The electric energy metering box serves as a crucial node in power grid operations, offering essential protection for key components in the distribution network, such as smart meters, data acquisition terminals, and circuit breakers, thereby ensuring their safe and reliable operation. However, the non-metallic housings of these boxes are susceptible to aging under environmental stress, which can result in diminished flame-retardant properties and an increased risk of fire. Currently, there is a lack of rapid and accurate methods for assessing the fire resistance of non-metallic metering box enclosures. In this study, laser-induced breakdown spectroscopy (LIBS), which enables fast, multi-element, and non-contact analysis, was utilized to develop an effective assessment approach. Thermal aging experiments were conducted to systematically investigate the degradation patterns and mechanisms underlying the reduced flame-retardant performance of sheet molding compound (SMC), a representative non-metallic material used in metering box enclosures. The results showed that the intensity ratio of aluminum ionic spectral lines is highly correlated with the flame-retardant grade, serving as an effective performance indicator. On this basis, a one-dimensional convolutional neural network (1D-CNN) model was developed utilizing LIBS data, which achieved over 92% prediction accuracy for different flame-retardant grades on the test set and demonstrated high recognition accuracy for previously unseen samples. This method offers significant potential for rapid, on-site evaluation of flame-retardant grades of non-metallic electric energy metering boxes, thereby supporting the safe and reliable operation of power systems. Full article

To address the challenges of prolonged current isolation times and high dependency on varistors in traditional flexible short-circuit fault isolation schemes for DC systems, this paper proposes a rapid fault isolation circuit design based on an adaptive solid-state circuit breaker (SSCB). By introducing an adaptive current-limiting branch topology, the proposed solution reduces the risk of system oscillations induced by current-limiting inductors during normal operation and minimizes steady-state losses in the breaker. Upon fault occurrence, the current-limiting inductor is automatically activated to effectively suppress the transient current rise rate. An energy dissipation circuit (EDC) featuring a resistor as the primary energy absorber and an auxiliary varistor (MOV) for voltage clamping, alongside a snubber circuit, provides an independent path for inductor energy release after faults. This design significantly alleviates the impact of MOV capacity constraints on the fault isolation process compared to traditional schemes where the MOV is the primary energy sink. The proposed topology employs a symmetrical bridge structure compatible with both pole-to-pole and pole-to-ground fault scenarios. Parameter optimization ensures the IGBT voltage withstand capability and energy dissipation efficiency. Simulation and experimental results demonstrate that this scheme achieves fault isolation within 0.1 ms, reduces the maximum fault current-to-rated current ratio to 5.8, and exhibits significantly shorter isolation times compared to conventional approaches. This provides an effective solution for segment switches and tie switches in millisecond-level self-healing systems for both low-voltage (LVDC, e.g., 750 V/1500 V DC) and medium-voltage (MVDC, e.g., 10–35 kV DC) smart DC distribution grids, particularly in applications demanding ultra-fast fault isolation such as data centers, electric vehicle (EV) fast-charging parks, and shipboard power systems. Full article

As the global energy transition moves towards the goal of low-carbon sustainability, it is crucial to build a new energy power system. The performance and reliability of Smart Circuit Breakers are the key to ensuring safe operation. The control circuit is the key to the reliability of Smart Circuit Breakers, so studying its performance-degradation process is of great significance. This study centers on the development of a degradation model and the performance-degradation-assessment method for the control circuit of Smart Circuit Breakers and proposes a novel approach for lifetime prediction. Firstly, a test platform is established to collect necessary data for developing a performance-degradation model based on the two-stage Wiener process. According to the theory of maximum likelihood estimation and Schwarz information criterion, the estimation method of model distribution parameters in each degradation stage and the degradation ‘turning point’ method are studied. Then, reliability along with residual life serve as evaluation criteria for analyzing the control circuit’s performance deterioration. Taking the degradation characteristic data into the degradation model, for example, analysis, combined with the Arrhenius empirical formula, the reliability function at room temperature and the curve of the residual life probability density function is obtained. Ultimately, the average service life of the Smart Circuit Breaker control circuit at room temperature is 178,100 h (20.3 years), with a degradation turning point at 155,000 h (17.7 years), providing a basis for the lifetime evaluation of low-voltage circuit breakers. Full article

