Photonics, Volume 10, Issue 9 (September 2023) – 112 articles

The analysis reported in this paper shows that the homogeneous sensitivity of both fundamental rib waveguide modes, HE₀₀ and EH₀₀, can slightly exceed the sensitivity of the optimized parent slab waveguide. The most crucial difference in the behavior of these two polarizations is that the sensitivity of the HE₀₀ mode is the maximum for strip waveguides. In contrast, the sensitivity of the EH₀₀ mode can either decrease monotonically or not-monotonically with increasing rib height or behave like a homogeneous sensitivity characteristic of the slab waveguide’s EH₀ mode. The second important conclusion comes from comparing the sensitivity characteristics with the distributions of the fundamental mode’s optical power. Namely, the homogeneous sensitivity of the rib waveguide is at the maximum if, due to a slight variance in the cover refractive index, a variation in the weighted optical power carried by the mode is the maximum. Full article

In order to meet the requirements of dynamic monitoring from a bird’s eye view for typical rapidly changing processes such as mechanical rotation and photoresist exposure reaction, we propose a vertical high-speed Mueller matrix ellipsometer that consists of a polarization state generator (PSG) based on the time-domain polarization modulation and a polarization state analyzer (PSA) based on division-of-amplitude polarization demodulation. The PSG is realized using two cascaded photoelastic modulators, while the PSA is realized using a six-channel Stokes polarimeter. On this basis, the polarization effect introduced by switching the optical-path layout of the instrument from the horizontal transmission to the vertical transmission is fully considered, which is caused by changing the incidence plane. An in situ calibration method based on the correct definition of the polarization modulation and demodulation reference plane has been proposed, enabling the precise calibration of the instrument by combining it with a time-domain light intensity fitting algorithm. The measurement experiments of SiO₂ films and an air medium prove the accuracy and feasibility of the proposed calibration method. After the precise calibration, the instrument can exhibit excellent measurement performance in the range of incident angles from 45° to 90°, in which the measurement time resolution is maintained at the order of 10 μs, the measurement accuracy of Mueller matrix elements is better than 0.007, and the measurement precision is better than 0.005. Full article

In the present investigation, commercially pure titanium is welded to AISI 316L stainless steel by intermixing niobium as filler material in a lap joint configuration. For this purpose, a pulsed Nd:YAG laser with various pulse durations and pulse peak powers is employed to obtain different mixing conditions for the materials. It will be demonstrated that, despite the implementation of the filler material, the weld seams are characterized by a high affinity for cracking, which in turn can be attributed to the formation of hard intermetallic compounds. Nevertheless, utilization of optimized process parameters can yield crack-free specimens in a reproducible manner through equable intermixing of otherwise critical alloy elements. Lap-shear forces of up to 140 N can be achieved with a single weld seam measuring 2.5 mm in length. By increasing the joint area with four adjacent weld seams, maximum loads up to 320 N are attained, thus exceeding the yield strength of the applied stainless steel. Considering the biocompatibility of the niobium filler material used, this work provides the foundation for this dissimilar material combination to be implemented in future medical technology applications. Full article

Developing fast-response liquid crystals (LCs) is an essential way to achieve low cost, high resolution, and good visual experience for augmented reality (AR) displays. In this paper, we optimized one new nematic LC mixture SNUP01 to meet the requirements of fast-response phase-only liquid crystal on silicon (LCoS) devices in AR displays. The photoelectric performance of this new LC mixture and three commercial LC mixtures were further comparatively evaluated, and the 2π phase-change response speed of this new LC mixture was extrapolated. The research results indicate that SNUP01 possesses high birefringence, moderate dielectric anisotropy, low viscoelastic coefficient, low activation energy, and high figure of merit values. When using this LC mixture at 25 °C @ λ = 633 nm, a 2π phase change can be achieved at 5 V with a total response time of up to millisecond response. Widespread applications of this LC mixture for AR displays are foreseeable. Full article

