Search Results (46)

This paper presents Enhanced Voltage Sensorless Control for PWM converter with DSOGI-FLL under grid disturbances. Even without grid voltage sensors, the proposed method accurately estimates the grid angle and voltage, which are necessary for power transfer between the DC link of the PWM converter and the grid. The estimated grid voltage obtained through observer design is separated into positive and negative sequence components, and the grid frequency is estimated using the Dual Second-Order Generalized Integrator Quadrature Signal Generator (DSOGI-QSG) and Dual Second-Order Generalized Integrator Frequency-Locked Loop (DSOGI-FLL). The estimated positive and negative sequence voltages were effectively controlled using a dual current controller. The method operates effectively under normal, balanced AC source conditions and in various grid fault scenarios, including unbalanced voltage, harmonic distortion, voltage sag, and frequency step changes. The validity of the proposed method was evaluated through experimental results by using a grid simulator to implement the fault condition. Full article

Grid-connected photovoltaic (PV) systems require a power converter to extract maximum power and deliver high-quality electricity to the grid. Traditional control methods, such as proportional-integral (PI) control for DC-link voltage regulation, often struggle under abnormal operating conditions, resulting in voltage fluctuations and instability in the maximum power point tracker (MPPT). This paper proposes a synergistic control strategy that combines a musical chairs algorithm (MCA) MPPT with sliding mode control (SMC) together for the boost converter DC-link control. This approach enhances DC-link voltage stability by switching the MPPT to SMC of the boost converter when the DC-link voltage exceeds the predefined limit. This strategy enhances the stability of the DC-link voltage and allows for a smaller DC-link capacitor, thereby reducing system cost and improving the power quality of PV systems. A phase-locked loop (PLL) further ensures effective grid synchronization. The reduction in DC-link voltage overshoot (from 570 V to 522 V) improved stability under varying irradiance conditions. Moreover, a 48 V reduction in overshoot voltage and a 66% decrease in DC-link voltage ripple (standard deviation from 17.93 V to 5.92 V) occurred. Simulation and experimental results demonstrate the superiority of the proposed strategy compared to the case without coordination between the DC-DC converter and inverter controllers, particularly under challenging conditions. Full article

Grid-connected photovoltaic (PV) systems inject nonsinusoidal currents into the grid at the point of their connection. The technology of the inverter utilized for the conversion of DC power into AC is directly associated with distortion characteristics. Even though pulse-width-modulated (PWM) converters generate considerably lower harmonic distortion than their predecessors, they are responsible for the emergence of a new power quality issue in distribution grids known as supraharmonics, which can cause problems such as overheating and malfunctions of equipment. PV systems are known sources of supraharmonics, but their impact has not yet been thoroughly researched. Due to the multitude of parameters affecting their performance, a more rigorous treatment is required compared to more common nonlinear devices. In this paper, emissions from a three-phase grid-connected PV system are examined by means of a dedicated simulation tool taking into account the specifics of inverter switching action without overly increasing computational cost. The impact of environmental parameters as well as factors affecting the switch control of the converter is investigated. The dependence of the supraharmonic emission of the PV system on the converter characteristics rather than environmental conditions is demonstrated. Furthermore, simulation studies on a network comprising the PV system and an additional supraharmonic-emitting system in simultaneous operation are conducted. Their combined effect on the distortion at the connection point of the network to the grid is assessed by means of a power flow-based approach, capable of quantifying interactions within this network. From the viewpoint of the grid, an increase of supraharmonic-related disturbance at low irradiance conditions is revealed. Full article

Aiming at the problem that silicon-controlled rectifiers (SCR) and pulse width modulation (PWM) rectifiers cannot balance high power levels, high hydrogen production efficiency, and high grid connected quality in the current research on rectifier power supplies for electrolytic hydrogen production, a new hybrid rectifier topology based on a modular multilevel converter (MMC) is proposed. The hybrid topology integrates a silicon-controlled rectifier (SCR) with an auxiliary power converter, wherein the SCR is designated as the primary power source for electrolytic hydrogen production. The auxiliary converter employs a cascaded modular multilevel converter (MMC) and an input-series-output-parallel (ISOP) phase-shifted full-bridge (PSFB) arrangement. This configuration allows the auxiliary converter to effectively mitigate AC-side harmonics and minimize DC-side ripple, concurrently transmitting a small amount of power. The effectiveness of the hybrid rectifier in achieving low ripple and harmonic distortion outputs was substantiated through hardware-in-the-loop experiments. Notably, the hybrid topology is characterized by its enhanced electric-to-hydrogen conversion efficiency, elevated power density, cost efficiency, and improved grid compatibility. Full article

