Search Results (41)

Search Parameters:
Keywords = planar inductor

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
11 pages, 7128 KB
Article
An On-Chip Balun Using Planar Spiral Inductors Based on Glass Wafer-Level IPD Technology
by Jiang Qian, Peng Wu, Haiyang Quan, Wei Wang, Yong Wang, Shanshan Sun and Jingchao Xia
Micromachines 2025, 16(4), 443; https://doi.org/10.3390/mi16040443 - 9 Apr 2025
Viewed by 2655
Abstract
As integrated electronic microsystems advance, their internal components demonstrate increasing miniaturization, higher-density integration, and, consequently, significantly enhanced performance. This paper presents an on-chip transformer balun. The balun has a combination of planar coupled inductors and filtering capacitors using integrated passive device (IPD) technology, [...] Read more.
As integrated electronic microsystems advance, their internal components demonstrate increasing miniaturization, higher-density integration, and, consequently, significantly enhanced performance. This paper presents an on-chip transformer balun. The balun has a combination of planar coupled inductors and filtering capacitors using integrated passive device (IPD) technology, giving it the advantages of a more compact circuit size and lower cost to achieve single-ended to differential function on glass substrates. Moreover, it can be integrated in systems by flip-chip. The die has a size of 1.81 mm × 1.36 mm with a −15 dB single-ended return loss bandwidth of 2.07 GHz to 4.30 GHz. Within this bandwidth, the maximum insertion loss is 2.56 dB, and the amplitude imbalance is less than 2.04 dB. The phase difference between the differential signals is 180 ± 14.02° and the common mode rejection ratio (CMRR) is above 19.08 dB. The balun has the potential of miniaturization for integration on package or through-glass interposers (TGIs). Full article
Show Figures

Figure 1

23 pages, 30948 KB
Article
Adapting the Formula for Planar Spiral Inductors’ Inductance Computation to the New Oval Geometric Shape, Ideal for Designing Wireless Power Transfer Systems for Smart Devices
by Claudia Pacurar, Vasile Topa, Claudia Constantinescu, Calin Munteanu, Marian Gliga, Sergiu Andreica and Adina Giurgiuman
Mathematics 2025, 13(3), 348; https://doi.org/10.3390/math13030348 - 22 Jan 2025
Viewed by 4518
Abstract
The most used spiral inductors, in the available scientific literature and in our research activities, so far, have been those with square, hexagonal, octagonal, and circular geometric shapes. Geometry plays an important role in the efficiency of these inductors when used in wireless [...] Read more.
The most used spiral inductors, in the available scientific literature and in our research activities, so far, have been those with square, hexagonal, octagonal, and circular geometric shapes. Geometry plays an important role in the efficiency of these inductors when used in wireless power transfer. In this article, a new geometric shape is designed by combining the square and the circle to create an oval shape of a planar spiral inductor. Inductors with this new shape are designed, numerically modelled, and practically constructed for experimental testing. The formula for inductance computation for planar spiral inductors is adapted for this new oval shape. New geometric coefficients, required for inductance computation formula, have been determined. The new formula for inductance computation is validated both analytically, by comparing the results with those from numerical modelling, and experimentally, by comparing with measurements, for a wide range of oval spiral inductors. Five sets of different oval spiral inductors are optimally designed, numerically modelled, practically constructed, and experimentally tested. By designing this new shape for planar spiral inductors, the inductance is increased 2.16 times compared to square, 1.84 times compared to hexagonal, 2.12 times compared to octagonal, and 2.52 times compared to circular shapes. The new oval spiral inductor design will be very useful for constructing wireless power transfer systems for pacemakers, smartphones, smartwatches, and/or any other type of smart device. Full article
Show Figures

Figure 1

17 pages, 8257 KB
Article
High-Frequency High-Magnetic Flux Variation Foil Winding AC Inductor Design with the Vertical Penetrating Magnetic Field Elimination
by Jinxu Yang, Lin Tian and Xinke Wu
Electronics 2025, 14(2), 298; https://doi.org/10.3390/electronics14020298 - 13 Jan 2025
Cited by 1 | Viewed by 1229
Abstract
In traditional inductor design with planar windings, the magnetic field distribution may not be well-organized, leading to significant winding loss, particularly at high switching frequencies. This study explores the relationship between current distribution and magnetic field distribution in the winding region. Unlike conventional [...] Read more.
In traditional inductor design with planar windings, the magnetic field distribution may not be well-organized, leading to significant winding loss, particularly at high switching frequencies. This study explores the relationship between current distribution and magnetic field distribution in the winding region. Unlike conventional magnetic flux distribution, which directs a large portion of the magnetic field vertically through the windings in the winding region, this work introduces a structure that maintains most of the magnetic flux parallel to the foil windings through the application of quasi-distributed air gaps. This paper presents a design methodology for a high-frequency foil winding inductor with high flux variation. Building on this concept, a high-power density, low loss inductor with foil windings is designed based on the four-switch buck-boost (FSBB) converter. Experimental results demonstrate that the proposed inductor design significantly reduces winding loss in inductors with planar windings. Full article
Show Figures

