Search Results (38)

Search Parameters:
Keywords = lumped transmission line

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 3152 KiB
Article
Differential Phase Coupler Using Balun-Type Power Divider
by Chatrpol Pakasiri, Chung-Yu Chang and Sen Wang
Micromachines 2025, 16(5), 496; https://doi.org/10.3390/mi16050496 - 24 Apr 2025
Viewed by 260
Abstract
This paper presents a differential phase coupler design methodology in the IPD process. The coupler consists of a balun and two phase-shifter circuits. The compact balun was designed with lumped components and a common inductor. Each output of the balun circuit was connected [...] Read more.
This paper presents a differential phase coupler design methodology in the IPD process. The coupler consists of a balun and two phase-shifter circuits. The compact balun was designed with lumped components and a common inductor. Each output of the balun circuit was connected to a phase shifter with an opposite phase to make a desired output phase. In the design example, a three-port 90-degree hybrid coupler was implemented on the IPD process to operate at the 6 GHz WIFI frequency. The post-simulation showed that all reflection coefficients were below −19 dB, with an insertion loss of 1.76 dB and isolation of 20 dB. The core chip size was only 0.02λ0 × 0.018λ0. Full article
Show Figures

Figure 1

12 pages, 9780 KiB
Article
A Dual-Bandpass Frequency Selective Absorber with Wide-Angle Oblique Incidence
by Yong-Xing Che, Qiang Sun, Xue-Mei Du and Yong-Ling Ban
Materials 2025, 18(3), 473; https://doi.org/10.3390/ma18030473 - 21 Jan 2025
Viewed by 757
Abstract
This study proposes a frequency-selective absorber (FSA) with dual passbands and wide-angle oblique incidence. The design consists of a circuit analog (CA) sheet and a dual-bandpass frequency selective surface (FSS) sheet, both embedded in dielectric slabs separated by a foam spacer. The CA [...] Read more.
This study proposes a frequency-selective absorber (FSA) with dual passbands and wide-angle oblique incidence. The design consists of a circuit analog (CA) sheet and a dual-bandpass frequency selective surface (FSS) sheet, both embedded in dielectric slabs separated by a foam spacer. The CA sheet unit cell is based on a tripole loaded with multiple shorted transmission lines and lumped resistors. In this way, the performance of the CA sheet is equivalent to a resistive sheet in a low-frequency band and a transparent sheet in two high-frequency bands. By comprehensively designing the CA sheet and the dual-bandpass FSS sheet, we created an FSA structure that exhibits microwave absorption in the band from 2.6 GHz to 9.2 GHz with a reflectivity lower than −10 dB. It also possesses transmission in the 12.2–15.1 GHz and 30.6–31.5 GHz bands, with a transmittance greater than −3 dB in both. In addition, the FSA structure provides a stable transmission response of up to 60° of oblique incidence and absorption performance of up to 45° of oblique incidence in TE and TM polarization. A 400 × 400 mm flat FSA sample was fabricated, was measured, and is discussed. The experimental results are consistent with the simulation results, proving that the proposed FSA design holds great potential for applications in dual-frequency low-scattering radomes with high curvature and multi-directional electromagnetic interference suppression. Full article
(This article belongs to the Special Issue Terahertz Materials and Technologies in Materials Science)
Show Figures

Figure 1

20 pages, 11249 KiB
Article
Design and Equivalent Circuit Model Extraction of a Fractal Slot-Loaded 3–40 GHz Super Wideband Antenna
by Wasan Alamro, Boon-Chong Seet, Lulu Wang and Prabakar Parthiban
Electronics 2024, 13(22), 4380; https://doi.org/10.3390/electronics13224380 - 8 Nov 2024
Viewed by 1041
Abstract
In this paper, we present the design and equivalent circuit model (ECM) of a fractal slot-loaded super wideband (SWB) antenna for compact and high-performance applications operating in the 3–40 GHz range. The proposed antenna features a compact dimension of 40 × 35 × [...] Read more.
In this paper, we present the design and equivalent circuit model (ECM) of a fractal slot-loaded super wideband (SWB) antenna for compact and high-performance applications operating in the 3–40 GHz range. The proposed antenna features a compact dimension of 40 × 35 × 1.57 mm³, a measured bandwidth ratio of 13:1, a peak gain of 9.7 dBi, an average radiation efficiency of 94%, and a low cross-polarization level across the entire bandwidth. The presented ECM is derived using transmission line theory and incorporates the individual behavior of each constituting element of the antenna. A dual sequential optimization approach is employed to determine the optimal element values. The ECM results show good agreement with both simulated and measured results in terms of the magnitude of reflection coefficient |S11| and both real and imaginary impedances with low mean absolute percentage errors of 4.9%, 7.5%, and 7.7%, respectively, demonstrating the model’s ability to accurately predict the antenna’s performance. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

