During the in-orbit operation of spacecraft, permanent magnet synchronous motors are commonly used as power sources in the drive mechanisms of solar panel arrays and the high-precision servo control systems based on satellites. Apart from the performance of the motors themselves and the software control algorithms, the accuracy of the entire control system is also influenced by angle sensors used to detect the rotor position of the motors. As a high-precision angular measuring instrument, the inductosyn possesses excellent environmental adaptability and long service life. Effectively utilizing the inductosyn can greatly enhance the performance of servo control systems. To address the complexity of the decoding process for dual-channel round inductosyn-to-digital converters, this paper proposes a design of the decoding circuit for dual-channel round inductosyn based on the parallel-synchronization decoding method of two AD2S1210 Resolver-to-Digital Converter (RDC) decoding chips. The decoding circuit amplifies the excitation signal outputted by the AD2S1210 for driving the round inductosyn, and processes the sine and cosine induction signals outputted by the round inductosyn through filtering, amplification, and other methods; by using analog circuitry, the output signals of the dual-channel round inductosyn are processed to meet the input requirements of the AD2S1210. Finally, through both the Multisim (circuit simulation software Version 14.1) simulation and physical experiments, it was verified that the decoding circuit designed in this paper could process the input/output signals of the dual-channel round inductosyn and AD2S1210, and successfully decoded the analog induction signal of the round inductosyn. This greatly simplifies the signal decoding process for the dual-channel round inductosyn. Full article

Low-frequency harmonic interference is an important factor that affects the performance of low-speed direct-drive servo systems. In order to improve the low-speed smoothness of direct-drive servo, firstly, the causes of the first and second harmonics of electromagnetic torque and tooth harmonics are analyzed based on the mathematical model of PMSM (permanent magnet synchronous motor) and the principle of vector control. Accordingly, the CC-EUMA (Electrical angle Update and Mechanical angle Assignment algorithm for Center Current) and SL-DQPR (Double Quasi-Proportional Resonant control algorithm for Speed Loop) algorithm are proposed. Second, to confirm the algorithm’s efficacy, the harmonic environment is simulated using Matlab/Simulink, and the built harmonic suppression module is simulated and analyzed. Then, a miniaturized, fully digital drive control system is built based on the architecture of the Zynq-7000 series chips. Finally, the proposed suppression algorithm is verified at the board level. According to the experimental results, the speed ripple decreases to roughly one-third of its initial value after the algorithm is included. This effectively delays the speed ripple’s low-speed deterioration and provides a new idea for the low-speed control of the space direct-drive servo system. Full article

To improve the Solar Array Drive Assembly (SADA) system, a servo control method known as Linear Active Disturbance Rejection Control (LADRC) is introduced, utilizing a speed loop for a Permanent Magnet Synchronous Motor (PMSM). This method serves as an alternative to the conventional proportional–integral (PI) controller, which exhibits a limited stability margin. The use of the LADRC controller leads to decreased overshoot and enhances the system’s robustness against disturbances. First, the mathematical representation of the PMSM alongside the dynamic model of the solar wing is established. Following that, the application of the Lyapunov stability theory is employed to illustrate the stability of the drive system utilizing LADRC, thereby validating the stability of the SADA. Lastly, simulation experiments are performed using the MATLAB2021a/Simulink digital environment. The simulation results under various operational conditions indicate the significant improvement in stability compared to the PI controller, achieving the stability level of $9.603\times {10}^{-5}$, demonstrates enhanced performance in terms of speed and resistance to disturbances. Full article