In response to the high performance requirements of pulse width modulation (PWM) converters in grid-connected power systems, H-Infinity (H∞) control has attracted significant research interest due to its robustness against parameter variations and external disturbances. In this work, an advanced robust H∞ control is proposed for a grid-connected three-phase PWM rectifier. A two-level control strategy is adopted, where cascaded H∞ controllers are designed to simultaneously regulate the DC bus voltage and input currents even under load disturbances and non-ideal grid conditions. As a result, unit power factor, stable DC bus voltage, and sinusoidal input currents with lower harmonics can be accurately achieved. The design methodology and stability of the proposed controller are verified through a comprehensive analysis. Simulation tests and experimental implementation on a dSPACE 1103 board demonstrate that the proposed control scheme can effectively enhance disturbance rejection performance under various operating conditions. Full article

Aiming at the problems of large power fluctuations and poor stability in photovoltaic and other new energy power generation systems, a step-up multiport converter (MPC) that can simultaneously connect low-voltage photovoltaic cells, batteries, and loads (independent loads or power grids) is proposed in this manuscript. According to the possible operating conditions of the system, the working principles are described in detail. Theoretical analysis based on different working modes is presented and a hybrid modulation control method including pulse width modulation (PWM) and phase shift modulation (PSM) are applied to realize energy transmission between photovoltaics, batteries, and power grids. A simulation model is built in the PSIM environment to validate each working state of the system and mode switching function. Experiments are carried out on an experimental platform using the dsPIC33FJ64GS606 digital microcontroller as the control center, and the experimental results successfully verify the system function and PWM + PSM control efficiency. Full article

In order to effectively mitigate the issue of frequent fluctuations in the output power of a PV system, this paper proposes a working mode for PV and energy storage battery integration. To address maximum power point tracking of PV cells, a fuzzy control-based tracking strategy is adopted. The principles and corresponding mathematical models are analyzed for the three-phase voltage PWM converter and bidirectional DC/DC converter, while feedforward decoupling double closed loop, constant power (PQ), and constant voltage charge/discharge control strategies are proposed. Space vector pulse width modulation (SVPWM) technology is utilized to generate power switching tube driver signals. Finally, a simulation model is developed in MATLAB/Simulink for system analysis. The results demonstrate that the proposed method enables constant grid-connected power generation and constant voltage charging of the energy storage battery when the PV cell’s power generation exceeds that of the grid. When insufficient solar power generation occurs, both the PV system and energy storage battery work together to achieve constant grid-connected power. Full article

To propel us toward a greener and more resilient future, it is imperative that we adopt renewable sources and implement innovative sustainable solutions in response to the escalating energy crisis. Thus, renewable energies have emerged as a viable solution to the global energy crisis, with photovoltaic energy being one of the prominent sources in this regard. This paper represents a significant step in the desired direction by focusing on detailed, comprehensive dynamic modeling and efficient control of photovoltaic (PV) systems as grid-connected energy sources. The ultimate goal is to enhance system reliability and ensure high power quality. The behavior of the suggested photovoltaic system is tested under varying sun radiation conditions. The PV system is complemented by a boost converter and a three-phase pulse width modulation (PWM) inverter, with MATLAB software employed for system investigation. This research paper enhances photovoltaic (PV) system performance through the integration of model-predictive control (MPC) with a high-gain DC–DC converter. It improves maximum power point tracking (MPPT) efficiency in response to the variability of solar energy by combining MPC with the traditional incremental conductance (IN-C) method. Additionally, the system incorporates a DC–AC converter for three-phase pulse width modulation, which is also controlled by predictive control technology supported by Particle Swarm Optimization (PSO) to further enhance performance. PSO was selected due to its capability to optimize complex systems and its proficiency in handling nonlinear functions and multiple variables, making it an ideal choice for improving MPC control performance. The simulation results demonstrate the system’s ability to maintain stable energy production despite variations in solar irradiation levels, thus highlighting its effectiveness. Full article