The supercontinuum generation and manipulation of Airy-Gaussian pulses in a photonic crystal fiber with three zero-dispersion points are studied using the split-step Fourier method. Firstly, the spectral evolution of Airy-Gaussian pulses in four photonic crystal fibers with different barrier widths was discussed, and the optimal fiber was determined after considering the factors of width and flatness. By analyzing the mechanism of supercontinuum generation in photonic crystal fibers with single, double and three zero-dispersion points, it is found that the photonic crystal fiber with three zero-dispersion points have a larger spectral width due to the component of tunneling solitons. Then, the effects of four characteristic parameters (truncation factor a, distribution factor χ₀, initial chirp C and central wavelength λ) on forming the supercontinuum spectrum of Airy-Gaussian pulses are analyzed in detail. The results show that the spectral width and energy intensity of the dispersive wave and tunneling soliton generation can be well controlled by adjusting the barrier width and initial parameters of the pulse. These research results provide a theoretical basis for generating and manipulating high-power mid-infrared supercontinuum sources. Full article

Three different stimulated Brillouin scattering (SBS) configurations in perfluorooctane were experimentally compared to achieve the ultimate compression of ~1.1 ns pulses from a commercially available Nd:YAG mini-laser. These schemes contained either a focusing lens and a plane feedback mirror, a spherical mirror, or variable pulse splitting to provide self-seeding of the SBS. In the optimal configuration with a focusing lens and return mirror, 93 ps pulses with an energy of 9.5 mJ were achieved at the output of the double-pass phase-conjugated Nd:YAG amplifier. The resulting diffraction-free, high-quality beams with M²~1.2 and excellent pointing stability are of practical interest for scientific, medical, and industrial applications. Full article

The modulation accuracy of Multi-Plane Light Conversion (MPLC) mainly depends on the positioning accuracy of the phase mask on the Spatial Light Modulator (SLM). To improve positioning accuracy, the impact of phase mask shift on modulation accuracy is investigated, and a position method is proposed. In order to investigate the influence of phase mask offset on the input light conversion effect, a convolution transmission model for the adjustable multi-pass cavity is established. Then, the positioning process for the phase masks is analyzed and simulated, and a method of positioning the phase masks is presented. This method reduces the positioning time and increases the positioning accuracy to 8 μm. Finally, experiments are performed to verify the feasibility of the method. Experimental results show that the similarity of the adjustable multi-pass cavity positioned by this method can reach 93.44%. Full article

The X-ray free-electron laser oscillator (XFELO) has received significant attention due to its ability to produce fully coherent, high-brightness, and highly stable X-ray beams. Despite these advantages, the operation of the XFELO can be impeded by the surrounding environment. Specifically, vibrations of the optical components within the cavity can lead to poor alignment, which can diminish the interaction between the light and electrons in the undulator. Consequently, the quality of the output X-rays may be compromised. This study aims to investigate the impact of mirror vibrations on the output laser at various vibration frequencies. Firstly, we develop three single-frequency vibration models at 10 Hz, 0.01 MHz, and 1.1 MHz to investigate the changes in energy, spectral width, beam size, and beam divergence angle of the output laser. Secondly, we build a more complex multi-frequency vibration model based on the single-frequency one to simulate the realistic vibration of the mirror. Finally, we utilize the multi-frequency vibration model to investigate the tolerance limits of the output laser to vibration amplitude at different vibration frequencies of the mirror. The results show that the tolerance of the amplitude near the low and middle frequencies has less effect on the output power, which is approximately 250 nrad or more. However, in certain particular instances, particularly in the vicinity of the resonant frequency, there will be deviations from the tolerance limit. These deviations can result in values that are excessively high or excessively low. The study could prove useful in the future installation of XFELOs. Full article

Single-phase samples of the Ba_1−xCe_xF_2+x solid solution (x = 0.3–0.4) were synthesized by directional crystallization in the form of single crystals and by co-precipitation from aqueous nitrate solutions using potassium fluoride as a fluorinating agent in the form of nanopowders. The cathodoluminescence of the pressed powder samples was studied in comparison with the BaF₂: Ce single crystals in 250–460 nm (2.7–5 eV) spectral range upon excitation by an electron accelerator. The cathodoluminescence spectra of the samples revealed a wide band in the range of 3.0–4.0 eV, which consists of two typical components of Ce³⁺ with decay time 23 ns in the case of single crystals and three decay times 27 ns, 140–170 ns, and ~600 ns in the case of pressed powders. The decay time of the short-wavelength component (27 ns) in the case of pressed powders is close to the lifetime of the excited state of the Ce³⁺ ion. The developed X-ray phosphors can be applied for embedding in diamonds for diamond–nanoparticle composite preparation. Full article

