Search Results (33)

Pump-turbines are critical for maintaining power grid stability, but they frequently suffer from flow instabilities induced by cavitation due to frequent operating condition changes. This study employs numerical simulations to systematically analyze the internal flow characteristics and changes in runner forces within a model pump-turbine under varying guide vane openings and cavitation coefficients. Results indicate that, under low opening conditions, a spiral vortex rope forms within the draft tube, inducing significant low-frequency pressure fluctuations. As cavitation intensifies, the vortex rope undergoes substantial expansion. At guide vane openings of 30.6 degrees and 37.3 degrees, the draft tube vortex rope exhibits a straight conical shape, with its dimensions increasing as flow rate rises. Additionally, the radial force on the runner is dominated by low-frequency fluctuations generated by the draft tube at low opening conditions, shifting to high-frequency characteristics caused by rotor–stator interaction at high opening conditions. Meanwhile, the expansion and contraction of the cavity volume induce low-frequency fluctuations in the axial force on the runner. These findings reveal the mechanism of vortex rope evolution on runner forces, emphasizing the impact of cavitation on the flow characteristics and force characteristics of the unit. Full article

We theoretically investigate the influence of uniaxial distortion on the stability of square skyrmion crystals, which are described as double-Q spin textures composed of two orthogonal spiral modulations, in noncentrosymmetric magnets. An effective spin model incorporating momentum-resolved frustrated exchange interactions and Dzyaloshinskii–Moriya (DM) interactions is analyzed using simulated-annealing calculations at low temperatures. The results reveal that uniaxial distortion drives a transformation from the double-Q square skyrmion crystal to a single-Q tilted conical spiral or vertical spiral state. The low-temperature phase diagrams further show that the stability region of the skyrmion crystal expands with increasing the magnitude of the DM interaction, making the phase more robust against the uniaxial anisotropy between exchange interactions parallel and perpendicular to the distortion axis. This study provides insight into how uniaxial strain and DM interactions cooperatively influence the formation and stability of skyrmion crystal phases in noncentrosymmetric magnetic systems. Full article

This study investigates an inlet design for a gravitational vortex turbine (GVT), drawing inspiration from the ancient Nazca puquios. The puquios are ingenious subterranean aqueducts constructed by the Nazca culture (c. 100 BC–800 AD) in southern Peru, featuring spiral ojos de agua (water eyes) used to access groundwater and stabilize flow.The primary objective was to enhance vortex stability and overall GVT efficiency under low-head, low-flow operating conditions. A parametric Nazca-type inlet feeding a conical basin was defined by two controlling factors: the number of turns (N) and the inclination angle ($\theta$). The optimal geometry was determined through a $3^2$ full factorial design, computational fluid dynamics (CFD) simulations, and response surface methodology (RSM), with vortex circulation $(\Gamma )$ serving as the optimization metric. The best-performing inlet configuration ($N=4$, $\theta ={13}^{\circ }$) yielded $\Gamma =1.3459$ m²/s. This circulation level is comparable to that reported for optimized conventional wrap-around inlets at similar flow rates, but uniquely produced a broader and more symmetric vortex structure. Subsequently, two four-bladed runners (one with twisted blades and one with curved cross-flow blades) were evaluated numerically and experimentally using a laboratory-scale prototype operated at a consistent flow rate ($Q\approx 0.00143$ m³/s). CFD predicted maximum efficiencies of $15.37\%$ and $17.07\%$ for the twisted and curved runners, respectively, while experimental tests achieved $8.70\%$ and $11.61\%$, demonstrating similar efficiency ($\eta$) versus angular velocity ($\omega )$ characteristics. These results indicate reduced hydraulic effectiveness of the Nazca-inspired geometry for the GVT, with experimental efficiencies below those reported in the literature. Full article