Figure 1

20 pages, 15674 KB
Article
Numerical Modeling, Analysis, and Optimization of RFID Tags Functioning at Low Frequencies
by Claudia Constantinescu, Sergiu Andreica, Rapolti Laszlo, Adina Giurgiuman, Marian Gliga, Calin Munteanu and Claudia Pacurar
Appl. Sci. 2024, 14(20), 9544; https://doi.org/10.3390/app14209544 - 19 Oct 2024
Cited by 4 | Viewed by 3589
Abstract
RFID (radio frequency identification) tags play a crucial role in a wide range of applications, from wireless communications to personal tracking and smart city infrastructure. These tags come in various shapes and sizes, prompting the authors to review the specialized literature and focus [...] Read more.
RFID (radio frequency identification) tags play a crucial role in a wide range of applications, from wireless communications to personal tracking and smart city infrastructure. These tags come in various shapes and sizes, prompting the authors to review the specialized literature and focus on optimizing planar designs with different geometries. This study prioritizes reducing the size of the most commonly used tags while enhancing their reliability. The primary objective of this article is to understand and improve the performance of planar RFID tags operating at 13.56 MHz through numerical simulations based on structures generated by algorithms developed in MATLAB. Building on previous research, the methodology is validated, followed by a detailed description of the algorithm designed and implemented by the authors in MATLAB to identify all possible structures that meet the design criteria. The authors compared various analyzed structures, considering different inductor shapes, dielectric materials, and thicknesses while examining their effects on gain and resonant frequency. The study also provides thermal analysis of the structures, and experimental validation of the studied designs. Finally, the researchers conclude with recommendations on the optimal structure for RFID tags. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

16 pages, 6484 KB
Article
An Enhanced Six-Turn Multilayer Planar Inductor Interleaved Winding Design for LLC Resonant Converters with Low Current Ringing
by Qichen Liu and Zhengquan Zhang
Electronics 2024, 13(16), 3201; https://doi.org/10.3390/electronics13163201 - 13 Aug 2024
Cited by 2 | Viewed by 1739
Abstract
Planar magnetic components have been widely used in high-density power converters and are suitable for various topologies. The application of planar inductors in LLC resonant converters can lead to parasitic capacitance, which causes current ringing and results in EMI issues. To mitigate the [...] Read more.
Planar magnetic components have been widely used in high-density power converters and are suitable for various topologies. The application of planar inductors in LLC resonant converters can lead to parasitic capacitance, which causes current ringing and results in EMI issues. To mitigate the impact of current ringing, the parasitic capacitance of the planar inductor needs to be reduced. This paper proposes a new six-turn interleaved winding design. Compared to the previous four-turn interleaved winding design, it maintains low parasitic capacitance while positioning both the input and output terminals of the inductor on the outer turn, further enhancing the integration of high-density power converters. The parasitic capacitance was calculated using theoretical methods and verified through finite element simulations. Experimental validation was conducted using an LLC resonant converter test platform. Compared to the previous four-turn interleaved winding design, the new six-turn interleaved winding design satisfies both the input and output terminals, using an outer turn configuration. Additionally, the new design exhibits reduced parasitic capacitance and is suitable for use in LLC resonant converters, where it also minimizes current ringing. Full article
(This article belongs to the Special Issue Compatibility, Power Electronics and Power Engineering)
Show Figures

