As human activities increasingly encroach on ecologically sensitive lake zones, China’s lake-ring urban agglomerations struggle to balance the intensifying human footprint (HF) and declining habitat quality (EQ). Addressing the spatiotemporal interactions between HF and EQ is essential for achieving human–environment coordination. This study examined five major freshwater lake-ring urban agglomerations in China during the period from 2000 to 2020 and developed an HF–EQ assessment framework. First, the coupling coordination degree (CCD) model quantified the spatiotemporal coupling between HF and EQ. Second, GeoDetector identified how HF and EQ interact to influence CCD. Finally, the four-quadrant static model and CCD change rate index formed a dual-dimensional management framework. The results indicate that the spatiotemporal evolution patterns of HF and EQ are highly complementary, exhibiting a significant coupling interaction. High-CCD zones expanded from lakeside urban areas and transport corridors, while low-CCD zones remained in remote, forested areas. HF factors such as GDP, land use intensity, and nighttime lights dominated CCD dynamics, while EQ-related factors showed increasing interaction effects. Five human–environment coordination zones were identified based on the static and dynamic characteristics of HF and EQ. Synergy efficiency zones had the highest coordination with diverse land use. Ecological conservation potential zones were found in low-disturbance hilly regions. Synergy restoration zones were concentrated in croplands and urban–rural fringe areas. Imbalance regulation zones were in forest areas under development pressure. Conflict alert zones were concentrated in urban cores, transport corridors, and lakeshore belts. These findings offer insights for global human–environment coordination in lake regions. Full article

In gravitational wave measurement and inter-satellite laser communication systems, the relative rotation and motion between the transmitter and receiver terminals introduces small angular deviations over a link distance of thousands of kilometers, which need to be measured with high accuracy and sensitivity. The heterodyne coherent angle measurement has a higher measurement accuracy and detection sensitivity compared with the traditional direct detection technique, which performs angle measurement through the phase of a beat frequency signal. In this paper, we propose a four-quadrant heterodyne coherent angle measurement technique with μrad accuracy and nW-level detection sensitivity. A mathematical model of a differential wavefront sensing (DWS) angle solution was formulated, and a Monte Carlo simulation system was built for performance testing. An experimental system was devised to assess the accuracy and sensitivity of the heterodyne coherent measurement method and to compare the performance with that of the direct detection method. The experimental results showed that for azimuth and pitch axes, the accuracy of the heterodyne coherent angle measurement was 2.54 μrad and 2.85 μrad under the same signal power of −16 dBm, which had a 5-fold improvement compared with direct detection. The sensitivity of the heterodyne coherent detection was −50 dBm at the 20 μrad accuracy threshold, which was a 1000-fold improvement compared with direct detection. This research is of great significance for the phase measurement and tracking system in the field of gravitational wave detection and has a guiding role in system design work in the field of inter-satellite laser communication. Full article

The four-quadrant detector (4QD), as a highly sensitive and fast-response position-sensitive device, is widely used in laser guidance, target tracking, and related fields. However, traditional visible and infrared 4QDs exhibit significant vulnerability to ambient light interference, particularly under high-intensity background illumination. To address this issue, this paper presents a solar-blind ultraviolet (UV) 4QD and a spot positioning system based on AlGaN diodes, achieving a UV/visible suppression ratio of 2.17 × 10⁴ (without solar-blind filters). The system employs a high-linearity, low-noise capacitive transimpedance amplifier (CTIA) as the readout circuit for the high-sensitivity and rapid-response solar-blind UV detectors, enabling the precise conversion of weak photocurrent signals into voltage signals for digitization. Utilizing a third-order polynomial least-squares fitting algorithm without introducing complex filtering techniques, the system achieves a maximum positioning error of 0.0101 mm and a root-mean-square error (RMSE) of 0.0057 mm, among of one the best-performing solar-blind UV 4QDs. The experimental results demonstrate exceptional spot positioning performance under a 275 nm laser source, meeting the high-precision requirements for space target detection. This research provides a reference for the application of solar-blind UV 4QDs in positioning, alignment, and monitoring scenarios, thereby holding significant practical implications. Full article