With the development of intelligent grid systems, smart circuit breakers are widely used. The control circuit is the core component of the smart circuit breaker, making its performance degradation characteristics highly significant. This paper focuses on the control circuit’s accelerated degradation test and performance degradation characteristics. First, an accelerated degradation test is designed, and a test platform is established. By analyzing the degradation mechanism of the intelligent circuit breaker control loop, the key weak links in the control loop are determined, and then the monitoring quantity is determined. Then, degradation data are preprocessed to extract features from the time, frequency, and wavelet domains. The multidimensional evaluation index model is applied to select the optimal features, fit the degradation trend, and use the fixed segmentation algorithm to divide the degradation stages and analyze the performance degradation characteristics of the control circuit. The experimental results show that the turning points of the two-stage degradation process at 85 °C, 95 °C, and 105 °C are 78.8%, 77.6%, and 77.0%, respectively. The position of the turning point is relatively fixed. The key circuit’s PSpice simulation model is built to verify the two-stage nonlinear characteristics observed in the experimental results. Finally, the results are verified by the Pearson correlation coefficient. The results show that the Pearson correlation coefficient between the simulation and accelerated life test results is above 0.9158, and the consistency between the two is high. Full article

Neural-networks (NNs) for the current feature analysis bring novel electrical safety functions in smart circuit breakers (CBs), especially for preventing the fire hazard from electric vehicle/bike battery charging. In this work, the edge artificial intelligence (AI) solutions for the electrical anomaly detection were designed and demonstrated based on the process-in-memory (PIM) AI chip. The ultra-low power and high-performance character of PIM AI chips enable the edge solution to embed in the limited space inside the circuit breaker and to detect improper battery charging at millisecond latency. Full article

A smart grid protection system based on phasor information at circuit breakers is proposed in this paper. Phasor data for fault diagnosis is obtained from phasor measurement units or intelligent electronic devices installed near circuit breakers, without the need for additional measurement equipment. When a fault occurs, the protection system first locates the core protection circuit breaker closest to the fault point. It then identifies the faulty component by analyzing the current phasor differences between this breaker and adjacent ones. This scheme offers high computational efficiency, enabling rapid identification of faulty equipment and its precise location. The proposed protection system structure can be divided into two types: centralized and decentralized, and the most suitable scheme should be selected based on the actual situation. Finally, the feasibility of the proposed scheme was verified through the IEEE 39-bus system and a simulated actual area power grid model, demonstrating its applicability to practical smart grid scenarios. The simulation network validates the implementation method of the proposed protection strategy. Full article

This paper thoroughly explores the feasibility of integrating a variety of intelligent electrical equipment and smart maintenance technologies within nuclear power plants to enhance the currently limited level of intelligence of these systems and better support operational and maintenance tasks. Initially, this paper outlines the demands and challenges of intelligent electrical systems in nuclear power plants, highlighting the current state of development of intelligent electrical systems, including new applications of artificial intelligence and big data technologies in power grid companies, such as intelligent defect recognition through image recognition, intelligence-assisted inspections, and intelligent production commands. This paper then provides a detailed introduction to the architecture of intelligent electrical equipment, encompassing the smart electrical equipment layer, the smart control system layer, and the cloud platform layer. It discusses the intelligentization of medium- and low-voltage electrical equipment, such as smart circuit breakers, smart switchgear, and low-voltage distribution systems, emphasizing the importance of intelligentization in improving the safety, reliability, and maintenance efficiency of medium- and low-voltage distribution equipment in nuclear power plants. Furthermore, this paper addresses issues in the intelligentization of nuclear power plant electrical systems, such as information silos, the inefficiency of traditional manual inspection processes, and the lack of comprehensive intelligent design and evaluation standards, proposing corresponding solutions. Additionally, this paper presents the trends in intelligent operation and maintenance technology and applications, including primary and secondary fusion technology, intelligent patrol system architecture, intelligent inspection based on non-destructive testing, and a comprehensive solution based on inspection robots. The application of these technologies aids in achieving automated inspection, real-time monitoring, and the intelligent diagnosis of electrical equipment in nuclear power plants. Finally, this paper proposes basic principles for the development of intelligent electrical systems in nuclear power plants, including intelligent architecture, the evolutionary path, and phased goals and key technologies. It emphasizes the gradual transition from automation to digitization and then to intelligentization and presents a specific implementation plan for the intelligentization of the electrical systems in nuclear power plants. This paper concludes with a summary of short-term and long-term goals for improving the performance of nuclear power plant electrical systems through intelligent technologies and prospects for the application of intelligent technologies in the operation and maintenance of nuclear power plants in the future. Full article