The frequency-swept laser (FSL) is applied widely in various sensing systems in the scientific and industrial fields, especially in the light detection and ranging (Lidar) area. However, the inherent nonlinearity limits its performance in application systems, especially in the broadband frequency-swept condition. In this work, from the perspective of data-driven control, we adopt the reinforcement learning-based broadband frequency-swept linearization method (RL-FSL) to optimize the control policy and generate the modulation signals. The nonlinearity measurement system and the system simulator are established. Since the powerful learning ability of the reinforcement learning algorithm, the linearization policy is optimized off-line and the generated modulation signals reduce the nonlinearity almost 20 times, compared to the case without control. In the long-term operation, the regular updated modulation signals perform better than the traditional iteration results, demonstrating the efficiency of the proposed data-driven control method in application systems. Therefore, the RL-FSL method has the potential to be the candidate of optical system control. Full article

This paper presents the results of studying the process of laser formation of microstructures from silver nanoparticles in nanoporous quartz glasses. Glass samples were impregnated with organometallic molecules Ag(hfac)COD in a supercritical carbon dioxide environment. The formation of point and linear microstructures was carried out by high-frequency (70 MHz) femtosecond laser radiation with a wavelength of 525 nm and energy in the pulse up to 1 nJ. It was found that the formation of microstructures occurs due to photo- and thermal decomposition of precursor molecules with the formation of plasmonic silver nanoparticles. It is shown that the developed temperatures can exceed the melting point of glass, which leads to the appearance of microstructures with altered refractive index. A qualitative model explaining the individual stages of cluster formation in the glass volume under point laser impact is presented. Full article

Wide-range crystal spectrometers are important tools for performing X-ray spectroscopic measurements of medium- and high-Z tracer elements in research on laser-driven inertial confinement fusion (ICF) plasmas. In this paper, we propose a wide-range high-resolution crystal spectrometer based on a tandem array of crystals that have the same geometric parameters. We have developed a three-channel crystal spectrometer that covers the range of 8–18 keV by combining Ge<311>, Ge<331>, and Ge<531> crystals. Here, we report the design, optical simulations, and X-ray test experiments of this spectrometer. The calibration results indicate that the spectral resolution E/ΔE is greater than 2800 at 8.048 keV. By selecting appropriate Bragg angles, crystal materials, orientations, or other geometrical parameters, the wide-range crystal spectrometer developed in this paper can also be used to make measurements in other energy ranges. Full article

This paper proposes a novel method to improve the anti-dispersion ability of the all-optical orthogonal frequency division multiplexing (AO-OFDM) system. By replacing the Sinc-shaped filter with a Gauss-shaped filter for sub-carrier generation and inserting a cyclic prefix (CP), the impact of dispersion on the system can be significantly mitigated. Formula derivation and numerical analysis of the pulse-shaping function of the AO-OFDM system in the time domain for each cycle indicated that the pulse-shaping function generated by the Gauss-shaped filter was less affected by the dispersion effect than that of the Sinc-shaped filter. Meanwhile, less inter-carrier crosstalk between carriers was also observed. After carrying out system transmission simulations employing these two different filters, we found that the AO-OFDM system based on the Gauss-shaped filter could greatly improve the anti-dispersion ability compared with the system based on a Sinc-shaped filter. When the parameter settings in both schemes were identical, that is, the number of subcarriers was 32 and the power of a single subcarrier was −13 dBm, the bit error rate (BER) of the system based on the proposed Gauss-shaped filter after 60 km SMF transmission was only 1.596 × 10⁻³, while the BER of the traditional Sinc-shaped filter based system scheme was as high as 8.545 × 10⁻². Full article