In Building Information Modeling (BIM) of bridge piers, persistent limitations have been observed in the modeling of spiral hoop rebar with variable pitch and diameter. Taking Revit as an example, its built-in family files can only generate spirals with constant geometry. When dealing with non-uniform rebar, designers often have to rely on segmented modeling or manual operations, which is not only time-consuming but also prone to deviations. To solve this problem, this paper proposes a parameterized modeling method based on the secondary development of Revit. By combining the Revit API with the C# programming language, the spiral equation is embedded into the Non-Uniform Rational B-Spline (NURBS) curve reconstruction framework, realizing the continuous modeling of spiral hoop rebar in a unified model. This method also allows users to flexibly input parameters such as cover thickness, rebar diameter, and segment length through a graphical user interface. Through comparative experiments, the proposed method and the traditional family file modeling method were verified respectively in the modeling of a single column and an entire bridge pier. The results indicate that the proposed method reduces the average modeling time of a single bridge pier by 66.5% and that of the entire project by 48.7%. While maintaining high geometric accuracy, this method significantly shortens modeling time and reduces workload, especially demonstrating higher consistency in pitch transition sections and conical sections. Beyond technical performance, this study also demonstrates that the secondary development of Revit provides a practical and feasible solution for the efficient, precise, and generalizable modeling of complex reinforcing bar components in terms of expanding BIM functions, which holds significant practical implications. Full article

We theoretically investigate the stability of double-Q square skyrmion crystals under uniaxial distortion. Using an effective spin model with frustrated exchange interactions and bond-dependent anisotropy in momentum space, we construct the low-temperature magnetic phase diagram via simulated annealing. Our results reveal that uniaxial distortion drives a phase transition from the skyrmion crystal to a single-Q conical spiral state when the ratio of exchange interactions parallel and perpendicular to the uniaxial axis is reduced to about 95%. We further find that topologically trivial double-Q states, which emerge in the low- and high-field regimes, are more robust against uniaxial distortion than the skyrmion crystal appearing in the intermediate-field regime. Finally, we examine the role of bond-dependent anisotropy and demonstrate that a finite relative magnitude of this anisotropy is crucial for stabilizing the skyrmion crystal, even under uniaxial distortion. These findings highlight the delicate interplay between lattice distortions and bond-dependent interactions in determining the stability of multiple-Q magnetic textures, and they provide useful guidance for experimental efforts to manipulate skyrmion crystal phases in centrosymmetric magnets. Full article

Multiple-Q magnetic states encompass a broad class of noncollinear and noncoplanar spin textures generated by the superposition of spin density waves. In this study, we theoretically explore the emergence of vortex crystals formed by multiple-Q spin density waves on a two-dimensional triangular lattice with $D_{3\mathrm{h}}$ point group symmetry. Using simulated annealing applied to an effective spin model, we demonstrate that the synergy among the easy-plane single-ion anisotropy, the biquadratic interaction, and the out-of-plane Dzyaloshinsky–Moriya interaction defined in momentum space can give rise to a variety of double-Q and triple-Q vortex crystals. We further examine the role of easy-plane single-ion anisotropy in triple-Q vortex crystals and show that weakening the anisotropy drives topological transitions into skyrmion crystals with skyrmion numbers $\pm 1$ and $\pm 2$. The influence of an external magnetic field is also analyzed, revealing a field-induced phase transition from vortex crystals to single-Q conical spirals. These findings highlight the crucial role of out-of-plane Dzyaloshinskii–Moriya interactions in stabilizing unconventional vortex crystals, which cannot be realized in systems with purely polar or chiral symmetries. Full article

The increasing demand for on-orbit servicing (OOS), such as satellite life extension and space debris removal, has highlighted the need for research into precise relative navigation between space objects. Model-based tracking (MBT) was applied using the imaging data for relative navigation, incorporating SPNv2 (Spacecraft Pose Network v2) for an initial pose estimation. Furthermore, the performance of General Loss was evaluated by applying it during the model tracking processes and comparing it with seven other robust M-estimators, including Tukey, Welsch, and Huber. The simulations were conducted in a ROS–Gazebo environment that emulated a rendezvous with the International Space Station (ISS). Six approach profiles were generated by pairing three mutually different conic-section apertures with two attitude modes—boresight locked on the ISS versus boresight fixed on the inertial origin—producing six distinct spiral trajectories that bring the chaser from 500 m to 100 m along the depth axis of the camera. General Loss achieved superior estimation accuracy in most profiles. Thus, the proposed algorithm, which integrates General Loss into the MBT-based relative navigation framework, provides robust and stable performance in the presence of diverse residual distributions and outliers. In the few instances where it did not yield the very best results, the initial error arose from matching virtual edges—generated according to the sample weight distribution—to the actual edges in the image frame; notably, by the end of the simulation, when the camera reached a depth of approximately 100 m, these errors were substantially reduced. Thus, the proposed algorithm, which integrates General Loss into the MBT-based relative navigation framework, provides robust and stable performance in the presence of diverse residual distributions and outliers. Full article

