plasma, DC streamer discharge and dielectric plasma discharge, were used to crack and activate the oily sludge under different operating conditions. The fuel compositions and properties of the refined fuel treated by two types of non-thermal plasma were compared. The elemental carbon and oxygen of the oily sludge after treatment in a direct DBD plasma reactor for 8 min were 1.96 wt.% less and 1.38 wt.% higher than those of commercial diesel. The research results indicate that the pre-treatment process can effectively improve the refined fuel properties. After pre-treatment, the calorific value of the primary product from the oily sludge can reach 10,598 cal/g. However, the carbon residue of the oily sludge after pre-treatment remained as high as 5.58 wt.%, which implied that further refining processes are required. The streamer discharge plasma reactor used a tungsten needle tip as a high-voltage electrode, leading to a rather small treated range. Corona discharge and arc formation are prone to being produced during the plasma action. Moreover, the addition of quartz glass beads can form a protruding area on the surface of the oily sludge, generating an increase in the reacting surface of the oily sludge, and hence an enhancement of treatment efficiency, in turn. The direct treatment of DBD plasma can thus have a wider and more uniform operating range of plasma generation and a superior efficiency of plasma reaction. Therefore, a direct DBD type of non-thermal equilibrium plasma reactor is preferable to treat oily sludge among those three types of plasma reactor designs. Additionally, when the plasma voltage is increased, it effectively enhances fuel properties. Full article

This study proposes an electrohydrodynamic multiphysics modeling and finite element analysis technique to accurately simulate corona-streamer discharges in a two-phase flow medium. The discharge phenomenon is modeled as a multiphysics system, coupling the Poisson equation for the electric field with a charge dynamics model based on fluid methods and a thermofluid field for temperature effects. To optimize the numerical simulation, the tip-flat plate electrode model was simplified to two-dimensional axisymmetry, and an unordered lattice network was used to reduce computational time while maintaining high resolution in the region of interest. A high DC voltage was applied to the model to generate a local non-uniform electric field exceeding 10 MV/m, allowing the numerical simulations of ionization, recombination, and charge attachment in the streamer channel. The numerical results were compared with voltage and current measurements from full-scale experiments under identical geometry and initial conditions to verify the effectiveness of the proposed method. The results of this study enhance the understanding of the multiphysical mechanisms behind electrical discharge phenomena and can enable the prediction of insulation failure through simple simulations, eliminating insulation experiments on devices. Full article

This study investigates the performance of DC corona discharge electrostatic precipitators (ESPs) for NO conversion to increase DeNO_x technologies’ efficiency for small-scale biomass combustion systems. Experiments were conducted using a 5 kW automatic wood pellet domestic heat source with combustion gas treated in a specially designed ESP operated in both positive and negative corona modes, resulting in a reduction in NO concentrations from 130 mg/m³ to 27/29 mg/m³ for positive/negative polarities (at 0 °C and 101.3 kPa). NO conversion efficiency was evaluated across a range of specific input energies (SIEs) from 0 to 50 J/L. The results demonstrate that DC corona ESPs can achieve up to 78% NO reduction, with positive corona demonstrating a greater energy efficiency, requiring a lower SIE (35 J/L) compared to the negative corona mode (48 J/L). A detailed analysis of reaction pathways revealed distinct conversion mechanisms between the two modes. In positive corona, dispersed active species distribution led to more uniform NO conversion, while negative corona exhibited concentrated reaction zones with about 20% higher ozone production. The reactions involving O and OH radicals were more important in positive corona, whereas ozone-mediated oxidation dominated in negative corona. The research results demonstrate that ESP technology with DC corona offers a promising, energy-efficient solution for NO_x control in small-scale combustion systems. Full article

With the demand for high-safety, high-integration, and lightweight micro- and nano-electronic components, an MEMS electromagnetic energy-releasing component was innovatively designed based on the corona discharge theory. The device subverted the traditional device-level protection method for electromagnetic energy, realizing the innovation of adding a complex circuit system to the integrated chip through micro-nanometer processing technology and enhancing the chip’s size from the centimeter level to the micron level. In this paper, the working performance of the MEMS electromagnetic energy-releasing component was verified through a combination of a simulation, a static experiment, and a dynamic test, and a characterization test of the tested MEMS electromagnetic energy-releasing component was carried out to thoroughly analyze the effect of the MEMS electromagnetic energy-releasing component. The results showed that after the strong electromagnetic pulse injection, the pulse breakdown voltage of the MEMS electromagnetic energy-releasing component increased exponentially in terms of the pulse injection voltage, and the residual pulse current decreased significantly from one-third to one-half of the original, representing a significant protective effect. In a DC environment, the breakdown voltage of the needle–needle structure of the MEMS electromagnetic energy-releasing component was 144 V, and the on-time was about 0.5 ms. Full article