Twist sensors have emerged as crucial tools in the field of structural health monitoring, playing a significant role in monitoring and ensuring the integrity of critical infrastructure such as dams, tunnels, bridges, pipelines, and buildings. We proposed and demonstrated an all-fiber in-line twist sensor which was based on a capillary fiber spliced between two single-mode fibers with a transverse offset. Through a series of experiments, the sensor’s performance was evaluated and quantified. The results showcased remarkable twist sensitivities in both clockwise and anticlockwise directions. With a transverse offset of 8.0 µm, the sensor exhibited twist sensitivities of −0.077 dB/° and 0.043 dB/° in the clockwise and anticlockwise directions, respectively, in the measured twist range from 0 to 90°. Furthermore, it was also demonstrated that the sensor was temperature insensitive at the chosen wavelength of 1520 nm, which can assist in increasing measurement accuracy. Our sensor’s low cost, simplicity of manufacture, and improved performance will push forward its adoption in future engineering applications such as structural health monitoring in dams, tunnels, and buildings. Full article

In the last decade, terahertz (THz) technologies have been introduced to the detection, identification, and quantification of biomolecules in various biological samples. This review focuses on substances that represent important biomarkers in the urine associated with various cancers and their treatments. From a diagnostic point of view, urine liquid biopsy is particularly important because it allows the non-invasive and rapid collection of large volumes of samples. In this review, the THz spectral responses of substances considered metabolic biomarkers in urine and obtained in previous studies are collected. In addition, the findings from the relatively small number of prior studies that have already been carried out on urine samples are summarised. In this context, we also present the different THz methods used for urine analysis. Finally, a brief discussion is given, presenting perspectives for future research in this field, interpreted based on the results of previous studies. This work provides important information on the further application of THz techniques in biomedicine for detecting and monitoring urinary biomarkers for various diseases, including cancer. Full article

Equiprobable incoherent mixtures of two totally polarized states of light whose associated three-dimensional Jones vectors are mutually orthogonal are called discriminating states and constitute a peculiar type of state that plays a key role in the characteristic decomposition of a generic state into a totally polarized state, a totally unpolarized state, and a discriminating state. In general, discriminating states are three-dimensional, in the sense that the strengths of the three components of the electric field are nonzero for any Cartesian reference frame considered. In the limiting case that the electric field evolves in a fixed plane, the discriminating state is said to be regular and corresponds to a two-dimensional unpolarized state. The special features of discriminating states cover, e.g., their possible synthesis from infinite pairs of mutually orthogonal states as well as their transverse spin. The nature and properties of discriminating states are comprehensively analyzed based on their associated intrinsic Stokes parameters, which leads to meaningful interpretations in terms of the associated polarization ellipsoids and spin vectors. Full article

Underwater LED light sources are commonly implemented in array configurations with a wide-angle field of view, primarily catering to high-speed communication within a few meters. To increase transmission distance and mitigate oceanic turbulence effects, this paper focuses on the spatial coherence analysis of narrow-beam partially coherent light-emitting diode (PCLED) arrays, examining their average light intensity distribution, beam width, and spatial coherence during oceanic transmission. Based on the extended Huygens–Fresnel integral, the optical field models and spatial characteristics of the radial PCLED array are derived under oceanic conditions, considering parameters such as water attenuation coefficient, kinetic energy dissipation rate, temperature dissipation rate, temperature-to-salinity ratio, as well as the radial filling factor and the sub-beam spatial coherence length of the light source at different transmission distances. The simulations show that, as the spatial coherence length of the sub-beam decreases from hundreds to a few micrometers, the combining distance of the beam arrays also decreases. This reduction in coherence results in the average light intensity distribution degrading into a Gaussian-like distribution, with a significant five-fold decrease in peak intensity. Furthermore, the width of the array spreads, starting from distances of 7 m and 0 m, respectively. The radial PCLED beam array, with its sub-beam spatial coherence length inside micrometers, possesses inherent characteristics that suppress turbulence effects and has future extensive possibilities in the ocean. Full article