We present the design and manufacturing of a deployable conical log spiral spring antenna for small spacecraft, along with a test campaign to evaluate its suitability for space applications. The conical spring was 45.7 cm in height, with base and apex diameters of 18.9 and 2.8 cm, respectively. The spring had a mass of 0.138 kg and was constructed from a carbon fiber-infused epoxy matrix with an embedded coaxial cable. We conducted dynamic and thermal mechanical analysis to determine the coefficient of thermal expansion and glass transition temperature. The initial 10 compressions of the spring shortened the structure’s overall height, but the change had a negligible effect on the antenna’s radio frequency (RF) performance. Thermal cycling between −70 °C and 80 °C did not cause any damage or deformation to the spring structure. Outgassing tests were conducted in a thermal vacuum chamber, and the total mass loss was 0.03%. We conducted vibration tests representative for a typical launch vehicle, and all natural frequencies remained stable above 250 Hz, while the antenna was stowed, satisfying launch vehicle requirements. Post-test functional checks confirmed that there was no change in antenna functionality. The environmental test results provide confidence that the antenna is suitable for spacecraft applications. Full article

An ultra-high-frequency (UHF) deployable conical log spiral antenna’s design and experimental test results are presented. The antenna is a spring constructed from a carbon-fiber-infused epoxy matrix. The spring design simplified the spacecraft deployment mechanism, and the use of composite materials allowed for the integration of radiating elements into the spring structure. A Chebyshev transformer at the base of the antenna is used to match the incoming transmission line impedance to a 95 $\mathrm{\Omega }$ coaxial cable. The 95 $\mathrm{\Omega }$ coaxial, which is the balun and the radiating element, is embedded into the antenna structure. The antenna is fed at the cone’s base without requiring a ground plane whilst maintaining radiation in the cone’s apex-pointing direction. This facilitated an uncomplicated deployment mechanism. Prototypes have been manufactured for 500 to 1500 MHz designs. Antenna measurements show a realized gain of between approximately 3 to 6 dBi from 500 to 1500 MHz. Full article

Computer modelling of technical constructions is increasingly carried out using software that includes more detailed knowledge, which requires an increase in the level as well as an expansion of the scope of the geometric knowledge. A significant part of motion transmission mechanisms are worm drive pairs, for which the separation of the parts dealing with the theoretical and practical problems found in the literature can be experienced in numerous instances. Due to the different technical features, in many cases the helical surfaces are not designed and manufactured in a geometrically correct way, or the best solution is not the compulsory chosen. The geometric model describing the production process of the worm surfaces provides the basis for examining the deviation between the surface mathematically determined by the designer and the surface produced. An integrated mathematical kinematic model was developed for the production geometrical analysis of the elements of cylindrical and conical worm gear drive pairs for machining with a traditional thread grinding machine, which causes a serious pitch fluctuating error among several other problems in the case of machining the conical worm. Modelling of the production process of surfaces and the simultaneous study of the manufacturing errors is basically performed with the toolbox of descriptive geometry, including the use of the projective invariants. Knowing the inheritance of the invariants of projective geometry, the aim was the mathematical generalization of the integrated model and the creation of a projective relationship between the reference surfaces of conical and cylindrical spiral surfaces. As a result, the improved constructive geometric model was created, in which the method of analytically creating the projective geometric relationship between the reference surfaces of conical and cylindrical helicoid surfaces has been described for the first time in this article. This procedure is considered the most important result of the present article. Another significance of the further development presented is that during production of the conical helicoid surface, the thread pitch fluctuation has been eliminated. The results obtained, consisting of an improved geometric model, lead to a new geometry of the technological environment regarding the relative position of the cutting tool and the workpiece as well as the relative motion between them. Full article