Figure 1

19 pages, 8014 KB
Article
A 10 µH Inductance Standard in PCB Technology with Enhanced Protection against Magnetic Fields
by Žarko Martinović, Martin Dadić, Ivan Matas and Lovorka Grgec Bermanec
Electronics 2024, 13(15), 3009; https://doi.org/10.3390/electronics13153009 - 30 Jul 2024
Cited by 1 | Viewed by 1433
Abstract
Low-frequency working standards of inductance are generally uniformly wound toroids on a ceramic core. Planar inductors made using printed circuit board (PCB) technology are simple and cheap to manufacture in comparison to inductors wound on toroid cores, but they are significantly prone to [...] Read more.
Low-frequency working standards of inductance are generally uniformly wound toroids on a ceramic core. Planar inductors made using printed circuit board (PCB) technology are simple and cheap to manufacture in comparison to inductors wound on toroid cores, but they are significantly prone to the influence of external magnetic fields. In this paper, we propose the design of a PCB inductance working standard of 10 μH, consisting of a duplex system of planar PCB coils, electrostatic shielding, and an enclosure. Alongside an electromagnetic analysis and design procedure, the measurements on the manufactured prototype included the generated magnetic field, the thermal time constant of the enclosure, temperature coefficients, and its error analysis. The measurements show negligible generated magnetic fields (<1.68 nT at 7 cm, 49 mA, 10 kHz). The minimum thermal time constant of the enclosure is 1270 s and the temperature coefficient of resistance is 0.00384 1/. The presented method of temperature coefficient measurement using a climate chamber allows for measurements in the temperature range of 10 °C to 40 °C. In this temperature range, the results show an inductance variation of 0.05 µH at 50 kHz, while the uncertainty of inductance measurement at this frequency was 0.03 µH (k = 2). Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

13 pages, 1733 KB
Article
Wireless and Battery-Free Sensor for Interstitial Fluid Pressure Monitoring
by Chengyang Qian, Fan Ye, Junye Li, Peter Tseng and Michelle Khine
Sensors 2024, 24(14), 4429; https://doi.org/10.3390/s24144429 - 9 Jul 2024
Cited by 3 | Viewed by 5335
Abstract
Congestive heart failure (CHF) is a fatal disease with progressive severity and no cure; the heart’s inability to adequately pump blood leads to fluid accumulation and frequent hospital readmissions after initial treatments. Therefore, it is imperative to continuously monitor CHF patients during its [...] Read more.
Congestive heart failure (CHF) is a fatal disease with progressive severity and no cure; the heart’s inability to adequately pump blood leads to fluid accumulation and frequent hospital readmissions after initial treatments. Therefore, it is imperative to continuously monitor CHF patients during its early stages to slow its progression and enable timely medical interventions for optimal treatment. An increase in interstitial fluid pressure (IFP) is indicative of acute CHF exacerbation, making IFP a viable biomarker for predicting upcoming CHF if continuously monitored. In this paper, we present an inductor-capacitor (LC) sensor for subcutaneous wireless and continuous IFP monitoring. The sensor is composed of inexpensive planar copper coils defined by a simple craft cutter, which serves as both the inductor and capacitor. Because of its sensing mechanism, the sensor does not require batteries and can wirelessly transmit pressure information. The sensor has a low-profile form factor for subcutaneous implantation and can communicate with a readout device through 4 layers of skin (12.7 mm thick in total). With a soft silicone rubber as the dielectric material between the copper coils, the sensor demonstrates an average sensitivity as high as –8.03 MHz/mmHg during in vitro simulations. Full article
(This article belongs to the Special Issue Wearable Sensors for Physical Activity and Healthcare Monitoring)
Show Figures

Figure 1

16 pages, 13215 KB
Article
Design of Interleaved Winding for Multilayer Planar Inductor and Its Application in Reducing Current Ringing of LLC Resonant Converter
by Qichen Liu and Zhengquan Zhang
Energies 2024, 17(7), 1649; https://doi.org/10.3390/en17071649 - 29 Mar 2024
Cited by 1 | Viewed by 2043
Abstract
To enhance the power density of LLC resonant converters, multilayer planar inductors are required. However, multilayer planar inductors have high parasitic capacitance, which may cause inductor current ringing in LLC resonant converters, leading to EMI problems. In this paper, it is found that [...] Read more.
To enhance the power density of LLC resonant converters, multilayer planar inductors are required. However, multilayer planar inductors have high parasitic capacitance, which may cause inductor current ringing in LLC resonant converters, leading to EMI problems. In this paper, it is found that by using interleaved winding inductors, compared with traditional winding inductors, the parasitic capacitance of multilayer planar inductors is reduced, which can reduce current ringing, without sacrificing power density and increasing manufacturing complexity. The method used to analyze current ringing is to establish an impedance model, and the parasitic capacitance of the interleaved winding inductors is verified by FEM simulations. The analysis is validated in an LLC resonant converter prototype. Full article
Show Figures

