Search Results (23)

In this work, we report the evaluation of a (CuO/WO₃)-CuWO₄ heterostructured system as a methanol and acetone gas sensor in different configurations, contrasted with the pure oxides CuO and WO₃. The samples were synthesized using a modified precipitation route followed by a single thermal treatment step to induce multiphase simultaneous crystallization. The structural characterization by XRD showed that all the materials presented the formation of monoclinic CuO and WO₃ and triclinic CuWO₄. No additional phases were detected in the samples, and a reduction in the crystallite size of the CuO phase after the crystallization in the heterostructured system was observed. FE-SEM analysis made it possible to directly observe the morphology and the structures of the samples at the nanometer scale, showing a heterogeneous grain formation and supporting the formation of a heterostructure. UV-Vis DRS was used to study the optical properties of the materials, and the presence of two optical band gaps was successfully determined, which provides further evidence of heterostructure formation via this modified synthesis route. The variation in the resistance of the materials was observed in the presence of methanol and acetone vapors, where the heterostructure exhibited a substantial change in performance in the configuration with 40% copper precursor (Cu40:W60), the sample that presented the highest response as a sensor against these VOCs. To our knowledge, this is the first time that this system has been reported as a gas sensor, using the multiple configurations of the (CuO/WO₃)-CuWO₄ heterostructured system. Full article

The worldwide adoption of artificial turf in sports facilities and urban landscapes, alongside the systematic transition from natural grass and soil-based grounds, has raised growing concerns about its contribution to the significant source of nano- and microplastics in ecosystems. This review examines current knowledge on the mechanisms of nano- and microplastic generation from artificial turf systems and their environmental impacts. Combined mechanical stress, ultra-violet radiation, and weathering processes contribute to the breakdown of synthetic grass fibers and infill materials, generating particles ranging from nanometer to millimeter scales. These nano- and microplastics are detected in drainage systems and surrounding soils near sports facilities. Laboratory studies demonstrate that artificial turf-derived nano- and microplastics can adversely affect soil microbial communities, aquatic organisms, and potentially human health, through various exposure pathways. While current mitigation approaches include hybrid turf, particle retention systems, and improved maintenance protocols, emerging research focuses on developing novel, environmentally friendly materials as alternatives to conventional synthetic turf components. However, field data on emission rates and environmental fate remain limited, and standardized methods for particle characterization and quantification are lacking. This review identifies critical knowledge gaps, underscoring the need for comprehensive research on long-term ecological impacts and highlights the future goal of mitigating nano- and microplastic emissions from artificial turf systems into the ecosystem. Full article

In this work, we present a low-cost, label-free cellulose-based paper SERS (Surface-Enhanced Raman Scattering) substrate for the sensitive detection of thiol compounds. Uniform silver nanoparticles (AgNPs) were synthesized on cellulose filter paper via in situ reduction of a silver precursor under UVC irradiation, achieving a high SERS enhancement factor of 8.5 × 10⁶. The Ag-cellulose substrate demonstrated reliable detection of benzenethiol, capturing its characteristic SERS signals with remarkable sensitivity. Quantitative analysis was enabled by adjusting exposure times for accurate calibration. Furthermore, Principal Component Analysis (PCA) was successfully employed to distinguish mixed samples of benzenethiol, hexanethiol, and propanethiol, showcasing the substrate’s capability in separating complex mixtures. This cellulose-based AgNP platform offers a sustainable, cost-effective solution for rapid chemical detection, with significant potential for real-world applications such as environmental monitoring and food safety. Full article

This study investigates the dislocation density in ceramics processed by severe plastic deformation at room and elevated temperatures via high-pressure torsion (HPT) for various numbers of turns and shear strains. Ceramics, characterized by ionic or covalent bonding, typically exhibit brittleness due to limited dislocation activity. However, HPT enables significant microstructural transformations in ceramics including dislocation nucleation and accumulation. Despite recent advances in the visualization of such dislocations by transmission electron microscopy (TEM), there is a lack of comprehensive reports on the quantification of dislocation density in severely deformed ceramics. This paper addresses this gap by employing X-ray diffraction (XRD) analysis to quantify dislocation density and crystallite size in a few oxide ceramics. Results demonstrate that HPT induces exceptionally high dislocation densities comparable to theoretical upper limits of dislocation density in ceramics, on the order of 10¹⁵ to 10¹⁶ m⁻², with crystallite sizes reduced to the nanometer scale. These findings significantly enhance the understanding of dislocation behavior in ceramics and suggest a potential approach for tuning the mechanical and functional properties of these materials by dislocations. Full article