10 pages, 3422 KiB
Article
High Quality Factor Miniaturized CMOS Transmission Lines Using Cascaded T-Networks for 60 GHz Millimeter Wave Applications
by Adel Barakat and Ramesh K. Pokharel
Electronics 2024, 13(18), 3748; https://doi.org/10.3390/electronics13183748 - 20 Sep 2024
Viewed by 1062
Abstract
This work presents an on-chip 60 GHz lumped element transmission line (TL) using cascaded T-networks with a high Quality factor. Each T-network consists of a series inductance with a shunt capacitance at its center. We have derived the design equations for this TL [...] Read more.
This work presents an on-chip 60 GHz lumped element transmission line (TL) using cascaded T-networks with a high Quality factor. Each T-network consists of a series inductance with a shunt capacitance at its center. We have derived the design equations for this TL configuration and proved that a TL whose electrical length ≥ 60° achieves additional miniaturization when implemented with three or more cascaded T-networks. The inductance is implemented using a straight wire model with no ground below it, while the capacitance is implemented using a parallel plate model with a grounding pedestal. Both configurations guarantee maximum inductance per unit length and capacitance per unit area to further improve the miniaturization level. A quarter wavelength TL with three cascaded T-networks is fabricated as proof of concept. The measured and simulated results of the fabricated TL have good agreement, and the measured quality factor is 17 at 60 GHz. Full article
(This article belongs to the Special Issue New Advances in Semiconductor Devices/Circuits)
Show Figures

Figure 1

15 pages, 2676 KiB
Article
Short-Circuit Current Calculation of Flexible Direct Current Transmission Lines Considering Line Distribution Parameters
by Zhuoya Wang, Liangliang Hao and Zemin Wang
Energies 2024, 17(15), 3800; https://doi.org/10.3390/en17153800 - 2 Aug 2024
Cited by 2 | Viewed by 1223
Abstract
A fault on the DC side of a flexible HVDC system, along with the rise in short-circuit current, develops rapidly. With the gradual expansion of flexible HVDC technology to large capacities and long-distance transmission and offshore transmission scenarios, the problem of short-circuit current [...] Read more.
A fault on the DC side of a flexible HVDC system, along with the rise in short-circuit current, develops rapidly. With the gradual expansion of flexible HVDC technology to large capacities and long-distance transmission and offshore transmission scenarios, the problem of short-circuit current calculation considering the characteristics of line distribution parameters needs urgent attention. Therefore, in order to solve the problem of the inaccurate calculation of the short-circuit current on the DC side, the lumped parameter model is used in a flexible DC system for long-distance transmission. This study analyzes the transmission line structure on the basis of the general model of the MMC short-circuit current calculation on the DC side and establishes a mathematical model of a long-distance transmission line considering the characteristics of distributed parameters. Two impedance equivalent models for different length lines are proposed to facilitate the analytical calculation of the short-circuit current. A short-circuit current calculation method for a flexible HVDC system with long-distance transmission lines is proposed. Additionally, the correctness of the proposed method is verified through the comparison of the simulation values and calculation values. The results show that the error of the lumped parameter calculation is about 10%, and the error of the distributed parameter calculation is less than 2%. Full article
(This article belongs to the Section F1: Electrical Power System)
Show Figures

