Search Results (49)

With power demands continuously growing, the penetration of renewable energy resources, particularly solar photovoltaic (PV) systems, across the residential sector has been extensive. A voltage source inverter (VSI) is the key element for efficiently processing energy conversion and connecting PV systems to home loads or utility grids. The operation of this inverter relies heavily on power-switching devices, which suffer from larger power losses due to the conventional semiconductors used based on silicon (Si) material. The new materials of wide bandgap (WBG) semiconductors, for example, gallium nitride (GaN) and silicon carbide (SiC), provide remarkably distinct characteristics of semiconductor devices to minimize power loss and boost the inverter’s operational capabilities. This research paper assesses the effects of integrating SiC-MOSFET devices into VSIs in order to improve the switching behavior and efficiency level. An experimental double-pulse testing (DPT) circuit was configured and set up for investigating the switching characterization of SiC-MOSFETs compared to the widely used Si-IGBTs. Under various operating circumstances, the switching behavior of two different types of power transistors was tested while their turning-on and turning-off losses were measured. The VSI based on SiC and Si transistors was simulated to examine the performance of the inverter. The results reveal that incorporating SiC-MOSFETs into the VSI substantially enhances the switching operation and reduces total power losses while increasing the efficiency compared to the inverter based on Si-IGBTs. Full article

The increasing penetration of renewable energy sources (RESs) into medium-voltage (MV) and low-voltage (LV) power systems presents significant challenges in ensuring power grid stability and energy sustainability. Advanced power conversion technologies are essential to mitigate voltage and frequency fluctuations while meeting stringent power quality standards. RES-based generation systems typically employ multistage power electronics to achieve: (i) maximum power point tracking; (ii) galvanic isolation and voltage transformation; (iii) high-quality power injection into the power grid. In this context, this paper provides a comprehensive review of up-to-date isolated DC–DC converter topologies tailored for the integration of RES. As a contribution to support this topic, recent advancements in solid-state transformers (SSTs) are explored, with particular emphasis on the adoption of wide bandgap (WBG) semiconductors technologies, such as silicon carbide (SiC) and gallium nitride (GaN). These devices have revolutionized modern power systems by enabling operation at a higher switching frequency, enhanced efficiency, and increased power density. By consolidating state-of-the-art advancements and identifying technical challenges, this review offers insights into the suitability of power converter topologies in light of future trends, serving as a valuable resource for optimizing grid-connected RES-based sustainable power systems. Full article

Silicon carbide (SiC) MOSFETs, as a member of the emerging technology of wide-bandgap (WBG) semiconductors, are transforming high-power and high-temperature applications due to their superior electrical and thermal properties. Their potential to outperform traditional silicon-based devices, particularly in terms of efficiency and operational stability, has made them a popular choice for power electronics. However, reliability issues about numerous failure types, including gate-oxide degradation, threshold voltage instability, and body diode degeneration, remain serious challenges. This article critically evaluates the key failure mechanisms that affect SiC MOSFET reliability and their impact on device performance. Furthermore, this paper discusses current advances in SiC technology, including both improvements and continued dependability difficulties. Key areas of future study are suggested, with an emphasis on improved material characterization, thermal management, and creative device architecture to improve SiC MOSFET performance and long-term reliability. The insights presented will help to improve the design and testing processes required for SiC MOSFETs’ widespread use in critical high-power applications. Full article

Electric vehicles (EVs) rely on robust inverter-to-motor connections to ensure high-efficiency operation under the challenging conditions imposed by wide-bandgap (WBG) semiconductors. High switching frequencies and steep voltage rise times in WBG inverters lead to repetitive transient overvoltages, causing insulation degradation and premature motor winding failure. This study proposes a wideband (WB) model of EV cables, developed in EMTP-RV, to improve transient voltage prediction accuracy compared to the traditional constant parameter (CP) model. Using a commercially available EV-dedicated cable, the WB model incorporates frequency-dependent parasitic effects calculated through the vector fitting technique. The motor design is supported by COMSOL Multiphysics and MATLAB 2023 simulations, leveraging the multi-conductor transmission line (MCTL) model for validation. Using practical data from the Toyota Prius 2010 model, including cable length, motor specifications, and power ratings, transient overvoltages generated by high-frequency inverters are studied. The proposed model demonstrates improved alignment with real-world scenarios, providing valuable insights into optimizing insulation systems for EV applications. Full article