We have demonstrated efficiency of employing the ABCD matrix approach to transform higher-order structured Laguerre–Gaussian (sLG) beams into structurally stable astigmatic sLG (asLG) beams, highlighting their dynamics at propagating. Radical transformations of the beam structure by a cylindrical lens form not only orbital angular momentum (OAM) fast oscillations and bursts, but also make the asLG beams structurally unstable in propagation through cylindrical and spherical lenses when focusing paraxially. But, if the spherical lens performs a Fourier transform of the asLG beam after a cylindrical lens, the symmetric beam emerges at the lens focal plane with a sharp OAM dip; then, the OAM restores its former astigmatism, becoming structurally stable at the far diffraction domain. By investigating the beam structure at the focal area, we have showed that the OAM sharp dip is associated with nothing less than the process of dividing the OAM into the vortex and astigmatic constitutes predicted by Anan’ev and Bekshaev. Full article

Conventional solar-pumped lasers rely on expensive and highly accurate solar tracking systems, which present a significant economic barrier to both solar laser research and practical applications. To address this challenge, an end-side-pumped four-rod solar laser head was designed and built for testing at PROMES-CNRS. Solar radiation was collected and concentrated using a heliostat–parabolic mirror system. A fused silica aspheric lens further concentrated the solar rays into a flux homogenizer within which four Nd:YAG rods were symmetrically positioned around a reflective cone and cooled by water. Four partially reflective mirrors were precisely aligned to extract continuous-wave 1064 nm solar laser power from each laser rod. The prototype demonstrated stable multibeam solar laser operation with the solar tracking system turned on. Even when the tracking system was turned off, the total output power extracted from the solar-pumped laser remained stable for 1 min, representing, to the best of our knowledge, the first successful demonstration of a stable multibeam solar laser operation without solar tracking. For typical solar tracking errors up to ±0.5°, the loss in the total solar laser power produced was only about 1%, representing an 8.0-fold improvement over the previous solar laser experiments under tracking error conditions. Full article

This paper investigates the routing, modulation, and spectrum assignment (RMSA) problem for advance reservation (AR) requests in semi-filterless optical networks (semi-FONs). A link resource-aware (LRA) algorithm consisting of three parts is proposed. First, in the request scheduling phase, a request sorting strategy based on the flexible window size of the starting time is proposed. This strategy schedules AR requests based on the size of a flexible window with respect to the starting time. Next, in the routing phase, a link resource-aware strategy is proposed. This strategy evenly distributes the requests across the network resources, thereby avoiding request blocking due to excessive resource occupation on a single or few links. In the spectrum assignment phase, a frequency–time block-based metric is employed to measure the availability of each frequency–time block for AR requests. This metric is a sum of two factors: the distance to the block and spectrum boundaries, and the time interval between the request start time and the earliest start time. Our simulation results demonstrate that the proposed LRA algorithm has a lower blocking probability compared to the benchmark algorithms. Full article

As is known, quasi-periodicity attracts great attention in many scientific regions. For instance, the discovery of the quasicrystal was rewarded the Nobel Prize in 2011, leading to a series of its applications. However, in the area of manipulating optical fields, the two-dimensional quasi-periodicity is rarely considered. Here, we study the two-dimensional quasi-periodic diffraction properties of the scalar and vector optical fields based on the Penrose tiling, which is one of the most representative kinds of two-dimensional quasi-periodic patterns. We propose type-A and type-B Penrose tiling masks (PTMs) with phase modulation, and further show the diffraction properties of the optical fields passing through these masks. The intensity of the diffraction field holds a tenfold symmetry. It is proved that the iteration number n of the PTM shows the “weeding” function in the diffraction field, and this property is useful in filtering, shaping, and manipulating diffraction fields. Meanwhile, we also find that the diffraction patterns have the label of the Golden ratio, which can be applied in areas such as optical encryption and information transmission. Full article

In this work, studies are carried out in the field of optical singular beams that have passed through gyrotropic crystals. We have experimentally shown that singular beams with a helical intensity distribution are formed when passing through a system of two gyrotropic crystals with opposite values of the gyration coefficient. It is shown that the system is capable of generating optical vortices with a double topological charge in one of the components of circular polarization when light propagates through two gyrotropic crystals. Full article