Figure 1

9 pages, 1635 KiB
Communication
Compact Absorptive Microstrip Bandpass Filter with Adjustable Bandwidth and Phase
by Lei Li, Zhongxiang Shen and Wen Wu
Electronics 2024, 13(15), 3037; https://doi.org/10.3390/electronics13153037 - 1 Aug 2024
Cited by 1 | Viewed by 1006
Abstract
In this communication, a compact absorptive bandpass filter (ABPF) characterized by adjustable bandwidth and phase, low group delay (GD), a high absorptive ratio and low insertion loss (IL) is proposed. The presented ABPF consists of a bandpass section that is made of a [...] Read more.
In this communication, a compact absorptive bandpass filter (ABPF) characterized by adjustable bandwidth and phase, low group delay (GD), a high absorptive ratio and low insertion loss (IL) is proposed. The presented ABPF consists of a bandpass section that is made of a quarter-wavelength coupled line and four stubs that are basically a lumped resistor in series with a short-circuited quarter-wavelength transmission line. The stubs not only perform the function of absorption but also have the advantage of adjustable bandwidth and phase. To verify the design concept and analysis formulas, an ABPF operating at 2.4 GHz is fabricated and measured; its simulated and measured results are in good agreement. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

17 pages, 2138 KiB
Article
Band-Stop Frequency-Selective Surface (FSS) with Elliptic Response Designed by the Extracted Pole Technique
by José R. Montejo-Garai, Juan E. Page, Gerardo Perez-Palomino and Robert Guirado
Sensors 2024, 24(14), 4452; https://doi.org/10.3390/s24144452 - 10 Jul 2024
Cited by 1 | Viewed by 1789
Abstract
This paper describes and validates an advanced synthesis design process of Frequency-Selective Surfaces (FSSs) with elliptic band-stop responses. A systematic procedure based on the Generalized Chebyshev Function and the extracted pole technique enables control of the position of the transmission zeros and the [...] Read more.
This paper describes and validates an advanced synthesis design process of Frequency-Selective Surfaces (FSSs) with elliptic band-stop responses. A systematic procedure based on the Generalized Chebyshev Function and the extracted pole technique enables control of the position of the transmission zeros and the attenuation level to obtain an equiripple rejection response. A systematic process is followed to obtain the lumped LC values of the resonator circuits extracted as poles and the impedance inverters. Then, equivalent dipoles and transmission lines are obtained to carry out the electromagnetic design at normal incidence for a linearly polarized field. The impact of the higher-order modes of the periodic structure on the electrical response of the FSS, which can be relevant due to the stringent selected specifications, has been also analyzed. A fourth-order band-stop filter with a 3 GHz bandwidth centered at 30 GHz and its attenuation at 50 dB has been designed considering three different implementations: two filters using a vacuum as a transmission line with different connection lengths and a third one using a dielectric substrate to enable its manufacturing. In order to verify the design procedure using experimental results, the third filter with printed dipoles in the dielectric substrate has been manufactured and measured, thus validating the developed process. Full article
(This article belongs to the Section Communications)
Show Figures

Figure 1

22 pages, 8080 KiB
Article
A Cross-Process Signal Integrity Analysis (CPSIA) Method and Design Optimization for Wafer-on-Wafer Stacked DRAM
by Xiping Jiang, Xuerong Jia, Song Wang, Yixin Guo, Fuzhi Guo, Xiaodong Long, Li Geng, Jianguo Yang and Ming Liu
Micromachines 2024, 15(5), 557; https://doi.org/10.3390/mi15050557 - 23 Apr 2024
Cited by 2 | Viewed by 2325
Abstract
A multi-layer stacked Dynamic Random Access Memory (DRAM) platform is introduced to address the memory wall issue. This platform features high-density vertical interconnects established between DRAM units for high-capacity memory and logic units for computation, utilizing Wafer-on-Wafer (WoW) hybrid bonding and mini Through-Silicon [...] Read more.
A multi-layer stacked Dynamic Random Access Memory (DRAM) platform is introduced to address the memory wall issue. This platform features high-density vertical interconnects established between DRAM units for high-capacity memory and logic units for computation, utilizing Wafer-on-Wafer (WoW) hybrid bonding and mini Through-Silicon Via (TSV) technologies. This 3DIC architecture includes commercial DRAM, logic, and 3DIC manufacturing processes. Their design documents typically come from different foundries, presenting challenges for signal integrity design and analysis. This paper establishes a lumped circuit based on 3DIC physical structure and calculates all values of the lumped elements in the circuit model with the transmission line model. A Cross-Process Signal Integrity Analysis (CPSIA) method is introduced, which integrates three different manufacturing processes by modeling vertical stacking cells and connecting DRAM and logic netlists in one simulation environment. In combination with the dedicated buffer driving method, the CPSIA method is used to analyze 3DIC impacts. Simulation results show that the timing uncertainty introduced by 3DIC crosstalk ranges from 31 ps to 62 ps. This analysis result explains the stable slight variation in the maximum frequency observed in vertically stacked memory arrays from different DRAM layers in the physical testing results, demonstrating the effectiveness of this CPSIA method. Full article
(This article belongs to the Special Issue Latest Advancements in Semiconductor Materials, Devices, and Systems)
Show Figures