Grid-connected photovoltaic (PV) power systems are one of the most promising technologies to address growing energy demand and ecological challenges. This paper proposes smart switching to mitigate inrush currents during the connection of single-phase transformers used in PV systems. An effective inrush current mitigation contributes to the reliability of PV systems. The inrush current severity is influenced by the pseudorandom residual flux at the transformer core and the energization point-on-wave. The most common approach to avoid inrush currents is controlled connection, which requires prior knowledge of the residual flux. However, the residual flux can differ in each case, and its measurement or estimation can be impractical. The proposed smart switching is based on a comprehensive analysis of the residual flux and the de-energization trajectories, and only requires two pieces of data (ϕ_RM and ϕ₀, flux values of the static and dynamic loops when the respective currents are null), calculated from two simple no-load tests. It has a clear advantage over common approaches: no need to estimate or measure the residual flux before each connection, avoiding the need for expensive equipment or complex setups. Smart switching can be easily implemented in practical settings, as it considers different circuit breakers with distinctive aperture features, making it cost-effective for PV systems. Full article

The advent of energy communities will revolutionize the energy market. However, exploiting their full potential requires innovations in the structure and management of low-voltage grids. End users shall be aggregated within microgrids, where their physical interaction is possible and coordinated operation of power sources and energy storage systems can be achieved. Moreover, meshed network topologies will enable multiple paths for the power flow. The combination of smart control and meshed networks can dramatically improve microgrid performance in terms of power quality, efficiency, and resilience to transients and faults. Ubiquitous control of the power flow becomes possible, as well as active fault clearing and isolation of subgrids without tripping circuit breakers. This paper proposes a control approach that pursues such goals without requiring modification of control and communication hardware implemented in commercial inverters. Instead, a revision of control firmware, integrated with local measurements, allows retrofitting existing plants to improve microgrid operation. Further improvements may derive from the installation of community power sources and energy storage systems, which can extend microgrid operation to pursue demand response and islanding. The potential of the proposed control methods is demonstrated by simulation considering a standard microgrid under different operating conditions. Full article

The electrical cabinet systems in power plants are critical non-structural components to maintaining sustainable operation and preventing unexpected accidents during extreme events. This system consists of various electrical equipment such as relays, circuit breakers, and switches enclosed by a steel cabinet for the protection of the equipment. The cabinet systems are installed in and protected by structures so that the cabinet’s behavior is totally dependent on the behavior of the structures when subjected to an earthquake. Therefore, it is essential to qualify the seismic performance of the cabinet system considering the effect of the primary structure where the electrical cabinet system is mounted. In addition, with the implementation of ASCE-43 design standards for nuclear facilities, facility design allowing nonlinear behavior has gained greater attention in nuclear power plants, and research on how the response of the cabinet varies according to allowable damage levels of structures is needed. In this study, Finite Element (FE) models of a single-door electrical cabinet and concrete shear wall structure validated through experimental data are used for a decoupled analysis to estimate the seismic demands of the electrical cabinet. Three different earthquake loadings, referred to as EQ#13, #17, and #19, used in the SMART-2013 project are selected to obtain floor responses of the concrete structure, and the loadings lead to different levels of damage (minor, moderate, and major damage, respectively) to the structure. Finally, the floor responses based on levels of the damage to the primary structure are applied to the electrical cabinet system as input loadings for the decoupled analysis. Thus, this study presents the effects of the cabinet elevation and performance limit-state for concrete shear wall structures on the response of the electrical cabinet, and it shows that while the difference in seismic demands is not significant in the minor and moderate damage states, a meaningful difference occurs in the degree of the major damage state. Full article