Figure 1

13 pages, 3427 KB
Article
Modeling and Simulation of a Planar Permanent Magnet On-Chip Power Inductor
by Jaber A. Abu Qahouq and Mohammad K. Al-Smadi
Modelling 2024, 5(1), 339-351; https://doi.org/10.3390/modelling5010018 - 22 Feb 2024
Cited by 1 | Viewed by 1954
Abstract
The on-chip integration of a power inductor together with other power converter components of small sizes and high-saturation currents, while maintaining a desired or high inductance value, is here pursued. The use of soft magnetic cores increases inductance density but results in a [...] Read more.
The on-chip integration of a power inductor together with other power converter components of small sizes and high-saturation currents, while maintaining a desired or high inductance value, is here pursued. The use of soft magnetic cores increases inductance density but results in a reduced saturation current. This article presents a 3D physical model and a magnetic circuit model for an integrated on-chip power inductor (OPI) to double the saturation current using permanent magnet (PM) material. A ~50 nH, 7.5 A spiral permanent magnet on-chip power inductor (PMOI) is here designed, and a 3D physical model is then developed and simulated using the ANSYS®/Maxwell® software package (version 2017.1). The 3D physical model simulation results agree with the presented magnetic circuit model, and show that in the example PMOI design, the addition of the PM increases the saturation current of the OPI from 4 A to 7.5 A, while the size and inductance value remain unchanged. Full article
Show Figures

Figure 1

18 pages, 2812 KB
Article
Design and Assessment of Track Structures in High-Frequency Planar Inductors
by Pouya Kolahian, Mehdi Zarei Tazehkand and Mehdi Baghdadi
Energies 2024, 17(4), 923; https://doi.org/10.3390/en17040923 - 16 Feb 2024
Cited by 3 | Viewed by 1326
Abstract
This paper investigates the effect of different designs and arrangements of conductors on the operational parameters of a planar inductor. Accordingly, it is suggested that there is no one-size-fits-all design that can achieve all desired parameters in every application, and the best design [...] Read more.
This paper investigates the effect of different designs and arrangements of conductors on the operational parameters of a planar inductor. Accordingly, it is suggested that there is no one-size-fits-all design that can achieve all desired parameters in every application, and the best design should be determined by the needs of the application. In order to have a comprehensive study, four different structures are considered and compared. Numerous design parameters such as track width, track length, location of the conductors between the central limb and the lateral limb, and number of transposition points among subtracks for both air-core and ferrite-core inductors are considered. Each structure is evaluated according to AC resistance, RAC/RDC, and inductance. Measurement results reveal that it is critical to take into account all three characteristics when deciding the suitable structure for the conductors. Studies are carried out based on measurement results for experimental prototypes in the frequency range of 10 Hz–1 MHz, and a set of guidelines is provided with regard to the design of planar inductors to achieve desired characteristics. Full article
(This article belongs to the Section F3: Power Electronics)
Show Figures

Figure 1

15 pages, 7346 KB
Article
An Inductor-Loaded Single-Port Planar Dual-Broadband Antenna with Stable Gains
by Wenxing An, Xinyu Xu, Jian Wang and Shenrong Li
Micromachines 2023, 14(6), 1233; https://doi.org/10.3390/mi14061233 - 11 Jun 2023
Cited by 1 | Viewed by 2218
Abstract
A single-port dual-wideband base-station antenna is reported here for mobile communication systems. Loop and stair-shaped structures with lumped inductors are adopted for dual-wideband operation. The low and high bands share the same radiation structure to accomplish a compact design. The operation principle of [...] Read more.
A single-port dual-wideband base-station antenna is reported here for mobile communication systems. Loop and stair-shaped structures with lumped inductors are adopted for dual-wideband operation. The low and high bands share the same radiation structure to accomplish a compact design. The operation principle of the proposed antenna is analyzed, and the effects of the lumped inductors are studied. The measured operation bands are from 0.64 GHz to 1 GHz and from 1.59 GHz to 2.82 GHz, with relative bandwidths of 43.9% and 55.8%, respectively. Broadside radiation patterns and stable gain with a variation of less than 2.2 dB are achieved for both bands. The inductor-loading technology is proven to be an effective way for dual-band antenna design with wide bandwidth and stable gain performance. Full article
(This article belongs to the Special Issue Recent Advances in Microwave Components and Devices)
Show Figures