Figure 1

14 pages, 4599 KiB
Article
New Complementary Resonator for Permittivity- and Thickness-Based Dielectric Characterization
by Tanveerul Haq and Slawomir Koziel
Sensors 2023, 23(22), 9138; https://doi.org/10.3390/s23229138 - 12 Nov 2023
Cited by 4 | Viewed by 1959
Abstract
The design of high-performance complementary meta-resonators for microwave sensors featuring high sensitivity and consistent evaluation of dielectric materials is challenging. This paper presents the design and implementation of a novel complementary resonator with high sensitivity for dielectric substrate characterization based on permittivity and [...] Read more.
The design of high-performance complementary meta-resonators for microwave sensors featuring high sensitivity and consistent evaluation of dielectric materials is challenging. This paper presents the design and implementation of a novel complementary resonator with high sensitivity for dielectric substrate characterization based on permittivity and thickness. A complementary crossed arrow resonator (CCAR) is proposed and integrated with a fifty-ohm microstrip transmission line. The CCAR’s distinct geometry, which consists of crossed arrow-shaped components, allows for the implementation of a resonator with exceptional sensitivity to changes in permittivity and thickness of the material under test (MUT). The CCAR’s geometrical parameters are optimized to resonate at 15 GHz. The CCAR sensor’s working principle is explained using a lumped-element equivalent circuit. The optimized CCAR sensor is fabricated using an LPKF protolaser on a 0.762-mm thick dielectric substrate AD250C. The MUTs with dielectric permittivity ranging from 2.5 to 10.2 and thickness ranging from 0.5 mm to 1.9 mm are used to investigate the properties and calibrate the proposed CCAR sensor. A two-dimensional calibration surface is developed using an inverse regression modelling approach to ensure precise and reliable measurements. The proposed CCAR sensor is distinguished by its high sensitivity of 5.74%, low fabrication cost, and enhanced performance compared to state-of-the-art designs, making it a versatile instrument for dielectric characterization. Full article
Show Figures

Figure 1

14 pages, 2933 KiB
Article
A Novel Compact Gysel Power Divider with Bandpass Filtering Responses
by Zeyu Wu, Zihao Chen and Kaixu Wang
Electronics 2023, 12(17), 3578; https://doi.org/10.3390/electronics12173578 - 24 Aug 2023
Cited by 1 | Viewed by 1667
Abstract
This study presents a novel compact design of the Gysel topology and a filtering power divider (FPD) that utilizes a coupling structure. The proposed design replaces the traditional four-quarter wavelength transmission lines of the Gysel power divider with transmission lines and lumped components, [...] Read more.
This study presents a novel compact design of the Gysel topology and a filtering power divider (FPD) that utilizes a coupling structure. The proposed design replaces the traditional four-quarter wavelength transmission lines of the Gysel power divider with transmission lines and lumped components, resulting in a significantly reduced circuit size. Furthermore, the introduction of this coupling structure ensures the integration of the filtering and power division functions. Two transmission zeros are created near the passband to enhance the frequency selectivity of the responses. Theoretical analysis is carried out, and closed-form equations are derived based on the even–odd-mode method. To validate the theory, a three-port equal Gysel FPD operating at 2 GHz was designed and fabricated. The simulated and measured results demonstrate that this FPD has good power splitting and filtering capability with the size of 0.15 λg × 0.25 λg (λg is the medium wavelength of the central frequency), which is a significant reduction compared to the existing Gysel FPDs. The simulated and measured results are presented to verify the theoretical derivation, demonstrating good features, such as a return loss greater than 15 dB, isolation greater than 15 dB, and an insertion loss of about 4.02 dB (3 + 1.02 dB) in the passband. Full article
(This article belongs to the Special Issue Microwave Devices: Analysis, Design, and Application)
Show Figures