In space laser communication, the wide divergence angle of beacon light leads to substantial spatial losses, compounded by background light and detector noise; this results in compromised precision in the detection of the beacon light position. To solve this problem, a high-precision detection technique and communication composite technology employing a four-quadrant detector (QD) with beacon spread-spectrum modulation are proposed. Pseudo-random sequences (PRNs) are employed to spread the beacon communication spectrum, with the spread-spectrum signal utilized to modulate the intensity of the transmitted beacon light at the transmitter end. At the receiver, QD photocurrent signals are cross-correlated with an identical PRN that is used for modulation. The strong auto-correlation properties of PRNs, which are uncorrelated with noise, enhance the output signal-to-noise ratio (SNR), enabling precise position detection and beacon communication under high-SNR conditions. Theoretical analysis is used to explore the effects of spreading gain on the sensitivity of system detection and the precision of position detection. The experimental results demonstrate that the beacon spread-spectrum modulation scheme effectively detects the position of the light spot. At a received optical power of −37 dBm and spreading sequence PRN depths of 1023, 127, and 31, the root-mean-square error (RMSE) values are 0.983 μm, 2.876 μm, and 7.275 μm, respectively. This corresponds to improvements of 14.96 dB, 10.29, dB, and 6.26 dB compared to direct detection precision (30.811 μm). Additionally, under an identical signal bandwidth, the sensitivity improves by 14.6 dB, 10.1 dB, and 6.4 dB, respectively. The proposed beacon spread-spectrum scheme mitigates the limitations of hardware reception sensitivity and position-detection precision, demonstrating its potential application in high-precision detection in long-distance interstellar laser communication. Full article

This work presents a novel multielectrode array (MEA) to quantitatively assess the dose enhancement factor (DEF) produced in a medium by embedded nanoparticles. The MEA has 16 nanocrystalline diamond electrodes (in a cell-culture well), and a single-crystal diamond divided into four quadrants for X-ray dosimetry. DEF was assessed in water solutions with up to a 1000 µg/mL concentration of silver, platinum, and gold nanoparticles. The X-ray detectors showed a linear response to radiation dose (r² ≥ 0.9999). Overall, platinum and gold nanoparticles produced a dose enhancement in the medium (maximum of 1.9 and 3.1, respectively), while silver nanoparticles produced a shielding effect (maximum of 37%), lowering the dose in the medium. This work shows that the novel MEA can be a useful tool in the quantitative assessment of radiation dose enhancement due to nanoparticles. Together with its suitability for cells’ exocytosis studies, it proves to be a highly versatile device for several applications. Full article

To achieve a lightweight design and wide field of view for the automatic alignment system in wireless optical communication, in the receiving antenna—a fisheye lens is incorporated as the receiving optical system. This feature enables the detection and tracking of lasers. The system utilizes a micro motor as the control servo system and a four-quadrant detector as the detection unit. Sequential and non-sequential ray tracing techniques were used to simulate the analysis of the fish-eye lens. Point array diagrams, ray trace diagrams, and encircled energy analysis were utilized to evaluate the spot’s quality. The simulation results demonstrate that the fish-eye lens has a field of view of 120°, and the spot with 80% energy has a diameter smaller than 30 μm. The experimental results indicate that the fish-eye lens effectively captures the light beam within the range of ±30°. The simulated and experimental results for the sum and difference frequency amplitudes show good agreement. The outdoor experiments have demonstrated a tracking error of 22.757 μrad in this system. After alignment, the average output optical power of the detector is 3.23 μW, and the detected waveform amplitude is 12.48 mV. These findings demonstrate the system’s potential for automatic alignment in wireless optical communication. Additionally, the system is relatively simple and practical. Full article

Laser-spot-location detection technology based on photodetectors is widely used in the aerospace, medical, military and communication fields. However, most of the current research focuses on continuous laser detection in the visible and near-infrared bands, and the real-time high-precision position detection of a long-wave infrared pulsed laser is lacking. In this paper, a spot-position detection system based on a four-quadrant detector is designed for a 10.6 μm CO₂-driven laser in extreme ultraviolet light source, and a second-order extended error compensation algorithm based on a Gaussian-spot model is proposed. Finally, the algorithm is verified and analyzed experimentally by a spot-position detection system under both focusing and defocusing conditions. The experimental results show that the root-mean-square error, maximum absolute error and average absolute error of the second-order error compensation algorithm are significantly reduced compared with the traditional algorithm, and the detection accuracy of the spot-position is better than 9 μm. The above results show that this spot-position detection system has obvious advantages and high accuracy, which can realize the high-precision real-time detection of a laser’s spot position to obtain accurate spot position information, provide feedback adjustments for subsequent beam pointing control, and provide a theoretical basis for the beam pointing stability of the extreme ultraviolet light source system. Full article