Gravitational vortex turbines can provide a sustainable and efficient solution for generating renewable energy from small watercourses, minimizing environmental impact, and contributing to the decentralization of energy production. Their design allows for high energy efficiency even under low flow conditions, thus benefiting rural communities and reducing their dependence on fossil fuels. This paper presents an experimental assessment of the hydrodynamic behavior of gravitational vortex turbines by examining various geometric configurations. The combinations of two types of inlet channels (spiral and tangential) and two types of discharge basins (conical and cylindrical) were investigated. Additionally, different geometries and placements of the runners were evaluated to determine their influence on the efficiency and performance of the turbine. The results indicate that the highest efficiency of 60.85% was achieved with a configuration that included a spiral inlet channel, cylindrical discharge, and a runner placement of 50%. Full article

Topological defects are a key concern in numerous branches of physics. It is meaningful to exploit the topological defect evolutions during the phase transitions of condensed matter. Here, via varying the initial azimuthal orientation of the square alignment lattice in a hybrid cell, the topological defect evolution of liquid crystal during the nematic (N)–smectic A (SmA) phase transition is investigated. The director fields surrounding ±1 point defects are manipulated by predesigning the initial azimuthal orientation. When further cooled to the SmA phase, spiral toric focal conic domain (TFCD) arrays are formed as a result of twisted deformation suppression and unique symmetry breaking after the phase transition. The variation in the azimuthal orientation causes the TFCDs to degenerate from infinite rotational symmetry to quadruple rotational symmetry, thus releasing new textures for the SmA phase. Landau–de Gennes numerical modeling is adopted to reproduce the director distributions in the N phase and reveal the evolution of the topological defects. This work enriches the knowledge on the self-organization of soft matter, enhances the capability for the manipulations of topological defects, and may inspire new intriguing applications. Full article

Current liquid crystal (LC) lenses cannot achieve lossless arbitrary movement of the optical axis without mechanical movement. This article designs a novel bottom electrode through simulation and optimization, which forms a special LC lens with an Archimedean spiral electrode, realizing a 3D LC wedge and an arbitrarily movable LC lens. When only the bottom electrode is controlled, it achieves a maximum beam steering angle of 0.164°, which is nearly an order of magnitude larger than the current design. When the top and bottom electrodes are controlled jointly, a 0.164° movement of the lens optical axis is achieved. With focal length varies, the movement of the optical axis ranges from zero to infinity, and the lens surface remains unchanged during movement. The focus can move in a 3D conical area. When the thickness of the LC layer is 30 μm, the fastest response time reaches only 0.635 s, much faster than now. Full article

This study centered around the practical problem that there is no machine available for deep planting with large holes in hilly and mountainous areas of China. According to the principle of spiral lifting, a conical, double-spiral hole-forming machine was innovatively designed. The structural design and parameter calculation were completed. By discrete-element-method (DEM) simulation, the optimal lead and rotation speed of the hole former were obtained, and the hole-forming mechanisms of soil cutting, soil lifting, soil discharging, soil extruding, and soil returning were further revealed. The field test results indicated that the prototype had the advantages of convenient operation and good performance, and the formed holes met the agronomic requirements, with a qualification rate of 88.5%. In addition, it was found that the soil moisture content has a great influence on the formation of holes. Under the condition of low moisture content, the residence time at the bottom of a hole should be appropriately increased to improve the qualification rate of the holes formed. Our research results provided theoretical guidance and technical support for the design, optimization, popularization, and application of a hole-forming machine for deep planting with large holes (DPLH). Full article

Martian rocks contain crucial information about the genesis of Mars and the historical evolution of Martian climate change. Consequently, extracting and examining Martian rocks are pivotal in advancing our comprehensive understanding of the red planet. However, the current core drill string is prone to wear and tear, and the samples are susceptible to thermal denaturation. To address these challenges, we introduce two novel types of drill bits, the conical straight junk slot and the conical spiral junk slot, both employing impregnated diamond as the primary material. Comparative experiments were meticulously conducted to evaluate the influence of different junk configurations on drilling parameters, including speed, abrasion resistance, drilling force loading, and sample temperature rise. The findings unequivocally demonstrate the superior performance of the spiral junk slot. Furthermore, simulations were performed to examine the drilling process on basalt using a fixed configuration drill bit, validating the occurrence of the sample temperature rise. The research presented in this paper offers valuable programmatic references and essential data support for future Martian rock coring drilling missions. Full article