This work deals with designing the optimal shape of the spinning electrode to optimize the distribution of the electric field and suppress the formation of corona discharges on the surface of the electrode during electrospinning using direct current (DC). Some of the solutions used for electrospinning are solved in flammable solvents, such as PVB; therefore, corona discharges are hazardous, as they cause sparks that can cause fires and explosions. The shape optimization was carried out on a plate weir electrode, which uses the principle of free surface spinning. Using the electric field simulation, an analysis of the plate weir spinner was carried out, and its optimization was aimed at minimizing the occurrence of corona discharges, which negatively affect the spinning process. Based on the simulations’ results, the spinning electrode design parameters were adjusted so that an even distribution of the electric field over the entire active surface of the electrode was ensured, and the incidence of corona discharges was prevented. A laboratory experiment was used to validate the function of the design changes in the spinning electrode. Full article

The detection of corona-related defects in transmission lines has been included in the work of transmission line defect detection. Ultraviolet detection technology has gradually been widely applied in the field of corona discharge detection. However, the current research on the application of ultraviolet detection technology in transmission lines is relatively simple and mainly limited to using changes in the photon count to determine whether corona discharge has occurred. To address this, this study used a mini corona cage to simulate transmission lines and measured the changes in the photon count, spot area, and corona current in the corona inception process of different types of smooth, stainless-steel conductors. This study also investigated the variations in the photon count and spot area depending on conductor corona intensity, ultraviolet imager gain, and observation distance. The results show that the photon count and spot area can, to some extent, reflect the intensity of corona discharge. Both the photon count and spot area exhibited quadratic relationships with the voltage. As the observation distance increased, both the photon count and spot area showed exponential decay. The photon count exhibited a trend of initially increasing, then decreasing, and finally increasing again with the increase of gain, while the spot area showed exponential growth with increasing gain. The photon count and spot area can complement each other to identify and characterize the intensity of corona discharge. Full article

The DC negative corona of needle-plate electrodes can generate atmospheric pressure low-temperature plasma active particles, which have important effects on biological mutagenesis. The DC negative corona discharge of an air needle-plate electrode with effective consideration of NO_x particles was simulated and the Trichel pulse current was obtained, focusing on the development of particles and the distribution of active nitrogen oxides (RONS) at four moments in the pulse process. The simulation results indicate that the positive ions (N₂⁺ and O₂⁺) and negative ions (O⁻ and O₂⁻) were closely related to the current changes, and the negative ions (O⁻ and O₂⁻) presented a typical stratification phenomenon. RONS (H₂O₂, O₃, and NO) were approximately uniformly distributed above the level of the plate electrode at the same instant, with H₂O₂ and O₃ except for the area below the needle tip. They trended to a cumulative increase in concentration with time. This study provides a theoretical basis for corona discharge plasma seed treatment technology. Full article

For investigating the relationship between the surface corona discharge of a DC wire and other influencing factors, a hybrid numerical model based on a fluid-chemical reaction was proposed to simulate the discharge process at the tip defect of the wire. Under different defect geometries and gas pressures achieved via simulation, the microscopic process of the reaction and movement of electrons and heavy particles during a positive corona discharge was studied, and characteristic parameters such as corona inception voltage and discharge current were analyzed. Furthermore, through the corona cage test, for a specific electrode configuration, corona inception voltages under different pressures were compared and verified, which showed that the model was reasonable. The results showed that the maximum electron density of the streamer head was about 1 × 10²⁰ m⁻³, the rise time of the pulse current was about 10 ns, and the decay time was about 300–500 ns. The corona inception voltage decreased with an increase in the tip height and decreases in the tip curvature radius, conductor radius, and background air pressure; the amplitude of the pulse current increased with increases in the wire radius and curvature radius of the defect tip and decreases in tip height and background air pressure. The experimental results are consistent with the simulation results, which verifies the reasonability of the model. Full article

The audible noise generated by corona discharge has the N-type characteristic at the initial generation stage, and it is a typical shock wave. This shock wave usually only exists around the corona source with a tiny range, making it difficult to obtain its characteristics through experimental measurements. An electrosound-combined simulation of the corona discharge based on the shock wave theory was conducted, and the development process involving the corona discharge, shock wave, and sound wave was simulated. First, the corona was numerically simulated based on the 2D pin–plate axisymmetric hydrodynamic model. It was found that the plasma was mainly distributed near the axis of the corona field where the electric field changed violently, and the maximum value of the electric field appeared at the head of the discharge channel. Then, the plasma energy was equivalent to the explosive energy, and a plasma explosion shock model was established. It was found that the shock wave pressure had obvious positive and negative pressure zones, and the propagation velocity decays to the sound velocity gradually. Finally, the shock wave pressure derived by the explosion model was used as the acoustic source, and the acoustic wave propagation process was simulated. The simulated sound pressure waveform had the same characteristics as the relevant experimental measurement results, proving that the developed method possessed strong applicability and gave rise to a new angle for the simulation of corona-generated audible noise. Full article