Contact scaling is a major challenge in nano complementary metal–oxide–semiconductor (CMOS) technology, as the surface roughness, contact size, film thicknesses, and undoped substrate become more problematic as the technology shrinks to the nanometer range. These factors increase the contact resistance and the nonlinearity of the current–voltage characteristics, which could limit the benefits of the further downsizing of CMOS devices. This review discusses issues related to the contact size reduction of nano CMOS technology and the validity of the Schottky junction model at the nanoscale. The difficulties, such as the limited doping level and choices of metal for band alignment, Fermi-level pinning, and van der Waals gap, in achieving transparent ohmic contacts with emerging two-dimensional materials are also examined. Finally, various methods for improving ohmic contacts’ characteristics, such as two-dimensional/metal van der Waals contacts and hybrid contacts, junction doping technology, phase and bandgap modification effects, buffer layers, are highlighted. Full article

In this experiment, we investigated the effects of different reactions on the growth process and morphology of h-MoO₃ and α-MoO₃, and their optical properties and photocatalytic activities were also investigated. Orthogonal experiments were designed to investigate the effects of four influencing factors, namely the amount of ammonium molybdate tetrahydrate (AHM), the type of acid, the reaction temperature and the holding time, on the morphology of h-MoO₃ by a microwave hydrothermal method. The phase and morphology were analyzed by using advanced physicochemical techniques. The XRD results showed that the samples produced by the microwave hydrothermal method had sharp diffraction peaks, high crystallinity and complete crystalline shape. AHM generates h-MoO₃ in both hydrochloric and nitric acid environments. In particular, when the temperature rises to 200 °C, the generated h-MoO₃ will be converted to α-MoO₃ in a nitric acid environment, which will be generated in a sulfuric acid environment. Therefore, increasing the reaction temperature will result in the conversion of h-MoO₃ to α-MoO₃ in sulfuric acid solution. SEM results show that the sample prepared from hydrochloric acid solution has a complete hexagonal prism morphology, while the sample prepared from sulfuric acid solution presents a long fibrous morphology, and the sample prepared from nitric acid solution has many defects on the surface of the hexagonal prism morphology. Interestingly, sample A11 prepared in nitric acid solution showed a spherical structure. Since the generated A3, A6 and A9 samples are all stable phase α-MoO₃, they have a wider band gap compared with other samples. Their particle size is up to the nanometer scale, so they have strong adsorption properties. The spherical sample A11 has excellent adsorption and photocatalytic activity. Full article

Coinage metal nanoclusters (MNCs) are a new type of ultra-small nanoparticles on the sub-nanometer (typically < three nm) scale intermediate between atoms and plasmonic nanoparticles. At the same time, the ultra-small size and discrete energy levels of MNCs enable them to exhibit molecular-like energy gaps, and the total structure involving the metal core and surface ligand together leads to their unique properties. As a novel environmentally friendly chromophore, MNCs are promising candidates for the construction of electroluminescent light-emitting diodes (LEDs). However, a systematic summary is urgently needed to correlate the properties of MNCs with their influences on electroluminescent LED applications, describe the synthetic strategies of highly luminescent MNCs for LEDs’ construction, and discuss the general influencing factors of MNC-based electroluminescent LEDs. In this review, we first discuss relevant photoemissions of MNCs that may have major influences on the performance of MNC-based electroluminescent LEDs, and then demonstrate the main synthetic strategies of highly luminescent MNCs. To this end, we illustrate the recent development of electroluminescent LEDs based on MNCs and present our perspectives on the opportunities and challenges, which may shed light on the design of MNC-based electroluminescent LEDs in the near future. Full article

Terahertz (THz) spectroscopy has been proven as an effective detection means for the label-free and nondestructive sensing of biochemical molecules based on their unique roto-vibrational transitions. However, the conventional THz spectroscopic system is unsuitable for minute material sensing due to its far-field detection scheme, low sample amount, and lack of spectral characteristics, leading to low absorption cross-sections and sensitivity. In this study, a 3D plasmonic structure based on a metal-coated woven-wire mesh (MCWM) was experimentally and numerically demonstrated for sensing trace amounts of analytes combined with THz spectroscopy. Dual sharp spectral features were exhibited in the transmission spectrum, originating from the resonant excitation of THz surface electromagnetic modes via the aperture and periodicity of the MCWM unit cell. According to the finite element simulation, an enhanced and localized surface field was formed at THz resonant frequencies and was concentrated at the metal gaps near the periodic corrugations of the MCWM, resulting in enormous resonant dip shifts caused by the tiny variations in membrane thicknesses and refractive indices. Different types and quantities of analytes, including hydrophilic biopolymer (PAA) membrane, nonuniformly distributed microparticles to mimic macro-biomolecules or cells, and electrolyte salts of PBS, were successfully identified by the MCWM sensor with the best thickness and refractive index sensitivities approaching 8.26 GHz/μm and 547 GHz/RIU, respectively. The demonstrated detection limit of thickness and molecular concentration could respectively achieve nanometer and femtomolar scales in PAA macromolecular detection, surpassing the available metallic mesh devices. The MCWM-based sensing platform presents a rapid, inexpensive, and simple analysis method, potentially paving the way for a new generation of label-free microanalysis sensors. Full article