We have fabricated planar interdigitated photodetectors exhibiting high responsivity. These detectors are based on thin layers of methylammonium lead bromide (MAPbBr₃) at 90 nm thickness. MAPbBr₃ thin films were first characterized on glass (borosilicate) substrates using absorption and photoluminescence measurements showing a high absorption edge at 521 nm and strong emission at 530 nm, as expected. MAPbBr₃ thin films were then deposited on top of interdigitated electrodes, hence producing planar photodetectors with responsivity up to 0.4 A/W. Such higher performances were attributed to the interdigitated design, low crack density (0.05 µm⁻²), and lower resistivity (20 MΩ.cm) compared to MAPbBr₃ single crystal. Therefore, this work highlights MAPbBr₃ thin films as very promising for photodetection applications. Full article

Filterless optical networks (FONs) have become a cost-effective solution for optical network deployment due to their low-cost characteristics. However, eliminating active switching elements causes signals to propagate over unintended links, wasting spectral resources. Therefore, semi-filterless optical networks (Semi-FONs) have become a more cost-effective solution. This paper mainly studies the routing, modulation, and spectrum assignment (RMSA) problem in semi-filterless optical networks. It proposes a single–multi-path combination (LR-SMPC) RMSA algorithm with the least resource consumption. The algorithm first obtains the K shortest paths that satisfy the conditions according to the K short path (KSP) algorithm and re-orders the paths according to the resource consumption path re-ordering strategy, selecting the three paths that consume the least resources as the set of candidate paths. Then, based on the single–multi-path combination scheme of the set of candidate paths, the resource consumption of each scheme and the maximum number of available spectrum blocks for each path is calculated, from which the single path or multi-path with the least resource consumption is selected to serve the request. We perform simulation experiments on two network topologies using Poisson traffic models and compare them with existing single-path algorithms (S-P), fixed spectrum assignment granularity algorithms (g = 1), and adaptation spectrum assignment algorithms (g adaptation) to evaluate the performance of the proposed algorithm. The simulation results show that the proposed algorithm exhibits better performance in terms of both blocking rate and spectrum utilization. Full article

Structured light beams have recently attracted enormous research interest for their unique properties and potential applications in optical communications, imaging, sensing, etc. Since most of these applications involve the propagation of structured light beams, which is accompanied by the phenomenon of diffraction, it is very necessary to employ diffraction theories to analyze the obstacle effects on structured light beams during propagation. The aim of this work is to provide a systematic summary and comparison of the scalar diffraction theories for structured light beams. We first present the scalar fields of typical structured light beams in the source plane, including the fundamental Gaussian beams, higher-order Hermite–Gaussian beams, Laguerre–Gaussian vortex beams, non-diffracting Bessel beams, and self-accelerating Airy beams. Then, we summarize and compare the main scalar diffraction theories of structured light beams, including the Fresnel diffraction integral, Collins formula, angular spectrum representation, and Rayleigh–Sommerfeld diffraction integral. Finally, based on these theories, we derive in detail the analytical propagation expressions of typical structured light beams under different conditions. In addition, the propagation of typical structured light beams is simulated. We hope this work can be helpful for the efficient study of the propagation of structured light beams. Full article

The geometric visualization in this study concerns the three−dimensional (3D) polarimetric information of an arbitrary electromagnetic field. Based on previous research, a 3 × 3 coherency matrix Φ can be decomposed into an incoherent superposition of a totally 3D−polarized component Φ_{3D_p}, a specific partially 3D−polarized component Φ_{3D_pp} with a 3D degree of polarization (DoP) of 1/2, and a totally 3D−unpolarized component Φ_{3D_up}. Combining the physical meaning of this decomposition, we mathematically construct three polarization purities, namely, P_{3D_p}, P_{3D_pp}, and P_{3D_up}, for an arbitrary electromagnetic field to quantify the weight of the three 3D−polarized components. In order to show the proportion of the three polarized components of an electromagnetic field intuitively, we propose a geometric representation of a spatially quadric surface. Finally, two examples are cited to demonstrate the applicability of intuitively displaying the 3D polarimetric information of an arbitrary electromagnetic field. Full article