Figure 1

27 pages, 6421 KB
Article
Planar Elliptical Inductor Design for Wireless Implantable Medical Devices
by Muhammad Farooq, Bilal Amin, Adnan Elahi, William Wijns and Atif Shahzad
Bioengineering 2023, 10(2), 151; https://doi.org/10.3390/bioengineering10020151 - 23 Jan 2023
Cited by 8 | Viewed by 4645
Abstract
Wireless implantable medical devices (WIMDs) have seen unprecedented progress in the past three decades. WIMDs help clinicians in better-understanding diseases and enhance medical treatment by allowing for remote data collection and delivering tailored patient care. The wireless connectivity range between the external reader [...] Read more.
Wireless implantable medical devices (WIMDs) have seen unprecedented progress in the past three decades. WIMDs help clinicians in better-understanding diseases and enhance medical treatment by allowing for remote data collection and delivering tailored patient care. The wireless connectivity range between the external reader and the implanted device is considered one of the key design parameters in WIMD technology. One of the common modes of communication in battery-free WIMDs is inductive coupling, where the power and data between the reader and the implanted device are transmitted via magnetically coupled inductors. The design and shape of these inductors depend on the requirements of the application. Several studies have reported models of standard planar inductors such as circular, square, hexagonal, and octagonal in medical applications. However, for applications, constrained by narrow implantable locations, elliptical planar inductors may perform better than standard-shaped planar inductors. The aim of this study is to develop a numerical model for elliptical inductors. This model allows for the calculation of the inductance of the elliptical planar inductor and its parasitic components, which are key design parameters for the development of WIMDs powered by inductive coupling. An area transformation technique is used to transform and derive elliptical inductor formulas from standard circular inductor formulas. The proposed model is validated for various combinations of the number of turns, trace width, trace separation, and different inner and outer diameters of the elliptical planar inductor. For a thorough experimental validation of the proposed numerical model, more than 75 elliptical planar inductors were fabricated, measured, and compared with the numerical output of the proposed model. The mean error between the measured inductor parameters and numerical estimates using the proposed model is <5%, with a standard deviation of <3.18%. The proposed model provides an accurate analytical method for estimating and optimizing elliptical planar inductor parameters using a combination of current sheet expression and area transformation techniques. An elliptical planar inductor integrated with a sensing element can be used as a wireless implant to monitor the physiological signal from narrow implantation sites. Full article
(This article belongs to the Section Nanobiotechnology and Biofabrication)
Show Figures

Figure 1

16 pages, 4266 KB
Article
An Ex Vivo Study of Wireless Linkage Distance between Implantable LC Resonance Sensor and External Readout Coil
by Muhammad Farooq, Bilal Amin, Marcin J. Kraśny, Adnan Elahi, Muhammad Riaz ur Rehman, William Wijns and Atif Shahzad
Sensors 2022, 22(21), 8402; https://doi.org/10.3390/s22218402 - 1 Nov 2022
Cited by 8 | Viewed by 3481
Abstract
The wireless monitoring of key physiological parameters such as heart rate, respiratory rate, temperature, and pressure can aid in preventive healthcare, early diagnosis, and patient-tailored treatment. In wireless implantable sensors, the distance between the sensor and the reader device is prone to be [...] Read more.
The wireless monitoring of key physiological parameters such as heart rate, respiratory rate, temperature, and pressure can aid in preventive healthcare, early diagnosis, and patient-tailored treatment. In wireless implantable sensors, the distance between the sensor and the reader device is prone to be influenced by the operating frequency, as well as by the medium between the sensor and the reader. This manuscript presents an ex vivo investigation of the wireless linkage between an implantable sensor and an external reader for medical applications. The sensor was designed and fabricated using a cost-effective and accessible fabrication process. The sensor is composed of a circular planar inductor (L) and a circular planar capacitor (C) to form an inductor–capacitor (LC) resonance tank circuit. The reader system comprises a readout coil and data acquisition instrumentation. To investigate the effect of biological medium on wireless linkage, the readout distance between the sensor and the readout coil was examined independently for porcine and ovine tissues. In the bench model, to mimic the bio-environment for the investigation, skin, muscle, and fat tissues were used. The relative magnitude of the reflection coefficient (S11) at the readout coil was used as a metric to benchmark wireless linkage. A readable linkage signal was observed on the readout coil when the sensor was held up to 2.5 cm under layers of skin, muscle, and fat tissue. To increase the remote readout distance of the LC sensor, the effect of the repeater coil was also investigated. The experimental results showed that the magnitude of the reflection coefficient signal was increased 3–3.5 times in the presence of the repeater coil, thereby increasing the signal-to-noise ratio of the detected signal. Therefore, the repeater coil between the sensor and the readout coil allows a larger sensing range for a variety of applications in implanted or sealed fields. Full article
(This article belongs to the Special Issue Novel Implantable Sensors and Biomedical Applications)
Show Figures