The paper relates to the development of an algorithm applicable for maintaining the rotational speed of low-speed drives using PMSM motors and operating under a sign-changing load. The moment of inertia of rotating parts does not play the role of a mechanical stabilizer for the speeds discussed in the article. Simulation studies are presented with the aim of developing a rotational speed control algorithm that utilizes only positional feedback and the previously assumed sign-changing load on the shaft. For the purposes of this research, a mathematical model was developed to calculate transient processes in a PMSM machine operating in the conditions of a sign-changing load on the shaft. This model assumes a deterministic control principle adapted to the known nature of the load change. In this model, the mutual influence occurring between the phase fluxes, the electromagnetic torque, the electric currents and the rotor position angle are established on the basis of FEM analysis of a two-dimensional magnetic field using a quasi-stationary approximation. Principles applicable for controlling a direct low-speed servo drive based on a PMSM machine operating with a known variable shaft load using only positional feedback and a predetermined shaft load change law are defined. The proposed regulation method is verified in an experimental manner. For this purpose, an experimental setup was built, which includes a PMSM with a load imitator on a variable sign shaft, an inverter providing sine-shaped power supply to the machine and a digital dual-processor control system. The discussed rotational speed stabilization algorithm was implemented in the form of a program for a microcontroller, which forms a part of the control system. The results of experimental tests confirm the adequacy of mathematical modeling and the effectiveness of the proposed rotational speed stabilization algorithm. Full article

This paper presents an analysis of the advantages stemming from the application of field-programmable gate arrays (FPGAs) in servo drives used within the control systems of industrial numerical machine tools. The method of improving the control system that allows for increasing the precision of machining, as well as incorporating new functionalities and streamlining diagnostic processes, is described. As demonstrated, the utilization of digital controllers with robust computational power and high-performance real-time communication interfaces is essential for achieving these objectives. This study underscores the limitations of commonly employed digital controllers in servo drives, which are constructed based on microcontrollers or signal processors collaborating with application-specific integrated circuits (ASICs). In contrast, the proposed FPGA-based solution offers substantial computational power and significantly reduced latencies in the real-time communication interface compared to other examined alternatives. This enables the realization of the planned objectives, specifically the enhancement of technical parameters and diagnostic capabilities of machine tools. Furthermore, the research indicates that FPGA-based digital controllers exhibit relatively low power consumption and a simplified design of the electronic printed circuit board in comparison to other analyzed digital platforms. These features can contribute to heightened reliability and diminished production costs of such controllers. Additional conclusions drawn from the study indicate that FPGA-based controllers provide greater developmental possibilities and their production is marked by potential resilience to challenges associated with the availability of electronic components in the market. Full article

The paper presents a DSP-based design and control of a three-axis servo motion system that effectively divides control tasks between the master control terminal and four slave drives. The proposed architecture enhances the immediacy of platform positioning and the integration between software and hardware. The paper utilizes a high-accuracy encoder as a reference value for accuracy improvement and integrates firmware via the proposed embedded execution program, thereby reducing the accuracy error of the low-accuracy encoder. The main control core employs a digital signal processor (DSP) for input and output signal reading and writing, digital communication interface processing, and user interface. The slave controller utilizes four digital signal processors to accomplish servo position control in a digital way. The paper employs encoder calibration technology to upgrade the positioning accuracy of the surge axis. Finally, the paper validates the correctness and feasibility of the proposed method through experimental results from a set of adjustable experimental platforms of linear motion stroke and rotary motion stroke. In summary, the paper underscores the integration of hardware and software to attain high-precision and dependable control of the motion system. Full article