The endurance of medium- and high-voltage electrical insulation is a key reliability element in a broad spectrum of applications that cover transmission and distribution levels, the transportation segment, the industrial environment, and power electronics-based energy-conversion systems. The high electric-field stress and high-frequency switching phenomena as well as the impact of environmental conditions lead to the occurrence of partial discharges (PD) and the subsequent deterioration of electrical insulation. Partial discharges usually occur inside solid insulation materials in tiny voids that may either be located adjacent to the electrodes or in the bulk of dielectric material. This effect refers to both AC and DC systems; however, AC voltage is usually much more intensive as compared to DC voltage. This paper describes a novel combined approach based on surface-resistance and potential mapping to reveal the effects of internal processes and the deterioration of insulating material due to the actions of partial discharges. To realize the research objective, the following two-step approach was proposed. Multi-point resistance mapping enables us to identify the spots of discharge channels, manifesting a-few-orders-of-magnitude-lower surface resistance as compared to untreated areas. In addition, surface-potential mapping that was stimulated by corona-charge deposition reflects quasi-equipotential clusters and the related polarity-dependent dynamics of charge decay. A high spatial and temporal resolution allows for the precise mapping and tracing of decay patterns. Experiments were carried out on polyethylene (PE) and Nomex specimens that contained embedded voids. During PD events, the effective discharge areas are identified along with the memory effects that originate from the accumulation of surface charges. Long-term aging processes may drive the formation of channels that are initiated from the deteriorated micro clusters, in turn, penetrating the bulk isolation. The presented methodology and experimental results extend the insight into PD mechanisms and internal surface processes. Full article

The audible noise (AN) of DC transmission lines is a crucial factor affecting environmental assessment and electromagnetic design. In recent years, the public has paid increasing attention to the audible noise after the emergence of the HVDC technique. This paper emphatically reviewed the work investigating audible noise characteristics in both time and frequency domains, especially the correlation between sound and discharge. The proposed mechanisms of DC audible noise and the mitigating techniques are summarized, including the noise generation process, the physical models, the measurement method, and the mitigating technologies. It is found that the existing literature mainly focused on the prediction and characteristics of AN, the environmental factors which influence AN, and the methods to minimize AN emission. However, existing achievements still need to be improved to fully understand the mechanism of AN generation and solve the adaptability problem of AN prediction methods. The following aspects are valuable in future research: The correlation between audible noise and other corona effects will help solve the problem of difficulty in measuring audible noise in field condition; The corona discharge mechanism and weather resistance anti-corona coating when raindrops are attached to the surface of the transmission line, which will help guide the development and application of anti-corona coatings for the transmission line. Future research should also understand the mechanism of sound wave generation when considering the space charge effect. Full article

In the design of MV AC and DC spacers, the predominant factors are surface and interface conditions. Design is generally carried out on specifications and standards which are based on long-term experience and lab testing. However, the diffusion of power electronics with a trend to increase electric field, switching frequency, and rise time to achieve higher power density calls for an innovative, global approach to optimized insulation system design. A new methodology, based on field simulation, discharge modeling, and partial discharge inception measurements, called the three-leg approach, can form the basis to optimize insulation design for any type of supply voltage waveform. This paper focuses on the influence of the type of electrode on the inception and phenomenology of surface discharges and, as a consequence, on the interpretation of the results used for application of the three-leg approach. It is demonstrated that a typical electrode system used for insulating material testing can generate both gas and surface discharges at the triple point, when the electrodes have a smooth profile that is used to avoid corona or flashover. Hence, testing partial discharge may not provide a straightforward indication of the surface discharge inception and, thus, be partially misleading for insulation design. Another takeover is that such analysis must benefit from PD testing tools endowed with analytics able to provide automatic identification of the type of defect generating PD, i.e., internal, surface, and corona, since design and remedy actions can be taken, and adequate insulating materials developed, only knowing the type of source generating PD. Hence, testing partial discharge may not provide a straightforward indication of surface discharge inception and, thus, be partially misleading for insulation design. In addition to the importance of the three-leg approach to favor reliable and optimized design of insulation systems, there is a clear need to have a PD testing tool endowed with analytics. It should preferably be able to provide automatic identification of the type of defect generating PD, i.e., internal, surface, and corona. Full article

Charged droplets driven by Coulomb force are an important part of a droplet-based micro reactor. In this study, we realized the rapid oscillatory motion of droplets both in oil and on superhydrophobic surface by injecting charges through corona discharge. Distinct from the oscillatory motion of water droplets under a DC electric field, charge injection can make the motion of water droplets more flexible. A droplet in the oil layer can move up and down regularly under the action of corona discharge, and the discharge voltage can control the movement period and height of the droplet. In addition, the left–right translation of droplets on a superhydrophobic surface can be achieved by injecting charges into the hydrophobic film surface through corona discharge. Two kinds of droplet motion behaviors are systematically analyzed, and the mechanism of droplet motion is explained. The present results could help establish new approaches to designing efficient machines in microfluidics and micromechanical equipment. Full article