LaBr${}_3$:Ce crystals have good scintillation properties for X-ray spectroscopy. Initially, they were introduced for radiation imaging in medical physics with either a photomultiplier or SiPM readout, and they found extensive applications in homeland security and gamma-ray astronomy. We used 1${}^{″}$ round LaBr${}_3$:Ce crystals to realize compact detectors with the SiPM array readout. The aim was a good energy resolution and a fast time response to detect low-energy X-rays around 100 keV. A natural application was found inside the FAMU experiment, at RIKEN RAL. Its aim is a precise measurement of the proton Zemach radius with impinging muons, to contribute to the solution to the so-called “proton radius puzzle”. Signals to be detected are characteristic X-rays around 130 KeV. A limit for this type of detector, as compared to the ones with a photomultiplier readout, is its poorer timing characteristics due to the large capacity of the SiPM arrays used. In particular, long signal falltimes are a problem in experiments such as FAMU, where a “prompt” background component must be separated from a “delayed” one (after 600 ns) in the signal X-rays to be detected. Dedicated studies were pursued to improve the timing characteristics of the used detectors, starting from hybrid ganging of SiPM cells; then developing a suitable zero pole circuit with a parallel ganging, where an increased overvoltage for the SiPM array was used to compensate for the signal decrease; and finally designing ad hoc electronics to split the 1${}^{″}$ detector’s SiPM array into four quadrants, thus reducing the involved capacitances. The aim was to improve the detectors’ timing characteristics, especially falltime, while keeping a good FWHM energy resolution for low-energy X-ray detection. Full article

Optical readout of large scale dual-phase liquid Argon TPCs is an attractive alternative to charge readout and has been successfully demonstrated on a 2 × 2 m active region within the CERN protoDUNE cold box. ARIADNE${}^{+}$ uses four Timepix3 cameras imaging the S2 light produced by 16 novel, patent pending, glass THGEMs. ARIADNE⁺ takes advantage of the raw Timepix3 data coming natively 3D and zero suppressed with a 1.6 ns timing resolution. Three of the four THGEM quadrants implement readouts in the visible light range through wavelength shifting, with the fourth featuring a VUV light intensifier, thus removing the need for wavelength shifting altogether. Cosmic ray reconstruction and energy calibration were performed. Presented is a summary of the detector setup and experimental run, preliminary analysis of the run data and future outlook for the ARIADNE program. Full article

Studying the relationship between human activities and soil erosion on a regional scale is of great significance for macro-decision-making in soil erosion prevention and control. The entropy weight method and RUSLE model are used to analyze the spatiotemporal variation in human activity intensity (HAI) and soil erosion in the Weihe River Basin (WRB) from 2005 to 2020. Through geographic detectors and a four-quadrant model, the impact of various driving factors and the coupling degree of the human–land relationship are studied. The results showed: (1) During the past 15 years, the moderate, high, strong, and severe erosion areas in the WRB decreased by 9.88%, 35.89%, 45.17%, and 70.05%, respectively. The ratio of the historical sand transport modulus to the RUSLE model result is 0.83, indicating that the results obtained by the RUSLE model can be used for further analysis. (2) Slight and weak degrees account for 80% in the northwest region. The high and strong regions are mainly distributed in the Shaanxi section, accounting for 3% of the total basin. (3) The coupling between human activities and soil erosion is constantly strengthening, and the joint effect of pop and crop is the main reason for the slowdown and spatial differences in soil erosion. This indicates that the ecological environment became stable. These findings contribute by acting as references for soil and water conservation and management in the WRB to promote a harmonious relationship between humans and the environment. Full article

Examining and assessing the characteristics of innovation networks among science and technology firms at the city level is essential for comprehending the innovation patterns of cities and improving their competitiveness. Nevertheless, the majority of studies in this field solely rely on patent and paper data, neglecting the analysis of networks across diverse scales and dimensions. Websites offer a novel platform for companies to exhibit their products and services, and the utilization of hyperlink data better captures the dynamics of innovative cooperation. Thus, to attain a more realistic and precise comprehension of China’s technology enterprise cooperation networks, enhance the understanding of intra-city and cross-border cooperation within innovation networks, and offer more scientific guidance to cities in enhancing their innovation capabilities by investigating the factors influencing innovation scenarios and the mechanisms of their interactions, this study constructs an innovation network based on the hyperlink data extracted from Chinese science and technology enterprises’ websites in 2022. It explores the network’s inherent characteristics and spatial patterns across multiple dimensions and scales. Additionally, it employs GeoDetector to analyze the driving factors behind the heterogeneity of city quadrants across each dimension. The findings suggest the following: (1) Evident polarization of innovation capability exists, with a more pronounced differentiation of cities between high capability zones. (2) Contrary to the conventional notion of geographical proximity, cross-region website cooperation prevails, with cross-provincial cooperation being more prevalent than intra-provincial cross-city cooperation. (3) Enterprise cooperation tends to align with partners of similar scale, and small and medium-sized enterprises primarily engage in internal cooperation, primarily concentrated in second and third-tier cities. (4) Cities with high degree centrality and structure holes are primarily located in the construction areas of Chinese urban agglomerations, while those with low degree centrality and structure holes are situated near double-high cities. (5) The spatial heterogeneity of innovation networks across the four dimensions is primarily influenced by STI, while cooperation intensity and innovation capacity dimensions are strongly influenced by traffic capacity. The intra- and inter-city cooperation intensity dimensions are significantly impacted by administrative grade, and the enterprise scale and network location dimensions are most affected by the level of digital infrastructure. Full article