Figure 1

10 pages, 9901 KiB
Communication
Identifying and Modeling Resonance-Related Fluctuations on the Experimental Characteristic Impedance for PCB and On-Chip Transmission Lines
by Yojanes Rodríguez-Velásquez, Reydezel Torres-Torres and Roberto Murphy-Arteaga
Electronics 2023, 12(13), 2994; https://doi.org/10.3390/electronics12132994 - 7 Jul 2023
Cited by 1 | Viewed by 1807
Abstract
It is well known that the fluctuations in experimentally obtained characteristic impedance versus frequency curves are associated with resonances originated by standing waves bouncing back and forth between the transitions at the transmission line terminations. In fact, microwave engineers are aware of the [...] Read more.
It is well known that the fluctuations in experimentally obtained characteristic impedance versus frequency curves are associated with resonances originated by standing waves bouncing back and forth between the transitions at the transmission line terminations. In fact, microwave engineers are aware of the difficulty to completely remove the parasitic effect of these transitions, which makes obtaining smooth and physically expected frequency-dependent curves for the characteristic impedance a tough task. Here, we point out for the first time that these curves exhibit additional fluctuations within the microwave range due to standing waves taking place within the transition itself. Experimental verification of this fact was carried out by extracting this fundamental parameter from measurements performed on on-chip and printed circuit board (PCB) lines using probe pad adapters and coaxial connectors. We demonstrate that the lumped circuit approach to represent the transitions lacks validity when the additional fluctuations due to the connectors become apparent, and we propose a new model including transmission line effects within the transition. Full article
Show Figures

Figure 1

18 pages, 7017 KiB
Article
Intercoupling of Cascaded Metasurfaces for Broadband Spectral Scalability
by Shaolin Zhou, Liang Liu, Qinling Deng, Shaowei Liao, Quan Xue and Mansun Chan
Materials 2023, 16(5), 2013; https://doi.org/10.3390/ma16052013 - 28 Feb 2023
Cited by 3 | Viewed by 2499
Abstract
Electromagnetic metasurfaces have been intensively used as ultra-compact and easy-to-integrate platforms for versatile wave manipulations from optical to terahertz (THz) and millimeter wave (MMW) ranges. In this paper, the less investigated effects of the interlayer coupling of multiple metasurfaces cascaded in parallel are [...] Read more.
Electromagnetic metasurfaces have been intensively used as ultra-compact and easy-to-integrate platforms for versatile wave manipulations from optical to terahertz (THz) and millimeter wave (MMW) ranges. In this paper, the less investigated effects of the interlayer coupling of multiple metasurfaces cascaded in parallel are intensively exploited and leveraged for scalable broadband spectral regulations. The hybridized resonant modes of cascaded metasurfaces with interlayer couplings are well interpreted and simply modeled by the transmission line lumped equivalent circuits, which are used in return to guide the design of the tunable spectral response. In particular, the interlayer gaps and other parameters of double or triple metasurfaces are deliberately leveraged to tune the inter-couplings for as-required spectral properties, i.e., the bandwidth scaling and central frequency shift. As a proof of concept, the scalable broadband transmissive spectra are demonstrated in the millimeter wave (MMW) range by cascading multilayers of metasurfaces sandwiched together in parallel with low-loss dielectrics (Rogers 3003). Finally, both the numerical and experimental results confirm the effectiveness of our cascaded model of multiple metasurfaces for broadband spectral tuning from a narrow band centered at 50 GHz to a broadened range of 40~55 GHz with ideal side steepness, respectively. Full article
Show Figures