The piston error has a significant effect on the imaging resolution of the optical sparse aperture system. In this paper, an improved phase diversity method based on particle swarm optimization and the sequential quadratic programming algorithm is proposed, which can overcome the drawbacks of the traditional phase diversity method and particle swarm optimization, such as the instability that results from polychromatic light conditions and premature convergence. The method introduces factor β in the stage of calculating the objective function, and combines the advantages of a heuristic algorithm and a nonlinear programming algorithm in the optimization stage, thus enhancing the accuracy and stability of piston detection. Simulations based on a dual-aperture optical sparse aperture system verified that the root mean square error obtained by the method can be guaranteed to be within 0.001λ (wavelength), which satisfies the requirement of practical imaging. An experimental test was also conducted to demonstrate the performance of the method, and the test results showed that the quality of the image after piston detection and correction improved significantly compared to images with the co-phase error. Full article

Leveraging their unique phase modulation characteristics, birefringent waveplates have been widely used in various optical systems. With the development of material science and manufacturing techniques, the polarization properties of waveplates have become increasingly complex and diverse. Among these properties, the field-of-view effect of the waveplate caused due to manufacturing defects or improper installation procedures is extremely difficult to calibrate and seriously affects the precision and accuracy of the relevant optical systems. In this paper, a calibration method that can compensate for the field-of-view effect of waveplates installed in the instrument is proposed. Moreover, to approve the fidelity of the proposed calibration method, a series of film thickness measurement experiments are carried out. The results show that under different installation conditions of the waveplates, the precision and accuracy of the film thickness measured with the proposed method significantly improved. This method can be expected to reduce the assembly difficulty of such optical systems, while also improving their accuracy and stability. Full article

This paper proposes a non-common-view axis alignment method for the alignment requirements of airborne laser communication systems. The system consists of a ground transmitting end and an airborne relay terminal. The ground transmitting end uses a camera and a pan-tilt for image tracking, while the airborne relay end uses a two-dimensional mirror to control the beam to achieve non-common-view axis alignment between the transmitting and receiving sides. The working principle and process of both the transmitter and receiver of the non-common-view axis alignment system for airborne laser communication were compared with traditional wireless optical alignment methods. The design process of the two-dimensional mirror used in this paper is introduced, the scanning trajectory of the two-dimensional mirror is simulated and analyzed according to the beam scanning principle, and the field experiment link is set up to carry out the airborne laser communication experiment. The experimental results show that when the link distance is 10 m, the tracking errors of the system in the azimuth and pitch directions are 19.02 µrad and 22.35 µrad respectively, and the amplitude of the electrical signal output by the signal detector is 84.0 mV; When the link distance is 20 m, the tracking errors of the system in the azimuth and pitch directions are 39.66 µrad and 33.94 µrad respectively, and the amplitude of the electrical signal output by the signal detector is 23.0 mV. Using this method, the alignment can be completed without data return, and the establishment of the reverse link can also be realized while the transmission link is quickly established, and there is no need for an air stability platform. The feasibility of the application of the non-common-view axis alignment method to the airborne laser communication system is verified. Full article

Phase measurement profilometry (PMP) is primarily employed to analyze the morphology of a functional surface with precision. Historically, one of the most complex and persistent challenges in PMP has been reducing errors stemming from inconsistent indicators at the edges of a surface. In response to this challenge, we propose an optimized error compensation methodology specifically designed to handle edge artefacts. This methodology introduces the Hilbert transform and object surface albedo as tools to detect the edges of the artefact region that need to be compensated. Moreover, we analyze the characteristics of the sinusoidal fringe waveform propagation direction and investigate the reconstruction results of the fringe vertical to the current directions to compensate for edge artefacts. The experimental results for various objects show that the optimized approach can compensate for edge artefacts by projecting in two directions and reducing the projection by half. The compensated root mean square error (RMSE) for planar objects can be reduced by over 45%. Full article