A digital twin for a multifunctional technology for flexible manufacturing on an assembly, disassembly, and repair mechatronics line (A/D/RML), assisted by a complex autonomous system (CAS), is presented in the paper. The hardware architecture consists of the A/D/RML and a six-workstation (WS) mechatronics line (ML) connected to a flexible cell (FC) and equipped with a six-degree of freedom (DOF) industrial robotic manipulator (IRM). The CAS has in its structure two driving wheels and one free wheel (2DW/1FW)-wheeled mobile robot (WMR) equipped with a 7-DOF robotic manipulator (RM). On the end effector of the RM, a mobile visual servoing system (eye-in-hand MVSS) is mounted. The multifunctionality is provided by the three actions, assembly, disassembly, and repair, while the flexibility is due to the assembly of different products. After disassembly or repair, CAS picks up the disassembled components and transports them to the appropriate storage depots for reuse. Disassembling or repairing starts after assembling, and the final assembled product fails the quality test. The virtual world that serves as the digital counterpart consists of tasks assignment, planning and synchronization of A/D/RML with integrated robotic systems, IRM, and CAS. Additionally, the virtual world includes hybrid modeling with synchronized hybrid Petri nets (SHPN), simulation of the SHPN models, modeling of the MVSS, and simulation of the trajectory-tracking sliding-mode control (TTSMC) of the CAS. The real world, as counterpart of the digital twin, consists of communication, synchronization, and control of A/D/RML and CAS. In addition, the real world includes control of the MVSS, the inverse kinematic control (IKC) of the RM and graphic user interface (GUI) for monitoring and real-time control of the whole system. The “Digital twin” approach has been designed to meet all the requirements and attributes of Industry 4.0 and beyond towards Industry 5.0, the target being a closer collaboration between the human operator and the production line. Full article

The operating efficiency of the hydraulic system depends on the response speed and driving efficiency of the hydraulic components. Seeking various methods and technologies to improve performance and work efficiency is an important work for many scholars. In this paper, the development and performance improvement of four generations of hydraulic cylinders are analyzed to obtain the development of the drag reduction technology by examples such as sealing methods, microtextured hydrodynamic lubrication, manufacturing materials, drive methods, control methods, etc. The reviewed results show that the drag reduction and efficiency improvement of hydraulic cylinders are affected by many factors, and the new drag reduction theories, advanced drag reduction technology, and emerging materials point toward the direction of the acceleration of hydraulic cylinders. Finally, according to the higher requirements for future cylinders, four new ideas are proposed for improving the speed performance of hydraulic cylinders, including new material sealing ring with low friction coefficient or self-lubricating, internal leakage suppression from smart material, implementation of servo control techniques and algorithms, and digital hydraulic technology. These new viewpoints may provide some methods and references for the speed improvement of hydraulic cylinders. Full article

Ultra-Precision Machining (UPM) is a kind of highly accurate processing technology developed to satisfy the manufacturing requirements of high-end cutting-edge products including nuclear energy producers, very large-scale integrated circuits, lasers, and aircraft. The information asymmetry phenomenon widely exists in the design and control of ultra-precision machining. It may lead to inconsistency between the designed performance and operational performance of the UPM equipment on stiffness, thermal stability, and motion accuracy, which result from its design, manufacturing, and control, and determine the form accuracy and surface roughness of machined parts. The performance of the UPM equipment should be improved continuously. It is still challenging to realize the real-time and self-adaptive control, in which building a high-fidelity and computationally efficient digital twin is a valuable solution. Nevertheless, the incorporation of the digital twin technology into the UPM design and control remains vague and sometimes contradictory. Based on a literature search in the Google Scholar database, the critical issues in the UPM design and control, and how to use the digital twin technologies to promote it, are reviewed. Firstly, the digital twins-based UPM design, including bearings module design, spindle-drive module design, stage system module design, servo module design, and clamping module design, are reviewed. Secondly, the digital twins-based UPM control studies, including voxel modeling, process planning, process monitoring, vibration control, and quality prediction, are reviewed. The key enabling technologies and research directions of digital twins-based design and control are discussed to deal with the information asymmetry phenomenon in UPM. Full article

The work describes the new architecture of a fixed-point arithmetic unit. It is based on the use of integer arithmetic operations for which the information about the scale of the processed numbers is contained in the binary code of the arithmetic instruction being executed. Therefore, this approach is different from the typical way of implementing fixed-point operations on standard processors. The presented solution is also significantly different from the one used in floating-point arithmetic, as the decision to determine the appropriate scale is made at the stage of compiling the code and not during its execution. As a result, the real-time processing of real numbers is simplified and, therefore, faster. The described method provides a better ratio of the processing efficiency to the complexity of the digital system than other methods. In particular, the advantage of using the described method in FPGA-based embedded control systems should be indicated. Experimental tests on an industrial servo-drive confirm the correctness of the described solution. Full article