The polymerase chain reaction is an important technique in biological research because it tests for diseases with a small amount of DNA. However, this process is time consuming and can lead to sample contamination. Recently, real-time PCR techniques have emerged which make it possible to monitor the amplification process for each cycle in real time. Existing camera-based systems that measure fluorescence after DNA amplification simultaneously process fluorescence excitation and emission for dozens of tubes. Therefore, there is a limit to the size, cost, and assembly of the optical element. In recent years, imaging devices for high-performance, open platforms have benefitted from significant innovations. In this paper, we propose a fluorescence detector for real-time PCR devices using an open platform camera. This system can reduce the cost, and can be miniaturized. To simplify the optical system, four low-cost, compact cameras were used. In addition, the field of view of the entire tube was minimized by dividing it into quadrants. An effective image processing method was used to compensate for the reduction in the signal-to-noise ratio. Using a reference fluorescence material, it was confirmed that the proposed system enables stable fluorescence detection according to the amount of DNA. Full article

A combined tip-sample scanning architecture can improve the imaging speed of atomic force microscopy (AFM). However, the nonorthogonality between the three scanners and the nonideal response of each scanner cause measurement errors. In this article, the authors systematically analyze the influence of the installation and response errors of the combined scanning architecture. The experimental results show that when the probe in the homemade high-speed AFM moves with the Z-scanner, the spot position on the four-quadrant detector changes, thus introducing measurement error. Comparing the experimental results with the numerical and theoretical results shows that the undesired motion of the Z-scanner introduces a large error. The authors believe that this significant error occurs because the piezoelectric actuator not only stretches along the polarization direction but also swings under nonuniform multifield coupling. This article proposes a direction for further optimizing the instrument and provides design ideas for similar high-speed atomic force microscopes. Full article

An electromagnetic immune Free Space Optical Communication (FSOC) system for an Unmanned Aerial Vehicle (UAV) command and control link is introduced in this paper. The system uses the scheme of omnidirectional receiving and ground scanning transmitting. It has a strong anti-turbulence ability by using a large area detector and short-focus lens. The design of omnidirectional communication improves the ability of anti-vibration and link establishment. Pure static reception has no momentum effect on the platform. The receiver is miniaturized under no use of a gimbal mirror system, beacon camera system, Four-Quadrant Photodetector (QPD) and multi-level lens system. The system can realize omnidirectional reception and the communication probability in 1 s is greater than 99.99%. This design strengthens the ability of the FSOC system, so it can be applied in the UAV command and control, the satellite submarine communication and other occasions where the size of the platform is restricted. Full article

The need for tissue contact makes photoacoustic imaging not applicable for special medical applications like wound imaging, endoscopy, or laser surgery. An easy, stable, and contact-free sensing technique might thus help to broaden the applications of the medical imaging modality. In this work, it is demonstrated for the first time that remote photoacoustic sensing by speckle analysis can be performed in the MHz sampling range by tracking a single speckle using a four quadrant photo-detector. A single speckle, which is created by self-interference of surface back-reflection, is temporally analyzed using this photo-detector. Phantoms and skin samples are measured in transmission and reflection mode. The potential for miniaturization for endoscopic application is demonstrated by fiber bundle measurements. In addition, sensing parameters are discussed. Photoacoustic sensing in the MHz sampling range by single speckle analysis with the four quadrant detector is successfully demonstrated. Furthermore, the endoscopic applicability is proven, and the sensing parameters are convenient for photoacoustic sensing. It can be concluded that a single speckle contains all the relevant information for remote photoacoustic signal detection. Single speckle sensing is therefore an easy, robust, contact-free photoacoustic detection technique and holds the potential for economical, ultra-fast photoacoustic sensing. The new detection technique might thus help to broaden the field of photoacoustic imaging applications in the future. Full article