Figure 1

14 pages, 4771 KiB
Article
A 10 GHz Compact Balun with Common Inductor on CMOS Process
by Chatrpol Pakasiri, Jian-Long Xu and Sen Wang
Electronics 2023, 12(2), 468; https://doi.org/10.3390/electronics12020468 - 16 Jan 2023
Cited by 4 | Viewed by 2519
Abstract
This paper presents a compact balun with a common inductor design. The design used Wilkinson-type balun topology with modified lumped transmission lines and a common inductor to realize circuit size reduction on a lossy CMOS process. Measurements of the prototype chip had a [...] Read more.
This paper presents a compact balun with a common inductor design. The design used Wilkinson-type balun topology with modified lumped transmission lines and a common inductor to realize circuit size reduction on a lossy CMOS process. Measurements of the prototype chip had a reflection coefficient below 17.8 dB at all ports, an insertion loss of 1.98 dB, and an isolation of 16.8 dB. The chip size was only 0.025λ0 × 0.034λ0. Full article
(This article belongs to the Special Issue Microwave Subsystems and Wireless Propagation)
Show Figures

Figure 1

17 pages, 5034 KiB
Article
Modeling and Measurement of an Ultrasound Power Delivery System for Charging Implantable Devices Using an AlN-Based pMUT as Receiver
by Antonino Proto, Libor Rufer, Skandar Basrour and Marek Penhaker
Micromachines 2022, 13(12), 2127; https://doi.org/10.3390/mi13122127 - 1 Dec 2022
Cited by 15 | Viewed by 3871
Abstract
Ultrasound power delivery can be considered a convenient technique for charging implantable medical devices. In this work, an intra-body system has been modeled to characterize the phenomenon of ultrasound power transmission. The proposed system comprises a Langevin transducer as transmitter and an AlN-based [...] Read more.
Ultrasound power delivery can be considered a convenient technique for charging implantable medical devices. In this work, an intra-body system has been modeled to characterize the phenomenon of ultrasound power transmission. The proposed system comprises a Langevin transducer as transmitter and an AlN-based square piezoelectric micro-machined ultrasonic transducer as receiver. The medium layers, in which elastic waves propagate, were made by polydimethylsiloxane to mimic human tissue and stainless steel to replace the case of the implantable device. To characterize the behavior of the transducers, measurements of impedance and phase, velocity and displacement, and acoustic pressure field were carried out in the experimental activity. Then, voltage and power output were measured to analyze the performance of the ultrasound power delivery system. For a root mean square voltage input of approximately 35 V, the power density resulted in 21.6 µW cm−2. Such a result corresponds to the data obtained with simulation through a one-dimensional lumped parameter transmission line model. The methodology proposed to develop the ultrasound power delivery (UPD) system, as well as the use of non-toxic materials for the fabrication of the intra-body elements, are a valid design approach to raise awareness of using wireless power transfer techniques for charging implantable devices. Full article
(This article belongs to the Special Issue Piezoelectric Ultrasound Transducer for Biomedical Applications)
Show Figures

Figure 1

17 pages, 9306 KiB
Article
Bridging the Gap between Physical and Circuit Analysis for Variability-Aware Microwave Design: Power Amplifier Design
by Simona Donati Guerrieri, Chiara Ramella, Eva Catoggio and Fabrizio Bonani
Electronics 2022, 11(18), 2832; https://doi.org/10.3390/electronics11182832 - 8 Sep 2022
Cited by 4 | Viewed by 2106
Abstract
Process Induced Variability (PIV) stemming from fabrication tolerance can impact the performance of integrated circuits. This issue is particularly significant at high frequencies, since Monolithic Microwave Integrated Circuits (MMICs) rely on advanced semiconductor technologies exploiting device sizes at the nanoscale in conjunction with [...] Read more.
Process Induced Variability (PIV) stemming from fabrication tolerance can impact the performance of integrated circuits. This issue is particularly significant at high frequencies, since Monolithic Microwave Integrated Circuits (MMICs) rely on advanced semiconductor technologies exploiting device sizes at the nanoscale in conjunction with complex passive structures, featuring both distributed elements (transmission lines) and lumped components. Black-box (behavioral) models extracted from accurate physical simulations can be profitably exploited to incorporate PIV into circuit-level MMIC analysis. In this paper, these models are applied to the statistical analysis of a single and of a combined MMIC power amplifier designed in GaAs technology for X-band applications. The relative impact of the active device variability towards the passive matching networks one is evaluated, demonstrating the relevance of PIV. The significant spread found, with only two variable parameters, confirms the importance of a PIV-aware PA design approach, with suitable margins and careful network optimization. Full article
(This article belongs to the Special Issue Feature Papers in Circuit and Signal Processing)
Show Figures

Figure 1