Induction motor (IM) drives are considered one of the important technologies in modern industry. Several industrial applications, such as material handling and food and beverage applications, are driven and operated by modern AC drives. Moreover, modern electric transportation systems such as EVs and e-trucks are based on AC drives. Recently, high-efficiency IM drive systems have been studied as a major opportunity to reduce energy and fuel consumption. This article addresses the recent trends and advancement in high-efficiency IM drives during a particular period (2017–2024), including the development of high-efficiency motors, the utilization of efficient wide bandgap (WBG) semiconductor devices for inverter topology, and commonly used control strategies to achieve high-performance drives. Moreover, the article addresses several manufacturers of industrial IM drives and the corresponding adopted control techniques in their products. A comparison of these control techniques, including their pros and cons, has been conducted as well. Full article

A matrix converter (MC) converts an AC source voltage into a variable-voltage variable-frequency AC output voltage (direct AC-AC) without an intermediate DC-link capacitance. By eliminating the traditional DC-link capacitor, MCs can achieve higher power densities and reliability when compared to conventional AC-DC-AC converters. MCs also offer the following characteristics: total semiconductor solution, sinusoidal input and output currents, bidirectional power flow and controllable input power factor. This paper reviews the history, recent developments and commercialization of MCs and discusses several technical requirements and challenges, including bidirectional switches, wide bandgap (WBG) opportunities using GaN and SiC, overvoltage protection, electromagnetic interference (EMI) and ride-through in motor drive applications. MC design solutions and operation are discussed, including a comparison of control and modulation techniques as well as the detailed development of space vector modulation (SVM) to provide a deep insight into the control implementation and results. The paper concludes with compelling motor drive innovation opportunities made possible by advanced MCs including fully integrated and multiphase systems. For conventional MCs, size reductions of 30% are reported, as well as efficiencies of 98% and low input current total harmonic distortion of 3–5%. Full article

Wide bandgap (WBG) power semiconductor devices are increasingly replacing silicon IGBTs in high-power and high-voltage power electronics applications. However, there is a significant gap in the literature regarding efficient testing methodologies for high-power and high-voltage converters under constrained laboratory resources. This paper addresses this gap by presenting comprehensive, hardware-focused testing methodologies for high-power and high-voltage WBG power semiconductor-based converter bring-up before the control validation phase steps in. The proposed methods enable thorough evaluation and validation of converter hardware, including device switching characteristics, driving circuit functionality, thermal management performance, insulation integrity, and sustained operation at full power. We utilized the double pulse test (DPT) to characterize switching performance in a two-level phase leg configuration, extract circuit parasitics, and validate magnetic components. The DPT was further applied to optimize gate driving circuits, validate overcurrent protection mechanisms, and measure device on-resistance. Additionally, a multicycle test was introduced to rapidly assess steady-state converter performance and estimate efficiency. Recognizing the critical role of thermal management in high-power converters, our methodologies extend to the experimental extraction of key thermal parameters—such as junction-to-ambient thermal resistance and thermal capacitance—via a heat loss injection method. A correlation method between temperature sensor measurements and junction temperature is presented to enhance the accuracy of device temperature monitoring during tests. To ensure reliability and safety, dielectric withstand tests and partial discharge measurements were conducted at both component and converter levels under conventional 60 Hz sinusoidal and high-frequency PWM waveforms. Finally, we highlight the importance of testing converters under full voltage, current, and thermal conditions through power circulating tests with minimal power consumption, applicable to both non-isolated and isolated high-power converters. Practical examples are provided to demonstrate the effectiveness and applicability of these hardware testing methodologies. Full article

This study presents a decision-support methodology to design and optimize modular Boost converters in the context of fuel-cell electric vehicles. It involves the utilization of interleaved techniques to reduce fuel-cell current ripple, enhance system efficiency, tackle issues related to weight and size concerns, and offer better flexibility and modularity within the converter. The methodology incorporates emerging technologies by wide-bandgap semiconductors, providing better efficiency and higher temperature tolerance. It employs a multiphysical approach, considering electrical, thermal, and efficiency constraints to achieve an optimal power architecture for FCHEVs. Results demonstrate the advantages of wide-bandgap semiconductor utilization in terms of volume reduction and efficiency enhancements for different power levels. Results from one of the considered power levels highlight the feasibility of certain architectures through the utilization of WBG devices. These architectures reveal improvements in both efficiency and volume reduction as a result of incorporating WBG devices. Additionally, the analysis presents a comparison of manufacturing cost between standard and wide-bandgap semiconductors to demonstrate the market penetration potential. Full article