The use of focused ion and focused electron beam (FIB/FEB) technology permits the fabrication of micro- and nanometer scale geometries. Therefore, FIB/FEB technology is a favorable technique for preparing TEM lamellae, nanocontacts, or nanowires and repairing electronic circuits. This work investigates FIB/FEB technology as a tool for nanotip fabrication and quantum mechanical tunneling applications at a low tunneling voltage. Using a gas injection system (GIS), the Ga-FIB and FEB technology allows both additive and subtractive fabrication of arbitrary structures. Using energy dispersive X-ray spectroscopy (EDX), resistance measurement (RM), and scanning tunneling microscope (STM)/spectroscopy (STS) methods, the tunneling suitability of the utilized metal–organic material–platinum carbon (PtC) is investigated. Thus, to create electrode tips with radii down to 15 nm, a stable and reproducible process has to be developed. The metal–organic microstructure analysis shows suitable FIB parameters for the tunneling effect at high aperture currents (260 pA, 30 kV). These are required to ensure the suitability of the electrodes for the tunneling effect by an increased platinum content (EDX), a low resistivity (RM), and a small band gap (STM). The STM application allows the imaging of highly oriented pyrolytic graphite (HOPG) layers and demonstrates the tunneling suitability of PtC electrodes based on high FIB aperture currents and a low tunneling voltage. Full article

This work presents an overview of the latest results and new data on the optical response from spherical CdSe nanocrystals (NCs) obtained using surface-enhanced Raman scattering (SERS) and tip-enhanced Raman scattering (TERS). SERS is based on the enhancement of the phonon response from nanoobjects such as molecules or inorganic nanostructures placed on metal nanostructured substrates with a localized surface plasmon resonance (LSPR). A drastic SERS enhancement for optical phonons in semiconductor nanostructures can be achieved by a proper choice of the plasmonic substrate, for which the LSPR energy coincides with the laser excitation energy. The resonant enhancement of the optical response makes it possible to detect mono- and submonolayer coatings of CdSe NCs. The combination of Raman scattering with atomic force microscopy (AFM) using a metallized probe represents the basis of TERS from semiconductor nanostructures and makes it possible to investigate their phonon properties with nanoscale spatial resolution. Gap-mode TERS provides further enhancement of Raman scattering by optical phonon modes of CdSe NCs with nanometer spatial resolution due to the highly localized electric field in the gap between the metal AFM tip and a plasmonic substrate and opens new pathways for the optical characterization of single semiconductor nanostructures and for revealing details of their phonon spectrum at the nanometer scale. Full article

Plastic production began in the early 1900s and it has transformed our way of life. Despite the many advantages of plastics, a massive amount of plastic waste is generated each year, threatening the environment and human health. Because of their pervasiveness and potential for health consequences, small plastic residues produced by the breakdown of larger particles have recently received considerable attention. Plastic particles at the nanometer scale (nanoplastics) are more easily absorbed, ingested, or inhaled and translocated to other tissues and organs than larger particles. Nanoplastics can also be transferred through the food web and between generations, have an influence on cellular function and physiology, and increase infections and disease susceptibility. This review will focus on current research on the toxicity of nanoplastics to aquatic species, taking into account their interactive effects with complex environmental mixtures and multiple stressors. It intends to summarize the cellular and molecular effects of nanoplastics on aquatic species; discuss the carrier effect of nanoplastics in the presence of single or complex environmental pollutants, pathogens, and weathering/aging processes; and include environmental stressors, such as temperature, salinity, pH, organic matter, and food availability, as factors influencing nanoplastic toxicity. Microplastics studies were also included in the discussion when the data with NPs were limited. Finally, this review will address knowledge gaps and critical questions in plastics’ ecotoxicity to contribute to future research in the field. Full article