With the increasing number of new energy sources connected to the grid, the unbalanced output of three-phase grid-connected inverters and the lack of no inertia and damping characteristics in the traditional microgrid control system will seriously affect the stability of voltage, frequency, and power angle for microgrids. This paper proposes a novel cascaded three-phase bridge inverter topology for the battery system used for the electric vehicle. Compared with traditional cascaded H-bridge inverters, the proposed multilevel inverter can achieve self-adaptive balance for three phases. The mathematical model of a cascaded three-phase bridge inverter is established in this paper. Based on the voltage and current equations of a multilevel inverter, a new modulation strategy named carrier phase-shifted-distributed pulse width modulation (CPSD-PWM) was developed, which is more suitable for cascaded three-phase bridge inverters. The harmonic analytic equations of carrier phase-shifted pulse width modulation (CPS-PWM) and CPSD-PWM are constructed by the double Fourier analysis method. Compared with the traditional PWM modulation strategy, the CPSD-PWM can reduce the output harmonics and improve the balance of the three-phase output, which can realize the three-phase adaptive balance in the cascaded three-phase bridge inverter. This paper develops a cascaded three-phase bridge multilevel power converter system based on the virtual synchronous generator (VSG) control strategy. The voltage and frequency of inverter output can be accurately controlled in both island mode and grid-connected mode through active power-frequency regulation and reactive power–voltage regulation, and the stability of primary frequency regulation for the multilevel microgrid inverter can be improved by collaborative optimization of virtual inertia and virtual damping. The CPSD-PWM modulation strategy and VSG control strategy are verified by the simulation results and experimental data for the cascaded three-phase bridge inverter. Full article

This paper proposes a method for minimizing the inductor current ripple of a DC–DC converter in a two-stage power conversion system consisting of a grid-connected PWM converter and an interleaved multiphase three-level DC–DC converter. To reduce the output voltage ripple, the three-level DC–DC converter is configured in parallel and operated interleaved. However, a circulating current generated by the interleaved operation increases the inductor current ripple of each DC–DC converter and causes system loss and inductor saturation. In this paper, the inductor and output current ripple of the interleaved three-phase three-level DC–DC converter is mathematically analyzed and the effect of the DC–DC converter’s duty ratio and output voltage on each current ripple is described. Based on this analysis, a method is proposed for controlling the optimal DC link voltage through the PWM converter, so that the DC–DC converter is controlled with the duty ratio that minimizes the inductor current ripple. The simulation and experimental results under various operating conditions are presented to verify the feasibility of the proposed control method. Full article

The issue of converted voltage distortion by high-power converters at pulse-width modulation (PWM) with a low switching frequency of semiconductor modules is still relevant. Currently, the Programmed Pulse Pattern PWM (PPWM) technique is used extensively that allows pre-eliminating the selected harmonics from the converter’s voltage and current spectrum or reducing them to meet the voltage quality standard requirements. A review of scientific publications has shown the insufficiency of available studies on defining and estimating the impact of powerful converters with PPWM. The problem of defining the amplitudes of higher harmonics generated by a converter with PPWM, which are the main cause of electronic equipment failures at the common grid connection point, is particularly relevant. This study considers the behavior of the NPC converter voltage and current spectra at PPWM with the selected harmonic elimination (SHE) for three-level (3L) voltage waveforms. The behavior of up to the 50th non-eliminated harmonics in the NPC converter voltage and current spectra is first shown for a modulation factor changing within 0–1.15 at the pitch of 0.01 for six different SHE PPWM: no. 1–5 and 7; no. 2–5, 7, 11, and 13; no. 3–5, 7, 11, 13, 17, and 19; no. 4–5, 7, 11, 13, 17, 19, 23, and 25; no. 5–5, 7, 11, 13, 17, 19, 23, 25; 29, and 31; no. 6–5, 7, 11, 13, 17, 19, 23, 25, 29, 31, 35, and 37. The concept proposed herein allows measuring the current consumed amplitudes of NPC converter with SHE PPWM at the low average error of about 6%. The adequacy of the approach used herein to determine the current harmonic amplitudes has been experimentally verified with laboratory equipment. The results are consistent with engineering accuracy. The research work is promising for further study and estimation of the impact of the NPC converter SHE PPWM for more complex multi-pulse grid connection circuits and resonance phenomena. Full article