In this paper, an overview of wide-bandgap (WBG) semiconductors for radiation detection applications is given. The recent advancements in the fabrication of high-quality wafers have enabled remarkable WBG semiconductor device applications. The most common 4H-SiC, GaN, and β-Ga₂O₃ devices used for radiation detection are described. The 4H-SiC and GaN devices have already achieved exceptional results in the detection of alpha particles and neutrons, thermal neutrons in particular. While β-Ga₂O₃ devices have not yet reached the same level of technological maturity (compared to 4H-SiC and GaN), their current achievements for X-ray detection indicate great potential and promising prospects for future applications. Full article

This article presents a new modulation technique called three-dimensional sigma–delta (3D-$\Sigma \Delta$) modulation for high-frequency three-leg four-wire voltage source converters (VSCs) that use wide-bandgap (WBG) semiconductors. These WBG devices allow for the use of high switching frequencies with a greater efficiency than silicon devices. The proposed 3D-$\Sigma \Delta$ technique enables operation at a variable switching frequency, resulting in a significant reduction in switching losses compared to classical pulse-width modulation (PWM) techniques. Moreover, the 3D-$\Sigma \Delta$ technique uses a fast-processing 3D quantiser that simplifies implementation and considerably reduces computational costs. The behaviour of the 3D-$\Sigma \Delta$ modulation is analysed using MATLAB/Simulink and PLECS. The experimental results performed on an active power filter that uses silicon carbide (SiC) MOSFETs demonstrate an improvement in converter efficiency compared to the conventional SPWM technique. Additionally, the experimental results show how 3D-$\Sigma \Delta$ allows for the compensation of harmonics and homopolar currents, thereby balancing the electrical grid currents. The experiments also show that the proposed 3D-$\Sigma \Delta$ modulation outperforms an SPWM technique in terms of power quality, since the former achieves a larger reduction in the harmonic content of the power grid. In conclusion, the proposed modulation technique is an attractive option for improving the performance of four-wire converters in active power filter applications. Full article

Power electronics are becoming increasingly more important, as electrical energy constitutes 40% of the total primary energy usage in the USA and is expected to grow rapidly with the emergence of electric vehicles, renewable energy generation, and energy storage. New materials that are better suited for high-power applications are needed as the Si material limit is reached. Beta-phase gallium oxide (β-Ga₂O₃) is a promising ultra-wide-bandgap (UWBG) semiconductor for high-power and RF electronics due to its bandgap of 4.9 eV, large theoretical breakdown electric field of 8 MV cm⁻¹, and Baliga figure of merit of 3300, 3–10 times larger than that of SiC and GaN. Moreover, β-Ga₂O₃ is the only WBG material that can be grown from melt, making large, high-quality, dopable substrates at low costs feasible. Significant efforts in the high-quality epitaxial growth of β-Ga₂O₃ and β-(Al_xGa_1−x)₂O₃ heterostructures has led to high-performance devices for high-power and RF applications. In this report, we provide a comprehensive summary of the progress in β-Ga₂O₃ field-effect transistors (FETs) including a variety of transistor designs, channel materials, ohmic contact formations and improvements, gate dielectrics, and fabrication processes. Additionally, novel structures proposed through simulations and not yet realized in β-Ga₂O₃ are presented. Main issues such as defect characterization methods and relevant material preparation, thermal studies and management, and the lack of p-type doping with investigated alternatives are also discussed. Finally, major strategies and outlooks for commercial use will be outlined. Full article