With the global trend to digitalize substation automation systems, International Electro technical Commission 61850, a communication protocol defined by the International Electrotechnical Commission, has been given much attention to ensure consistent communication and integration of substation high-voltage primary plant assets such as instrument transformers, circuit breakers and power transformers with various intelligent electronic devices into a hierarchical level. Along with this transition, equipment of primary plants in the switchyard, such as non-conventional instrument transformers, and a secondary system including merging units are expected to play critical roles due to their fast-transient response over a wide bandwidth. While a non-conventional instrument transformer has advantages when compared with the conventional one, extensive and detailed performance investigation and feasibility studies are still required for its full implementation at a large scale within utilities, industries, smart grids and digital substations. This paper is taking one step forward with respect to this aim by employing an optimized network engineering tool to evaluate the performance of an Ethernet-based network and to validate the overall process bus design requirement of a high-voltage non-conventional instrument transformer. Furthermore, the impact of communication delay on the substation automation system during peak traffic is investigated through a detailed simulation analysis. Full article

This paper presents a novel analysis methodology to detect degradation in electrical contacts, with the main goal of implanting a predictive maintenance procedure for sectionalizing switches, circuit breakers, and current transformers in bays of electric transmission and distribution substations. The main feature of the proposed methodology is that it will produce a predictive failure indication for the system under operation, based on the spectral analysis of the load current that is flowing through the bay’s components, using a defined relationship similar to the signal-to-noise ratio (SNR) used in data communication. A highlight of using the proposed methodology is that it is not necessary to make new investments in measurement devices, as the already-existing oscillography measurement infrastructure is enough. By implementing the diagnostic system proposed here, electrical utilities will have a modern tool for monitoring their electrical installations, supporting the implementation of new predictive maintenance functions typical of the current electrical smart grid scenario. Here, we present the preliminary results obtained by the application of the proposed technique using real data acquired from a 230 kV electrical substation, which indicate the effectiveness of the proposed diagnostic procedure. Full article

With the gradual increasing of the transmission voltage level, the situation of interference on secondary side equipment in smart substations is becoming more serious. The authors tested the interference waveforms caused by the circuit breaker’s operation at the smart substation, which showed the severity of the electromagnetic (EM) environment. This paper takes the electronic current transformer acquisition card as an example. The influence of EM interference sources on the reliability of the acquisition card is analyzed. Then, standardized electromagnetic compatibility (EMC) immunity tests of the international electrotechnical commission (IEC) for different interferences are implemented. Typical output characteristics of acquisition cards for different tests are analyzed. Innovatively, this paper proposes a quantitative evaluation method of output waveform disturbance to evaluate the acquisition card’s performance. This disturbance distortion is of great significance to the EM environment estimation of the acquisition card. Full article

To solve the problem of incompatibility and mutual repulsion between a distribution network (DN) and distributed generation (DG), this paper first analyzes the conflicts between current feeder automation (FA) and doubly-fed induction generation (DFIG). Then, a DFIG coordination control strategy compatible with FA is proposed to cause the DFIG operating continuously during fault isolation and power supply recovery. The strategy consists of three aspects: (1) a DFIG islanding active synchronization control technology to support islanding and distant presynchronization control; (2) DFIG senses the status of circuit breakers/tie-switch through generic object oriented substation event (GOOSE) messages to achieve rapid switch of control modes and distant synchronization; (3) tie-switch senses the status of DFIG through GOOSE messages for closing. Finally, the effectiveness of the strategy is validated by multiple sound and detailed time-domain simulation cases. This study indicates future possible development trends and provides a simple and effective strategy for researches in the field of smart grid DN–DG compatibility. Full article

Smart meters (SMs) are key components of the smart grid (SG) which gather electricity usage data from residences and businesses. Home area networks (HANs) are used to support two-way communications between SMs and devices within a building such as appliances. This can be implemented using power line communications (PLCs) via home wiring topologies. In this paper, a bottom-up approach is designed and a HAN-PLC channel model is obtained for a split-phase power system which includes branch circuits, an electric panel with circuit breakers and bars, a secondary transformer and the wiring of neighboring residences. A cell division (CD) method is proposed to construct the channel model. Furthermore, arc fault circuit interrupter (AFCI) and ground fault circuit interrupter (GFCI) circuit breaker models are developed. Several HAN-PLC channels are presented and compared with those obtained using existing models. Full article