This study developed a grid-connected biogas power generation system for a rural community using a 3-phase 2.2 kW squirrel-cage induction machine as the self-excited induction generator. The generator was driven by a 196 cc single-cylinder spark-ignition engine fueled by biogas. We developed a back-to-back converter that consists of a 3-phase PWM rectifier as the generator-side converter and a single-phase LCL-filtered grid-connected inverter. The generator-side converter transferred the active power to the grid-side converter and supplied the reactive power control back to the generator. The notch filter-based bus voltage control on the generator side mitigated the inter-harmonics in the generator current. The injected grid current complied with the IEEE 1547 standard because of the multi-frequency unbalanced synchronous reference frame control. The proposed system was validated with biogas produced from pig manure at a pig farm in central Thailand, which found a maximum output of 1.2 kW with a thermal system efficiency of 10.7%. The proposed system was scheduled to operate at 1.2 kW for 8 h per day with a levelized cost of 0.07 US$/kWh, 42% cheaper than the retail electricity price, and a payback period of 2.76 years. The proposed system is suitable for a farm with a minimum of 34 pigs. Full article

Grid-connected converters (GCCs) are used extensively for the integration of DC power sources with AC power sources. However, since it is a complex topic, there are many possibilities for regulating grid-injected currents, as well as different modulation techniques for generating full-bridge PWM voltages. The control techniques are directly related to the type of output filter, as well as to the topology of the converter, since a complex plant can require more sophisticated controllers to keep the system stable, and with good regulation performance. Furthermore, a discussion of the applicability of these converters in weak and very weak grids with high inductance content has recently been growing, which adds a greater degree of complexity to the control structure of the converter. In this brief overview are outlined some topics about topologies, output filters, and control, focusing on the current regulation of grid-connected converters. In addition, a discussion of the main challenges and critical areas in operating on weak and very weak grids is also presented. Full article

The efficiency of renewable energy sources like PV and fuel cells is improving with advancements in technology. However, maximum power point (MPP) tracking remains the most important factor for a PV-based fuel cell power system to perform at its best. The MPP of a PV system mainly depends on irradiance and temperature, while the MPP of a fuel cell depends upon factors such as the temperature of a cell, membrane water content, and oxygen and hydrogen partial pressure. With a change in any of these factors, the output is changed, which is highly undesirable in real-life applications. Thus, an efficient tracking method is required to achieve MPP. In this research, an optimal salp swarm algorithm tuned fractional order PID technique is proposed, which tracks the MPP in both steady and dynamic environments. To put that technique to the test, a system was designed comprised of a grid-connected proton exchange membrane fuel cell together with PV system and a DC-DC boost converter along with the resistive load. The output from the controller was further tuned and PWM was generated which was fed to the switch of the converter. MATLAB/SIMULINK was used to simulate this model to study the results. The response of the system under different steady and dynamic conditions was compared with those of the conventionally used techniques to validate the competency of the proposed approach in terms of fast response with minimum oscillation. Full article

Inverters with Quasi-Z-Source Networks (QZSN) provide DC-DC boosting and DC-AC conversion in a single stage. It offers reduced cost, complexity, and volume compared with the classical two-stage conversion system, which is composed of a boost converter followed by a Voltage-Source-Inverter (VSI). Further, QZSI provides superior conversion characteristics for single-stage grid-connected photovoltaic transformerless systems. However, the absence of galvanic isolation in these systems makes it possible to allow leakage current through these systems’ parasitic capacitances due to the high-frequency Common-Mode Voltage (CMV) generated by the Pulse Width Modulation (PWM) nature of the inverter output voltages. As a result of this current, critical safety issues may arise with PV systems. Many PWM techniques have been presented in recent years for QZSIs. This paper is intended to provide a comprehensive analysis and review study of the characteristics of most of these PWM techniques in terms of CMV and leakage currents. In this study, closed-form equations have been derived to determine the effective CMV and leakage current analyses for all modulation techniques. Analytical and simulation approaches are used to identify schemes with the lowest CMV and current leakage effects. Moreover, the experimental setup is presented by applying the Simple-Boost Modified Space Vector Modulation (SB-MSVM) technique. Full article