Silicon (Si)-based semiconductor devices have long dominated the power electronics industry and are used in almost every application involving power conversion. Examples of these include metal-oxide-semiconductor field-effect transistors (MOSFETs), insulated-gate bipolar transistors (IGBTs), gate turn-off (GTO), thyristors, and bipolar junction transistor (BJTs). However, for many applications, power device requirements such as higher blocking voltage capability, higher switching frequencies, lower switching losses, higher temperature withstand, higher power density in power converters, and enhanced efficiency and reliability have reached a stage where the present Si-based power devices cannot cope with the growing demand and would usually require large, costly cooling systems and output filters to meet the requirements of the application. Wide bandgap (WBG) power semiconductor materials such as silicon carbide (SiC), gallium nitride (GaN), and diamond (Dia) have recently emerged in the commercial market, with superior material properties that promise substantial performance improvements and are expected to gradually replace the traditional Si-based devices in various power electronics applications. WBG power devices can significantly improve the efficiency of power electronic converters by reducing losses and making power conversion devices smaller in size and weight. The aim of this paper is to highlight the technical and market potential of WBG semiconductors. A detailed short-term and long-term analysis is presented in terms of cost, energy impact, size, and efficiency improvement in various applications, including motor drives, automotive, data centers, aerospace, power systems, distributed energy systems, and consumer electronics. In addition, the paper highlights the benefits of WBG semiconductors in power conversion applications by considering the current and future market trends. Full article

Hexagonal BN (h-BN) has emerged as an important ultrawide bandgap (UWBG) semiconductor (E_g~6 eV). The crystal growth technologies for producing semi-bulk crystals/epilayers in large wafer sizes and understanding of defect properties lag decades behind conventional III-nitride wide bandgap (WBG) semiconductors. Here we report probing of boron vacancy (V_B)-related defects in freestanding h-BN semi-bulk wafers synthesized by hydride vapor phase epitaxy (HVPE). A photocurrent excitation spectroscopy (PES) was designed to monitor the transport of photoexcited holes from deep-level acceptors. A dominant transition line at 1.66 eV with a side band near 1.62 eV has been directly observed, which matches well with the calculated energy levels of 1.65 for the V_B-H deep acceptor in h-BN. The identification of V_B complexes via PES measurement was further corroborated by the temperature-dependent dark resistivity and secondary ion mass spectrometry measurements. The results presented here suggested that it is necessary to focus on the optimization of V/III ratio during HVPE growth to minimize the generation of V_B-related defects and to improve the overall material quality of h-BN semi-bulk crystals. The work also provided a better understanding of how V_B complexes behave and affect the electronic and optical properties of h-BN. Full article

To preserve the structural integrity of power semiconductor devices, ensuring a reliable connection between wide-bandgap (WBG) chips and their substrates at temperatures above 200 °C is crucial. Therefore, easily processable chip-attach materials with high bonding strengths at high temperatures should be developed. Herein, we determined the optimal pre-heating conditions of chip-attach materials to achieve highly reliable WBG semiconductor devices. Sintering with silver-coated copper (Cu@Ag) particle paste was investigated as a model system for chip attachment in electric power devices. After printing the paste onto a direct-bonded ceramic substrate and placing the Si chip on the paste, the pre-heating process was conducted at 50 and 70 °C for different periods of time. Finally, the samples were sintered at a pressure of 9 MPa at 250 °C in an N₂ atmosphere for 1 h. The quality of the obtained Cu@Ag joints significantly varied depending on the pre-heating temperature and time. When Cu@Ag joints were pre-heated at 50 °C, more reliable and reproducible bonding was achieved than at 70 °C. In particular, high-quality sintered joints were obtained with a pre-heating time of 4 min. However, after excessive pre-heating time, cracks and voids were generated impacting negatively the performance of the sintered joints. Full article

This paper presents a comprehensive review on the employment of wide bandgap (WBG) semiconductor power devices in wind energy conversion systems (WECSs). Silicon-carbide- (SiC) and gallium-nitride (GaN)-based power devices are highlighted and studied in this review, focusing on their application in the wind energy system. This is due to their premium characteristics such as the operation at high switching frequency, which can reduce the switching losses, and the capability to operate at high temperatures compared with silicon (Si)-based devices. These advantages promote the replacement of the conventional Si-based devices with the WBG semiconductor devices in the new modular converter topologies due to the persistent demand for a more-efficient power converter topology with lower losses and smaller sizes. The main objective of this paper was to provide a comprehensive overview of the WBG power devices commercially available on the market and employed in the modular converter topologies for renewable energy systems. The paper also provides a comparison between the WBG power technologies and the traditional ones based on the Si devices. The paper starts from the conventional modular power converter topology circuits, and then, it discusses the opportunities for integrating the SiC and WBG devices in the modular power converters to improve and enhance the system’s performance. Full article