Besides human red blood cells (RBC), a standard model used in AFM-single cell force spectroscopy (SCFS), little is known about apparent Young’s modulus (Ea) or adhesion of animal RBCs displaying distinct cellular features. To close this knowledge gap, we probed chicken, horse, camel, and human fetal RBCs and compared data with human adults serving as a repository for future studies. Additionally, we assessed how measurements are affected under physiological conditions (species-specific temperature in autologous plasma vs. 25 °C in aqueous NaCl solution). In all RBC types, Ea decreased with increasing temperature irrespective of the suspension medium. In mammalian RBCs, adhesion increased with elevated temperatures and scaled with reported membrane sialic acid concentrations. In chicken only adhesion decreased with higher temperature, which we attribute to the lower AE-1 concentration allowing more membrane undulations. Ea decreased further in plasma at every test temperature, and adhesion was completely abolished, pointing to functional cell enlargement by adsorption of plasma components. This halo elevated RBC size by several hundreds of nanometers, blunted the thermal input, and will affect the coupling of RBCs with the flowing plasma. The study evidences the presence of a RBC surface layer and discusses the tremendous effects when RBCs are probed at physiological conditions. Full article

Research institutions and industrial enterprises demand high accuracy and precision positioning systems to fulfil cutting edge requirements of up-to-date technological processes in the field of metrology and optical fabrication. Linear motor system design with high performance mechanical guiding system and optical encoder ensures nanometer scale precision and constant static error, which can be calibrated by optical instruments. Mechanical guiding systems has its benefits in case of control theory and its stability; unfortunately, on the other hand, there exists high influence of structure geometry and tribological effects such as friction and modal response. The aforementioned effect cannot be straightforwardly identified during the assembly process. Degradation of dynamic units can be detected only after certain operating time. Single degree of freedom systems are well investigated and the effect of degradation can be predicted, but there exists a gap in the analysis of nanometer scale multi degree of freedom dynamic systems; therefore, novel diagnostic tools need to be proposed. In this particular paper, dual axes dynamic system analysis will be presented. The main idea is to decouple standard stacked XY stage and analyse X and Y configuration as two different configurations of the same object, while imitators of corresponding axes are absolutely solid and stationary. As storage and analysis of time domain data is not efficient, main attention will be concentrated on frequency domain data, while, of course, statistical and graphical representation of dynamic response will be presented. Transfer function, dynamic response, spectral analysis of dynamic response, and modal analysis will be presented and discussed. Based on the collected data and its analysis, comparison of X and Y responses to different velocity excitation will be presented. Finally, conclusions and recommendations of novel diagnostic way will be presented. Full article

Lateral tunnel junctions are fundamental building blocks for molecular electronics and novel sensors, but current fabrication approaches achieve device yields below 10%, which limits their appeal for circuit integration and large-scale application. We here demonstrate a new approach to reliably form nanometer-sized gaps between electrodes with high precision and unprecedented control. This advance in nanogap production is enabled by the unique properties of 2D materials-based contacts. The large difference in reactivity of 2D materials’ edges compared to their basal plane results in a sequential removal of atoms from the contact perimeter. The resulting trimming of exposed graphene edges in a remote hydrogen plasma proceeds at speeds of less than 1 nm per minute, permitting accurate control of the nanogap dimension through the etching process. Carrier transport measurements reveal the high quality of the nanogap, thus-produced tunnel junctions with a 97% yield rate, which represents a tenfold increase in productivity compared to previous reports. Moreover, 70% of tunnel junctions fall within a nanogap range of only 0.5 nm, representing an unprecedented uniformity in dimension. The presented edge-trimming approach enables the conformal narrowing of gaps and produces novel one-dimensional nano-trench geometries that can sustain larger tunneling currents than conventional 0D nano-junctions. Finally, the potential of our approach for future electronics was demonstrated by the realization of an atom-based memory. Full article

The success of van-der-Waals electronics, which combine large-scale-deposition capabilities with high device performance, relies on the efficient production of suitable 2D materials. Shear exfoliation of 2D materials’ flakes from bulk sources can generate 2D materials with low amounts of defects, but the production yield has been limited below industry requirements. Here, we introduce additive-assisted exfoliation (AAE) as an approach to significantly increase the efficiency of shear exfoliation and produce an exfoliation yield of 30%. By introducing micrometer-sized particles that do not exfoliate, the gap between rotor and stator was dynamically reduced to increase the achievable shear rate. This enhancement was applied to WS₂ and MoS₂ production, which represent two of the most promising 2D transition-metal dichalcogenides. Spectroscopic characterization and cascade centrifugation reveal a consistent and significant increase in 2D material concentrations across all thickness ranges. Thus, the produced WS₂ films exhibit high thickness uniformity in the nanometer-scale and can open up new routes for 2D materials production towards future applications. Full article