This paper developed a rotatable multi-axis motion platform combined with virtual reality (VR) immersion for flight simulation purposes. The system could simulate the state of the flight operation. The platform was mainly comprised of three crank linkage mechanisms to replace an expensive six degrees of freedom (DoF) Stewart platform. Then, an independent subsystem which could rotate ±180° was installed at the center of the platform. Therefore, this platform exhibited 4-DoF movement, such as heave, roll, pitch, and yaw. In the servo motor control unit, Visual Studio C# was applied as the software to establish a motion control system to interact with the motion controller and four sets of servo motors. Ethernet Control Automation Technology (EtherCAT) was utilized to communicate the commands and orders between a PC and each servo motor. The optimum controller parameters of this system were obtained using Simulink simulation and verified by experiment. The multiple sets of servo motors and crank linkage mechanisms were synchronized with flight VR imagery. For VR imagery, the software Unity was used to design the flying digital content. The controller was used to transmit the platform’s spatial information to meet the direction of the pilot commands and to compensate the direction of the deviation in spatial coordinates. To achieve synchronized response and motion with respect to the three crank linkage mechanism platform and VR imagery on the tester’s goggle view, the relation of the spatial coordinate of VR imagery and three crank linkage mechanisms was transformed to angular displacement, speed and acceleration which were used to command the motor drive system. As soon as the position of the VR imagery changed, the computer instantly synchronized the VR imagery information to the multi-axis platform and performed multi-axis dynamic motion synchronously according to its commanded information. The testers can thus immerse in the VR image environment by watching the VR content, and obtain a flying experience. Full article

This paper presents the issue of generating motion trajectories in a digital servo drive in accordance with the PLCopen Motion Control standard. This standard does not limit the details of motion generation in the electromechanical systems, but indicates its interface and set of necessary parameters. Moreover, it is placed within a state machine, which allows the individual software elements to integrate with it seamlessly. This work discusses time-optimal point-to-point trajecto-ries, i.e., the initial and final reference speeds are zero, and they are compliant with the MC_MoveAbsolute() function defined in the PLCopen Motion Control standard. The smoothness of the resulting trajectory can be attributed to the use of a fourth order trajectory generator, which defines the bounds up to snap – the second derivative of acceleration. One of the aims of this article was to bridge the theoretical aspect of trajectory generation with the algorithms practical implementation, by the means of PLC code generation using the MATLAB/Simulink package. Full article

This project aims to develop a novel large stroke asymmetric pneumatic servo system of a hardware-in-the-loop for path tracking control under variable loads based on the MATLAB Simulink real-time system. High pressure compressed air provided by the air compressor is utilized for the pneumatic proportional servo valve to drive the large stroke asymmetric rod-less pneumatic actuator. Due to the pressure differences between two chambers, the pneumatic actuator will operate. The highly nonlinear mathematical models of the large stroke asymmetric pneumatic system were analyzed and developed. The functional approximation technique based on the sliding mode controller (FASC) is developed as a controller to solve the uncertain time-varying nonlinear system. The MATLAB Simulink real-time system was a main control unit of a hardware-in-the-loop system proposed to establish driver blocks for analog and digital I/O, a linear encoder, a CPU and a large stroke asymmetric pneumatic rod-less system. By the position sensor, the position signals of the cylinder will be measured immediately. The measured signals will be viewed as the feedback signals of the pneumatic servo system for the study of real-time positioning control and path tracking control. Finally, real-time control of a large stroke asymmetric pneumatic servo system with measuring system, a large stroke asymmetric pneumatic servo system, data acquisition system and the control strategy software will be implemented. Thus, upgrading the high position precision and the trajectory tracking performance of the large stroke asymmetric pneumatic servo system will be realized to promote the high position precision and path tracking capability. Experimental results show that fifth order paths in various strokes and the sine wave path are successfully implemented in the test rig. Also, results of variable loads under the different angle were implemented experimentally. Full article