Figure 1

20 pages, 4593 KB
Article
A Novel Design Nomogram for Optimization of Micro Search Coil Magnetometer for Energy Monitoring in Smart Buildings
by Hadi Tavakkoli, Kui Song, Xu Zhao, Mingzheng Duan and Yi-Kuen Lee
Micromachines 2022, 13(8), 1342; https://doi.org/10.3390/mi13081342 - 18 Aug 2022
Cited by 6 | Viewed by 2159
Abstract
In this paper, a new analytical method to achieve the maximum signal-to-noise ratio (SNR) of a micro search coil magnetometer (µSCM) is presented. A planar spiral inductor was utilized to miniaturize conventional bulky search coil magnetometers. First, dimensional analysis was applied [...] Read more.
In this paper, a new analytical method to achieve the maximum signal-to-noise ratio (SNR) of a micro search coil magnetometer (µSCM) is presented. A planar spiral inductor was utilized to miniaturize conventional bulky search coil magnetometers. First, dimensional analysis was applied to identify three dimensionless parameters for the µSCM’s key performance indices (sensitivity (Se), noise, and SNR). The effect of the parameters on the µSCM’s performance was carefully investigated, and a novel 4D nomogram was developed. Furthermore, an SNR analysis considering noise sources of a low-noise amplifier was performed. By combining the results from the nomogram and the effect of the noise sources from the amplifier circuit, optimum values for the dimensionless parameters were calculated. According to the calculation results, the dominant noise source varied with an increase in the track width ratio to the outer diameter. Seven different samples were fabricated by a single-mask lithography process. The sensitivity of 1612 mV/mT was demonstrated at a 50 Hz input magnetic field, which was better than the previous µSCM (Se = 6.5 mV/mT) by more than 2 orders of magnitude. Finally, one of the fabricated µSCMs was employed to measure the online power consumption of a personal computer while different types of software were running. Full article
(This article belongs to the Special Issue Design, Fabrication, Testing of MEMS/NEMS)
Show Figures

Graphical abstract

15 pages, 3157 KB
Article
Variation Range of Different Inductor Topologies with Shields for RF and Inductive Sensing Applications
by Fares Tounsi, Mohamed Hadj Said, Margo Hauwaert, Sinda Kaziz, Laurent A. Francis, Jean-Pierre Raskin and Denis Flandre
Sensors 2022, 22(9), 3514; https://doi.org/10.3390/s22093514 - 5 May 2022
Cited by 4 | Viewed by 4833
Abstract
In this study, different planar inductor topologies were studied to evaluate their characteristic parameters’ variation range upon approaching Fe- and Cu-based shield plates. The use of such materials can differently alter the electrical properties of planar inductors such as the inductance, resonant frequency, [...] Read more.
In this study, different planar inductor topologies were studied to evaluate their characteristic parameters’ variation range upon approaching Fe- and Cu-based shield plates. The use of such materials can differently alter the electrical properties of planar inductors such as the inductance, resonant frequency, resistance, and quality factor, which could be useful in multiple devices, particularly in inductive sensing and radio-frequency (or RF) applications. To reach an optimal design, five different square topologies, including spiral, tapered, non-spiral, meander, and fractal, were built on a printed circuit board (PCB) and assessed experimentally. At the working frequency of 1 MHz, the results showed a decrease in the inductance value when approaching a Cu-based plate and an increase with Fe-based plates. The higher variation range was noticeable for double-layer topologies, which was about 60% with the Cu-based plate. Beyond an intrinsic deflection frequency, the inductance value began to decrease when approaching the ferromagnetic plate because of the ferromagnetic resonance (FMR). It has been shown that the FMR frequency depends on the inductor topology and is larger for the double-layer spiral one. The Q-factor was decreasing for all topologies but was much faster when using ferromagnetic plates because of the FMR, which intensely increases the track resistance. The resonant frequency was increasing for all double-layer topologies and decreasing for single-layer ones, which was mainly due to the percentage change in the stray capacitance compared to the inductance variation. The concept of varying inductors by metal shielding plates has great potential in a wide range of nondestructive sensing and RF applications. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1
